ALEXANDER ROSE ARL-371 User manual

ALEXANDER ROSE ASSURANCE OF QUALITY
Left Chair Left Side Frame
Left Chair Right Side Frame
Top Shelf
Bottom Shelf
Right Chair Left Side Frame
Right Chair Right Side Frame
Seat Assembly x 2
Back Assembly x 2
Hardware Bag
Assembly Instructions
Model Number
Garden Centre Purchased From: Purchase Date:
Other Comments:
Home Address:
Present In Parcel Quality Checked
Date
Trial Assembly Made
Yes No
Signed
Inspector NumberContract Number
ARL-371 PINE COMPANION SET
ASSEMBLY INSTRUCTIONS
ROSE LTD
ALEXANDER
AFFIX
POSTAGE
STAMP
FOLD 2
TAPE THIS EDGE
FOLD 1
Thank you for choosing to buy Alexander Rose garden furniture. We are confident that you will be pleased
with the quality of the product. To ensure that the highest standards are maintained, please help us by
completing this short questionnaire.
For information on all our products including treatments
available please visit our web site: www.alexander-rose.co.uk
Thankyou for taking the time to complete and return this
questionnaire and for choosingAlexander Rose.
Condition of Packaging
Condition of Product
Ease of Assembly
PoorGood Average
(Tick Boxes)
READ IN FULL BEFORE COMMENCING ASSEMBLY
This product is very heavy. Take care when lifting.
TWO PEOPLE are required for assembly of this product.
Product Information
Maintenance
Your furniture is manufactured using FSC Pine from Europe. It has been treated with preservative to
protect against decay, giving a life span in excess of ten years.
The swing seat will have knots and other natural features in the timber.
Under normal circumstances Pine cracks; this is due to these natural characteristics, and will not
compromise the strength of your swing seat, which is designed with this in mind.
We strongly recommend a once yearly application of a water repellent preservative such as Cuprinol or
similar, to protect against fungal attack and blackening of the wood. Alternatively, use our timber sealer
available fromAlexander Rose stockists.
Your furniture can be cleaned using soapy water and a stiff brush, allowing it to dry fully before the
application of any timber treatment. More severe stains such as spillages, bird droppings and mildew
etc. can be removed by the use of our cleaner, which is available from all Alexander Rose stockists.
Alternatively, sand using a medium grit sandpaper.
Alexander Rose Ltd.
Alexander House
Victoria Road
BURGESS HILL
West Sussex
RH15 9LE
Ref. ARL-371 - Pine Companion Set -08-02-08
Ref. ARL-371 - Pine Companion Set -08-02-08
!
I

Identify Components
H
G
A
I
I
F
B
E
1
F
C
I
C
E
D
E
I
2
Before starting to assemble your furniture, identify and
count all components for your chosen model, as shown in
the table and drawings below. In the unlikely event that
any components are missing or damaged, please contact
the retailer where you purchased this product.
PLEASE RETAIN THESE ASSEMBLY INSTRUCTIONS FOR FUTURE REFERENCE.
Attach Shelves
Attach Second Chair
Fix Seat Assemblies
Assemble Chairs
Attach the two shelves again noting that the short edges are to the
front and the batons are on the underside. Secure using Two 45mm
bolts for the Top shelf and Two 35mm wood screws for Bottom .
Attach the second chair to the shelves and secure using two
45mm bolts for top shelf and two 35mm wood screws for bottom
shelf. Tighten using the Allen key provided. Turn the companion
set upright noting the important safety advice given below. The
assembly is now complete.
Screw SeatAssemblies (F) to side frames on both
chairs using four 35mm wood screws (K) per chair
Attach side frames to back and seat assemblies
using six 70mm allen bolts per chair.
This companion set is
and requires
to turn it into the
upright position.
VERY
HEAVY TWO
PEOPLE
IMPORTANT
SAFETY NOTE
SHORT EDGE TO TOP
33
J
K
KK
J
J
5
6
6
K
3
4
Code Description
A Left Chair Left
Side Frame
B Left Chair Right
Side
C Right
Back Assembly
F Seat Assembly
G Top Shelf
H
J
K 35mm woodscrews
Frame
Chair Left
Side Frame
D Right Chair Right
Side Frame
E
Bottom Shelf
I 6 x 70mm Allen Bolts
6 x 45mm Allen Bolts
L 4mm Allen Key
Qty.
1
1
1
1
2
2
1
1
12
4
12
1
I
