Alfain aXe 201 MIG LCD User manual

ALFA IN a.s. © www.alfain.eu aXe 201 MIG LCD manual EN 01
WELDING MACHINE
aXe 201 MIG LCD
OPERATING MANUAL

2/30
ALFA IN a.s. © www.alfain.eu
CONTENT
1. INTRODUCTION.................................................................................... 3
2. SAFETY INSTRUCTIONS AND WARNINGS......................................... 4
3. OPERATING CONDITIONS................................................................... 5
4. TECHNICAL DATA................................................................................. 7
5. MACHINE ACCESSORIES .................................................................... 8
6. DESCRIPTION OF THE MACHINE AND FUNCTIONS........................ 11
7. MAIN MENU......................................................................................... 15
8. MACHINE PREPARATION FOR MIG/MAG METHOD......................... 19
9. MACHINE PREPARATION FOR TIG METHOD................................... 26
10. MACHINE PREPARATION FOR MMA METHOD................................. 27
11. ROUTINE MAINTENANCE & INSPECTION......................................... 28
12. SERVICE.............................................................................................. 29
13. ELECTRIC WASTE DISPOSAL ........................................................... 30
14. WARRANTY LIST ................................................................................ 30

3/30
ALFA IN a.s. © www.alfain.eu
Introduction
Congratulations on your new ALFA IN product. We are proud to have you as our
customer and will strive to provide you with the best service and reliability in the
industry.
This Operating Manual was designed to instruct you on your ALFA IN product's
correct use and operation. Your satisfaction with this product and its safe
operation is our ultimate concern. Therefore, please take the time to read the
entire manual, especially the Safety Precautions. They help you avoid potential
hazards when working with this product.
The machine complies with the appropriate CE mark.
For maintenance and repairs, use only original spare parts. There is, of course,
a complex of our services.
The model of aXe 201 MIG LCD is multi-functional inverter power generator
welding by the methods:
a) MIG/MAG in 2T, 4T, manually or synergistically with wires G3Si1 or
stainless steel 0,6 - 1,0 mm, Al wires 1,0 mm, flux cored wires shelf
shielding or standard.
b) E –(MMA) coated electrodes up to 4,0 mm
c) TIG lift arc
S
The machine can be used for welding in areas with elevated danger of electric
shock.
We reserve the law of adjustments and changes in case of printing errors,
changes of technical parameters, accessories, etc., without previous notice.
These changes may not be reflected in the manuals for paper or electronic form.

4/30
ALFA IN a.s. © www.alfain.eu
1. SAFETY INSTRUCTIONS AND WARNINGS
PERSONAL PROTECTION
1. For safety reasons, protective gloves must be worn during welding. These
gloves protect you from electric shock (circuit voltage at no load). It also
protects you from heat radiation and splashing drops of hot metal.
2. Wear sturdy insulated shoes. Open shoes are not suitable, as drops of hot
metal can cause burns.
3. Do not look into the welding arc without face and eye protection. Always
use a high-quality welding helmet with an intact protective filter.
4. Ensure that the insulation of the torch and grounding cable is in good
condition.
5. Persons near the welding site must also be informed of the danger and
provided with protective equipment.
6. When welding, especially in small spaces, it is necessary to ensure a
sufficient supply of fresh air, as welding produces harmful emissions.
7. Do not perform welding work on gas, oil, fuel, etc. Tanks (even empty ones)
as there is a risk of explosion.
8. Special regulations apply in potentially explosive atmospheres.
9. Welded joints that are subject to high stress must meet special safety
requirements. These are mainly rails, pressure vessels, etc. These joints
may only be made by qualified, trained welders with the necessary
authorization.
SAFETY REGULATIONS
1. Before starting work with the welding machine, getting acquainted with the
provisions in EN 050601 –Safety provisions for metal welding and the
standard EN 050630 –Safety provisions for arc welding of metals is
necessary.
2. The CO2 bottle of mixed gases must be handled following the regulations
for working with pressure vesselscontained in EN 07 8305and EN 078304.
The requirements of EN 07 8304 may limit the size of the gas bottle that
can be placed on the machine platform.
3. The welder must use protective equipment.
4. Disconnect the device from the mains before working on the electrical
system, cleaning it, or removing the cover.

5/30
ALFA IN a.s. © www.alfain.eu
2. OPERATING CONDITIONS
1. The device may only be operated by trained personnel within the technical
regulations. The manufacturer is not liable for damage caused by improper
use and operation. Only use original spare parts from ALFA IN for
maintenance and repairs.
2. The device complies with IEC 61000-3-12.
3. The welding machine is tested according to the standard for degree of
protection IP 23S, which protects against the intrusion of solids with a
diameter greater than 12 mm and protection against the intrusion of water
falling in a vertical to the oblique direction to a slope of 60˚.
4. Operating ambient temperature between -10 to +40 °C.
5. Relative humidity below 90% at +20 °C.
6. As high as 3000 meters above sea level.
7. Connecting more than one generator in series or parallel is prohibited.
8. The machine must be located so the cooling air can enter and exit through
the cooling vents without restriction. Care must be taken to ensure that no
mechanical particles, especially metal particles, are sucked into the
machine (e.g., during grinding). Cooling is driven by electronic temperature
automation.
9. For the welding machine, it is necessary to perform a periodic inspection
once every 6/12 months by an authorized employee according to EN
331500 and EN 050630 –see paragraph Maintenance and service tests.
10. An authorized person may only carry out all interventions in the
electrical equipment and repairs (disassembly of the mains plug,
replacement of fuses).
11. The manufacturer sets the welding machine to 230 V with a tolerance
range of 110 - 230 V ± 10 %, which allows the operation of the machine in
the mains ~230 V and ~110 V.
12. The relevant mains voltage and power supply must match the mains
plug.
CautionExtension cables must have conductors with cross-
sections larger than 3x2,5 mm2. Welder can be operated on a single-phase
power generator of 8 kVA (1x230V/50Hz) or more, with a voltage
stabilization of ± 15%. Generators with lower power can damage the
machine.
CautionIf the machine is transported from a colder place to a much
warmer location, moisture condensation might occur, particularly inside the
welder. This could decrease electrical strength and increase the likelihood of

6/30
ALFA IN a.s. © www.alfain.eu
electrical short circuits in strained parts. Consequently, severe damage to the
machine may occur. Therefore, allowing the welder to rest for approximately an
hour is vital until the temperature stabilizes with the surroundings. This eliminates
any condensation.Only after this time should you connect the welder to the mains
and switch it on.
13. The stability of the machine is guaranteed up to an inclination of 10°
if the following conditions are met:
a. The machine must be secured against spontaneous movement.
b. A gas cylinder with a maximum height of 0,9 m may be placed on the
platform and properly anchored.
14. The machine must be protected against the following:
a. Moisture, rain, and intense sunlight
b. Mechanical damage
c. Drafts and possible ventilation of neighbouring machines
d. Excessive overloading –exceeding tech. parameters
e. Rough treatment
ELECTROMAGNETIC COMPATIBILITY
Concerning interference suppression, the welding equipment is designed
primarily for industrial premises. It meets the requirements of EN 60974-10
class A and is not intended for use in residential areas where a public low-
voltage power supply network supplies electricity. Possible problems with
ensuring electromagnetic compatibility in these areas may be caused by line
propagation and radiated interference.
The device may be a source of interference during operation.
NoticeWe warn the user that he is responsible for any interference from
welding.

7/30
ALFA IN a.s. © www.alfain.eu
3. TECHNICAL DATA
Method
MIG/
MAG
MMA
TIG
MIG/
MAG
MMA
TIG
Mains voltage
V/Hz
1x110/50-60
1x230/50-60
Welding current range
A
25 - 130
10 - 100
10 - 140
25 - 200
10 - 200
10 - 200
Open-circuit voltage
U20
V
67,0
67,0
Mains protection
A
20 @
16 @
Max. effective current
I1eff
A
17,0
18,0
17,0
14,9
16,0
12,0
Welding current
(DZ=100%) I2
A
85
65
95
130
120
140
Welding current
(DZ=60%) I2
A
110
80
125
150
140
160
Welding current
(DZ=x%) I2
A
30%=
130
30%=
100
35%=
140
30%=
200
25%=
200
35%=
200
Protections
IP 23S
Stand
EN 60974-1, EN 60974-10 cl. A
Dimensions (w x l x h)
generator
mm
474 x 911 x 670
Compact weight
kg
44,5
Wire-speed
m/
min
1,5 - 4,5
---
---
1,5 -
16,5
---
---
Spool diameter
mm
300
---
---
300
---
---
Spool weight
kg
18
---
---
18
---
---
S
The machine marked with this symbol can be used for welding in areas with
an increased risk of electric shock.
The design of the machine is such that in no case, even in the event of a rectifier
failure, is the permissible peak value of the no-load voltage according to EN
60974-1 ed. 3 exceeded, i.e., 113 V DC or 68 V AC.
CautionDue to the size of the installed capacity, the approval of
the distribution companies is required to connect the equipment to
the public distribution network.

8/30
ALFA IN a.s. © www.alfain.eu
4. MACHINE ACCESSORIES
PART OF DELIVERY
Code
Name
5.0318
aXe 201 MIG LCD
VM0151-1
Hose Gas 3m G1/4-G1/4
VM0023
Earthing Cable 3 m 400 A 35mm2
35-50
K910-1
Adapter up to 18 kg
ACCESSORIES TO ORDER
Code
Name
SGB25-3
Torch PARKER SGB 250 3m
(MIG/MAG)
SGB25-4
Torch PARKER SGB 250 4m
(MIG/MAG)
SGB25-5
Torch PARKER SGB 250 5m
(MIG/MAG)
STH24-3
Torch PARKER STH 240AE
3m Hybrid (MIG/MAG)
STH24-4
Torch PARKER STH 240AE
4m Hybrid (MIG/MAG)
STH24-5
Torch PARKER STH 240AE
5m Hybrid (MIG/MAG)

9/30
ALFA IN a.s. © www.alfain.eu
T24ST
Torch T2 4m 35-50 arc ST
(TIG)
T28ST
Torch T2 8m 35-50 arc ST
(TIG)
5847
Set Connectors ST 12 PIN
VM0253
Welding Cable Set 2x 3m 35-
50 200A
Rolls –see an overview of
rolls for wire feed
6008
Pressure Reducer
FIXICONTROL Argon 2
manometers
6124
Pressure Reducer
BASECONTROL Ar 2
manometers
6125
Pressure Reducer
BASECONTROL CO2 2
manometers
S777c.
Welding Helmet Barracuda
S777C Black

10/30
ALFA IN a.s. © www.alfain.eu
S7SUN9B
Welding Helmet S9B Shooting
Shark Blue
4488
Wire 0.8 Coreshield 15 A
D200 Self Shielding 4,5kg
spool
VM0453
Adapter for spool 5kg
5174
Torch holder MIG ALFA IN
V9040095
Wire cleaner - Holder
6050
Set for Aluminium with roll AL
22/30 0,8-1,0 4 rolls
SGL2
Small Gas Lens Body Starter
Kit 1.6mm-1/16"
SGL4
Small Gas Lens Body Starter
Kit 2.4mm-3/32"
SGL5
Small Gas Lens Body Starter
Kit 3.2mm-1/8"
700.0306.10
Electrode wolf.1.6x175-Violet
700.0308.10
Electrode wolf.2.4x175-Violet
700.0310.10
Electrode wolfram E3 3.2x175
- violet

11/30
ALFA IN a.s. © www.alfain.eu
5. DESCRIPTION OF THE MACHINE AND FUNCTIONS
MAIN PARTS OF THE MACHINE
Fig.
1.
Main parts of the machine

12/30
ALFA IN a.s. © www.alfain.eu
Pos.
Name
A1
ON/OFF switch
A2
PCB control panel
A3
Quick connector (+)
A4
Quick connector (-)
A5
Euro connector
A6
Wire feeder
A7
Spool holder
A8
Gas valve
A9
Mains cable
A10
TIG torch control connector
A11
Switch Spool Gun
B1
Euro connector
B2
Euro connector male
B3
Torch
C1
Quick connector male
C2
Grounding clamps
C3
Quick connector (+)
C4
Quick connector (-)
F1
Gas bottle
F2
Cylinder valve
F3
Pressure reducer
F4
High-pressure manometer
F5
Low-pressure manometer
F6
Adjusting screw
F7
Gas outlet
F8
Solenoid valve
F9
Chain

13/30
ALFA IN a.s. © www.alfain.eu
CONTROL PANEL
Fig.
2.
Control panel
Pos.
Description
V1
Encoder
Wire-speed for MIG/MAG
Current for MMA and TIG
V2
MENU button
V3
Display
V4
Welding current and voltage adjustment button
V5
Encoder
Voltage for MIG/MAG
Correction for MMA
DOWN SLOPE for TIG
V6
Main switch

14/30
ALFA IN a.s. © www.alfain.eu
WIRE FEEDER
Fig,
3.
Wire feeder
OVERVIEW OF ROLLS FOR WIRE FEED
ab
4pulley
a = 22 mm
b = 30 mm
Groove type
Wire diameter
Item No
Steel
0,6-0,8
2187
0,8-1,0
2188
Aluminum
0,8-1,0
2270
Flux core
0,8-1,0
2318
1,0-1,2
2319
Pos.
Description
E1
The nut of a pressure arm
E2
Pressure arms
E3
Inlet liner
E4
EURO connector
E5
Roll

15/30
ALFA IN a.s. © www.alfain.eu
6. MAIN MENU
Fig.
4.
Main menu
Press the MENU button V2 to navigate between the submenus.
Pos.
Description
1
Method selection
2
Selection of synergy parameters
3
Setting welding parameters
4
System settings (including language)
5
Icon of the selected function
6
Icon of the selected mode
7
Multi-functional window
8
Synergy parameter (from left: program number, welding wire
material, shielding gas, and wire diameter)

16/30
ALFA IN a.s. © www.alfain.eu
METHOD SELECTION
Select the method by turning and pressing encoder V1 (MIG/MAG Synergy,
MIG/MAG Manual, MMA Electrode, and TIG Lift).
Fig.
5.
Submenu for method selection
With button V4 on the top right panel, you can access the welding current and
voltage settings. You are changing parameters by rotating the encoders V1 and
V5.
Fig.
6.
Welding parameter settings

17/30
ALFA IN a.s. © www.alfain.eu
SELECTION OF SYNERGY PARAMETERS
The synergy parameters submenu is only available when using MIG/MAG
Synergy method. The synergy parameter is selected by rotating and then
pressing encoder V1.
Fig.
7.
Selection of synergy parameters
SETTING OF SECONDARY WELDING PARAMETERS
Parameters select by rotating encoder V1 and pressing encoder V5.
Fig.
8.
Setting of secondary welding parameters

18/30
ALFA IN a.s. © www.alfain.eu
Secondary
welding
parameters
MIG/MAG
welding
parameters
(default)
TIG welding
parameters
(default)
MMA welding
parameters
(default)
2/4 Tact
2T/4T (2T)
2T/4T (2T)
-
Burn Out
0-10 (0)
-
-
Initial Speed
0-10 (0)
-
-
Pregas
0-2 s (0 s)
-
-
Postgas
0-10 s (0 s)
0-10 s (0 s)
-
Choke
0-10 (5)
-
-
Rundown
-
0-10 s (0 s)
-
Hot Start
-
-
0-10 s (0 s)
Arc Force
-
-
0-10 s (0 s)
SYSTEM SETTINGS
Set the parameters by rotating encoder V1 and then pressing encoder V5.
The last position of the System Setup submenu is Factory Reset. Perform a
Factory Reset by pressing encoder V5.
Fig.
9.
System settings submenu

19/30
ALFA IN a.s. © www.alfain.eu
7. MACHINE PREPARATION FOR MIG/MAG METHOD
CHOOSING THE FEEDING ROLL
All machines (ALFA IN MIG / MAG) use rolls with two grooves. These grooves
are intended for two different wire diameters (e.g., 0,8 and 1,0 mm).
Rolls for wire feed must comply with the diameter and material of the welding
wire. Only this way a smooth wire feed can be achieved. Irregularities of the wire
feed lead to poor welding quality and deformation of the wire.
  
ABC
Fig.
10.
The influence of the roll groove on the welding wire
INSERTING THE WIRE
1. Open the side cover of the wire feeder space.
2. Put the wire spool on the wire spool holder D1 and fix it with the fixing nut
D2.
3. Cut off the curved or damaged end of the welding wire, lead it through the
inlet liner E3, and roll it into the liner inside the EURO torch connector
(about 5 cm). Make sure that you use a suitable groove.
4. Put the pressure arm E2 down so that the teeth or the gear fit and fix it by
setting lever E1 vertically.
5. Adjust the pressure nut so that it provides constant movement of the wire
but does not deform it. The adjusting screw is located under the plastic
screw E1. The clamping force of the feed rolls is essential for the reliable
operation of the feeding mechanism. The size of the force depends on the
type of welding wire. For Aluminium or tubular wire, choose a smaller
clamping force. If the clamping force is insufficient, rolls can slip, which
results in the feed speed being irregular. If the contact force is too high, the
mechanical wear of the bearings increases, the pressure mechanism does
not fulfil its protective function, and in case of increased resistance of the
wire feed (damaged or dirty Bowden, baked wire in the feedthrough, etc.),
the slipping does not occur, and there is a risk of the wire being displaced
sideways. In the extreme case, the motor may be blocked entirely, and the
gearbox will be unduly mechanically stressed. The electric motor and the
controller's power output could be overloaded and damaged.
6. Clean the pulleys of preservative oil before starting up.
A
Correct
B
Wrong
C
Wrong

20/30
ALFA IN a.s. © www.alfain.eu
7. The manufacturer sets the spool brake. If necessary, the brake can be
adjusted by a screw D1so that while stopping the feed, the spool is stopped
on time (This avoids the excessive release of wire). However, a too-tight
brake needlessly strains the feeding mechanism, and thus slippage may
occur in the wire rolls.
Fig.
11.
Spool holder
INSERTING THE WIRE TO THE TORCH AND CONNECTION OF THE
GROUNDING CABLE
1. Connect the MIG/MAG torch to the EURO connector A5 on the machine
while the machine is turned off.
2. Connect the grounding cable to the quick connector A4 (-).
3. Connect the grounding clamps to the welder or the welding table.
4. NoticeWhen inserting the wire, do not point with a torch to the eyes!
5. Remove the gas nozzle from the torch.
6. Unscrew the current nozzle.
7. Connect the machine with the mains plug to the 1x230 V/50-60 (1x110
V/50-60) Hz mains and switch it on with the main switch V6 located on the
front panel of the welder.
8. MENU button V2 and encoder V1 select desired MIG/MAG program.
9. In the submenu of welding parameters settings, select two-stroke or four-
stroke.
10. Press the torch button, and the welding wire is fed into the torch. After
the wire has run out of the torch tube, screw in the current pass and gas
nozzle.
11. Before welding, spray the area in the gas nozzle and the jet tube with
a separating spray to prevent the spatter from sticking.
Pos.
Description
D1
Spool Holder
D2
Nut Spool Holder
D3
It is not for this welder
