Alfaled AFR-7 User manual

AFR-7 AFR-7-1
●Apply to dual color LED controller.
Ultra sensitive color adjustment touch w heel.●
●Each remote can match one or more receiver.
● R bC 2032 attery pow ered.
●Operate w ith LED indicator light.
Technical Parameters
Input and Output
W arranty
5 years
W arranty
Operation temperature
Case temperature (Max.)
Environment
IP20
IP rating
Ta: -30
O
C ~+55
O
C
Tc: +85
O
C
Model No.: AFR-7/AFR-7-1
Features
1 and 4 z one dual w hite/ Touch color w heel/ W ireless remote 30m distance/ CR2 0 3 2 battery
Ultrathin Touch W heel RF Remote Controller
Output signal RF 2.4GHz( )
W orking voltage 3VDC CR2032( )
W orking current ＜5mA
Standby current ＜1 0μA
Standby time 1 year
Remote distance 30m
S afety a nd E M C
EMC standard (EMC) EN301 489,EN 62479
Radio Equipment(RED) EN300 328
Certification CE,EMC,LVD,RED
EN60950
Safety standard(LVD)
LVD RED
4 Zone CCT 1 Zone CCT
User Manual Ver 1.0.2 www.alfaled.sk Page 1

AFR-7, AFR-7-1 Ultrathin Touch Wheel RF Remote Controller
M echanica l S tructures and Insta llati ons
9mm
58.5mm
107mm
58.5mm
Operation
●W hen light is on, touch the color wheel,the indicator will display red.
●To extend battery life, no touch or press key operation after a few seconds,
the touch wheel will enter sleep state, you need press any key to make touch wheel quit sleep state.
Match Remote Control (two match w ays)
Use the controller’s Match key
Match:
Short press match key, immediately press on/ off
key (single zone remote) or zone key (multiple zone
remote) of the remote.
Use Pow er Restart
Match:
Switch off the power, then switch on power again,
immediately short press on/ off key (single zone remote)
or zone key (multiple zone remote) 3 times on the remote.
The light blinks 3 times means match is successful.
.
Delete:
Switch off the power, then switch on power again,
immediately short press on/ off key (single zone remote)
or zone key (multiple zone remote) 5 times on the remote.
The light blinks 5 times means all matched remotes w ere
deleted.
Delete:
Press and hold match key for 5s to delete all match,
The light blinks 5 times means all matched remotes
were deleted.
End user can choose the suitable match/ delete w ays. Tw o options are offered for selection:
37.00 mm
63.00 mm
68.00 mm
Note: Before the first use,
please remove the protective
film on the battery.
C 2032 BatteryR
Back holder
To fix the remote, two options are offered for selection:
Option 1: fix the remote' back holder on the wall with two screws.
Option 2: adhere the remote' back holder to the wall with paster.
User Manual Ver 1.0.2 www.alfaled.sk Page 2

W W 0%
CW 1 00%
On/ Off: Short press turn on/ off all z one light.
1,2,3,4 z one:Short press select and turn on z one light, long press 2s turn off z one light.
Short press multiple z one key fastly, w ill synchronous select multiple z one sy nchronously.
Color w heel: Touch to change current z one color temperature.
Bright+/ -:Adjust brightness for current selected z one,
short press 10 levels, long press 1-6s for continuous 2 5 6 levels adjustment.
3 Scene: Short press recall the scene, long press 2s save the current color into the scene.
4 z one recall or save synchronously.
On/ Off: Turn on/ off light.
Color w heel: Touch to change color temperature.
Bright+/ -:Adjust brightness, short press 1 0 levels, long press 1-6s for continuous 2 5 6 levels adjustment.
10 0% ,5 0% : Get 1 00 % or 5 0% brightness directly.
W W : Get w arm w hite directly.
N W : Get cold w hite directly.
3 Scene: S hort press recall the scene, long press 2s save the current color into the scene.
W W 10 0%
CW 0 %
W W 50 %
CW 5 0%
100%
●AFR-7 4 zone CCT remote
●AFR-7-1 1 zone CCT remote
Bright-
3 Scene
2 Bright
Bright-
3 Scene
4 Zone
Bright+
On/ Off
Color w heel
Bright+
On/ Off
Color w heel
2 color temperature
Key function
User Manual Ver 1.0.2 www.alfaled.sk Page 3
AFR-7, AFR-7-1 Ultrathin Touch Wheel RF Remote Controller

S afety informa tion
1 Read all instructions carefully before y ou begin this installation. .
2 W hen installing battery, pay attention to the battery positive and negative polarity..
A long time w ithout the remote control, remove the battery.
W hen remote distance becomes smaller and insensitive, replace the battery.
3. If no response from the receiver, please re-match the remote.
4 Gently handle remote, bew are of falling.
.
5. For indoor and dry location use only.
User Manual Ver 1.0.2 www.alfaled.sk Page 4
