Alfaled AFR-T5 User manual

AFR-T5 AFR-T10
●Apply to RGB+CCT LED controller.
Ultra sensitive color adjustment touch w heel.●
●Each remote can match one or more receiver.
●AAAx2 battery powered.
●Operate with LED indicator light.
● Magnet on the back which can be easily stuck
on back holder or any metal surfaces.
Technical Parameters
Input and Output
W arranty
5 years
W arranty
Operation temperature
Case temperature (Max.)
Environment
IP20
IP rating
Ta: -30
O
C ~+55
O
C
Tc: +85
O
C
Model No.: AFR-T5/AFR-T10
Features
1 and 4 zone RGB+CCT/ Touch color w heel/ W ireless remote 30m distance/ AAAx2 battery/ Magnet stuck fix
Touch W heel RF Remote Controller
Output signal RF 2.4GHz( )
W orking voltage 3VDC A AAx2( )
W orking current ＜5mA
Standby current ＜10μA
Standby time 1 year
Remote distance 30m
S afety a nd EM C
EMC standard (EMC) EN301 489,EN 62479
Radio Equipment(RED) EN300 328
Certification CE,EMC,LVD,RED
EN60950
Safety standard(LVD)
LVD RED
1 Zone RGB+CCT 4 Zone RGB+CCT
M echa nical S tructures and Installati ons
53.00 mm
122.00 mm
17.50 mm
53.50 mm
3VDC(AAAx2) Battery Back holder with magnet
User Manual Ver 1.0.2 www.alfaled.sk Page 1

Match Remote Control (two match ways)
Use the controller’s Match key
Match:
Short press match key, immediately press on/ off
key (single zone remote) or z one key (multiple zone
remote) of the remote.
Use Power Restart
Match:
Switch off the power, then switch on power again,
immediately short press on/ off key (single zone remote)
or zone key (multiple zone remote) 3 times on the remote.
The light blinks 3 times means match is successful.
.
Delete:
Switch off the power, then switch on power again,
immediately short press on/ off key (single zone remote)
or zone key (multiple zone remote) 5 times on the remote.
The light blinks 5 times means all matched remotes w ere
deleted.
Delete:
Press and hold match key for 5s to delete all match,
The light blinks 5 times means all matched remotes
were deleted.
End user can choose the suitable match/ delete w ays. Tw o options are offered for selection:
AFR-T5, AFR-T10 Touch Wheel RF Remote Controller
●AFR-T5 1 zone RGB+CCT remote
: Adjust RGB or color temperature brightness,
short press 10 levels, long press 1-6s for continuous 256 levels adjustment.
CCT RGB
R G WB
S1S2
:Turn on/ off light.
:Touch to change RGB color or color temperature.
Press RGB or CCT key to switch between RGB w heel and CCT wheel.
:Adjust color temperature by W W / CW channel,
short press 11 levels, long press adjust W W +CW brightness continuously.
1
Warm White
WW 100%
CW 0%
11
Cool White
WW 0%
CW 100%
6
Natural White
WW 100%
CW 100%
CCT
Operation
●W hen turn on light, the indicator display blue. w hen turn off light, the indicator display red.
●W hen touch the color wheel,the indicator will display the same color.
●W hen press or touch operation is invalid (If the light is off), the indicator display red.
●To extend battery life,no touch or press key operation after a few seconds,
the touch wheel will enter sleep state, you need press any key to make touch wheel quit sleep state.
To x the remo t e, thr ee opt ions ar e of fer ed for sel ect ion:
Option 1: stuck the remote on any metal surfaces directly.
Option 2: fix the remote' back holder on the wall with two screws.
Option 3: adhere the remote' back holder to the wall with paster.
Key function
User Manual Ver 1.0.2 www.alfaled.sk Page 2

1
R 100% 9
G 100%
21
R 100%
B 100%
17
B 100% 25(1) R 100%
5
R 100%
G 100%
13
G 100%
B 100%
: Short press get 24 kinds static RGB color.
: For dynamic RGB mode, adjust speed,
short press 10 levels, long press 2s get the default speed.
For static RGB color, adjust saturation,
namely change current static RGB color to mixed white slowly,
short press 11 levels, long press 1-6s for continuous 256 levels adjustment.
: Short press run next dynamic mode, long press 2s run mode-cycle.
: Short press recall the scene, long press 2s save current color into S1 S2/ .
RGB
: Short press turn on/ off white(W W / CW ),
long press 1-6s to adjust white(W W +CW ) brightness continuously,
namely change saturation by adding white color slowly.
: Short press get red green or blue color directly.,
long press 1-6s to adjust R/ G/ B brightness continuously.
R G B
W
S1S2
124
3
●AFR-T10 4 zone RGB+CCT remote
CCT RGB
S1S2
124
3
Each z one can match single color, dual color(W W / CW ), RGB, RGBW,
or RGB+CCT(W W / CW ) controller or lamp.
For example, long press + key for 2s w ill set zone 1 as RGB light type.
W hen remote type change OK, the green indicator go on a long time.
+
+
+
+
+
: Single color
: Dual color(W W / CW )
: RGB
: RGBW
: RGB+CCT
: Short press turn on/ off all zone light.
: Touch to change current zone RGB color or color temperature.
Press RGB or CCT key to switch between RGB wheel and CCT wheel.
124
3
124
3
124
3
124
3
RGB
CCT
RGB
1
: Adjust RGB or color temperature brightness,
short press 10 levels, long press 2s get min or max brightness.
: Short press select and turn on zone light,
long press 2s turn off zone light.
124
3
AFR-T5, AFR-T10 Touch Wheel RF Remote Controller
User Manual Ver 1.0.2 www.alfaled.sk Page 3

1
R 100% 9
G 100%
21
R 100%
B 100%
17
B 100% 25(1)
R 100%
5
R 100%
G 100%
13
G 100%
B 100%
: Short press get 24 kinds static RGB color.
: For dynamic RGB mode, adjust speed,
short press 10 levels, long press 2s get the default speed.
For static RGB color, adjust saturation,
namely change current static RGB color to mixed white slowly,
short press 11 levels, long press 1-6s for continuous 256 levels adjustment.
: Short press run next dynamic mode, long press 2s run mode-cycle.
: Short press recall the scene, long press 2s save current state into S1/S2.
4 zone recall or save synchronously.
: For dual color or RGB+CCT(W W / CW ) lamp, adjust color temperature by W W / CW channel,
short press 11 levels, long press adjust W W +CW brightness continuously.
For RGB lamp, adjust color temperature by mix R/ G/ B channel,11 levels.
1
Warm White
WW 100%
CW 0%
11
Cool White
WW 0%
CW 100%
6
Natural White
WW 100%
CW 100%
1
Warm White
R 100%
G 50%
B 0%
6
Natural White
R 100%
G 100%
B 100%
11
Cool White
R 0%
G 50%
B 100%
For RGBW lamp, adjust color temperature by adjust W channel brightness,11 levels.
1
W 0%
11
W 100%
6
W 50%
CCT
RGB
S1S2
S afety information
1.Read all instructions carefully before y ou begin this installation.
2.W hen installing battery, pay attention to the battery positive and negative polarity.
A long time w ithout the remote control, remove the battery.
W hen remote distance becomes smaller and insensitive, replace the battery.
3. If no response from the receiver, please re-match the remote.
4.Gently handle remote, bew are of falling.
5. For indoor and dry location use only.
AFR-T5, AFR-T10 Touch Wheel RF Remote Controller
User Manual Ver 1.0.2 www.alfaled.sk Page 4
