ALFAMATIC CSQ-Visual User manual

Feb. 6, 2012
CSQ-Visual
Version with CSQVIO7 card
Installation manual

2
1Installing CSQ-Visual .............................................................................................................3
1.1 Important notes for installation ...................................................................................................... 3
1.2 Operating of the instrument ............................................................................................................ 3
1.3 Internal cards.................................................................................................................................... 4
1.4 Electric wiring................................................................................................................................... 4
1.5 Configure automatic work selection ............................................................................................. 10
1.6 Configuring the use of the phases.................................................................................................. 11
1.7 Connection of an external reset ..................................................................................................... 12
1.8 SETPOINT output.......................................................................................................................... 12
1.9 Instructions for setting up the CSQ-Visual................................................................................... 12

3
1 Installing CSQ-Visual
This paragraph describes the operations necessary to fit and connect the CSQ-Visual to the machine
and make it operative.
The CSQ-Visual has been designed to be independent: all you have to do is connect the valves and
sensors that will be powered by the instrument. Naturally there’s nothing to stop you from
combined use with a PLC.
To operate, the CSQ-Visual requires different input and output signals. As regards the inputs, a
force transducer (load cell), a position transducer (incremental encoder, potentiometer or 0-10 V
transducer) and various sensors are required. The outputs are connected to the unit descent
enabling valve, the protection closure valve (where installed) and the warning lights.
1.1 Important notes for installation
This manual refers only to the instrument with expansion card CSQVIO6.
The CSQ-Visual has to be powered at 24VDC. An optional internal power feeder is
available, enabling direct connection to the mains power.
This instrument is not (and could not be) a safety device: the descent of the press must be
entrusted to elements outside the instrument. The instrument synchronises the descent of
the press in order for it to work.
It is very important for the load cell wire terminal, which is not sheathed, to be as short as
possible.
When the machine has electric motors, these must be equipped with an anti-interference
filter and be controlled using semiconductor devices.
Always connect the container of the instrument to the earth conductor.
1.2 Operating of the instrument
Attention: the CSQ-Visual is not (and could not be) a safety device: the descent of the press must
be entrusted to external elements. The CSQ-Visual synchronises the descent for its operation.
The GO Output is usually connected serially to the chain of the cylinder descent. In short, if the
CSQ-Visual activates the GO enabling output, the cylinder must not descend if it is not safe.
Operation takes place as follows: when the START input is activated by an external command, the
CSQ–Visual, if ready, activates the protection descent output (PROTECTION) where present and
enables the cylinder descent (GO). When the protection is closed, a safety device must activate the
cylinder until the CSQ-Visual removes the cylinder descent enabling signal (GO). The CSQ-Visual
then commands the arrest of the press, removing the GO signal, controls the curve until the force
begins to diminish or is activated by way of the T.D.C. input (withdraw cylinder signal). Only then
does it indicate whether or not the piece is good or a reject.
If the piece is good, the GOOD output is activated and the PROTECTION output, where present, is
deactivated. If the piece is a reject, the REJECTED output is activated intermittently and the
PROTECTION output, where present, is left active. When the operator presses the reset button,
which can be external or always active, the instrument maintains the REJECTED output as fixed
and removes the PROTECTION output.

4
The correct alignment of the encoder takes place using its zero notch and the T.D.C. withdraw
cylinder signal.
1.3 Internal cards
There are two cards inside the CSQ–Visual:
frontal supports the display, keyboard and main CPU.
input e output for the connection of input signals, output signals and transducers.
We make all the cards ourselves and they can be altered to suit your specific requirements.
1.4 Electric wiring
The following information explains how to install the electric wiring.
1.4.1 Information for connection to an external controller (PLC)
To connect the CSQ-Visual to a PLC, the latter must have PNP positive logic. The inputs and
outputs of the instrument are optoinsulated from the instrument’s control electronics. The power
supply of the instrument’s inputs and outputs must be the same that powers the inputs and outputs
of the PLC. We recommend the use of at least one output (START signal) and three inputs of the
PLC (GO, GOOD and REJECTED). If necessary, with the press controlled directly by the
instrument, it is possible to use a single input to know whether the piece is good (GOOD output)
and a single output to control the start of the pressing cycle (START input).
Remember that, in all cases, it is always necessary too connect the T.D.C. input of the CSQ-Visual.
The T.D.C. signal can be acquired directly by a limit switch activated with the press in the resting
position. However, the signal indicating that the press is in the resting position is almost always
used by the PLC. In this case the signal to be given to the instrument may be taken parallel to that
delivered to the PLC.
1.4.2 CSQVIO7 card wiring
Attention: this information refers only to the CSQVIO7 card. Check that the correct type of card is
fitted.

5
The wiring is supported by removable terminal blocks (X3, X4, X5...). Every terminal on every
terminal block is numbered. For example, when terminal X5.7 is indicated, reference is made to the
seventh terminal of terminal block X5. The numbers are also printed on the printed circuit of the
card.
Figure 1
Main power terminal block (X24)
The electronics of the CSQ-Visual and the transducers are powered at 24VDC via the X24 three-
pole terminal block.
Name Function Terminal
0VDC Negative power X24.1
PE Earth connection X24.2
+24VDC Positive power X24.3
If the internal power feeder is fitted, the switch behind the instrument has to interrupt the phase and
neutral before reaching the power feeder. The power feeder output must be connected to terminal
block X24.
If the power card CSQVPOW is present, is necessary remove the jumper J1 and connect the power
to X24 from terminals X3.11 and X3.12.

6
Inputs terminal block (X3)
The inputs are optoinsulated and compatible with clean contact signals or 24 VDC PNP transistor
outputs.
Name Function Terminal Description
Input 0 START X3.1 Request for new cycle start
NU1 X3.2 Do not use
Input 1 T.D.C. X3.3 “Top dead point” signal, used to reset for a new cycle and in AND
with the zero notch of the encoder for the zero of the absolute
positions
NU2 X3.4 Do not use
Input 2 RESET X3.5 Re-enables the instrument after a reject (rejects basket)
Input 3 A.V. BASKET X3.6 Consent used in Auto-Check
Input 4 EXT. CHECK or
WORKSEL D
X3.7 Selection of work or external good/reject signal
Input 5 WORKSEL C X3.8 Work selection
Input 6 WORKSEL B X3.9 Work selection
Input 7 WORKSEL A X3.10 Work selection (less important)
0VDC Negative power
supply for inputs
and outputs
X3.11
+24VDC Positive power
supply for inputs
and outputs
X3.12
Outputs terminal block (X4)
Outputs for 24VDC loads. For inductive loads such as valves and relays, it is necessary to have a
diode parallel to the coils to eliminate peaks in voltage.
Name Function Terminal Description
Output 0 GOOD X4.1 Good piece signal. Active after the return of the cylinder until the
next start.
0VDC Power supply
earth
X4.2 This terminal can be used as the return of the utilities connected to
the outputs. It is connected internally to terminal X3.11.
Output 1 REJECTED X4.3 Rejected piece signal. Active after the return of the cylinder until
the next start. The output is intermittent until the reset signal.
NU3 X4.4 Do not use
Output 2 GO X4.5 Enables the press. Active after the start if the instrument is ready
and deactivated upon reaching the stoppage value.
Output 3 PROTECTION X4.6 Command for the closure of the protection or an acoustic signal.
Output 4 MEASURE X4.7 Activation of external measuring
Output 5 X4.8
Output 6 X4.9
Output 7 X4.10
Encoder and 0-10V input terminal block (X5)
An incremental encoder and a 0-10V signal can be connected to the X5 terminal block. A 12VDC
power supply is available for the encoder. A very high-precision 10VDC power supply is available
for the potentiometer.
Name Terminal Description
0V X5.1 Screened wire sheath
0V X5.2 Earth of the encoder or potentiometer
+12V X5.3 12 V encoder power (200mA max)
+10V X5.4 10 V potentiometer power (10mA max)
Phase A X5.5 PHASE A signal
Phase B X5.6 PHASE B signal
Phase Z X5.7 Zero notch signal
POT X5.8 Potentiometer cursor

7
Electrical features of terminals X5.5, X5.6 and X5.7
Electrical features of terminal X5.8
Load cell terminal block (X6)
Input for load cell with resistive jumper with a sensitivity of 2mV/V. The power for supply the load
cell is also available on this terminal block.
Name Terminal Description
0VL X6.1 Logic earth
IN+ X6.2 Positive input
IN- X6.3 Negative input
0V X6.4 Power earth
0V X6.5 Screened wire sheath
+10V X6.6 Power positive (60mA max)

8
Tipical connection

9
Connector D-Sub RS232
The RS232 pinout:
Pin 2: RX interface input signal to the CSQ-Visual.
Pin 3: TX interface output signal from the CSQ-Visual.
Pin 5: GND
1.4.3 CSQVIO6 card options
The CSQVIO6 card can be supplied with special optional features:
Option for RS485 or internal RS232 on X15
The CSQVIO6 can mount a connector with an RS232 serial port and an RS485 serial port. The
CSQ-Visual recognises and automatically selects the port connected. It is not possible to use both
serial ports at the same time. The RS232 serial port can be used for connections with the computer
(WinScope), for connection with a PLC or for connection with a barcode reader. The RS485 serial
port can be used only for connection with a PLC.
Name Terminal Description
+12VDC X15.1 Supplied power to the barcode reader or for any interface circuits
TX232 X15.2 RS232 interface output signal from the instrument
RX232 X15.3 RS232 interface input signal to the instrument
A+245 X15.4 Signal A+ of the RS485 interface
B-245 X15.5 Signal B- of the RS485 interface
0V X15.6 Earth
Option for several load cells
It is possible to connect up to six load cells to the instrument to simultaneously check six curves. In
this case there will be several six-pole terminal blocks identical to X6, marked as shown in the table
below:
Terminal
block
Description
X6 Channel 1 load cell
X7 Channel 2 load cell
X8 Channel 3 load cell
X9 Channel 4 load cell
X10 Channel 5 load cell
X11 Channel 6 load cell
Option for 0-10 V differential input
It is possible to have a differential input for the 0-10V signal. In this case there will be a second six-
pole terminal block marked X7.
Name Terminal Description
X7.1 Do not use
IN+ X7.2 Positive input
IN- X7.3 Negative input

10
0V X7.4 Power reference
0V X7.5 Screened wire sheath
X7.6 Do not use
Option for special transducers
It is possible to request the card adapted for use with special types of transducer. For example, it is
possible to use load cells with a 5V power supply or transducers with a 0-10mA output.
1.5 Configure automatic work selection
The CSQ-Visual supports the automatic selection of work using the combination of the inputs or a
command sent to the serial port. This selection can be useful for automatically recognising the
piece or the tool fitted.
To enable the automatic selection of work it is necessary to give the instrument the maximum
number of selectable works and the way in which they are selected.
To do this, select the TOOLS > ADVANCED OPTIONS > MACHINE TYPE > WORKS PHASES
CHANNELS menu and change the Number of selectable works value; then indicate the selection
mode, changing the Automatic selection code as shown in paragraph Errore. L'origine
riferimento non è stata trovata..
After changing the configuration, the instrument will create the selectable works, initially empty; to
make an empty work suitable for use, use the WORKS MANAGEMENT > CHANGE WORK command
and press enter on the work required. Now change the name of the work. The CREATE NEW WORK
item in the WORKS MANAGEMENT menu enables the creation of extra works which can be used
separately from the work selected automatically; to create an extra work and use a work other than
that selected automatically the unlock password in required.
Automatic selection only works if the instrument START input is not active.
1.5.1 Selection through inputs
The work number is obtained from the binary combination of the inputs. The binary code of the
first work is zero, i.e.: no input active. The maximum number of selectable works, if enough inputs
are available, is 64 (with binary codes from 0 to 63).
The wiring is connected to a terminal block inside the instrument marked X3.
The highest inputs must be used for selection.
Example: assuming the use of the CSQVIO card, which has 8 inputs, if it is necessary to select a
maximum of 4 works, inputs 7 and 8 will be used: input 8 will be the least significant bit, while
input 7 will be the most significant.
1.5.1.1 Connection of sensors for work selection
It is possible to use positive logic sensors (PNP) or clean contacts for connection to positive.
For example, if it is necessary to connect 4 sensors to the instrument (selection from 9 to 16 works)
which has 8 inputs, inputs 5, 6, 7 and 8 must be used. Input 8 will be the least significant bit, while
input 5 will be the most significant.

11
Example of wiring of three sensors (selection of 5 to 8 works):
1.5.2 Selection through serial command
The CSQ-Visual supports serial communication through which it is possible to select a work
remotely. Using serial communication, it is possible to select up to 250 works. To be able to
operate it is necessary to enable slow serial communication and set the Automatic selection code.
For the use of serial communication, see the relative manual.
1.6 Configuring the use of the phases
It is sometimes necessary to perform different machining process on the same piece, for instance,
different gears are fitted onto a drive shaft one after the other: hence the need to analyse all the
different machining phases.
The CSQ-Visual is able to manage up to four phases for each single process. The choice of the
phase may take place automatically, in succession or through the digital inputs of the instrument.
For every work process is it possible to decide whether to exclude one or more phases.
To enable a function for several phases, it is necessary to indicate the maximum number of phases
supported. To do this, select the TOOLS > ADVANCED OPT
TOOLS > ADVANCED OPTTOOLS > ADVANCED OPT
TOOLS > ADVANCED OPTIONS > MACHINE TYPE
IONS > MACHINE TYPE IONS > MACHINE TYPE
IONS > MACHINE TYPE > WORKS
> WORKS > WORKS
> WORKS
PHASES CHANNELS
PHASES CHANNELSPHASES CHANNELS
PHASES CHANNELS menu and change the Number of phases value. As well as indicating the
number of phases, it is necessary to indicate the way to behave, changing the Automatic selection
code.
If the maximum number of phases is changed, it will be necessary to cancel all the works created
previously:
Figure 2

12
If required, it is possible to save them first on the computer using the WinScope program.
1.7 Connection of an external reset
When a reject is detected, the instrument blocks, preventing the machining of other pieces. The
release the instrument it is necessary to reset the reject. It is possible to connect an external reset
signal which can be a button, key or sensor. The reset signal can be left active at all times to have
the autoreset function. Like all the other inputs, the reset signal has to have a 24VDC clean contact
or an electronic sensor with a PNP (positive logic) output.
1.8 SETPOINT output
The CSQ-Visual has an auxiliary output which can be activated when a determined absolute
position or a determined force have been reached. The value of this position or force of the
setpoint can be different for every single work.
Once the absolute position or force value has been reached, the output is activated and kept active
until the press stops.
With the CSQ Visual Setup program it is possible to assign a descriptive name to this output.
This output is normally used to command a hydraulic brake or the start of the press power.
Naturally it can be used for any other function.
To set the setpoint activation threshold use the CHANGE WORK > PARAME
CHANGE WORK > PARAMECHANGE WORK > PARAME
CHANGE WORK > PARAMETERS > OTHER LIMITS
TERS > OTHER LIMITSTERS > OTHER LIMITS
TERS > OTHER LIMITS
command.
1.9 Instructions for setting up the CSQ-Visual
Always disconnect the instrument from the electricity supply before opening it.
Open the CSQ-Visual by loosening the four screws in the corners of the front panel.
Figure 3
Pull out the internal cards by a few centimetres. Then release the cards from the front panel.

13
Figure 4
Pull out all the cards from the container and remove the five terminal block units.
To fasten the instrument in place it is possible to perforate the container on the top or bottom (after
removing all the cards) in the middle.
Fit the wire passage and plugs. To fit a larger wire passage, the hole C8 can be enlarged using a
stepped cutter.
Figure 5
Slot the wires through the wire passage and start wiring.
It is extremely important for the end of the wire of the load cell which is not covered by a
sheath to be as short as possible:
Figure 6
After completing the wiring, insert the card:

14
Lastly, insert the terminal block units, paying attention to the direction.
Make sure that cables are not squashed on the bottom of the instrument.
After completing the wiring it is possible to supply power to the instrument, switching it on using
the switch on the back and proceeding as follows:
•Configure the instrument.
•Check the operation of the inputs and outputs, using the controls of the DIAGNOSIS menu.
•Calibrate the transducers.
