Alinco DJ-CRX2 User manual

MIC
A
FUN
D
ESC/M
B
C
1
FM
2
TONE
3
T.SCA
6
SKIP
9
HI/LO
#
5
SCAN
8
SET
0
DTMF
4
7
REV
M/S
ENT
/
KL
DJ-CRX2
Thank you for purchasing your new Alinco transceiver. Please read this manual
carefully before using the product to ensure full performance, and keep this
manual for future reference as it contains information on after-sales service.
In case addendum or errata sheets are included with this product, please read
those materials and keep them together with this instruction manual for future
reference.
VHF FM Transceiver
Instruction Manual
DJ-CRX2

A2.171122
ALINCO, INC.
Yodoyabashi Dai-bldg 13F
4-4-9 Koraibashi, Chuo-ku, Osaka 541-0043 Japan
Phone: [phone] Fax: [phone]
http://www.alinco.com
E-mail:[email protected]
Copyright Alinco, lnc. PS0891 / FNEJ-NH
Printed in China

Introduction
Please be informed that this manual has been edited with dealer-use in mind. The product is delivered to
consumers after being programmed by dealers. The product is blocked and not functional in ex-factory state
due to regulations.
Please read this manual completely from the first page to the last, to learn all the functions the
product offers. It is important to note that some of the operations may be explained in relation
to information in other chapters. By reading just one part of the manual, you may risk not
understanding the complete explanation of the function.
Before transmitting
There are many radio stations operating in proximity to the frequency ranges this product covers. Be careful
not to cause interference when transmitting around such radio stations.
■ Lightning
Any person is not safe outdoor during thunderstorm and lightning. This condition is getting worse if
somebody keeps a hand-held radio; chances of being hit by lightning are doubled since lightning may hit a
radio antenna as well. At this time, there is no hand-held radio having any kind of protection against lightning
current (which is higher than10 kA.). Note also that no car provides adequate protection of its passengers or
drivers against lightning as well. Therefore, Alinco will not take responsibility for any danger associated with
using its hand-held radios outdoor or inside the car during lightning.

■ Covering ranges
You may expect a range of approx.3km/2 miles or more at high-power when located on a at, noise-free
place like on a beach. However, it may vary drastically depending on how to wear and carry the radios,
surrounding locations/conditions and static noise levels (below or near power transmission lines), etc. In
urban areas with many buildings or inside a building, such covering range may become drastically short
even to several tens of meters.
IMPORTANT NOTICE / DEALER PROGRAMMING
The utility software may be available to distributors/dealers only. USB programming cable is required. The
manufacturer will not release the software to unauthorized party so please contact your dealer for details.
This product may be delivered to the consumer after being preprogrammed with the operating parameters,
then certain operation may be disabled for user-accesses. This is the Commercial radio mode, and it may
not work as described in this booklet. The manufacturer and distributers are not aware of details of such
dealer-programming.Therefore, please contact to your dealer in case any technical assistance may be
necessary.

■ Output power selectable 5W/2W/1W
■ 199 PC-programmable channels
■ Li-Ion battery pack and stand-charger as standard accessories
■ Alphanumeric name tags
■ FM broadcast 76-108MHz receiver built-in
■ Selectable Battery-save parameters
■ Busy Channel Lockout
■ CTCSS/DCS Encode/Decode, DTMF
■ VOX built-in
■ Emergency, Alarm signal, Various scan modes, Key lock, Wide/Narrow operations
and more.
Features

WARNING
To prevent any hazard during operation of Alinco’s radio product, in this manual and on the product you may
nd symbols shown below. Please read and understand the meanings of these symbols before starting to
use the product.
This symbol is intended to alert the user a possible hazard that may cause
loss of property or injure the user if the warning is disregarded.
Alert symbol. An explanation is given.
Warning symbol. An explanation is given.
Instruction symbol. An explanation is given.
This symbol is intended to alert the user to a possible hazard that may cause
loss of life and property if the user disregards the warning.
This symbol is intended to alert the user to an immediate danger that may
cause loss of life and property if the user disregards the warning.
Danger
Alert
Caution

Alert
Environment and condition of use
Use of this product may be prohibited or illegal outside of your country. Be informed in advance when you
travel.
It is recommended that you check local traffic regulations regarding the use of a radio equipment while
driving. Some countries prohibit or apply restrictions for the operation of radios and mobile-phones while
driving.
Do not use this product in close proximity to other electronic devices, especially medical ones. It may cause
interference to those devices.
Keep the radio out of the reach of children.
In case a liquid leaks from the product, do not touch it. It may damage your skin. Rinse with plenty of cold
water if the liquid contacted your skin.
Never operate this product in facilities where radio products are prohibited for use such as aboard aircraft, in
airports, in ports, within or near the operating area of business wireless stations or their relay stations.
The manufacturer declines any responsibilities against loss of life and/or a property due to a failure of this
product when used to perform important tasks like life-guarding, surveillance, and rescue.
Do not use multiple radios in very close proximity. It may cause interference and/or damage to the product(s).
Risk of explosion if battery is replaced with an incorrect type. Dispose of, or recycle used batteries according
to your local regulations.

Handling this product
The manufacturer declines any responsibilities against loss of life and property due to a failure of this product
when used with or as a part of a device made by third parties.
Use of third party accessory may result in damage to this product. It will void our warranty for repair.
Be sure to reduce the audio output level to minimum before using an earphone or a headset. Excessive audio
may damage hearing.
Do not open the unit without permission or instruction from the manufacturer. Unauthorized modication or
repair may result in electric shock, re and/or malfunction and voids warranty.
Do not operate this product in a wet place such as in a shower room. It may result in electric shock, re and/or
malfunction, This product is splash-proof but not a complete water-proof.
Do not place the product in a container carrying conductive materials, such as water or metal in close proximity.
A short-circuit to the product may result in electric shock, re and/or malfunction.
About chargers
Do not use adapters other than having the specified voltage. It may result in electric shock, fire and/or
malfunction,Never turn on the radio while charging.
Do not plug multiple devices using an adapter into a single wall outlet. It may result in overheating and/or re.
Do not handle adapter with a wet hand. It may result in electric shock.

In case of emergency
In case of the following situation(s), please turn off the product, switch off the source of power, then
remove or unplug the power-cord. Please contact your local dealer of this product for service and
assistance. Do not use the product until the trouble is resolved. Do not try to troubleshoot the problem
by yourself.
●When a strange sound, smoke and/or strange odor comes out of the product.
●When the product is dropped or the case is broken or cracked.
●When a liquid penetrated inside.
●When a power cord (including DC cables, AC cables and adapters) is damaged
For your safety, turn off then remove all related AC lines to the product and its accessories from the wall outlet
if a thunderstorm is likely.
Maintenance
Do not open the unit and its accessories. Please consult with your local dealer of this product for service and
assistance.
Securely plug the adapter into the wall outlet. Insecure installation may result in short-circuit, electronic shock
and/or re.
Do not use the adapter if the plug or socket contacts are dirty. Overheating and/or short-circuiting may result in
re, electric shock and/or damage to the product.

About transceiver
Caution
Do not use the product in proximity to a TV or a radio. It may cause interference or receive interference.
Do not install in a humid, dusty or insufficiently ventilated place. It may result in electric shock, fire and/or
malfunction.
Do not install in an unstable or vibrating position. It may result in electric shock, re and/or malfunction when/if
the product falls to the ground.
Do not install the product in proximity to a source of heat and humidity such as a heater or a stove. Avoid
placing the unit in direct sunlight.
Be cautious of a dew formation. Please completely dry the product before use when it happens.
Be cautious of the whip antenna when carried in your shirt-pocket etc. It may make contact with your eye and
cause injury.
Do not connect devices other than specied ones to the jacks and ports on the product. It may result in damage
to the devices.
Turn off and remove the power source (AC cable, DC cable, battery, cigar cable, charger adapter etc.) from the
product when the product is not in use for extended period of time or in case of maintenance.
Never pull the cord alone when you unplug AC cable form the wall outlet.
