Allegion Simons Voss Technologies SmartCD2.G2 User manual

SmartCD2.G2
Manual
29.08.2020

Contents
1 Intended use ................................................................................................................................................ 3
2 General safety instructions.....................................................................................................................4
3 Product-specific safety instructions....................................................................................................6
4 Unpacking..................................................................................................................................................... 7
5 Connecting ...................................................................................................................................................8
6 Recharging ...................................................................................................................................................9
7 Getting started.......................................................................................................................................... 10
8 Configuring the Bluetooth connection................................................................................................11
9 Programme .................................................................................................................................................12
9.1 Programming with a PC or laptop..........................................................................................................12
9.2 Programming with a Windows notebook/tablet............................................................................12
9.3 Programming with smartphone/tablet (Android/iOS) ...............................................................12
10 Align the antenna......................................................................................................................................13
11 Replacing the batteries.......................................................................................................................... 14
12 Signalling .....................................................................................................................................................15
13 Technical specifications........................................................................................................................ 16
14 Declaration of conformity ..................................................................................................................... 18
15 Help and other information .................................................................................................................. 19
SmartCD2.G2 (Manual) Contents
2 / 20

1 Intended use
The SmartCD2.G2 is a programming device that has been specially
developed for running on a PC/tablet/laptop or for coupling with a
smartphone. It is a very convenient way for you to programme and read all
digital components in SimonsVoss System 3060 (locking cylinders,
transponders, SmartHandles and SmartRelays).
To program digital, passive SimonsVoss products (MP variants), you need
the SmartCD.MP programming device. This can only be used together with
the LSM.Mobile.PC on a Windows notebook or Windows tablet (not with
the app).
AX locking components can be reprogrammed directly with the
smartphone and the app. You do not need a SmartCD2.G2 for this.
SmartCD2.G2 (Manual) 1. Intended use
3 / 20

2 General safety instructions
Signal word (ANSI
Z535.6) Possible immediate effects of non-compliance
DANGER Death or serious injury (likely)
WARNING Death or serious injury (possible, but unlikely)
CAUTION Minor injury
IMPORTANT Property damage or malfunction
NOTE Low or none
WARNING
Blocked access
Access through a door may stay blocked due to incorrectly fitted and/or in-
correctly programmed components. SimonsVoss Technologies GmbH is
not liable for the consequences of blocked access such as access to in-
jured or endangered persons, material damage or other damage!
Blocked access through manipulation of the product
If you change the product on your own, malfunctions can occur and access through a door can
be blocked.
Modify the product only when needed and only in the manner described in the
documentation.
IMPORTANT
Damage resulting from electrostatic discharge (ESD)
This product contains electronic components that may be damaged by electrostatic discharges.
1. Use ESD-compliant working materials (e.g. Grounding strap).
2. Ground yourself before carrying out any work that could bring you into contact with the
electronics. For this purpose, touch earthed metallic surfaces (e.g. door frames, water pipes
or heating valves).
Damage resulting from liquids
This product contains electronic components that may be damaged by liquids of any kind.
Keep liquids away from the electronics.
Damage resulting from aggressive cleaning agents
The surface of this product may be damaged as a result of the use of unsuitable cleaning agents.
Only use cleaning agents that are suitable for plastic or metal surfaces.
SmartCD2.G2 (Manual) 2. General safety instructions
4 / 20

Damage as a result of mechanical impact
This product contains electronic components that may be damaged by mechanical impacts of
any kind.
1. Avoid touching the electronics.
2. Avoid other mechanical influences on the electronics.
Damage due to polarity reversal
This product contains electronic components that may be damaged by reverse polarity of the
power source.
Do not reverse the polarity of the voltage source (batteries or mains adapters).
Operational malfunction due to radio interference
This product may be affected by electromagnetic or magnetic interference.
Do not mount or place the product directly next to devices that could cause electromagnetic
or magnetic interference (switching power supplies!).
Communication interference due to metallic surfaces
This product communicates wirelessly. Metallic surfaces can greatly reduce the range of the
product.
Do not mount or place the product on or near metallic surfaces.
NOTE
Intended use
SimonsVoss-products are designed exclusively for opening and closing
doors and similar objects.
Do not use SimonsVoss products for any other purposes.
Qualifications required
The installation and commissioning requires specialized knowledge.
Only trained personnel may install and commission the product.
Modifications or further technical developments cannot be excluded and may be implemented
without notice.
The German language version is the original instruction manual. Other languages (drafting in the
contract language) are translations of the original instructions.
Read and follow all installation, installation, and commissioning instructions. Pass these instruc-
tions and any maintenance instructions to the user.
SmartCD2.G2 (Manual) 2. General safety instructions
5 / 20

3 Product-specific safety instructions
WARNING
Dangers from built-in lithium batteries
The programming device contains lithium batteries. Lithium batteries are
dangerous if not handled properly.
1. Do not open the programming device. SimonsVoss can replace used
batteries (subject to a charge).
2. Do not expose the programming device to temperatures above 70 °C.
3. Do not burn the programming device.
NOTE
Initial charging of the built-in batteries.
The built-in rechargeable batteries are discharged when delivered.
Charge the programming device for at least three hours before using it.
Damage due to unsuitable cables
Defective USB cables may cause malfunctions.
Use only the supplied USB cable.
SmartCD2.G2 (Manual) 3. Product-specific safety instructions
6 / 20

4 Unpacking
Scope of delivery SmartCD2.G2 programming device, (including permanently built-in
batteries)
Cable to connect to a USB port
Quick guide
You need the LSM software to operate the SmartCD2.G2.
For mobile programming on site, the LSM Mobile software or app must also
be installed on the mobile device.
The LSM Mobile software must be purchased separately.
The app is free of charge. You need the export tool included in the LSM
Mobile PC to use the app.
Software and drivers can be found on the SimonsVoss homepage in the
service area during software downloads (
https://www.simons-voss.com/
en/service/software-downloads.html ).
SmartCD2.G2 (Manual) 4. Unpacking
7 / 20

5 Connecting
SmartCD2.G2 can be directly connected to a PC or laptop by plugging the
supplied cable into an unassigned USB port.
All digital locking devices and all active transponder media in SimonsVoss
System 3060 can be programmed using a SmartCD2.G2 in conjunction
with a PC/laptop.
NOTE
SmartCD2.G2 coupling on the Smartphone
If you use the SmartCD2.G2 with a Smartphone via Bluetooth, the connec-
tion cable from the SmartCD2.G2 to the PC/laptop must be unplugged
again. It is not possible to use Bluetooth to communicate between
SmartCD.G2 and a PC or laptop.
USB and Bluetooth cannot be used simultaneously
You must ensure that the Bluetooth connection is not active before connecting SmartCD2.G2 to
the USB port. The Bluetooth function switches off automatically after 15 minutes. It can also be
switched off manually by pressing a button on the programming device. If this not the case, com-
munication cannot be established via the USB port.
Transponders can only be programmed if the SmartCD2.G2 is connected
directly (via USB cable) to a PC/tablet/laptop and the LSM software is
installed.
SmartCD2.G2 (Manual) 5. Connecting
8 / 20

6 Recharging
Connect the SmartCD2.G2 to a USB port (PC/laptop/power bank or
similar) using a USB cable. The SmartCD2.G2 batteries are then charged
via the USB port.
NOTE
USB connections are in standby or switched off
On your PC or laptop, the USB ports may be turned off in standby or off
mode.
1. Check the USB settings in your device's power plan.
2. Alternatively, use a USB charger, active USB hub, or power bank.
Power supply on passive USB hubs
On passive USB hubs, all connected devices share the power supply. This may result in insuffi-
cient power being available to the programming device.
Connect the programming device to an active USB hub with its own power supply or connect
it directly to a USB port of your PC/tablet/laptop.
Self-discharge of the batteries
Like all batteries, the batteries in the SmartCD2.G2 discharge over a long period of time. In this
case, you cannot use it until it is charged.
Leave the SmartCD2.G2 connected to a suitable USB port if you are not going to use it for a
longer period of time.
SmartCD2.G2 (Manual) 6. Recharging
9 / 20

7 Getting started
1. Install the LSM software.
9Required drivers are installed automatically.
2. Connect the programming device to a USB port (see Connecting [}8] ).
9The programming device is ready for use.
If you want to use the programming device with a smartphone, follow the
instructions in the app or the manual for the app.
SmartCD2.G2 (Manual) 7. Getting started
10 / 20

8 Configuring the Bluetooth connection
üThe smartphone is switched on and visible to other Bluetooth devices.
üThe programming device is loaded and switched on.
üThe smartphone and programming device are in close proximity to each
other.
üNo other SimonsVoss programming device with the Bluetooth interface
activated is nearby.
1. Call up the Bluetooth settings on your smartphone.
2. Open the menu for pairing a new device.
3. Follow the instructions. Your programming device has the device name
SV_[serial number].
9Programming device coupled with Smartphone.
SmartCD2.G2 (Manual) 8. Configuring the Bluetooth connection
11 / 20

9 Programme
During programming, there should a minimum gap of around 10 cm
between SmartCD and the locking device; for SmartRelay it should be
around 30cm and 70cm for the block lock.
9.1 Programming with a PC or laptop
üCurrent version of the LSM software installed.
üProgramming device connected.
1. Click the button Programming in the LSM software.
9The window "Programming" opens.
2. Follow the further instructions.
The current version of the LSM software must be installed on the PC/
laptop.
NOTE
Requirements for new installation or update of the LSM software
The new installation or update of the LSM software can only take place
under certain conditions.
1. Connect a programming device to the PC/laptop.
2. Perform the installation or update with administrator rights.
9.2 Programming with a Windows notebook/tablet
üCurrent LSM-Mobile version installed on your notebook.
1. Export your locking plan from your PC to an external storage medium
(e.g. USB stick).
2. Import this locking plan into your notebook.
For further information, please refer to the LSM-Mobile manual.
9.3 Programming with smartphone/tablet (Android/iOS)
Google Play and the Google Play logo are trade-
marks of Google LLC.
App Store® is a trademark of Apple Inc., registered
in the United States and other countries.
Coming soon...
üLatest app installed on your phone.
Follow the instructions on the app.
SmartCD2.G2 (Manual) 9. Programme
12 / 20

10 Align the antenna
To ensure trouble-free programming, the antenna alignment of selected
components is shown below. You can achieve the greatest possible read
range for programming if the SmartCD2.G2 and locking device antennas
are positioned in parallel to one another.
As a general rule, the distance between antennas should be at least 10cm
to prevent overshooting.
In this example, all antennas are parallel to one another!
SmartCD2.G2 (Manual) 10. Align the antenna
13 / 20

11 Replacing the batteries
Contact your retail specialist if you should need to replace batteries. The
retailer can then have batteries replaced by SimonsVoss Technologies
GmbH for a fee.
NOTE
Do not try to replace the batteries yourself under any circumstances.
SmartCD2.G2 (Manual) 11. Replacing the batteries
14 / 20

12 Signalling
LED 1 lights up green. Programming device
ready for operation.
LED 1 flashes green. Programming unit in
standby mode.
The first LED lights up when connected via USB on the PC/laptop or
without USB connection only after the SmartCD2.G2 has been switched on
by pressing the button. The device can be switched off again to save power
by re-pressing the button.
LED 2 lights up yellow. Batteries are being
charged.
LED 2 is off. Batteries are fully
charged.
The second LED only lights up when:
The programming device is connected to a suitable USB port for
charging and
At least one of the batteries must be charged.
LED 3 flashes green
quickly.
Communication with a
SimonsVoss locking
device.
LED 3 flashes green
slowly. No connection.
The third LED only signals only when wireless communication is active (e.g.
programming, readout) between programming device and a corresponding
locking device.
LED 4 lights up blue. Bluetooth active.
LED 4 is off. Bluetooth inactive.
The fourth LED lights up when using the Bluetooth interface for the
duration of the programming, readout or reset procedure, and then goes
out again.
SmartCD2.G2 (Manual) 12. Signalling
15 / 20

13 Technical specifications
Housing dimensions H x W x D: 112 x 63 x 22 mm
Weight (including batteries): 95 g
Housing material: Composite
Housing colour: Grey
Number of LEDs: 4
Battery type Li-ion manganese batteries (per-
manently built-in)
USB port Mini USB
Standard protection rating IP20
Working temperature range: -5°C to +40°C
Storage temperature range: -20°C to +60°C
SmartCD2.G2 (Manual) 13. Technical specifications
16 / 20

Supported profiles: SPP (Serial Port Profile), serial data
transmission
Radio emissions
SRD 25kHz (fL>10kHz,
fH<40kHz)
-28.5dBµA/m (10m
distance)
BLE 2402 MHz - 2480 MHz 0 dBm
There are no geographical restrictions within the EU.
SmartCD2.G2 (Manual) 13. Technical specifications
17 / 20

14 Declaration of conformity
The company SimonsVoss Technologies GmbH hereby declares that
article SMARTCD2.G2 complies with the following guidelines:
2014/53/EU "Radio equipment"
2014/30/EU "EMC"
2011/65/EU "RoHS" with 2015/863 and 2017/2102
2012/19/EU "WEEE"
and regulation (EG) 1907/2006 "REACH"
The full text of the EU Declaration of conformity is available at the
following internet address:
https://www.simons-voss.com/en/
certificates.html .
SmartCD2.G2 (Manual) 14. Declaration of conformity
18 / 20

15 Help and other information
Information material/documents
You will find detailed information on operation and configuration and other
documents under Informative material/Documents in the Download
section on the SimonsVoss website (
https://www.simons-voss.com/en/
downloads/documents.html ).
Declarations of conformity
You will find declarations of conformity for this product in the Certificate
section on the SimonsVoss website (
https://www.simons-voss.com/en/
certificates.html ).
Information on disposal
Do not dispose the device (SMARTCD2.G2) in the household waste.
Dispose of it at a collection point for electronic waste as per European
Directive 2012/19/EU.
Take the packaging to an environmentally responsible recycling point.
Hotline
If you have any questions, the SimonsVoss Service Hotline will be happy to
help you on [phone] (German fixed network; call charges
vary depending on the operator).
Email
You may prefer to send us an email.
[email protected] (System 3060, MobileKey)
FAQs
You will find information and help for SimonsVoss products in the FAQ
section on the SimonsVoss website (
https://faq.simons-voss.com/otrs/
public.pl ).
Address
SimonsVoss Technologies GmbH
Feringastrasse 4
85774 Unterföhring
Germany
SmartCD2.G2 (Manual) 15. Help and other information
19 / 20

This is SimonsVoss
SimonsVoss is a technology leader in digital
locking systems.
The pioneer in wirelessly controlled, cable-free
locking technology delivers system solutions
with an extensive product range for SOHOs,
SMEs, major companies and public institutions.
SimonsVoss locking systems unite intelligent
functions, optimum quality and award-winning
German-made design. As an innovative system
provider, SimonsVoss attaches great importan-
ce to scalable systems, effective security, reliable components, high-perform-
ance software and simple operation.
Our commercial success lies in the courage to innovate, sustainable thinking and
action, and heartfelt appreciation of employees and partners. With its headquar-
ters in Unterföhring, near Munich, and its production site in Osterfeld, eastern
Germany, the company employs around 300 staff in eight countries.
SimonsVoss is a company in the ALLEGION Group, a globally active network in
the security sector. Allegion is represented in around 130 countries worldwide
(www.allegion.com).
© 2020, SimonsVoss Technologies GmbH, Unterföhring
All rights are reserved. Text, images and diagrams are protected under copyright
law.
The content of this document must not be copied, distributed or modified. More
information about this product can be found on the SimonsVoss website. Sub-
ject to technical changes.
SimonsVoss and MobileKey are registered brands belonging to SimonsVoss
Technologies GmbH.
