ArmorBlock WeldBlock 2-Port Ethernet
Self-configurable with QuickConnect
CatalogNumbers1732E-16CFGM12QCWR,1732E-16CFGM12P5QCWR
Parts List
Your package contains one 1732E ArmorBlock™ WeldBlock module and these
pinout guide wiring instructions.
For complete installation instructions, refer to the Module Publication Number
table and visit http://www.rockwellautomation.com/literature/.
I/O Connectors
Micro-style 5-Pin Selectable Point Connector
Module Publication Number
Module Publication Number
1732E ArmorBlock 2-Port Ethernet Modules with QuickConnect 1732E-IN010
WARNING: HOT SURFACE. RISK OF BURN.
ATTENTION: Two sets of mounting holes are used to mount the module
directly to a panel or machine. Mounting holes accommodate #8 (M4) pan
head screws. The torque specification is 1.13 Nm (10 lb-in.).
1 2
4
5
3
(View into connector)
Pin 1 Sensor source voltage
Pin 2 Input B or Output B
Pin 3 Return
Pin 4 Input A or Output A
Pin 5 PE
44807

2ArmorBlock WeldBlock 2-Port Ethernet Self-configurable with QuickConnect
Publication 1732E-WD005C-EN-P - May 2013
EtherNet/IP Connector
D-Code Micro Network Female Connector
Auxiliary Power Connector
Mini-style 4-Pin Receptacles
Mini-style 5-Pin Receptacles
TIP
The ground for both module power and output power are shared.
ATTENTION: This equipment is considered Group 1, Class A industrial
equipment according to IEC/CISPR 11. Without appropriate precautions,
there may be difficulties with electromagnetic compatibility in residential
and other environments due to conducted and radiated disturbance.
(View into connector 1)
Pin 1 M12_Tx+
Pin 2 M12_Rx+
Pin 3 M12_Tx-
Pin 4 M12_Rx-
Pin 5 Connector shell
shield GND
1
2
3
4
5
45793
(View into connector 2)
Pin 1 M12_Rx+
Pin 2 M12_Tx+
Pin 3 M12_Rx-
Pin 4 M12_Tx-
Pin 5 Connector shell
shield GND
4 2
3 1
44809
(View into receptacle)
Pin 1 Output power+
Pin 2 Sensor/MDL power+
Pin 3 Sensor/MDL power-
Pin 4 Output power-
42
31
45677
Male Input Female Output
4
2
5
1
3
46199
(View into receptacle)
Pin 1 Output power-
Pin 2 Sensor/MDL power-
Pin 3 Protective Earth
Pin 4 Sensor/MDL power+
Pin 5 Output power+
42
51
3
46200
Male Input Female Output

ArmorBlock WeldBlock 2-Port Ethernet Self-configurable with QuickConnect 3
Publication 1732E-WD005C-EN-P - May 2013
Specifications
Environmental Specifications
Attribute Value
Temperature, operating IEC60068-2-1 (Test Ad, Operating Cold),
IEC60068-2-2, (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
-20...60 °C (-4…140 °F)
Temperature, ambient, max 60 °C (140 °F)
Voltage, operating 12…30V DC
Output current, per port 0.5 A
Enclosure type rating Meets IP65/66/67/69K (when marked), and Type 4X Indoor
Use Only, with receptacle dust caps or cable termination
Certifications
Certification (when
product is marked)(1)
(1) See the Product Certification link at http://www.rockwellautomation.com/products/certification/ for
Declaration of Conformity, Certificates, and other certification details.
Value
c-UR-us UL Recognized Industrial Control Equipment, certified for US and
Canada. See UL File E322657.
CE European Union 2004/108/EC EMC Directive, compliant with:
EN 61326-1; Meas./Control/Lab., Industrial Requirements
EN 61000-6-2; Industrial Immunity
EN 61000-6-4; Industrial Emissions
EN 61131-2; Programmable Controllers (Clause 8, Zone A & B)
C-Tick Australian Radiocommunications Act, compliant with:
AS/NZS CISPR 11; Industrial Emissions
EtherNet/IP ODVA conformance tested to Ethernet/IP specifications.
KC Korean Registration of Broadcasting and Communications
Equipment, compliant with:
Article 58-2 of Radio Waves Act, Clause 3
