Allen-Bradley CompactLogix 1769-L20 User manual

Publication 1769-IN047C-EN-P - April 2003
Installation Instructions
1769-L20, 1769-L30 CompactLogix™ Controllers
(Cat. No. 1769-L20, 1769-L30)
Inside...
Before You Begin .................................................................................... 2
For More Information.............................................................................. 2
European Communities (EC) Directive Compliance ................................ 4
Hazardous Location Considerations ....................................................... 5
CompactLogix Controller Description ..................................................... 6
System Planning ..................................................................................... 6
Install the Controller ............................................................................... 7
Connect the Battery ................................................................................ 8
Assemble the System ............................................................................. 9
Mount the System ................................................................................ 10
Grounding Considerations .................................................................... 12
Select the Controller’s Operating Mode ............................................... 12
RS-232 Connections to the Controller .................................................. 13
Default Communication Configuration ................................................. 14
Using the Channel 0 Default Communication Push Button .................. 15
Troubleshoot the Controller Using the LEDs......................................... 16
Flash Upgrade the Controller Firmware................................................ 17
Specifications ....................................................................................... 18
Dimensions ........................................................................................... 19
Battery Handling, Storing, and Transporting ........................................ 20

21769-L20, 1769-L30 CompactLogix™ Controllers
Publication 1769-IN047C-EN-P - April 2003
Before You Begin
Use this document as a guide for installing and powering-up your 1769-L20, -L30
CompactLogix controller system. You should already be familiar with the
CompactLogix system components.
You must FLASH upgrade the firmware on your CompactLogix controller before
you can use it. The controller ships with firmware revision 1.x but must be
upgraded to match the version of RSLogix 5000 that you are using (e.g. if you are
using RSLogix 5000 V11, you must upgrade your CompactLogix controller firmware
to revision 11.x before using it. For more information on upgrading your
controller’s firmware, see page 17.
For More Information
If you would like a manual, you can obtain it as follows:
·download a free electronic version from the internet:
www.theautomationbookstore.com
·purchase a printed manual by:
–contacting your local distributor or Rockwell Automation representative
–visiting www.theautomationbookstore.com and placing your order
–calling 1.800.963.9548 (USA/Canada)
or 001.330.725.1574 (Outside USA/Canada)
For Information on Refer to this Document Pub. No.
How to use 1769-L20, -L30 CompactLogix™
controllers
CompactLogix™ System User Manual 1769-UM007
Programming the controller Logix5000™ Controllers Common
Procedures Programming Manual
1756-PM001
General instructions Logix5000 Controller General
Instructions Reference Manual
1756-RM003
Process control and drives instructions Logix5000 Controller Process Control
and Drives Instructions Reference
Manual
1756-RM006
Installing and operating Compact power
supplies
Compact™ 1769 Expansion I/O Power
Supplies Installation Instructions
1769-IN028
Installing and operating Compact I/O Compact 1769 Expansion I/O Installation Instructions for your
particular module
Installing and operating Compact I/O
analog modules
Compact 1769 I/O Analog Modules
User Manual
1769-UM002
How to use the 1769-ADN DeviceNet
adapter module
DeviceNet Adapter Module User
Manual
1769-UM001
Proper wiring and grounding techniques. Industrial Automation Wiring and
Grounding Guidelines
1770-4.1

1769-L20, 1769-L30 CompactLogix™ Controllers 3
Publication 1769-IN047C-EN-P - April 2003
Important User Information
Because of the variety of uses for the products described in this publication, those responsible for the
application and use of these products must satisfy themselves that all necessary steps have been taken to
assure that each application and use meets all performance and safety requirements, including any applicable
laws, regulations, codes and standards. In no event will Rockwell Automation be responsible or liable for
indirect or consequential damage resulting from the use or application of these products.
Any illustrations, charts, sample programs, and layout examples shown in this publication are intended solely
for purposes of example. Since there are many variables and requirements associated with any particular
installation, Rockwell Automation does not assume responsibility or liability (to include intellectual property
liability) for actual use based upon the examples shown in this publication.
Allen-Bradley publication SGI-1.1, Safety Guidelines for the Application, Installation and Maintenance of
Solid-State Control (available from your local Rockwell Automation office), describes some important
differences between solid-state equipment and electromechanical devices that should be taken into
consideration when applying products such as those described in this publication.
Reproduction of the contents of this copyrighted publication, in whole or part, without written permission of
Rockwell Automation, is prohibited.
Throughout this publication, notes may be used to make you aware of safety considerations. The following
annotations and their accompanying statements help you to identify a potential hazard, avoid a potential
hazard, and recognize the consequences of a potential hazard:
!
WARNING
Identifies information about practices or circumstances that can cause an explosion in a
hazardous environment, which may lead to personal injury or death, property damage,
or economic loss.
ATTENTION
!
Identifies information about practices or circumstances that can lead to personal injury
or death, property damage, or economic loss.
IMPORTANT Identifies information that is critical for successful application and understanding of the
product.

41769-L20, 1769-L30 CompactLogix™ Controllers
Publication 1769-IN047C-EN-P - April 2003
European Communities (EC) Directive Compliance
If this product has the CE mark it is approved for installation within the European
Union and EEA regions. It has been designed and tested to meet the following
directives.
EMC Directive
This product is tested to meet the Council Directive 89/336/EC Electromagnetic
Compatibility (EMC) by applying the following standards, in whole or in part,
documented in a technical construction file:
·EN 50081-2 EMC — Generic Emission Standard, Part 2 — Industrial
Environment
·EN 50082-2 EMC — Generic Immunity Standard, Part 2 — Industrial
Environment
This product is intended for use in an industrial environment.
Low Voltage Directive
This product is tested to meet Council Directive 73/23/EEC Low Voltage, by
applying the safety requirements of EN 61131-2 Programmable Controllers, Part 2 -
Equipment Requirements and Tests. For specific information required by
EN 61131-2, see the appropriate sections in this publication, as well as the
Allen-Bradley publication Industrial Automation Wiring and Grounding Guidelines
For Noise Immunity, publication 1770-4.1. and the Automation Systems Catalog,
publication B111.
This equipment is classified as open equipment and must be mounted in an
enclosure during operation to provide safety protection.

1769-L20, 1769-L30 CompactLogix™ Controllers 5
Publication 1769-IN047C-EN-P - April 2003
Hazardous Location Considerations
This equipment is suitable for use in Class I, Division 2, Groups A, B, C, D or
non-hazardous locations only. The following WARNING statement applies to use in
hazardous locations.
Environnements dangereux
Cet équipement est conçu pour être utilisé dans des environnements de Classe 1,
Division 2, Groupes A, B, C, D ou non dangereux. La mise en garde suivante
s’applique à une utilisation dans des environnements dangereux.
!
WARNING EXPLOSION HAZARD
·Substitution of components may impair suitability for Class
I, Division 2.
·Do not replace components or disconnect equipment
unless power has been switched off or the area is known
to be non-hazardous.
·Do not connect or disconnect components unless power
has been switched off or the area is known to be
non-hazardous.
·This product must be installed in an enclosure. All cables
connected to the product must remain in the enclosure or
be protected by conduit or other means.
·All wiring must comply with N.E.C. article 501-4(b).
AVERTISSEMENT
!
DANGER D’EXPLOSION
·La substitution de composants peut rendre cet équipement
impropre à une utilisation en environnement de Classe 1,
Division 2.
·Ne pas remplacer de composants ou déconnecter
l'équipement sans s'être assuré que l'alimentation est
coupée et que l'environnement est classé non dangereux.
·Ne pas connecter ou déconnecter des composants sans
s'être assuré que l'alimentation est coupée ou que
l'environnement est classé non dangereux.
·Ce produit doit être installé dans une armoire.

61769-L20, 1769-L30 CompactLogix™ Controllers
Publication 1769-IN047C-EN-P - April 2003
CompactLogix Controller Description
System Planning
Consider the following when planning your CompactLogix system:
·The CompactLogix controller is always the left-most module in the system.
·The controller must be located within four modules of the system power
supply. Some I/O module’s may be located up to 8 modules away from the
power supply. See the documentation for your 1769 I/O modules for details.
·The 1769-L20 controller supports up to 8 I/O modules in a maximum of 2
I/O banks (1 expansion cable allowed).
·The 1769-L30 controller supports up to 16 I/O modules in a maximum of 3
I/O banks (2 expansion cables allowed).
·Each I/O bank requires its own power supply.
·Only one controller can be used in a CompactLogix system.
·A 1769-ECR (right end cap) or 1769-ECL (left end cap) is required to
terminate the end of the communication bus.
1 DIN rail latch 8 Channel 0 RS-232 Port
2 panel mounting tab 9 Channel 0 default communication push button
3 tongue and groove slots 10 Channel 1 RS-232 Port
4 stationary bus connector 11 Channel 1 RS-232 Port Status LED
5 status LEDs 12 battery door
6 key switch 13 battery door label
7 Channel 0 RS-232 Port Status LED 14 battery(1)
(1) See Connect the Battery on page 8 for the actual position of the battery.
15 battery connector
1
12
23
3
4
5
6
7
8
7
8
99
10
14
15
12
13
11
1769-L20 controller 1769-L30 controller

1769-L20, 1769-L30 CompactLogix™ Controllers 7
Publication 1769-IN047C-EN-P - April 2003
Install the Controller
The 1769-L20 and 1769-L30 controllers are suitable for use in an industrial
environment when installed in accordance with these instructions. Specifically, this
equipment is intended for use in clean, dry environments (Pollution Degree 2(1))
and with circuits not exceeding Over Voltage Category II(2) (IEC 60664-1).(3)
Prevent Electrostatic Discharge
Remove Power
(1) Pollution Degree 2 is an environment where, normally, only non-conductive pollution occurs except that occasionally a
temporary conductivity caused by condensation shall be expected.
(2) Over Voltage Category II is the load level section of the electrical distribution system. At this level transient voltages are
controlled and do not exceed the impulse voltage capability of the product’s insulation.
(3) Pollution Degree 2 and Over Voltage Category II are International Electrotechnical Commission (IEC) designations.
ATTENTION
!
Electrostatic discharge can damage integrated circuits or
semiconductors if you touch bus connector pins. Follow these
guidelines when you handle the module:
·Touch a grounded object to discharge static potential.
·Wear an approved wrist-strap grounding device.
·Do not touch the bus connector or connector pins.
·Do not touch circuit components inside the module.
·If available, use a static-safe work station.
·When not in use, keep the module in its static-shield bag.
ATTENTION
!
Remove power before removing or inserting this module.
When you remove or insert a module with power applied, an
electrical arc may occur. An electrical arc can cause personal
injury or property damage by:
·sending an erroneous signal to your system’s field devices,
causing unintended machine motion
·causing an explosion in a hazardous environment
Electrical arcing causes excessive wear to contacts on both the
module and its mating connector. Worn contacts may create
electrical resistance.

81769-L20, 1769-L30 CompactLogix™ Controllers
Publication 1769-IN047C-EN-P - April 2003
Connect the Battery
The controller is shipped with the battery packed separately. To connect the
battery, follow the procedure shown below.
1. Slide the battery door (a) forward.
2. Insert the battery (b) into the battery holder. Insert the battery connector into
the connector port (c). The connector is keyed to engage only in the
correct polarity.
3. Slide the battery door (a) back until it clicks into position.
For information on battery handling, see page 20.
ATTENTION
!
Do not connect or disconnect the battery unless the
environment is known to be non-hazardous.
IMPORTANT Do not remove the plastic insulation covering the battery. The
insulation is necessary to protect the battery contacts.
b
a
c
b
a
c
1769-L20 controller 1769-L30 controller

1769-L20, 1769-L30 CompactLogix™ Controllers 9
Publication 1769-IN047C-EN-P - April 2003
Assemble the System
The controller can be attached to an adjacent I/O module or power supply before
or after mounting. For mounting instructions, see “Panel Mounting” on page 10, or
“DIN Rail Mounting” on page 11.
1. Disconnect line power.
2. Check that the lever of the adjacent module (A) is in the unlocked (fully
right) position.
3. Use the upper and lower tongue-and-groove slots (B) to secure the modules
together.
4. Move the module back along the tongue-and-groove slots until the bus
connectors line up with each other.
5. Use your fingers or a small screwdriver to push the module’s bus lever back
slightly to clear the positioning tab (C).
6. Move the module’s bus lever fully to the left (D) until it clicks. Ensure it is
locked firmly in place.
7. Attach an end cap terminator (E) to the last module in the system by using
the tongue-and-groove slots as before.
8. Lock the end cap bus terminator (F).
ATTENTION
!
When attaching the controller, power supply, and I/O
modules, it is very important that the bus connectors are
securely locked together to ensure proper electrical
connection.
F
E
D
C
B
B
A

10 1769-L20, 1769-L30 CompactLogix™ Controllers
Publication 1769-IN047C-EN-P - April 2003
Mount the System
Minimum Spacing
Maintain spacing from
enclosure walls,
wireways, adjacent
equipment, etc. Allow 50
mm (2 in.) of space on all
sides, as shown. This
provides ventilation and
electrical isolation.
Panel Mounting
Mount the controller to a panel using two screws per module. Use M4 or #8
panhead screws. Mounting screws are required on every module.
Panel Mounting Using the Dimensional Template
ATTENTION
!
During panel or DIN rail mounting of all devices, be sure that
all debris (metal chips, wire strands, etc.) is kept from falling
into the controller. Debris that falls into the controller could
cause damage while the controller is energized.
Bottom
Side Side
Top
CompactLogix
Controller
Power Supply
Compact I/O
Compact I/O
End Cap
50 mm
50 mm
50 mm
50 mm
35
(1.38)
35
(1.38)
132
(5.197)
122.6±0.2
(4.826±0.008)
35
(1.38)
28.5
(1.12)
25
(.985)
15
(.590)
35
(1.38)
CompactLogix Controller
Power Supply
Compact I/O Compact I/O
End Cap
NOTE: All dimensions are in mm (in.).
Hole spacing tolerance: ±0.4 mm (0.016 in.)
battery door

1769-L20, 1769-L30 CompactLogix™ Controllers 11
Publication 1769-IN047C-EN-P - April 2003
Panel Mounting Procedure Using Modules as a Template
The following procedure allows you to use the assembled modules as a template
for drilling holes in the panel. If you have sophisticated panel mounting equipment,
you can use the dimensional template provided on page 10. Due to module
mounting hole tolerance, it is important to follow these procedures:
1. On a clean work surface, assemble no more than three modules.
2. Using the assembled modules as a template, carefully mark the center of all
module-mounting holes on the panel.
3. Return the assembled modules to the clean work surface, including any
previously mounted modules.
4. Drill and tap the mounting holes for the recommended M4 or #8 screw.
5. Place the modules back on the panel and check for proper hole alignment.
6. Attach the modules to the panel using the mounting screws.
7. Repeat steps 1 to 6 for any remaining modules.
DIN Rail Mounting
The controller can be mounted using the following DIN rails:
·35 x 7.5 mm (EN 50 022 - 35 x 7.5)
·35 x 15 mm (EN 50 022 - 35 x 15)
Before mounting the controller on a DIN rail, close the DIN rail latches. Press the
DIN rail mounting area of the controller against the DIN rail. The latches will
momentarily open and lock into place.
TIP If mounting more modules, mount only the last one of
this group and put the others aside. This reduces
remounting time during drilling and tapping of the next
group.

12 1769-L20, 1769-L30 CompactLogix™ Controllers
Publication 1769-IN047C-EN-P - April 2003
Grounding Considerations
This product is intended to be mounted to a well-grounded mounting surface such
as a metal panel. Additional grounding connections from the controller’s mounting
tabs or DIN rail (if used), are not required unless the mounting surface cannot be
grounded. Refer to Industrial Automation Wiring and Grounding Guidelines,
Allen-Bradley publication 1770-4.1, for additional information.
Select the Controller’s Operating Mode
Use the keyswitch on the front panel of the controller to determine the controller’s
operating mode.
Keyswitch
Position
Description
RUN ·Run the program and enable outputs.
·You cannot create or delete tasks, programs, or routines. You cannot create or delete tags
or edit online while the keyswitch is in the RUN position.
·You cannot change the mode using the programming software while the keyswitch is in
the RUN position.
PROG ·Disable outputs.
·Upload projects.
·Create, modify, and delete tasks, programs, or routines.
·The controller does not execute (scan) tasks while the keyswitch is in the PROG position.
·You cannot change the mode through the programming software while the keyswitch is in
the PROG position.
REM Change between Remote Program, Remote Test, and Remote Run modes through the
programming software.
Remote Run ·The controller executes (scans) tasks.
·Enable outputs.
·Edit online.
Remote Program ·Disable outputs.
·Create, modify, and delete tasks, programs or routines.
·Download projects.
·Edit online.
·The controller does not execute (scan) tasks.
Remote Test ·Execute tasks with outputs disabled.
·Edit online.

1769-L20, 1769-L30 CompactLogix™ Controllers 13
Publication 1769-IN047C-EN-P - April 2003
RS-232 Connections to the Controller
The following illustrations show which cables can be used to connect to the
controller. To connect two cables to the 1769-L30 controller, you must connect the
straight cable end to Channel 0.
ATTENTION
!
When you connect or disconnect the serial cable while
backplane power is on, an electrical arc can occur. In
hazardous locations, this could cause an explosion.
NOTE: The Channel 0 port is locally
grounded. Only Channel 1 of the 1769-L30
controller is electrically isolated.
1769-L20 controller 1769-L30 controller
2 RDX
3 TXD
4 DTR
COMMON
6 DSR
7 RTS
8 CTS
9
1 CD
2 RDX
3 TXD
4 DTR
COMMON
6 DSR
7 RTS
8 CTS
9
1 CD
1747-CP3 or 1756-CP3
9-pin, male D-shell straight
cable end
9-pin, female D-shell
right-angle cable end
straight cable end right-angle cable end
This cable must be shielded and tied to the connector
housing.

14 1769-L20, 1769-L30 CompactLogix™ Controllers
Publication 1769-IN047C-EN-P - April 2003
Default Communication Configuration
Channel 0 and Channel 1 (1769-L30 controller only) have the following default
communication configuration.
Parameter Default
Protocol DF1 full-duplex
Baud Rate 19.2K
Parity none
Station Address 0
Control Lines no handshaking
Error Detection BCC
Embedded Responses auto detect
Duplicate Packet (Message) Detect enabled
ACK Timeout 50 (x 20 ms)
NAK Receive Limit 3 retries
ENQ Transmit Limit 3 retries
Data Bits 8
Stop Bits 1

1769-L20, 1769-L30 CompactLogix™ Controllers 15
Publication 1769-IN047C-EN-P - April 2003
Using the Channel 0 Default Communication Push Button
The Channel 0 Default Communication Push Button is located on the front of the
controller in the lower right corner as shown in the illustration below.
Use the Channel 0 Default Communication Push Button to change from the
user-defined communication configuration to the default communications mode.
The Channel 0 Default Communications (DCH0) LED turns on (green, steady) to
show when the default communication configuration is active.
TIP
·The Default Communication Push Button is recessed.
· Before pressing the Default Communication Push Button, be
sure to note the present communication configuration for
Channel 0. Pushing the Default Communication Push Button
resets all configured parameters back to their default settings.
To return the channel to its user-configured parameters, you
must enter them manually while online with the controller or
download them as part of an RSLogix 5000 Project file. To
accomplish this online using RSLogix 5000, enter the Controller
Properties screen and use the Serial Port, System Protocol and
User Protocol tabs.
CompactLogix5320 CompactLogix5330
Channel 0 Default
Communication Push
Button
Channel 0 Default
Communication Push
Button

16 1769-L20, 1769-L30 CompactLogix™ Controllers
Publication 1769-IN047C-EN-P - April 2003
Troubleshoot the Controller Using the LEDs
Indicator Color/Status Description
RUN Off No task(s) running
Controller in Program mode
Green One or more tasks are running
Controller is in the Run mode
FORCE Off No forces enabled
Amber Forces enabled
Amber Flashing One or more input or output addresses have been forced to an On
or Off state, but the forces have not been enabled
BAT Off Battery supports memory
Red Battery may not support memory, replace battery
OK Off No power applied
Green Controller OK
Red flashing Recoverable controller fault
Red Non-recoverable controller fault:
Cycle power. The OK LED should change to flashing red.
If LED remains solid red, replace the controller.
I/O Off(1)
(1) If the controller does not contain an application (controller memory is empty), the I/O indicator will be off.
No activity
No I/O or communications configured
Green Communicating to all modules
Green flashing One or more modules not responding
Red flashing Not communicating to any modules
DCH0 Off User-configured communications active
Green Default communication configuration active
Channel 0 Off No activity
Green Network activity (DH485)
Green flickering Data is being received or transmitted (DF1)
Channel 1 Off No activity
Green Network activity (DH485)
Green flickering Data is being received or transmitted (DF1)

1769-L20, 1769-L30 CompactLogix™ Controllers 17
Publication 1769-IN047C-EN-P - April 2003
Flash Upgrade the Controller Firmware
To update the firmware of a controller, first install a firmware upgrade kit.
·An upgrade kit ships on a supplemental CD along with RSLogix 5000
software.
·To download an upgrade kit, go to www.ab.com. Choose Product Support.
Choose Firmware Updates.
Update the Controller
1. Connect the controller’s serial port to your workstation. You can use either
serial port on the 1769-L30 controller.
2. Start ControlFLASH software.
3. Choose Next >.
4. Select the catalog number of the controller and choose Next >.
5. Expand the network until you see the controller. If the required network is
not shown, first configure a driver for the network in RSLinx software.
6. Select the controller and choose OK.
7. Select the revision level to which you want to update the controller and
choose Next >.
8. To start the update of the controller, choose Finish and then Yes. After the
controller is updated, the status box displays Update complete.
9. Choose OK.
10. To close ControlFLASH software, choose Cancel and then Yes
TIP RSLogix 5000 software, revision 10.0 or later, lets you update
controller firmware as part of the download sequence. To
update the controller, download your project and follow the
prompts of the software.
IMPORTANT If the Revision list is empty, download a new upgrade kit. Some
older upgrade kits do not work with new controllers.

18 1769-L20, 1769-L30 CompactLogix™ Controllers
Publication 1769-IN047C-EN-P - April 2003
Specifications
Description 1769-L20 controller 1769-L30 controller
Communication Ports (1) RS-232 (2) RS-232
User Memory 64K bytes 256K bytes
Maximum number of I/O modules
supported
8 I/O modules 16 I/O modules
Maximum number of I/O banks supported 2 banks 3 banks
Backplane Current 600 mA at +5V dc
0 mA at +24V dc
800 mA at +5V dc
0 mA at +24V dc
Operating Temperature 0° to +60°C (+32° to +140°F)
Storage Temperature -40° to +85°C (-40° to +185°F)
Relative Humidity 5% to 95% non-condensing
Power Supply Distance Rating 4 (The controller must be within four slot positions of the
power supply.)
Vibration Operating: 10 to 500 Hz, 5G, 0.030 in. peak-to-peak
Shock Operating: 30G, 11 ms, panel mounted
(20G, 11 ms, DIN rail mounted)
Non-operating: 40G, panel mounted
(30G, DIN rail mounted)
Shipping Weight 325g (0.715 lbs) 360g (0.792 lbs)
Battery 1747-BA; containing Sanyo CR14250SE battery cell
Programming Cable 1747-CP3 or 1756-CP3
Agency Certification ·C-UL certified (under CSA C22.2 No.142)
·UL 508 listed
·CE compliant for all applicable directives
Hazardous Environment Class Class I, Division 2, Hazardous Location, Groups A, B, C, D
(UL 1604, C-UL under CSA C22.2 No. 213)
Radiated and Conducted Emissions EN50081-2 Class A
Electrical /EMC: The unit has passed testing at the following levels:
ESD Immunity (IEC61000-4-2) 4 kV contact, 8 kV air, 4 kV indirect
Radiated Immunity (IEC61000-4-3) 10 V/m, 80 to 1000 MHz, 80% amplitude modulation, +900 MHz
keyed carrier
Fast Transient Burst (IEC61000-4-4) 2 kV, 5 kHz
Surge Immunity (IEC61000-4-5) 1 kV galvanic gun
Conducted Immunity (IEC61000-4-6) 10V, 0.15 to 80 MHz(1)
(1) Conducted Immunity frequency range may be 150 kHz to 30 MHz if the Radiated Immunity frequency range is 30 MHz to
1000 MHz.

1769-L20, 1769-L30 CompactLogix™ Controllers 19
Publication 1769-IN047C-EN-P - April 2003
Dimensions
CompactLogix Controller
See page 10 for CompactLogix System dimensions.
Compact I/O Expansion Cable, I/O, Power Supply and End Cap
Height (A) 118 mm (4.649 in.)
Width (B) 50 mm (1.97 in.)
Depth (C) 87 mm (3.43 in.)
TIP Compact I/O expansion cables have the same dimensions as
the end caps. Expansion cables can be used on either the right
or left end. A 1769-ECR (right end cap) or 1769-ECL (left end
cap) is required to terminate the end of the communication
bus.
RUN
FORCE
BATT
I/O
OK
DCH0
RUN
FORCE
BATT
I/O
OK
DCH0
REM PROGRUN
CompactLogix CompactLogix
LOGIX5320 LOGIX5330
A
B
A
BC
1769-L20 controller 1769-L30 controller
REM PROGRUN
NOTE: All dimensions are in mm (in.).
Hole spacing tolerance: ±0.4 mm (0.016 in.)
35
(1.38)
40
(1.58)
132
(5.197)
122.6±0.2
(4.826±0.008)
35
(1.38)
28.5
(1.12)
35
(1.38)
Power Supply
Right End Cap or Cable
Compact I/O Compact I/O
Left End Cap or Cable
NOTE: All dimensions are in mm (in.).
Hole spacing tolerance: ±0.4 mm (0.016 in.)

20 1769-L20, 1769-L30 CompactLogix™ Controllers
Publication 1769-IN047C-EN-P - April 2003
Battery Handling, Storing, and Transporting
(Cat. No. 1747-BA; containing Sanyo CR14250SE battery cell)
Handling
Storing
Store the lithium batteries in a cool, dry environment, typically +20°C to +25°C
(+68°F to +77°F) and 40% to 60% relative humidity.
Transporting
One or Two Batteries - Up to two batteries can be shipped together within the
United States without restriction. Regulations governing shipment to or within other
countries may differ.
Three or More Batteries - Procedures for the transportation of three or more
batteries shipped together within the United States are specified by the Department
of Transportation (DOT) in the Code of Federal Regulations, CFR49,
“Transportation”. An exemption to these regulations, DOT - E7052, covers the
transport of certain hazardous materials classified as flammable solids. This
exemption authorizes transport of lithium batteries by motor vehicle, rail freight,
cargo vessel, and cargo-only aircraft, providing certain conditions are met.
Transport by passenger aircraft is not permitted.
Shipment of depleted batteries for disposal may be subject to specific regulation of
the countries involved or to regulations endorsed by those countries, such as the
IATA Restricted Articles Regulations of the International Air Transport Association,
Geneva, Switzerland.
ATTENTION
!
Do not charge the batteries. An explosion could result or the
cells could overheat causing burns. Do not open, puncture,
crush, or otherwise mutilate the batteries. An explosion may
result and/or toxic, corrosive, and flammable liquids would be
exposed.
IMPORTANT Regulations for transportation of lithium batteries are
periodically revised.
