Allen + Roth L-DN2000SAL-B-ZH User manual

1
ITEM # 0809090
SOFA AND COFFEE TABLE
MODEL # L-DN2000SAL-B-ZH
Français p.10
PH18739
ATTACH YOUR RECEIPT HERE
Serial Number Purchase Date
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Friday.

2
PACKAGE CONTENTS
PART
DESCRIPTION
QUANTITY
A
Back
1
B1
Armrest 1
1
B2
Armrest 2
1
C
Seat
1
D
Leg
2
E
Back cushion
3
F
Cushion
3
G
Foot Pad (preassembled)
4
H
Top
1
I
Leg
2
J
Connect bar
4
K
Foot Pad (preassembled)
4

3
M6 x 45 mm
Bolt
Qty. 4 + 1 Spare
M6 x 35 mm
Bolt
Qty. 6 + 1 Spare
M6 x 15 mm
Bolt
Qty. 12 + 1 Spare
M6 x 20 mm
Bolt
Qty. 8 + 1 Spare
M6 Wrench
Qty. 2
HARDWARE CONTENTS (shown actual size)

4
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble or install
the product.
WARNING
Keep all children and pets away from assembly area. Children and pets should be
supervised when they are in the area of the set.
When placing in the desired location, ensure that all legs are resting on the same surface.
You may adjust the leg levelers as required to ensure that the item stands in a rigid position.
Some parts may contain sharp edges.
Any assembly or maintenance of the product must be carried out by adults only.
Proper placement of your set is essential. Do not place the product underneath electrical lines.
•
Keep fingers away from places where they can be pinched or trapped.
CAUTION
• Examine occasionally to ensure that there are no loose parts. If loose parts are found, they must
be retightened fully before additional use.
• Clean the product with mild soap and water. Rinse thoroughly and wait until the product is dry
before reassembling it.
• Do not use bleach, acid, or other abrasive cleaners on the products or frame parts.
• Do not attempt to assemble the set if any parts are missing.
• This product is intended for outdoor use only.
• Keep the original packaging to store the set.
The recommended weight limits for the following item is listed below:
Chair: 250 lbs. (per chair)
If you overload your furniture, injuries can occur.
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list and hardware contents list. If any part is missing or damaged, do not attempt to
assemble the product.
Estimated Assembly Time: 30 minutes

5
ASSEMBLY INSTRUCTIONS
M6 x 35 mm Bolt M6 Wrench x 1
1.
Attach seat (C) to armrests (B1, B2) using bolts (AA),hand tighten only with wrench (EE).
Hardware Used
1
x 6

6
ASSEMBLY INSTRUCTIONS
x 4
x 1
Hardware Used
3.
Attach back (A) to armrests (B1, B2) using bolts (BB), and to seat (C) using bolts (CC), hand
tighten only with wrench (EE), and then tighten all the bolts at last.
Hardware Used
2
3
2. Insert leg (D) to back (A) first, then secure with bolts (DD), hand tighten only with wrench (EE).
M6 Wrench
M6 x 45mm Bolt x 4
M6 x 20mm Bolt x 2
M6 Wrench x 1
M6 x 15 mm Bolt

7
ASSEMBLY INSTRUCTIONS
4.
Place cushions (F) onto seat (C), back
cushions (E) onto back (A)， secure with
hook and loop.
5.
Attach connect bar (J) to leg (I) using bolts (DD),hand tighten only with wrench (EE).
Hardware Used
4
5
x 8
M6 x 15 mm Bolt M6 Wrench x 1

8
ASSEMBLY INSTRUCTIONS
6.
6
Attach leg (I) to top (H) using bolts (CC),
hand tighten only with wrench (EE). Tighten all
the bolts at last.
Hardware Used
CARE AND MAINTENANCE
• Wash the frame with a mild solution of soap and water, rinse with clean water, and dry thoroughly.
• Cushions may also be cleaned by hand with a mild solution of soap and water. Rinse the cushion
cover thoroughly and allow to drip dry. Do not machine wash or tumble dry, as cushions may shrink.
Do not use bleach or solvents on fabrics. Never use cleaners that contain acid or abrasive materials.
• Bolts can loosen over time. Be sure to check bolts occasionally, tightening as needed.
• To improve the lifespan of this furniture, cover when not in use and store in a dry
place in the off season.
WARRANTY
This limited warranty is extended to the original purchaser and applies to defects in material and
workmanship of your item provided the item is maintained with care and used only for personal,
residential purposes.
The manufacturer warranty for this item, is to be free of defects in material and workmanship for
a period of 5 year frame and one (1) year fabric limited. If any defect is found, please call our
customer service department at
1-866-439-9800 for help. The manufacturer will not cover transportation or delivery costs or
compensate the individual or any outside party for assembling or disassembling the product. This
warranty gives you certain rights, and you may have other rights that vary from state to state.
6
M6 x 20mm Bolt x 4
M6 Wrench x 1

9
Printed in China
Production Number：20190785
REPLACEMENT PARTS LIST
For replacement parts, call our customer service department at 1-866-439-9800, 8 a.m. - 8 p.m.,
EST, Monday - Friday.
PART
DESCRIPTION
PART#
A
Back
P30129A06108
B1
Handrail 1
P30051A06108
B2
Handrail 2
P30055A06108
C
Seat
P30231A06108
D
Leg
P32314A06108
E
Back cushion
P00511B10126
F
Cushion
P00413B06126
G
Foot Pad (preassembled)
P91014A07001
H
Table top
P31343A06108
I
Leg
P31457A06108
J
Connect bar
P32509A06108
K
Foot Pad (preassembled)
P91012A07001
AA
M6 x 35 mm Bolt
H06035C11
BB
M6 x 45 mm Bolt H06045C11
CC
M6 x 20 mm Bolt H06020C11
DD
M6 x 15 mm Bolt H06015C11
EE
M6 Wrench H00002C12

10
ARTICLE # 0809090
CAUSEUSE ET TABLE BASSE
MODÈLE # L-DN2000SAL-B-ZH
JOIGNEZ VOTRE REÇU ICI
Numéro de série Date d’achat
Des questions, des problèmes, des pièces manquantes? Avant de retourner l’article au
détaillant, appelez notre service à la clientèle au 1 866 439-9800, entre 8 h et 20 h (HNE),
du lundi au vendredi.
