Allen + Roth LG-1009-LR User manual

ITEM #0355049
MODEL #LG-1009-LR
WOVEN ROCKER
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-866-439-9800, 8:00 a.m. – 8:00 p.m., EST, Monday – Friday.
ATTACH YOUR RECEIPT HERE
Serial Number__________________________ Purchase Date________________________
1
Française p. 6
Español p. 11
Lowes.com/allenandroth
allen + roth®is a registered trademark
of LF, LLC. All rights reserved.

PACKAGE CONTENTS
PART DESCRIPTION QUANTITY
A Right Arm 1
B Left Arm 1
C Seat 1
D Woven Back Panel 1
E Back Bar 1
HARDWARE CONTENTS (shown actual size)
AA BB CC DD
1/4 in. - 20 x 1.378 in. L
Long Bolt
Qty. 4
1/4 in. - 20
x 0.787 in. L
Short Bolt
Qty. 8
Washer Hex Wrench
Qty. 12 Qty. 1
2
A
F
G
H
Seat Cushion
Back Cushion
Lumbar Pillow
1
1
1
D
B
C
D
E
F
G
H
Lowes.com/allenandroth

• Read these instructions carefully before assembly.
• It takes two people to assemble this product.
• Paint on this furniture might peel if it is not handled properly. Handle with care.
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with
package contents list and hardware contents list. If any part is missing or damaged, do not
attempt to assemble the product.
Estimated Assembly Time: 30 minutes
Tools Required for Assembly: Hex Wrench (provided)
Hardware Used
Short Bolt (1/4 in. - 20 x 0.787 in. L)
Washer
x 2
x 2
SAFETY INFORMATION
ASSEMBLY INSTRUCTIONS
2
1
3
CC
AA
2. Assemble the back bar (E) to the left arm (B)
by inserting short bolt (AA) and washer (CC).
Match the sticker dots as shown.
Don’t tighten the bolts completely.
BB
CC
AA
AA
CC
Hardware Used
Long Bolt (1/4 in. - 20
x 1.378 in. L)
Washer
x 2
x 2
CC
BB
D
C
E
B
Lowes.com/allenandroth
1. Lay the back (D) on a soft surface such as a
carpet. Assemble the seat (C) to the back with two
sets of long bolts (BB) and washers (CC).
Do not tighten the bolts completely.

CARE AND MAINTENANCE
3. Assemble the seat (C) to the left arm (B)
by inserting short bolt (AA) and washer (CC).
Don’t tighten the bolts completely.
4
5
3
4. Assemble the seat (C) to the right arm (A)
by insert long bolt (BB) and washer (CC).
Again, don’t tighten the bolts completely.
Hardware Used
Washer
x 1
x 1
BB
Long Bolt (1/4 in. - 20
x 1.378 in. L)
CC
5. Assemble the seat (C) to the left arm (B)
by inserting long bolt (BB) and washer (CC).
Assemble the back bar (E) to the right arm
(A) by inserting short bolt (AA) and washer
(CC). Check alignment of all hardware and
make corrections if necessary. Fasten all
bolts tightly with hex wrench (DD).
Hardware Used
Short Bolt (1/4 in. - 20
x 0.787 in. L)
Washer
x 4
x 1
DD
AA
BB
x 5
Long Bolt (1/4 in. - 20
x 1.378 in. L)
CC
Hex Wrench
x 1
DD
AA
AA
CC
BB
CC
AA
CC
AA
CC
BB
CC
Hardware Used
Short Bolt (1/4 in. - 20
x 0.787 in. L)
Washer
x 2
x 2
CC
AA
Clean frame with a solution of warm water and mild soap. Dry completely. Do not use bleach
or solvents. Use a fine automotive wax to maintain gloss on non-textured finishes.
•
•The finish on furniture is formulated and baked on to make it highly resistant to repellents and
lotions. However, to avoid discoloration, clean the frame as soon as possible after exposure.
• Paint on this furniture might peel if it is not handled properly. Handle with care.
C
B
C
A
prevent mildew by washing out dirt particles that may become trapped. Shake out excess
moisture after rinsing and allow to dry thoroughly before storing.
• For best results, clean weave regularly with mild detergent and warm water. Cleaning will help
Lowes.com/allenandroth
4

LIMITED WARRANTY
•This limited warranty is extended to the original purchaser and applies to defects in materials
and workmanship of your patio furniture, provided your furniture is maintained with care and
used only for personal, residential purposes.
•Frames and welds are warranted to be free from defects in material or workmanship for a
period of five (5) years.
•Finish is warranted against peeling, cracking or blistering for a period of one (1) year.
•
•Exclusions: Items used for commercial, contract or other non-residential purposes; display
models; items purchased “as is;” or items damaged due to acts of nature, vandalism, misuse
or improper assembly are not covered. Discoloration or fading of the finish or fabrics as a
result of exposure to the elements, chemicals or spills; tabletop breakage; corrosion or rusting
of hardware; and damages to frames or welds caused by improper assembly, misuse or natural
causes are not covered.
If within the stated warranty period a product is found to be defective in material or workmanship,
the purchaser must contact the manufacturer’s customer service department at 1-866-439-9800.
The manufacturer, at its option, will repair or replace the defective parts.
Warranty is to the original purchaser and is non-transferable. Any replacement of warranted items
will be in the original style and color, or a similarstyle and color if the original is unavailable or has
been discontinued. As some states do not allow exclusions or limitations on an implied warranty,
the above exclusions and limitations may not apply. This warranty gives you specific rights, and
you may also have other rights which vary from state to state.
REPLACEMENT PARTS LIST
For replacement parts, call our customer service department at 1-866-439-9800,
8:00 a.m. – 8:00 p.m., EST, Monday – Friday.
PART DESCRIPTION
A
B
C
D
E
F
Hardware Kit
Printed in China
PART#
LG1009-3608-SR
G
H
5
Cushion and throw pillow are warranted to be NO-FADE free from defects in workmanship for
a period of five (5) years.
•
Spot wash fabric by sponging briskly with a soapy solution in lukewarm water (do not exceed 100 F).
Thoroughly rinse with clean water to remove soap. Allow to air dry completely before storing.
Right Arm
Left Arm
Seat
Woven Back Panel
Back Bar
Seat Cushion
Back Cushion
Throw Pillow
LG1009-3608-SL
LG1009-3608-CS
LG1009-3608-CB
LG1009-3608-BT
LG1009-3608-SC
LG1009-3608-BC
LG1009-3608-MP
LG1009-3608-HW
I
A
D
B
C
D
E
F
G
H
Lowes.com/allenandroth
I
BB&CC 1/4"-20x1.378"LONG BOLT&WASHER 4PCS
AA&CC 1/4"-20x0.787"SHORT BOLT&WASHER 8PCS
DD HEX WRENCH 1PC
ITEM# 355049 MODEL# LG-1009-LR
A+R LAWLEY WOVEN ROCKER
