Alliance Laundry Systems HSA030N User manual

Installation
Stacked Washer-Extractor/
Tumble Dryer
Stacked 30 Pound (13/13 Kilogram) Capacity
Stacked 50 Pound (22/22 Kilogram) Capacity
Designs 1 and 2
Refer to Page 15 for Model Identification
STX1C_SVG
Original Instructions
Keep These Instructions for Future Reference.
CAUTION: Read the instructions before using the machine.
(If this machine changes ownership, this manual must accompany machine.)
www.alliancelaundry.com Part No. F8690001ENR7
December 2021

Installation must conform with local codes or, in the absence of
local codes, with:
In the U.S.A., installation must conform to the latest edition of
the American National Standard Z223.1/ NFPA 54 “National
Fuel Gas Code” and Standard ANSI/NFPA 70 “National Electric
Code.”
In Canada, installation must comply with Standards CAN/CSA-
B149.1 Natural Gas and Propane Installation Code and CSA
C22.1, latest edition, Canadian Electric Code, Part I.
In Australia and New Zealand, installation must comply with the
Gas Installations Standard AS/NZS 5601 Part 1: General Installa-
tions.
In Europe, before installation, check that the local distribution
conditions, nature of gas and pressure, and the adjustment of the
appliance are compatible.
This equipment has been designed and certified to comply with
IEC/EN 60335 electrical safety standards for tumble dryers.
Read all instructions before using tumble dryer.
IMPORTANT: If it is unavoidable that fabrics that con-
tain vegetable or cooking oil or have been contaminat-
ed by hair care products be placed in a tumble dryer,
they should first be washed in hot water with extra de-
tergent. This will reduce, but not eliminate, the hazard.
WARNING
FOR YOUR SAFETY, the information in this manual
must be followed to minimize the risk of fire or ex-
plosion or to prevent property damage, personal in-
jury or death.
W033
DANGER
Electric shock hazard will result in death or serious
injury. Disconnect all electric power to appliance and
accessories and wait five (5) minutes before servic-
ing.
W925
Units are IPx4 when enclosed per these instructions.
WARNING
• Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
• WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Clear the room, building or area of all occu-
pants.
• Immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s in-
structions.
• If you cannot reach your gas supplier, call the
fire department.
• Installation and service must be performed by a
qualified installer, service agency or the gas sup-
plier.
W052
IMPORTANT: Information must be obtained from a lo-
cal gas supplier on instructions to be followed if the
user smells gas. These instructions must be posted in
a prominent location. Step-by-step instructions of the
above safety information must be posted in a promi-
nent location near the tumble dryer for customer use.
IMPORTANT: Post the following statement in a promi-
nent location
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appli-
ance.
IMPORTANT: The installer must fully test the tumble
dryer after installation and demonstrate to the owner
how to operate the machine.
IMPORTANT: The machine shall only be installed in a
room separated from inhabited rooms, incorporating
appropriate ventilation specified in the National Instal-
lation Regulations.
IMPORTANT: The tumble dryer is not to be used if in-
dustrial chemicals have been used for cleaning.
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
3 Part No. F8690001ENR7

WARNING
To reduce the risk of electric shock, fire, explosion,
serious injury or death:
• Disconnect electric power to the tumble dryer be-
fore servicing.
• Close gas shut-off valve to gas tumble dryer be-
fore servicing.
• Close steam valve to steam tumble dryer before
servicing.
• Never start the tumble dryer with any guards/
panels removed.
• Whenever ground wires are removed during serv-
icing, these ground wires must be reconnected to
ensure that the tumble dryer is properly ground-
ed.
W002R1
WARNING
• Installation of unit must be performed by a quali-
fied installer.
• Install tumble dryer according to manufacturer’s
instructions and local codes.
• DO NOT install a tumble dryer with flexible plastic
venting materials. If flexible metal (foil type) duct
is installed, it must be of a specific type identified
by the appliance manufacturer as suitable for use
with tumble dryer. Refer to section on connecting
exhaust system. Flexible venting materials are
known to collapse, be easily crushed, and trap
lint. These conditions will obstruct tumble dryer
airflow and increase the risk of fire.
W752R1
CAUTION
TO AVOID THE RISK OF FIRE THIS DRYER MUST BE
EXHAUSTED OUTDOORS.
W928
WARNING
To reduce the risk of serious injury: Avoid contact
with hot surfaces.
W927
WARNING
Electrical shock hazard can cause death or serious
injury. To reduce the risk of electric shock, discon-
nect all electric power to appliance and accessories
before servicing.
W929
WARNING
Moving parts hazard can cause serious injury. Dis-
connect electric power to unit before servicing. Un-
expected start of machinery will occur if the unit is
equipped with the extended tumble feature.
W937
WARNING
Lint compartment must be cleaned daily
To avoid the risk of fire:
• Use for drying water washed fabrics only.
• DO NOT dry articles containing foam rubber, plas-
tic, or similarly textured rubber like materials.
• DO NOT put articles soiled with cooking oil in dry-
er as cooking oil may not be removed during
washing. Due to the remaining oil the fabric may
catch on fire by itself.
• DO NOT put articles soiled with flammable liquids
or flammable cleaning solvents in dryer.
W930
CAUTION
• Risk of fire, a clothes dryer produces combustible
lint. Exhaust outdoors. Care should be taken to
prevent the accumulation of lint around the ex-
haust opening and in the surrounding area.
• DO NOT reach into the dryer until all moving parts
have stopped.
• DO NOT let children play on or in the dryer.
W931
In Australia and New Zealand:
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
4 Part No. F8690001ENR7

WARNING
• DO NOT operate this appliance before reading the
instruction booklet.
• DO NOT place articles on or against this appli-
ance.
• DO NOT store chemicals or flammable materials
or spray aerosols near this appliance.
• DO NOT operate with panels, covers or guards re-
moved from this appliance.
• DO NOT load materials containing flammable sol-
vents into this appliance.
• If repeated ignition reset is required, the dryer
should not be used and a service call booked.
Risk of fire/flammable material.
W926
The following information applies to the state of Massachusetts,
USA.
• This appliance can only be installed by a Massachusetts li-
censed plumber or gas fitter.
• This appliance must be installed with a 36 inch [91 cm] long
flexible gas connector.
• A “T-Handle” type gas shut-off valve must be installed in the
gas supply line to this appliance.
• This appliance must not be installed in a bedroom or bath-
room.
Regulatory Statements
PRODUCT COMPLIANCE
Users of this product are cautioned not to make modifications or
changes that are not approved by Alliance Laundry Systems,
LLC. Doing so may void the compliance of this product with ap-
plicable laws and regulatory requirements and may result in the
loss of the user’s authority to operate the equipment.
UNITED STATES
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions; (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause un-
desired operation.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. How-
ever, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful inter-
ference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following meas-
ures:
• Reorient or relocate the radio or television receiving antenna.
• Increase the separation between the computer equipment or
receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the radio or television receiver is connect-
ed.
• Consult the dealer or experienced radio television technician
for help.
CAUTION
To comply with the limits of the Class B device, pur-
suant to Part 15 of the FCC Rules, this device is to
comply with Class B limits. All peripherals must be
shielded and grounded. Operation with non-certified
peripherals or non-shielded cables is likely to result
in interference and reception of the device.
W1004
Radiation Exposure Statement: This equipment complies with
FCC radiation exposure limits set forth for an uncontrolled envi-
ronment. The radio installed in this equipment and is intended to
operate with minimum distance 20cm between the radiator and
your body.
Limited Channels Fixed For Use In USA: IEEE 802.11b or
802.11g or 802.11n(HT20) operation of this product in the U.S. is
firmware-limited to Channel 1 through 11.
CANADA - CAN ICES-3(B)/NMB-3(B)
This device contains license-exempt transmitter(s)/receiver(s)
that comply with Innovation, Science and Economic Develop-
ment Canada’s license-exempt RSS(s) standards. Operation is
subject to the following two conditions:
• This device may not cause interference.
• This device must accept any interference, including interfer-
ence that may cause undesired operation of the device.
Radiation Exposure Statement: This equipment complies with
Innovation, Science and Economic Development Canada’s radia-
tion exposure limits set forth for in RSS-102. The radio installed
in this equipment is installed and is intended to operate with min-
imum distance 20cm between the radiator and your body.
EUROPE
Products bearing the CE mark comply with the following EU di-
rectives:
• EMC Directive 2014/30/EU
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
5 Part No. F8690001ENR7

• Machinery Directive 2006/42/EC
• Gas Appliance Directive 2016/426/EU
• RoHS Directive 2011/65/EU and its amendment directives;
Commission Delegated Directive 2015/863 to restrict four
phthalates
If the product has telecommunications functionality, it also com-
plies with the requirements of the following EU directive:
• Radio Equipment Directive 2014/53/EU
Compliance with these Directives implies conformity to harmon-
ized European standards that are noted in the EU Declaration of
Conformity which is available upon request.
Alliance Laundry Systems products comply with the requirement
of Article 12 as it can be operated in at least one Member State as
examined and the product is compliant with Article 11 as it has
no restrictions on putting into service in all EU member states.
This device contains a 2.4GHz transceiver, intended for indoor
use only in all EU member states, EFTA states, and Switzerland.
Attention has been given to allowed operational frequencies. For
detailed information concerning installations in France, the user
should contact the national spectrum authority in France (http://
www.arcep.fr/ )
Be aware that outdoor installations require special attention and
will only be handled by trained and qualified installation person-
nel. No one from the general-public is permitted to install wire-
less products outdoors when external antennas, power and
grounding must be installed for use.
AUSTRALIA/NEW ZEALAND
The radio in this equipment complies with and is certified to the
Australian and New Zealand regulatory requirements.
BRAZIL ANATEL
This device is not entitled to protection against harmful interfer-
ence and may not interfere with duly authorized systems.
CHINA SRRC
The radio device has recieved certification of conformance in ac-
cordance with the People's Republic of China State Radio Regu-
lation Committee (SRRC) certification scheme. Integrations of
this radio into a final product does not require additional radio
certification provided installation instructions are followed. No
changes are authorized to the radio or the antenna of the ap-
proved device.
JAPAN
This product is equipped with a certified wireless device pursuant
to Article 2-1-19 of the Certification Ordinance. No changes are
authorized to the radio or the antenna of the approved device.
MEXICO IFETEL
“The operation of this equipment is subject to the following two
conditions: (1) it is possible that this equipment or device does
not cause harmful interference and (2) this equipment or device
must accept any interference, including that which may cause its
unwanted operation.”
SOUTH KOREA (KC)
The radio device has received certification of conformance in ac-
cordance with the Radio Waves Act. Integration of this radio into
a final product does not require additional radio certification pro-
vided installation instructions are followed. No changes are au-
thorized to the radio or the antenna of the approved device.
TAIWAN
The information in this section applies to products bearing the
Taiwan National Communications Commission mark:
This telecom equipment has complied with NCC regulations.
According to “Administrative Regulations of Low Power Radio
Waves Radiated Devices:
Article 12 The low-power radio-frequency devices must not be
altered by changing the frequency, enhancing emission power,
adding external antenna, and modification of original design
characteristic as well as function.
Article 14 The operation of the low-power radio-frequency devi-
ces is subject to the conditions that no harmful interference is
caused. The user must stop operating the device immediately
should harmful interference is caused and shall not resume until
the condition causing the harmful interference has been correct-
ed.
Moreover, the interference must be accepted that may be caused
by the operation of an authorized communications, or ISM equip-
ment. (1) Precautions (marked in the product manual and on out-
er packaging)
THAILAND
The information in this section applies to products approved by
the Thailand National Communications Commission:
These telecommunication and device are compliance with the re-
quirements of National Broadcasting and Telecommunication
Commission.
Manufacturing Date
The manufacturing date for your unit can be found on the serial
number. The first two digits indicate the year. The third and
fourth digits indicate the month. For example, a unit with serial
number 1505000001 was manufactured in May 2015.
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
6 Part No. F8690001ENR7

Recommended Program For Nominal
Load
The wash program recommended in this manual is for a nominal
load at rated load capacity. Refer to programming manual for de-
tails of wash program.
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
7 Part No. F8690001ENR7

China Restriction of hazardous substances
(RoHS)
The Table of Hazardous Substances/Elements and their Content As required by China’s Management Methods for Restricted Use
of Hazardous Substances in Electrical and Electronic Products
Hazardous substances
Part Name Lead
(Pb)
Mercury
(Hg)
Cadmium
(Cd)
Hexavalent
Chromium
(CR[VI])
Polybromi-
nated biphen-
yls
(PBB)
Polybromi-
nated diphen-
yl ethers
(PBDE)
PCBs X O O O O O
Electromechanical Parts O O O O O O
Cables and Wires O O O O O O
Metal Parts O O O O O O
Plastic Parts O O O O O O
Batteries O O O O O O
Hoses and Tubing O O O O O O
Timing Belts O O O O O O
Insulation O O O O O O
Glass O O O O O O
Display O O O O O O
This table is prepared in accordance with the provisions of SJ/T-11364.
O: Indicates that the content of said hazardous substance in all of the homogenous materials in the component is within the limits
required by GB/T 26572.
X: Indicates that the content of said hazardous substance exceeds the limits required by GB/T 26572 in at least one homogenous
material in the component.
All parts named in this table with an “X” are in compliance with the European Union’s RoHS Legislation.
NOTE: The referenced Environmental Protection Use Period Marking was determined according to normal oper-
ating use conditions of the product such as temperature and humidity.
This product under normal use, durable years of environmental protection is 15 years.
China Restriction of hazardous substances (RoHS)
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
8 Part No. F8690001ENR7

Safety Information
Explanation of Safety Messages
Precautionary statements (“DANGER,” “WARNING,” and
“CAUTION”), followed by specific instructions, are found in this
manual and on machine decals. These precautions are intended
for the personal safety of the operator, user, servicer, and those
maintaining the machine.
DANGER
Indicates an imminently hazardous situation that, if
not avoided, will cause severe personal injury or
death.
WARNING
Indicates a hazardous situation that, if not avoided,
could cause severe personal injury or death.
CAUTION
Indicates a hazardous situation that, if not avoided,
may cause minor or moderate personal injury or
property damage.
Additional precautionary statements (“IMPORTANT” and
“NOTE”) are followed by specific instructions.
IMPORTANT: The word “IMPORTANT” is used to in-
form the reader of specific procedures where minor
machine damage will occur if the procedure is not fol-
lowed.
NOTE: The word “NOTE” is used to communicate in-
stallation, operation, maintenance or servicing informa-
tion that is important but not hazard related.
Important Safety Instructions (Tumble
Dryer)
WARNING
To reduce the risk of fire, electric shock, serious in-
jury or death to persons when using your tumble
dryer, follow these basic precautions.
W776R1
Save These Instructions
• Read all instructions before using the tumble dryer.
• Install the tumble dryer according to the INSTALLATION in-
structions. Refer to the EARTHING (grounding) instructions
for the proper earthing (grounding) of the tumble dryer. All
connections for electrical power, earthing (grounding) and gas
supply must comply with local codes and be made by licensed
personnel when required. It is recommended that the machine
be installed by qualified technicians.
• Do not install or store the tumble dryer where it will be ex-
posed to water and/or weather. The tumble dryer cannot be
used in a closed room where the air supply is insufficient. If
necessary, ventilation grids must be installed in the doors or
the windows.
• This tumble dryer must not be activated without lint screen
filter.
• When you perceive a gas odor, immediately shut off the gas
supply and ventilate the room. Do not power on electrical ap-
pliances and do not pull electrical switches. Do not use
matches or lighters. Do not use a phone in the building. Warn
the installer, and if so desired, the gas company, as soon as
possible.
• To avoid fire and explosion, keep surrounding areas free of
flammable and combustible products. Regularly clean the cyl-
inder and exhaust tube should be cleaned periodically by
competent maintenance personnel. Daily remove debris from
lint screen filter and inside of filter compartment.
• Do not use or store flammable materials near this appliance.
• Do not place into tumble dryer articles that have been previ-
ously cleaned in, washed in, soaked in or spotted with gaso-
line or machine oils, vegetable or cooking oils, cleaning wax-
es or chemicals, dry-cleaning solvents, thinner or other flam-
mable or explosive substances as they give off vapors that
could ignite, explode or cause fabric to catch on fire by itself.
• Do not spray aerosols in the vicinity of this appliance while it
is in operation.
• Items such as foam rubber (latex foam), shower caps, water-
proof textiles, rubber backed articles and clothes or pillows
filled with foam rubber pads should not be dried in the tumble
dryer. Do not use the appliance to dry materials with a low
melting temperature (PVC, rubber, etc.).
• Do not tumble fiberglass curtains and draperies unless the la-
bel says it can be done. If they are dried, wipe out the cylinder
with a damp cloth to remove particles of fiberglass.
• Do not allow children to play on or in the dryer. Close super-
vision of children is necessary when the dryer is used near
children. This appliance is not intended for use by persons
(including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning the use
of the appliance by a person responsible for their safety. This
is a safety rule for all appliances.
• Cleaning and user maintenance shall not be made by children
without supervision.
• Children less than three years should be kept away unless
continuously supervised.
• Do not reach into the tumble dryer if the cylinder is revolving.
Safety Information
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
9 Part No. F8690001ENR7

• Use tumble dryer only for its intended purpose, drying fab-
rics. Always follow the fabric care instructions supplied by
the textile manufacturer and only use the dryer to dry textiles
that have been washed in water. Only insert spin-dried linen
in the dryer to avoid damage to dryer.
• Always read and follow manufacturer’s instructions on pack-
ages of laundry and cleaning aids. Follow all warnings or pre-
cautions. To reduce the risk of poisoning or chemical burns,
keep them out of the reach of children at all times (preferably
in a locked cabinet).
• Do not use fabric softeners or products to eliminate static un-
less recommended by the manufacturer of the fabric softener
or product.
• Remove laundry immediately after tumble dryer stops.
• DO NOT operate the tumble dryer if it is smoking, grinding
or has missing or broken parts or removed guards or panels.
DO NOT tamper with the controls or bypass any safety devi-
ces.
• Tumble dryer will not operate with the loading door open. DO
NOT bypass the door safety switch to permit the tumble dryer
to operate with the door open. The tumble dryer will stop ro-
tating when the door is opened. Do not use the tumble dryer if
it does not stop rotating when the door is opened or starts
tumbling without pressing the START mechanism. Remove
the tumble dryer from use and call for service.
• Tumble dryer will not operate with lint panel open. DO NOT
bypass lint panel door safety switch to permit the tumble dry-
er to operate with the lint panel door open.
• Do not alter this tumble dryer from factory construction ex-
cept as otherwise described in the technical instructions.
• Always clean the lint filter daily. Keep area around the ex-
haust opening and adjacent surrounding area free from the ac-
cumulation of lint, dust and dirt. The interior of the tumble
dryer and the exhaust duct should be cleaned periodically by
qualified service personnel.
• Solvent vapors from dry-cleaning machines create acids when
drawn through the heater of the drying unit. These acids are
corrosive to the tumble dryer as well as the laundry load being
dried. Be sure make-up air is free of solvent vapors.
• At the end of each working day, close off all main supplies of
gas, steam and electricity.
IMPORTANT: For fire suppression equipped tumble
dryers, electricity and water should NOT be turned
off.
• Do not repair or replace any part of the tumble dryer, or at-
tempt any servicing unless specifically recommended in the
user-maintenance instructions or in published user-repair in-
structions that the user understands and has the skills to carry
out. ALWAYS disconnect and lockout the electrical power to
the tumble dryer before servicing. Disconnect power by shut-
ting off appropriate breaker or fuse.
• Activation of the emergency stop switch stops all tumble dry-
er control circuit functions, but DOES NOT remove all elec-
trical power from tumble dryer.
• Exhaust ductwork should be examined and cleaned annually
after installation.
• Before the tumble dryer is removed from service or discarded,
remove the door to the drying compartment and the door to
the lint compartment.
• Failure to install, maintain, and/or operate this tumble dryer
according to the manufacturer’s instructions may result in
conditions which can produce bodily injury and/or property
damage.
NOTE: The WARNINGS and IMPORTANT SAFETY IN-
STRUCTIONS appearing in this manual are not meant
to cover all possible conditions and situations that may
occur. Observe and be aware of other labels and pre-
cautions that are located on the machine. They are in-
tended to provide instruction for safe use of the ma-
chine. Common sense, caution and care must be exer-
cised when installing, maintaining, or operating the
tumble dryer.
Always contact your dealer, distributor, service agent or the man-
ufacturer about any problems or conditions you do not under-
stand.
NOTE: All appliances are produced according to the
EMC-directive (Electro-Magnetic-Compatibility). They
can be used in restricted surroundings only (comply
minimally with class A requirements). For safety rea-
sons there must be kept the necessary precaution dis-
tances with sensitive electrical or electronic device(s).
These machines are not intended for domestic use by
private consumers in the home environment.
Important Safety Instructions (Washer-
Extractor)
WARNING
To reduce the risk of fire, electric shock, serious in-
jury or death to persons when using your washer,
follow these basic precautions:
W023
• Read all instructions before using the washer.
• Install the washer according the INSTALLATION instruc-
tions. Refer to the EARTH/GROUND instructions in the IN-
STALLATION manual for the proper earth/ground connection
of the washer. All connections for water, drain, electrical
power and earth/ground must comply with local codes and be
made by licensed personnel when required. It is recommend-
ed that the machine be installed by qualified technicians.
• Do not install or store the washer where it will be exposed to
water and/or weather.
• To prevent fire and explosion, keep the area around machine
free from flammable and combustible products. Do not add
the following substances or textiles containing traces of the
Safety Information
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
10 Part No. F8690001ENR7

following substances to the wash water: gasoline, kerosene,
waxes, cooking oils, vegetable oils, machine oils, dry-clean-
ing solvents, flammable chemicals, thinners, or other flamma-
ble or explosive substances. These substances give off vapors
that could ignite, explode or cause the fabric to catch fire by
itself.
• Under certain conditions, hydrogen gas may be produced in a
hot water system that has not been used for two weeks or
more. HYDROGEN GAS IS EXPLOSIVE. If the hot water
system has not been used for such a period, before using a
washing machine or combination washer-dryer, turn on all hot
water faucets and let the water flow from each for several mi-
nutes. This will release any accumulated hydrogen gas. The
gas is flammable, do not smoke or use an open flame during
this time.
• To reduce the risk of an electric shock or fire, DO NOT use an
extension cord or an adapter to connect the washer to the elec-
trical power source.
• Do not allow children to play on or in the washer. Close su-
pervision of children is necessary when the washer is used
near children. This appliance is not intended for use by young
children or infirm persons without supervision. Young chil-
dren should be supervised to ensure that they do not play with
the appliance. This is a safety rule for all appliances.
• DO NOT reach and/or climb into the tub or onto the washer,
ESPECIALLY if the wash drum is moving. This is an immi-
nently hazardous situation that, if not avoided, will cause se-
vere personal injury or death.
• Never operate the washer with any guards, panels and/or parts
removed or broken. DO NOT bypass any safety devices or
tamper with the controls.
• Use washer only for its intended purpose, washing textiles.
Never wash machine parts or automotive parts in the ma-
chine. This could result in serious damage to the basket or
tub.
• Use only low-sudsing, no-foaming types of commercial deter-
gent. Be aware that hazardous chemicals may be present.
Wear hand and eye protection when adding detergents and
chemicals. Always read and follow manufacturer’s instruc-
tions on packages of laundry and cleaning aids. Heed all
warnings or precautions. To reduce the risk of poisoning or
chemical burns, keep them out of the reach of children at all
times [preferably in a locked cabinet].
• Do not use fabric softeners or products to eliminate static un-
less recommended by the manufacturer of the fabric softener
or product.
• Always follow the fabric care instructions supplied by the tex-
tile manufacturer.
• Do not attach anything to the supply dispenser’s nozzles, if
applicable. The air gap must be maintained.
• Do not operate the machine without the water reuse plug or
water reuse system in place, if applicable.
• Be sure water connections have a shut-off valve and that fill
hose connections are tight. CLOSE the shut-off valves at the
end of each wash day.
• Keep washer in good condition. Bumping or dropping the
washer can damage safety features. If this occurs, have wash-
er checked by a qualified service person.
• DANGER: Before inspecting or servicing machine, power
supply must be turned OFF. The servicer needs to wait for at
least 5 minutes after turning the power OFF and needs to
check for residual voltage with a voltage meter. The inverter
capacitor or EMC filter remains charged with high voltage for
some time after powering OFF. This is an imminently hazard-
ous situation that, if not avoided, will cause severe personal
injury or death.
• Do not repair or replace any part of the washer, or attempt any
servicing unless specifically recommended in the user-mainte-
nance instructions or in published user-repair instructions that
the user understands and has the skills to carry out. ALWAYS
disconnect the washer from electrical, power and water sup-
plies before attempting any service.
• Disconnect the power by turning off the circuit breaker or by
unplugging the machine. Replace worn power cords.
• Failure to install, maintain, and/or operate this washer accord-
ing to the manufacturer’s instructions may result in conditions
which can produce bodily injury and/or property damage.
NOTE: The WARNINGS and IMPORTANT SAFETY IN-
STRUCTIONS appearing in this manual are not meant
to cover all possible conditions and situations that may
occur. Common sense, caution and care must be exer-
cised when installing, maintaining, or operating the
washer.
Any problems or conditions not understood should be reported to
the dealer, distributor, service agent or the manufacturer.
WARNING
Machine installations must comply with minimum
specifications and requirements stated in the appli-
cable Installation Manual, any applicable municipal
building codes, water supply requirements, electrical
wiring regulations and any other relevant statutory
regulations. Due to varied requirements and applica-
ble local codes, this machine must be installed, ad-
justed, and serviced by qualified maintenance per-
sonnel familiar with applicable local codes and the
construction and operation of this type of machinery.
They must also be familiar with the potential hazards
involved. Failure to observe this warning may result
in personal injury, property damage, and/or equip-
ment damage, and will void the warranty.
W820
Safety Information
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
11 Part No. F8690001ENR7

NOTE: All appliances are produced according the EMC-
directive (Electro-Magnetic-Compatibility). They can be
used in restricted surroundings only (comply minimally
with class A requirements). For safety reasons there
must be kept the necessary precaution distances with
sensitive electrical or electronic device(s). These ma-
chines are not intended for domestic use by private
consumers in the home environment.
Safety Decals
Safety decals appear at crucial locations on the machine. Failure
to maintain legible safety decals could result in injury to the oper-
ator or service technician.
Use manufacturer-authorized spare parts to avoid safety hazards.
Operator Safety
WARNING
NEVER insert hands or objects into basket until it
has completely stopped. Doing so could result in se-
rious injury.
SW012
Machines referred to by model in this manual are intended to be
used by the general public in applications such as:
• staff areas in shops, offices, kitchens and other working envi-
ronments
• by clients in hotels, motels and other residential type environ-
ments
• areas for communal use in blocks of flats or in launderettes
• any other similar applications
Installation of these machines must fully conform to the instruc-
tions contained in this manual.
The following maintenance checks must be performed daily:
1. Verify that all warning labels are present and legible, replace
as necessary.
2. Check door interlock before starting operation of the ma-
chine:
a. Attempt to start the machine with the door open. The ma-
chine should not start.
b. Close the door without locking it and start the machine.
The machine should not start.
c. Attempt to open the door while a cycle is in progress. The
door should not open.
If the door lock and interlock are not functioning properly, dis-
connect power and call a service technician.
3. Do not attempt to operate the machine if any of the following
conditions are present:
a. The door does not remain securely locked during the en-
tire cycle.
b. Excessively high water level is evident.
c. Machine is not connected to a properly grounded circuit.
Do not bypass any safety devices in the machine.
WARNING
Operating the machine with severe out-of-balance
loads could result in personal injury and serious
equipment damage.
W728
Safety Information
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
12 Part No. F8690001ENR7

Table of Contents
Safety Information................................................................................. 9
Explanation of Safety Messages....................................................................... 9
Important Safety Instructions (Tumble Dryer)................................................... 9
Important Safety Instructions (Washer-Extractor).............................................10
Safety Decals................................................................................................12
Operator Safety.............................................................................................12
Introduction..........................................................................................16
Model Identification......................................................................................16
Contact Information...................................................................................... 17
Replacement Parts ........................................................................................17
Customer Service..........................................................................................17
Specifications and Dimensions.............................................................. 19
Specifications and Dimensions.......................................................................19
Cabinet Dimensions...................................................................................... 22
Front Machine Dimensions............................................................................ 23
Rear Machine Dimensions............................................................................. 24
Exhaust and Gas Connection Locations...........................................................26
Mounting Bolt Hole Locations....................................................................... 27
Floor Mounting Layout................................................................................. 29
Installation........................................................................................... 31
Pre-Installation Inspection............................................................................. 31
Location Requirements..................................................................................31
Removing Dryer........................................................................................... 32
Single Machine Foundation Requirements.......................................................37
Machine Installation on Existing Floor........................................................ 37
Isolated Pad Installation............................................................................. 37
Foundation Requirements.............................................................................. 37
Machine Mounting and Grouting....................................................................38
Drain Connection Requirements.....................................................................41
Water Connection Requirements.....................................................................43
Connect Inlet Hoses ..................................................................................44
Plumbing Diagrams.......................................................................................46
Chemical Injection Supply System................................................................. 48
External Supplies..........................................................................................51
Chemical Injection Using Internal 24VAC Control Transformer.....................51
Chemical Injection Using External AC Power Source................................... 52
External Supply Signals............................................................................. 53
Before Placing Tumble Dryer into Service.......................................................54
Required for IEC Models Only (Tumble Dryer)........................................... 55
© Copyright 2021, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed
written consent of the publisher.
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
13 Part No. F8690001ENR7

Exhaust Requirements - Tumble Dryer................................................. 56
Exhaust Requirements................................................................................... 56
Layout......................................................................................................... 56
Make-Up Air................................................................................................56
Venting........................................................................................................ 56
Individual Venting..................................................................................... 57
Manifold Venting...................................................................................... 58
Gas Requirements - Tumble Dryer........................................................61
Gas Requirements.........................................................................................61
How to Change Burner Orifice Size............................................................ 64
How to Adjust Gas Valve Governor/Regulator............................................. 66
Installing CE Gas Tumble Dryer.....................................................................66
Adjusting Manifold Pressure for Natural Gas G20 or G25................................ 67
Adjusting Supply Pressure for L.P.G. G30 or G31............................................67
Converting From Natural Gas to L.P.G. or From Unregulated L.P.G. to Regulated
L.P.G........................................................................................................67
Start-Up Procedure........................................................................................67
Gas Supply Pipe Sizing and Looping.............................................................. 68
Low Pressure Gas Pipe Sizes......................................................................69
High Pressure Gas Pipe Sizes..................................................................... 71
High Altitude Burner Orifice Sizing............................................................... 72
Electrical Requirements........................................................................75
Electrical Requirements.................................................................................75
Electrical Installation Requirements................................................................75
Wiring Diagram............................................................................................76
Wiring for Central Pay...................................................................................76
Grounding Instructions..................................................................................76
Service/Ground Location (Tumble Dryer)....................................................77
Grounding (Washer-Extractor)....................................................................78
To Connect Electrical Service To Machine...................................................... 78
Electrical Specifications................................................................................ 79
Input Power Conditioning..............................................................................83
Input Voltage Requirements........................................................................83
Circuit Breakers and Quick Disconnects......................................................... 83
Connection Specifications..............................................................................83
Single-Phase Connections.......................................................................... 84
Three-Phase Connections........................................................................... 84
Phase Adder..............................................................................................85
Thermal Overload Protector....................................................................... 85
Adjustments - Tumble Dryer.................................................................86
Adjustments................................................................................................. 86
Gas Burner Air Shutter.................................................................................. 86
Airflow Switch ............................................................................................ 87
Loading Door Switch.................................................................................... 87
Door Strike...................................................................................................88
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
14 Part No. F8690001ENR7

Manual Resettable Thermostat....................................................................... 88
Before You Call for Service................................................................... 89
Removing Machine from Service...........................................................90
Disposal of Unit.................................................................................... 91
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
15 Part No. F8690001ENR7

Introduction
Model Identification
Information in this manual is applicable to these models. Refer
to the machine serial plate for the model number.
S30 (13/13 Kg) Stacked Washer-Extractor/Tumble Dryer * Only available in gas and electric
HSA030N HSK030L SS030E-A SS030N-A SSG030L SSK030L SST030L UST030E
HSG030E HSK030N SS030F-A SSA030N SSG030N SSK030N SST030N UST030N
HSG030N HST030N SS030L-A SSG030E SSJ030D SST030E
S50 (22/22 Kg) Stacked Washer-Extractor/Tumble Dryer * Only available in gas
HSA050N HSK050L HST050N SS050N-A SSG050L SSJ050D SSK050N SST050N
HSG050N HSK050N SS050L-A SSA050N SSG050N SSK050L SST050L UST050N
Heater Digit (Position 6)
E - Electric
L - L.P. Gas
N - Natural Gas
Vended Control Suffixes
Control Digit (position 7) Actuation Digit (position 8)
Example Control Suffix Combi-
nation
V - Touch Control C - Single Coin Drop
E - Electronic Coin Drop
L - Prep for Central Pay
Y - Prep for Card
VC - Touch Control, Single Coin Drop
VX - Touch Control, Prep for Coin
Introduction
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
16 Part No. F8690001ENR7

OPL Control Suffixes
Control Digit (position 7) Actuation Digit (position 8)
Example Control Suffix Combi-
nation
F - Dual Digital Control N - OPL FN- Dual Digital Control, OPL
Contact Information
If service is required, contact the nearest Factory Authorized
Service Center.
If you are unable to locate an authorized service center or are un-
satisfied with the service performed on your unit, contact the
source from which you purchased your unit.
When calling or writing about your unit, PLEASE GIVE THE
MODEL AND SERIAL NUMBERS. The model and serial num-
bers are located on the serial plate. The serial plate will be in the
location shown in Figure 1 .
Date Purchased ______________________________
Model Number ______________________________
Serial Number _______________________________
Please include a copy of your bill of sale and any service receipts
you have.
WARNING
To reduce the risk of serious injury or death, DO NOT
repair or replace any part of the unit or attempt any
servicing unless specifically recommended in the
user-maintenance instructions or in published user-
repair instructions that you understand and have the
skills to carry out.
W329
If replacement parts are required, contact the source from where
you purchased your unit.
STX5N_SVG
1
NOTE: An alternate serial plate is located on the front of the machine on the inside of the loading door hinge.
1. Serial Plate
Figure 1
Replacement Parts
If literature or replacement parts are required, contact the source
from which the machine was purchased or contact Alliance Laun-
dry Systems at [phone] for the name and address of
the nearest authorized parts distributor.
Customer Service
For technical assistance, contact your local distributor or contact:
Alliance Laundry Systems
Shepard Street
Introduction
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
17 Part No. F8690001ENR7

P.O. Box 990
Ripon, WI 54971-0990
U.S.A.
www.alliancelaundry.com
Phone: [phone] Ripon, Wisconsin
Introduction
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
18 Part No. F8690001ENR7

Specifications and Dimensions
Specifications and Dimensions
Refer to machine serial plate for additional specifications.
Specifications 30 50
Weights and Shipping Information
Net Weight (approximate):
Pounds [kg]
Gas 765 [347]
Electric 795 [361]
930 [422]
Standard Packaging Weight: Pounds [kg] Gas 795 [361]
Electric 825 [374]
950 [431]
Slat Crate Packaging Weight: Pounds
[kg]
Gas 925 [420]
Electric 955 [433]
1130 [513]
Standard Packaging Shipping Dimen-
sions: Inch [mm]
36.5 x 48 x 84 [927 x 1219 x 2134] 36.5 x 54 x 89 [927 x 1372 x 2261]
Standard Packaging Shipping Volume: ft3
[m3]
71 [2.4] 102 [2.9]
Slat Crate Packaging Shipping Dimen-
sions: Inch [mm]
41 x 51 x 91 [1041 x 1295 x 2311] 41 x 57 x 91 [1041 x 1448 x 2311]
Slat Crate Packaging Shipping Volume:
ft3 [m3]
110 [3.1] 123 [3.5]
Noise Emissions
Noise level meas-
ured during opera-
tion at operator po-
sition of 3.3 feet [1
meter] in front of
machine and 5.2
feet [1.6 meters]
from floor, dBA
Washer-Extractor/
Tumble Dryer
Wash 57/60 55/63
Extract (100G) 55/60 61.5/65
Extract (200G) 60/62 66/67.5
TUMBLE DRYER
Cylinder Information
Cylinder Size:
Inch [mm]
30.0 x 26.0 [762 x 660] 33.0 x 30.0 [838 x 762]
Table 1 continues...
Specifications and Dimensions
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
19 Part No. F8690001ENR7

Specifications 30 50
Cylinder Capacity (dry weight):
Pounds [kg]
30 [13] 50 [22]
Cylinder Volume:
feet3 [Liter]
10.6 [300] 14.8 [420]
Operational Information
Drive Motor: Horsepower [kW] 0.3 [0.2] 0.5 [0.4]
Fan Motor: Horsepower [kW] 0.3 [0.2] 0.5 [0.4]
Air Outlet Diameter: Inch [mm] Elliptical
8.0 [200]
Elliptical
10.0 [250]
Maximum Airflow:
C.F.M. [l/sec]
400 [188] 600 [283]
Maximum Static Back Pressure:
Inch W.C. [mbar, kPa]
0.50 [1.2, 0.12] 0.50 [1.2, 0.12]
Minimum Static Back Pressure:
Inch W.C. [mbar, kPa]
0.0 [0.0, 0.0] 0.0 [0.0, 0.0]
Heat dissipation of surface area exposed
to conditioned air: Btu/ft2 [Joules/m2]
60 [680,000] 60 [680,000]
Door Opening Information
Door Opening Diameter: Inch [mm] 22.7 [576] 26.9 [684]
Door Hinge Side Right Right
Door Maximum Open Angle: Degrees 180 180
Gas Models
Gas Connection 1/2 NPT 1/2 NPT
Gas Burner Rating:
BTU/hr. [kW, Mj/hr.]
73,000 [21.4, 77.0] 95,000 [27.8, 100]
Electric Models
Heating Element Rating: Kilowatts 3 Phase - 21
1 Phase - 9
Not Applicable
WASHER-EXTRACTOR
Wash Cylinder Information
Cylinder diameter, in. [mm] 24.0 [610] 26.3 [668]
Table 1 continues...
Specifications and Dimensions
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
20 Part No. F8690001ENR7
