Alliance Laundry Systems T477C User manual

Installation
www.comlaundry.com
Part No. 70304601R8
September 2008
Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.)
NOTA: Para bajar una
copia de estas
instrucciones en
español, visite
www.comlaundry.com.
Drying Tumblers
Stacked 30 Pound Capacity
Stacked 45 Pound Capacity
Starting Serial No. 0602004144
Refer to Page 4 for Model Identification
START
25
C
HIGH
TEMP
MED
TEMP
LOW
TEMP
NO
HEAT
123
SELECT
TEMP
INSERT
COIN
PUSH
START
123
SELECT
TEMP
INSERT
COIN
PUSH
START
START
25
C
HIGH
TEMP
MED
TEMP
LOW
TEMP
NO
HEAT
T477C
T477C

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT70304601 1
Installation must conform with local codes or in the absence of local codes with:
In the U.S.A.,installation must conform to the latest edition of the American National Standard Z223.1/
NFPA 54 “National Fuel Gas Code” and Standard ANSI/NFPA 70 “National Electric Code.”
In Canada, installation must comply with Standards CAN/CSA-B149.1 or Natural Gas and Propane
Installation Code and CSA C22.1, latest edition, Canadian Electric Code, Part I.
In Australia, installation must comply with the Australian Gas Association Installation Code for Gas
Burning Appliances and Equipment.
The following information applies to the state of
Massachusetts, USA.
•This appliance can only be installed by a
Massachusetts licensed plumber or gas fitter.
•This appliance must be installed with a 36
inch (91 cm) long flexible gas connector.
•A "T-Handle" type gas shut-off valve must be
installed in the gas supply line to this
appliance.
•This appliance must not be installed in a
bedroom or bathroom.
IMPORTANT: Information must be obtained from
a local gas supplier on instructions to be followed if
the user smells gas. These instructions must be
posted in a prominent location. Step-by-step
instructions of the above safety information must
be posted in a prominent location near the tumbler
for customer use.
FOR YOUR SAFETY, the information in this
manual must be followed to minimize the
risk of fire or explosion or to prevent
property damage, personal injury or death.
W033
WARNING
• Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
• WHAT TO DO IF YOU SMELL GAS:
– Do not try to light any appliance.
– Do not touch any electrical switch; do
not use any phone in your building.
– Clear the room, building or area of all
occupants.
– Immediately call your gas supplier from
a neighbor’s phone. Follow the gas
supplier’s instructions.
– If you cannot reach your gas supplier,
call the fire department.
• Installation and service must be
performed by a qualified installer, service
agency or the gas supplier. W052
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance. W053
POUR VOTRE SÉCURITÉ
Ne pas entreposer ou utiliser d’essence ou
toutes autres vapeurs et liquides
inflammables à proximité de cette unité ou
de tout autre appareil. W053R2QU
MISE EN GARDE
POUR VOTRE SÉCURITÉ, les informations
de ce guide doivent être respectées afin de
réduire les risques d’incendie, d’explosion
ou d’éviter les dommages matériels,
personnels ou blessures mortelles. W033R3QU
• Ne pas entreposer ou utiliser d’essence
ou toutes autres vapeurs et liquides
inflammables à proximité de cette
machine ou de tout autre appareil.
• QUE FAIRE EN CAS D’ODEUR DE GAZ :
– Ne pas mettre d’appareil en marche.
– Ne pas toucher aux interrupteurs
électriques ; ne pas utiliser le
téléphone des lieux.
– Évacuer la pièce, le bâtiment ou la zone
de tous les occupants.
– Appeler immédiatement le fournisseur
de gaz de la maison d’un voisin.
Respecter les instructions
communiquées par le fournisseur.
– Si vous ne pouvez pas joindre le
fournisseur de gaz, appeler le service
d’incendie.
• L’installation et l’entretien doivent être
effectués par un installateur, service
d’entretien qualifiés ou par le fournisseur
de gaz. W052R5QU

© Copyright 2008, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any
means without the expressed written consent of the publisher.
270304601© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Table of
Contents
Introduction......................................................................................... 4
Model Identification ............................................................................. 4
Customer Service.................................................................................. 5
Wiring Diagram .................................................................................... 5
Serial Plate Location............................................................................. 5
Safety Information.............................................................................. 6
Explanation of Safety Messages........................................................... 6
Important Safety Instructions ............................................................... 7
Specifications and Dimensions........................................................... 9
Cabinet Dimensions.............................................................................. 10
Exhaust Outlet Locations...................................................................... 11
Gas Connection Locations.................................................................... 12
Electrical Connection Locations........................................................... 13
Steam Connection Locations ................................................................ 14
Installation........................................................................................... 15
Pre-Installation Inspection .................................................................... 15
Location Requirements......................................................................... 15
Position and Level the Tumbler............................................................ 17
Before Placing Tumbler into Service ................................................... 18
Required for CE Models Only ......................................................... 19
Installing CE Gas Drying Tumblers ..................................................... 19
General Information......................................................................... 19
Basic Configuration ......................................................................... 20
Specific Conversion Procedures ...................................................... 22
Exhaust Requirements ....................................................................... 24
Layout ................................................................................................... 24
Make-Up Air......................................................................................... 24
Venting ................................................................................................. 24
Individual Venting ........................................................................... 25
Manifold Venting............................................................................. 27
Gas Requirements............................................................................... 30
Gas Supply Pipe Sizing and Looping ................................................... 32
High Altitude Burner Orifice Sizing..................................................... 34
Electrical Requirements..................................................................... 35
Grounding Instructions ......................................................................... 35
For CE Models Only............................................................................. 35
Service/Ground Location...................................................................... 36
Connecting Electrical Service............................................................... 37
Configuring Your Tumbler for Other Service Voltages .................. 37
Electrical Connections ..................................................................... 37
Conversion Instructions ........................................................................ 38
Electrical Requirements for Gas and Steam Models ............................ 40
Electrical Requirements for Electric Models........................................ 42
Steam Requirements........................................................................... 43
Piping Recommendations ..................................................................... 43
Installing Steam Trap and Making Condensate Return Connections... 44

70304601 3 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Single Drop Timer .............................................................................. 46
Power-Up Mode.................................................................................... 46
Ready Mode.......................................................................................... 46
Start Mode ............................................................................................ 46
Run Mode ............................................................................................. 46
Setting Dry Time Dipswitches.............................................................. 46
Dipswitch Settings ................................................................................ 47
Adjustments......................................................................................... 49
Loading Door Switch............................................................................ 49
Airflow Switch...................................................................................... 49
Door Strike............................................................................................ 50
Removing Tumbler from Service...................................................... 51

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70304601
4
Introduction
Model Identification
Information in this manual is applicable to these models:
Includes models with control suffixes:
Gas Steam Electric
T30
CHD30STG2-CAT30L
CHD30STG2-CAT30N
CHD30STG2-CTT30L
CHD30STG2-CTT30N
CHD30STG2-CUT30L
CHD30STG2-CUT30N
DRST30G2-BAT30L
DRST30G2-BAT30N
DRST30G2-BTT30D
DRST30G2-BTT30L
DRST30G2-BTT30N
DRST30G2-BUT30L
DRST30G2-BUT30N
HAT30L
HAT30N
HTT30D
HTT30L
HTT30N
HUT30L
HUT30N
IPD30STG2-ITT30L
IPD30STG2-ITT30N
MTT30N
NTT30N
SAT30L
SAT30N
STT30D
STT30L
STT30N
SUT30L
SUT30N
UAT30L
UAT30N
UTT30L
UTT30N
UUT30L
UUT30N
CHD30STS2-CTT30S
CHD30STS2-CUT30S
DRST30S2-BTT30S
DRST30S2-BUT30S
HTT30S
HUT30S
IPD30STS2-ITT30S
STT30S
SUT30S
UTT30S
UUT30S
CHD30STE2-CTT30E
CHD30STE2-CUT30E
DRST30E2-BTT30E
DRST30E2-BUT30E
HTT30E
HUT30E
IPD30STE2-ITT30E
STT30E
SUT30E
UTT30E
UUT30E
T45
CTT45L
CTT45N
DRST45G2-BTT45D
DRST45G2-BTT45L
DRST45G2-BTT45N
HTT45D
HTT45L
HTT45N
HUT45L
HUT45N
IPD45STG2-ITT45L
IPD45STG2-ITT45N
MTT45N
NTT45N
STT45D
STT45L
STT45N
SUT45L
SUT45N
UTT45L
UTT45N
Not Applicable Not Applicable
3O– DX4 OPL NC– NetMaster coin SX– single drop, prep for coin
3V– DX4 vended NR– NetMaster card ZC– NetMaster network coin
3X– DX4 prep for coin NX– NetMaster, prep for coin ZR– NetMaster network card
BC– basic electronic, coin NY– NetMaster, prep for card ZX– NetMaster network, prep for coin
BL– basic electronic, central pay OM– OPL micro ZY– NetMaster network, prep for card
BX– basic electronic, prep for coin QT– dual digital timer
BY– basic electronic, prep for card SD– single drop

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Introduction
5
70304601
Customer Service
If literature or replacement parts are required, contact
the source from which the machine was purchased or
contact Alliance Laundry Systems at [phone]
for the name and address of the nearest authorized
parts distributor.
For technical assistance, call [phone].
Wiring Diagram
The wiring diagram is located in the upper junction or
upper contactor box.
The wiring diagram part number is located in the
lower portion of the electrical data on the serial plate.
Serial Plate Location
When calling or writing for information about your
product, be sure to mention model and serial numbers.
Model and serial numbers are found on serial plate on
the rear of machine and inside door.
TMB1974N
1Serial Plate
1
Conversion Table
Multiply By To Obtain Multiply By To Obtain
Btu 0.252 kCal Pounds/sq. inch 0.06895 Bars
Btu 1055 Joules Pounds/sq. inch 0.070 kg/sq. cm
Inch 25.4 Millimeters Pounds (lbs.) 0.454 Kilograms
Inches W.C. 0.036 Pounds/sq. inch Boiler Horsepower 33,479 Btu/hr.
Inches W.C. 0.249 kPa Boiler Horsepower 34.5 lbs. steam/hr.
lb/inch2(psi) 6.895 kPa CFM 0.471 liters/second
ft328.32 Liters kW 3414 Btu/hr.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70304601
6
Safety Information
Explanation of Safety Messages
Precautionary statements (“DANGER,” “WARNING,”
and “CAUTION”), followed by specific instructions,
are found in this manual and on machine decals. These
precautions are intended for the personal safety of the
operator, user, servicer, and those maintaining the
machine.
Additional precautionary statements (“IMPORTANT”
and “NOTE”) are followed by specific instructions.
IMPORTANT: The word “IMPORTANT” is used
to inform the reader of specific procedures where
minor machine damage will occur if the procedure
is not followed.
NOTE: The word “NOTE” is used to communicate
installation, operation, maintenance or servicing
information that is important but not hazard
related.
NOTE: The WARNING and IMPORTANT
instructions appearing in this manual are not
meant to cover all possible conditions and
situations that may occur. It must be understood
that common sense, caution and carefulness are
factors which CANNOT be built into this tumbler.
These factors MUST BE supplied by the person(s)
installing, maintaining or operating the tumbler.
Always contact your dealer, distributor, service agent
or the manufacturer on any problems or conditions you
do not understand.
Indicates an imminently hazardous
situation that, if not avoided, will cause
severe personal injury or death.
DANGER
Indicates a hazardous situation that, if not
avoided, could cause severe personal
injury or death.
WARNING
Indicates a hazardous situation that, if not
avoided, may cause minor or moderate
personal injury or property damage.
CAUTION
Failure to install, maintain, and/or operate
this machine according to manufacturer’s
instructions may result in conditions which
can produce serious injury, death and/or
property damage. W051R1
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Information
7
70304601
Important Safety Instructions
Save These Instructions
1. Read all instructions before using the tumbler.
2. Refer to the GROUNDING INSTRUCTIONS
for the proper grounding of the tumbler.
3. Do not dry articles that have been previously
cleaned in, washed in, soaked in, or spotted with
gasoline, dry cleaning solvents, other flammable
or explosive substances as they give off vapors
that could ignite or explode.
4. Do not allow children on or in the tumbler. This
appliance is not intended for use by young
children or infirm persons without supervision.
Young children should be supervised to ensure
that they do not play with the appliance.
5. Before the tumbler is removed from service or
discarded, remove the door to the drying
compartment and the door to the lint
compartment.
6. Do not reach into the tumbler if the cylinder is
revolving.
7. Do not install or store the tumbler where it will
be exposed to water and/or weather.
8. Do not tamper with the controls.
9. Do not repair or replace any part of the tumbler,
or attempt any servicing unless specifically
recommended in the user-maintenance
instructions or in published user-repair
instructions that you understand and have the
skills to carry out.
10. Do not use fabric softeners or products to
eliminate static unless recommended by the
manufacturer of the fabric softener or product.
11. To reduce the risk of fire, DO NOT DRY plastics
or articles containing foam rubber or similarly
textured rubberlike materials.
12. Always clean the lint filter daily.
13. Keep area around the exhaust opening and
adjacent surrounding area free from the
accumulation of lint, dust and dirt.
14. The interior of the tumbler and the exhaust duct
should be cleaned periodically by qualified
service personnel.
15. If not installed, operated and maintained in
accordance with the manufacturer’s instructions
or if there is damage to or mishandling of this
product’s components, use of this product could
expose you to substances in the fuel or from fuel
combustion which can cause death or serious
illness and which are known to the State of
California to cause cancer, birth defects or other
reproductive harm.
16. Tumbler will not operate with the loading door
open. DO NOT bypass the door safety switch to
permit the tumbler to operate with the door open.
The tumbler will stop tumbling when the door is
opened. Do not use the tumbler if it does not stop
tumbling when the door is opened or starts
tumbling without pressing or turning the START
mechanism. Remove the tumbler from use and
call for service.
17. Tumbler will not operate with lint panel open.
DO NOT bypass lint panel safety switch to
permit the tumbler to operate with the lint panel
open.
18. Do not put articles soiled with vegetable or cooking
oil in the tumbler, as these oils may not be
removed during washing. Due to the remaining
oil, the fabric may catch on fire by itself.
19. To reduce the risk of fire, DO NOT put clothes
which have traces of any flammable substances
such as machine oil, flammable chemicals,
thinner, etc. or anything containing wax or
chemicals such as in mops and cleaning cloths, or
anything dry-cleaned at home with dry-cleaning
solvent in the tumbler.
20. Use the tumbler only for its intended purpose,
drying fabrics.
21. ALWAYS disconnect and lockout the electrical
power to the tumbler before servicing. Disconnect
power by shutting off appropriate breaker or fuse.
22. Install this tumbler according to the
INSTALLATION INSTRUCTIONS. All
connections for electrical power, grounding, and
gas supply must comply with local codes and be
made by licensed personnel when required.
Hazardous Voltage. Can cause shock, burn
or cause death. Allow machine power to
remain off for two minutes prior to working
in and around AC inverter drive. W359
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Information
70304601
8
23. Remove laundry immediately after tumbler stops.
24. Always read and follow manufacturer’s
instructions on packages of laundry and cleaning
aids. Heed all warnings or precautions. To reduce
the risk of poisoning or chemical burns, keep
them out of reach of children at all times
(preferably in a locked cabinet).
25. Do not tumble fiberglass curtains and draperies
unless the label says it can be done. If they are
dried, wipe out the cylinder with a damp cloth to
remove particles of fiberglass.
26. Always follow the fabric care instructions
supplied by the garment manufacturer.
27. Never operate the tumbler with any guards and/or
panels removed.
28. DO NOT operate the tumbler if it is smoking,
grinding, has missing or broken parts.
29. DO NOT bypass any safety devices.
30. Solvent vapors from dry-cleaning machines
create acids when drawn through the heater of the
drying unit. These acids are corrosive to the
tumbler as well as to the laundry load being
dried. Be sure make-up air is free of solvent
vapors.
31. Failure to install, maintain, and/or operate this
machine according to the manufacturer’s
instructions may result in conditions which can
produce bodily injury and/or property damage.
WARNING
To reduce the risk of serious injury, install
lockable door(s) to prevent public access
to rear of tumblers. W055
