Alliance Laundry Systems PA20 X CONTROL User manual

Programming
Washer-Extractors
X Control
Refer to Page 8 for Model Identification
Original Instructions
Keep These Instructions for Future Reference.
CAUTION: Read the instructions before using the machine.
(If this machine changes ownership, this manual must accompany machine.)
www.alliancelaundry.com Part No. D1676ENR11
September 2022

Table of Contents
Safety Information..................................................................................8
Important Safety Instructions........................................................................... 8
Introduction........................................................................................... 9
Model Identification........................................................................................9
Machine Type in Configuration Menu...............................................................9
Control Identification........................................................................... 10
Symbol Used................................................................................................10
Main Menu...................................................................................................11
Basic Description of Controls................................................................ 13
General........................................................................................................ 13
Specific........................................................................................................13
Entering and Changing Values Utilizing the Control Keypad.............................14
How to Get into the Setup Mode.................................................................... 14
15 Wash Programs - 99 Steps......................................................................... 15
Available Wash Sequences......................................................................... 16
The Creation of a Wash Program.................................................................... 16
Programming the Wash Sequence............................................................... 16
Programming the Drain Sequence............................................................... 16
The Tumble Sequence................................................................................16
Programming the Functions........................................................................... 16
Programming the Water Temperature.......................................................... 16
Programming the Water Inlets Valves.......................................................... 16
Top Soap Dispenser Machines.................................................................... 16
Programming the Water Level.................................................................... 17
Cabinet Freestanding 6.5-28 kg / 14-70 lb / 65-280 L....................................18
Cabinet Hardmount 7.5-52 kg / 20-120 lb / 80-520 L.................................... 19
Programmable Water Level........................................................................ 23
Speed of Machines with Frequency Inverter.................................................23
Programming the Wash Speed.................................................................... 25
Programming Extraction Speed...................................................................25
Programming Supplies...............................................................................25
Programming the Motor On and Off Times for Reversing............................. 25
Programming the Sequence Time................................................................25
Signal.......................................................................................................26
Initializing the Machine........................................................................ 27
Initialization Menu........................................................................................27
© Copyright 2022, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed
written consent of the publisher.
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
3 Part No. D1676ENR11

Configuration Menu......................................................................................31
Passwords.................................................................................................32
Advanced Menu............................................................................................36
Hygienic Cycle Menu................................................................................ 36
Program Mode Lock Menu.........................................................................37
Program Lock Menu..................................................................................38
Weighing Menu.........................................................................................39
Data EXPORT / IMPORT.......................................................................... 40
Payment Menu..............................................................................................40
Selection of Payment Mode........................................................................42
Selection of Additional Functions............................................................... 42
Audit Data Menu.......................................................................................... 43
Programming........................................................................................47
General........................................................................................................ 47
Step 1: Program Menu...................................................................................47
Step 2: Program Functions............................................................................. 47
Step 3: Program Step Function....................................................................... 48
Step 4: Programming the Wash Part................................................................50
Selecting the Wash Part..............................................................................50
The Prewash Sequence...............................................................................51
The Wash Sequence...................................................................................52
The Cooldown Sequence............................................................................53
The Rinse Sequence...................................................................................54
The Extra Rinse Sequence..........................................................................55
The Final Rinse Sequence.......................................................................... 56
The Soak Sequence....................................................................................57
The Spray Sequence.................................................................................. 58
The No Wash Sequence..............................................................................59
Step 5: Programming the Drain Step............................................................... 59
Selecting the Drain / Extraction Step........................................................... 59
The Drain Sequence...................................................................................60
The Extract Sequence................................................................................ 60
The No Drain Sequence............................................................................. 61
The Static Drain Sequence......................................................................... 61
The Reversing Drain Sequence................................................................... 61
Operation Menu................................................................................... 63
Starting Up...................................................................................................63
Switching On the Power................................................................................ 63
Load the Washing Machine............................................................................63
Put Soap into the Soap Dispenser................................................................... 63
Starting a Wash Program............................................................................... 63
The Active Program...................................................................................... 63
Advancing a Wash Program........................................................................... 64
Wash Time................................................................................................... 64
Program End................................................................................................ 64
Water Fill Process......................................................................................... 64
Heating Process............................................................................................ 64
Cooldown Function.......................................................................................65
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
4 Part No. D1676ENR11

Spray Function............................................................................................. 65
Unbalance.................................................................................................... 65
Adding Detergents........................................................................................ 65
Wait State.....................................................................................................65
How to Handle Failure Messages................................................................... 65
How to Handle Power Interruptions................................................................66
Special Functions..........................................................................................66
External Liquid Soap Boxes...........................................................................66
Pre-programmed Programs.................................................................. 67
Water Inlets (Valves) Information................................................................... 67
Wash Program Legend Water Levels...............................................................67
Wash Actions............................................................................................... 67
RPM (Revolutions per Minute)...................................................................... 67
Wash Programs.............................................................................................68
Wash Program 1: Normal Hot 140°F [60°C] ............................................... 68
Wash Program 2: Normal Warm 95°F [35°C] .............................................. 69
Wash Program 3: Normal Cold 59°F [15°C] ................................................70
Wash Program 4: Extra Wash Hot 140°F [60°C] ..........................................70
Wash Program 5: Extra Wash Warm 95°F [35°C] ........................................ 71
Wash Program 6: Pernament Press 95°F [35°C] ...........................................72
Wash Program 7: Delicates 59°F [15°C] ..................................................... 73
Wash Program 8: Bulky 95°F [35°C] ..........................................................74
Wash Program 9: Denim 95°F [35°C] .........................................................75
Wash Program 10: Whites 140°F [60°C] .....................................................76
Wash Program 11: Colors 59°F [15°C] ....................................................... 77
Wash Program 12: Casual 95°F [35°C] .......................................................78
Wash Program 13: Sport Fabrics 95°F [35°C] ............................................. 78
Wash Program 14: Wool 59°F [15°C] ......................................................... 79
Wash Program 15: Rinse & HI spin.............................................................80
Troubleshooting....................................................................................81
Display Messages......................................................................................... 81
Fault Messages............................................................................................. 81
How to Handle Fault Messages...................................................................... 81
Failure Message Overview.............................................................................82
Service Menu............................................................................................... 84
Faults Menu (Service Faults)...................................................................... 85
Toolbox Menu...........................................................................................86
Diagnostic Program.......................................................................................87
Test Sequence........................................................................................... 89
Basic Diagnostic Wash Program................................................................. 90
Troubleshooting............................................................................................91
External Communication Problems.................................................................92
Error Message Descriptions........................................................................... 92
Failure 2: Drain Failure..............................................................................92
Failure 3: Safety Switch Activated.............................................................. 92
Failure 4: The Linen is Not Correctly Distributed in the Stage when the Ma-
chine Starts Up the Spinning Sequence.................................................... 93
Failure 5: Safety Switch High Spin............................................................. 93
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
5 Part No. D1676ENR11

Failure 6: Door Switch Failure....................................................................93
Failure 7: Door Lock Switch Failure........................................................... 94
Failure 8: Door Close Check at Start Failure................................................ 94
Failure 9: Door Lock Switch Failure at Cycle End........................................ 94
Failure 10: Target Temperature not Reached................................................ 95
Failure 11: Fill Failure............................................................................... 95
Failure 12: Overfill Failure.........................................................................95
Failure 13: Heating Failure.........................................................................96
Failure 14: Heating Time Failure................................................................ 96
Failure 15: Too Hot................................................................................... 96
Failure 16: Coin Blocking 1........................................................................97
Failure 17: Coin Blocking 2........................................................................97
Failure 18: Door Lock Pre-test Before Start................................................. 97
Failure 19: Door Lock Test After Start.........................................................97
Failure 21: Overflow Failure...................................................................... 97
Failure 24: Defective Level Sensor..............................................................98
Failure 25: Defective Temperature Sensor....................................................98
Failure 26: Undefined Mitsubishi Frequency Inverter Error Code.................. 98
Failure 27: Communication Fault Inverter....................................................98
Failure 28: THT (Mitsubishi) Time Out....................................................... 99
Failure 29: OV3 (Mitsubishi) Time Out....................................................... 99
Failure 31: Initialization Fault Inverter........................................................ 99
Failure 32: Verification Fault Inverter..........................................................99
Failure 35: Wrong Software Version..........................................................100
Failure 36: The Linen is Not Correctly Distributed in the Stage Before the Start
Up of the Spinning Sequence................................................................ 100
Failure 37: Drain Failure at the Spray Sequence......................................... 100
Failure 39: Empty Soap Supply Box..........................................................100
Failure 41: Service Due Warning...............................................................100
Failure 42: No Network Connection.......................................................... 101
Failure 43: Wrong Voltage Range Selection............................................... 101
Failure 44: Incorect Selection of Machine Type.......................................... 101
Failure 45: Drum Rotation Sensor is not Working.......................................101
Failure 60: Inner Door Lock..................................................................... 101
Failure 77: Time for Heating Blocking is Out............................................. 102
Failure 80: Time for Dispensing Liquid Detergents is Out........................... 102
Failure 85: RTC Low Battery....................................................................102
Failure 95: Watch Dog............................................................................. 102
Failure 106: Calibration Error................................................................... 102
Failure 107: Not Calibrated...................................................................... 103
Failure 300-353: Mitsubishi Inverter Alarm Message..................................103
Failure 500-526: Memory Errors...............................................................107
Failure 560: USB Not Found.................................................................... 107
Failure 561: File Not Found......................................................................107
Failure 562: Export Failed........................................................................ 107
Failure 563: Import Failed........................................................................ 107
Failure 570-571: Card Reader Error...........................................................107
Failure 600-628: Software Errors.............................................................. 108
Service Information............................................................................ 109
Maintenance............................................................................................... 109
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
6 Part No. D1676ENR11

Information for Service................................................................................109
Programmer Circuit Board........................................................................... 109
Instructions for Replacing the Programmer Boards.........................................110
Instructions for Installing New Software........................................................110
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
7 Part No. D1676ENR11

Safety Information
Important Safety Instructions
WARNING
Before operating a machine controlled by an elec-
tronic programmer, read this manual. Incorrect use
can result in serious injuries or damage to the ma-
chine controls. Ignoring instructions can cause an
incorrect machine function, which may result in inju-
ries or machine and/or linen damages.
C001
• Before installation, operating and maintenance of the ma-
chine, read complete instructions thoroughly which means the
following manuals: "Original Programming Manual" and
"Original Installation, maintenance and user's manual". Fol-
low these instructions and keep them handy for later use.
• A machine must be installed by following the "Original In-
stallation, maintenance and user's manual". Before the first
machine start, it must be initialized and tested by a qualified
worker.
• The electric service line must not be affected by other electri-
cal loading. A nominal voltage, if loaded or not must work in
the range ±10% with a maximum permanent frequency devia-
tion of 1% or a short-time one at 2% of a given frequency.
Connecting or starting the machine at an incorrect voltage can
damage the programmer.
• The machine must not be exposed to high humidity or ex-
treme high and low temperatures.
• Do not tamper with the controls.
•Instructions in this manual do not cover all dangerous sit-
uations. It is up to the user to handle the machine careful-
ly.
• The manufacturer has the right to change specifications in this
manual without prior notice. All the stated information is only
for informative purpose and must be considered as general. It
is not possible to present all the specific data of the device.
NOTE: Every circuit board has a serial number and
board code. The model and serial number of the ma-
chine, must be mentioned in all correspondence or in-
quiries addressed to the distributor or manufacturer.
NOTE: The programmer uses machine type codes to
select different machines´ programmable machines ex-
ecutions. The model number on the machine doesn’t
indicate the machine type directly. It must be linked
with the description of the machine type letters.
Safety Information
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
8 Part No. D1676ENR11

Introduction
Model Identification
Information in this manual is applicable to these models:
PA20_X_CONTROL PAN080X
PA25_X_CONTROL PY20_X_CONTROL
PA30_X_CONTROL PY25_X_CONTROL
PA40_X_CONTROL PY30_X_CONTROL
PA55_X_CONTROL PY40_X_CONTROL
PA70_X_CONTROL PY55_X_CONTROL
PA80_X_CONTROL PY70_X_CONTROL
PAN020X PYN020X
PAN025X PYN025X
PAN030X PYN030X
PAN040X PYN040X
PAN055X PYN055X
PAN070X PYN070X
Machine Type in Configuration Menu
Machine Type in Configuration Menu
Dry Load Capacity Machine Type
Freestanding, High Spin Washer Extractors
7.5 kg / 20 lb / 80 L PY20
10.5 kg / 25 lb / 105 L PY25
13.5 kg / 30 lb / 135 L PY30
18 kg / 40 lb / 180 L PY40
24 kg / 55 lb / 240 L PY55
28 kg / 70 lb / 280 L PY70
Cabinet Hardmount Washer Extractors
7.5 kg / 20 lb / 80 L (100 G) PA20N
7.5 kg / 20 lb / 80 L (200 G) PA20M
10.5 kg / 25 lb / 105 L (100 G) PA25N
10.5 kg / 25 lb / 105 L (200 G) PA25M
Table 1 continues...
Machine Type in Configuration Menu
Dry Load Capacity Machine Type
13.5 kg / 30 lb / 135 L (100 G) PA30N
13.5 kg / 30 lb / 135 L (200 G) PA30M
18 kg / 40 lb / 180 L (100 G) PA40N
18 kg / 40 lb / 180 L (200 G) PA40M
24 kg / 55 lb / 240 L (100 G) PA55N
24 kg / 55 lb / 240 L (200 G) PA55M
28 kg / 70 lb / 280 L (100 G) PA70N
28 kg / 70 lb / 280 L (200 G) PA70M
35 kg / 80 lb / 332 L (100 G) PA80N
35 kg / 80 lb / 332 L (150 G) PA80M
Table 1
Introduction
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
9 Part No. D1676ENR11

Control Identification
Symbol Used
Buttons
CHM1682R1
SCROLL UP BACK
SCROLL DOWN START
SELECT
1 2
1. Hidden navigation button LEFT
2. Hidden navigation button RIGHT
Figure 1
Decal
CHM1612R
START
CHM1614R
CONFIRM THE SELECTION (ENTER)
CHM1615R
CANCEL THE SELECTION
CHM1616R
MOVE UP
CHM1617R
MOVE DOWN
Table 2
Control Identification
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
10 Part No. D1676ENR11

Main Menu
Initialization Menu
Program Menu
Service Menu
Configuration Menu
Advanced Menu
Price Menu
Audit Data
Initialization Menu
Program Menu
Service Menu
Configuration Menu
Advanced Menu
Price Menu
Audit Data
Initialization Menu
Program Menu
Service Menu
Configuration Menu
Advanced Menu
Price Menu
Audit Data
Initialization Menu
Language
Service Interval
Buzzer Time
Allow Advance
Automatic Cooldown
Wait for Temperature
Temperature Balance
Motor On Time
Motor Off Time
Smart Motion
Hot Water Heat. temp
Temp Overshoot Protection
Max. Heating Time
Max. Water Fill Time
Overfill Detection
External Wait Control
Prewash Soap Info
Wash Liq. Soap Info
Temp. Info
Preset Program
Direct Selection 1
Direct Selection 2
Eco Mode
Exit
Program Menu
Refer to corresponding
flowchart
How to Create and
Adjust a Wash Program
Service Menu
Software
Diagnostic Progr
Faults Menu
Toolbox
Exit
Navigation Key
Selection list: Press button LEFT or RIGHT.
Selecting a new Program Submenu and
go to this Submenu: ENTER button.
Confirming a menu item and
go to the next menu item: ENTER button.
Insert a value or select another List element.
Attention!
Depending the machine
type, some items will
not be displayed.
Selecting the menu item: Press button UP or DOWN.
Heat.Err.Det.Time
Extra Soap Timing
CFS374R_SVG
Figure 2
Control Identification
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
11 Part No. D1676ENR11

Initialization Menu
Program Menu
Service Menu
Configuration Menu
Advanced Menu
Price Menu
Audit Data
Initialization Menu
Program Menu
Service Menu
Configuration Menu
Advanced Menu
Price Menu
Audit Data
Configuration Menu
Password
Machine Type
Reset Defaults
Brightness Display
Inverter Menu
Total Number of Inlets
Drain Val.1 Inverted
Drain Valve 2
Liquid Soap Supply
Min. Level Start Sup
Temperature
Full Heating
Wet Cleaning
Wash Programs
Communicaton Address
Exit
Advanced Menu
Hygienic Cycle
Program Mode Lock
Program Lock
Data Export/Import
Exit
Attention!
Depending the machine
type, some items will
not be displayed.
Initialization Menu
Program Menu
Service Menu
Configuration Menu
Advanced Menu
Price Menu
Audit Data
Price Menu
Payment mode
Decimal point
Coin
Coin 1 Value
Coin 1 Currency
Coin 2 Value
Coin 2 Currency
Programs Prices
Special Prices
Program Blocking
Optional Functions
Delayed Start
Show Start Info
Show Prog Nr
Show Prog Time
Show Soap Info
Show Error Details
Exit
Initialization Menu
Program Menu
Service Menu
Configuration Menu
Advanced Menu
Price Menu
Audit Data
Audit Data
Life Cycle Count
Service Cycle Count
Vend Statistics
Program Statistics
Audit Data Export
Exit
Navigation Key
Selecting the menu item: Press button UP or DOWN.
Selecting a new Program Submenu and
go to this Submenu: ENTER button.
Confirming a menu item and
go to the next menu item: ENTER button.
Insert a value or select another List element.
CZW3R
Selection list: Press button LEFT or RIGHT.
Figure 3
Control Identification
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
12 Part No. D1676ENR11

Basic Description of Controls
General
The Control Offers:
• 15 pre-programmed programs.
• Control of signal voltages for external pumps or liquid supply
dispensers.
• Redistribution of the garments to avoid imbalance.
• Automatic temperature balance during the water fill process.
• Setting the machine options and configuration.
• Multiple languages can be selected (one at a time).
In Operation the Following Data is Displayed:
• The remaining program time.
• Wash cycle progression bar.
• Diagnostic messages.
The Operation Menu:
• A pause can be programmed.
• Program overview.
• Service information.
The Hardware and Software of the Wash Computer:
• Easy operation by a comprehensive keypad.
• The hardware contains 2 electronic boards.
• The wash computer with graphic LCD display.
• The control software of the washing machine is stored in the
internal memory of the wash computer and it can be easily ad-
justed (USB flash drive).
• The Wash Programs are kept in EEPROM memory (non-vola-
tile memory).
• Direct control of liquid-detergent pumps.
Specific
The PROGRAM Menu is Designated for:
• The creation of a specific name for a wash program.
• The creation and implementation of a new wash program step
by step.
• Editing a wash program step by step.
• Inserting and deleting steps in the wash program.
• Copying a wash program.
• Deleting a wash program.
• Inspecting the wash program by the view function.
The CONFIGURATION Menu is Designated for :
• The selection of the machine type.
• Loading the default factory settings for the CONFIGURA-
TION and INITIALIZATION menu.
• The selection of the Brightness of the display.
• The selection of the power supply voltage of the washing ma-
chine.
• Loading the frequency inverter parameters.
• Erasing all the programmed wash programs (reset Wash pro-
gram EEPROM memory).
• Loading the standard wash programs.
• The selection of the number of wash machine water supply
inlets.
• The selection of a second drain valve (water recycling sys-
tem).
• Enablization of external liquid pumps (if applicable).
• The selection if the temperature must be displayed in degrees
Celsius or degrees Fahrenheit.
• The selection Full Heating.
• The selection of Wet Cleaning (very low programmable water
levels).
• The selection of the minimum level start supplies.
The INITIALIZATION Menu is Designated for :
• The selection of the displayed Language.
• Programming the Service due value.
• The selection of the Buzzer time interval.
• The selection of the Advance function.
• The selection of the Wait for temperature function.
• The selection of the Manual override function.
• The selection of the Temperature balance function.
• Programming the Default Motor On and Off times for revers-
ing wash action.
• The selection of the Automatic Cooldown function.
• Programming the Boiler temperature (hot water supply).
• Programming the Temperature Overshoot Protection value.
• Programming the Maximum Heating time value.
• Programming the Maximum Fill time value.
• Programming the Maximum Level overfill value.
The SERVICE Menu is Designated for :
• The inspection of the error messages log register and the list
with statistics.
• Activating the power of the frequency inverter.
• The inspection of the functionality of the electric input sig-
nals.
• Resetting the Cycle counter.
The ADVANCED Menu is Designated for :
• Special optional applications.
The PAYMENT Menu is Designated for:
• Selection of the payment mode.
• Setting the value of coins and currency.
• Setting the prices of programs (including special prices).
Basic Description of Controls
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
13 Part No. D1676ENR11

• Disabling (blocking) of programs.
• Optional functions.
• Type of displaying the program information.
Entering and Changing Values Utilizing
the Control Keypad
Entering a Numeric Value
1. Use the navigation buttons LEFT and RIGHT and choose the
position which you want to enter (change).
2. Use the CANCEL THE SELECTION button and enter the re-
quired value.
3. Use the START button to confirm the entered value.
EXAMPLE: How to Enter the Number "264":
1. Use the RIGHT button to move the cursor into the position of
the digit for single units.
2. Use the CANCEL THE SELECTION button and set the digit
to "4".
3. Use the LEFT button to move the cursor into the position of
the digit for tens
4. Use the CANCEL THE SELECTION button and set the digit
to "6".
5. Use the LEFT button to move the cursor into the position of
the digit for hundreds.
6. Use the CANCEL THE SELECTION button and set the digit
to "2".
7. Use the START button to finish the process of entering the
value.
Entering a Logical Value and Selection from a List
1. Use the hidden navigation buttons LEFT and RIGHT to enter
(change) a logical value or to select an item from a list.
2. Use the START button to confirm the entered value.
How to Get into the Setup Mode
1. Press the buttons LEFT and CANCEL THE SELECTION at
the same time.
2. Release the LEFT button and then, after one second, release
the CANCEL THE SELECTION button.
3. The display shows Service Info.
CFD1343R_SVG
Service Info
Figure 4
4. Press the buttons LEFT and RIGHT at the same time.
5. The display shows the main menu. If the password has been
activated, you will have to enter the correct password first.
CFD1344R_SVG
To Program Mode
Password
Figure 5
How to Leave a Setup Mode
When the "Main Menu" screen is shown.
1. Press the CANCEL THE SELECTION button on the keypad.
2. Then you will return to “Run Mode“ and the program over-
view is shown.
Basic Description of Controls
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
14 Part No. D1676ENR11

15 Wash Programs - 99 Steps
Program 1 Program 2 Program 3 . . . Program 15
Name Prog Name Prog Name Prog Name Prog
Step 1 Step 1 Step 1 . . . Step 1
Wash
Sequence
Wash
Sequence
Wash
Sequence
Wash
Sequence
Drain/
Extraction
Sequence
Drain/
Extraction
Sequence
Drain/
Extraction
Sequence
Drain/
Extraction
Sequence
Step 2 Step 2 . . . Step 2
Wash
Sequence
Wash
Sequence
Wash
Sequence
Drain/
Extraction
Sequence
Drain/
Extraction
Sequence
Drain/
Extraction
Sequence
Step 3 . . . Step 3
Wash
Sequence
Wash
Sequence
Drain/
Extraction
Sequence
Drain/
Extraction
Sequence
. . . . . .
Step 99 Step 99
Wash
Sequence
Wash
Sequence
Drain/
Extraction
Sequence
Drain/
Extraction
Sequence
Tumble
Sequence
Tumble
Sequence
Tumble
Sequence
. . . Tumble
Sequence
CHM1685R
Figure 6
Basic Description of Controls
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
15 Part No. D1676ENR11

Available Wash Sequences
Available Wash Sequences: Prewash, Wash, Cooldown, Rinse,
Extra Rinse, Final Rinse, Soak, Spray, No Wash.
Available drain/extraction sequences: Drain, Extract, No drain,
Static drain, Rev drain.
The Creation of a Wash Program
•A Wash Program is created step by step.
•Each step always consists of a Wash sequence and a
Drain/Extraction sequence.
Programming the Wash Sequence
First choose the type of Wash sequence.
• PREWASH
• WASH
• COOLDOWN
• RINSE
• EXTRA RINSE
• FINAL RINSE
• SOAK
• SPRAY
• No WASH
Then program all the related functions of the sequence.
Available functions
• Temperature
• Water Level
• Water Inlet Valves
• The Wash Speed
• The Reversing Interval times
• Supplies
• Sequence Time (length of step)
• Drain valve 1 - 2
• Pause Signal
Each step is pre-loaded with default settings. When creating a
program, you can choose to utilize these suggested settings.
Programming the Drain Sequence
After programming the Wash sequence, next program the Drain/
Extraction sequence.
• DRAIN
• EXTRACTION
• No DRAIN
• STATIC DRAIN
• REVERSING DRAIN
Then program all the related functions of the Drain/Extraction se-
quence.
Available functions
• Sequence Time (length of step)
• Speed
• Drain valve 1 - 2
You can skip a sequence between two by programming No
WASH or No Drain.
Example : The No drain sequence should be programmed be-
tween a wash and a cooldown sequence.
NOTE: A more detailed explanation for the specific se-
quences can be found in Chapter Step 4: Programming
the Wash Part , Step 5: Programming the Drain Step.
The Tumble Sequence
• The wash cycle will always end with the Tumble sequence.
• The tumble sequence takes 30 Seconds, then the program is
finished and the door can be opened.
•The Tumble sequence cannot be skipped.
Programming the Functions
Limits
• To ensure the correct functionality of the washing machine
you have to program values within certain limits.
• If you program a value that falls below the minimal or above
the maximal programmable limit then the new value will not
be accepted and the previous value stays valid.
Programming the Water Temperature
Limits
• Minimum value : 33.8°F [1°C]
• Maximum value : 113°F [45°C] for the PREWASH and
SOAK and 197.6°F [92°C] for the WASH sequence.
• For RINSE, EXTRA RINSE, FINAL RINSE and SPRAY no
Temperature can be programmed.
Programming the Water Inlets Valves
• Depending on the programmed temperature the water inlet
valves are suggested.
• While the tub is filling with water, the computer controls the
water temperature. By switching on and off the hot and cold
water inlet valves the correct water temperature is obtained.
• For machines with a Top Soap Dispenser you have to consider
that by programming the water inlet valves, at the same time,
you are also selecting the soap Box at which the soap must be
added.
• If you want to program a wash sequence with :
• Cold Water : only Cold Inlet Valves must be programmed
• Warm or Hot water : Cold and Hot Inlet Valves must be
programmed
Top Soap Dispenser Machines
The Cold Water Inlet Valves
Basic Description of Controls
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
16 Part No. D1676ENR11

• Inlet Valve 1 corresponds with soap box for a Prewash.
• Inlet Valve 2 corresponds with soap box for a Wash - deter-
gent.
• Inlet Valve 3 corresponds with soap box for a Wash - liquid
soap.
• Inlet Valve 4 corresponds with soap box for a Final Rinse.
• Inlet Valve 7 is a direct Inlet Valve and speeds up the water
fill process.
The Hot Water Inlet Valves
• Inlet Valve 5 corresponds with soap box for a Prewash.
• Inlet Valve 6 corresponds with soap box for a Wash - deter-
gent.
• Inlet Valve 8 corresponds with soap box for a Wash - liquid
soap.
How to Select Inlet Valves: EXAMPLE
For a Prewash: Programmable tem-
perature:
33.8 - 113°F [1 -
45°C]
Inlet Valve 1 (cold)
and/or 5 (hot)
soap box for a Pre-
wash
and/or 7 (cold) direct Inlets
For a Wash: Programmable tem-
perature:
33.8 - 197.6°F [1 -
92°C]
Inlet Valve 2 (cold)
and/or 6 (hot)
soap box for a
Wash - detergent
and/or 7 (cold) direct Inlets
For a Rinse: Inlet valves 1+2+7
(cold)
No detergent is
added
Table 3 continues...
How to Select Inlet Valves: EXAMPLE
For a Final Rinse: Inlet valve 4 soap box for a Final
rinse
and/or 7 (cold) direct inlets
Table 3
WARNING
For machines with liquid supply pumps, direct water
inlet valve 7 must be programmed because the liquid
is added at the direct water inlet channel. For wash-
ing machines with water recycling, the water recy-
cling supply must be connected to inlet valve 5 or 7.
C015
Programming the Water Level
Water Level Limits
• Refer to Table 6 . The values are different for each machine
type.
• Minimum value: above the heating elements and the tempera-
ture sensor.
• Maximum value: half the wash drum.
Normal Low Level, Normal High Level
• The Normal Low Level is recommended for the PREWASH,
WASH and SOAK sequences.
• The Normal High Level is recommended for the RINSE and
FINAL RINSE Sequences.
• At the COOLDOWN sequence, the Wash Computer makes
use of a low water level and is draining the water automatical-
ly.
• At the Spray sequence, the Drain valve stays open.
Wet Cleaning Selection Configuration Menu
• It’s possible to program a level below default minimum pro-
grammable level. Refer to Table 6 .
• The heating will not be functional for a water level below the
standard minimum programmable water level.
NOTE: For woolens and other delicate linen a normal
high water level is recommended. The economic func-
tion should only be used for lightly soiled and/or small-
er volumes of laundry. In other cases, the program will
give poor washing quality.
Basic Description of Controls
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
17 Part No. D1676ENR11

Cabinet Freestanding 6.5-28 kg / 14-70 lb / 65-280 L
Water Volume per Water Level - With No Load - Cabinet Freestanding Models
Water
Level
Machine Capacity
6.5 kg / 14
lb / 65 L
7.5 kg / 20
lb / 80 L
10.5 kg /
25 lb / 105
L
13.5 kg /
30 lb / 135
L
18 kg / 40
lb / 180 L
24 kg / 55
lb / 240 L
28 kg / 70
lb / 280 L
7 - - - - 2.11 gal [8 l] 3.83 gal [14.5
l]
2.93 gal [11.1
l]
8 - - - - 2.64 gal [10 l] 4.62 gal [17.5
l]
3.72 gal [14.1
l]
9 2.51 gal [9.5 l] 2.77 gal [10.5
l]
2.77 gal [10.5
l]
3.17 gal [12 l] 3.30 gal [12.5
l]
5.55 gal [21 l] 4.54 gal [17.2
l]
10 2.91 gal [11 l] 3.17 gal [12 l] 3.17 gal [12 l] 3.83 gal [14.5
l]
3.83 gal [14.5
l]
6.34 gal [24 l] 5.57 gal [21.1
l]
11 (1) 3.43 gal
[13 l]
3.57 gal [13.5
l]
3.70 gal [14 l] 4.36 gal [16.5
l]
4.49 gal [17 l] 7.40 gal [28 l] 6.46 gal [24.4
l]
12 (2) 3.83 gal
[14.5 l]
(1) 4.09 gal
[15.5 l]
(1) 4.23 gal
[16 l]
5.02 gal [19 l] 5.15 gal [19.5
l]
8.32 gal [31.5
l]
7.50 gal [28.4
l]
13 (3) 4.23 gal
[16 l]
(2) 4.49 gal
[17 l]
(2) 4.76 gal
[18 l]
(1) 5.68 gal
[21.5 l]
5.81 gal [22 l] 8.85 gal [33.5
l]
8.53 gal [32.3
l]
14 (4) 4.76 gal
[18 l]
(3) 5.02 gal
[19 l]
(3) 5.28 gal
[20 l]
(2) 6.34 gal
[24 l]
6.60 gal [25 l] 9.77 gal [37 l] 9.64 gal [36.5
l]
15 5.15 gal [19.5
l]
(4) 5.55 gal
[21 l]
(4) 5.81 gal
[22 l]
(3) 7.13 gal
[27 l]
7.40 gal [28 l] 10.83 gal [41
l]
10.83 gal [41
l]
16 5.68 gal [21.5
l]
6.08 gal [23 l] 6.47 gal [24.5
l]
(4) 7.79 gal
[29.5 l]
(1) 8.32 gal
[31.5 l]
(1) 11.89 gal
[45 l]
(1) 11.83 gal
[44.8 l]
17 6.21 gal [23.5
l]
6.74 gal [25.5
l]
7.13 gal [27 l] 8.59 gal [32.5
l]
(2) 9.11 gal
[34.5 l]
(2) 12.81 gal
[48.5 l]
(2) 13.18 gal
[49.9 l]
18 6.74 gal [25.5
l]
7.26 gal [27.5
l]
7.79 gal [29.5
l]
9.51 gal [36 l] (3) 10.04 gal
[38 l]
(3) 13.74 gal
[52 l]
(3) 14.50 gal
[54.9 l]
19 7.26 gal [27.5
l]
7.79 gal [29.5
l]
8.45 gal [32 l] 10.30 gal [39
l]
(4) 10.83 gal
[41 l]
(4) 14.40 gal
[54.5 l]
(4) 15.80 gal
[59.8 l]
20 7.66 gal [29 l] 8.32 gal [31.5
l]
8.98 gal [34 l] 11.23 gal [42.5
l]
11.76 gal [44.5
l]
15.72 gal
[59.5 l]
17.14 gal
[64.9 l]
21 8.19 gal [31 l] 8.85 gal [33.5
l]
9.77 gal [37 l] 12.02 gal
[45.5 l]
12.68 gal [48
l]
16.91 gal [64
l]
18.33 gal
[69.4 l]
22 8.85 gal [33.5
l]
9.51 gal [36 l] 10.43 gal
[39.5 l]
12.81 gal
[48.5 l]
13.60 gal
[51.5 l]
18.10 gal
[68.5 l]
19.65 gal
[74.4 l]
Table 4 continues...
Basic Description of Controls
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
18 Part No. D1676ENR11

Water Volume per Water Level - With No Load - Cabinet Freestanding Models
Water
Level
Machine Capacity
6.5 kg / 14
lb / 65 L
7.5 kg / 20
lb / 80 L
10.5 kg /
25 lb / 105
L
13.5 kg /
30 lb / 135
L
18 kg / 40
lb / 180 L
24 kg / 55
lb / 240 L
28 kg / 70
lb / 280 L
23 9.51 gal [36 l] 10.17 gal
[38.5 l]
11.10 gal [42
l]
13.74 gal [52
l]
14.53 gal [55
l]
19.28 gal [73
l]
21.13 gal [80
l]
24 10.17 gal
[38.5 l]
10.7 gal [40.5
l]
11.89 gal [45
l]
14.53 gal [55
l]
15.45 gal
[58.5 l]
20.47 gal
[77.5 l]
22.48 gal
[85.1 l]
25 10.70 gal
[40.5 l]
11.36 gal [43
l]
12.68 gal [48
l]
15.45 gal
[58.5 l]
16.51 gal
[62.5 l]
21.93 gal [83
l]
23.78 gal [90
l]
26 11.36 gal [43
l]
12.15 gal [46
l]
13.47 gal [51
l]
16.38 gal [62
l]
17.44 gal [66
l]
22.85 gal
[86.5 l]
25.20 gal
[95.4 l]
27 12.15 gal [46
l]
12.94 gal [49
l]
14.27 gal [54
l]
17.17 gal [65
l]
18.36 gal
[69.5 l]
24.04 gal [91
l]
26.60 gal
[100.7 l]
28 12.94 gal [49
l]
13.74 gal [52
l]
15.06 gal [57
l]
18.10 gal
[68.5 l]
19.28 gal [73
l]
25.23 gal
[95.5 l]
27.71 gal
[104.9 l]
29 13.74 gal [52
l]
14.53 gal [55
l]
15.98 gal
[60.5 l]
18.89 gal
[71.5 l]
20.21 gal
[76.5 l]
26.55 gal
[100.5 l]
29.09 gal
[110.1 l]
30 - - 16.77 gal
[63.5 l]
19.81 gal [75
l]
21.13 gal [80
l]
27.74 gal [105
l]
30.56 gal
[115.7 l]
(1) Economic Low Level
(2) Economic High Level
(3) Normal Low Level
(4) Normal High Level
Table 4
Cabinet Hardmount 7.5-52 kg / 20-120 lb / 80-520 L
Water Volume per Water Level - With No Load – Cabinet Hardmount Models
Water
Level
Machine Capacity
7.5 kg /
20 lb / 80
L
10.5 kg /
25 lb /
105 L
13.5 kg /
30 lb /
135 L
18 kg /
40 lb /
180 L
24 kg /
55 lb /
240 L
28 kg /
70 lb /
280 L
35 kg /
80 lb /
332 L
52 kg /
120 lb /
520 L
7 - - - 2 gal [7.6 l] 2.40 gal
[9.10 l]
2.17 gal [8.2
l]
- -
Table 5 continues...
Basic Description of Controls
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
19 Part No. D1676ENR11

Water Volume per Water Level - With No Load – Cabinet Hardmount Models
Water
Level
Machine Capacity
7.5 kg /
20 lb / 80
L
10.5 kg /
25 lb /
105 L
13.5 kg /
30 lb /
135 L
18 kg /
40 lb /
180 L
24 kg /
55 lb /
240 L
28 kg /
70 lb /
280 L
35 kg /
80 lb /
332 L
52 kg /
120 lb /
520 L
8 - - - 2.54 gal [9.6
l]
3.06 gal
[11.60 l]
2.88 gal
[10.9 l]
- -
9 2.38 gal [9 l] 2.64 gal [10
l]
2.77 gal
[10.5 l]
3.17 gal [12
l]
3.83 gal
[14.50 l]
3.59 gal
[13.6 l]
- -
10 2.77 gal
[10.5 l]
3.17 gal [12
l]
3.30 gal
[12.5 l]
3.78 gal
[14.3 l]
4.49 gal [17
l]
4.46 gal
[16.9 l]
- -
11 3.30 gal
[12.5 l]
3.70 gal [14
l]
4.09 gal
[15.5 l]
4.39 gal
[16.6 l]
5.36 gal
[20.3 l]
5.36 gal
[20.3 l]
- -
12 (1) 3.83 gal
[14.5 l]
(1) 4.23 gal
[16 l]
4.62 gal
[17.5 l]
5.10 gal
[19.3 l]
6.23 gal
[23.6 l]
6.37 gal
[24.1 l]
- -
13 (2) 4.23 gal
[16 l]
(2) 4.76 gal
[18 l]
(1) 5.28 gal
[20 l]
5.73 gal
[21.7 l]
7.21 gal
[27.3 l]
7.34 gal
[27.8 l]
- -
14 (3) 4.89 gal
[18.5 l]
(3) 5.28 gal
[20 l]
(2) 5.94 gal
[22.5 l]
6.55 gal
[24.8 l]
8.27 gal
[31.3 l]
8.40 gal
[31.8 l]
- -
15 (4) 5.42 gal
[20.5 l]
(4) 5.94 gal
[22.5 l]
(3) 6.74 gal
[25.5 l]
7.26 gal
[27.5 l]
9.14 gal
[34.6 l]
9.46 gal
[35.8 l]
5.28 gal [20
l]
-
16 5.94 gal
[22.5 l]
6.60 gal [25
l]
(4) 7.53 gal
[28.5 l]
(1) 8.06 gal
[30.5 l]
(1) 10.20 gal
[38.6 l]
(1) 10.62 gal
[40.2 l]
6.21 gal
[23.5 l]
-
17 6.60 gal [25
l]
7.26 gal
[27.5 l]
8.19 gal [31
l]
(2) 8.93 gal
[33.8 l]
(2) 11.25 gal
[42.6 l]
(2) 11.78 gal
[44.6 l]
7.26 gal
[27.5 l]
8.72 gal [33
l]
18 7.13 gal [27
l]
7.93 gal [30
l]
8.98 gal [34
l]
(3) 9.85 gal
[37.3 l]
(3) 12.36 gal
[46.8 l]
(3) 13.05 gal
[49.4 l]
8.19 gal [31
l]
10.43 gal
[39.5 l]
19 7.66 gal [29
l]
8.45 gal [32
l]
9.77 gal [37
l]
(4) 10.78 gal
[40.8 l]
(4) 13.58 gal
[51.4 l]
(4) 14.27 gal
[54 l]
9.11 gal
[34.5 l]
12.02 gal
[45.5 l]
20 8.19 gal [31
l]
9.25 gal [35
l]
10.57 gal
[40 l]
11.62 gal [44
l]
14.40 gal
[54.5 l]
15.59 gal
[59 l]
10.17 gal
[38.5 l]
13.21 gal
[50 l]
21 8.72 gal [33
l]
9.77 gal [37
l]
11.36 gal [43
l]
12.55 gal
[47.5 l]
15.72 gal
[59.5 l]
16.80 gal
[63.6 l]
11.23 gal
[42.5 l]
15.32 gal
[58 l]
22 9.38 gal
[35.5 l]
10.57 gal
[40 l]
12.15 gal
[46 l]
13.31 gal
[50.4 l]
16.83 gal
[63.7 l]
18.10 gal
[68.5 l]
12.55 gal
[47.5 l]
17.17 gal
[65 l]
23 9.91 gal
[37.5 l]
11.23 gal
[42.5 l]
13.08 gal
[49.5 l]
14.24 gal
[53.9 l]
18.10 gal
[68.5 l]
19.44 gal
[73.6 l]
13.47 gal
[51 l]
19.02 gal
[72 l]
24 10.57 gal
[40 l]
11.89 gal [45
l]
14 gal [53 l] 15.16 gal
[57.4 l]
19.28 gal
[73 l]
20.74 gal
[78.5 l]
14.66 gal
[55.5 l]
21 gal [79.5
l]
Table 5 continues...
Basic Description of Controls
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
20 Part No. D1676ENR11
