Alliance Laundry Systems F8343001 Operating instructions

www.comlaundry.com
CHM1772C
Part No. F8343001
December 2009
Washer-Extractor
Cabinet Hardmount
Refer to Page 8 for Model Numbers
Troubleshooting

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
© Copyright 2009, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any
means without the expressed written consent of the publisher.
F8343001 1
Table of
Contents
Safety Information.............................................................................. 2
Explanation of Safety Messages........................................................... 2
General Safety Precautions................................................................... 2
Important Safety Instructions ............................................................... 3
Safety Decals ........................................................................................ 5
Operator Safety..................................................................................... 5
Introduction......................................................................................... 6
Customer Service.................................................................................. 6
Nameplate Location.............................................................................. 6
Model Identification ............................................................................. 7
Theory of Operation ........................................................................... 8
Starting the Machine............................................................................. 8
Fill......................................................................................................... 8
Supply................................................................................................... 8
Wash ..................................................................................................... 8
Drain ..................................................................................................... 8
Extract................................................................................................... 8
Troubleshooting .................................................................................. 9
1. Machine Does Not Start When Control Reads “Press Start”......... 10
2. “dOOr” Displayed at Startup or When Vend Satisfied.................. 12
3. Door Does Not Lock at Startup...................................................... 14
4. No Display ..................................................................................... 16
5. Machine Does Not Fill with Water ................................................ 20
6. Abnormal Operation ...................................................................... 22
7. Door Fails to Unlock at End of the Cycle...................................... 24
8. Excessive Cycle Time.................................................................... 26
9. No Outputs ..................................................................................... 27
10. Excessive Vibration and/or Noise During Spin ............................. 30
11. No External Supplies ..................................................................... 32
12. Machine Powers Up in Factory Test Mode ................................... 34
13. Machine Fills at Wrong Temperature ............................................ 38
14. No Rotation with Drive Fault (80 Pound Models Only)................ 40
15. No Rotation without Drive Fault (80 Pound Models Only)........... 41
16. No Basket Rotation (F-speed Models)........................................... 43
17. No Extract (F-speed Models) ......................................................... 44
18. No Extract (2 Speed Models)......................................................... 46
19. Heat Error (Machines with Auxillary Heat Only) ......................... 48
20. Can’t Access Programming ........................................................... 49

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8343001
2
Safety Information
Explanation of Safety Messages
Throughout this manual and on machine decals, you
will find precautionary statements (“DANGER,”
“WARNING,” and “CAUTION”) followed by specific
instructions. These precautions are intended for the
personal safety of the operator, user, servicer, and
those maintaining the machine.
Additional precautionary statements (“IMPORTANT”
and “NOTE”) are followed by specific instructions.
IMPORTANT: The word “IMPORTANT” is used
to inform the reader of specific procedures where
minor machine damage will occur if the procedure
is not followed.
NOTE: The word “NOTE” is used to communicate
installation, operation, maintenance or servicing
information that is important but not hazard
related.
General Safety Precautions
In the interest of safety, some general precautions
relating to the operation of this machine follow.
Danger indicates the presence of a hazard
that will cause severe personal injury,
death or substantial property damage if
the danger is ignored.
DANGER
Warning indicates the presence of a
hazard that can cause severe personal
injury, death or substantial property
damage if the warning is ignored.
WARNING
Caution indicates the presence of a
hazard that will or can cause minor
personal injury or property damage if the
caution is ignored.
CAUTION
Failure to install, maintain and/or
operate this product according to the
manufacturer’s instructions may result
in conditions which can produce
serious injury, death and/or property
damage.
Do not repair or replace any part of the
product or attempt any servicing unless
specifically recommended or published
in this Service Manual and unless you
understand and have the skills to carry
out the servicing.
Whenever ground wires are removed
during servicing, these ground wires
must be reconnected to ensure that the
product is properly grounded and to
reduce the risk of fire, electric shock,
serious injury or death.
W006R2
WARNING
To reduce the risk of electric shock, fire,
explosion, serious injury or death:
Disconnect electric power to the
washer-extractor before servicing.
Never start the washer-extractor with
any guards/panels removed.
Whenever ground wires are removed
during servicing, these ground wires
must be reconnected to ensure that the
washer-extractor is properly grounded.
W460
WARNING
Repairs that are made to your products
by unqualified persons can result in
hazards due to improper assembly or
adjustments subjecting you, or the
inexperienced person making such
repairs, to the risk of serious injury,
electrical shock, or death.
W007
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Information
3
F8343001
Always contact your dealer, distributor, service agent
or the manufacturer about any problems or conditions
you do not understand.
Important Safety Instructions
1. Read all instructions before using the washer.
2. Refer to the GROUNDING INSTRUCTIONS in
the INSTALLATION manual (supplied with your
washer) for the proper grounding of the washer.
3. Do not wash textiles that have been previously
cleaned in, washed in, soaked in or spotted with
gasoline, kerosene, waxes, cooking oils, dry-
cleaning solvents or other flammable or
explosive substances. They give off vapors that
could ignite or explode.
4. Do not add gasoline, dry-cleaning solvents or
other flammable or explosive substances to the
wash water. These substances give off vapors that
could ignite or explode.
5. Under certain conditions, hydrogen gas may be
produced in a hot water system that has not been
used for two weeks or more. HYDROGEN GAS
IS EXPLOSIVE. If the hot water system has not
been used for such a period, before using a
washer, turn on all hot water faucets and let the
water flow from each for several minutes. This
will release any accumulated hydrogen gas. The
gas is flammable. Do not smoke or use an open
flame during this time.
6. Do not allow children to play on or in a washer.
Close supervision of children is necessary when
the washer is used near children.
7. Before the washer is removed from service or
discarded, remove the door to the washing
compartment.
8. Do not reach into the washer if the wash drum is
moving.
9. Do not install or store the washer where it will be
exposed to water and/or weather.
10. Do not tamper with the controls.
11. Do not repair or replace any part of the washer or
attempt any servicing unless specifically
recommended in the user-maintenance
instructions or in published user-repair
instructions that the user understands and has the
skills to carry out.
12. To reduce the risk of an electrical shock or fire,
DO NOT use an extension cord or an adapter to
connect the washer to an electrical power source.
13. Use the washer only for its intended purpose,
washing clothes.
14. Never wash machine parts or automotive parts in
the machine. This could result in serious damage
to the basket.
15. ALWAYS disconnect the washer from its
electrical supply before attempting any service.
16. Install the washer according to the
INSTALLATION INSTRUCTIONS. All
connections for water, drain, electrical power and
grounding must comply with local codes and,
when required, be made by licensed personnel.
17. To reduce the risk of fire, textiles which have
traces of any flammable substances such as
vegetable oil, cooking oil, machine oil,
flammable chemicals, thinner, etc. or anything
containing wax or chemicals such as in mops or
cleaning cloths, must not be put into the washer.
These flammable substances may cause the
fabric to ignite.
18. Do not use fabric softeners or products to
eliminate static unless recommended by the
manufacturer of the fabric softener or product.
19. Keep the washer in good condition. Bumping or
dropping the washer can damage its safety
features. If this occurs, have the washer checked
by a qualified service person.
If you or an unqualified person perform
service on your product, you must
assume the responsibility for any
personal injury or property damage
which may result. The manufacturer will
not be responsible for any injury or
property damage arising from improper
service and/or service procedures.
W008
WARNING
To reduce the risk of fire, electric shock,
serious injury or death to persons when
using your washer, follow these basic
precautions:
W023
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Information
F8343001
4
20. If the supply cord is damaged, it must be replaced
by a special cord or assembly available from the
manufacturer or its service agent.
21. Be sure that water connections have a shut-off
valve and that fill hose connections are tight.
CLOSE the shut-off valves at the end of each
wash day.
22. The loading door MUST BE CLOSED any time
the washer is to fill, tumble or spin. DO NOT
bypass the loading door switch and permit the
washer to operate with the loading door open.
23. Always read and follow the manufacturer’s
instructions on packages of laundry and cleaning
aids. Heed all warnings and precautions. To
reduce the risk of poisoning or chemical burns,
keep them out of the reach of children at all times
(preferably in a locked cabinet).
24. Always follow the fabric care instructions
supplied by the textile manufacturer.
25. Never operate the washer with any guards and/or
panels removed.
26. DO NOT operate the washer with missing or
broken parts.
27. DO NOT bypass any safety devices.
28. Failure to install, maintain and/or operate this
washer according to the manufacturer's
instructions may result in conditions that can
produce bodily injury and/or property damage.
NOTE: The WARNING and IMPORTANT
SAFETY INSTRUCTIONS appearing in this
manual are not meant to cover all possible
conditions and situations that may occur. Common
sense, caution and care must be exercised when
installing, maintaining and operating the washer.
Any problems or conditions not understood should be
reported to the dealer, distributor, service agent or the
manufacturer.
IMPORTANT: Ensure that the recommended
clearances for inspection and maintenance
are provided. Never allow the inspection and
maintenance space to be blocked.
This machine must be installed, adjusted,
and serviced by qualified electrical
maintenance personnel familiar with the
construction and operation of this type of
machinery. They must also be familiar
with the potential hazards involved.
Failure to observe this warning may result
in personal injury and/or equipment
damage, and may void the warranty.
SW004
WARNING
Install the machine on a level floor of
sufficient strength. Failure to do so may
result in conditions which can produce
serious injury, death and/or property
damage.
W703
WARNING
Be careful around the open door,
particularly when loading from a level
below the door. Impact with door edges
can cause personal injury.
SW025
CAUTION
Never touch internal or external steam
pipes, connections, or components.
These surfaces can be extremely hot and
will cause severe burns. The steam must
be turned off and the pipe, connections,
and components allowed to cool before
the pipe can be touched.
SW014
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Information
5
F8343001
Safety Decals
Safety decals appear at crucial locations on the
machine. Failure to maintain legible safety decals
could result in injury to the operator or service
technician.
To provide personal safety and keep the machine in
proper working order, follow all maintenance and
safety procedures presented in this manual. If
questions regarding safety arise, contact the
manufacturer immediately.
Use manufacturer-authorized spare parts to avoid
safety hazards.
Operator Safety
To ensure the safety of machine operators, the
following maintenance checks must be performed
daily:
1. Prior to operating the machine, verify that all
warning signs are present and legible. Missing or
illegible signs must be replaced immediately.
Make certain that spares are available.
2. Check door interlock before starting operation of
the machine:
a. Attempt to start the machine with the door
open. The machine should not start with the
door open.
b. Close the door without locking it and attempt
to start the machine. The machine should not
start with the door unlocked.
c. Close and lock the door and start a cycle.
Attempt to open the door while the cycle is in
progress. The door should not open.
If the door lock and interlock are not functioning
properly, call a service technician.
3. Do not attempt to operate the machine if any of
the following conditions are present:
a. The door does not remain securely locked
during the entire cycle.
b. Excessively high water level is evident.
c. Machine is not connected to a properly
grounded circuit.
Do not bypass any safety devices in the machine.
NEVER insert hands or objects into
basket until it has completely stopped.
Doing so could result in serious injury.
SW012
WARNING
Never operate the machine with a
bypassed or disconnected balance
system. Operating the machine with
severe out-of-balance loads could result
in personal injury and serious equipment
damage.
SW039
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8343001
6
Introduction
Customer Service
Alliance Laundry Systems is not responsible for
personal injury or property damage resulting from
improper service. Review all service information
before beginning repairs.
If literature or replacement parts are required, contact
the source from whom the machine was purchased or
contact Alliance Laundry Systems at [phone]
for the name of the nearest authorized parts distributor.
For technical assistance, contact your local distributor
or call:
Alliance Laundry Systems
[phone]
Ripon, Wisconsin U.S.A.
Alliance International
[phone]
Wevelgem, Belgium
Nameplate Location
When calling or writing about your product, be sure to
mention model and serial numbers. Model and serial
numbers are located on nameplate(s) as shown.
CHM3025P
CHM3025P
*CN030GCUOU001
00000000000
208 – 240
3
Hz
Hz
Phase
Phase
SupplyWater:
SupplyWater:
BAR
BAR
Numberof wires :
Numberof wires :
FLA:
FLA :
amps
amps
3
CircuitBreaker Size :
CircuitBreaker Size :
amps
amps
60 3
SerialNo.
Serial No.
ModelNo.
ModelNo.
Voltage
Voltage
40
30 - 85 psi, 2 - 5.7
Max.Load :
Max.Load :
Schematic:
Schematic:
KG
KG
18.2
LB
LB
*CN030GCUOU001
00000000000
208 – 240
3
Hz
Hz
Phase
Phase
Supply Water:
Supply Water:
BAR
BAR
Number of wires :
Number of wires :
FLA :
FLA :
amps
amps
3
Circuit Breaker Size :
Circuit Breaker Size :
amps
amps
60 3
Serial No.
Serial No.
Model No.
Model No.
Voltage
Voltage
40
30 - 85 psi, 2 - 5.7
Max. Load :
Max. Load :
Schematic :
Schematic :
KG
KG
18.2
LB
LB

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Introduction
7
F8343001
Model Identification
Information in this manual is applicable to these washers.
HCD020GD2
HCL020GD2
HCL020GN2
HCL030GN2
HCL040GN2
HCL060GN2
HCN020GC2
HCN020GD2
HCN020GE2
HCN020GN2
HCN020GX2
HCN020GY2
HCN030GC2
HCN030GD2
HCN030GE2
HCN030GN2
HCN030GX2
HCN030GY2
HCN040GC2
HCN040GD2
HCN040GE2
HCN040GN2
HCN040GX2
HCN040GY2
HCN060GC2
HCN060GD2
HCN060GE2
HCN060GN2
HCN060GX2
HCN060GY2
HCN080GCF
HCN080GDF
HCN080GEF
HCN080GNF
HCN080GXF
HCN080GYF
HCU020GC2
HCU020GD2
HCU020GE2
HCU020GL2
HCU020GN2
HCU020GX2
HCU020GY2
HCU030GC2
HCU030GD2
HCU030GE2
HCU030GL2
HCU030GN2
HCU030GX2
HCU030GY2
HCU040GC2
HCU040GD2
HCU040GE2
HCU040GL2
HCU040GN2
HCU040GX2
HCU040GY2
HCU060GC2
HCU060GD2
HCU060GE2
HCU060GL2
HCU060GN2
HCU060GX2
HCU060GY2
HCU080GCF
HCU080GDF
HCU080GEF
HCU080GLF
HCU080GNF
HCU080GXF
HCU080GYF
HCZ020GN2
HCZ030GN2
SCD030GD2
SCD040GD2
SCD060GD2
SCL020GN2
SCL030GC2
SCL030GN2
SCL040GC2
SCL040GN2
SCL060GN2
SCL080GNF
SCN020GC2
SCN020GD2
SCN020GE2
SCN020GN2
SCN020GX2
SCN020GY2
SCN030GC2
SCN030GD2
SCN030GE2
SCN030GN2
SCN030GX2
SCN030GY2
SCN040GC2
SCN040GD2
SCN040GE2
SCN040GN2
SCN040GX2
SCN040GY2
SCN060GC2
SCN060GD2
SCN060GE2
SCN060GN2
SCN060GX2
SCN060GY2
SCN080GCF
SCN080GDF
SCN080GEF
SCN080GNF
SCN080GXF
SCN080GYF
SCU020GC2
SCU020GD2
SCU020GE2
SCU020GL2
SCU020GN2
SCU020GX2
SCU020GY2
SCU030GC2
SCU030GD2
SCU030GE2
SCU030GL2
SCU030GN2
SCU030GX2
SCU030GY2
SCU040GC2
SCU040GD2
SCU040GE2
SCU040GL2
SCU040GN2
SCU040GX2
SCU040GY2
SCU060GC2
SCU060GD2
SCU060GE2
SCU060GL2
SCU060GN2
SCU060GX2
SCU060GY2
SCU080GCF
SCU080GDF
SCU080GEF
SCU080GLF
SCU080GNF
SCU080GXF
SCU080GYF
UCL030GN2
UCL040GN2
UCL060GN2
UCL080GNF
UCN020GN2
UCN030GN2
UCN040GN2
UCN060GN2
UCN080GNF
UCU020GN2
UCU030GN2
UCU040GN2
UCU060GN2
UCU080GNF
UCZ020GN2
UCZ030GN2

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8343001
8
Theory of Operation
Starting the Machine
The door lock will not allow a cycle to be started until
the door has been closed.
Fill
The operator selects a cycle and starts the machine.
Water enters the machine through water valves that are
controlled by the microcomputer. As water fills the
basket, a column of air is trapped in a pressure bulb
and hose. The air pressure continues to increase as the
basket fills with water. When the desired water level is
reached, the water level sensor triggers the
microcomputer and the water valves turn off.
A vacuum breaker installed in the inlet plumbing
prevents the backflow of water.
Supply
The operator can either connect external liquid
supplies to the machine or fill the supply dispenser
with liquid or dry supplies. The supply dispenser's
nozzles flush the compartments with water at the
appropriate times throughout a cycle.
Wash
The basket includes ribs that lift the laundry from the
wash water. The laundry then tumbles back into the
bath.
In 2-speed and variable-speed models, 1 dual-speed
motor drives the basket's shaft with a V-belt.
20-60 pound capacity models use 2 bearings that are
held in place by a single cast-iron trunnion that is
bolted to the frame. 80-pound capacity models use a 2
flange-type bearing that is bolted to the frame.
Drain
Cabinet Hardmount washer-extractors use a normally
open gravity-type drain system. No pump is used.
When the drain valve opens, the perforated basket
allows water to drain from it.
In the event of a power failure, the drain valve will
open automatically and the machine will drain.
Extract
A final high-speed extract step removes water from the
load, which maximizes drying efficiency.
The door lock system will not allow the door to be
opened until the cycle has finished.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 9
F8343001
Troubleshooting
To reduce the risk of electrical shock, fire, explosion, serious injury or death:
Disconnect electrical power to the washer-extractor before servicing it.
Close the gas shut-off valve to the washer-extractor (when applicable) before servicing it.
Never start the washer-extractor with any guards/panels removed.
Whenever ground wires are removed during servicing, these ground wires must be
reconnected to ensure that the washer-extractor is properly grounded.
W461R1
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
F8343001
10
1. Machine Does Not Start When Control Reads “Press Start”
CHM497S
Machine does not start when control reads “Press Start”
and Start Button is pressed
Is there 5VDC between H6
-3 and H6-6 on the AP2
Control Logic Board when
Start Button is pressed?
Start switch circuit is open. Inspect wiring
and switch, repair/replace as necessary.
Yes
Is there 5VDC between H6
-3 and H6-6 on the AP2
Control Logic Board when
Start Button is released?
Start switch circuit is functioning properly.
Replace AP2 Control Logic Board.
No
No
Start circuit is shorted closed. Check wiring for damage and start
switch for proper operation. Repair/replace as necessary.
Yes
A
A
B
CHM497S

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
11
F8343001
Machine Does Not Start When Control Reads “Press Start”
NOTE: Refer to the wiring diagram supplied with
your machine.
CHM505S
CHM505S
B
A

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
F8343001
12
2. “dOOr” Displayed at Startup or When Vend Satisfied
CHM482S
Is door handle
fully engaged? Fully latch door.
No
Is magnet
present on door?
Yes
Replace magnet.
No
Is J15 plug fully
engaged?
Yes
Firmly seat plug.
No
Door circuit is open. Diagnose and repair circuit.
Replace AP1 Output Board.
Is there 24VDC
between H6-1
and H6-5 on the
AP1 Output
Board?
Yes
No
Yes
“dOOr” Displayed at Startup or When Vend Satisfied
A
CHM482S

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
13
F8343001
“dOOr” Displayed at Startup or When Vend Satisfied
NOTE: Refer to the wiring diagram supplied with
your machine.
CHM504
CHM504S
A

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
F8343001
14
3. Door Does Not Lock at Startup
CHM480S
Door Does Not Lock at Startup
Is door handle
fully engaged?
No
Fully latch door.
Replace/Adjust solenoid
as neccsssary.
Is there 24VDC
between H6-1 and
H6-5?
Door circuit is open. Diagnose and repair
circuit.
A
B
Yes
Yes
Yes
Check for continuity through SP1a
empty level pressure switch:
If SP1a is open -
Pressure switch bad
Water in machine
Plugged pressure hose
If SP1a is closed -
Check door solenoid for
mechanical issues.
No
Make sure machine is empty and
check for continuity across H6-7
and H6-8?
NOTE: Only perform continuity
check if PSW SEL LED is OFF
No
No
Is the solenoid
mechanically bound?
CHM480S

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
15
F8343001
Door Does Not Lock at Startup
NOTE: Refer to the wiring diagram supplied with
your machine.
CHM504
CHM504S
A
A
B

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
F8343001
16
4. No Display
CHM483S
No Display
Is there power
between F1 and
F2 on AP1
Output Board?
Verify that voltage is present at all points
shown in callout B. Refer to No Display Schematic.
No
Are F1 and F2
fuse elements
intact?
Replace blown fuse(s) and find out why fuse(s) blew.
No
Yes
4. Is correct transformer jumper installed?
5. Is there:
+24VDC from H1-18 to H1-4
+33VDC from H1-18 to H1-3
+5VDC from H1-18 to H1-5
Yes
Verify H1/H3 harness is intact.
No
Is harness in
good condition?
Repair/replace
harness as
necessary.
No
Yes
Verify E-stop or Bypass Jumper is
installed, on coin machine.
Check for 220V at H9-3
and H9-2 on AP1 Output Board.
Yes
Is control in Low
Power Mode?
Yes
Press start switch or change
selected cycle for OPL
models to wake up the control
or cycle power to machine.
Replace AP2 Control Logic Board.
Yes
No
A
A
C
D
B
C
If voltage across H9-3, H9-2 is below
208 VAC install 208V transformer
jumper.
3. Is there 24VAC from H1-1 to H1-3 on
AP1 Output Board and the 5VDC LED lit?
1. Is there 200 - 240VAC from
H8-1 to H8-2?
2. Is there 24VAC from J9-2 to J9-3?
CHM483S

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
17
F8343001
Please see following 2 pages for wiring diagram information.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
F8343001
18
No Display (Sheet 1 of 2)
NOTE: Refer to the wiring diagram supplied with
your machine.
CHM509S
CHM509S
A
B
