Alliance Laundry Systems WF065B Maintenance and service guide

Installation/Maintenance
Washer-Extractors
Commercial Softmount
Refer to Page 11 for Model Identification
Original Instructions
Keep These Instructions for Future Reference.
CAUTION: Read the instructions before using the machine.
(If this machine changes ownership, this manual must accompany machine.)
www.alliancelaundry.com Part No. D2418ENR6
October 2023

Table of Contents
Safety Information..................................................................................5
Explanation of Safety Instructions Messages..................................................... 5
Important Safety Instructions........................................................................... 6
Introduction..........................................................................................11
Model Identification......................................................................................11
Regulatory Statements...................................................................................14
Serial Plate Location..................................................................................... 16
Manufacturing Date...................................................................................... 16
Delivery Inspection....................................................................................... 17
Specifications and Dimensions.............................................................. 18
General Specifications...................................................................................18
Machine Dimensions.....................................................................................23
Machine Dimensions (Models with Filter for Mops)........................................ 25
Machine Dimensions (Models with Base Frame with Built-in Filter for Mops)... 26
Mounting Bolt Hole Locations....................................................................... 28
Mounting Bolt Hole Locations (Models with Base Frame with Built-in Filter for
Mops).......................................................................................................31
Floor Mounting Layout .................................................................................33
Installation........................................................................................... 34
NOTE: Read Important Safety Instructions first...............................................34
Handling and Installation in Place.................................................................. 34
Mounting Bolt Installation ............................................................................ 35
Shipping Brace Removal............................................................................... 36
Top and Front Panel Reinstallation................................................................. 36
Machine Installation......................................................................................38
Elevated Base Frame Installation with Existing Floor (Base Frame Supplied by
Manufacturer)........................................................................................... 38
Machine Installation with Base Frame with Built-in Filter for Mops.................. 39
Drain Connection..........................................................................................41
Drain Valve...............................................................................................41
Drain Pump 6.5 kg / 14 lb. / 65 L and 7.5 kg / 20 lb. / Models outside of North
America ............................................................................................... 44
Water Connection Requirements.....................................................................45
Connecting Hoses......................................................................................47
Water Reuse System ................................................................................. 49
Reused Water Treatment............................................................................ 49
Water Reuse Tank Properties...................................................................... 49
Electrical Installation Requirements................................................................50
© Copyright 2023, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed
written consent of the publisher.
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
3 Part No. D2418ENR6

Residual Current Device (RCD) - Models Outside of North America............. 51
Supply Protection Device...........................................................................51
Supply Cable............................................................................................ 52
Machine Protective Earth Connection and Equipotential Bonding.................. 53
Input Power Conditioning..............................................................................54
Input V
oltage Requirements........................................................................54
Circuit Breakers and Quick Disconnects......................................................... 54
Connection Specifications..............................................................................54
Single-Phase Connections ......................................................................... 54
Three-Phase Connections........................................................................... 56
Phase Adder..............................................................................................57
Voltage Settings.........................................................................................57
Thermal Overload Protector....................................................................... 57
Electrical Specifications - Models Outside of North America ........................... 58
Electrical Specifications - North American Models.......................................... 66
Steam Requirements (Steam Heat Option Only)...............................................68
Steam Valve Installation.............................................................................68
Chemical Injection Supply System................................................................. 69
Connection of External Liquid Supplies.......................................................... 69
Electrical Connection of External Liquid Soap Supply System.......................... 70
External Wait Control....................................................................................70
Chemical Soap Supply System.............................................................. 71
Maintenance......................................................................................... 72
Maintenance.................................................................................................72
Daily........................................................................................................... 72
Beginning of Day...................................................................................... 72
End of Day............................................................................................... 72
Quarterly......................................................................................................74
Every 6 Months............................................................................................ 75
Emergency Unblocking of Door Lock.............................................................77
Care of Stainless Steel................................................................................... 77
Disposal of Unit.................................................................................... 78
Disconnecting the Machine............................................................................78
Disposal of Unit............................................................................................78
China Restriction of hazardous substances (RoHS)............................... 79
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
4 Part No. D2418ENR6

Safety Information
Explanation of Safety Instructions
Messages
Precautionary statements (“DANGER,” “WARNING,” and
“CAUTION”), followed by specific instructions, are found in this
manual and on machine decals. These precautions are intended
for the personal safety of the operator, user, servicer, and those
maintaining the machine.
DANGER
Indicates an imminently hazardous situation that, if
not avoided, will cause severe personal injury or
death.
WARNING
Indicates a hazardous situation that, if not avoided,
could cause severe personal injury or death.
CAUTION
Indicates a hazardous situation that, if not avoided,
may cause minor or moderate personal injury or
property damage.
Additional precautionary statements (“IMPORTANT” and
“NOTE”) are followed by specific instructions.
IMPORTANT: The word “IMPORTANT” is used to in-
form the reader of specific procedures where minor
machine damage will occur if the procedure is not fol-
lowed.
NOTE: The word “NOTE” is used to communicate in-
stallation, operation, maintenance or servicing informa-
tion that is important but not hazard related.
Safety Information
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
5 Part No. D2418ENR6

Important Safety Instructions
WARNING
Read all the instructions before using the ma-
chine. Safe these Instructions for future reference.
Electrical shock prevention
DANGER
Electrical shock hazard will result in death or serious
injury.
Before inspecting, maintenance or servicing ma-
chines, power supply must be turned OFF. The serv-
icer needs to wait for at least ten (10) minutes after
turning the power OFF.
This machine must be connected to a grounded met-
al, permanent wiring system, and an equipment
grounding conductor must be run with the supply
conductors and connected to the equipment ground-
ing terminal on the machine.
When the main switch is turned off, the inlet termi-
nals of the main switch are still under current.
The inverter remains charged with high voltage for
some time after powering OFF. Before starting in-
spection of the inverter, check for residual voltage
across main circuit terminals “ + “ and “ - “. This
voltage must be below 30 VDC before the servicer
can access the inverter for inspection.
Do NOT connect inverter manufacturer devices or
other devices to the frequency controller to manipu-
late the behavior. No modification to the settings are
allowed.
This is an imminently hazardous situation that, if not
avoided, will cause severe personal injury or death.
Installation – Maintenance prevention
WARNING
Machine installations must comply with minimum
specifications and requirements stated in the appli-
cable Installation Manual, any applicable municipal
building codes, water supply regulations, electrical
wiring regulations and any other relevant statutory
regulations. Due to varied requirements and applica-
ble local codes, this machine must be installed, ad-
justed, troubleshooting and serviced by qualified
maintenance technician which is familiar with the ap-
plicable local codes and the construction and opera-
tion of this type of machinery. They must also be fa-
miliar with the potential hazards involved. Failure to
observe this warning may result in personal injury
and/or property damage.
Always verify the static and dynamic requirements
with a building engineer to meet the requirements of
the permissible loads, vibrations and noise level of
the building.
Ensure and install the machine on a level floor of
sufficient strength. Ensure that the recommended
clearances for inspection and maintenance are pro-
vided. Never allow the inspection and maintenance
space to be blocked.
To reduce the risk of fire, this appliance must be in-
stalled and secured to an uncovered not obstructed
concrete floor.
If a forklift or a pallet truck is used to transport or in-
stall the machine, ensure that the carrying capacity
and the forks length are sufficient. By given center of
gravity, pay the necessary attention to the distribu-
tion of the center of gravity by lifting and transport.
In case the machine needs to be anchored, do not
tighten nuts of the anchoring bolts before the con-
crete base around the bolts is completely hardened.
The bolts must be tightened by means of torgue
wrench.
Do not install the machine over an open water stor-
age or drain system.
Adequate ventilation must be provided to avoid the
back flow of gases into the room from appliances
burning other fuels.
Safety Information
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
6 Part No. D2418ENR6

WARNING
ALWAYS disconnect the machine from Electrical
power, Water, Steam and all other connected sup-
plies during installation, before attempting any serv-
ice, replacing parts and maintenance.
If the machine is not equipped with means to isolate
them from all energy sources (e.g. water, electricity,
steam, compressed air), than such means must be
part of the fixed installation external to the machine.
Such isolators shall be clearly identified. They shall
be capable of being locked if reconnection could en-
danger persons.
After the energy source is disconnected, follow the
install procedure to safely, dissipate any remaining
or stored energy in the circuits of the machine.
Use machine only for its intended purpose, suitable
laundry textiles. Never wash/dry/iron something else
like polymers, machine parts, automotive parts or
other ferro materials in the machine. This could re-
sult in serious injury and machine damage.
In case the machine is provided with shipping bra-
ces, they must be removed prior to putting into serv-
ice. See Install instruction for safely remove them.
Sharp edges can cause personal injury. Wear safety
glasses and gloves, use proper tools and provide
lighting when handling sheet metal parts.
WARNING
Failure to do so may result in conditions which can
produce serious injury, death and/or property dam-
age.
WARNING
The washer is provided with Air vents wherefrom Va-
pors can escape! Do not connect or cover them!
Automatic door-lock unlocking devices must not be
utilized or installed on machines that are fitted with a
drain pump or reverse function drain valve.
The new hose sets supplied with the appliance are to
be used. Old hose sets should not be reused.
Electrical - Energy Prevention
WARNING
Machine must be hard-wired. Use copper conductors
only.
Refer to the Earthing (grounding) instructions in the
INSTALLATION manual for the proper grounding of
the machine. In event of malfunction, breakdown or
leakage current, grounding will reduce the risk of
electrical shock and serve as a protecting device by
providing a path of least resistance of electrical cur-
rent. Therefore, it is very important, and the respon-
sibility of the qualified installer to ensure the ma-
chine is adequately grounded at installation, follow-
ing all the national and local requirements.
If there are other washers or appliances with ex-
posed conductive parts, which can touch simultane-
ously, make sure to make equipotential bonding be-
tween all these appliances. The external protective
terminal for this purpose is located on the rear side
of the machine frame. The minimum protection con-
ductor's cross section depends on the supply cable
cross section of the appliance of the highest current
rating.
An individual branch circuit needs to be used for
each machine.
If the machine is not equipped with a supply mains
disconnecting device, means for disconnection all
poles must by incorporated in fixed wiring in accord-
ance with overvoltage category Ill conditions and the
relevant local wiring rules and must be located so
that it is easily accessible with the machine in place.
If disconnection is foreseen by means of a plug, it
must be placed and installed in such a way that an
operator can check from any of the points to which
he has access, that the plug remains removed. If this
is not possible, due to its installation, a disconnec-
tion with a locking system in the isolated position
shall be provided.
Dangerous voltages are present inside the machine.
Disconnect power from the machine before remov-
ing any cover and guards, and before attempting any
maintenance, troubleshooting or service procedures
or replacing parts.
To reduce the risk of an electric shock or fire, DO
NOT use an extension cord or an adapter to connect
the machine to the electrical power source.
The machine is not designed for use in IT networks.
Applicable measures need to be provided.
Safety Information
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
7 Part No. D2418ENR6

Use Limitation
WARNING
The machine cannot used by children aged under 8
years.
This appliance cannot be used by children aged from
8 and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge, unless they have been given super-
vision and instruction concerning use of the ma-
chine in a safe way and understand the hazard in-
volved, by a person responsible for their safety.
Children should be supervised to ensure that they
do not play on, in or with the machine. Close super-
vision of children is necessary when the machine is
used near children.
Cleaning and maintenance shall not be made by chil-
dren.
Operation Prevention
WARNING
Never operate the machine with any guards, panels
and/or parts removed or broken. Do NOT bypass any
safety devices or tamper with the controls.
Safety decals appear at crucial locations on the ma-
chine. Failure to maintain legible safety decals could
result in injury to the operator or service technician.
Use only authorized spare parts in the event of fail-
ure. Do not repair or replace any part of the machine
or attempt any servicing unless specifically recom-
mended in the user-maintenance instructions or in
published user-repair instructions that the user un-
derstands and has the skills to carry out.
If the supply cord is damaged, it must be replaced by
a qualified technician to avoid a hazard.
Never touch internal or external steam pipes, con-
nections, or components. These surfaces can be ex-
tremely hot and will cause severe burns. The steam
supply must be turned off and allow the pipe, con-
nections and components to cool before these can
be touched.
Avoid contact with hot inlet water temperatures high-
er than 125° Fahrenheit [51°C] or hot surfaces.
WARNING
Never interfere with the setting of the door handle.
Never try to modify the setting or repair the handle!
Any interference with its setting may lead to serious
risk for the operator! A damaged or incorrectly func-
tioning door handle must always be immediately re-
placed with a new original part by qualified person-
nel.
Loading door must be closed any time the machine
is operating.
Do NOT attempt to open the door until the machine
has drained and all moving parts have stopped. NEV-
ER insert hands or objects into basket until it has
completely stopped.
Do NOT bypass the door protections that prevent the
machine from operating with the loading door open.
Operating the washer with severe out-of-balance
loads could result in personal injury and serious
equipment damage.
Before using the emergency door opening function,
turn off the machine's main switch. Never open the
door while the basket is still running or if the ma-
chine parts feel too warm or if "Too hot" is indicated.
Always wait to open the door until there is no water
in the drum.
WARNING
If the washer is fitted with an automatic unlocking
device, to unlock the door after a power disconnect,
wait until the circuit unlocks the doorlock. Before
open the door makes sure that the basket is com-
pletely stopped and the water has drained.
Safety Information
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
8 Part No. D2418ENR6

Injury Prevention
WARNING
To reduce the risk of fire, electric shock, or in jury to
persons when using your machine, follow these pre-
cautions, including the following:
• Do not install or store the washer where it will be
exposed to water and/or weather conditions.
• To prevent fire and explosion, keep the area
around machine free from flammable and com-
bustible products. Do not add the following sub-
stances or textiles containing traces of the follow-
ing substances to the wash water: gasoline, kero-
sene, waxes, cooking oils, vegetable oils, ma-
chine oils, dry-cleaning solvents, flammable
chemicals, thinners, or other flammable or explo-
sive substances. These substances give off va-
pors that could ignite, explode or cause the fabric
to catch fire by itself.
• Under certain conditions, hydrogen gas may be
produced in a hot water system that has not been
used for two weeks or more. HYDROGEN GAS IS
EXPLOSIVE. If the hot water system has not been
used for such a period, before using a washing
machine or combination washer-dryer, turn on all
hot water faucets and let the water flow from each
for several minutes. This will release any accumu-
lated hydrogen gas. The gas is flammable, do not
smoke or use an open flame during this time.
• Use only low-sudsing, no-foaming types of deter-
gents. Be aware that hazardous chemicals may be
present. Wear hand and eye protection when han-
dling detergents and chemicals. Always read and
follow manufacturer's instructions on packages
of laundry and cleaning aids. Read all warnings or
precautions. To reduce the risk of poisoning or
chemical burns, always keep them out of the
reach of children [preferably in a locked cabinet].
WARNING
• Do not use fabric softeners or products to elimi-
nate static unless recommended by the manufac-
turer of the fabric softener product.
• Always follow the fabric care instructions sup-
plied by the textile manufacturer.
• If the machine is provided with a bath sample tap,
be careful by taking the sample to avoid injuries
by hot water or chemicals.
• Do not climb or stand on the washer, do not reach
or climb into the drum.
• Do not push, pull or press on the enclosure, its
corners or on protruding parts of the contour line
of the machine.
• Never put fingers between door sealing and drum
by manipulating or closing the door.
• Be aware that water is used to flush the supply
dispenser. Avoid opening the dispenser lid while
the machine is running.
• Do not attach anything to the supply dispenser's
nozzles, if applicable. The air gap and overflows
must be maintained.
WARNING
• Do not operate the machine without the water re-
use plug or water reuse system in place, if appli-
cable.
•Be sure that fill hose connections are tight.
CLOSE the shut-off valves at the end of each
wash day.
• Keep the washer in good condition. Bumping or
dropping the washer can damage safety features.
If this occurs, have the washer checked by a
qualified service person.
• Before the washer is removed from service or dis-
carded, remove the door from the tub assembly
and in case present, the washing compartment.
Secure door and glass to prevent breaking and in-
jury of by sharp edges.
• To avoid machine corrosion and component fail-
ure, do not use corrosive chemicals in the ma-
chine. The use of hypochlorite will cause corro-
sion which may cause component failure under
certain circumstances.
• Always contact your dealer, distributor, service
agent or the manufacturer on any problems or
conditions you do not understand.
Safety Information
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
9 Part No. D2418ENR6

Operation Prevention
CAUTION
Machines referred to by model in this manual are
NOT intended for domestic use by private consum-
ers in the home environment. Machines referred to
by model in this manual are intended to be used by
the general public in applications such as:
• Staff kitchen areas in shops, offices, kitchens and
other working environments
• Farmhouses, bed and breakfast type environ-
ments
• By clients in hotels, motels and other residential
type environments
• Areas for communal use in blocks of flats or in
launderettes
• any other similar applications
IMPORTANT: Models outside of North America : All ma-
chines are produced in according to the EU EMC direc-
tive (Electro-Magnetic-Compatibility). They can be used
in restricted surroundings only (comply minimally with
class A requirements). For safety reasons there must
be kept the necessary precaution distances with sensi-
tive electrical or electronic device(s).
IMPORTANT: The IMPORTANT SAFETY INSTRUC-
TIONS appearing in this manual are not meant to cover
all possible conditions and situations that may occur.
Observe and be aware of other labels and precautions
that are located on the machine. They are intended to
provide instructions for safe use of the machine. Com-
mon sense, caution and care must be exercised when
installing, maintaining, or operating the machine.
NOTE: If literature or replacement parts are required,
contact the source from which the machine was pur-
chased or contact Alliance Laundry Systems at +1
[phone] for the name and address of the nearest
authorized parts distributor.
NOTE: For technical assistance, contact your local dis-
tributor or contact:
Alliance Laundry Systems
Shepard Street
P.O. Box 990
Ripon, WI 54971-0990 U.S.A.
www.alliancelaundry.com
Phone: [phone]
Safety Information
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
10 Part No. D2418ENR6

Introduction
Model Identification
Information in this manual is applicable to these models:
EC – UK Declaration of Conformity
We, Alliance Laundry CE s.r.o., as manufacturer hereby declares on our own and sole responsibility, that the products to which this
document relates, is designed accordance and fulfils all the relevant provisions of the EU Directives and UK Regulations.
Manufacturer:
Alliance Laundry CE s.r.o.
Místecká 1116
742 58 Příbor
Czech Republic
Apparatus Product: Commercial Washing Machines with the following Model Numbers:
WF065B WR080B WR280BN
WF080B WR105B WR280B
WF105B WR135B WR330B
WF135B WR180BN WR520B
WF180B WR180B
WF240B WR240BN
WF280B WR240B
The object of the declaration described above is in conformity with the relevant EU Directives, UK Regulations, EU standards and
UK standards:
MD #2006/42/EC -- UK SoM (Safety) Regulations 2008
EN50571:2013
IEC60335-2-7:2008/A1:2011/A2:2016
Fulfil the safety objectives of the LVD 2014/35/EU and UK EE (Safety) Regulations 2016
EMC Directive #2014/30/EU -- UK EMC Regulations 2016
EN IEC61000-6-2:2005
EN61000-6-3:2007/A1:2011
IEC61000-6-3:2006/A1:2010
RED #2014/53/EU -- UK RE Regulations 2017
ETSI EN 300 328 V2.1.1
ETSI EN 301 489-17 Draft V3.2.0
ETSI EN 301-489-1 Draft V2.2.
RoHS Directive #2011/65/EU‐‐ UK RoHS Regulations 2012
EN IEC63000:2018
Technical file compiled by and retained at Alliance Laundry CE s.r.o. Místecká, 1116742 58, Příbor, Czech Republic and Alliance
Laundry Finance LTD, 1 Bartholomew Lane, London, England, EC2N 2AXUK.
Signed for and on behalf of:
Alliance Laundry CE s.r.o.
Místecká 1116
742 58 Příbor
Czech Republic
Radim Polednik, Quality Manager, 1/1/2023 CZW264N
Figure 1
Introduction
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
11 Part No. D2418ENR6

*Y(1)020V *Y(1)025V *Y(1)030V *Y(1)040V *Y(1)055V *Y(1)070V
*Y(1)065V *Y(1)080V *Y(1)105V *Y(1)135V *Y(1)180V *Y(1)240V *Y(1)280V
* = H; S; U
(1) = C; E; T; X; A; R; U; M
SY020_QUAN-
TUM_TOUCH_VEND
SYT020V SYE065V SYX280V
SY025_QUAN-
TUM_TOUCH_VEND
SYT025V SYE080V HY020_GAL-
AXY_TOUCH_VEND
SY030_QUAN-
TUM_TOUCH_VEND
SYT030V SYE105V HY025_GAL-
AXY_TOUCH_VEND
SY040_QUAN-
TUM_TOUCH_VEND
SYT040V SYE135V HY030_GAL-
AXY_TOUCH_VEND
SY055_QUAN-
TUM_TOUCH_VEND
SYT055V SYE180V HY040_GAL-
AXY_TOUCH_VEND
SY070_QUAN-
TUM_TOUCH_VEND
SYT070V SYE240V HY055_GAL-
AXY_TOUCH_VEND
SY65_QUAN-
TUM_TOUCH_VEND
SYC065V SYE280V HY070_GAL-
AXY_TOUCH_VEND
SY80_QUAN-
TUM_TOUCH_VEND
SYC080V SYX065V HYT020V
SY105_QUAN-
TUM_TOUCH_VEND
SYC105V SYX080V HYT025V
SY135_QUAN-
TUM_TOUCH_VEND
SYC135V SYX105V HYT030V
SY180_QUAN-
TUM_TOUCH_VEND
SYC180V SYX135V HYT040V
SY240_QUAN-
TUM_TOUCH_VEND
SYC240V SYX180V HYT055V
SY280_QUAN-
TUM_TOUCH_VEND
SYC280V SYX240V HYT070V
SY65_QUAN-
TUM_TOUCH_OPL
SYA065V SYR065V SYU065V
SY80_QUAN-
TUM_TOUCH_OPL
SYA080V SYR080V SYU080V
SY105_QUAN-
TUM_TOUCH_OPL
SYA105V SYR105V SYU105V
SY135_QUAN-
TUM_TOUCH_OPL
SYA135V SYR135V SYU135V
SY180_QUAN-
TUM_TOUCH_OPL
SYA180V SYR180V SYU180V
Table continues...
Introduction
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
12 Part No. D2418ENR6

SY240_QUAN-
TUM_TOUCH_OPL
SYA240V SYR240V SYU240V
SY280_QUAN-
TUM_TOUCH_OPL
SYA280V SYR280V SYU280V
UY65_PRO-
FORM_TOUCH_OPL
UYC065V UYC080V UYC105V
UY80_PRO-
FORM_TOUCH_OPL
UYC135V UYC180V UYC240V
UY105_PRO-
FORM_TOUCH_OPL
UYC280V UYE065V UYE080V
UY135_PRO-
FORM_TOUCH_OPL
UYE105V UYE135V UYE180V
UY180_PRO-
FORM_TOUCH_OPL
UYE240V UYE280V UYX065V
UY240_PRO-
FORM_TOUCH_OPL
UYX080V UYX105V UYX135V
UY280_PRO-
FORM_TOUCH_OPL
UYX180V UYX240V UYX280V
UYA065V UYA080V UYA105V UYA135V
UYA180V UYA240V UYA280V UYR065V
UYR080V UYR105V UYR135V UYR180V
UYR240V UYR280V UYU065V UYU080V
UYU105V UYU135V UYU180V UYU240V
UYU280V
Introduction
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
13 Part No. D2418ENR6

Regulatory Statements
PRODUCT COMPLIANCE
Users of this product are cautioned not to make modifications or
changes that are not approved by Alliance Laundry Systems,
LLC. Doing so may void the compliance of this product with ap-
plicable laws and regulatory requirements and may result in the
loss of the user’s authority to operate the equipment.
UNITED STATES
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions; (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause un-
desired operation.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. How-
ever, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful inter-
ference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following meas-
ures:
• Reorient or relocate the radio or television receiving antenna.
• Increase the separation between the computer equipment or
receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the radio or television receiver is connec-
ted.
• Consult the dealer or experienced radio television technician
for help.
CAUTION
To comply with the limits of the Class B device, pur-
suant to Part 15 of the FCC Rules, this device is to
comply with Class B limits. All peripherals must be
shielded and grounded. Operation with non-certified
peripherals or non-shielded cables is likely to result
in interference and reception of the device.
W1004
Radiation Exposure Statement : This equipment complies with
FCC radiation exposure limits set forth for an uncontrolled envi-
ronment. The radio installed in this equipment and is intended to
operate with minimum distance 20cm between the radiator and
your body.
Limited Channels Fixed For Use In USA : IEEE 802.11b or
802.11g or 802.11n(HT20) operation of this product in the U.S. is
firmware-limited to Channel 1 through 11.
CANADA - CAN ICES-3(B)/NMB-3(B)
This device contains license-exempt transmitter(s)/receiver(s)
that comply with Innovation, Science and Economic Develop-
ment Canada’s license-exempt RSS(s) standards. Operation is
subject to the following two conditions:
• This device may not cause interference.
• This device must accept any interference, including interfer-
ence that may cause undesired operation of the device.
Radiation Exposure Statement: This equipment complies with
Innovation, Science and Economic Development Canada’s radia-
tion exposure limits set forth for in RSS-102. The radio installed
in this equipment is installed and is intended to operate with min-
imum distance 20cm between the radiator and your body.
AUSTRALIA/NEW ZEALAND
The radio in this equipment complies with and is certified to the
Australian and New Zealand regulatory requirements.
BRAZIL ANATEL (Brazilian Portuguese)
This equipment operates in secondary status, that is, it is not enti-
tled to protection against harmful interference, even for type sta-
tions, and cannout cause interference to systems operating in pri-
mary status.
CHINA SRRC (Simplified Chinese)
The radio device has recieved certification of conformance in ac-
cordance with the People's Republic of China State Radio Regu-
lation Committee (SRRC) certification scheme. Integrations of
this radio into a final product does not require additional radio
certification provided installation instructions are followed. No
changes are authorized to the radio or the antenna of the ap-
proved device.
JAPAN
This product is equipped with a certified wireless device pursuant
to Article 2-1-19 of the Certification Ordinance. No changes are
authorized to the radio or the antenna of the approved device.
MEXICO IFETEL (Mexico Spanish)
“The operation of this equipment is subject to the following two
conditions: (1) it is possible that this equipment or device does
not cause harmful interference and (2) this equipment or device
must accept any interference, including that which may cause its
unwanted operation.”
SOUTH KOREA (KC) (Korean)
The radio device has received certification of conformance in ac-
cordance with the Radio Waves Act. Integration of this radio into
Introduction
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
14 Part No. D2418ENR6

a final product does not require additional radio certification pro-
vided installation instructions are followed. No changes are au-
thorized to the radio or the antenna of the approved device.
TAIWAN
The information in this section applies to products bearing the
Taiwan National Communications Commission mark:
This telecom equipment has complied with NCC regulations.
According to “Administrative Regulations of Low Power Radio
Waves Radiated Devices:
Article 12 The low-power radio-frequency devices must not be
altered by changing the frequency, enhancing emission power,
adding external antenna, and modification of original design
characteristic as well as function.
Article 14 The operation of the low-power radio-frequency devi-
ces is subject to the conditions that no harmful interference is
caused. The user must stop operating the device immediately
should harmful interference is caused and shall not resume until
the condition causing the harmful interference has been correc-
ted.
Moreover, the interference must be accepted that may be caused
by the operation of an authorized communications, or ISM equip-
ment. (1) Precautions (marked in the product manual and on out-
er packaging)
THAILAND
The information in this section applies to products approved by
the Thailand National Communications Commission:
These telecommunication and device are compliance with the re-
quirements of National Broadcasting and Telecommunication
Commission.
MIX4N_SVG
Figure 2
Introduction
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
15 Part No. D2418ENR6

Serial Plate Location
1. Serial Plate Location
Figure 3
The serial plate is located on the rear panel of the machine and on
the frame inside the machine.
Always provide the machine serial number when ordering parts
or when seeking technical assistance.
Manufacturing Date
The manufacturing date for your unit can be found on the serial
number. The last two characters indicate first the year and then
the month. Refer to Table 1 and Table 2 . For example, a unit with
serial number 520I000001DK was manufactured in May 2015.
Manufacturing Date - Year
Year Serial Number Character
2009 P
2010 R
2011 T
2012 V
2013 X
2014 B
2015 D
2016 F
2017 H
2018 K
2019 M
Table 1 continues...
Manufacturing Date - Year
Year Serial Number Character
2020 Q
2021 S
2022 U
2023 W
2024 Y
Table 1
Introduction
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
16 Part No. D2418ENR6

Manufacturing Date - Month
Month Serial Number Character
January A or B
February C or D
March E or F
April G or H
May J or K
June L or M
July N or Q
August P or S
September R or U
October T or W
November V or Y
December X or Z
Table 2
Delivery Inspection
Upon delivery, visually inspect crate, protective cover, and unit
for any visible shipping damage. If signs of possible damage are
evident, have the carrier note the condition on the shipping pa-
pers before the shipping receipt is signed, or advise the carrier of
the condition as soon as it is discovered.
Introduction
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
17 Part No. D2418ENR6

Specifications and Dimensions
General Specifications
Specifi-
cations
6.5 kg /
14 lb. /
65 L
Models
7.5 kg /
20 lb. /
75 L
Models
10.5 kg /
25 lb. /
105 L
Models
13.5 kg /
30 lb. /
135 L
Models
18 kg /
40 lb. /
180 L
Models
24 kg /
55 lb. /
240 L
Models
28 kg /
70 lb. /
280 L
Models
Capacity
Drum Ca-
pacity, lb.
[kg]
14 lb. [6.5
kg]
20 lb. [7.5
kg]
25 lb. [10.5
kg]
30 lb. [13.5
kg]
40 lb. [18 kg] 55 lb. [24 kg] 70 lb. [28 kg]
Overall Dimensions
Overall
width, in.
[mm]
27.95 [710] 27.95 [710] 31.29 [795] 31.29 [795] 38.18 [970] 38.18 [970] 38.18 [970]
Overall
height, in.
[mm]
44.69 [1135] 44.69 [1135] 49.02 [1245] 49.02 [1245] 56.30 [1430] 56.30 [1430] 56.30 [1430]
Overall
depth, in.
[mm]
28.74 [730] 30.71 [780] 30.91 [785] 36.81 [935] 37.80 [960] 43.11 [1095] 46.26 [1175]
Weight and Shipping Information
Net weight,
lbs. [kg]
375 [170] 408 [185] 463 [210] 563 [255] 838 [380] 948 [430] 1092 [495]
Shipping
weight, lbs.
[kg]
397 [180] 441 [200] 518 [235] 606 [275] 871 [395] 992 [450] 1135 [515]
Shipping di-
mensions
(WxDxH),
in. [mm]
29.53 x
33.01 x
49.80 [750 x
840 x 1265]
29.53 x
33.01 x
49.80 [750 x
840 x 1265]
32.87 x
33.01 x
53.75 [835 x
840 x 1365]
32.87 x
38.78 x
53.75 [835 x
985 x 1365]
40.35 x
39.96 x
61.81 [1025
x 1015 x
1570]
40.35 x
45.28 x
61.81 [1025
x 1150 x
1570]
40.35 x
48.23 x
61.81 [1025
x 1225 x
1570]
Wash Cylinder Information
Cylinder di-
ameter in.
[mm]
20.87 [530] 20.87 [530] 24.40 [620] 24.40 [620] 29.53 [750] 29.53 [750] 29.53 [750]
Table 3 continues...
Specifications and Dimensions
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
18 Part No. D2418ENR6

Specifi-
cations
6.5 kg /
14 lb. /
65 L
Models
7.5 kg /
20 lb. /
75 L
Models
10.5 kg /
25 lb. /
105 L
Models
13.5 kg /
30 lb. /
135 L
Models
18 kg /
40 lb. /
180 L
Models
24 kg /
55 lb. /
240 L
Models
28 kg /
70 lb. /
280 L
Models
Cylinder
depth in.
[mm]
12.01 [305] 13.78 [350] 13.78 [350] 17.72 [450] 16.14 [410] 21.46 [545] 24.41 [620]
Cylinder vol-
ume ft 3 [l]
2.3 [65] 2.65 [75] 3.71 [105] 4.77 [135] 6.36 [180] 8.48 [240] 9.9 [280]
Table 3 continues...
Specifications and Dimensions
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
19 Part No. D2418ENR6

Specifi-
cations
6.5 kg /
14 lb. /
65 L
Models
7.5 kg /
20 lb. /
75 L
Models
10.5 kg /
25 lb. /
105 L
Models
13.5 kg /
30 lb. /
135 L
Models
18 kg /
40 lb. /
180 L
Models
24 kg /
55 lb. /
240 L
Models
28 kg /
70 lb. /
280 L
Models
Door Opening Information
Door open-
ing size, in.
[mm]
13 [330] 13 [330] 16.14 [410] 16.14 [410] 18.11 [460] 18.11 [460] 18.11 [460]
Height of
door bottom
above floor,
in. [mm]
13.74 [349] 13.74 [349] 13.46 [342] 13.46 [342] 18.77 [477] 18.77 [477] 18.77 [477]
Drive Train Information
Number of
motors in
drive train
1111111
Motor Size,
hp [kW]
1 [0.75] 1 [0.75] 1.48 [1.1] 2.01 [1.5] 2.95 [2.20] 4.02 [3.0] 4.02 [3.0]
Cylinder Speeds
Wash, RPM 49 49 49 49 42 42 42
Extraction,
RPM (G)
1165 (400G) 1165 (400G) 1075 (400G) 1075 (400G) 980 (400G) 980 (400G) 915 (350G)
Extraction,
RPM (G)
1298 (500G) 1298 (500G) 1200 (500G) 1151 (460G) 1047 (460G) 1035 (450G) 975 (400G)
Heating
Electric, kW 6 / 9 (4.6) 6 / 9 (4.6) 6 / 9 / 12 9 / 12 12 / 18 18 21.9
Minimum
and Maxi-
mum Steam
pressure, PSI
[bar] [kPa]
15-116 [1-8]
[100-800]
15-116 [1-8]
[100-800]
15-116 [1-8]
[100-800]
15-116 [1-8]
[100-800]
15-116 [1-8]
[100-800]
15-116 [1-8]
[100-800]
15-116 [1-8]
[100-800]
Minimum
and Maxi-
mum Water
pressure, PSI
[bar] [kPa]
15-87 [1-6]
[100-600]
15-87 [1-6]
[100-600]
15-87 [1-6]
[100-600]
15-87 [1-6]
[100-600]
15-87 [1-6]
[100-600]
15-87 [1-6]
[100-600]
15-87 [1-6]
[100-600]
Hot water, °F
[°C]
185 [85] 185 [85] 185 [85] 185 [85] 185 [85] 185 [85] 185 [85]
Table 3 continues...
Specifications and Dimensions
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
20 Part No. D2418ENR6
