Alliance Laundry Systems EC001F User manual

Operation/Programming
www.comlaundry.com
Part No. F232088R3
January 2007
Washer-Extractors
Pocket Hardmount
Instructions for
Operating and Programming
the Mechanical Timer
UW35M2
UW60M2
EC001F
Para bajar una copia de estas instrucciones
en español, visite www.comlaundry.com.
Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.)

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
F232088
© Copyright 2007, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any
means without the expressed written consent of the publisher.
1
Table of
Contents
Safety Information.............................................................................. 3
Explanation of Safety Messages........................................................... 3
Important Safety Instructions ............................................................... 3
Safety Decals ........................................................................................ 6
Operator Safety..................................................................................... 7
Safe Operating Environment ................................................................ 7
Environmental Conditions ............................................................... 7
Machine Location ............................................................................ 8
Input and Output Services................................................................ 8
Operation............................................................................................. 11
Customer Service.................................................................................. 11
Machine Familiarization....................................................................... 12
Theory Of Operation............................................................................. 13
Display Indications ............................................................................... 14
Start-up ................................................................................................. 15
Opening Door ....................................................................................... 15
Loading ................................................................................................. 15
Supply Dispenser .................................................................................. 16
Cycle Selection ..................................................................................... 17
Cycle Execution.................................................................................... 18
Prewash ............................................................................................ 18
Wash ................................................................................................ 18
Rinse 1 ............................................................................................. 18
Rinse 2 ............................................................................................. 18
Rinse 3 ............................................................................................. 19
Programming ...................................................................................... 21
Setting the Jumpers............................................................................... 21
No Jumpers Installed on the Board.................................................. 22
1a to 3a............................................................................................. 22
1a to 3a to 3b.................................................................................... 22
1a to 3a to 3b to 5b........................................................................... 23
1a to 3a to 5a .................................................................................... 23
1a to 3a to 5a to 5b........................................................................... 23
1a to 3b............................................................................................. 23
1a to 3b to 5b.................................................................................... 23
1a to 5a............................................................................................. 23
1a to 5a to 5b.................................................................................... 23
1a to 5b............................................................................................. 23
2a to 2b............................................................................................. 24
10a to 10b......................................................................................... 24

2F232088
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Notes

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 3
F232088
Safety Information
Explanation of Safety Messages
Precautionary statements (“DANGER,” “WARNING,”
and “CAUTION”), followed by specific instructions,
are found in this manual and on machine decals. These
precautions are intended for the personal safety of the
operator, user, servicer, and those maintaining the
machine.
Additional precautionary statements (“IMPORTANT”
and “NOTE”) are followed by specific instructions.
IMPORTANT: The word “IMPORTANT” is used
to inform the reader of specific procedures where
minor machine damage will occur if the procedure
is not followed.
NOTE: The word “NOTE” is used to communicate
installation, operation, maintenance or servicing
information that is important but not hazard
related.
Important Safety Instructions
1. Read all instructions before using the washer.
2. Refer to the GROUNDING INSTRUCTIONS in
the INSTALLATION manual for the proper
grounding of the washer.
3. Do not wash textiles that have been previously
cleaned in, washed in, soaked in, or spotted with
gasoline, kerosene, waxes, cooking oils, dry-
cleaning solvents, or other flammable or
explosive substances as they give off vapors that
could ignite or explode.
4. Do not add gasoline, dry-cleaning solvents, or
other flammable or explosive substances to the
wash water. These substances give off vapors that
could ignite or explode.
5. Under certain conditions, hydrogen gas may be
produced in a hot water system that has not been
used for two weeks or more. HYDROGEN GAS
IS EXPLOSIVE. If the hot water system has not
been used for such a period, before using a
washing machine or combination washer-dryer,
turn on all hot water faucets and let the water
flow from each for several minutes. This will
release any accumulated hydrogen gas. The gas
is flammable, do not smoke or use an open flame
during this time.
6. Do not allow children to play on or in the washer.
Close supervision of children is necessary when
the washer is used near children. This is a safety
rule for all appliances.
7. Before the washer is removed from service or
discarded, remove the door to the washing
compartment.
8. Do not reach into the washer if the wash drum is
moving.
DANGER indicates the presence of a
hazard that will cause severe personal
injury, death, or substantial property
damage if the danger is ignored.
DANGER
WARNING indicates the presence of a
hazard that can cause severe personal
injury, death, or substantial property
damage if the warning is ignored.
WARNING
CAUTION indicates the presence of a
hazard that will or can cause minor
personal injury or property damage if the
caution is ignored.
CAUTION
To reduce the risk of fire, electric shock,
serious injury or death to persons when
using your washer, follow these basic
precautions:
W023
WARNING

Safety Information
F232088
4© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
9. Do not install or store the washer where it will be
exposed to water and/or weather.
10. Do not tamper with the controls.
11. Do not repair or replace any part of the washer, or
attempt any servicing unless specifically
recommended in the user-maintenance
instructions or in published user-repair
instructions that the user understands and has the
skills to carry out.
12. To reduce the risk of an electric shock or fire, DO
NOT use an extension cord or an adapter to
connect the washer to the electrical power
source.
13. Use washer only for its intended purpose,
washing textiles.
14. Never wash machine parts or automotive parts in
the machine. This could result in serious damage
to the basket.
15. ALWAYS disconnect the washer from electrical
supply before attempting any service. Disconnect
the power cord by grasping the plug, not the cord.
16. Install the washer according to the
INSTALLATION INSTRUCTIONS. All
connections for water, drain, electrical power and
grounding must comply with local codes and be
made by licensed personnel when required.
17. To reduce the risk of fire, textiles which have
traces of any flammable substances such as
vegetable oil, cooking oil, machine oil,
flammable chemicals, thinner, etc., or anything
containing wax or chemicals such as in mops and
cleaning cloths, must not be put into the washer.
These flammable substances may cause the
fabric to catch on fire by itself.
18. Do not use fabric softeners or products to
eliminate static unless recommended by the
manufacturer of the fabric softener or product.
19. Keep washer in good condition. Bumping or
dropping the washer can damage safety features.
If this occurs, have washer checked by a
qualified service person.
20. Replace worn power cords and/or loose plugs.
21. Be sure water connections have a shut-off valve
and that fill hose connections are tight. CLOSE
the shut-off valves at the end of each wash day.
22. Loading door MUST BE CLOSED any time the
washer is to fill, tumble or spin. DO NOT bypass
the loading door switch by permitting the washer
to operate with the loading door open.
23. Always read and follow manufacturer’s
instructions on packages of laundry and cleaning
aids. Heed all warnings or precautions. To reduce
the risk of poisoning or chemical burns, keep
them out of the reach of children at all times
(preferably in a locked cabinet).
24. Always follow the fabric care instructions
supplied by the textile manufacturer.
25. Never operate the washer with any guards and/or
panels removed.
26. DO NOT operate the washer with missing or
broken parts.
27. DO NOT bypass any safety devices.
28. Failure to install, maintain, and/or operate this
washer according to the manufacturer’s
instructions may result in conditions which can
produce bodily injury and/or property damage.
NOTE: The WARNINGS and IMPORTANT
SAFETY INSTRUCTIONS appearing in this
manual are not meant to cover all possible
conditions and situations that may occur. Common
sense, caution and care must be exercised when
installing, maintaining, or operating the washer.
Any problems or conditions not understood should be
reported to the dealer, distributor, service agent or the
manufacturer.

Safety Information
5
F232088 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
This machine must be installed, adjusted,
and serviced by qualified electrical
maintenance personnel familiar with the
construction and operation of this type of
machinery. They must also be familiar
with the potential hazards involved.
Failure to observe this warning may result
in personal injury and/or equipment
damage, and may void the warranty.
SW004
WARNING
Ensure that the machine is installed on a
level floor of sufficient strength and that
the recommended clearances for
inspection and maintenance are provided.
Never allow the inspection and
maintenance space to be blocked.
SW020
CAUTION
Be careful around the open door,
particularly when loading from a level
below the door. Impact with door edges
can cause personal injury.
SW025
CAUTION
Never touch internal or external steam
pipes, connections, or components.
These surfaces can be extremely hot and
will cause severe burns. The steam must
be turned off and the pipe, connections,
and components allowed to cool before
the pipe can be touched.
SW014
WARNING

Safety Information
F232088
6© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Decals
Safety decals appear at crucial locations on the
machine. Failure to maintain legible safety decals
could result in injury to the operator or service
technician.
To provide personal safety and keep the machine in
proper working order, follow all maintenance and
safety procedures presented in this manual. If
questions regarding safety arise, contact the
manufacturer immediately.
Use manufacturer-authorized spare parts to avoid
safety hazards.

Safety Information
7
F232088 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Operator Safety
To ensure the safety of machine operators, the
following maintenance checks must be performed
daily:
1. Prior to operating the machine, verify that all
warning signs are present and legible. Missing or
illegible signs must be replaced immediately.
Make certain that spares are available.
2. Check door interlock before starting operation of
the machine:
a. Attempt to start the machine with the door
open. The machine should not start with the
door open.
b. Close the door without locking it and attempt
to start the machine. The machine should not
start with the door unlocked.
c. Close and lock the door and start a cycle.
Attempt to open the door while the cycle is in
progress. The door should not open.
If the door lock and interlock are not functioning
properly, call a service technician.
3. Do not attempt to operate the machine if any of
the following conditions are present:
a. The door does not remain securely locked
during the entire cycle.
b. Excessively high water level is evident.
c. Machine is not connected to a properly
grounded circuit.
Do not bypass any safety devices in the machine.
Safe Operating Environment
Safe operation requires an appropriate operating
environment for both the operator and the machine. If
questions regarding safety arise, contact the
manufacturer immediately.
Environmental Conditions
●Ambient Temperature. Water in the machine will
freeze at temperatures of 32°F (0°C) or below.
●Temperatures above 120°F (50°C) will result in
more frequent motor overheating and, in some
cases, malfunction or premature damage to solid
state devices that are used in some models.
Special cooling devices may be necessary.
●Water pressure switches are affected by increases
and decreases in temperature. Every 25°F (10°C)
change in temperature will have a 1% effect on
the water level.
●Humidity. Relative humidity above 90% may
cause the machine’s electronics or motors to
malfunction or may trip the ground fault
interrupter. Corrosion problems may occur on
some metal components in the machine.
●If the relative humidity is below 30%, belts and
rubber hoses may eventually develop dry rot.
This condition can result in hose leaks, which
may cause safety hazards external to the machine
in conjunction with adjacent electrical
equipment.
●Ventilation. The need for make-up air openings
for such laundry room accessories as dryers,
ironers, water heaters, etc., must be evaluated
periodically. Louvers, screens, or other
separating devices may reduce the available air
opening significantly.
●Radio Frequency Emissions. A filter is available
for machines in installations where floor space is
shared with equipment sensitive to radio
frequency emissions.
●Elevation. If the machine is to be operated at
elevations of over 3280 feet (1000 m) above sea
level, pay special attention to water levels and
electronic settings (particularly temperature) or
desired results may not be achieved.
●Chemicals. Keep stainless steel surfaces free of
chemical residues.
NEVER insert hands or objects into
basket until it has completely stopped.
Doing so could result in serious injury.
SW012
WARNING
Never operate the machine with a
bypassed or disconnected balance
system. Operating the machine with
severe out-of-balance loads could result
in personal injury and serious equipment
damage.
SW039
WARNING

Safety Information
F232088
8© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
●Water Damage. Do not spray the machine with
water. Short circuiting and serious damage may
result. Repair immediately all seepage due to
worn or damaged gaskets, etc.
Machine Location
●Foundation. The concrete floor must be of
sufficient strength and thickness to handle the
floor loads generated by the high extract speeds
of the machine.
●Service/Maintenance Space. Provide sufficient
space to allow comfortable performance of
service procedures and routine preventive
maintenance.
Consult installation instructions for specific details.
Input and Output Services
●Wat er Pressure. Best performance will be
realized if water is provided at a pressure of 30 –
85 psi (2.0 – 5.7 bar). Although the machine will
function properly at lower pressure, increased fill
times will occur. Water pressure higher than 100
psi (6.7 bar) may result in damage to machine
plumbing. Component failure(s) and personal
injury could result.
●Steam Heat (Optional) Pressure. Best
performance will be realized if steam is provided
at a pressure of 30 – 80 psi (2.0 – 5.4 bar). Steam
pressure higher than 125 psi (8.5 bar) may result
in damage to steam components and may cause
personal injury.
●For machines equipped with optional steam heat,
install piping in accordance with approved
commercial steam practices. Failure to install the
supplied steam filter may void the warranty.
●Drainage System. Provide drain lines or troughs
large enough to accommodate the total number of
gallons that could be dumped if all machines on
the site drained at the same time from the highest
attainable level. If troughs are used, they should
be covered to support light foot traffic.
●Power. For personal safety and for proper
operation, the machine must be grounded in
accordance with state and local codes. The
ground connection must be to a proven earth
ground, not to conduit or water pipes. Do not use
fuses in place of the circuit breaker. An easy-
access cutoff switch should also be provided.
Always disconnect power and water supplies before a
service technician performs any service procedure.
Where applicable, steam and/or compressed air
supplies should also be disconnected before service is
performed.
Do not place volatile or flammable fluids
in any machine. Do not clean the machine
with volatile or flammable fluids such as
acetone, lacquer thinners, enamel
reducers, carbon tetrachloride, gasoline,
benzene, naptha, etc. Doing so could
result in serious personal injury and/or
damage to the machine.
SW002
DANGER
Replace all panels that are removed to
perform service and maintenance
procedures. Do not operate the machine
with missing guards or with broken or
missing parts. Do not bypass any safety
devices.
SW019
CAUTION
Ensure that a ground wire from a proven
earth ground is connected to the ground
lug near the input power block on this
machine. Without proper grounding,
personal injury from electric shock could
occur and machine malfunctions may be
evident.
SW008
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 9
F232088
Operation
This manual is designed as a guide to operating and
programming the UW35 and UW60 rigid-mount
washer-extractor equipped with the mechanical timer
control.
The manuals, installation instructions, and wiring
diagrams which accompany the machine have been
included with the machine at no charge. Additional
copies are available at a nominal charge.
NOTE: Read this manual thoroughly before
attempting to operate the machine.
NOTE: Do not use this manual in conjunction with
earlier model UW machines. Do not use technical
literature intended for earlier models when
operating this machine.
NOTE: All information, illustrations, and
specifications contained in this manual are based
on the latest product information available at the
time of printing. We reserve the right to make
changes at any time without notice.
Customer Service
If literature or replacement parts are required, contact
the source from whom the machine was purchased or
contact Alliance Laundry Systems LLC at
[phone] for the name and address of the
nearest authorized parts distributor.
For technical assistance, call [phone]
Ripon, Wisconsin.
A record of each machine is on file with the
manufacturer. Always provide the machine’s serial
number and model number when ordering parts or
when seeking technical assistance.

Operation
F232088
10 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Machine Familiarization
The machine familiarization guide in Figure 1
identifies major operational features of the UW
washer-extractor.
Figure 1
Shell Front
Door Hinge
Control Module Supply Dispenser
Door Latch Handle
Door Handle
Door Box
Door Latch
Side Panel
Door Latch
Extension Arm
Supply Valve Box
Rub Rail
FA001G

Operation
11
F232088 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Theory Of Operation
The design of the machine emphasizes performance
reliability and long service life. The cylinder, shell,
and main body panels are fabricated of stainless steel.
Electrical controls for the machine are housed in a
separate enclosure located on the top of the machine.
Removing the screws from the module cover, lifting
the cover, and pulling to the rear provides access to the
control module. This module contains the mechanical
timer, contactors, water-level switch, and other control
components.
All models use one 2-speed motor to drive the cylinder
via a V-belt drive in both speeds.The cylinder is
supported via the shaft by two bearings. The UW35
uses two ball bearings held in place by a single cast-
iron housing that is bolted to the A-frame. The UW60
uses two flange-mounted, spherical roller bearings
bolted to the A-frame.
The cylinder is constructed with lifters or ribs that lift
the laundry from the bath solution when the cylinder
rotates at slow speed and then allow the laundry to
tumble back into the bath. This mechanical action
accomplishes the washing function. The cylinder is
perforated, allowing the water to drain from within
during the wash and extract steps.
On the UW60, a balance switch is installed between
the faces of the A-frame to signal the controls to slow
the machine when a severely out-of-balance load
occurs during extract.
Water enters the machine through electromechanical
water valves controlled by the mechanical timer. The
mechanical timer also controls the drain and door lock.
In addition, the timer selects the water levels according
to the selected cycle. A vacuum breaker is installed in
the water-inlet plumbing to prevent backflow of water.
The standard production UW 2-speed model uses a
single drain valve. (A dual drain is available as an
option.) The drain valve is normally open, which
means that it closes only when power is applied, thus
allowing the machine to drain in the event of a power
failure.
A door-lock system prevents opening of the stainless
steel door when a cycle is in progress. It also prevents
operation of the machine when the door is open. The
doorbox contains the door-lock microswitch, door-
closed magnetic switch, and the door-unlock solenoid.
The UW35 shaft seal assembly includes two lip seals
integrated into the cast-iron bearing housing. Each seal
has two lips which make contact with a polished
stainless steel bushing mounted to the shaft.
The UW60 shaft seal assembly includes a brass collar
held in place on the cylinder shaft with set screws. The
collar has a flange with a ceramic ring which makes
contact with a spring-loaded phenolic face seal
enclosed in a nylon housing mounted on the rear of the
shell. The collar contains two internal O rings which
maintain contact with the cylinder shaft.
The polypropylene supply dispenser is mounted on the
right side of the washer-extractor, viewed from the
front. The dispenser has 5 supply compartments,
numbered 1–5, starting from the rear of the machine.
The compartments hold plastic supply cups that are
used for for either liquid or dry supplies. A nozzle
flushes supplies from the cups with water at the
appropriate time in the cycle.
Liquid supplies can be injected directly into the cups
by a customer-supplied external chemical supply
system. Five hose strain reliefs on top of the supply
dispenser facilitate connection to an external supply
system. A terminal strip inside a compartment
attached to the left side of the control module, viewed
from the rear of the washer-extractor, provides
connection points for external supply signals.

Operation
F232088
12 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Display Indications
Figure 2 shows the control panel for mechanical timer-
controlled machines.
The red light labeled “ON” on the control panel
illuminates when a cycle is started and will stay
illuminated until the completion of the cycle.
The amber light labeled “BLEACH” on the control
module illuminates at the beginning of the wash step,
once water level is reached (and cycle temperature has
been reached on auxiliary heat models). This indicates
when the machine is flushing supply dispenser
compartment 3.
The amber light labeled “WASH” on the control
module illuminates during fill, heat, and agitation
steps.
The amber light labeled “SOFTENER” on the control
module illuminates at the beginning of the third rinse
step. This indicates when the machine is flushing
supply dispenser compartments 4 and 5.
The cycle indicator dial on the control module displays
the current cycle step.
The depressed push button on the cycle selector switch
indicates the currently selected cycle.
Figure 2
EC001F

Operation
13
F232088 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Start-up
Switch the ON/OFF rocker switch on the control
module to the ON position.
Opening Door
Use left hand to press and hold the door unlock button
located on the lower right front of the control panel.
Use right hand to turn door handle clockwise and
swing the door left to open. See Figure 3.
Figure 3
The door will not open if the timer pointer is not in the
vertical position at the top of the dial. If the pointer is
not vertical, the timer must be rapid-advanced until the
timer pointer is in the vertical position. The rapid-
advance procedure is as follows:
1. Press and hold the START button. The timer will
begin rapid-advancing through the cycle.
2. Release the START button when the timer stops
advancing.
3. Wait one minute.
4. The door unlock button will be enabled, allowing
the door to be opened.
Loading
Load the machine to full capacity whenever possible,
but do not exceed the rated dry-weight capacity of the
machine if the fabric to be washed is quite dense,
closely woven, and heavily soiled. Overloading can
result in an inferior wash. The operator may need to
experiment to determine load size based on fabric
content, soil content, and level of cleanliness required.
Partial loads are a waste of energy, water, and
chemicals, and cause greater machine wear than full
loads. Partial loads also increase the possibility of a
severe out-of-balance condition.
When loading is complete, ensure that all fabric is
inside the basket. Then close and lock the door. The
machine should not start or run unless the door is both
closed and locked.
NOTE: When washing items which may
disintegrate or fragment, such as mop heads or
sponges, use laundry nets to prevent drain
blockage.
MD004J
Be careful around the open door,
particularly when loading from a level
below the door. Impact with door edges
can cause personal injury.
SW025
CAUTION
Never operate the machine with a
bypassed or disconnected out-of-balance
switch. Operating the machine with
severe out-of-balance loads could result
in personal injury and serious equipment
damage.
SW010
WARNING
Check the door safety interlock daily
before the machine is placed in operation.
SW024
CAUTION

Operation
F232088
14 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Supply Dispenser
Dry supplies are placed in the supply dispenser
compartment cups prior to the start of each cycle.
Liquid supplies can be injected directly into the supply
dispenser by an external chemical supply system.
NOTE: Supply dispenser compartment cups
should not be removed when an external chemical
injection supply system is attached to the washer-
extractor.
The supply system flushes at preset times in the wash
cycle. Refer to the following tables for more details.
Supply Dispenser Flush Times
Compartment Time
1 Prewash and Wash Fill
2 Wash Fill
3WashAfterFill
4 Rinse 3 Fill
5 Rinse 3 Fill
Supply Signal Output Times
Output Time
1 Prewash and Wash Fill
2WashFill
3 Wash After Fill
4 Rinse 3 Fill
5 Rinse 3 Fill

Operation
15
F232088 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Cycle Selection
The push button cycle selector switch on the control
module provides a selection of four complete
automatic cycles. See the table below for more
information.
Press the START button to start the selected cycle.
Mechanical Timer Cycles
Step Time
(Min)* Water Level
Program Water Temperature
White Permanent
Press Colors Bright Colors
Prewash 2High Warm Warm Cold Cold**
Drain 1
Auxiliary Heat Wash Step Temperature † 194 °F / 90 °C 140 °F / 60 °C 104 °F / 40 °C 86 °F / 30 °C
Wash 4
Low Hot Warm Warm Cold
Drain 1
Extract 0.5
Rinse 1 1.5
High Cold Cold Cold Cold
Drain 1
Extract 0.5
Rinse 2 1.5
High Cold Cold Cold Cold
Drain 1
Extract 0.5
Rinse 3 1.5
High Cold Cold Cold Cold
Drain 1
Extract 4
Shakeout 0.5
*Cycle times are for the factory-preset jumper configuration and do not include fill and heat times. See the Programming
section for more information.
**Auxiliary heat-equipped models only. Standard models do not have a prewash step in the Bright Colors cycle.
†Auxiliary heat-equipped models only.

Operation
F232088
16 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Cycle Execution
NOTE: The following description is for the factory-
preset program. Prewash times, wash times, final
extract times, fill levels, and water temperatures
may vary depending on jumper configuration. See
the Programming section for more details.
The program timer advances one step every thirty
seconds, except during fills.
Prewash
After the START button has been pressed, the door
unlock button is disabled, the drain valve closes, the
red “ON” indicator light illuminates, and the water
inlet valve(s) opens to fill the machine with water to
high level.
The door unlock button will remain disabled and the
red “ON” indicator light will remain illuminated for
the duration of the cycle.
The cylinder rotates clockwise at wash speed during
each fill.
The amber indicator light labeled “WASH” illuminates
during fill, heat, and agitation steps.
External chemical supply signal output 1 energizes
and supply dispenser compartment 1 flushes
throughout the duration of this fill.
When high water level is reached, the water valve(s)
closes and the washing action begins.
Standard washing action is as follows: 12 seconds
rotation clockwise at wash speed, a
3-second pause, then 12 seconds rotation
counterclockwise at wash speed.
The Bright Colors cycle uses a gentle washing action:
3 seconds rotation clockwise at wash speed, a 12-
second pause, then 3 seconds rotation
counterclockwise at wash speed.
After two minutes of washing action, the drain valve
opens.
Wash
After the machine has drained, the drain valve closes
and the water inlet valve(s) opens to fill the machine
with water to low level.
External chemical supply signal output 2 energizes
and supply dispenser compartment 2 flushes
throughout the duration of this fill.
External chemical supply signal output 1 energizes
and supply dispenser compartment 1 flushes
throughout the duration of this fill.
On standard models, the amber indicator light labeled
“BLEACH” illuminates after water level is reached
and remains illuminated for 1 minute. The machine
resumes the washing action once low water level is
reached. External chemical supply signal output 3
energizes and supply dispenser compartment 3 flushes
once low water level is reached.
On models equipped with auxiliary heat, the timer will
stop and the heating system will activate once the
water level is reached. The timer will resume once
cycle temperature is achieved, illuminating the amber
indicator light labeled “BLEACH,” energizing external
chemical supply signal output 3, and flushing supply
dispenser compartment 3 for 1 minute.
When the wash step is completed, the drain valve
opens. After the machine has drained, the machine
performs a 30-second intermediate extract.
Rinse 1
After the intermediate extract step, the machine closes
the drain valve and opens the cold water inlet valve to
fill the machine to high level.
Once high level is reached, the washing action
resumes for 90 seconds.
The drain then opens. After the machine has drained,
the machine performs a 30-second intermediate
extract.
Rinse 2
Rinse 2 is identical to rinse 1.

Operation
17
F232088 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Rinse 3
After the second intermediate extract, the machine
closes the drain valve and opens the cold water inlet
valve to fill the machine to high level.
The amber indicator light labeled “SOFTENER”
illuminates at the beginning of the fill, and remains
illuminated for 1 minute.
External chemical supply signal outputs 4 and 5
energize, and supply dispenser compartments 4 and 5
flush for 1 minute during this fill.
Once high level is reached, the washing action
resumes for 90 seconds.
The drain then opens. Once the machine has drained,
the machine performs a four-minute final extract.
A 30-second shakeout is then executed, completing the
cycle.
A 30-second delay is in effect after the “ON” light
goes off before the door unlock button is enabled.
NEVER insert hands or objects into
basket until it has completely stopped.
Doing so could result in serious injury.
SW012
WARNING
