Alliance Laundry Systems HD60 User manual

Programming
www.alliancelaundry.com
CFD583N
ECO
4
...
5
4
3
2
130°
40°
60°
30° 90°
3
2
1
ll
l
N
o
Washer-Extractor
Cygnus Standard OPL Control
Refer to Page 4 for Model Numbers
Part No. D1347ENR3
December 2013
Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.)

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
D1347ENR3 1
NOTE: The WARNING and IMPORTANT
instructions appearing in this manual are not meant
to cover all possible conditions and situations that
may occur. It must be understood that common
sense, caution, and carefulness are factors which
cannot be built into these washer-extractors. These
factors MUST BE supplied by the person(s)
installing, maintaining, or operating the washer-
extractor.
Always contact the distributor, service agent, or
the manufacturer about any problems or
conditions you do not understand.
Failure to install, maintain, and/or operate
this machine according to the
manufacturer's instructions may result in
conditions which can produce bodily injury
and/or property damage.
W030
WARNING

© Copyright 2013, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any
means without the expressed written consent of the publisher.
2D1347ENR3
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Table of
Contents
Model Identification ........................................................................... 4
Preliminary Information.................................................................... 5
About the Control ................................................................................. 5
Glossary of Terms................................................................................. 5
Power Failure Recovery ....................................................................... 5
Communications ................................................................................... 5
Control Identification......................................................................... 6
Display Identification ......................................................................... 7
LED Status Lights................................................................................. 7
Special Features .................................................................................. 8
Viewing Control Information ............................................................... 8
Testing Machine Components .............................................................. 8
Rapid Advance Feature......................................................................... 8
Communication Mode .......................................................................... 8
Washer-Extractor Operation ............................................................ 9
Start Up................................................................................................. 9
Start Mode ............................................................................................ 9
Run Mode ............................................................................................. 9
Stop Mode............................................................................................. 9
End of Cycle Mode............................................................................... 9
The Non-Active Menu ........................................................................ 10
What is Available in the Non-Active Menu? ....................................... 10
Entering the Non-Active Menu ............................................................ 10
Non-Active Menu Navigation .............................................................. 10
Non-Active Menu Options ................................................................... 11
Non-Active Menu Flowchart ....................................................... 12
1. Information Sub-Menu “LQIR”.................................................... 13
Information Sub-Menu Flowchart ............................................... 14
2. Test Sub-Menu “W(6W” (1 of 4)................................................... 15
Test Sub-Menu Flowchart (1 of 4)............................................... 16
2. Test Sub-Menu “W(6W” (2 of 4)................................................... 17
Test Sub-Menu Flowchart (2 of 4)............................................... 18
2. Test Sub-Menu “W(6W” (3 of 4)................................................... 19
Test Sub-Menu Flowchart (3 of 4)............................................... 20
2. Test Sub-Menu “W(6W” (4 of 4)................................................... 21
Test Sub-Menu Flowchart (4 of 4)............................................... 22
3. Entry Code Set Sub-Menu “FRG( 6(W”...................................... 23
Entry Code Set Sub-Menu Flowchart .......................................... 24
4. Clock Set Sub-Menu “F/RF 6(W”............................................. 25
Clock Set Sub-Menu Flowchart................................................... 26
5. Network Address Sub-Menu “QHWDGGUHVV”............................ 27
Network Address Sub-Menu Flowchart ...................................... 28
6. Rapid Advance Enable Sub-Menu “$GX$QF( (Q$E/(G”........... 29
Rapid Advance Enable Sub-Menu Flowchart.............................. 30
7. Temperature Indication Enable Sub-Menu “W( 3 (Q$E/(G” .... 31
Temperature Indication Enable Sub-Menu Flowchart................. 32
8. MMC Sub-Menu “ &” (1 of 3).................................................. 33
MMC Sub-Menu Flowchart (1 of 3)............................................ 34
8. MMC Sub-Menu “ &” (2 of 3).................................................. 35
MMC Sub-Menu Flowchart (2 of 3)............................................ 36
\
X
X
X
X
X

D1347ENR3 3
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
8. MMC Sub-Menu “ &” (3 of 3).................................................. 37
MMC Sub-Menu Flowchart (3 of 3)............................................ 38
9. Service Counters Sub-Menu “6HUXLFH FRYQW(UV” .................. 39
Service Counters Sub-Menu Flowchart ....................................... 40
10. Weekly Cycle Count Sub-Menu “Z(( /\ FRYQW(UV” .............. 41
Weekly Cycle Count Sub-Menu Flowchart................................. 42
11. Last Errors Sub-Menu “/$6W (UURU6” ...................................... 43
Last Errors Sub-Menu Flowchart................................................. 44
12. Out of Order Sub-Menu “RYW R) RUG(U” ................................. 45
Out of Order Sub-Menu Flowchart.............................................. 46
13. SmartWave Sub-Menu “6PDUW:DYH” ......................................... 47
SmartWave Sub-Menu Flowchart................................................ 48
Cycle Charts ........................................................................................ 49
Error Messages ................................................................................... 54
Error Messages ..................................................................................... 54
Events ................................................................................................... 57
Rapid Advance Feature...................................................................... 58
Communication Mode ........................................................................ 59
Infra-red Communications.................................................................... 59
X
X
\

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
4D1347ENR3
Model Identification
Information in this manual is applicable to these
washer-extractor models:
HD60_CYGNUS-STANDARD
HD65_CYGNUS-STANDARD
HD75_CYGNUS-STANDARD-
HD100_CYGNUS-STANDARD
HD135_CYGNUS-STANDARD
HD165_CYGNUS-STANDARD-
HD195_CYGNUS-STANDARD
HD235_CYGNUS-STANDARD
HD305_CYGNUS-STANDARD
IHA065C
IHA075C
IHA100C
IHA135C
IHA150C
IHA165C
IHA185C
IHA195C
IHA235C
IHA305C
IHA400C
IHG065C
IHG075C
IHG100C
IHG135C
IHG150C
IHG165C
IHG185C
IHG235C
IHG305C
IHG400C
IHN065C
IHN075C
IHN100C
IHN135C
IHN150C
IHN165C
IHN185C
IHN235C
IHN305C
IHN400C
IHU065C
IHU075C
IHU100C
IHU135C
IHU150C
IHU165C
IHU185C
IHU235C
IHU305C
IHU400C
IHW065C
IHW075C
IHW100C
IHW135C
IHW150C
IHW165C
IHW185C
IHW235C
IHW305C
IHW400C
IHY014C
IHY018C
IHY025C
IHY030C
IHY033C
IHY035C
IHY040C
IHY045C
IHY055C
IHY075C
IHY090C
IHZ065C
IHZ075C
IHZ100C
IHZ135C
IHZ150C
IHZ165C
IHZ185C
IHZ235C
IHZ305C
IHZ400C
IXA060C
IXA065C
IXA075C
IXA100C
IXA135C
IXA165C
IXA195C
IXA235C
IXA305C
IXG060C
IXG065C
IXG075C
IXG100C
IXG135C
IXG165C
IXG195C
IXG235C
IXG305C
IXN060C
IXN065C
IXN075C
IXN100C
IXN135C
IXN165C
IXN195C
IXN235C
IXN305C
IXU060C
IXU065C
IXU075C
IXU100C
IXU135C
IXU165C
IXU195C
IXU235C
IXU305C
IXW060C
IXW065C
IXW075C
IXW100C
IXW135C
IXW165C
IXW195C
IXW235C
IXW305C
IXY012C
IXY014C
IXY018C
IXY025C
IXY030C
IXY035C
IXY045C
IXY055C
IXY075C
IXZ060C
IXZ065C
IXZ075C
IXZ100C
IXZ135C
IXZ165C
IXZ195C
IXZ235C
IXZ305C
WD65_CYGNUS-STANDARD
WD75_CYGNUS-STANDARD
WD100_CYGNUS- STANDARD
WD135_CYGNUS-STANDARD
WD150_CYGNUS-STANDARD
WD165_CYGNUS-STANDARD
WD185_CYGNUS-STANDARD
WD235_CYGNUS-STANDARD
WD305_CYGNUS-STANDARD
WD400_CYGNUS-STANDARD
YHG065C
YHG075C
YHG100C
YHG135C
YHG150C
YHG165C
YHG185C
YHG235C
YHG305C
YHG400C
YHG065C
YHG075C
YHG100C
YHG135C
YHG150C
YHG165C
YHG185C
YHG235C
YHG305C
YHG400C

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 5
D1347ENR3
Preliminary Information
About the Control
This control is an advanced, programmable computer
that lets the owner control machine features by
pressing a sequence of keypads. Refer to Figure 1.
The control allows the owner to obtain information
from the machine, run test cycles, modify the control’s
programmable features, set the service counters and
view the error code history. Refer to The Non-Active
Menu section for a list of features.
IMPORTANT: In the event of a power failure, the
control will not have to be reprogrammed. It is
designed with a memory system that will remember
how it was programmed until the electrical power
is restored.
IMPORTANT: It is extremely important that the
washer-extractor has a good ground connection and
that all mechanical and electrical connections to the
control are made before applying power to or
operating the washer-extractor.
Glossary of Terms
The following are a few terms and abbreviations to
learn. These are referred to throughout the
instructions.
Display – This term refers to the window area of the
control that displays words and values.
LED (Light Emitting Diode) – This term refers to the
lights next to the keypads and status words of
the control.
Power Failure Recovery
If a cycle is in progress and the power fails, the water
will be drained from the machine and the door can be
opened after approximately 3 minutes. If the door is
not opened and the power failure is not longer than 2
weeks, the washer-extractor will resume the
previously active cycle.
If the door is opened or if the length of the power
failure is longer than 2 weeks, the control will end the
cycle and the display will revert back to Start Mode.
Communications
The control may be programmed manually or by infra-
red communication with an external device. (PC)
Infra-red Communications
A PC allows the owner to program and retrieve
information from the control without using the
machine’s keypad, which greatly expands the
programming options available to the owner. However,
it is not required to program and operate the washer-
extractor. The operation of a PC and the advanced
features available are covered separately in the
instructions included with the PC programming
software, Cygnus Assist. (Cygnus Std. can only be
programmed by a PC, not manually.)

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
6D1347ENR3
Control Identification
CFD583N
1Cycle Numbers, Water Temperature and 4Start/Stop Keypad
Cycle Time Display 5Optical Download Window
2Program Number Keypads 6Cycle’s Segments and Steps
3ECO Keypad
Figure 1
CFD583N
ECO
4
...
5
4
3
2
1
30°
40°
60°
30° 90°
3
2
1
ll
l
No
1
3
4
5
2
6

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 7
D1347ENR3
Display Identification
LED Status Lights
(Refer to Figure 1)
LED Status Lights are used to indicate the cycle status.
See below for information on each LED.
PREWASH LED
The Prewash LED is lit at the beginning of the
prewash portion of the cycle and will remain lit until
the prewash is complete.
WASH LED
The Wash LED is lit at the beginning of the wash
portion of the cycle and will remain lit until the wash
is complete.
RINSE 1 LED
The Rinse 1 LED is lit at the beginning of the rinse 1
portion of the cycle and will remain lit until the rinse 1
is complete.
RINSE 2 LED
The Rinse 2 LED is lit at the beginning of the rinse 2
portion of the cycle and will remain lit until the rinse 2
is complete.
RINSE 3 LED
The Rinse 3 LED is lit at the beginning of the rinse 3
portion of the cycle and will remain lit until the rinse 3
is complete.
RINSE 4 LED
The Rinse 4 LED is lit at the beginning of the rinse 4
portion of the cycle and will remain lit until the rinse 4
is complete.
SPIN LED
The Spin LED is lit at the beginning of the spin
portion of the cycle and will remain lit until the spin is
complete.
Cycle Numbers, Water Temperature and
Cycle Time Display
The display is used to show the cycle numbers, water
temperature, cycle time, error codes and descriptive
codes related to the control’s programmable options.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
8D1347ENR3
Special Features
Viewing Control Information
The control will store information in its memory that
can be retrieved by pressing various combinations of
Select Cycle keypads. The control will record machine
cycles and hours of operation.
For more information, refer to the 1. Information Sub-
Menu “
,QIR
” section.
Testing Machine Components
By entering the Non-Active Menu’s Test Sub-Menu,
the operator may perform the following tests:
xWater Level Test
xWater Inlet Test
xMotor Test
xTemperature Sensor Test and Calibration
xDrain Valve Test
xRelay Test
xDoor, Door Lock Out-Of-Balance Switch and
Rotation Sensor Test.
xDisplay Test
For detailed information, refer to the 2. Test Sub-
Menu “
W(6W
”section.
Rapid Advance Feature
This feature allows the operator to manually advance
through an active cycle. This feature is useful when
tests must be performed immediately on a washer-
extractor currently in an active cycle.
For detailed information on using the Rapid Advance
feature, refer to the Rapid Advance Feature section.
Communication Mode
This feature allows the control to communicate with a
PC equipped with the Cygnus Assist software using
infra-red communications. This allows the control to
be programmed and have its data read without using
the machine’s keypad.
For more detailed information on using the
Communication Mode feature, refer to the
Communication Mode section.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 9
D1347ENR3
Washer-Extractor Operation
Start Up
When power is applied to the washer-extractor, if the
control was not powered down during a running cycle,
it will enter Start Mode.
Start Mode
The control enters this mode when the machine is
ready for operation. The display will show the cycle
number.
After pressing the keypad with the door closed, the
door will lock and the cycle will begin.
Run Mode
Upon the start of a cycle, the control’s display
alternates between the water temperature and the
remaining cycle time. The appropriate cycle segment
and step LEDs will light while the machine passes
through the cycle.
Stop Mode
The control enters this mode if the operator ends the
cycle before it is completed by pressing the
keypad. Once the control does not detect water or
cylinder rotation, it will enter End Of Cycle mode.
End of Cycle Mode
When a cycle is complete, the control will display
“(QG” until the door is opened. When the door is opened,
the control will return to Start mode.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
10 D1347ENR3
The Non-Active Menu
What is Available in the Non-Active
Menu?
The Non-Active menu can be used to obtain
information from the machine, run test cycles, modify
the control’s programmable features, set the service
counters and view the error code history.
Entering the Non-Active Menu
NOTE: To Enter the Non-Active Menu, a cycle
must not be in process.
1. Press and hold the 1 keypad.
2. While continuing to press the 1 keypad, press and
release the 2 keypad.
3. Continue to hold the 1 keypad until the display
shows the entry code.
NOTE: By default, the entry code is 1000.
4. Modify the entry code as needed and press the 3
keypad. The display shows “LQIR”, which is the
abbreviation for the Info Menu, the first option
within the Non-Active Menu.
Non-Active Menu Navigation
1. Enter the Non-Active Menu (refer to the
Entering the Non-Active Menu section).
2. Press the 1 or 2 keypads to scroll through the
Non-Active Menu options (Refer to Table 1).
3. Press the 3 keypad to enter a Non-Active Menu
option.
4. Press the keypad to exit the Non-Active
Menu.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
The Non-Active Menu
11
D1347ENR3
Non-Active Menu Options
Option Number Option Display Description
1“L QIR”The Information Sub-Menu allows the operator to view information
about the control.
a. “F\F/HV”Total number of cycles performed
b. “KRYU6”Total hours of operation
c. “6(UL$/QU”Machine's serial number
d. “GRL”Machine's installation date
e. “3DU$ /L6W”Version of drive parameters
2“W(6W”The Test Sub-Menu allows the operator to test some of the machine’s
components.
a. “/(X(/”Water level test
b. “L Q/(W6”Water inlet test
c. “RWRU”Motor test
d. “K($W”Temperature sensor test and calibration
e. “GU$LQ”Drain valve test
f. “U(/$\6”Relay test
g. “L Q3YW6”Door, door lock and out-of-balance switch test
h. “GL 63/$\”Display test
3“FRG( 6(W”The Entry Code Set Sub-Menu allows the user to modify the
machine’s entry code.
4“F/RF 6(W”The Clock Set Sub-Menu allows the user to set the machine’s year,
month, day, day of the week, hour and minutes.
5“PHWDGGUHVV”Enter a network address.
6“$GX$QF( (Q$E/(G”The Rapid Advance Enable Sub-Menu allows the operator to turn the
rapid advance option on or off.
7“ 7( 3 (Q$E/(G”The Temperature Indication Enable Sub-Menu allows the operator to
turn the temperature indicator (which appears during a cycle) on or off.
8“&”The MMC Sub-Menu allows the operator to manage data on the MMC
card.
9“6HUXL F(FRYQW(U6”
The Service Counters Sub-Menu allows the operator to display service
maintenance reminders on the machine's control after the machine has
been operated for a specified number of hours or cycles.
10 “Z(( /\ FRYQW(U6”The Weekly Cycle Count Sub-Menu allows the operator to view the
number of times each cycle has been run.
11 “/$6W (UURU6”The Last Errors Sub-Menu allows the operator to view a list of errors
that have occurred during the last cycle that was run on the machine.
12 “RYW R) RUG(U”The Out of Order Sub-Menu allows the operator to place a machine
out of service, preventing it from being used.
13 “6PDUW:DYH”The SmartWave Sub-Menu allows the operator to turn the SmartWave
option on or off.
Tab l e 1
X
X
\
X
X
X
\

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
The Non-Active Menu
D1347ENR3
12
Non-Active Menu Flowchart
CFD1032R
Refer to the SmartWave
Sub-Menu Flowchart
1
3
CFD1032
R
Ready Mode
“info”
Info Sub-Menu
Refer to Entering
the Non-Active
Menu
Refer to Info Sub-Menu
Flowchart
Refer to the Test Sub-Menu
Flowchart
Refer to the Entry Code Set
Sub-Menu Flowchart
Refer to the Clock Set Sub-Menu
Flowchart
Refer to the Rapid Advance Enable
Sub-Menu Flowchart
Refer to the Temperature Indication
Enable Sub-Menu Flowchart
Refer to the MMC Sub-Menu
Flowchart
Refer to the Service Counters
Sub-Menu Flowchart
Refer to the Weekly Cycle Count
Sub-Menu Flowchart
Refer to the Last Errors
Sub-Menu Flowchart
Refer to the Out of Order
Sub-Menu Flowchart
“test”
Test Sub-Menu
“code Set”
Entry Code Set
Sub-Menu
“cLoc Set”
Clock Set Sub-Menu
“ C ”
MMC Sub-Menu
“SerU ce coVnters”
Service Counters
Sub-Menu
“Last Errors”
Last Errors Sub-Menu
“AdUance EnabLed”
Rapid Advance Enable
Sub-Menu
“te p EnabLed”
Temperature Indication
Enable Sub-Menu
“wee ly coVnters”
Weekly Cycle Count
Sub-Menu
“oVt of order”
Out of Order Sub-Menu
“s artwaue”
SmartWave Sub-Menu
U
U
y
U
i
1
2
3
1
2
3
1
3
21
3
21
3
21
3
21
3
21
3
21
3
21
3
2
2
2
1
3
Refer to the Network Address
Sub-Menu Flowchart
“net address”
Network Address
Sub-Menu
3
21
u
y

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
The Non-Active Menu
13
D1347ENR3
1. Information Sub-Menu “
L QIR
”
The Information Sub-Menu allows the operator to
view information about the control.
How to Access the Information Sub-Menu
1. Enter the Non-Active menu (refer to the
Entering the Non-Active Menu section).
2. Press the 1 or 2 keypads to scroll through the
Non-Active Menu’s sub-menus until “L QIR”
appears in the display.
3. Press the 3 keypad. “F\F/HV” appears in the
display.
4. Press the 1 or 2 keypads until the desired option
appears in the display. Refer to Table 2.
How to Exit the Information Sub-Menu
Press the keypad until the control returns to the
Ready Mode.
Option
Display Description
“F\F/HV” Total number of cycles performed
“KRYU6” Total hours of operation
“6(UL$/QU” Machine's serial number
“GRL”
Machine’s installation date
NOTE: The date on which the machine
completed it’s 10th cycle will be
recorded by the control as the
machine’s “installation date”
(DD-MM-YYYY).
“3$U$ /L6W” Version of drive parameters
Table 2
X

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
The Non-Active Menu
D1347ENR3
14
Information Sub-Menu Flowchart
CFD140R
CFD140R
info
cycLes XXXX
hoVrs XXXX
seriaL nr XXXX
XXXX
do
i
i
XX - XX - XXXX
test
(Return
to Ready
Mode)
PArA
L st
U
1
1
2 1
2
3
2 1
2 1
2
2
1
1 2
s artwaue
u

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
The Non-Active Menu
15
D1347ENR3
2. Test Sub-Menu “
W(6W
” (1 of 4)
The Test Sub-Menu allows the operator to test some of
the machine’s components.
How to Access the Test Sub-Menu
1. Enter the Non-Active menu (refer to the
Entering the Non-Active Menu section).
2. Press the 1 or 2 keypads to scroll through the
Non-Active Menu’s sub-menus until “W(6W”
appears in the display.
3. Press the 3 keypad. “/(X(/” appears in the
display.
4. Press the 1 or 2 keypads to scroll through the Test
Sub-Menu’s options.
5. Press the 3 keypad to access the desired Test Sub-
Menu’s option. Refer to the Using the Test Sub-
Menu’s Options section for details on each
option.
Using the Test Sub-Menu’s Options
a. Water Level Test “/(X(/”
NOTE: Make sure all water has been
drained from the machine.
i. Press the 3 keypad. “XX.X”, which is the
measured water level, appears in the
display and flashes.
ii. Press the 3 keypad. “XX.X”, which is the
water level to be measured, appears in the
display.
iii. Note the number shown in the display and
mark the middle of the door glass.
iv. Press the 3 keypad. “)L//.” appears in the
display and the machine begins to fill with
water.
v. Fill the machine to the mark made on the
middle of the door glass. Press the
2 keypad to turn off the water and the
1 keypad to turn on the water as needed.
vi. Press the 3 keypad. “XX.X”, which is the
current water level, appears in the display
and flashes.
vii. Compare the number shown in the display
to the number that was recorded earlier. If
necessary, press the 1 or 2 keypads to
change the number shown in the display
until it matches the number that was
recorded earlier.
viii. Press the 3 keypad. “XX.X”, which is the
measured water level, is shown in the
display.
ix. Press the keypad. “/(8(/” appears in
the display.
b. Water Inlet Test “L Q/(W6”
i. Press the 3 keypad. “KRW ” appears in the
display.
ii. Press the 1 or 2 keypads to scroll through
the inlets until the desired inlet is shown in
the display. Refer to Table 3.
iii. Press the 3 keypad to turn on the desired
inlet. The display shows a dot next to the
inlet number (e.g., “KRW .”).
iv. Press the 3 keypad to turn off the desired
inlet.
v. Press the keypad. “L Q/(W6” appears in
the display.
(continued)
Display Description
“KRW ”Hot water 1
“KRW ”Hot water 2
“KRW ”Hot water 3
“F/G ”Cold water 1
“F/G ”Cold water 2
“F/G ”Cold water 3
“GUFW”Direct
Tab l e 3

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
The Non-Active Menu
D1347ENR3
16
Test Sub-Menu Flowchart (1 of 4)
CFD429R
CFD429
R
33
3
XX.X
XX.X
hot 1
hot 2
hot 3
hot 3.
hot 2.
hot 1.
2
2
2
1
1
1
1
1
1
1
2
info
3
FiLL.
3
XX.X
3
3
3
3
3
3
3
3
3
XX.X
2
2
2
2
2
cLd 1
cLd 1.
cLd 2
cLd 2.
cLd 3
drct drct.
cLd 3.
2 1
2
2
2
2
2
2
2
1
1
(Return
to Ready
Mode)
back to the
end of the
Test Sub-Menu
Test
display
2 1
LeUeL
InLets

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
The Non-Active Menu
17
D1347ENR3
2. Test Sub-Menu “
W(6W
” (2 of 4)
c. Motor Test “ RWRU”
i. Press the 3 keypad. “:$6K” appears in the
display.
ii. Press the 1 or 2 keypads to scroll through
the Motor Test sub-menu’s options until the
desired option is shown in the display.
Refer to Table 4.
iii. Press the 3 keypad to select the desired
option.
x“:$6K”: The motor goes into wash speed
and “UXX” or “/XX” appears on the
display.
x“63LQ”: The motor goes into spin speed
and the speed “XX” appears on the
display. The machine will accelerate to
500 RPM (if allowed by the machine)
and continue at this speed for a few
seconds. The machine will then
accelerate to it’s maximum spin speed
and will continue at this speed for 10
minutes.
x“WYQH”: The display shows “ZDLW” and
then “U(6(WWLQJL QX(UWRU”. The
display then flashes “WYQ(” as the
invertor drive is autotuned.
NOTE: The “
WYQH
” option will
automatically turn off once the autotune
is complete.
iv. Press the keypad to turn off the
option.
v. Press the keypad. “ RWRU” appears in
the display.
d. Temperature Sensor Test and Calibration
“K($W”.
i. Press the 3 keypad. The measured
temperature “XX°F” appears in the
display. The machine is filled with water
to the safety level.
ii. Press the 1 or 2 keypads to scroll through
the Temperature Sensor Test and
Calibration sub-menu’s options until the
desired option is shown in the display.
Refer to Table 5.
iii. Press the 3 keypad to select the desired
option.
x“R))” or “RQ”: Turn the heating off or
on. “R))” is displayed when the heating
is turned off and “RQ” is displayed when
the heating is turned on.
NOTE: This option is only visible if the
machine is configured for 1 heating type.
x“+ ” or u+ .”: Turn heating type 1 off
or on. “+ ” is displayed when the
heating is turned off and “+ .” is
displayed when the heating is turned on.
NOTE: This option is only visible if the
machine is configured for 2 heating types.
x“+” or “+.”: Turn heating type 2 off
or on. “+” is displayed when the
heating is turned off and “+.” is
displayed when the heating is turned on.
NOTE: This option is only visible if the
machine is configured for 2 heating types.
x“F$/”:
a. The measured temperature “XX°F”
appears in the display and flashes.
b. Press the 1 or 2 keypads to increase or
decrease the temperature displayed as
needed.
c. Press the 3 keypad. “VDXH QR” appears
in the display.
d. To save the temperature display
change, press the 1 or 2 keypad.
“VDXH \(6” appears in the display.
e. Press the 3 keypad. “F$/” appears in
the display.
iv. Press the keypad. “K($7” appears in
the display.
Display Description
“:$6K”Motor wash speed
“63LQ”Motor spin speed
“WYQH”Autotune the invertor drive
Table 4
X
X
Display Description
“R))” or
“RQ”
Turn the heating off or on
NOTE: This option is only visible if the
machine is configured for 1 heating type.
“+ ” or
“+ .”
Turn heating type 1 off or on
NOTE: This option is only visible if the
machine is configured for 2 heating type.
“+” or
“+.”
Turn heating type 2 off or on
NOTE: This option is only visible if the
machine is configured for 2 heating type.
“F$/”Calibrate the temperature sensor
Table 5

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
The Non-Active Menu
D1347ENR3
18
Test Sub-Menu Flowchart (2 of 4)
CFD430R
3
START
2 1
2
2
2
1
2 1
(Return
to Ready
Mode)
Test
motor
START
heat
wASh
wAit
r
1
1
1
3
3
3
Spin
tvne tvne
XX
LXX
START
XX
XX <
resettin{
inverter
i
2
3
3
2
2
2
START
1
1
1
1or
or
3 3
3
off
2
on
SAUE
no
yes
o
XX <
o
cAL
or
