Washer-Extractors
Cabinet Freestanding
Models SF135PV, SF250PV, SF250PV Tilt,
UF135PV, UF250PV and UF250PV Tilt
R017I
OperatingInstructions
OutputIndicators
EmergencyStop
1. Open Door
3. Close Door
4. Enter 2 Digit Wash Cycle
5. Press Start
2. Load Articles
OperatingInstructions
OutputIndicators
EmergencyStop
1. Open Door
3. Close Door
4. Enter 2 Digit Wash Cycle
5. Press Start
2. Load Articles
®
R072I
Part No. F232102R3
January 2002
Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.)

© Copyright, Alliance Laundry Systems LLC –DO NOT COPY or TRANSMIT
© Copyright 2002, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any
means without the expressed written consent of the publisher.
F232102 1
Table of
Contents
Safety.................................................................................................... 3
Key to Symbols..................................................................................... 4
Operator Safety..................................................................................... 6
Safe Operating Environment ................................................................ 6
Environmental Conditions ............................................................... 6
Machine Location ............................................................................ 7
Input and Output Services................................................................ 7
AC Inverter Drive ............................................................................ 8
Misuse................................................................................................... 8
Installation........................................................................................... 9
Machine Overview................................................................................ 9
Emergency Stop Button ................................................................... 9
Wet Clean Capable Features............................................................ 9
Delivery Inspection............................................................................... 10
Customer Service.................................................................................. 10
Machine Dimensions ............................................................................ 15
Dimensional Clearances................................................................... 15
Machine Foundation ............................................................................. 21
Mechanical Installation – Standard Models ......................................... 22
Mounting Bolt Installation for Standard 135 Pound Capacity
and 250 Pound Capacity Machines ................................................ 22
Mechanical Installation – Models with Tilt Option.............................. 25
Mounting Bolt Installation for 250 Pound Capacity Models
with Forward or Two-Way Tilt Option.......................................... 25
Drain Connection.................................................................................. 28
Water Connection ................................................................................. 30
Electrical Installation............................................................................ 31
Power Cable/Plug Disconnect.......................................................... 32
Steam Requirements (Steam Heat Option Only).................................. 34
Air Requirements.................................................................................. 34
Chemical Injection Supply System....................................................... 35
Supply Compartments...................................................................... 36
Connecting External Liquid Supplies to the Washer-Extractor....... 36
Electrical Connections for Chemical Injection Supply Systems ..... 36
Control Function Test........................................................................... 38
Maintenance ........................................................................................ 39
Daily ..................................................................................................... 39
Beginning of Day............................................................................. 39
End of Day ....................................................................................... 40
Weekly.................................................................................................. 40
Monthly................................................................................................. 40
Quarterly............................................................................................... 42
Care of Stainless Steel .......................................................................... 42
Daily Preventive Maintenance Checklist.............................................. 43
Weekly Preventive Maintenance Checklist.......................................... 44
Monthly Preventive Maintenance Checklist......................................... 45
Quarterly Preventive Maintenance Checklist....................................... 46
Removal from Service ........................................................................ 47
Decommissioning ................................................................................. 47

© Copyright, Alliance Laundry Systems LLC –DO NOT COPY or TRANSMIT
2F232102
Notes

© Copyright, Alliance Laundry Systems LLC –DO NOT COPY or TRANSMIT 3
F232102
Safety
Anyone operating or servicing this machine must
follow the safety rules in this manual. Particular
attention must be paid to the CAUTION, WARNING,
and DANGER blocks which appear throughout the
manual.
The following warnings are general examples that
apply to this machine. Warnings specific to a particular
operation will appear in the manual with the
discussion of that operation.
Be careful around the open door,
particularly when loading from a level
below the door. Impact with door edges
can cause personal injury.
SW025
CAUTION
Dangerous voltages are present in the
electrical control box(es) and at the motor
terminals. Only qualified personnel
familiar with electrical test procedures,
test equipment, and safety precautions
should attempt adjustments and
troubleshooting. Disconnect power from
the machine before removing the control
box cover, and before attempting any
service procedures.
SW005
WARNING
Death or serious injury can result if
children become trapped in the machine.
Do not allow children to play on or around
this machine. Do not leave children
unattended while the machine door is
open.
SW001
DANGER
This machine must be installed, adjusted,
and serviced by qualified electrical
maintenance personnel familiar with the
construction and operation of this type of
machinery. They must also be familiar
with the potential hazards involved.
Failure to observe this warning may result
in personal injury and/or equipment
damage, and may void the warranty.
SW004
WARNING
Ensure that the machine is installed on a
level floor of sufficient strength and that
the recommended clearances for
inspection and maintenance are provided.
Never allow the inspection and
maintenance space to be blocked.
SW020
CAUTION
Never touch internal or external steam
pipes, connections, or components.
These surfaces can be extremely hot and
will cause severe burns. The steam must
be turned off and the pipe, connections,
and components allowed to cool before
the pipe can be touched.
SW014
WARNING

© Copyright, Alliance Laundry Systems LLC –DO NOT COPY or TRANSMIT
Safety
F232102
4
Key to Symbols
The lightning flash and arrowhead within the triangle
is a warning sign indicating the presence of dangerous
voltage.
The exclamation point within the triangle is a warning
sign indicating important instructions concerning the
machine and possibly dangerous conditions.
This warning symbol indicates the presence of
potentially dangerous drive mechanisms within the
machine. Guards should always be in place when the
machine is in operation.
This warning symbol indicates the presence of possibly
dangerous chemicals. Proper precautions should be
taken when handling corrosive or caustic materials.
This warning symbol indicates the presence of hot
surfaces that could cause serious burns. Stainless steel
and steam lines can become extremely hot and should
not be touched.
This warning symbol indicates the presence of
possibly dangerous pinch-points. Moving mechanical
parts can crush and/or sever body parts.

© Copyright, Alliance Laundry Systems LLC –DO NOT COPY or TRANSMIT
Safety
5
F232102
Figure 1
Safety decals appear at crucial locations on the
machine. Failure to maintain legible safety decals could
result in injury to the operator or service technician.
To provide personal safety and keep the machine in
proper working order, follow all maintenance and
safety procedures presented in this manual. If questions
regarding safety arise, contact the factory immediately.
Use factory-authorized spare parts to avoid safety
hazards.
R066I
R066I
DO NOT EXCEED

© Copyright, Alliance Laundry Systems LLC –DO NOT COPY or TRANSMIT
Safety
F232102
6
Operator Safety
To ensure the safety of machine operators, the following
maintenance checks must be performed daily:
1. Prior to operating the machine, verify that all
warning signs are present and legible. Missing or
illegible signs must be replaced immediately.
Make certain that spares are available.
2. Check door interlock before starting operation of
the machine:
a. Attempt to start the machine with the door
open. The machine should not start with the
door open.
b. Close the door without locking it and attempt
to start the machine. The machine should not
start with the door unlocked.
c. Close and lock the door and start a cycle.
Attempt to open the door while the cycle is in
progress. The door should not open.
If the door lock and interlock are not functioning
properly, call a service technician.
3. Do not attempt to operate the machine if any of
the following conditions are present:
a. The door does not remain securely locked
during the entire cycle.
b. Excessively high water level is evident.
c. Machine is not connected to a properly
grounded circuit.
Do not bypass any safety devices in the machine.
Safe Operating Environment
Safe operation requires an appropriate operating
environment for both the operator and the machine. If
questions regarding safety arise, contact the factory
immediately.
Environmental Conditions
●Ambient Temperature. Water in the machine will
freeze at temperatures of 32°F (0°C) or below.
Temperatures above 120°F (50°C) will result in
more frequent motor overheating and, in some
cases, malfunction or premature damage to solid
state devices that are used in some models.
Special cooling devices may be necessary.
Water pressure switches are affected by increases
and decreases in temperature. Every 25°F
(10°C) change in temperature will have a
1% effect on the water level.
●Humidity. Relative humidity above 90% may
cause the machine’s electronics or motors to
malfunction or may trip the ground fault
interrupter. Corrosion problems may occur on
some metal components in the machine.
If the relative humidity is below 30%, belts and
rubber hoses may eventually develop dry rot.
This condition can result in hose leaks, which
may cause safety hazards external to the machine
in conjunction with adjacent electrical
equipment.
●Ventilation. The need for make-up air openings
for such laundry room accessories as dryers,
ironers, or water heaters must be evaluated
periodically. Louvers, screens, or other
separating devices may reduce the available air
opening significantly.
●Radio Frequency Emissions. A filter is available
for machines in installations where floor space is
shared with equipment sensitive to radio
frequency emissions.
●Elevation. If the machine is to be operated at
elevations of over 3280 ft. (1000 m) above sea
level, pay special attention to water levels and
electronic settings (particularly temperature) or
desired results may not be achieved.
NEVER insert hands or objects into
basket until it has completely stopped.
Doing so could result in serious injury.
SW012
WARNING
Never operate the machine with a
bypassed or disconnected balance
system. Operating the machine with
severe out-of-balance loads could result
in personal injury and serious equipment
damage.
SW039
WARNING

© Copyright, Alliance Laundry Systems LLC –DO NOT COPY or TRANSMIT
Safety
7
F232102
●Chemicals. Keep stainless steel surfaces free of
chemical residues.
●Water Damage. Do not spray the machine with
water. Short circuiting and serious damage may
result. Repair immediately all seepage due to
worn or damaged gaskets, etc.
Machine Location
●Foundation. The concrete floor must be of
sufficient strength and thickness to handle the
floor loads generated by the high extract speeds
of the machine.
●Service/Maintenance Space. Provide sufficient
space to allow comfortable performance of
service procedures and routine preventive
maintenance.
This is especially important in connection with
machines equipped with an AC inverter drive.
Consult installation instructions for specific details.
Input and Output Services
●Water Pressure. Best performance will be
realized if water is provided at a pressure of
30 –85 psi (2.0 –5.7 bar). Although the machine
will function properly at lower pressure,
increased fill times will occur. Water pressure
higher than 100 psi (6.7 bar) may result in
damage to machine plumbing. Component
failure(s) and personal injury could result.
●Steam Heat (Optional) Pressure. Best
performance will be realized if steam is provided
at a pressure of 30 –80 psi (2.0 –5.4 bar). Steam
pressure higher than 125 psi (8.5 bar) may result
in damage to steam components and may cause
personal injury.
For machines equipped with optional steam heat,
install piping in accordance with approved
commercial steam practices. Failure to install the
supplied steam filter may void the warranty.
●Compressed Air. For machines requiring
compressed air service, best performance will
be realized if air is provided at a pressure of
80 –100 psi (5.4 –6.7 bar).
●Drainage System. Provide drain lines or troughs
large enough to accommodate the total number of
gallons that could be dumped if all machines on
the site drained at the same time from the highest
attainable level. If troughs are used, they should
be covered to support light foot traffic.
●Power. For personal safety and for proper
operation, the machine must be grounded in
accordance with state and local codes. The
ground connection must be to a proven earth
ground, not to conduit or water pipes. Do not
use fuses in place of the circuit breaker. An easy-
access cutoff switch should also be provided.
Always disconnect power and water supplies before
a service technician performs any service procedure.
Where applicable, steam and/or compressed air
supplies should also be disconnected before service
is performed.
Do not place volatile or flammable fluids
in any machine. Do not clean the machine
with volatile or flammable fluids such as
acetone, lacquer thinners, enamel
reducers, carbon tetrachloride, gasoline,
benzene, naptha, etc. Doing so could
result in serious personal injury and/or
damage to the machine.
SW002
DANGER
Replace all panels that are removed to
perform service and maintenance
procedures. Do not operate the machine
with missing guards or with broken or
missing parts. Do not bypass any safety
devices.
SW019
CAUTION
Ensure that a ground wire from a proven
earth ground is connected to the ground
lug near the input power block on this
machine. Without proper grounding,
personal injury from electric shock could
occur and machine malfunctions may be
evident.
SW008
WARNING

© Copyright, Alliance Laundry Systems LLC –DO NOT COPY or TRANSMIT
Safety
F232102
8
AC Inverter Drive
Machines equipped with the AC inverter drive require
special attention with regard to the operating
environment.
●An especially dusty or linty environment will
require more frequent cleaning of the AC inverter
drive cooling fan filter and of the AC inverter
drive itself.
●Power line fluctuations from sources such as
uninterruptible power supplies (UPS) can
adversely affect machines equipped with the AC
inverter drive. Proper suppression devices should
be utilized on the incoming power to the machine
to avoid problems.
●A clean power supply free from voltage spikes
and surges is absolutely essential for machines
equipped with the AC inverter drive. Nonlinear
inconsistencies (peaks and valleys) in the power
supply can cause the AC inverter drive to
generate nuisance errors.
If voltage is above 230 Volt for 200 Volt
installations or above 440 Volt for 400 Volt
installations, a buckboost transformer is
recommended. If voltage is above 240 Volt or
480 Volt, a buckboost transformer is required.
●Sufficient space to perform service procedures
and routine preventive maintenance is especially
important for machines equipped with the AC
inverter drive.
Misuse
Never use this machine for any purpose other than
washing fabric.
●Never wash petroleum-soaked rags in the
machine. This could result in an explosion.
●Never wash machine parts or automotive parts in
the machine. This could result in serious damage
to the basket.
●Never allow children to play on or around this
machine. Death or serious injury can result if
children become trapped in the machine. Do not
leave children unattended while the machine door
is open. These cautions apply to animals as well.

© Copyright, Alliance Laundry Systems LLC –DO NOT COPY or TRANSMIT 9
F232102
Installation
This manual is designed as a guide to the installation
and maintenance of the 135 pound and 250 pound
capacity cabinet freestanding washer-extractors.
The manuals, installation instructions, and the wiring
diagrams which accompany the washer-extractor have
been included with the machine at no charge.
Additional copies are available at a nominal charge.
NOTE: All information, illustrations, and
specifications contained in this manual are based
on the latest product information available at the
time of printing. We reserve the right to make
changes at any time without notice.
Machine Overview
The design of the washer-extractor emphasizes
performance and long service life. The cylinder, shell,
and main body panels are fabricated of stainless steel.
The washer-extractor features the WE-6
microcomputer which offers 39 preprogrammed
cycles and programming versatility in the field.
The AC inverter drive control provides programmable
motor speeds using a single motor. This makes it
possible to achieve ultra-high extract speeds.
Two separate bearings support the cylinder on
135 pound and 250 pound models.
The cylinder is constructed with four lifters or ribs that
lift the laundry from the bath solution when the
cylinder rotates at slow speed and then allow it to
tumble back into the bath. This mechanical action
accomplishes the cleaning function. The cylinder is
perforated, allowing the water to drain from within
during the wash and extract steps.
The supply dispenser is located on the left side panel
of the washer-extractor. The supply dispenser
compartments are accessed by unlatching the supply
dispenser cover door. These compartments accept
powder or liquid supplies. Each compartment is
controlled independently by the WE-6 computer.
Electrical controls for the washer-extractor are housed
in three enclosures. The front control module is
located just behind the keypad and control panel. It
houses the WE-6 computer board, a fuse/relay board,
and other functional electrical components. The rear
control module houses the AC inverter drive and its
components.
A door-lock system prevents opening of the door when
water is in the washer-extractor. It also prevents
operation of the washer-extractor when the door is
open.
The doorbox contains the Hall-effect door-closed
sensor, door-open sensor, and the door-unlock
solenoid.
On 135 pound capacity models, water enters the
machine through electromechanical water valves. On
250 pound capacity models, water enters the machine
through pneumatic water valves on the rear of the
machine. (Pneumatic water valves are an option on
135 pound capacity models.)
Emergency Stop Button
On 135 pound capacity models, a red emergency stop
button is located on the right side of the washer-
extractor front. On 250 pound capacity models, the
emergency stop button is located on the left side. Push
the button to stop the machine.
Wet Clean Capable Features
The washer-extractor is equipped with the following
wet clean capable features: one-half wash speed for
gentle mechanical action during wash; eight supply
signals, providing normal laundering signals to
dispense detergents, bleaches, softeners, sours, etc.,
and also chemicals unique to wet clean processing.

© Copyright, Alliance Laundry Systems LLC –DO NOT COPY or TRANSMIT
Installation
F232102
10
Delivery Inspection
Upon delivery, visually inspect crate, protective cover,
and unit for any visible shipping damage. If the crate,
protective cover, or unit are damaged or signs of
possible damage are evident, have the carrier note the
condition on the shipping papers before the shipping
receipt is signed, or advise the carrier of the condition
as soon as it is discovered.
Remove the crate and protective cover as soon after
delivery as possible. If any damage is discovered upon
removal of the crate and/or protective cover, advise the
carrier and file a written claim immediately.
Customer Service
If literature or replacement parts are required, contact
the source from whom the washer-extractor was
purchased or contact Alliance Laundry Systems LLC
at [phone] for the name of the nearest
authorized parts distributor.
For technical assistance, call any of the following
numbers:
[phone]
[phone]
Marianna, Florida
[phone]
Ripon, Wisconsin
A record of each washer-extractor is on file with the
manufacturer. The serial number decal is located at the
rear of the washer-extractor. Figure 2 shows the
location of the serial number on the decal. Always
provide the washer-extractor’s serial number and
model number when ordering parts or when seeking
technical assistance.

© Copyright, Alliance Laundry Systems LLC –DO NOT COPY or TRANSMIT
Installation
11
F232102
Figure 2
Model Number Familiarization Guide
Sample Model Number: UF135PVQU20001
UF Model Number Prefix
135 Washer-Extractor Capacity (pounds dry weight)
PType of Electrical Control P = WE-6 Computer
VWasher-Extractor Speed Capabilities V = 7 Speeds
QElectrical Characteristics Refer to Tabl e 6.
U2 Design Series
0001 Option Identification (varies from machine to machine)
R073I
UF135PVQU20001

© Copyright, Alliance Laundry Systems LLC –DO NOT COPY or TRANSMIT
Installation
F232102
12
Cabinet Freestanding
135 Pound and 250 Pound Capacity Models
General Specifications
135 250
Standard Standard Forward Tilt
Option Two-Way Tilt Option
Overall Dimensions
Overall width 71 in.
(1803 mm)
77.06 in.
(1957 mm)
81 in.
(2057 mm)
79.0 in.
(2006 mm)
Overall height 75 in.
(1829 mm)
82 in.
(2083 mm)
88 in.
(2235 mm)
88 in.
(2235 mm)
Overall depth 61 in.
(1550 mm) 80.2 in. (2040 mm) 86.1 in. (2190 mm) 91 in.
(2311 mm)
Weight and Shipping Information
Net weight 4000 lbs.
(1818 kg) 7800 lbs. (3545 kg) 8600 lbs. (3909 kg) 9600 lbs. (4364 kg)
Domestic shipping weight 4200 lbs.
(1909 kg)
8000 lbs.
(3636 kg)
8800 lbs.
(4000 kg)
9800 lbs.
(4445 kg)
Domestic shipping volume 253 ft3
(7.1 m3)
406 ft3
(11.4 m3)
406 ft3
(11.4 m3)
406 ft3
(11.4 m3)
Export shipping weight 4500 lbs.
(2045 kg) 8500 lbs. (3860 kg) 9300 lbs. (4227 kg) 10,300 lbs. (4682 kg)
Export shipping volume 291 ft3
(8.1 m3)
454 ft3
(12.7 m3)
454 ft3
(12.7 m3)
454 ft3
(12.7 m3)
Wash Cylinder Information
Cylinder diameter 43 in.
(1092 mm)
52 in.
(1321 mm)
52 in.
(1321 mm)
52 in.
(1321 mm)
Cylinder depth 25 in.
(635 mm)
32 in.
(813 mm)
32 in.
(813 mm)
32 in.
(813 mm)
Cylinder volume 21.0 ft3
(596 l) 39.3 ft3 (1114 l) 39.3 ft3 (1114 l) 39.3 ft3 (1114 l)
Perforation size 0.188 in.
(4.77 mm)
0.188 in.
(4.77 mm)
0.188 in.
(4.77 mm)
0.188 in.
(4.77 mm)
Perforation open area 23% 20% 20% 20%
Door Opening Information
Door opening size 23 in.
(584 mm) 28.5 in. (724 mm) 28.5 in. (724 mm) 28.5 in. (724 mm)
Height of door bottom above floor 28.25 in.
(718 mm)
30.9 in.
(784 mm)
36.9 in.
(937 mm)
36.9 in.
(937 mm)

© Copyright, Alliance Laundry Systems LLC –DO NOT COPY or TRANSMIT
Installation
13
F232102
135 250
Standard Standard Forward Tilt
Option Two-Way Tilt Option
Water Consumption
Average water consumption per cycle HOT
COLD
153 gal
(579 l)
219 gal
(829 l)
219 gal
(829 l)
219 gal
(829 l)
70 gal
(266 l)
105 gal
(399 l)
105 gal
(399 l)
105 gal
(399 l)
Average hot water consumed per hour 220 gal
(833 l) 285 gal (1079 l) 285 gal (1079 l) 285 gal (1079 l)
Power Consumption
Average power used per cycle 0.9 kW-hr 1.5 kW-hr
(Est.) 1.5 kW-hr (Est.) 1.5 kW-hr (Est.)
Average HVAC load 1500 BTU/hr
(kcal/hr)
2200 BTU/hr
(kcal/hr)
2200 BTU/hr
(kcal/hr)
2200 BTU/hr
(kcal/hr)
Nominal sound emission 75 dBA 75 dBA 75 dBA 75 dBA
Drive Train Information
Number of motors in drive train 1 1 1 1
Drive motor power 10 hp
(7.5 kW)
25 hp
(18.5 kW)
25 hp
(18.5 kW)
25 hp
(18.5 kW)
Cylinder Speeds
1/2 Wash/reverse speed 26 rpm 21 rpm 21 rpm 21 rpm
Wash/reverse speed 36 rpm 31 rpm 31 rpm 31 rpm
Distribution speed 62 rpm 54 rpm 54 rpm 54 rpm
Medium extract speed 170 rpm 140 rpm 140 rpm 140 rpm
High extract speed l 375 rpm 340 rpm 340 rpm 340 rpm
High extract speed 2 480 rpm 435 rpm 435 rpm 435 rpm
High extract speed 3 715 rpm 650 rpm 650 rpm 650 rpm
Centrifugal Force Data
1/2 Wash/reverse centrifugal force 0.412 Gs 0.325 Gs 0.325 Gs 0.325 Gs
Wash/reverse centrifugal force 0.790 Gs 0.708 Gs 0.708 Gs 0.708 Gs
Distribution centrifugal force 2.34 Gs 2.15 Gs 2.15 Gs 2.15 Gs
Medium extract centrifugal force 17.6 Gs 14.7 Gs 14.7 Gs 14.7 Gs
High extract 1 centrifugal force 85.8 Gs 85.3 Gs 85.3 Gs 85.3 Gs
High extract 2 centrifugal force 141 Gs 140 Gs 140 Gs 140 Gs
High extract 3 centrifugal force 312 Gs 312 Gs 312 Gs 312 Gs
Balance Detection
Vibration safety switch installed Standard Standard Standard Standard
Cabinet Freestanding
135 Pound and 250 Pound Capacity Models
General Specifications (Continued)

© Copyright, Alliance Laundry Systems LLC –DO NOT COPY or TRANSMIT
Installation
F232102
14
135 250
Standard Standard Forward Tilt
Option Two-Way Tilt Option
Direct Steam Heating (Optional)
Steam inlet connection size
0.75 in.
(DN19)
(19.05 mm)
1.0 in.
(DN25)
(25.4 mm)
1.0 in.
(DN25)
(25.4 mm)
1.0 in.
(DN25)
(25.4 mm)
Number of steam inlets 1 1 1 1
Steam required to raise bath temperature
10°F
LOW 7.89 lbs.
(5.68 kg) 12.75 lbs. (9.18 kg) 12.75 lbs. (9.18 kg) 12.75 lbs. (9.18 kg)
HIGH 10.2 lbs.
(7.36 kg)
17.6 lbs.
(12.6 kg)
17.6 lbs.
(12.6 kg)
17.6 lbs.
(12.6 kg)
Average steam use per cycle 5.28 BHP 8.8 BHP 8.8 BHP 8.8 BHP
Electric Heating (Optional)
Total electric heating capacity 45 kW N/A N/A N/A
Number of electrical heat elements 18 N/A N/A N/A
Electrical heat element size 2.5 kW N/A N/A N/A
Time required to raise bath temperature 10°F LOW 3.2 min N/A N/A N/A
HIGH 4.2 min N/A N/A N/A
Cabinet Freestanding
135 Pound and 250 Pound Capacity Models
General Specifications (Continued)

© Copyright, Alliance Laundry Systems LLC –DO NOT COPY or TRANSMIT
Installation
15
F232102
Machine Dimensions
Refer to Figure 3 for dimensions of the 135 pound
capacity model. Refer to Figure 4, Figure 5, and
Figure 6 for dimensions of the 250 pound capacity
models.
Dimensional Clearances
Table 1 below shows recommended minimum
clearances on all sides of the washer-extractor.
Washer-extractors equipped with the tilt option require
a minimum overhead clearance, as well. Refer to
Figure 7 for the minimum overhead clearance for the
250 pound capacity model with tilt option.
NOTE: The dimensions shown here are for
planning purposes only. They are approximate and
subject to normal manufacturing tolerances. If
exact dimensions are required for construction
purposes, contact the distributor or manufacturer.
We reserve the right to make changes at any time
without notice.
Cabinet Freestanding
Recommended Minimum Clearances
135 250
Standard Standard Forward Tilt
Option Two-Way Tilt Option
Minimum rear clearance 24 in.
(610 mm)
24 in.
(610 mm)
36 in.
(914 mm)
36 in.
(914 mm)
Minimum clearance between washer-extractor
and wall
18 in.
(457 mm)
18 in.
(457 mm)
18 in.
(457 mm)
18 in.
(457 mm)
Minimum clearance between washer-extractors
(side)
18 in.
(457 mm) 18 in. (457 mm) 18 in. (457 mm) 18 in. (457 mm)
Minimum front clearance 23 in.
(584 mm)
36 in.
(914 mm)
36 in.
(914 mm)
36 in.
(914 mm)
Minimum overhead clearance 60.5 in.
(1537 mm)
88 in.
(2235 mm)
108 in.
(2743 mm)
108 in.
(2743 mm)
Table 1

© Copyright, Alliance Laundry Systems LLC –DO NOT COPY or TRANSMIT
Installation
F232102
16
Figure 3
CFS209N
1Recirculation Port 6Main Power
2Vent 7External Signal Supply
3Steam Inlet (Optional) 8Extra Fill Valve
4Standard Drain Outlet 9Cold Water Inlet
5Reuse Drain Outlet (Optional) 10 Hot Water Inlet
65.5 in.
(1664 mm)
62 in.
(1575 mm)
71 in.
(1803 mm)
28.25 in.
(718 mm)
30.25 in.
(768 mm)
41.75 in.
(1060 mm)
61 in.
(1549 mm)
58.69 in.
(1491 mm)
75 in.
(1905 mm)
57.31 in.
(1457 mm)
54.19 in.
(1376 mm)
23 in.
(584 mm)
20.81 in.
(529 mm)
39.09 in.
(992 mm)
37.5 in.
(952 mm)
35.91 in.
(913 mm)
57.81 in.
(1468 mm)
56.5 in.
(1435 mm)
56.31 in.
(1430 mm)
6.75 in.
(171 mm)
20.5 in.
(521 mm) 20.06 in.
(509 mm)
67.5 in.
(1715 mm)
71 in.
(1803 mm)
72 in.
(1829 mm)
135 POUND CAPACITY MODELS
FRONT
SIDE
REAR
6
1
23
4
5
8
910
7

© Copyright, Alliance Laundry Systems LLC –DO NOT COPY or TRANSMIT
Installation
17
F232102
Figure 4
CFS210N
1Recirculation Port 6Standard Drain Outlet
2Hot Water Inlet 7Reuse Drain Outlet (Optional)
3Vent 8External Supply Signals
4Cold Water Inlet 9Main Power
5Steam Inlet (Optional) 10 Extra Fill Valve (Optional)
82 in.
(2083 mm)
11.5 in.
(292 mm)
77.06 in.
(1957 mm)
32.63 in.
(829 mm)
30.88 in.
(784 mm)
40.69 in.
(1034 mm)
80.19 in.
(2037 mm)
64.5 in.
(1639 mm)
63.63 in.
(1615 mm)
28 in.
(712 mm)
47.19 in.
(1198 mm)
43.19 in.
(1096 mm)
35.91 in.
(912 mm)
78.63 in.
(1997 mm)
62.38 in.
(1584 mm)
22.5 in.
(572 mm) 22.5 in.
(572 mm)
59.91 in.
(1446 mm)
69.41 in.
(1763 mm)
77.19 in.
(1960 mm)
250 POUND CAPACITY MODELS
FRONT SIDE
REAR
68.5 in.
(1740 mm)
72 in.
(1829 mm)
47.5 in.
(1207 mm)
28.38 in.
(721 mm)
22 in.
(559 mm)
19 in.
(483 mm)
19 in.
(483 mm)
68.69 in.
(1744 mm)
60.25 in.
(1530 mm)
8.63 in.
(218 mm)
6
1
2
3
4
5
7
8
9
10

© Copyright, Alliance Laundry Systems LLC –DO NOT COPY or TRANSMIT
Installation
F232102
18
Figure 5
CFS211N
1Recirculation Port 6Standard Drain Outlet
2Hot Water Inlet 7Reuse Drain Outlet (Optional)
3Vent 8External Supply Signals
4Cold Water Inlet 9Main Power
5Steam Inlet (Optional) 10 Extra Fill Valve (Optional)
88 in.
(2235 mm)
81 in.
(2057 mm)
36.88 in.
(936 mm)
38.91 in.
(981 mm)
53.5 in.
(1359 mm)
86.1 in.
(2190 mm)
47.19 in.
(1198 mm) 43.19 in.
(1096 mm)
68.69 in.
(1744 mm)
64.5 in.
(1639 mm) 63.63 in.
(1615 mm)
250 POUND CAPACITY MODELS WITH FORWARD TILT OPTION
FRONT SIDE
REAR
76 in.
(1930 mm)
13.5 in.
(343 mm) 25.5 in.
(648 mm)
40.69 in.
(1034 mm)
12.5 in.
(572 mm)
80.19 in.
(2037 mm)
28.38 in.
(721 mm)
22 in.
(559 mm)
35.91 in.
(912 mm)
28 in.
(712 mm)
84.63 in.
(2149 mm)
68.38 in.
(1737 mm)
66.25 in.
(1683 mm)
14.63 in.
(370 mm)
63.5 in.
(1613 mm)
76 in.
(1930 mm)
83.5 in.
(2121 mm)
74.41 in.
(1736 mm)
76
1
23
45
10
9
8
