Alliance Laundry Systems UW150PV Series Programming manual

www.comlaundry.com
PHM1394C
123
456
789
10
Part No. F232329
March 2007
Troubleshooting
Washer-Extractor
Pocket Hardmount
UW150PV
Refer to Page 8 for Model Numbers

© Copyright 2007, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without
the expressed written consent of the publisher.
F232329 1
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Table of
Contents
Section 1 – Safety Information ...............................................................3
General Safety Precautions....................................................................3
Important Safety Instructions ................................................................4
Locating an Authorized Servicer...........................................................6
Section 2 – Introduction ..........................................................................7
Customer Service...................................................................................7
Nameplate Location...............................................................................7
Model Identification ..............................................................................8
Section 3 – Troubleshooting....................................................................9
1. WE-6 Control Has No Visible Display.......................................10
2. No Fill Analysis ..........................................................................14
3. Water Runs Continuously into the Washer-Extractor
(Either when the machine is in cycle or not)18
4. Door Lock Switch Analysis ........................................................22
5. No Fuseboard Functions .............................................................26
6. No Motor Operation (With No AC Drive Fault) ........................30
A-B 1336 Control Logic .............................................................31
7. No Motor Operation (With AC Drive Fault) ..............................34
AC Drive Fault Codes and Troubleshooting Information ..........35
8. The Motor is Running, but at an Abnormal Speed .....................36
9. No Spin .......................................................................................37
10. Fill Alarm Analysis.....................................................................38
11. Empty Alarm Analysis................................................................42
12. Automatic Supply Dispenser Analysis .......................................46
13. No Keypad Functions..................................................................47
14. Door Unlocking Function ...........................................................48
15. Excessive Cycle Time.................................................................52
16. Excessive Vibration and/or Noise During Spin ..........................53
17. Stop/Done Situation in Mid Cycle..............................................54
18. Power Wait Situation in Mid Cycle ............................................55
19. External Supply Pumps Turning on in Mid Cycle Without Being
Programmed to Do So.................................................................56
20. Rotation Sensor Analysis ............................................................57

2F232329
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Notes

F232329 3
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Section 1
Safety Information
Throughout this manual and on machine decals, you will find precautionary statements (“CAUTION,”
“WARNING,” and “DANGER”) followed by specific instructions. These precautions are intended for the personal
safety of the operator, user, servicer and those maintaining the machine.
aDANGER
Danger indicates the presence of a hazard that will cause severe personal injury, death or substantial property
damage if the danger is ignored.
aWARNING
Warning indicates the presence of a hazard that can cause severe personal injury, death or substantial property
damage if the warning is ignored.
aCAUTION
Caution indicates the presence of a hazard that will or can cause minor personal injury or property damage if the
caution is ignored.
Additional precautionary statements (“IMPORTANT” and “NOTE”) are followed by specific instructions.
IMPORTANT
The word “IMPORTANT” is used to inform the reader of specific procedures where minor machine damage will
occur if the procedure is not followed.
NOTE
The word “NOTE” is used to communicate installation, operation, maintenance or servicing information that is
important but not hazard related.
General Safety Precautions
In the interest of safety, some general precautions relating to the operation of this machine follow.
• Failure to install, maintain and/or operate this product according to the manufacturer’s
instructions may result in conditions which can produce serious injury, death and/or property
damage.
• Do not repair or replace any part of the product or attempt any servicing unless specifically
recommended or published in this Service Manual and unless you understand and have the
skills to carry out the servicing.
• Whenever ground wires are removed during servicing, these ground wires must be
reconnected to ensure that the product is properly grounded and to reduce the risk of fire,
electric shock, serious injury or death.
W006R2
WARNING

4F232329
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Information
Always contact your dealer, distributor, service agent or the manufacturer about any problems or conditions you do
not understand.
Important Safety Instructions
1. Read all instructions before using the washer-extractor.
2. Refer to the GROUNDING INSTRUCTIONS in the INSTALLATION manual (supplied with your washer-
extractor) for the proper grounding of the washer-extractor.
3. Do not wash textiles that have been previously cleaned in, washed in, soaked in or spotted with gasoline, dry-
cleaning solvents or other flammable or explosive substances. They give off vapors that could ignite or
explode.
4. Do not add gasoline, dry-cleaning solvents or other flammable or explosive substances to the wash water.
These substances give off vapors that could ignite or explode.
5. Under certain conditions, hydrogen gas may be produced in a hot water system that has not been used for two
weeks or more. HYDROGEN GAS IS EXPLOSIVE. If the hot water system has not been used for such a
period, before using a washer-extractor, turn on all hot water faucets and let the water flow from each for
several minutes. This will release any accumulated hydrogen gas. The gas is flammable. Do not smoke or use
an open flame during this time.
To reduce the risk of electric shock, fire, explosion, serious injury or death:
• Disconnect electric power to the washer-extractor before servicing.
• Never start the washer-extractor with any guards/panels removed.
• Whenever ground wires are removed during servicing, these ground wires must be
reconnected to ensure that the washer-extractor is properly grounded.
W460
WARNING
Repairs that are made to your products by unqualified persons can result in hazards due to
improper assembly or adjustments subjecting you or the inexperienced person making such
repairs to the risk of serious injury, electrical shock or death.
W007
WARNING
If you or an unqualified person perform service on your product, you must assume the
responsibility for any personal injury or property damage which may result. The manufacturer
will not be responsible for any injury or property damage arising from improper service and/or
service procedures.
W008
WARNING
To reduce the risk of fire, electric shock, serious injury or death to persons when using your
washer, follow these basic precautions:
W023E
WARNING

F232329 5
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Information
6. Do not allow children to play on or in a washer-extractor. Close supervision of children is necessary when the
washer-extractor is used near children.
7. Before the washer-extractor is removed from service or discarded, remove the door to the washing
compartment.
8. Do not reach into the washer-extractor if the wash basket is moving.
9. Do not install or store the washer-extractor where it will be exposed to water and/or weather.
10. Do not tamper with the washer-extractor’s controls.
11. Do not repair or replace any part of the washer-extractor or attempt any servicing unless specifically
recommended in the user-maintenance instructions or in published user-repair instructions that the user
understands and has the skills to carry out.
12. To reduce the risk of an electrical shock or fire, DO NOT use an extension cord or an adapter to connect the
washer-extractor to an electrical power source.
13. Use the washer-extractor only for its intended purpose, washing clothes.
14. ALWAYS disconnect the washer-extractor from its electrical supply before attempting any service.
15. Install the washer-extractor according to the INSTALLATION INSTRUCTIONS. All connections for water,
drain, electrical power and grounding must comply with local codes and, when required, be made by licensed
personnel.
16. To reduce the risk of fire, textiles which have traces of any flammable substances such as vegetable oil,
cooking oil, machine oil, flammable chemicals, thinner, etc. or anything containing wax or chemicals such as
in mops or cleaning cloths, must not be put into the washer-extractor. These flammable substances may cause
the fabric to ignite.
17. Do not use fabric softeners or products to eliminate static unless recommended by the manufacturer of the
fabric softener or product.
18. Keep the washer-extractor in good condition. Bumping or dropping the washer-extractor can damage its safety
features. If this occurs, have the washer-extractor checked by a qualified service person.
19. Replace worn power cords and/or loose plugs.
20. Be sure that water connections have a shut-off valve and that fill hose connections are tight. CLOSE the shut-
off valves at the end of each wash day.
21. The loading door MUST BE CLOSED any time the washer-extractor is to fill, tumble or spin. DO NOT by-
pass the loading door switch and permit the washer-extractor to operate with the loading door open.
22. Always read and follow the manufacturer’s instructions on packages of laundry and cleaning aids. Heed all
warnings and precautions. To reduce the risk of poisoning or chemical burns, keep them out of the reach of
children at all times (preferably in a locked cabinet).
23. Always follow the fabric care instructions supplied by the textile manufacturer.
24. Never operate the washer-extractor with any guards and/or panels removed.
25. DO NOT operate the washer-extractor with missing or broken parts.
26. DO NOT by-pass any safety devices.
27. Failure to install, maintain and/or operate this washer-extractor according to the manufacturer's instructions
may result in conditions that can produce bodily injury and/or property damage.
NOTE: The WARNING and IMPORTANT SAFETY INSTRUCTIONS appearing in this manual are not
meant to cover all possible conditions and situations that may occur. Common sense, caution and care must
be exercised when installing, maintaining and operating the washer-extractor.
Any problems or conditions not understood should be reported to the dealer, distributor, service agent or the
manufacturer.

6F232329
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Information
Locating an Authorized Servicer
Alliance Laundry Systems is not responsible for personal injury or property damage resulting from improper
service. Review all service information before beginning repairs.
Warranty service must be performed by an authorized technician, using authorized factory parts. If service is
required after the warranty expires, Alliance Laundry Systems also recommends contacting an authorized technician
and using authorized factory parts.

F232329 7
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Section 2
Introduction
Customer Service
Alliance Laundry Systems is not responsible for
personal injury or property damage resulting from
improper service. Review all service information
before beginning repairs.
If literature or replacement parts are required, contact
the source from whom the machine was purchased or
contact Alliance Laundry Systems at [phone]
for the name of the nearest authorized parts distributor.
For technical assistance, call [phone].
Nameplate Location
When calling or writing about your product, be sure to
mention model and serial numbers. Model and serial
numbers are located on nameplate(s) as shown.
PHM2521P

8F232329
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Introduction
Model Identification
Information in this manual is applicable to these washer-extractors.
UW150PV

F232329 9
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Section 3
Troubleshooting
To reduce the risk of electrical shock, fire, explosion, serious injury or death:
• Disconnect electrical power to the washer-extractor before servicing it.
• Close the gas shut-off valve to the washer-extractor (when applicable) before servicing it.
• Never start the washer-extractor with any guards/panels removed.
• Whenever ground wires are removed during servicing, these ground wires must be
reconnected to ensure that the washer-extractor is properly grounded.
W461R1
WARNING

10 F232329
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
1. WE-6 Control Has No Visible Display
THE WE-6
CONTROL HAS NO
VISIBLE DISPLAY.
IS
THE
MAIN POWER
CIRCUIT
BREAKER
ON?
TURN ON THE MAIN
POWER CIRCUIT
BREAKER.
NO
YES
MAKE SURE THAT
THE WIRING CONNECTIONS
ARE SECURE.
NO
NO
IS
THERE
VOLTAGE (220
VOLTS) BETWEEN
THE FU1A AND
FU1B
FUSES?
YES
YES
RESET AND RETURN (EITHER BY
PULLING OR BY TWISTING AND
PULLING) THE E-STOP SWITCH SB1. IF,
AFTER RESETTING AND RETURNING,
THERE IS STILL NO VOLTAGE,
REPLACE THE E-STOP SWITCH SB1.
IS
THERE
VOLTAGE (220 VOLTS)
FROM INTO AND OUT OF THE
E-STOP SWITCH SB1 TO
THE ACN ON
THE FUSEBOARD?
NO
IS
THERE
VOLTAGE
(220 VOLTS) ON THE
J2 WHITE TRANSFORMER
PLUG ON THE
FUSEBOARD
BETWEEN PINS 1
AND 4?
RETURN TO THE TOP. CHECK EACH OF THE
ABOVE STEPS CAREFULLY.
ALSO, ON THE J2 WHITE TRANSFORMER
PLUG ON THE FUSEBOARD, MAKE SURE
THAT THERE IS VOLTAGE BETWEEN PIN 1
TO GROUND AND PIN 4 TO GROUND.
IS
THERE
10VDC BETWEEN
THE +10VDC
MALE SPADE
AND THE
GROUND?
IS
THERE
CONTINUITY
BETWEEN
THE
FUSES?
IS THERE 10VDC ON THE RIBBON CABLE
LOCATED BETWEEN THE FUSEBOARD AND
THE WE-6 COMPUTER? IF NOT, REPLACE IT.
IF THERE IS 10VDC ON THE RIBBON CABLE,
DISCONNECT ALL OF THE CABLES FROM THE
WE-6 COMPUTER EXCEPT THE GROUND WIRE
AND THE RIBBON CABLE FROM THE
FUSEBOARD. IF THE WE-6 STILL DOESN'T
SHOW A DISPLAY, THE FUSEBOARD MAY NOT
BE WORKING PROPERLY. CONTACT THE
FACTORY BEFORE REPLACING IT.
IF THE FUSEBOARD DOES SHOW A DISPLAY,
RECONNECT THE RIBBON CABLE.
NOTE: IF THE J1 RIBBON CABLE IS INSTALLED
INCORRECTLY, THERE WILL BE NO DISPLAY.
CHECK THE FU4 (125MA) FUSE
LOCATED BEHIND THE
TRANSFORMER. IF THE FUSE IS
BLOWN, REPLACE IT. IF THE FUSE
ISN'T BLOWN, REPLACE THE
FUSEBOARD.
REPLACE THE
FUSES.
YES
YES
NO
YES
NO
1
2
3
4
5
PHM1989S

F232329 11
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
Please refer to the following 2 pages for wiring diagram information.

12 F232329
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
WE-6 Control Has No Visible Display (Sheet 1 of 2)
NOTE: Refer to the wiring diagram supplied with your machine.
1

F232329 13
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
WE-6 Control Has No Visible Display (Sheet 2 of 2)
PHM1990S
2002037(D)
5
2
4
3

14 F232329
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
2. No Fill Analysis
IS THERE WATER
COMING IN
THROUGH THE
WATER SUPPLY
LINES?
CHECK THE MAIN WATER
VALVE SHUT-OFFS, INSIDE
OF THE WATER HOSES AND
IN-LINE STRAINERS.
NO
ARE ANY OF
THE LIGHTS ON
THE
FUSEBOARD
TURNED ON?
YES
3
ARE THE CORRECT LIGHTS ON
THE FUSEBOARD LIT THAT
CORRESPOND TO THAT WHICH
IS DISPLAYED ON THE CONTROL
MODULE DECAL (E.G., IF COLD
SPRAY AND COLD FILL ARE
DISPLAYED ON THE DECAL, CS
AND CF SHOULD BE LIT ON THE
FUSEBOARD)?
YES
ARE THE FUSES ON
THE FUSEBOARD
(THAT
CORRESPOND TO
THE LIGHTS THAT
SHOULD BE LIT)
INTACT?
NO
REPLACE THE
FUSES.
NO
IS THE RIBBON
CABLE BETWEEN
THE
MICROPROCESSOR
AND THE
FUSEBOARD
INTACT?
YES
REPLACE THE
RIBBON CABLE.
NO
THERE IS A
POSSIBILITY THAT
EITHER THE
FUSEBOARD OR
MICROCOMPUTER MAY
NEED REPLACING.
CONTACT THE
CUSTOMER SERVICE
DEPARTMENT.
YES
READ THE VOLTAGE AT
THE CORRESPONDING
WATER VALVE
BETWEEN THE TWO
WIRES. IS THERE
VOLTAGE (220 VOLTS)?
1
2
YES
NO
IS THERE
MAGNETISM
WITHIN THE
CENTER WALLS
OF THE
SOLENOID
VALVE?
YES
YES
NO
POINT A
REFER TO THE "NO
FUSEBOARD FUNCTIONS"
FLOWCHART AT POINT B.
NO
REPLACE THE
VALVE'S SOLENOID.
REPLACE OR REPAIR THE
MECHANICAL PARTS OF THE
VALVE.
CHECK THE WIRING
BETWEEN THE
FUSEBOARD AND J15.
CHECK THE WIRING
BETWEEN J15 AND THE
WATER VALVES.
PHM1991S

F232329 15
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
Please refer to the following 2 pages for wiring diagram information.

16 F232329
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
No Fill Analysis (Sheet 1 of 2)
NOTE: Refer to the wiring diagram supplied with your machine.

F232329 17
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
No Fill Analysis (Sheet 2 of 2)
PHM1992S
2002037(D)
1
3
2

18 F232329
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
3. Water Runs Continuously into the Washer-Extractor
(Either when the machine is in cycle or not)
NO
3
TURN THE MAIN
POWER TO THE
MACHINE OFF.
DOES THE WATER
SHUT OFF?
THIS IS AN ELECTRICAL ISSUE.
DOES THE CORRESPONDING
LIGHT ON THE FUSEBOARD STAY
ON CONTINUOUSLY AFTER THE
DOOR IS CLOSED AND THE ACH
HAS BEEN ENERGIZED (E.G., IF
THE COLD SPRAY VALVE IS IN
QUESTION, IS THE CS LIGHT
STAYING ON)?
YES
THIS IS A MECHANICAL ISSUE.
REPLACE OR REPAIR THE
MECHANICAL PARTS OF THE
VALVE.
CHECK FOR MISWIRING AT THE
FUSEBOARD OR FOR A SHORT
ON THE WIRE THAT
ENERGIZES THE RESPECTIVE
VALVE (E.G., IF YV1 STAYS
ENERGIZED BUT THE COLD
FILL LIGHT ISN'T LIT ON THE
FUSEBOARD, CHECK THE
WIRING BETWEEN J5-1-2 AND
J15-1-1).
NO
Note: This information applies to the four main fill valves as well as the 4-way supply valves.
The first task in this process is to determine which valve is staying on. If it is one of the four
main valves (i.e., hot spray, hot fill, cold spray or cold fill), this may be done by individually
shutting off the water supply to each valve. If it is a supply valve that is staying open, find
the location in the dry supply box where the water is flushing into and follow the hose back
to the solenoid. Once the valve has been identified, proceed as follows:
YES
CHECK THE RIBBON CABLE
BETWEEN THE COMPUTER AND
THE FUSEBOARD. REPLACE THE
RIBBON CABLE IF NEEDED. IF
THE RIBBON CABLE IS OKAY,
REPLACE THE COMPUTER.
YES
NO
THERE IS A POSSIBILITY THAT THE
FUSEBOARD IS CONTAMINATED. TRY
CLEANING IT. IF THE TEST MENTIONED
IN THE PREVIOUS STEP IS STILL
UNSUCCESSFUL, REPLACE THE
FUSEBOARD.
1
2
PHM1993S
MAKE SURE
THAT THE MAIN POWER
TO THE MACHINE HAS BEEN TURNED
OFF. REMOVE THE WIRES BETWEEN J4-2
AND J5-2 ON THE INTERFACE BOARD.
PLACE A JUMPER BETWEEN THE TWO
WIRES. DISCONNECT THE RIBBON
CABLE BETWEEN THE COMPUTER AND
THE FUSEBOARD. TURN ON THE
MACHINE'S MAIN POWER. DOES THE
RESPECTIVE LIGHT ON THE
FUSEBOARD COME ON
IMMEDIATELY?
