Allied Telesis CentreCOM AT-MR118FT User manual

Allied
Telesyn
CentreCOM™
AT-MR118FT
AT-MR128FT
Micro Repeaters
User Manual
StockCheck.com

 Copyright 1994 Allied Telesyn International Corp.
All rights reserved. No part of this publication may be reproduced without prior written
permission from Allied Telesyn International Corp.
Allied Telesyn International Corp. reserves the right to make changes in specifications and
other information contained in this document without prior written notice. The information
provided herein is subject to change without notice. In no event shall Allied Telesyn
International Corp. be liable for any incidental, special, indirect, or consequential damages
whatsoever, including but not limited to lost profits, arising out of or related to this manual
or the information contained herein, even if Allied Telesyn International Corp. has been
advised of, known, or should have known, the possibility of such damages.
Trademarks: CentreCOM is a registered trademark of Allied Telesyn International Corp.
Ethernet is a registered trademark of Xerox Corporation. UNIX is a registered trademark
of UNIX System Laboratories. Novell and NetWare are registered trademarks of Novell,
Inc. Microsoft and MS-DOS are registered trademarks and LAN Manager and Windows for
Workgroups are trademarks of Microsoft Corporation. 3Com is a registered trademark of
3Com.PC-NFSisatrademarkofSunMicrosystems,Inc.PC/TCPisaregisteredtrademark
of FTP Software, Inc.
StockCheck.com

iii
Electrical Safety and Installation
Requirements
RADIATED ENERGY
U.S. Federal Communications
Note: This equipment has been tested and found to comply with the limits for a Class A
digital device pursuant to Part 15 of FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercialenvironment.Thisequipmentgenerates,uses,andcanradiateradiofrequency
and,ifnotinstalledand usedinaccordance withthisinstruction manual,maycause harmful
interference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
Note:Modifications orchangesnot expresslyapprovedof bythemanufacturerortheFCC,
can void your right to operate this equipment.
Canadian Department of Communications
This digital apparatus does not exceed the Class A limits for radio noise emissions from
digital apparatus as set out in the radio interference regulations of the Canadian
Department of Communications.
Leprésentapparielnumériquen'émetpasdebruitsradioélectriquesdépassantleslimites
appicables aux appariels numériques de Classe A. Prescrites dans le réglement sur le
brouillage radioélectrique edicte par le minestére des Communications Du Canada.
SAFETY
WARNING: ELECTRICAL NOTICES
ELECTRIC SHOCK HAZARD
TopreventELECTRICshock,donotremovecover.Nouser-serviceablepartsinside.This
unit contains HAZARDOUS VOLTAGES and should only be opened by a trained and
qualified technician. To avoid the possibility of ELECTRIC SHOCK disconnect electric
power to the product before connecting or disconnecting the LAN cables.
LIGHTNING DANGER
DANGER: DO NOT WORK onequipment orCABLESduringperiods of LIGHTNING
ACTIVITY.
CAUTION: POWER CORD IS USED AS A DISCONNECTION DEVICE.
TO DE-ENERGISE EQUIPMENT disconnect the power cord.
INSTALLATION
ELECTRICAL — AUTO VOLTAGE ADJUSTMENT
This product will automatically adjust to any voltage between the ranges shown on the
label.
ELECTRICAL — TYPE CLASS 1 EQUIPMENT
THISEQUIPMENTMUSTBEEARTHED. Powerplugmustbeconnectedto aproperly
wiredearthground socketoutlet.Animproperlywiredsocketoutletcouldplacehazardous
voltages on accessible metal parts.
ELECTRICAL — CORD NOTICE
Use power cord, maximum 4.5 meters long, rated 6 amp minimum, 250V, made of HAR
cordage molded IEC 320 connector on one end and on the other end a plug approved by
the country of end use.
CAUTION: Air vents must not be blocked and must have free access to the room ambient
air for cooling.
Operating temperature
This product is designed for a maximum ambient temperature of 50 ° C.
All Countries: Install product in accordance with local and National Electrical Codes.
!
StockCheck.com

iv
SICHERHEIT
ACHTUNG: GEFÄHRLICHE SPANNUNG
DasGehäusenichtöffnen.DasGerätenthältkeine vom Benutzer wartbaren Teile. Das
Gerät steht unter Hochspannung und darf nur von qualifiziertem technischem
Personal geöffnet werden. Vor Anschluß der LAN-Kabel, Gerät vom Netz trennen.
GEFAHR DURCH BLITZSCHLAG
GEFAHR: Keine Arbeiten am Gerät oder an den Kabeln während eines Gewitters
ausführen
VORSICHT: DAS NETZKABEL DIENT ZUM TRENNEN DER
STROMVERSORGUNG. ZUR TRENNUNG VOM NETZ, KABEL AUS DER
STECKDOSE ZIEHEN.
INSTALLATION
AUTOMATISCHE SPANNUNGSEINSTELLUNG
Dieses Gerät stellt sich automatisch auf die auf dem Etikett aufgeführten
Spannungswerte ein.
KLASSE 1 GERÄTE
DIESE GERÄTE MÜSSEN GEERDET SEIN. Der Netzstecker darf nur mit einer
vorschriftsmäßig geerdeten Steckdose verbunden werden. Ein unvorschriftsmäßiger
Anschluß kann das Metallgehäuse Teile unter gefährliche elektrische Spannungen
setzen.
NETZKABEL
Das Netzkabel sollte eine maximale Länge von 4.5 Metern, einen Nennwert von
mindestens 6 A und 250 V haben, aus HAR-Material hergestellt und mit einer gepreßten,
IEC 320 entsprechenden, Anschlußverbindung an einem Ende, und am anderen Ende mit
einem im Land des Endverbrauchers geprüften Stecker ausgestattet sein.
VORSICHT : Die Entlüftungsöffnungen dürfen nicht versperrt sein und müssen zum
Kühlen freien Zugang zur Raumluft haben.
BETRIEBSTEMPERATUR
Dieses Produkt wurde für den Betrieb in einer Umgebungstemperatur von nicht mehr als
50 ° C entworfen.
Alle Länder: Installation muß örtlichen und nationalen elektrischen Vorschriften
entsprechen.
STRÅLINGSENERGI
Dette kommercielle produkt opfylder de krav, der i USA stilles til udstyr af Klasse A.
SIKKERHED
ADVARSEL: ELEKTRISK FORH OLDSREGLER RISIKO FOR ELEKTRISK
STØD RISIKO FOR ELEKTRISK STØD
For at forebygge ELEKTRISK stød, undlad at åbne apparatet. Der er ingen indre dele,
der kan repareres af brugeren. Denne enhed indeholder LIVSFARLIGE
STRØMSPÆNDINGER og bør kun åbnes af en uddannet og kvalificeret tekniker. For at
undgå risiko for ELEKTRISK STØD, afbrydes den elektriske strøm til produktet, før
LAN-kablerne monteres eller afmonteres.
FARE UNDER UVEJR
FARE: UNDLADat arbejde på udstyr eller KABLER iperiodermedLYNAKTIVITET.
ADVARSEL: DEN STRØMFØRENDE LEDNING BRUGES TIL AT AFBRYDE
STRØMMEN. SKAL STRØMMEN TIL APPARATET AFBRYDES, tages ledningen
ud af stikket.
INSTALLATION
ELEKTRISK — AUTOMATISK SPAENDINGSREGULERING
Dette apparat vil automatisk tilpasse sig enhver spænding indenfor de værdier, der er
angivet på etiketten.
ELEKTRISK — KLASSE 1-UDSTYR
DETTE UDSTYR KRAEVER JORDFORBINDELSE. Stikket skal være forbundet
meden korrekt installeret jordforbunden stikkontakt.En ukorrekt installeret stikkontakt
kan sætte livsfarlig spænding til tilgængelige metaldele.
!
!
StockCheck.com

v
ELEKTRISK — LEDNING
Anvendledning afmaksimum4.5 meterslængde,med enkapacitetpå minimum 6amp,250
v, bestående af en IEC 320 connector med indstøbt HAR ledning i den ene ende og et stik
i den anden ende godkendt der er af myndighederne i brugerlandet.
ADVARSEL : Ventilationsåbninger må ikke blokeres og skal have fri adgang til den
omgivende luft i rummet for afkøling.
BETJENINGSTEMPERATUR
Dette apparat er konstrueret til en omgivende temperatur på maksimum 50 grader C.
ALLE LANDE: Installation af produktet skal ske i overensstemmelse med lokal og
national lovgivning for elektriske installationer.
STRALINGSENERGIE
Dit handelsprodukt werd getest en voldoet aan de Amerikaanse vereisten voor een
klasse A toestel.
VEILIGHEID
WAARSCHUWINGEN MET BETREKKING TOT ELEKTRICIT EIT
WAARSCHUWING: GEVAAR VOOR ELEKTRISCHE SCHOKKEN
Gelieve het deksel niet te verwijderen, teneinde ELEKTRISCHE schokken te
voorkomen.Binnenin bevindenzichgeen onderdelendiedoor degebruikerkunnenworden
onderhouden.DittoestelstaatonderGEVAARLIJKESPANNINGenmagalleenworden
geopend door een daartoe opgeleide en bevoegde technicus. Om het gevaar op
ELEKTRISCHE SCHOKKEN te vermijden, moet u het toestel van de stroombron
ontkoppelen alvorens de LAN-kabels te koppelen of ontkoppelen.
WAARSCHUWINGEN:
GEVAAR VOOR BLIKSEMINSLAG
GEVAAR: NIET aan toestellen of KABELS WERKEN bij BLIKSEM.
WAARSCHUWING: HET TOESTEL WORDT UITGESCHAKELD DOOR DE
STROOMKABEL TE ONTKOPPELEN. OM HET TOESTEL STROOMLOOS TE
MAKEN: de stroomkabel ontkoppelen.
INSTALLATIE
AELEKTRISCH AUTOMATISCHE AANPASSING VAN DE SPANNINGL
Dit toestel past zich automatisch aan elke spanning aan, tussen de waarden op het label
vermeld.
ELEKTRISCHE TOESTELLEN VAN KLASSE 1
DIT TOESTEL MOET GEAARD WORDEN. Destekkermoetaangeslotenzignopeen
juist geaarde contactdoos. Een onjuist geaarde contactdoos. Een onjuist geaarde
contactdoos kan de metalen onderdelen onderdelen waarmee de gebruiker eventueel in
aanraking komt onder gevaarlijke spanning stellen.
ELEKTRISCHE — SNOEREN
Gebruik een elektrisch snoer, maximum 4,5 meter lang, berekend voor ten minste 6
ampère, 250 V, uit HAR vervaardigd, met aan het ene uiteinde een gevormde IEC 320
stekker en aan het andere uiteinde een stekker die goedgekeurd is door het land waar het
toestel zal worden gebruikt.
WAARSCHUWINGEN:
De ventilatiegaten mogen niet worden gesperd en moeten de
omgevingslucht ongehinderd toelaten voor afkoeling.
BEDRIJFSTEMPERATUUR
De omgevingstemperatuur voor dit produkt mag niet meer bedragen dan 50 graden
Celsius.
ALLE LANDEN: het toestel installeren overeenkomstig de lokale en nationale
elektrische voorschriften.
!
StockCheck.com

vi
ENERGIE RAYONNEE
Ce matériel a été testé et est certifié conforme par la réglementation américaine aux
normes définies pour les appareils de classe A.
SECURITE
INFORMATION SUR L’ELECTRICITE
AVERTISSEMENT: DANGER D’ELECTROCUTION
Pour empêcher les dangers d’ELECTROCUTION, ne pas enlever le couvercle.
L’équipementnecontientaucunélémentréparableparl’utilisateur.Cetappareilcomprend
des TENSIONS DANGEREUSES et ne doit être ouvert que par un technicien dûment
qualifié. Pour éviter tout risque d’ELECTROCUTION, débrancher l’appareil de la prise
de courant avant de connecter ou de déconnecter les câbles LAN.
DANGER DE FOUDRE
DANGER: DANGER NE PAS MANIER l’équipement ou les CABLES pendant les
périodes d’activité orageuse.
ATTENTION: LE CORDON D’ALIMENTATION SERT DE MISE HORS CIRCUIT
POUR COUPER L’ALIMENTATION DE L’APPAREIL, débranchez le cordon.
INSTALLATION
ELECTRICITE—REGLAGE DE TENSION AUTOMATIQUE
Ce produit peut s’ajuster automatiquement sur n’importe quelle tension comprise dans la
plage indiquée sur le label.
ELECTRICITE—EQUIPEMENT DE CLASSE 1
CET APPAREIL DOIT ETRE MIS A LA TERRE. La prise de courant doit être
branchée dans une prise femelle correctement mise à la terre. Sinon, des tensions
dangereuses risqueraient d’atteindre les pièces métalliques accessibles à l’utilisateur.
ELECTRICITE—INFORMATION SUR LE CORDON
Utiliser un cordon secteur de 4,5 mètres de long maximum, calibré à 6 ampères minimum,
250V, et fabriqué en câblage HAR avec connecteur IEC 32C moulé à une extrémité et à
l’autre extrémité, une prise de courant mâle répondant aux normes du pays d’utilisation.
INSTRUCTIONS DE MONTAGE ATTENTION: Ces modèles sont destiné à
functionner en position horizontale. L’appareil NE DOIT PAS être utilisé en MONTAGE
VERTICAL sans employer un chassis de montage vertical.
ATTENTION: Ne pas bloquer les fentes d’aération, ce qui empêcherait l’air ambiant de
circuler librement pour le refroidissement.
TEMPERATURE DE FONCTIONNEMENT
Ce produit est capable de tolérer une température ambiante maximum de 50 degrés
Celsius
POUR TOUS PAYS: Installer le produit conformément aux normes électriques
nationales et locales.
SÄTEILYENERGIA
Tämä kaupallinen tuote on testattu ja noudattaa Yhdysvaltojen vaatimuksia
luokan A laitteelle.
TURVALLISUUS
SÄHKÖÖN LIITTYVIÄ HUOMAUTUKSIA
VAROITUS: SÄHKÖISKUVAARA
Estääksesi SÄHKÖISKUN älä poista kantta. Sisällä ei ole käyttäjän huollettavissa
olevia osia. Tämä laite sisältää VAARALLISIA JÄNNITTEITÄ ja sen voi avata vain
koulutettu ja pätevä teknikko. Välttääksesi SÄHKÖISKUN mahdollisuuden katkaise
sähkövirta tuotteeseen ennen kuin liität tai irrotat paikallisverkon (LAN) kaapelit.
SALAMANISKUVAARA
HENGENVAARA:ÄLÄTYÖSKENTELE laitteiden tai KAAPELEIDEN KANSSA
SALAMOINNIN AIKANA.
!
StockCheck.com

vii
HUOMAUTUS: VIRTAJOHTOA KÄYTETÄÄN
VIRRANKATKAISULAITTEENA. VIRTA KATKAISTAAN irrottamalla
virtajohto.
ASENNUS
SÄHKÖ —AUTOMAATTINEN JÄNNITTEENSÄÄTÖ
Tämä tuote säätää automaattisesti mihin tahansa jännitteeseen ohjetarrassa
annettujen arvojen välillä.
SÄHKÖ —TYYPPILUOKAN 1 LAITTEET
TÄMÄ LAITE TÄYTYY MAADOITTAA. Pistoke täytyy liittää kunnollisesti
maadoitettuun pistorasiaan. Virheellisesti johdotettu pistorasia voi altistaa metalliosat
vaarallisille jännitteille.
SÄHKÖ —JOHTOON LIITTYVÄ HUOMAUTUS
Käytä seuraavanlaista virtajohtoa: maksimipituus 4,5 metriä, minimiteho 6 ampeeria,
250 V, valmistettu HAR-johdostosta, muovattu IEC 320 -liitin toisessa päässä ja
käyttömaassa hyväksytty pistoke toisessa päässä.
HUOMAUTUS: Ilmavaihtoreikiä ei pidä tukkia ja niillä täytyy olla vapaa yhteys
ympäröivään huoneilmaan, jotta ilmanvaihto tapahtuisi.
KÄYTTÖLÄMPÖTILA
Tämä tuote on suunniteltu ympäröivän ilman maksimilämpötilalle 50 ° C.
KAIKKI MAAT: Asenna tuote paikallisten ja kansallisten
sähköturvallisuusmääräysten mukaisesti.
ENERGIA IRRADIATA
Questo prodotto commerciale è stato collaudato e risponde ai requisiti U.S.A. per i
dispositivi di classe A.
NORME DI SICUREZZA
AVVERTENZE ELETTRICHE
PERICOLO DI SCOSSE ELETTRICHE
Per evitare SCOSSE ELETTRICHE non asportare il coperchio. Le componenti interne
non sono riparabili dall’utente. Questa unità ha TENSIONI PERICOLOSE e va aperta
solamente da un tecnico specializzato e qualificato. Per evitare ogni possibilità di SCOSSE
ELETTRICHE,interromperel’alimentazionedel dispositivo prima di collegare o staccare
i cavi LAN.
PERICOLO DI FULM INI
PERICOLO: NONLAVORAREsuldispositivoosui CAVIdurantePRECIPITAZIONI
TEMPORALESCHE.
ATTENZIONE: ILCAVODIALIMENTAZIONEÈUSATOCOMEDISPOSITIVODI
DISATTIVAZIONE. PER TOGLIERE LA CORRENTE AL DISPOSITIVO staccare il
cavo di alimentazione.
INSTALLAZIONE
ELETTRICITÀ—REGOLAZIONE AUTOMATICA DELLA TENSIONE
Questoprodottoregolerà automaticamente la tensioneadunvalorecompresonella gamma
indicata sull’etichetta.
ELETTRICITÀ—DISPOSITIVI DI CLASSE 1
QUESTO DISPOSITIVO DEVE AVERE LA MESSA A TERRA. La spina deve essere
inserita in una presa di corrente specificamente dotata di messa a terra. Una presa non
cablata in maniera corretta rischia di scaricare una tensione pericolosa su parti metalliche
accessibili.
ELETTRICITÀ—AVVERTENZA SUL CAVO
Usare un cavo della lunghezza massima di metri 4,5, con capacità minima di 6 A, 250 V, di
filo HAR, dotato di connettore stampato IEC 320 ad un’estremità e di spina approvata dal
paese di destinazione all’altra.
ATTENZIONE: Le prese d’aria non vanno ostruite e devono consentire il libero ricircolo
dell’aria ambiente per il raffreddamento.
!
!
StockCheck.com

viii
TEMPERATURA DI FUNZIONAMENTO
Questo prodotto è concepito per una temperatura ambientale massima di 50 gradi
centigradi.
TUTTI I PAESI: installare il prodotto in conformità alle vigenti normative elettriche
nazionali.
UTSTRÅLT ENERGI
Dette kommersielle produktet har blitt testet og er i samsvar med amerikanske krav
for et A-Klasse apparat.
SIKKERHET
ELEKTRISKE MEDDELELSE
ADVARSEL: FARE FOR ELEKTRISK SJOKK
For å unngå ELEKTRISK sjokk, må dekslet ikke tas av. Det finnes ingen deler som du
kan bruke på innsiden. Denne enheten inneholder FARLIGE SPENNING, og må kun
åpnes av en opplært, kvalifisert tekniker. For å unngå muligheten av ELEKTRISK
SJOKK, må den elektriske strømmen til produktet være av når du slår LAN-ledninger av
og på.
FARE FOR LYNANTENNELSE
MÅ IKKE BRUKES på utstyr eller ledninger mens LYN-AKTIVITET er i gang.
FORSIKTIG: STRØMLEDNINGEN BRUKES TIL Å SLÅ APPARATET AV. HVIS
DU VIL DEAKTIVISERE UTSTYRET, må du fjerne strømledningen.
INSTALLASJON
ELEKTRISK—AUTO SPENNINGSTILPASSING
Dette produktet vil automatisk bli tilpasset hvilken som helst strøminnstilling i de
områdene som vises på etiketten.
ELEKTRISKE—TYPE 1. KLASSE UTSTYR
DETTE UTSTYRET MÅ JORDES. Strømkontakten må være tilkoplet en korrekt
jordetgrunnstøpselkontakt. En støpselkontakt somikkeerjordet pårettmåte,kantilføre
farlig spenning til lett tilgjengelige metalldeler.
ELEKTRISKE—MEDDELELSE OM LEDNINGER
Bruk en strømledning av maksimal størrelse 4,5 m i lengde, vurdert for minst av 6 amp,
250V, fremstilt av HAR ledning IEC 320 koplingsstykke på den ene kanten og på den
andrekanten en plugg somharblitt godkjent i detlandet hvor den siste brukerenbefinner
seg.
FORSIKTIG:
Luftventilene må ikke blokkeres og må ha fri tilgang til luft med
romtemperatur for avkjøling.
DRIFTSTEMPERATUR
Dette produktet har blitt fremstilt til bruk med maksimum romtemperatur på 50 grader
celsius.
ALLE LAND: Produktet må installeres i samsvar med de lokale og nasjonale elektriske
koder.
ENERGIA RADIADA
Este produto foi testado e atende aos requisitos para dispositivos comerciais de Classe
A nos E.U.A.
SEGURANÇA
AVISOS SOBRE CARACTERÍSTICAS ELÉTRICAS
ATENÇÃO: PERIGO DE CHOQUE ELÉTRICO
Para evitar CHOQUE ELÉTRICO, não retire a tampa. Não contém peças que possam ser
consertadaspelousuário.EsteaparelhocontémVOLTAGENS PERIGOSASesódeveser
aberto por um técnico qualificado e treinado. Para evitar a possibilidade de CHOQUE
ELÉTRICO, desconecte o aparelho da fonte de energia elétrica antes de conectar e
desconectar os cabos da LAN.
PERIGO DE CHOQUE CAUSADO POR RAIO
PERIGO: NÃO TRABALHE no equipamento ou nos CABOS durante períodos
suscetíveis de QUEDAS DE RAIO.
!
!
StockCheck.com

ix
CUIDADO: O CABO DE ALIMENTAÇÃO É UTILIZADO COMO UM DISPOSITIVO
DEDESCONEXÃO.PARADESELETRIFICAROEQUIPAMENTOdesconecteocabo
de alimentação.
INSTALAÇÃO
ELÉTRICO — AJUSTE AUTOMÁTICO DE VOLTAGEM
Este produto ajustar-se-á automaticamente a qualquer voltagem que esteja dentro dos
limites indicados no rótulo.
ELÉTRICO—EQUIPAMENTOS DO TIPO CLASSE 1
DEVE SER FEITA LIGAÇÃO DE FIO TERRA PARA ESTE EQUIPAMENTO. O
plugue deve ser conectado a uma tomada com ligação de fio terra. Tomadas sem ligação de
fio terra podem transmitir voltagens perigosas a peças metálicas expostas.
ELÉTRICO—AVISO SOBRE O CABO DE ALIMENTAÇÃO
Use cabo de alimentação com comprimento máximo de 4,5 metros, com uma capacidade
mínimade6ampe250V, fabricado de material para cabo HAR com conector moldado IEC
320emuma extremidade e, naoutraextremidade,umplugueaprovado para uso no paísem
questão .
CUIDADO:
As entradas de ar não devem ser bloqueadas e devem ter acesso livre ao ar
ambiente para arrefecimento adequado do aparelho.
TEMPERATURA DE FUNCIONAMENTO
Este produto foi projetado para uma temperatura ambiente máxima de 50 graus
centígrados.
TODOS OS PAÍSES: Instale o produto de acordo com as normas federais e locais para
instalações elétricas.
ENERGIA RADIADA
Esteproducto comercial ha sidoprobado y cumple conlas normas requeridas enlos EE.
UU. para un dispositivo de Clase A .
SEGURIDAD
AVISOS ELECTRICOS
ADVERTENCIA: PELIGRO DE ELECTROCHOQUE
Para evitar un ELECTROCHOQUE, no quite la tapa. No hay ningún componente en el
interior al cual puede prestar servicio el usuario. Esta unidad contiene VOLTAJES
PELIGROSOS y sólo deberá abrirla un técnico entrenado y calificado. Para evitar la
posibilidaddeELECTROCHOQUEdesconecte la corriente eléctrica que llega alproducto
antes de conectar o desconectar los cables LAN.
PELIGRO DE RAYOS
PELIGRO: NO REALICE NINGUN TIPO DE TRABAJO O CONEXION en los
equipos o en LOS CABLES durante TORMENTAS DE RAYOS
ATENCION: EL CABLE DE ALIMENTACION SE USA COMO UN DISPOSITIVO
DE DESCONEXION. PARA DESACTIVAR EL EQUIPO, desconecte el cable de
alimentación.
INSTALACION
ELECTRICO—AUTO-AJUSTE DE TENSION
Este producto se ajustará automáticamente a cualquier tensión entre los valores máximos
y mínimos indicados en la etiqueta.
ELECTRICO—EQUIPO DEL TIPO CLASE 1
ESTE EQUIPO TIENE QUE TENER CONEXION A TIERRA. El cable tiene que
conectarse a un enchufe con tierra debidamente instalado. Un enchufe que no está
correctamente instalado podría ocasionar tensiones peligrosas en las partes metálicas
están expuestas.
ELECTRICO—ADVERTENCIA SOBRE EL CABLE
Use un cable eléctrico con un máximo de 4,5 metros de largo, con una capacidad mínima de
6 amperios, 250 V, hecho de cable HAR, con el conector moldeado IEC 320 en un extremo
y con un enchufe que está aprobado por el país de uso final en el otro.
ATENCION:
Las aberturas para ventilación no deberán bloquearse y deberán tener
acceso libre al aire ambiental de la sala para su enfriamiento.
!
StockCheck.com

x
TEMPERATURA REQUERIDA PARA LA OPERACIÓN
Este producto está diseñado para una temperatura ambiental máxima de 50 grados C.
PARA TODOS LOS PAÍSES: Monte el producto de acuerdo con los Códigos Eléctricos
locales y nacionales.
ENERGIUTSTRÅLNING
Denna handelsprodukt har testats och befunnits vara i enlighet med U.S.A.s krav för
klass A utrustning.
SÄKERHET
TILLKÄNNAGIVANDEN BETRÄFFANDE ELEKTRICITETSRISK:
RISK FÖR ELEKTRISK STÖT
För att undvika ELEKTRISK stöt, ta ej av locket. Det finns inga delar inuti som behöver
underhållas. Denna apparat är under HÖGSPÄNNING och får endast öppnas av en
utbildad kvalificerad tekniker. För att undvika ELEKTRISK STÖT, koppla ifrån
produktens strömanslutning innan LAN-kablarna ansluts eller kopplas ur.
FARA FÖR BLIXTNEDSLAG
FARA: ARBETA EJ på utrustningen eller kablarna vid ÅSKVÄDER.
VARNING: NÄTKABELN ANVÄNDS SOM STRÖMBRYTARE
FÖR ATT KOPPLA FRÅN STRÖMMEN, dra ur nätkabeln.
INSTALLATION
ELEKTRISKT—AUTOMATISK SPÄNNINGSJUSTERING
Denna produkt justeras automatiskt till alla spänningar inom omfånget som indikeras på
produktens märkning.
ELEKTRISKT —TYP KLASS 1 UTRUSTNING
DENNA UTRUSTNING MÅSTE VARA JORDAD. Nätkabeln måste vara ansluten till
ettordentligtjordat uttag. Ett felaktigtuttagkangöraattnärliggande metalldelar utsätts
för högspänning. Apparaten skall anslutas till jordat uttag, när den ansluts till ett nätverk.
ELEKTRISKT —ANMÄRKNING BETRÄFFANDE KABELN
Använd en kabel med maximum längd 4,5 meter och minimum 6 amp nominal, 250V, av
HAR kabelfabrikat med ett specialutformat IEC 320-kontaktdon i ena änden och i den
andra en plugg som godkänts i landet där produkten används.
VARNING:
Luftventilerna får ej blockeras och måste ha fri tillgång till omgivande
rumsluft för avsvalning.
DRIFTSTEMPERATUR
Denna produkt är konstruerad för rumstemperatur ej överstigande 50 grader Celsius.
ALLA LÄNDER: Installera produkten i enlighet med lokala och statliga bestämmelser
för elektrisk utrustning
!
StockCheck.com

List of Figures
i
List of Figures
Figure 1: AT-MR118FT Front and Back Panels 8
Figure 2: AT-MR128FT Front and Back Panels 9
Figure 3: Typical Hub Configuration 11
Figure 4: 10BASE-T UTP Cabling Hub to MAU or NIC (Straight-Through) 19
Figure 5: 10BASE-T UTP Cabling Hub to Hub (Cross-Over) 19
Figure 6: Hub to MAU Wiring
A.Usable and B. Unusable 21
Figure 7: Pin 1 Orientation on an RJ45 Connector 22
StockCheck.com

List of Tables
i
List of Tables
Table 1: The AT-MR118FT and AT-MR128FT Characteristics 1
Table 2: CentreCOM Micro Repeater Dimensions 2
Table 3: Usable and Unusable Twisted Pair Cable 18
Table 4: MDI/MDI-X Switch Settings for Common Connection 20
StockCheck.com

xi
Table of Contents
Electrical Safety and Installation Requirements ......................................iii
List of Figures ............................................................................................................. i
List of Tables ...............................................................................................................i
Chapter 1
Overview .......................................................................................................................1
CentreCOM Fiber Optic to 10BASE-T Micro Repeaters.........................................1
Dimensions of Internal and External Micro Repeaters.............................................2
Full- and Half-Repeater Modes.....................................................................................2
Connector Types..............................................................................................................3
Power Requirements.......................................................................................................3
External Power Supply Micro Repeaters............................................................3
Internal Power Supply Micro Repeaters.............................................................3
Chapter 2
Cabling ...........................................................................................................................5
10BASE-T (UTP) Connections......................................................................................5
FOIRL or 10BASE-FL Fiber Optic Connections......................................................6
Chapter 3
Operation ......................................................................................................................7
Switches ............................................................................................................................7
Indicators..........................................................................................................................7
Setting Up Your Repeater.............................................................................................8
Chapter 4
Configuration ............................................................................................................11
Chapter 5
Troubleshooting .......................................................................................................13
Experiment with Possible Solutions...........................................................................13
17
Data Cabling Techniques .....................................................................................17
10BASE-T.......................................................................................................................17
UTP Port Wiring...................................................................................................18
10BASE-FL/FOIRL Ethernet....................................................................................22
10BASE5 (Thick) Ethernet..........................................................................................22
AUI Drop Cables...................................................................................................22
10BASE2 (Thin) Ethernet............................................................................................23
StockCheck.com

xii
25
Glossary ......................................................................................................................25
31
Technical Support Fax Order ........................................................................... 31
33
CentreCOM AT-MR118FT and AT-MR128FT Manual Feedback.......... 33
Index .............................................................................................................................35
List of Figures
Figure 1: AT-MR118FT Front and Back Panels.............................................. 8
Figure 2: AT-MR128FT Front and Back Panels.............................................. 8
Figure 3: Typical Hub Configuration ............................................................. 11
Figure 4: 10BASE-T UTP Cabling Hub to MAU or NIC
(Straight-Through) ......................................................................... 19
Figure 5: 10BASE-T UTP Cabling Hub to Hub (Cross-Over) ...................... 19
Figure 6: Hub to MAU Wiring A. Usable and B. Unusable ......................... 21
Figure 7: Pin 1 Orientation on an RJ45 Connector ...................................... 22
List of Tables
Table 1: The AT-MR118FT and AT-MR128FT Characteristics ..................... 1
Table 2: CentreCOM Micro Repeater Dimensions .......................................... 2
Table 3: Usable and Unusable Twisted Pair Cable ...................................... 18
Table 4: MDI/MDI-X Switch Settings for Common Connection ................... 20
StockCheck.com

1
Chapter 1
Overview
CentreCOM Fiber Optic to 10BASE-T Micro Repeaters
The AT-MR118FT and AT-MR128FT are fiber optic to Unshielded Twisted Pair
(UTP)micro repeaters. TheAT-MR118FT hasanexternal powersupply while the
AT-MR128FT has an internal power supply. Both of these repeaters are two-port
mediaconvertersdesignedforconnectionstoaFiberOptic(10BASE-FL)or Fiber
Optic Inter-Repeater Link (FOIRL) segment and a UTP (10BASE-T) segment.
Table 1 lists the product line.
Table 1: The AT-MR118FT and AT-MR128FT Characteristics
Repeaters are used for two principal reasons. They are:
❑To extend a signal beyond its normal length of transmission
❑To complete a network connection in instances when one cannot be made
Segments on either side of both repeaters support full length, fully repeated
transmission. Only the fiber optic segment supports both full- and half-repeated
transmission.Both segments allowthe maximumnumberof nodesspecified by the
IEEE 802.3 specification. The repeaters are both compliant with both IEEE 802.3
and Ethernet standards. Both repeaters use state-of-the-art technologies,
including a custom Application Specific Integrated Circuit (ASIC) and Surface
Mount Technology (SMT), which provide enhanced functionality, increased
reliability and improved performance.
Network diagnostic LEDs are provided on the front of the micro repeaters to aid
in troubleshooting and fault isolation. Both segments have On Line, Collision,
Receive, Transmitand Link indicators.Inaddition,both repeaters haveacentral
Power indicator. Refer to “Indicators” on page 7 for more information.
Model Power Supply Port 1 Port 2
AT-MR118FT-11/21 External UTP SMA Fiber Optic
AT-MR118FT-13/23 External UTP ST Fiber Optic
AT-MR128FT-11/21 Internal UTP SMA Fiber Optic
AT-MR128FT-13/23 Internal UTP ST Fiber Optic
StockCheck.com

Overview
2
Dimensions of Internal and External Micro Repeaters
The primary difference between the AT-MR118FT and the AT-MR128FT
repeaters is that the AT-MR128FT is alarger repeater because both the repeater
and the power supply reside together in one chassis. The dimensions of the two
repeaters are shown below in Table 2.
Table 2: CentreCOM Micro Repeater Dimensions
The AT-MR118FT has a separate external power supply. Consequently, it is
smaller,enablingyoutoconnecttoahuboraMediaAccessUnit(MAU)whenyour
physical environment does not allow space for a larger repeater.
The CentreCOM Micro Repeaters are both relatively small in size and provide the
complete functionality of larger repeaters that contain many ports, including
packet regeneration and network partitioning.
Full- and Half-Repeater Modes
The AT-MR118FT and AT-MR128FT micro repeaters support both full- and
half-repeater modes. You can select the appropriate mode required, using the
full-repeater/half-repeater switch located next to the fiber optic ports.
Full-repeater modeenables a simple retransmission of signals from the fiber optic
port to the UTP port and vice versa, using the Packet Retiming Controller (PRC)
to ensure bit integrity in signal packets. The packet regeneration results in a
higherperformance networkbyregenerating preamble,retiming thedatapackets
and extending collision fragments to ensure collision enforcement by all nodes.
Half-repeater mode aids in reducing the effective repeater count in networks
capable of supporting half repeaters. This reduction is achieved by taking
advantage of the lower distortion in the fiber optic media. The technique is used
whenasignalissentfromthefiberoptic port to theUTPport,therefore,repeating
occurs in only one direction.
The half-repeater mode is used to reduce the number of repeaters a signal must
traverse so that the four repeater rule restriction is not violated. For example, if
you are using four repeaters, and two of them are set for half-repeater mode, the
effective repeater count is three, enabling you to add another repeater without
violating the four-repeater limit. If you want to realize the benefit of a repeater
reduction, you have to remember to initiate half-repeating on two repeaters
connected to each other.
Model Dimensions
AT-MR118FT 5.5 in. (140 mm) x 4.5 in. (114 mm) x 1.25 in. (32 mm)
AT-MR128FT 8.5 in. (216 mm) x 4.5 in. (114 mm) x 1.25 in. (32 mm)
StockCheck.com

CentreCOM™ Micro Repeaters
3
The UTP-to-fiber optic port transmission needs to be regenerated by
the PRC to ensure integrity of timing. Because the UTP-to-fiber optic
transmission is routed through a regenerating chip, it uses the full-
repeater strategy and does not provide the repeater count reduction
benefit associated with the half-repeater strategy.
Connector Types
Each repeater supports both fiber optic and UTP versions (RJ45 connection). The
fiberoptic repeateris availablein eitheran SMAand STversion. TheSMA screws
into a threaded receptacle. The ST twists into a twist-lock receptacle.
Power Requirements
The power requirements of both the AT-MR118FT and the AT-MR128FT are
described below.
External Power Supply Micro Repeaters
The AT-MR118FT has an external universal AC input/DC output power supply.
Locate a 100-240 VAC, 50/60 Hz outlet and plug in the standard-equipment power
cord. The power cord is only supplied in the U.S.A. version.
Use only the AC power adapter. Using another manufacturer’s power
adapter may permanently damage your micro repeater and void your
warranty.
Connect the power connector from the AC power adapter to the micro repeater.
The Power indicator should illuminate.
Internal Power Supply Micro Repeaters
The AT-MR128FT has an internal universal AC input/DC output power supply.
Locate the 100-120/200-240 VAC, 50/60 Hz power outlet and plug in the standard-
equipment power cord. The power cord is only supplied in the U.S.A. version.
Insert the power plug into the micro repeater. The Power indicator should
illuminate.
N
ote
N
ote
StockCheck.com

5
Chapter 2
Cabling
Two types of cabling exist for the AT-MR118FT and AT-MR128FT. They are:
❑UTP (10BASE-T)
❑Fiber Optic (10BASE-FL/FOIRL)
The 10BASE-T cabling type is UTP while 10BASE-FLand FOIRL is fiber optic
with FL covering a greater distance than FOIRL. Both cabling types have IEEE
802.3 specifications and limits associated with them. They are described in the
following sections. If you need detailed information on cabling, see Appendix A.
For more information, read the IEEE 802.3 specification where cabling
regulations are outlined.
10BASE-T (UTP) Connections
The micro repeater’s UTP connections support a full 100 meters (328 ft.) of UTP
cableperthe 10BASE-Tspecification.This twistedpairsegment connectsdirectly
to either a Data Terminal Equipment (DTE) or transceiver. The RJ45 connector
maybepluggeddirectly totheUTPport.ThecableshouldbeatleastLevel3UTP,
100 Ωimpedance, 22 to 26 American Wire Gauge (AWG), a minimum of three
twists per foot, and should not exceed 100 meters (328 ft.) in length.
10BASE-T UTP media was implemented to reduce Ethernet wiring
costs. Much of the existing cabling is not suitable for Ethernet 10 Mb
data rates. Care must be taken to ensure the UTP wiring used for
10BASE-T is able to carry these Ethernet data rates before a
10BASE-T network solution is implemented. Unlike the coaxial
Ethernet,10BASE2and10BASE5architectures, the 10BASE-TUTP
protocol is point-to-point wiring. For more detailed information on
10BASE-T, see Appendix A.
N
ote
StockCheck.com

Cabling
6
FOIRL or 10BASE-FL Fiber Optic Connections
Hazardouslightemissionsmay exist infiberopticsystems.Severe eye
damage may result if precautions are not taken. Never look into a
transmitting fiber optic device, transceiver, repeater or cable.
The IEEE 802.3 10BASE-FL port supports up to 2,000 meters (6,560 ft.) of
multimode duplex fiber optic cable in a point-to-point link which directly attaches
two devices. Duplex refers to support for fiber optic cable pairs, enabling a two-
cable fiber optic connection with transmit mode dedicated to one cable and receive
mode on the other. 10BASE-FL supports connections of 2,000 meters (6,560 ft.)
while FOIRL supports connections of 1,000 meters (3,280 ft.). FL is compatible
with FOIRL, but restricts distance to 1 km. The wide dynamic range of the fiber
optic interface on the AT-MR118FT and AT-MR128FT allows for an easy
installation. Both the SMA and ST connections are industry-standard interfaces.
Make sure the fiber optic cable connector is not forced into the ST
receptacle. The ST connector is keyed. Gently rotate the connector
plug until the key slips into the notch of the fiber optic receptacle.
Warning
!
C
aution
StockCheck.com

7
Chapter 3
Operation
The AT-MR118FT and AT-MR128FT repeaters both retime and regenerate the
Ethernet signal symmetry and regenerate the packet preamble. The micro
repeaters also count the number of consecutive collisions. If this number reaches
32, then the repeater will take the segment Off Line (partition) to prevent a total
network failure. This process is known asautomatic segmentation. If one valid
Ethernet packet is received on that segment, the repeater will place the segment
On Line automatically, thus disconnecting problem segments and reconnecting
valid segments.
Switches
TheAT-MR118FT andAT-MR128FT repeaterseach have twoswitches. Theyare:
❑A full-repeater/half-repeaterswitch
❑A straight-through/cross-over selection switch (MDI/MDI-X)
The full-repeater/half-repeaterselection switch is used to select the half- or full-
repeater functions. Thestraight-through/cross-over selection switch enables and
disables the internal cross-over function. It indicates whether straight-through
(MDI) or cross-over (MDI-X) connections are being enabled.
Indicators
The following diagnostic indicators are common to the micro repeaters. The
AT-MR118FT and AT-MR128FT both have five indicators per port. In addition,
there is a power LED for the entire repeater. Each indicator is described below.
Power—Indicates the AC power adapter or power supply is providing power to
the repeater.
Collision—Indicates a collision detected on that port.
On Line—Indicates when the port is ready for operation and is not partitioned.
Receive—Indicates when a packet is received on that port. Brief flashes indicate
low traffic levels.
Transmit—Indicates when a packet is transmitted.
StockCheck.com
