Allnet ALL02880ND User manual

0
ALL02880ND
Wireless N 300Mbit Dual Band AP PoE
User´sManual

ALL02880ND Manual
1
Table of Contents
1INTRODUCTION 5
1.1Features and Benefits ....................................................................................5
1.2Package Contents...........................................................................................6
1.3System Requirements ....................................................................................7
1.4Applications ...................................................................................................7
2BEFORE YOU BEGIN 9
2.1Considerations for Wireless Installation ......................................................9
2.2Computer Settings (in Windows XP/Windows 7)......................................10
2.3Computer Settings in Apple Mac OS X.......................................................13
2.4Hardware Installation ..................................................................................14
3CONFIGURING YOUR ALL02880ND 16
3.1Default Settings ...........................................................................................16
3.2Web Configuration ......................................................................................17
4BUILDING A WIRELESS NETWORK 19
4.1Access Point Mode.......................................................................................19
4.2Client Bridge Mode......................................................................................20
4.3WDS AP / WDS Station Mode .....................................................................21
4.4WDS Bridge Mode .......................................................................................22
4.5Repeater mode.............................................................................................23
5STATUS 24
5.1Save/Reload..................................................................................................24
5.2Main..............................................................................................................25

ALL02880ND Manual
2
5.32.4G/5G Wireless Client List........................................................................28
5.42.4G/5G Connection Status .........................................................................29
5.52.4G/5G WDS Link List.................................................................................30
5.6System Log ...................................................................................................31
6SYSTEM 32
6.1Operation Mode...........................................................................................32
6.2IP Settings ....................................................................................................34
6.3Spanning Tree Setting .................................................................................35
6.4Band Steering...............................................................................................36
72.4G/5G WIRELESS 37
7.1Wireless Network.........................................................................................37
7.2Wireless Security..........................................................................................41
7.3Site Survey....................................................................................................44
7.4Wireless MAC Filtering ................................................................................47
7.5Wireless Advanced Settings ........................................................................48
7.6WPS (Wi-Fi Protected Setup)......................................................................50
7.7WDS Link Settings .......................................................................................52
8MANAGEMENT 54
8.1Administration .............................................................................................54
8.2Management VLAN Settings.......................................................................55
8.3Wireless Traffic Shaping..............................................................................61
8.4SNMP Settings .............................................................................................63
8.5Backup/Restore............................................................................................65
8.6Firmware Upgrade .......................................................................................66

ALL02880ND Manual
3
8.7Time Settings ...............................................................................................67
8.8Schedule .......................................................................................................68
8.9CLI Setting ....................................................................................................70
8.10Log ................................................................................................................71
8.11Diagnostics ...................................................................................................72
8.12LED Control ..................................................................................................73
8.13Logout ..........................................................................................................74
8.14Reset .............................................................................................................75

ALL02880ND Manual
4

5
1Introduction
The ALL02880ND is a high-powered, long-range dual-band concurrent wireless
802.11a/b/g/n access point with six major functional modes. It is designed to operate
in numerous environments from large homes, small and medium-sized businesses,
multiple-floor offices, hotels and other venues to larger enterprise deployments. Its
high-powered, long-range characteristics make it a cost-effective alternative to
ordinary access points that don’t have the range and reach to connect to a growing
number of wireless users who wish to connect to a large home or business network.
The ALL02880ND supports IEEE 802.11b/g/n standards in the 2.4GHz frequency band
while at the same time supporting IEEE 802.11a/n standards in the less congested
5GHz frequency band ideal for streaming or transferring other large files.
The ALL02880ND delivers up to 6x faster wireless speeds and 7x extended coverage
than legacy 802.11a/b/g wireless devices. Even though the ALL02880ND has been
designed and engineered for traffic heavy and demanding business environments it is
also quite at home in larger house scenarios because it efficiently extends the wireless
range of an existing home router, especially in very architecturally-challenging
structures to provide whole home connectivity.
To protect sensitive data during wireless transmissions, the ALL02880ND offers
different encryption settings for wireless transmissions including industry-standard
WPA and WPA2 encryption. The ALL02880ND also includes MAC address filtering to
allow network administrators to offer network access only to known computers and
other devices based on their MAC addresses.
1.1 Features and Benefits
Features Benefits
High Speed Data Rate Up to
300 Mbps for each band
(2.4GHz / 5GHz)
Capable of handling heavy data payloads such as HD
multimedia streaming.
10/100/1000 Gigabit Ethernet Supports up to 1000Mbps wired networking speed.
IEEE 802.11n Compliant and
Backwards Compatible with
Fully compatible with IEEE 802.11 a/b/g/n devices.

ALL02880ND Manual
6
802.11 a/b/g devices
Multiple Operation Modes Allowing users to select any one of the following
modes: Access Point, Client Bridge, WDS AP, WDS
Bridge, WDS Station and Repeater depending on
their specific networking deployment need.
Support Multiple SSIDs in AP
mode (up to 8 in each
frequency band)
Allows clients to access different networks through
a single access point and assign different policies
and functions for each SSID through the built-in
software.
WPA/WPA2/IEEE 802.1x
Support
Supports industry-standard wireless encryption.
MAC Address Filtering in AP
Mode
For more secure network connections with known
users and devices.
User Isolation Support (AP
mode)
Offers an additional layer of protection within the
network by isolating specific client users.
Power-over-Ethernet
(IEEE802.3at/af)
Allows installers to deploy the ALL02880ND in
locations via a PoE connection (Ethernet cable)
where a power outlet may not be available.
Save User Settings Enables network administrators to save their device
settings so firmware upgrades do not permanently
delete previous device settings.
SNMP Remote Configuration
Management
Allows remote connection to configure or manage
the ALL02880ND easily.
QoS (WMM) support Prioritizes bandwidth-intensive and sensitive data
traffic.
IPv6 Address support ALL02880ND supports IPv6, you can use IPv6
address in ALL02880ND.
Band Steering When Band Steering is activated dual-band client
devices are associated to the ALL02880ND access
point on the 5 GHz frequency band.
1.2 Package Contents
The ALL02880ND package contains the following items (Resellers and dealers require
that all items must be in package to issue a refund):
ALL02880ND Access Point/Client Bridge
12V/2A 100V~240V Power Adapter
RJ-45 Ethernet LAN Cable

ALL02880ND Manual
7
2.4 GHz Detachable Antenna x 2
5 GHZ Detachable Antenna x 2
Wall Mount Screw Kit
CD with User's Manual
Quick Installation Guide
Please use only the power supply unit that is delivered with the device.
Bitte verwenden Sie nur das mitgelieferte Netzteil.
1.3 System Requirements
The following are the Minimum System Requirements in order configure the device.
Computer with an Ethernet interface or wireless network capability
Windows OS (XP, Vista, 7), Mac OS X, or Linux-based operating systems
Web-Browsing Application (i.e.: Internet Explorer, Firefox, Safari, or other similar
browser application)
1.4 Applications
Wireless LAN (WLAN) products are easy to install and highly efficient. The following
list describes the benefits of deploying a wireless access point:
a) Difficult-to-Wire Environments
There are many situations where wires cannot be installed, deployed easily or
cannot be hidden from view. Many older buildings sites, or areas within a
building may make the installation of an Ethernet-based LAN impossible,
impractical or expensive.
b) Temporary Workgroups
A deployed wireless access point or several access points, gives businesses the
flexibility to create temporary workgroups/networks in more open areas within a
building – auditoriums, amphitheater classrooms, ballrooms, arenas, exhibition
centers, and temporary offices.
c) The Ability to Access Real-Time Information
Doctors/Nurses, Point-of-Sale Employees, and/or Warehouse Workers can
access real-time information on their network via the access point while dealing
with patients, serving customers, and/or processing information.
d) Frequently Changing Environments
Setting up an access point, like the ALL02880ND, to provide access to a
company network or its Internet connection is quick and easy which also makes

ALL02880ND Manual
8
it ideal for establishing network access in temporary venues like exhibits, special
events, or show rooms.
e) Small Office and Home Office (SOHO) Networks
A wireless access point, like the ALL02880ND, is ideal for SOHO users who need
a cost-effective way to expand their existing network to provide more access for
more devices, easy and quick installation of a small network.
f) Wireless Extensions to Existing Ethernet-based Networks
Wireless access points, like the ALL02880ND, enable network administrators,
installers and end-users to extend the range and reach of an existing
Ethernet-based network.
g) Training/Educational Facilities
Training sites at corporations and universities deploy wireless access points to
provide connectivity their networks and the Internet connection for their
employees and students.

9
2Before you Begin
This section will guide you through the installation process. Placement of the
EnGenius ALL02880ND is essential to maximize the access point’s performance. Avoid
placing the ALL02880ND in an enclosed space such as a closet, cabinet, or stairwell.
2.1 Considerations for Wireless Installation
Generally, the exact operating distance of a wireless device, like the ALL02880ND,
cannot be pre-determined due to a number of unknown variables or obstacles in the
environment in which the device will be deployed. These could be the number,
thickness, and location of walls, ceilings, elevator shafts, stairwells, or other objects
that the device's wireless signals must pass through. Here are some key guidelines to
allow the ALL02880ND to have optimal wireless range.
Keep the number of walls and/or ceilings between the ALL02880ND and other
network devices to a minimum. Each wall and/or ceiling can reduce the signal
strength, resulting in lower signal strength.
Building materials make a difference. A solid metal door and/or aluminum studs
may have a significant negative effect on the signal strength of the ALL02880ND.
Locate your wireless devices carefully so the signal can pass through drywall
and/or open doorways. Materials such as glass, steel, metal, concrete, water
(example: fish tanks), mirrors, file cabinets and/or brick can also diminish wireless
signal strength.
Interference from other electrical devices and/or appliances that generate RF
noise can also diminish the ALL02880ND’s signal strength. The most common
types of devices are microwaves or cordless phones.

10
2.2 Computer Settings (in Windows XP/Windows 7)
In order to use the ALL02880ND, you must first configure the TCP/IPv4 connection of
your Windows OS computer system.
Click Start button and open Control Panel.
WindowsXP Windows7

ALL02880ND Manual
11
In Windows XP, click Network Connections
In Windows 7, click View Network Status and Tasks in the Network and
Internet section, then select Change adapter settings
Right click on Local Area Connection and select
Properties
Select “Internet Protocol Version 4 (TCP/IPv4)” and then select Properties

ALL02880ND Manual
12
Select Use the following IP address and enter
an IP address that is different from the
ALL02880ND and subnet mask then click OK.
2Note: Ensure that the IP address and subnet
mask are on the same subnet as the device.
3For example: ALL02880ND IP address:
192.168.1.1
4PC IP address: 192.168.1.2 – 192.168.1.255
5PC subnet mask: 255.255.255.0

13
2.3 Computer Settings in Apple Mac OS X
Go to System Preferences (can be opened in the Applications folder or
selecting it in the Apple Menu)
Select Network in the Internet & Network section
Highlight Ethernet
In Configure IPv4, select Manually
Enter an IP address that is different from the ALL02880ND and subnet mask then
press OK
Note: Ensure that the IP address and subnet mask are on the same subnet as the
device.
For example: ALL02880ND IP address: 192.168.1.1
PC IP address: 192.168.1.2 – 192.168.1.255
PC subnet mask: 255.255.255.0
Click Apply when done.


14
2.4 Hardware Installation
1. Ensure that the computer in use has an available Ethernet (RJ-45) Port. For
more information, verify with your computer’s user manual.
2. Connect one end of the Category 5e Ethernet cable into the RJ-45 port of the
ALL02880ND and the other end to the RJ-45 port of the computer. Ensure that
the cable is securely connected to both the ALL02880ND and the computer.
3. Connect the Power Adapter DC connector to the DC-IN port of the
ALL02880ND and the Power Adapter to an available electrical outlet. Once
both connections are secure, verify the following:
a) Ensure that the POWER light is on (it will be orange).
b)Ensure that the 2.4GHz/5GHz WLAN light is on (they will be blue).
c) Ensure that the LAN (Computer/ALL02880ND Connection) light is on (it
will be blue).
d)Once all lights are on, proceed to set up the ALL02880ND using the
computer.
This diagram depicts the hardware configuration.

ALL02880ND Manual
15
Front Panel
LED Lights LED lights for Power, Gigabit Ethernet port, WLAN 2.4G and WLAN
5G.
Rear Panel
Power DC IN for Power.
Gigabit Ethernet Port Gigabit Ethernet port for RJ-45 cable.
Reset Button One click for reset the device. Press over 10 seconds for reset to
factory default.

16
3Configuring Your ALL02880ND
This section will show you how to configure the device using the web-based
configuration interface.
3.1 Default Settings
Please use your Ethernet port or wireless network adapter to connect the
ALL02880ND.
DefaultSettings
IP Address 192.168.1.1
Username / Password admin / admin
Operation Mode AP / AP

17
3.2 Web Configuration
Open a web browser (Internet Explorer/Firefox/Safari) and enter the IP Address
http://192.168.1.1
Note: If you have changed the default LAN IP Address of the Access Point, ensure you enter the correct
IP Address.
The default username and password are admin. Once you have entered the
correct username and password, click the Login button to open the web-base
configuration page.
If successful, you will be logging in and see the ALL02880ND User Menu.

ALL02880ND Manual
18

ALL02880ND User’s Manual
19
4Building a Wireless Network
The ALL02880ND has the ability to operate in various modes. This chapter describes
the operating modes of the ALL02880ND.
4.1 Access Point Mode
In Access Point Mode, ALL02880ND behaves likes a central connection for stations or
clients that support IEEE 802.11a/b/g/n networks. The stations and clients must be
configured to use the same SSID (Service Set Identifier) and security password to
associate with the ALL02880ND. The ALL02880ND supports up to eight SSIDs at the
same time for secure access.
