Alpinestars HT Series User manual

v 1.0 - Printed 2021
NOT TO BE REMOVED EXCEPT BY CONSUMER
HT-3 / HT-5 / HT-7 HEAT TECH
DRYSTAR®GLOVES
USER GUIDE
IMPORTANT USER
INFORMATION

Please read the following important WARNINGS
and LIMITATIONS of use notice carefully:
Motorcycling is an inherently dangerous activity and an ultra-hazardous
sport, which may result in serious personal injury, including death. Each
individual motorcycle rider must be familiar with motorcycling, recognize
the wide range of foreseeable hazards and decide whether to assume
the risks inherent in such an activity with the knowledge of the dangers
involved and accept any and all risks of injury, including death. While all
motorcycle riders should utilize appropriate protective equipment, each
rider should exercise extreme care for safety while riding and understand
that no product can offer complete protection from injury including death
or damage to individuals and property in case of fall, collision, impact,
loss of control or otherwise. Riders should ensure that safety products
are correctly fitted and used. DO NOT use any product that is worn out,
modified or damaged.
Alpinestars makes no guarantees or representations,
express or implied, regarding the fitness of its products
for any particular purpose.
Alpinestars makes no guarantees or representations,
express or implied, regarding the extent to which its
products protect individuals or property from injury,
death or damage.
ALPINESTARS DISCLAIMS ANY RESPONSIBILITY
FOR INJURIES INCURRED WHILE WEARING ANY
OF ITS PRODUCTS.
NOT TO BE REMOVED EXCEPT BY CONSUMER
HT-3 / HT-5 / HT-7 HEAT TECH DRYSTAR®GLOVES - USER GUIDE
v 1.0 - Printed 2021

4EN
1. INTRODUCTION
The Alpinestars’ heated glove models HT-3, HT-5 and HT-7 HEAT TECH Drystar®are motorcycling gloves
(hereinafter “Gloves” unless otherwise specified) designed to offer improved thermal comfort to the
motorcycle rider in cold and/or wet weather conditions due to the innovative heating technology embedded
inside the Gloves. This technology is made of ultra-fine enameled heating yarn elements, which due to their
enhanced performances in terms of resistance, heating efficiency and safety, provide unrivalled levels of
warmth and comfort without the bulk typically caused by excessive layers of materials.
The Gloves’ electronic components, except for the battery (5), are waterproof and equipped with safety
systems to provide controlled and even heating, thereby avoiding overheating and overcharging anomalies.
The Gloves can be operated safely in various weather conditions due to the combination of selected
materials, premium construction techniques and innovative heating technology.
The Gloves are powered by lightweight, rechargeable and powerful Lithium Polymer batteries.
2. EN13594:2015 – IMPORTANT USER INFORMATION
These Gloves are certified to EN13594:2015 and as such are considered PPE (Personal Protective Equipment)
under European Regulation (EU) 2016/425. An EU Type examination has been conducted on these Gloves
using the notified body indicated on the TABLE on back cover of this User Guide. This User Guide is important
as it will help you select the correct size of the Gloves and maintain them throughout their lifespan.
PROTECTION LEVEL
EN13594:2015 certified gloves are available with two performance levels of protection, Level 1 and Level 2.
Level 2 gloves have superior performance resistance and certified knuckle protection, however they may be
heavier and bulkier. For Level 1 gloves, certified knuckle protection is optional and is declared in the
marking. You should choose gloves which provide the best performance levels of protection suitable for the
type of riding you will do.
TABLE on back cover: please consult it together with the glossary found on the inside cover of
this User Guide to find the most suitable protection according to the Gloves’ predicted use.
It is essential to read this User Guide carefully, to understand it completely and
to follow the advice and WARNINGS. If you have any questions, please contact
Alpinestars.
The Gloves are not suitable for children under the age of 16 years. Do not allow
children to play with the Gloves or their accessories.
As with any electrical device, misuse of the Gloves or failure to follow the instruc-
tions may cause overheating, fire or injury to you or your property.
Do not attempt to repair any electrical part or component of the Gloves. This will
void the warranty and can result in temperature control malfunctions, which may
cause minor to severe burning.
Damaged heating elements may cause the Gloves to heat intermittently or completely
fail to heat. If the heating elements do not operate properly contact Alpinestars.
WARNING!
WARNING!
WARNING!
WARNING!
IMPORTANT!

5EN
EU DECLARATION OF CONFORMITY
The EU Declaration of Conformity of this PPE can be downloaded at the following internet website:
eudeclaration.alpinestars.com typing the model of the Gloves.
INFORMATION CONTAINED IN THE GLOVE MARKING
= CE Mark = Item is for Motorcycle Use= Manufacturer
= Read the instructions before use
HT-7 HEAT TECH DRYSTAR®GLOVES = Name and unique reference code
for the product (See Table 1)
3523921Y= Product code
EN13594:2015 = Reference Standard
= Size (See Table 2)
Where indicated,
indicates that the
knuckle protection is
certified, blank if not.
Level of protection
HT-7 HEAT TECH
3. LIMITATIONS ON USE
Despite the protection levels indicated above, Gloves will ONLY PROVIDE LIMITED PROTECTION against
abrasion or lacerations by blunt objects or road surfaces and (if ‘KP’ declared) small impacts.
Users must be aware that no glove can provide complete protection against injury of any kind in
the case of falls, collision, impact, loss of control of the motorcycle or other events, in particular
as the hands or fingers may be trapped under the motorcycle or impact with other obstacles
during an accident.
No guarantees, express or implied, are made regarding the Gloves ability to avoid the risk of
injury while riding.
These Gloves have been designed exclusively for motorcycling use and are not for use in other sporting,
non-sporting or industrial activities.
Do not submerge the Gloves in water while wearing the Gloves.
Users should be aware that different environmental conditions including high or low temperatures can
change the characteristics of the Gloves and may reduce their performance. In particular, the use of glove in
a cold environment (below 0°C/32F) will significantly reduce the battery duration.
The Gloves and their components, in particular the batteries found on the heated Gloves, may not activate
if frozen or stored in extreme cold. Should this happen, allow the Gloves and their components to thaw and/
or warm up before attempting to use or activate the heated Gloves.
4. SIZING
In order to offer proper protection to the user, it is important that the Gloves fit correctly. Gloves are sized
based on the circumference of the palm without the thumb as shown in Figure 1. Take this measurement of
your own palm and then use Table 1 to convert this to the letter size (S,M,L) which is on the glove marking.
FIGURE 1: PALM CIRCUMFERENCE MEASUREMENT
HOW TO MEASURE - cm system & inches system
TABLE 1 – SIZE CHART
MEN’S AND WOMEN’S GLOVES CHART (Inch / cm)
International Size XS S M L XL XXL 3XL 4XL
Men’s Hand Measurement (inch) 7½ - 8 8 - 8½ 8½ - 9 9 - 9½ 9½ - 10 10 - 11 11 - 11½
Men’s Hand Measurement (cm) 17,8 - 20,3 20,3 - 21,6 21,6 - 22,9 22,9 - 24,1 24,1 - 25,4 25,4 - 27,9 27,9 - 29,2
Women’s Hand Measurement (inch) 6½ - 7 7 - 7½ 7½ - 8 8 - 8½ 8½ - 9
Women’s Hand Measurement (cm) 16,5 - 17,8 17,8 - 19 19 - 20,3 20,3 - 21,6 21,6 - 22,9

6EN
Since the Gloves are partially made of leather, when selecting your size remember that, with normal use/
wear, the Gloves will stretch naturally to accommodate the fit of your hands. These Gloves are considered
winter gloves and, accordingly, the fit should be slightly looser to allow air to circulate through the glove
insulation.
Prior to riding, the Gloves must be put on and fastened as instructed above. At all times when riding, make
sure that your Gloves are correctly and tightly fastened.
Remember that for sensible motorcycling the full body must be protected and as such the Gloves should be
worn with correctly CE certified and fitting motorcycle clothing, boots and a homologated helmet.
For further instructions on the correct use of the HT-3 HEAT TECH Drystar®Gloves, HT-5 HEAT TECH Drystar®
Gloves and HT-7 HEAT TECH Drystar®Gloves, see the sections below.
6. GLOVES OVERVIEW
The Gloves are packaged with an Alpinestars USB Charging Cable and two 7.4V Lithium Polymer batteries.
These items are also provided as Alpinestars spare parts. Standard compatible USB cables and 7.4V
batteries – provided that they fit into the pocket (4) - may be used, however the performance of such
standard parts are not guaranteed and Alpinestars cannot confirm the suitability of the performances of
such alternative spare parts.
The Gloves feature: a heating LED control button (1) positioned on the cuff area. On the inner side of the cuff,
covered by the wrist adjustable closure flap (2), is located the pocket (4) for the battery installation, secured
by a closure with a hook and loop in the inner edge of the cuff (3). The battery (5) presents two ports, a
battery DC port (6) for the connection with the glove Glove DC plug (9) inside the pocket and a battery USB-C
port (7) for the connection with the USB Charging Cable (8). On the battery there is a Battery LED indicator
(10) to indicate charging status.
Figures below show the locations of the above:
5. FITTING
It is strongly recommended that the fit of the Gloves is checked before purchase, preferably with the jacket
that they will normally be worn with. Select a starting size of Gloves from Table 1, put the Gloves on and
adjust the fastening(s).
Glove fastenings are located at the cuff and/or the wrist. The wrist fastening should be pulled as tight as is
comfortable and then secured with the hook-and-loop strap. The Gloves’ wrist fastening is correctly
fastened when the cuff and strap overlap and no skin is exposed. The cuff fastening should be closed tight
such that it follows closely the jacket sleeve (if worn above the jacket) or your arm (if worn beneath the
jacket). Check that the Gloves cannot be removed easily by pulling it with your other hand. It is recommended
to wear these UNDER your jacket if you ride with your wrist lower than the elbow and OVER your jacket if
your wrist is higher than the elbow.
Open your hand flat. There should be no material in contact with the tips of your fingers. The glove should
feel tight, but not restrictive so as to impede sufficient movement of the hand. In a second step make a
clenched fist or grip a motorcycle handlebar. Check that there is none or only slight contact at the fingertips
and that there are no large folds of material on the palm. Ensure that there is enough finger movement to
correctly operate the motorcycle controls.

7EN
FIGURE 2: HT-7 HEAT TECH DRYSTAR®GLOVE
FIGURE 4: HT-3 HEAT TECH DRYSTAR®GLOVE
FIGURE 3: HT-5 HEAT TECH DRYSTAR®GLOVE
1. LED Control Button
2. Closure Flap
3. Battery pocket closure
4. Battery Pocket
5. 7.4V Lithium Polymer Battery
6. Battery DC Port
7. Battery USB-C Port
8. USB Charging Cable
9. Glove DC Plug
10. Battery LED Indicator
ELECTRONICHEATING TECHNOLOGY
ELECTRONICHEATINGTECHNOLOGY
2
33
3
4
2
2
4
1
8
9
4
6
10
5
7
11
4
1

8EN
When riding keep the battery in the pocket (4) with the waterproof zipper closed,
as this will allow for operating reliability when using the Gloves in wet weather
conditions.
These Gloves are not intended for use in warm weather. To avoid placing you at
risk of overheating do not use the Gloves if the weather/ambient environment tem-
peratures is above 30°C/86°F.
WARNING!
WARNING!
To enable the Gloves to function suitably in cold weather and subject to conditions such
as the external weather/ambient environment and the riding speed, the heating temper-
ature that the Gloves may reach on the RED High heating level can be as high as 70°C/
158°F maximum. Accordingly, use the Gloves only in the pre-defined conditions and ad-
just the heating level to the heating level appropriate to you and that will not cause you
discomfort or distraction while riding. If while riding you become aware that the heating
level is creating discomfort, stop your ride and adjust the heating level.
Connect the USB Charging Cable (8) to an AC adapter and then to the power source. Do
not use outdoors or in damp areas. Do not alter or subject the USB Charging Cable (8) to
damage or stress. Never alter the components.
While charging, always ensure that the USB Charging Cable (8) is properly connected to
both the USB-C port (7) and the USB port on the AC adapter is securely inserted in the
power source.
Alpinestars recommends to always use the original Alpinestars USB Charging Cable (8)
and battery (5) parts.
A fully charged battery is recommended before the first use of the Gloves.
Do not turn on or wear the Gloves during the charging process. It is essential that the
Gloves are switched off before starting the charging process.
IMPORTANT!
IMPORTANT!
IMPORTANT!
IMPORTANT!
IMPORTANT!
IMPORTANT!
7. BATTERY CHARGING INSTRUCTIONS
To charge the batteries before first use and/or recharge the batteries:
1. Plug the USB Charging Cable (8) to a standard AC adaptor with its appropriate adapter and connect the
USB Charging Cable (8) to the USB-C port (7) of the battery (5). USB Charging Cable (8) can also be plugged
into other USB sockets, such as notebooks and power banks; a full charge in these cases may take more
time.
2. When the LED Battery indicator (10) is RED the battery is not fully charged and is still charging.
3. When the LED Battery indicator (10) is GREEN the battery is fully charged and ready for use or storage
Approximately 3 hours charging time is required to fully charge the battery, with the exception of the first
battery charge which may require a longer time (approx. 4 hours).
The battery will naturally discharge itself over time. If the Gloves have not been used for more than a month,
battery charging may also require for a longer time; approximately four hours. It is also recommended to
recharge the batteries at least every 16 weeks to prevent capacity reduction.
For the best performance Alpinestars recommends to fully charge the battery before each use of the Gloves.

9EN
FIGURE 5
8. OPERATING INSTRUCTIONS FOR THE GLOVE MODEL:
HT-3 HEAT TECH DRYSTAR®
8.1 Introduction
The HT-3 HEAT TECH Drystar®Gloves are CE certified motorcycling gloves according to EN 13594:2015
standard and are equipped with protectors on the knuckles and are manufactured with premium high
resistant materials. The Drystar®waterproof and breathable membrane keeps the rider’s hand comfortably
dry in all-weather condition.
8.2 Getting started
a. Assembly: When the battery is fully charged (for battery charging instruction see section above)
disconnect the USB Charging Cable (8) from the battery USB-C port (7) on the battery (5). Next open the hook
and loop closure (3) located on the glove edge cuff, connect the battery (5) to the Glove DC plug (9) inside
the pocket (4), and close the closure (3).
To enable the Gloves to function suitably in cold weather and subject to conditions
such as the external weather/ambient environment and the riding speed, the heating
temperature that the Gloves may reach on the RED High Heating level can be as high as
70°C/ 158°F. Accordingly use the Gloves only in the pre-defined conditions and adjust
the heating level to the heating level appropriate to you and one that will not cause you
discomfort or distraction while riding. If while riding you become aware that the heating
level is creating discomfort, stop your ride and adjust the heating level.
IMPORTANT!
b. Activation: press the LED control button (1) for three seconds to turn the power ON. The LED will
illuminate with the RED (high heating) level. At this point adjust the temperature to the desired setting.
c. Temperature Adjustment: to select or change the desired in-glove heat setting, press the LED control
button (1) on the cuff until the desired heating color level is reached. LED colors have the following
meanings:
RED = HIGH HEATING
ORANGE = MEDIUM HEATING
YELLOW = LOW HEATING

10 EN
b. Activation: press the LED control button (1) for three seconds to turn the power ON. The LED will
illuminate with the RED (high heating) level. At this point adjust the temperature to the desired setting.
d. Shut Down: to turn the power off, press the LED control button (1) for three seconds. The LED will turn off.
FIGURE 6
OFF
LONG
PRESS PRESS PRESS PRESS
OFFLOW HEATING
YELLOW LIGHTORANGE LIGHTRED LIGHT
MEDIUM HEATINGHIGH HEATING
Alpinestars reserves all rights to, at any time, update the software and or the electronic
components of the Gloves.
IMPORTANT!
9. OPERATING INSTRUCTIONS FOR THE GLOVE MODEL:
HT-5 HEAT TECH DRYSTAR®
9.1 Introduction
The HT-5 HEAT TECH Drystar®Gloves are CE certified motorcycling gloves according to EN 13594:2015
standard and are equipped with protectors on the knuckles and palm sliders and are manufactured with
premium high resistant materials. The Drystar®waterproof and breathable membrane keeps the rider’s hand
comfortably dry in all-weather condition while Primaloft®padding provides enhanced thermal insulation
performance.
9.2 Getting started
a. Assembly: When the battery is fully charged (for battery charging instruction see section above)
disconnect the USB Charging Cable (8) from the battery USB-C port (7) on the battery (5). Next open the hook
and loop closure (3) located on the glove edge cuff, connect the battery (5) to the Glove DC plug (9) inside
the pocket (4), and close the closure (3).
FIGURE 5
