GAS FRYER
FryTech Series
ASF-60G and
ASF-75G
Gas Fryers
with
Basic Control
  •INSTALLATION
 •OPERATION
•MAINTENANCE
ASF-60G shown with
optional automatic
basket lifts
ASF-75G shown with
optional automatic
basket lifts

Gas Fryer Operation & Care Manual • 2
Delivery 1
Unpacking 1
Safety Procedures and Precautions 2
Installation
Installation Requirements 5-11
Dimension Drawings, weights & capacities 3-4
Clearance Requirements 5
Site Installation & Leveling 6
Ventilation 7
Gas Specifications 8
Gas Connection 9
Restraint Requirements - Mobile Equipment 10
Electrical Specifications 11
Operating Instructions
Oil/Shortening Requirements 12
Controls Behind Access Panel 13
Boil-Out Instructions 14-15
Start-Up & General Operation 16
Cleaning & Maintenance 17
Oil Filtrations (For units with installed option) 18-21
Suggested Frying Times 22-23
Basic Control Operation 24-30
Service
Service Troubleshooting 31-32
ASF-75G Service Views 34-38
ASF-60G Service Views 39-42
Wire Diagrams
ASF-75G, 120V 43
ASF-75G, 230V 44
ASF-60G, 120V 45
ASF-60G, 230V 46
Warranty
Transportation Damage and Claims Back Cover
Limited Warranty Back Cover

Gas Fryer Operation & Care Manual • 1
DELIVERY
This Alto-Shaam appliance has been
thoroughly tested and inspected to ensure only
the highest quality unit is provided. Upon
receipt, check for any possible shipping damage
and report it at once to the delivering carrier.
See Transportation Damage and Claims section
located in this manual.
This appliance, complete with unattached
items and accessories, may have been delivered
in one or more packages. Check to ensure that all
standard items and options have been received
with each model as ordered.
Save all the information and instructions
packed with the appliance. Complete and return
the warranty card to the factory as soon as
possible to ensure prompt service in the event of a
warranty parts and labor claim.
This manual must be read and understood
by all people using or installing the equipment
model. Contact the Alto-Shaam Tech Team Service
Department if you have any questions concerning
installation, operation, or maintenance.
NOTE: All claims for warranty must include the
full model number and serial number of
the unit.
UNPACKING
1. Carefully remove the
appliance from the
carton or crate.
NOTE: Do not discard the
carton and other
packaging material
until you have
inspected the unit
for hidden damage
and tested it for
proper operation.
2. Read all instructions in this manual carefully
before initiating the installation of this appliance.
DO NOT DISCARD THIS MANUAL.
This manual is considered to be part of the
appliance and is to be provided to the owner
or manager of the business or to the person
responsible for training operators. Additional
manuals are available from the Alto-Shaam
Tech Team Service Department.
3. Remove all protective plastic film, packaging
materials, and accessories from the appliance
before connecting electrical power. Store any
accessories in a convenient place for future use.
®
®
KEEP THIS MANUAL IN A CONVENIENT LOCATION FOR REFERENCE.
Gas Fryer Operation & Care Manual • 1
WARNING
In the event of loss of power to the
appliance, turn the “burner control
knobs” to the OFF position. Remove
food product from the unit. If burner
control fails to extinguish the flame,
shut off main gas valve located in
rear of unit.
DANGER
BEFORE STARTING THE
APPLIANCE, MAKE CERTAIN
YOU DO NOT DETECT THE
ODOR OF GAS.
iF the odor oF gas is detected:
• DO NOT attempt to light any appliance.
• DO NOT touch any electrical switches.
• Extinguish any open fl ame.
• Use a telephone OUTSIDE THE
PROPERTY & IMMEDIATELY
contact your gas supplier.
• If unable to contact your gas supplier,
contact the fire department.

Gas Fryer Operation & Care Manual • 2
INSTALLATION
CAUTION
Used to indicate the presence of a hazard that
can or will cause minor personal injury, property
damage, or a potential unsafe practice if the
warning included with this symbol is ignored.
CAUTION
Used to indicate the presence of a
hazard that can or will cause minor or
moderate personal injury or property
damage if the warning included with
this symbol is ignored.
DANGER
Used to indicate the presence of
a hazard that WILL cause severe
personal injury, death, or substantial
property damage if the warning
included with this symbol is ignored.
WARNING
Used to indicate the presence of
a hazard that CAN cause personal
injury, possible death, or major
property damage if the warning
included with this symbol is ignored.
1. This appliance is intended to cook, hold
or process foods for the purpose of human
consumption. No other use for this appliance is
authorized or recommended.
2. This appliance is intended for use in commercial
establishments where all operators are
familiar with the purpose, limitations, and
associated hazards of this appliance. Operating
instructions and warnings must be read and
understood by all operators and users.
3. Any troubleshooting guides, component views,
and parts lists included in this manual are for
general reference only and are intended for use
by qualified technical personnel.
4.Thismanualshouldbeconsideredapermanent
part of this appliance. This manual and all
supplied instructions, diagrams, schematics,
parts lists, notices, and labels must remain with
the appliance if the item is sold or moved to
another location.
NOTE: Used to notify personnel of
installation, operation, or
maintenance information that is
important but not hazard related.
SAFETY PROCEDURES
AND PRECAUTIONS
Knowledge of proper procedures is essential to the
safe operation of electrically and/or gas energized
equipment. In accordance with generally accepted
product safety labeling guidelines for potential
hazards, the following signal words and symbols
may be used throughout this manual.
NOTE
For equipment delivered for use
in any location regulated by the
following directive:
DO NOT DISPOSE OF ELECTRICAL
OR ELECTRONIC EQUIPMENT WITH
OTHER MUNICIPAL WASTE.
INSTALLATION
Gas Fryer Operation & Care Manual • 2

Gas Fryer Operation & Care Manual • 3
INSTALLATION
38-11/16" (983mm)
OIL
TROLLEY
50-3/16" (1274mm) LIFT UP
44-13/16" (1138mm) LIFT DOWN
Electrical
Gas
Connection
1/2" NPT
24-13/16" (629mm)
31-9/16" (802mm)
12-7/16"
(315mm)
2-7/8"
(72mm)
31-13/16" (808mm)
36-11/16" (931mm)
61-1/2" (1562mm)
150°
ASF-75G SPECIFICATIONS
CAPACITY
SHORTENING/OIL:
 73lb(33kg)maximum
LOAD CAPACITY:
 13lb(6kg)maximum
INSTALLATION
Gas Fryer Operation & Care Manual • 3
ASF-75G WITH LIFTS AND FILTRATION
DIMENSIONS exterior (hxwxd)
ASF-75G without filtration or lifts
44-13/16”x24-13/16”x37-7/16”(1138mmx629mmx951mm)
ASF-75G with filtration and lifts
44-13/16”x24-13/16”x38-11/16(1138mmx629mmx983mm)
basket dimensions (hxwxd)
6”x9-3/16”x14-3/16”(152mmx232mmx337mm)
WEIGHT est.
net weight: 360lb (163kg)
ship weight: 520lb (236kg)
carton dimensions: hxwxd
57”x34”x47”
(1448mmx864mmx1194mm)
STANDARD ACCESSORIES
Basket, Half-Size (2 included as standard) BS-27140
Brush Set (one 3-brush set included as standard)
scrub brush bh-28693
straight brush bh-28691
Filter, Paper (7 paper filters included as standard)
7 count refill package  FI-27791
100 count refill package  FI-27794
OPTIONS
Basket, Full-Size (48 chicken piece capacity) BS-26998
FILTERS
Charcoal/Carbon(30 count pkg.) FI-27648
ReusableMesh(single filter)  FI-27014
Fry Pot Cover 5005136
MobileDrawerCover  5006073
Strainer/Skimmer  CE-27400
OilDiscardHose  HO-27686
Banking Strip (1 strip req’dfor every 2 banked fryers) 5008809
MobileOilCaddy  TO-28359
Pre-filter Sieve Kit (for oil filtration system) 5010451

ASF-60G SPECIFICATIONS
33-5/8"(853 mm)
23-3/8"
(592mm)
47-1/2"(1206mm)
6-5/8"
(168mm) 5-9/16"
(141mm) Electric Connection
31-9/16"(802mm) Gas Connection
2-7/8"
(72mm)
36-11/16"(931mm)
150º
15-3/4"
(400mm)
44-3/4"(1136mm)
50-3/8"(1279mm) lift up
INSTALLATION
Gas Fryer Operation & Care Manual • 4
ASF-60G WITH LIFTS
DIMENSIONS exterior (hxwxd)
asf-60g without basket lifts
44-3/4”x15-3/4”x33-5/8”(1136mmx400mmx853mm)
asf-60g with basket lifts
44-3/4”x15-3/4”x33-5/8”(1136mmx400mmx853mm)
basket dimensions (hxwxd)
5-3/16”x5-7/8”x13-13/16”(131mmx149mmx328mm)
WEIGHT
net weight: 248lb(113kg)
ship weight: 330lb(150kg)est
carton dimensions: 39”x22”x55”est
hxwxd (991mmx559mmx1397mm)est
OPTIONS
 FryPotCover 5007596
Strainer/Skimmer CE-27400
Banking Strip (1 strip req’dfor every 2 banked fryers) 1009367
MobileOilCaddy  TO-28359
STANDARD ACCESSORIES
Basket, Half-Size (2 included as standard) BS-27963
Brush Set (one 3-brush set included as standard)
scrub brush bh-28693
straight brush bh-28691
CAPACITY
SHORTENING/OIL:
 62lb(28kg)maximum
LOAD CAPACITY:
 8lb(4kg)maximum

NOTE: To avoid equipment damage, remove the
Mobile Oil Trolley before moving this
appliance with a forklift or pallet lift.
MINIMUM CLEARANCE REQUIREMENTS
combustible non-combustible
surfaces surfaces
right side 0”(0mm) 0” (0mm)
left side 0”(0mm) 0” (0mm)
back 6”(152mm) 6” (152mm)
front 25”(635mm)
plus:6”(152mm)minimumbetweentheelementswingin
theextendedpositionandtheloweredgeoftheexhaust
hood and filter media.
entry clearance: 30”(762mm)uncrated
Ne pas installer à une distance inférirure à celle
indiquée ce-dessous d’une parol en matiére
combustible: Côtés 6 pouches, Arriére 6 pouches.
DANGER
IMPROPER INSTALLATION,
ALTERATION, ADJUSTMENT,
SERVICE, OR MAINTENANCE COULD
RESULT IN SEVERE INJURY, DEATH,
OR CAUSE PROPERTY DAMAGE.
READ THE INSTALLATION,
OPERATING AND MAINTENANCE
INSTRUCTIONS THOROUGHLY
BEFORE INSTALLING OR SERVICING
THIS EQUIPMENT.
DANGER
AVERTISSEMENT : UNE INSTALLATION,
UN AJUSTEMENT, UNE ALTÉRATION,
UN SERVICE OU UN ENTRETIEN NON
CONFORME AUX NORMES PEUT CAUSER
DES DOMMAGES À LA PROPRIÉTÉ, DES
BLESSURES OU LA MORT.
LIRE ATTENTIVEMENT LES DIRECTIVES
D’OPÉRATION ET D’ENTRETIEN
AVANT DE FAIRE L’INSTALLATION, OU
L’ENTRETIEN DE CET ÉQUIPEMENT.
SITE INSTALLATION
CAUTION
METAL PARTS OF THIS EQUIPMENT
BECOME EXTREMELY HOT WHEN
IN OPERATION. TO AVOID BURNS,
ALWAYS USE HAND PROTECTION
WHEN OPERATING THIS APPLIANCE.
INSTALLATION
Gas Fryer Operation & Care Manual • 5
CAUTION
DO NOT USE FORKLIFT FROM
FRONT OR REAR OF UNIT.
USE FORKLIFT FROM SIDE ONLY.
WARNING
MINIMUM CLEARANCES MUST
REMAIN UNOBSTRUCTED.
DO NOT place insulation or
any other type of materials
in clearance areas.

1. It is the responsibility of the installer to verify that
this fryer installation is in compliance with the
specifications listed in this manual and with local code
requirements.
2. Hood installation is required.
3. Both cooking and cleaning functions require
unobstructed access. The frypot, control panel, and
front access door must be maintained free from
obstruction. The access door must be accessible for
service and maintenance.
4. Locatethefryeronafirm,levelsurfaceONLY.The
area surrounding the fryer must be kept clear of all
combustible materials.
5. FOR YOUR SAFETY DO NOT store or use any
flammable liquids or allow flammable vapors in the
vicinity of this fryer or any other appliance.
6. FOR YOUR SAFETY DO NOT place insulation
or any other type of materials in clearance areas.
7. Whenproperlyinstalled,theelectricfryerisdesigned
for operation adjacent to non-combustible floors and
wallswitha6”clearanceattheback.Clearances
fromallcombustibleconstructionisaminimumof6”
(152mm)atthebackandbothsides.Concrete,tile,
terrazzo, or metal surfaces are recommended. Metal
over a combustible material may not meet code for
non-combustible surfaces. Verify site selection with
local codes for specific requirements.
Doit être utilisé seulement sur des planchers non
inflammables.
8. Adequate means must be provided to limit the
movement of this appliance. A restraining device is
required for field installation.
9. DONOTinstallthisfryerinanyareawhereitmaybe
affected by any adverse conditions such as steam or
dripping water, etc. DO NOT install the fryer over a
drain.
10. LEVELING: Make certain the
fryer is positioned firmly on all four
supporting casters. Level fryer front-
to-back and side-to-side by holding
lowercollar(#2)whiletwistingupper
collar(#1).Restraining ties can be
used for stabilization if necessary. Use
anallenwrench(#3)tolockcasterin
position.
SITE INSTALLATION
CAUTION
TO PREVENT PERSONAL INJURY,
USE CAUTION WHEN MOVING OR
LEVELING THIS APPLIANCE.
DANGER
To avoid electrical shock, this
appliance MUST be adequately
grounded in accordance with local
electrical codes or, in the absence of
local codes, with the current edition
of the National Electrical Code ANSI/
NFPA No. 70. In Canada, all electrical
connections are to be made in
accordance with CSA C22.1, Canadian
Electrical Code Part 1 or local codes.
1
2
3
INSTALLATION
Gas Fryer Operation & Care Manual • 6
WARNING
BURN WARNING: Make certain the
fryer is stabilized before operation to
prevent any movement or tipping and the
possibility of severe burns caused by
hot, splashing shortening or oil.
WARNING
IMPROPER INSTALLATION
MAY RESULT IN FIRE.
Carefully read and follow all installation
instructions located in this manual.

1. AsingleASF-75GorASF-60Gauto-liftgasfryer
requires a minimum of 120 CFM make-up air for
naturalgasand48CFMforpropanegas.Kitchen
ventilation must be of sufficient capacity to prevent
a negative-pressure condition. DO NOT obstruct or
restrict ventilation nor the air flow required to support
combustion.
2. DO NOTobstructtheflowoftheexhaustflueatthe
top rear of the fryer. It is especially critical that gas
supply piping and electrical support cord and/or
receptacle be routed away from the path of the hot
combustion fumes.
3. This fryer cannot be direct vented.
4. Install the fryer under a ventilation hood meeting all
applicable code requirements. Combustion fumes
must be vented in accordance with local, state, or
national codes.
VENTILATION
An adequate ventilation system is required for commercial cooking equipment. Information may be obtained by writing
totheNationalFireProtectionAssociation,BatterymarchPark,Quincy,MA02269.WhenwritingrefertoNFPANo.96.
DANGER
Installation, air adjustment and/or
service work must be in accordance
with all local codes and must be
performed by a certified service
technician qualified to work on
gas appliances.
CAUTION
To prevent malfunction or cause
negative back draft, DO NOT obstruct
exhaust flues or attach any flue
extension that will impede proper
burner operation.
INSTALLATION
Gas Fryer Operation & Care Manual • 7
DANGER
FAILURE TO VENT THIS FRYER PROPERLY
MAY BE HAZARDOUS TO THE
HEALTH OF THE OPERATOR.
Equipment damage and operational problems
may also be the consequence of improper venting.
Any damages sustained by a failure to properly vent
this fryer are not covered under warranty.
Ventilatinghoodsandexhaustsystemsshallbepermittedtobe
used to vent appliances installed in commercial applications.
Whereautomaticallyoperatedappliancesareventedthrougha
ventilatinghoodorexhaustsystemequippedwithadamperor
withapowermeansofexhaust,provisionsshallbemadetoallow
theflowofgastothemainburnersonlywhenthedamperisopen
to a position to properly vent the appliance and when the power
meansofexhaustisinoperation.
in accordance with nfpa 54
commonwealth of massachusetts only.
WARNING
This appliance shall be installed in
conformity with the current regulations
and used only in a well ventilated location.
Consult the instructions before
installing and using this appliance.

Declared input (kW) 35.15
Gas Group I2H(20),I2E(20),I2E+(20/25),I2L(25),I3+(28-30/37),
I3B/P(30),I3B/P(37),I3B/P(50),I3P(37),I3P(50)
Inlet pressure (mbar) 17.5(NAT)and27.5(LP)
Declared setting pressure at the
outlet from the gas valve (mbar)
12.5(NAT)and25(LP)
Main burner type Infrared type with blower and venturi valve
Number of injectors 1
Main injector type N/A
Main injector size and markings N/A
Main burner aeration opening size Variable pre-set at factory
Ignition Direct spark electronic ignition
Inlet connection 20.995mmmalethread
The Alto-Shaam open gas fryer has been set to operate
with either natural gas or propane as indicated on the
fryer identification name plate.
The appliance and its individual shutoff valve must be
disconnected from the gas supply piping system during any
pressuretestingofthatsystemattestpressuresinexcessof1/2
psi. The appliance must be isolated from the gas supply piping
system by closing its individual manual shutoff valve during any
pressure testing of the gas supply piping system at test pressures
equal to or less than 1/2 psi.
NOTE: Customer/installer must provide manual gas
shut-off valve in accordance with local code
requirements.
GAS PRESSURE CHART
The fryer has been factory adjusted according to
the gas type specified on the fryer identification
name plate.
GAS FRYER TECHNICAL SPECIFICATIONS
Natural Gas
 Min.ConnectedPressure 5.0”W.C. 1.2kPa
 Max.ConnectedPressure 14.0”W.C. 3.5kPa
Gas Consumption 120 CFM
Gross Thermal Output 120,000 Btu/hr
Propane Gas
 Min.ConnectedPressure 10.0”W.C. 2.5kPa
 Max.ConnectedPressure 14.0”W.C. 3.5kPa
 GasConsumption 48CFM
Gross Thermal Output 120,000 Btu/hr
INSTALLATION REQUIREMENTS
gas connection:1/2” npt
check plumbing codes for proper supply line sizing to
attain minimum burner manifold pressure shown:
natural gas: 5.0”W.C.
propane gas: 10.0”W.C.
maximum inlet pressure: 14”W.C.
NOTE:Ifaflexiblegaslineisused,itmustbeAGA
approved, commercial type and at least 3/4”I.D.
hood installation is required
GAS SPECIFICATIONS
natural gas propane gas
120,000 BTU/hr. input 120,000 BTU/hr. input
GAS SPECIFICATIONS
DANGER
CONNECTING TO THE WRONG GAS
SUPPLY COULD RESULT IN FIRE OR
AN EXPLOSION CAUSING SEVERE
INJURY AND PROPERTY DAMAGE.
WARNING
TO AVOID SERIOUS PERSONAL
INJURY, installation of this appliance
must conform to local, state, and
national codes; the current edition
of the American National Standard
Z223.1, National Fuel Gas Code, and
all local municipal building codes.
In Canada, installation must be in
accordance with Standard CAN/CSA
B 149.1 and Installation Codes - Gas
Burning Appliances, and local codes.
INSTALLATION
Gas Fryer Operation & Care Manual • 8
Category I2H at 20 mbar for use in AT, DK, FI, IE, IT, PT, SE, CH.
Category I2E(20) at 20/25 mbar for use in DE, LU.
Category I2E+(20/25) at 20/25 mbar for use in BE, FR.
Category I2L(25) at 25 mbar for use in NL.
Category I3+(28-30/37)at28-30/37mbarforuseinBE,FR,IE,IT,LU,
PT, CH.
Category I3B/P(30) at 30 mbar for use in DK, FI, NL, SE.
Category I3B/P(50) at 50 mbar for use in AT, DE, CH.
Category I3P(37)at37mbarforuseinFI,DE,IE,CH.

Use an approved
gas pipe sealant at
allexternalthreaded
connections, gas
piping used on gas
connections must
avoid sharp bends
that may restrict the
flow of gas to the
appliance. If the
connected pressure
exceeds14.0”W.C.(3.5kPa),astep-downregulatoris
required to be supplied by the owner/operator.
Close the individual manual shut-off valve to
isolate the fryer from the gas supply piping system
during any pressure testing at test pressures equal
to or less than 1/2psig.(3.4kPa).Thefryerand
individual shut-off valve must be disconnected
from the gas supply piping system during
any pressure testing at pressures in
excessof1/2psig.(3,4kPa).
In the U.S.A., installation must conform to local
codes or, in the absence of local codes, with the
current edition of the National Fuel Gas Code,
NFPA-54andANSIZ83.11aCSA1.8a2004(or
latestedition).InCanada,installationmustbein
accordancewithlocalcodes,CAN/CGA-B149.1,
Installation for Natural Gas Burning Appliances
and Equipment(latestedition)orCAN/
CGA-B149.2Installation for Propane Burning
Appliances and Equipment(latestedition).
The inlet supply line must be properly sized
to accommodate all individual appliances
simultaneously used on the same line but must
neverbesmallerthan3/4”I.D.
LEAK TESTING
Installation requires gas leak testing on all gas
piping and fittings. Use an approved electronic
leak device or a soap and water solution at all gas
connections. If bubbling appears when using a soap
and water solution, the connection must be refitted.
Never use an open flame to leak test.
INCORRECT CORRECT
A
B
C
D
E
F
G
H
GAS INTAKE
A-G Installation elbow
B Wall Valve
C-D Three-piece union fitting
(minimum 1 per installation)
E-F End connector for the flexible tube
H Marking line
GAS CONNECTION
DANGER
Installation, air adjustment and/or
service work must be in accordance
with all local codes and must be
performed by a certified service
technician qualified to work on
gas appliances.
DANGER
NEVER USE AN OPEN
FLAME TO LEAK TEST.
INSTALLATION
Gas Fryer Operation & Care Manual • 9

The fryer must be supplied with a connector that
complies with all state and local installation codes.
Any appliance that is not furnished with a power
supply cord but that includes a set of casters must be
tethered. Adequate means must be provided to limit
the movement of this appliance without depending
on or transmitting stress to the electrical conduit.
The following requirements apply:
1. Castersmustbeamaximumheightof4-inches(102mm).
2. Such mobile appliances must be installed with the
useofaflexibleconnectorsecuredtothebuilding
structure.
A mounting connector for a restraining device is
located on the lower back flange of the appliance
chassis,approximately7-inches(178mm)fromthe
floor.Aflexibleconnectorisnotsuppliedbynoris
it available from the factory.
RESTRAINT REQUIREMENTS - MOBILE EQUIPMENT
INSTALLATION
Gas Fryer Operation & Care Manual • 10
WARNING
RISK OF ELECTRIC SHOCK.
Appliance must be secured
to building structure.

An electrical wiring diagram is located in the front
access door of the fryer. The fryer must be installed by a
qualified electrician. This appliance must be branch circuit
protected with proper ampacities, in accordance with
the wiring diagram located in the fryer. The fryer must
be properly grounded in accordance with the National
Electrical Code and applicable local codes. A means to
disconnecttheunitmustbeincorporatedintothefixed
wiring in accordance with wiring codes.
Wiresizeforthemainincomingpowertotheunitmust
match the minimum size listed in the specifications
applicable to the specific fryer. For supply connections,
locate the wire size posted on the label located on the
electricalcontrolboxcover,behindtheservicepanelor
elsewhere listed in this manual.
Before operating the fryer, check all cable connections
in the electrical connection area for tightness since
connections can loosen during transport.
230V:
To prevent an electrical shock hazard between the
appliance and other appliances or metal parts in close
vicinity, an equalization-bonding stud is provided. An
equalization bonding lead must be connected to this
stud and the other appliances / metal parts to provide
sufficient protection against potential difference. The
terminal is marked with the following symbol.
DANGER
To avoid electrical shock, this
appliance MUST be adequately
grounded in accordance with local
electrical codes or, in the absence of
local codes, with the current edition
of the National Electrical Code ANSI/
NFPA No. 70. In Canada, all electrical
connections are to be made in
accordance with CSA C22.1, Canadian
Electrical Code Part 1 or local codes.
DANGER
ENSURE POWER SOURCE
MATCHES VOLTAGE STAMPED
ON APPLIANCE NAMEPLATE.
ELECTRICAL REQUIREMENTS
ELECTRICAL • ASF-75G with basic control
voltage phase cycle/hz amps kw
120 (agcy) 1 60 7.2 0.86 nema 5-15p
15a-125v plug
230 (agcy) 1 50 4.0 0.92 cee 7/7
220-230v plug
INSTALLATION
Gas Fryer Operation & Care Manual • 11
Hard wired models:
Hard wired models must be equipped with a
countrycertifiedexternalallpoledisconnection
switch with sufficient contact separation.
If a power cord is used for the connection of the
productanoilresistantcordlikeH05RNorH07RN
or equivalent must be used.
ELECTRICAL • ASF-60G with basic control
voltage phase cycle/hz amps kw cord & plug
120 (agcy) 1 60 2.2 0.27
230 1 50 1.0 0.23
nema 5-15p
15a-125v plug
cee 7 / 7
220-230v plug

Gas Fryer Operation & Care Manual • 12
OPERATION
OIL/SHORTENING REQUIREMENTS
TheASF-75Grequires73-pounds(33kg)ofoilor
shortening in the frypot and the ASF-60G requires
62-pounds(28kg)ofoilorshortening.Useonlyquality,
high-grade oil/shortening in the fryer. The high moisture
content of many lower grade shortening will result in
excessivefoamingandboilover.Thecoldoil/shortening
level requirement for the fryer is indicated below.
NOTE: ALWAYS maintain the proper level of
shortening by adding fresh oil/shortening
to the frypot whenever needed.
Check the quality of the oil/shortening in the frypot on a
daily basis for signs of deterioration. Use an approved test
kit.Signsofshorteningdeteriorationincludeexcessive
boiling, smoking, foaming, bad taste, and rancid odor.
Discard any shortening before it degrades to the point
of affecting product quality. Always filter the oil on a
regular basis and keep the frypot clean.
Remove ice crystals and ensure that food is dry before
frying.Excessivewaterandicecancauseoiltosplatter
or overflow. Do not over fill the basket. Food needs to be
surrounded by oil for best frying results.
Maximumshorteninglifeisachievedbyloweringthe
temperatureofthefryerto250°F(121°C)orturningthe
fryer station off when not in use. In multiple-station units,
heat only the component fryers necessary to meet cooking
needs.
Gas Fryer Operation & Care Manual • 12
OPERATION
OIL/SHORTENING REQUIREMENTS
CAUTION
METAL PARTS OF THIS EQUIPMENT
BECOME EXTREMELY HOT WHEN
IN OPERATION. TO AVOID BURNS,
ALWAYS USE HAND PROTECTION
WHEN OPERATING THIS APPLIANCE.
CAUTION
Cold oil or shortening expands as
the temperature increases. To avoid
injury and equipment damage, allow for
expansion by filling to the cold oil fill line.
WARNING
FAILURE TO PLACE SOLID SHORTENING
DIRECTLY ON THE BOTTOM OF THE
FRYPOT CAN CAUSE SERIOUS
EQUIPMENT DAMAGE.
CAUTION
ENSURE THERE IS NO WATER IN THE FRYPOT
BEFORE FILLING WITH OIL/SHORTENING. WHEN
COOKING COMPOUNDS ARE HEATED TO COOKING
TEMPERATURE, WATER IN THE FRYPOT WILL CAUSE
OIL TO SPLATTER AND MAY BE A BURN HAZARD.
DANGER
The flash point of shortening
occurs at a lower temperature
the longer the shortening is
used. Discard any shortening
showing signs of deterioration
to avoid serious burns, fire,
and property damage.
FRONT
MAXIMUM HOT
OIL FILL LINE
MINIMUM
HOT OIL FILL LINE
TOP BEND INSIDE
OIL KETTLE
COLD OIL
FILL LINE
fryer cross-section
oil/shortening levels
CAUTION
FIRE OR EQUIPMENT DAMAGE CAN RESULT FROM
IMPROPER SHORTENING LEVELS. THE LEVEL OF
SHORTENING MUST ALWAYS BE ABOVE THE HEAT
EXCHANGERS WHEN THE FRYER IS OPERATING.
THE REQUIRED SHORTENING LEVEL MUST ALWAYS
BE ABOVE THE MINIMUM HOT OIL FILL LINE.

Gas Fryer Operation & Care Manual • 13
OPERATION
Gas Fryer Operation & Care Manual • 13
OPERATION
igntion
alarm
master
power
switch
control
reset
oil
hi-limit
reset
open
closed
kettle drain
selector
ASF-60G, 120V
ASF-75G, 120V WITH FILTRATION
oil
hi-limit
reset
nozzle
kettle
selector
nozzle
connection pump
master
power
switch
ignition
alarm
control
reset
open
closed
kettle drain
selector
CONTROLS BEHIND ACCESS PANEL
ASF-75G, 230V
control
reset
master
power
switch
ignition
reset
ignition
alarm
open
closed
kettle drain
selector
oil
hi-limit
reset
ignition
alarm
master
power
switch
ignition
reset
oil
hi-limit
reset
open
closed
kettle drain
selector
ASF-60G, 230V
control
reset

NOTE: Perform an initial boil-out to clean and
sanitize the fryer before operating.
Carbonized deposits along with an accumulation of oil
will eventually build-up on the interior of the frypot as
well as fryer accessories. It is important to periodically
remove these deposits, not only to maintain fryer
efficiency, but also to provide the highest product quality.
NOTE: Always wear eye protection or a face
shield and protective rubber gloves
when cleaning the frypot as boil-out
chemical is an alkaline solution and can
cause severe burns.
NOTE: Because each fryer is controlled
separately, the following procedure must
be followed for every unit in multiple-
fryer units.
NOTE: Manual Boil-Out can only be performed
when the actual temperature of the
frypot is less than 230°F (110°C).
1. Place the mobile oil drawer or heat safe container
under the drain. Rotate drain valve to “OPEN”to
drain oil. If equipped with the optional oil hand wand,
use the wand to pump oil into the frypot to further rinse
food particles out of the frypot. Carefully disconnect the
wand from fryer and drain any residual oil from the
wand into the frypot and then drain the remaining oil
from frypot.
2. Whilewearingheatresistantgloves,wipeexcessoilout
of inside of frypot with paper towel or clean rag.
3. If oil has been drained into a mobile oil drawer, empty
theoilfromthedrawer.Washtheoildrawer,rinsewith
clean water, and dry drawer thoroughly.
4. If the fryer is equipped with a filtration system, clean
or replace the filter in the filter cartridge and remove
cartridgefromunit.(Seefiltrationinstructionsonpage
19.)
5. Open the front access door. If equipped with a
filtration system, rotate the Kettle/Nozzle selector to
the “KETTLE”position, then rotate the drain valve
clockwise until rotation stops and the drain valve is
“CLOSED.”
6. Fillthefryertothemaximumoilfilllinewithwater.
FRONT
MAXIMUM HOT
OIL FILL LINE
MINIMUM
HOT OIL FILL LINE
TOP BEND INSIDE
OIL KETTLE
COLD OIL
FILL LINE
fryer cross-section
oil/shortening levels
Gas Fryer Operation & Care Manual • 14
OPERATION
BOIL-OUT PROCEDURE
CAUTION
TO AVOID DAMAGING THE PUMP AND CONTAMINATING
CLEAN OIL WITH BOIL-OUT CHEMICAL ON UNITS EQUIPPED
WITH A FILTRATION SYSTEM, NEVER ALLOW BOIL-OUT
SOLUTION OR RINSE WATER TO CIRCULATE THROUGH THE
FRYER PUMP SYSTEM.
CAUTION
BEFORE ENTERING THIS PROGRAM, MAKE CERTAIN
THE FRYPOT IS EMPTY OF ALL OIL OR SHORTENING.
CAUTION
BOIL-OUT SOLUTION AND SURROUNDING METAL
SURFACES BECOME EXTREMELY HOT. TO AVOID
BURNS, ALWAYS USE HAND PROTECTION WHEN
PERFORMING THE BOIL-OUT FUNCTION AND FOLLOW
THE MANUFACTURER’S SAFETY INSTRUCTIONS FOR
THE BOIL-OUT PRODUCT BEING USED.
CAUTION
DO NOT LEAVE THE FRYER UNATTENDED DURING
THE BOIL-OUT PROCESS. THE FRYER MUST BE
CONTINUOUSLY MONITORED FOR BOIL-OVER
CONDITIONS, PARTICULARLY IN HIGH-ALTITUDE
LOCATIONS. IF BOIL-OVER IS IMMINENT, IMMEDIATELY
TURN THE MASTER POWER SWITCH OFF AND ALLOW
THE SOLUTION TO COOL. WHEN THE SOLUTION HAS
COOLED, RE-ENTER THE BOIL-OUT MODE.

Gas Fryer Operation & Care Manual • 15
OPERATION
7. Add boil out solution. Carefully follow the
manufacturer’sdirectionsformixingtheboil-out
solution.
8. TurntheMasterPowerSwitch(locatedbehindthe
frontaccessdoor)tothe“ON” position and press the
CONTROL RESET.
9. WaituntiltheLED reads “HEAt”, then press the
BOIL OUT button on the control panel.
10. When192°F(89°C)isreached,theLED will display
“bOIL”, the temperature will be maintained. Using
a separate timer, allow the frypot to boil-out for 10
minutes.
11. After the 10 minute boil-out period, turn the Master
Power Switch located behind the front access door to
the “OFF” position.
12. Wearingprotectiveglovestoavoidburns,scrubthe
inside of the fypot with a long-handled scrub brush.
13. Place another empty and dry mobile oil drawer
or heat safe container under the drain. Rotate the
drain to the “OPEN”position. The handle should
be rotated counterclockwise until it stops. Allow
the boil-out solution to completely drain into mobile
oil drawer or a heat safe container. Discard boil-
out solution. Return the drawer to the fully-inserted
position beneath the fryer.
14. Making sure the drain is “OPEN”, rinse all boil-out
solution from fry pot, drain, burner holes, etc. Follow
the boil-out solution manufacturer’s additional
boil-out instructions to rinse the frypot in order to
neutralize boil-out cleaner residue. Discard rinse
solution.
15. There may be residual boil-out solution in the oil fill-
hole and tube. This must be flushed out and discarded
separately before filling the tank with new oil to avoid
contamination of new oil.
For filtration-equipped fryers: Place a small amount of
clean, liquid oil in the clean fat drawer. Pump a small
amountofoilthroughthethesystem.Whilewearing
heat resistant gloves, catch the oil that is pumped
through the fill hole inside frypot with paper towel.
Drain the oil. Rinse fry pot with a small amount of
water.
For units without a pump or filtration system: Pour a
small amount of oil into the the fryer and drain it into a
separate container. Rinse frypot and frypot drain with
water.
16. Following the boil-out and rinse procedure, wipe
dry all accessible interior metal surfaces and interior
accessories with a clean, dry cloth to remove
remaining moisture. Clean and dry the fry baskets
separately.
NOTE: Make sure the inside of the frypot, the
drain opening and all parts that come
into contact with new oil/shortening are
as dry as possible.
17. Wipetheexteriorofthefryercabinetwitha
degreaser/sanitizer suitable for use on food contact
surfaces. Always follow the manufacturer’s
instructionsand/ormixingdirectionsforproper
solution strengths.
 Wipeexteriorstainlesssteelsurfaceswiththegrain
of the metal and avoid the use of abrasive pads, steel
wool, or metal implements.
18. Rotate drain to “CLOSED” position.
19. Replace the oil filter if equipped with filtration system.
(Seeinstructionsonpages19.)
20. Fill tank with new oil or shortening.
BOIL-OUT PROCEDURE
CAUTION
KEEP A CONTAINER OF COLD WATER ON HAND
DURING BOIL-OUT IN CASE OF BOIL-OVER. IF BOIL-
OVER IS IMMINENT, IMMEDIATELY TURN OFF MASTER
POWER SWITCH AND POUR COLD WATER INTO FRYPOT
TO QUICKLY REDUCE SOLUTION TEMPERATURE.
CAUTION
ENSURE THERE IS NO WATER IN THE FRYPOT
BEFORE FILLING WITH OIL/SHORTENING. WHEN
COOKING COMPOUNDS ARE HEATED TO COOKING
TEMPERATURE, WATER IN THE FRYPOT WILL CAUSE
OIL TO SPLATTER AND MAY BE A BURN HAZARD.

Gas Fryer Operation & Care Manual • 16
OPERATION
NOTE: Perform an initial Boil-Out to clean
and sanitize the fryer station before
operating. (See page 14.)
1. Service is to be performed by an authorized
Alto-Shaam service agent.
2. Ensure all local electrical codes, fire codes, and all
other requirements such as hood installation have
been met in the process of installation
NOTE: Because each fryer station is
controlled separately, the following
procedures must be followed for
every component fryer in multiple-
station units.
3. Open front access door and ensure drain valve is is in
the CLOSED position. The handle should be rotated
clockwise until it stops.
4. Fill frypot with frying compound as indicated. (see
illustration on the oil/shortening requirements page)
5. The Master Power Switch is located behind the front
access door. Turn Master Power Switch “ON.”
6. Press the CONTROL RESET button.
7. The LED display on the basic control panel will
indicate “-AS-”, the software version, and then “C ”.
8. Whenthefryerhasreached135°F,themeltcycleis
complete and the LED display on the control panel
will indicate “HEAt”.
9. Whenthefryerdisplaystheset-pointtemperature,
product can be fried.
10. More detailed operating guidelines along with
information on programming are located within this
manual.
11. To shutdown the fryer, turn the Master Power Switch
located behind the front access door to the “OFF”
position.
NOTE: for your protection The fryer station is
furnished with a hi-limit safety shutoff that will
disengage the control if the frying compound
temperature in the frypot would ever exceed
415°F (213°C).  The LED will display “Hi”, the
heat will shut off, the timer will be cancelled,
and a constant alarm will sound. In this event,
allow the frying compound temperature to drop
below415°F(213°C).Openthefrontaccessdoor
and press the OIL HI-LIMIT RESET button for
a period of 3-seconds to restart the control.
START UP & GENERAL OPERATION
DANGER
BEFORE STARTING THE
APPLIANCE, MAKE CERTAIN
YOU DO NOT DETECT THE
ODOR OF GAS.
iF the odor oF gas is detected:
• DO NOT attempt to light any appliance.
• DO NOT touch any electrical switches.
• Extinguish any open fl ame.
• Use a telephone OUTSIDE THE
PROPERTY & IMMEDIATELY
contact your gas supplier.
• If unable to contact your gas supplier,
contact the fire department.

Gas Fryer Operation & Care Manual • 17
OPERATION
THOROUGHLY CLEAN DAILY
The cleanliness and appearance of this unit
will contribute considerably to operating efficiency
and savory, appetizing food.
Good equipment kept clean works better
and lasts longer.
1. Disconnect unit from power source, and let cool.
2. Remove all detachable items. Clean these items
separately with a good grease solvent or commercial
detergent. Rinse well and dry.
3. Clean control panel, door vents, door handles,
and door gaskets thoroughly since these areas harbor
food debris. Rinse by wiping with
sponge and clean warm water. Wipedrywith
a clean cloth.
4. To help maintain the protective film coating on
polishedstainlesssteel,cleantheexterioroftheunit
with a cleaner recommended for stainless
steel surfaces. Spray the cleaning agent on a
clean cloth and wipe with the grain of the
stainless steel.
NOTE: Avoid the use of abrasive cleaning, compounds,
chloride based cleaners,
or cleaners containing quaternary salts.
Neverusehydrochloricacid(muriaticacid)
on stainless steel.
Alwaysfollowappropriatestateorlocalhealth(hygiene)
regulations regarding all applicable cleaning and
sanitation requirements for foodservice equipment.
CLEANING & MAINTENANCE
DANGER
DISCONNECT UNIT FROM
POWER SOURCE BEFORE
CLEANING OR SERVICING.
DANGER
AT NO TIME SHOULD THE INTERIOR
OR EXTERIOR BE STEAM CLEANED,
HOSED DOWN, OR FLOODED WITH
WATER OR LIQUID SOLUTION OF
ANY KIND. DO NOT USE WATER JET
TO CLEAN.
SEVERE DAMAGE OR
ELECTRICAL HAZARD
COULD RESULT.
WARRANTY BECOMES VOID IF
APPLIANCE IS FLOODED
CAUTION
TO PROTECT STAINLESS STEEL
SURFACES, COMPLETELY AVOID
THE USE OF ABRASIVE CLEANING
COMPOUNDS, CHLORIDE BASED
CLEANERS, OR CLEANERS
CONTAINING QUATERNARY SALTS.
NEVER USE HYDROCHLORIC ACID
(MURIATIC ACID) ON STAINLESS
STEEL. NEVER USE WIRE
BRUSHES, METAL SCOURING
PADS OR SCRAPERS.
N
O
W
I
R
E
B
R
U
S
H
E
S
N
O
S
T
E
E
L
P
A
D
S
N
O
S
C
R
A
P
E
R
S

Gas Fryer Operation & Care Manual • 18
OPERATION
Careful observation of the finished food product will
help determine optimal filtering frequency. Filtering
the cooking oil at regular intervals will help ensure food
quality.
FOR BEST RESULTS:Do not allow the temperature of
the oil to decrease below the “Idle Mode” temperature of
250°F(121°C)whenfiltering.Iffilteringattheendofthe
day, pump oil back into the kettle while still hot. Do not
allow oil to cool before returning to kettle.
1. Openthefrontaccessdoor.WiththeNozzle
selector in the “KETTLE FILL” position, rotate the
drain valve counterclock-wise until rotation stops
and the drain valve is in the “OPEN” position.
Power to the main control panel will automatically
switch “OFF.”
2. Allow contents of the fryer to completely drain into
fat drawer.
3. Press the PUMP “ON” to allow the oil to circulate
through the drain system to flush crumbs. Using the
brushes provided, brush the sides and bottom of the
fryer while the oil is circulating through the system.
Usetheanglebrushundertheheatexchangers.
4. Press the PUMP “OFF” and allow contents of the
fryer to completely drain.
5. Rotate the drain valve clockwise to the
“CLOSED” position.
6. Press the PUMP “ON” and allow the fryer to refill
to the recommended level adding additional oil/
shortening as required to maintain proper fill level.
7. Press the PUMP “OFF” button.
8. After the frypot has completely refilled, pull out the
mobile oil trolley and discard the disposable paper
or carbon filter into a proper receptacle or clean off
reusable mesh filter. Clean the filter assembly and
oil trolley, if needed.
9. Replace the oil filter and return the trolley to the
proper position beneath the fryer.
10. Push the ELEMENT HI LIMIT reset button.
11. Press and hold the “ON/OFF” key on the main
control panel for 1-1/2 to 2 seconds to energize the
fryer. Continue normal fryer operation after the
preheat function has been completed.
OIL FILTRATION INSTRUCTIONS (FOR UNITS WITH INSTALLED OPTION)
CAUTION
METAL PARTS OF THIS EQUIPMENT
BECOME EXTREMELY HOT WHEN
IN OPERATION. TO AVOID BURNS,
ALWAYS USE HAND PROTECTION
WHEN OPERATING THIS APPLIANCE.
CAUTION
OPERATORS MUST BE MADE AWARE OF THE HAZARDS
INVOLVED IN THE OPERATION OF A HOT OIL FILTERING
SYSTEM. ON-SITE SUPERVISION DURING THE
FILTRATION PROCESS AND THE CLEANING PROCESS IS
STRONGLY RECOMMENDED.
WARNING
TO AVOID PERSONAL INJURY, USE
CAUTION WHEN SURFACES BECOME
SLIPPERY DUE TO SPILLED OR
DRIPPING OIL.
