Alto-Shaam FryTech Series Operating instructions

W164 N9221 Wa er S ree • P.O. Box 450 • Menomonee Falls, Wisconsin 53052-0450 USA
PHONE: [phone] • 800.558.8744 USA/CANADA FAX: [phone] • 800.329.8744 U.S.A.ONLY
www.alto-s aam.com
®
M N - 2 8 6 4 1 • 0 3 / 0 9
PRINTED IN U.S.A.
G A S F R Y E R
F y Te c h S e i e s
ASF-60G and
ASF-75G
Gas F ye s
with
Basic Cont ol
• INSTALLATION
• OPERATION
• MAINTENANCE
ASF-60G shown with
optional automatic
basket lifts
ASF-75G shown with
optional automatic
basket lifts

D E L I V E R Y
This Alto-Shaa appliance has been
thoroughly tested and inspected to insure only the
highest quality unit is provided. Upon receipt,
check for any possible shipping da age and report
it at once to the delivering carrier. See
Transportation Damage and Claims section
located in this manual.
This appliance, co plete with unattached
ite s and accessories, ay have been delivered in
one or ore packages. Check to ensure that all
standard ite s and options have been received
with each odel as ordered.
Save all the infor ation and instructions
packed with the appliance. Co plete and return
the warranty card to the factory as soon as
possible to assure pro pt service in the event of a
warranty parts and labor clai .
This anual ust be read and understood by
all people using or installing the equip ent
odel. Contact the Alto-Shaa service
depart ent if you have any questions concerning
installation, operation, or aintenance.
NOTE: All clai s for warranty ust include the
full odel nu ber and serial nu ber of
the unit.
UNPACKING
1. Carefully re ove the
appliance fro the
carton or crate.
NOTE: Do not discard the
carton and other
packaging aterial
until you have
inspected the unit
for hidden da age
and tested it for
proper operation.
2. Read all instructions in this anual carefully
before initiating the installation of this appliance.
DO NOT DISCARD THIS MANUAL.
This anual is considered to be part of the
appliance and is to be provided to the owner or
anager of the business or to the person
responsible for training operators. Additional
manuals are available from the Alto-Shaam
service department.
3. Re ove all protective plastic fil , packaging
aterials, and accessories fro the appliance
before connecting electrical power. Store any
accessories in a convenient place for future use.
®
®
®
KEEP THIS MANUAL IN A CONVENIENT LOCATION FOR REFERENCE.
Ga s Fr ye r Op er at on & Ca re M an ua l • 1
W A R N I N G
In the event of loss of power to the
appliance, turn the “burner control
knobs” to the OFF position. Remove
food product from the unit. If burner
control fails to extinguish the flame,
shut off main gas valve located in
rear of unit.
D A N G E R
BEFORE STARTING THE
APPLIANCE, MAKE CERTAIN
YOU DO NOT DETECT THE
ODOR OF GAS.
IF THE ODOR OF GAS IS DETECTED:
• DO NOT attempt to lig t any appliance.
• DO NOT touc any electrical switc es.
• Extinguis any open flame.
• Use a telep one OUTSIDE THE
PROPERTY & IMMEDIATELY
contact your gas supplier.
• If unable to contact your gas supplier,
contact t e fire department.

1. This appliance is intended to cook, hold or
process foods for the purpose of human
consumption. No other use for this appliance is
authorized or recommended.
2. This appliance is intended for use in commercial
establishments where all operators are familiar
with the purpose, limitations, and associated
hazards of this appliance. Operating
instructions and warnings must be read and
understood by all operators and users.
3. Any troubleshooting guides, component views,
and parts lists included in this manual are for
general reference only and are intended for use
by ualified technical personnel.
4. This manual should be considered a permanent
part of this appliance. This manual and all
supplied instructions, diagrams, schematics,
parts lists, notices, and labels must remain with
the appliance if the item is sold or moved to
another location.
N O T E : Used to notify personnel of
installation, operation, or
maintenance information that is
important but not hazard related.
C A U T I O N
Used to indicate the presence of a hazard that can
or will cause minor personal injur , propert
damage, or a potential unsafe practice if the
warning included with this s mbol is ignored.
C A U T I O N
Used to indicate the presence of a
hazard that can or will cause minor or
moderate personal injur or propert
damage if the warning included with
this s mbol is ignored.
D A N G E R
Used to indicate the presence of a
hazard that WILL cause severe
personal injur , death, or substantial
propert damage if the warning
included with this s mbol is ignored.
W A R N I N G
Used to indicate the presence of a
hazard that CAN cause personal injur ,
possible death, or major propert
damage if the warning included with
this s mbol is ignored.
SAFETY PROCEDURES
AND PRECAUTIONS
Knowledge of proper procedures is essential to the
safe operation of electrically and/or gas energized
e uipment. In accordance with generally accepted
product safety labeling guidelines for potential
hazards, the following signal words and symbols
may be used throughout this manual.
N O T E
For equipment de ivered for use
in any ocation regu ated by the
fo owing directive:
DO NOT DISPOSE OF ELECTRICAL
OR ELECTRONIC EQUIPMENT WITH
OTHER MUNICIPAL WASTE.
I N S T A L L A T I O N
Ga s Fr ye r Op er at on & Ca re M an ua l • 2

60-1/16" (1525mm)
Electrical
Gas
Connection
1/2" NPT
24-13/16" (630mm)
9"
(229mm)
Dooropens120°
51-5/16" (1302mm) LIFT UP
45-5/16" (1150mm) LIFT DOWN
37-7/8" (961mm)
60-1/16" (1525mm)
OIL
TROLLEY
12-7/16" (315mm) 3-1/2"
(89mm)
ASF-75G SPECIFICATIONS
C A PA C I T Y
SHORTENING/OIL:
73 lb (33 kg) MAXIMUM
LOAD CAPACITY:
13 lb (6 kg) MAXIMUM
DIMENSIONS EXTERIOR H x x D:
45-5/16" x 24-13/16" x 37-7/8"
(1150mm x 630mm x 961mm)
BASKET DIMENSIONS (HXXD)
11-1/2" x 12-3/4" x 21-3/4"
(292mm x 324mm x 552mm)
WEIGHT EST.
NET EIGHT:360 lb (163 kg)
SHIP EIGHT:520 lb (236 kg)
CARTON DIMENSIONS: H x x D
57" x 34" x 47"
(1448mm x 864mm x 1194mm)
STANDARD ACCESSORIES
■■Basket, Half-Size (2 INCLUDED AS STANDARD)BS-27140
Brush Set (ONE 3-BRUSH SET INCLUDED AS STANDARD)
■■ ANGLE BRUSH BH-28692
■■ SCRUB BRUSH BH-28693
■
■ STRAIGHT BRUSH BH-28691
Filter, Paper (7 PAPER FILTERS INCLUDED AS STANDARD)
■■7 COUNT REFILL PACKAGE FI-27791
■■100 COUNT REFILL PACKAGE FI-27794
OPTIONS
■■ Basket, Full-Size (48 CHIC EN PIECE CAPACITY) BS-26998
FILTERS ■■ Charcoal/Carbon (30 COUNT PKG.) FI-27648
■■ Reusable Mesh (SINGLE FILTER) FI-27014
■■Fry Pot Cover 5005136
■■Mobile Drawer Cover 5006073
■■Strainer/Skimmer CE-27400
■■Oil Discard Hose HO-27686
INSTALLATION
Gas Fryer Operat on & Care Manual • 3
ASF-75G WITH LIFTS AND FILTRATION
37-7/16" (950mm)
44-13/16" (1137mm)
24-13/16" (629mm)
Electrical
Gas
Connection
1/2" NPT
12-7/16"
(315mm)
31-13/16" (808mm)
31-9/16" (802mm)
2-7/8"
(72mm)
Dooropens150°
61-5/8" (1564mm)
ASF-75G, NO LIFTS OR FILTRATION

ASF-60G SPECIFICATIONS
DIMENSIONS EXTERIOR H x W x D:
45-1/8" x 15-3/4" x 33-5/8"
(1146mm x 400mm x 854mm)
BASKET DIME SIO S (HXWXD)
5-7/8" x 5-3/16" x 13-13/16"
(149mm x 131mm x 351mm)
CAPACITY
SHORTENING/OIL: 62 lb (28 kg) MAXIMUM
WEIGHT
ET WEIGHT:248 lb (113 kg)
SHIP WEIGHT:330 lb (150 kg) EST
CARTO DIME SIO S:39" x 22" x 55" EST
(991mm x 559mm x 1397mm) EST
STANDARD ACCESSORIES
■■Basket, Half-Size (2 INCLUDED AS STANDARD)BS-27963
Brush Set (ONE 3-BRUSH SET INCLUDED AS STANDARD)
■■ ANGLE BRUSH BH-28692
■
■ SCRUB BRUSH BH-28693
■■ STRAIGHT BRUSH BH-28691
O P T I O N S
■■Fry Pot Cover 5007596
■■Strainer/Skimmer CE-27400
33-5/8"(854mm)
23-3/8"
(592mm)
47-1/2"(1206mm)
6-5/8"
(168mm)
5-7/16"
(142mm) Gas Connection
31-1/2"(802mm)
Electrical Connection
2-7/8"
(72mm)
150°
15-3/4"
(400mm)
44-3/8"(1127mm)
50-3/8"(1280mm)lift up
I N S T A L L A T I O N
Gas Fryer Operat on & Care Manual • 4

NOTE: To avoid equipment damage, remove the
Mobile Oil Trolley before moving this
appliance with a forklift or pallet lift.
MINIMUM CLEARANCE REQUIREMENTS
COMBUSTIBLE NON-COMBUSTIBLE
SURFACES SURFACES
RIGHT SIDE 0" (152mm) 0" (0mm)
LEFT SIDE 0" (0mm) 0" (0mm)
BACK 6" (152mm) 6" (152mm)
FRONT 25" (635mm)
PLUS :6" (152mm) minimum between the element swing in the
extended position and the lower edge of the exhaust hood
and filter media.
ENTRY CLEARANCE: 30" (762mm) UNCRATED
Ne pas installer à une distance inférirure à celle
indiquée ce-dessous d'une parol en matiére
combustible: C tés 6 pouches, Arriére 6 pouches.
D A N G E R
IMPROPER INSTALLATION,
ALTERATION, ADJUSTMENT,
SERVICE, OR MAINTENANCE COULD
RESULT IN SEVERE INJURY, DEATH
OR CAUSE PROPERTY DAMAGE.
READ THE INSTALLATION,
OPERATING AND MAINTENANCE
INSTRUCTIONS THOROUGHLY
BEFORE INSTALLING OR SERVICING
THIS EQUIPMENT.
D A N G E R
AVERTISSEMENT : UNE INSTALLATION,
UN AJUSTEMENT, UNE ALTÉRATION,
UN SERVICE OU UN ENTRETIEN NON
CONFORME AUX NORMES PEUT CAUSER
DES DOMMAGES À LA PROPRIÉTÉ, DES
BLESSURES OU LA MORT.
LIRE ATTENTIVEMENT LES DIRECTIVES
D’OPÉRATION ET D’ENTRETIEN AVANT
DE FAIRE L’INSTALLATION, OU
L’ENTRETIEN DE CET ÉQUIPEMENT.
SITE INSTALLATION
CAUTION
METAL PARTS OF THIS EQUIPMENT
BECOME EXTREMELY HOT WHEN IN
OPERATION. TO AVOID BURNS,
ALWAYS USE HAND PROTECTION
WHEN OPERATING THIS APPLIANCE.
INSTALLATION
Gas Fryer Operat on & Care Manual • 5
C A U T I O N
DO NOT USE FORKLIFT FROM
FRONT OR REAR OF UNIT.
USE FORKLIFT FROM SIDE ONLY.
W A R N I N G
MINIMUM CLEARANCES MUST
REMAIN UNOBSTRUCTED.
DDOO NNOOTT ppllaaccee iinnssuullaattiioonn oorr
aannyy ootthheerr ttyyppee ooff mmaatteerriiaallss
iinn cclleeaarraannccee aarreeaass..

1. It is the responsibility of the installer to verify that this
fryer installation is in compliance with the
specifications listed in this manual and with local code
requirements.
2. Hood installation is required.
3. Both cooking and cleaning functions require
unobstructed access. The frypot, control panel, and
front access door must be maintained free from
obstruction. The access door must be accessible for
service and maintenance.
4. Locate the fryer on a firm, level surface ONLY. The
area surrounding the fryer must be kept clear of all
combustible materials.
5. FOR YOUR SAFETY DO NOT store or use any
flammable liquids or allow flammable vapors in the
vicinity of this fryer or any other appliance.
6. FOR YOUR SAFETY DO NOT place insulation
or any other type of materials in clearance areas.
7. When properly installed, the electric fryer is designed
for operation adjacent to non-combustible floors and
walls with a 6" clearance at the back. Clearances from
all combustible construction is a minimum of 6"
(152mm) at the back and both sides. Concrete, tile,
terrazzo, or metal surfaces are recommended. Metal
over a combustible material may not meet code for
non-combustible surfaces. Verify site selection with
local codes for specific requirements.
Doit être utilisé seulement sur des planchers non
inflammables.
8. Adequate means must be provided to limit the
movement of this appliance. A restraining device is
required for field installation.
9. DO NOT install this fryer in any area where it may be
affected by any adverse conditions such as steam or
dripping water, etc. DO NOT install the fryer over a
drain.
10. LEVELING: Make certain the fryer
is positioned firmly on all four
supporting casters. Level fryer
front-to-back and side-to-side by
holding lower collar (#2) while
twisting upper collar (#1).
Restraining ties can be used for
stabilization if necessary. Use an allen
wrench (#3) to lock caster in position.
SITE INSTALLATION
C A U T I O N
TO PREVENT PERSONAL INJURY,
USE CAUTION WHEN MOVING OR
LEVELING THIS APPLIANCE.
D A N G E R
To avoid electrical shock, this
applia ce MUST be adequately
grou ded i accorda ce with local
electrical codes or, i the abse ce of
local codes, with the curre t editio
of the Natio al Electrical Code
ANSI/NFPA No. 70. I Ca ada, all
electrical co ectio s are to be
made i accordi g with CSA C22.1,
Ca adia Electrical Code Part 1 or
local codes.
1
2
3
I N S T A L L A T I O N
Gas Fryer Operat on & Care Manual • 6
W A R N I N G
BURN WARNING: Make certain the fryer
is stabilized before operation to prevent
any movement or tipping and the
possibility of severe burns caused by
hot, splashing shortening or oil.
W A R N I N G
IMPROPER INSTALLATION
MAY RESULT IN FIRE.
Carefully read and follow all ins alla ion
ins ruc ions loca ed in his manual.

V E N T I L A T I O N
1. A single ASF-75G or ASF-60G auto-lift gas fryer
requires a minimum of 120 CFM make-up air for
natural gas and 48 CFM for propane gas. itchen
ventilation must be of sufficient capacity to prevent a
negative-pressure condition. DO NOT obstruct or
restrict ventilation nor the air flow required to support
combustion.
2. DO NOT obstruct the flow of the exhaust flue at the
top rear of the fryer. It is especially critical that gas
supply piping and electrical support cord and/or
receptacle be routed away from the path of the hot
combustion fumes.
3. This fryer cannot be direct vented.
4. Install the fryer under a ventilation hood meeting all
applicable code requirements. Combustion fumes
must be vented in accordance with local, state, or
national codes.
An adequate ventilation system is required for commercial cooking equipment. Information may be obtained by writing
to the National Fire Protection Association, Batterymarch Park, Quincy, MA 02269. When writing refer to NFPA No. 96.
D A N G E R
Installation, air adjustment and/or
service work must be in accordance
with all local codes and must be
performed by a certified service
technician qualified to work on
gas appliances.
CAUTION
To prevent malfunction or cause
negative back draft, DO NOT obstruct
exhaust flues or attach any flue
extension that will impede proper
burner operation.
INSTALLATION
Gas Fryer Operat on & Care Manual • 7
D A N G E R
FAILURE TO VENT THIS FRYER PROPERLY
MAY BE HAZARDOUS TO THE
HEALTH OF THE OPERATOR.
Equipment damage and perati nal pr blems
may als be the c nsequence f impr per venting.
Any damages sustained by a failure t pr perly
vent this fryer are n t c vered under warranty.
Ventilatin hoods and exhaust systems shall be permitted to be
used to vent appliances installed in commercial applications.
Where automatically operated appliances are vented throu h a
ventilatin hood or exhaust system equipped with a damper or
with a power means of exhaust, provisions shall be made to allow
the flow of as to the main burners only when the damper is open
to a position to properly vent the appliance and when the power
means of exhaust is in operation. IN ACCORDANCE WITH NFPA 54
COMMONWEALTH OF MASSACHUSETTS ONLY.

The Alto-Shaam open gas fryer has been set to operate
with either natural gas or propane as indicated on the
fryer identification name plate.
The appliance and its individual shutoff valve must be
disconnected from the gas supply piping system during any
pressure testing of that system at test pressures in excess of 1/2
psi. The appliance must be isolated from the gas supply piping
system by closing its individual manual shutoff valve during any
pressure testing of the gas supply piping system at test pressures
equal to or less than 1/2 psi.
NOTE: Customer/installer must provide manual gas shut-
off valve in accordance with local code
requirements.
GAS PRES S U R E C H ART
The fryer has been factory adjusted according to
the gas type specified on the fryer identification
name plate.
GAS FRYER TECHNICAL SPECIFICATIONS
N a t u r a l G a s
Min. Connected Pressure 5.0" W.C. 1.2 kPa
Max. Connected Pressure 14.0" W.C. 3.5 kPa
Gas Consumption 120 CFM
Gross Thermal Output 120,000 Btu/hr
Propane Gas
Min. Connected Pressure 10.0" W.C. 2.5 kPa
Max. Connected Pressure 14.0" W.C. 3.5 kPa
Gas Consumption 48 CFM
Gross Thermal Output 120,000 Btu/hr
INSTALLATION REQUIREMENTS
GAS CONNECTION: 1/2" NPT
CHEC PLUMBING CODES FOR PROPER SUPPLY LINE SIZING TO
ATTAIN MINIMUM BURNER MANIFOLD PRESSURE SHOWN:
NATURAL GAS: 5.0" W.C.
PROPANE GAS: 10.0" W.C.
MAXIMUM INLET PRESSURE: 14" W.C.
NOTE: If a flexible gas line is used, it must be AGA
approved, commercial type and at least 3/4" I.D.
HOOD INSTALLATION IS REQUIRED
G A S S P E C I F I C AT I O N S
■■NATURAL GAS ■■PROPANE GAS
120,000 BTU/hr. INPUT 120,000 BTU/hr. INPUT
GAS SPECIFICATIONS
D A N G E R
CONNECTING TO THE WRONG GAS
SUPPLY COULD RESULT IN FIRE OR
AN EXPLOSION CAUSING SEVERE
INJURY AND PROPERTY DAMAGE.
W A R N I N G
TO AVOID SERIOUS PERSONAL
INJURY, installation of this appliance
must conform to local, state, and
national codes; the current edition of
the American National Standard
Z223.1, National Fuel Gas Code, and
all local municipal uilding codes. In
Canada, installation must e in
accordance with Standard CAN/CSA
B 149.1 and Installation Codes - Gas
Burning Appliances, and local codes.
I N S T A L L A T I O N
Gas Fryer Operat on & Care Manual • 8

Use an approved gas
pipe sealant at all
external threaded
connections, gas
piping used on gas
connections must
avoid sharp bends
that may restrict the
flow of gas to the
appliance. If the
connected pressure exceeds 14.0" W.C. (3.5 kPa), a
step-down regulator is required to be supplied by the
owner/operator.
Close the individual manual shut-off valve to
isolate the fryer from the gas supply piping system
during any pressure testing at test pressures equal to
or less than 1/2psig. (3.4 kPa). The fryer and
individual shut-off valve must be disconnected
from the gas supply piping system during
any pressure testing at pressures in
excess of 1/2 psig. (3,4 kPa).
In the U.S.A., installation must conform to local
codes or, in the absence of local codes, with the
current edition of the National Fuel Gas Code,
NFPA-54 and ANSI Z83.11a CSA 1.8a 2004 (or
latest edition). In Canada, installation must be in
accordance with local codes, CAN/CGA-B149.1,
Installation for Natural Gas Burning Appliances
and Equipment (latest edition) or CAN/CGA-
B149.2 Installation for Propane Burning
Appliances and Equipment (latest edition).
The inlet supply line must be properly sized to
accommodate all individual appliances
simultaneously used on the same line but must
never be smaller than 3/4"I.D.
LEAK TESTING
Installation requires gas leak testing on all gas
piping and fittings. Use an approved electronic leak
device or a soap and water solution at all gas
connections. If bubbling appears when using a soap
and water solution, the connection must be refitted.
Never use an open flame to leak test.
INCORRECT CORRECT
A
B
C
D
E
F
G
H
GAS INTAKE
A G Installation elbow
B Wall Valve
C D Three piece union fitting
(minimum 1 per installation)
E F End connector for the flexible tube
H Marking line
GAS CONNECTION
D A N G E R
Installation, air adjustment and/or
service work must be in accordance
with all local codes and must be
performed by a certified service
technician qualified to work on
gas appliances.
D A N G E R
NEVER USE AN OPEN
FLAME TO LEAK TEST.
INSTALLATION
Gas Fryer Operat on & Care Manual • 9

The fryer must be supplied with a connector that
complies with all state and local installation codes.
Any appliance that is not furnished with a power
supply cord but that includes a set of casters must be
tethered. Adequate means must be provided to limit
the movement of this appliance without depending
on or transmitting stress to the electrical conduit.
The following requirements apply:
1. Casters must be a maximum height of 4-inches (102mm).
2. Such mobile appliances must be installed with
the use of a flexible connector secured to the
building structure.
A mounting connector for a restraining device is
located on the lower back flange of the appliance
chassis, approximately 7-inches (178mm) from the
floor. A flexible connector is not supplied by nor is it
available from the factory.
RESTRAINT REQUIREMENTS - MOBILE EQUIPMENT
W A R N I N G
RISK OF ELECTRIC SHOCK.
Appliance must be secured
to building structure.
I N S T A L L A T I O N
Gas Fryer Operat on & Care Manual • 10

An electrical wiring diagram is located in the front access
door of the fryer. The fryer must be installed by a
qualified electrician. This appliance must be branch circuit
protected with proper ampacities, in accordance with the
wiring diagram located in the fryer. The fryer must be
properly grounded in accordance with the National
Electrical Code and applicable local codes. A means to
disconnect the unit must be incorporated into the fixed
wiring in accordance with wiring codes.
Wire size for the main incoming power to the unit must
match the minimum size listed in the specifications
applicable to the specific fryer. For supply connections,
locate the wire size posted on the label located on the
electrical control box cover, behind the service panel or
elsewhere listed in this manual.
Before operating the fryer, check all cable connections in
the electrical connection area for tightness since
connections can loosen during transport.
230V:
To prevent an electrical shock hazard between the
appliance and other appliances or metal parts in close
vicinity, an equalization-bonding stud is provided. An
equalization bonding lead must be connected to this
stud and the other appliances / metal parts to provide
sufficient protection against potential difference. The
terminal is marked with the following symbol.
D A N G E R
To avoid electrical shock, this
applia ce MUST be adequately
grou ded i accorda ce with local
electrical codes or, i the abse ce of
local codes, with the curre t editio
of the Natio al Electrical Code
ANSI/NFPA No. 70. I Ca ada, all
electrical co ectio s are to be
made i accordi g with CSA C22.1,
Ca adia Electrical Code Part 1 or
local codes.
D A N G E R
ENSURE POWER SOURCE
MATCHES VOLTAGE STAMPED
ON APPLIANCE NAMEPLATE.
E L E C T R I C A L R E Q U I R E M E N T S
ELECTRICAL • ASF-60G WI TH BA SIC CONTR OL
VOLTAGE PHASE CYCLE/HZ AMPS KW
120 (AGCY)1 60 1.2 1.5
230 (AGCY)1 50/60 1.0 2.3
ELECTRICAL • ASF-75G WITH BAS IC CO NTROL
VOLTAGE PHASE CYCLE/HZ AMPS K
120 (AGCY)1 60 7.2 0.864
230 (AGCY)1 50/60 4.0 0.92
N E M A 5-15P
15A-125V PLUG
NNEEMMAA5-15P
15A-125V Plug
CEE 7 / 7
220-230V PLUG
C E E 7 / 7
220-230V PLUG
INSTALLATION
Gas Fryer Operat on & Care Manual • 11

Gas Fryer Operat on & Care Manual • 12
OPERATION
OIL/SHORTENING REQUIREMENTS
The ASF-75G requires 73-pounds (33 kg) of oil or
shortening in the frypot and the ASF-60G requires
62-pounds (28 kg) of oil or shortening. Use only quality,
high-grade oil/shortening in the fryer. The high moisture
content of many lower grade shortening will result in
excessive foaming and boil over. The cold oil/shortening
level requirement for the fryer is indicated below.
NOTE: ALWAYS maintain the ro er level of
shortening by adding fresh oil/shortening
to the fry ot whenever needed.
Check the quality of the oil/shortening in the frypot on a
daily basis for signs of deterioration. Use an approved test
kit. Signs of shortening deterioration include excessive
boiling, smoking, foaming, bad taste, and rancid odor.
Discard any shortening before it degrades to the point of
affecting product quality. Always filter the oil on a regular
basis and keep the frypot clean.
Remove ice crystals and ensure that food is dry before
frying. Excessive water and ice can cause oil to splatter or
overflow. Do not over fill the basket. Food needs to be
surrounded by oil for best frying results.
Maximum shortening life is achieved by lowering the
temperature of the fryer to 250°F (121°C) or turning the
fryer station off when not in use. In multiple-station units,
heat only the component fryers necessary to meet cooking
needs.
MAXIMUM OIL FILL LINE
MINIMUM
OIL FILL LINE
KETTLE
FRONT
OIL/SHORT EN IN G
LEVELS
OIL/SHORTENING REQUIREMENTS
C A U T I O N
METAL PARTS OF THIS EQUIPMENT
BECOME EXTREMELY HOT WHEN IN
OPERATION. TO AVOID BURNS,
ALWAYS USE HAND PROTECTION
WHEN OPERATING THIS APPLIANCE.
C A U T I O N
Cold oil or shortening expands as
the temperature increases. To a oid
injury and equipment damage, allow
for expansion by filling 1/2˝ (13mm)
below the maximum hot oil fill line.
W A R N I N G
FAILURE TO PLACE SOLID SHORTENING
DIRECTLY ON THE BOTTOM OF THE
FRYPOT CAN CAUSE SERIOUS
E QU I PM E N T DA MAGE .
CAUTION
ENSURE THERE IS NO WATER IN THE FRYPOT BEFORE
FILLING WITH OIL/SHORTENING. WHEN COOKING
COMPOUNDS ARE HEATED TO COOKING
TEMPERATURE, WATER IN THE FRYPOT WILL CAUSE
OIL TO SPLATTER AND MAY BE A BURN HAZARD.
C A U T I O N
FIRE OR EQUIPMENT DAMAGE CAN RESULT FROM
IMPROPER SHORTENING LEVELS. THE LEVEL OF
SHORTENING MUST ALWAYS BE ABOVE THE HEATING
ELEMENTS WHEN THE FRYER IS OPERATING.
THE REQUIRED SHORTENING LEVEL MUST ALWAYS
BE ABOVE THE MINIMUM HOT OIL FILL LINE.
D A N G E R
The flash point of shortening
occurs at a lower temperature
the longer the shortening is
used. Discard any shortening
showing signs of deterioration
to avoid serious burns, fire,
and property damage.

Gas Fryer Operat on & Care Manual • 13
OPERATION
IGNTION
ALARM
MASTER
POWER
SWITCH
CONTROL
RESET
OIL
HI LIMIT
RESET
OPEN
CLOSED
KETTLE DRAIN
SELECTOR
ASF-60G, 120V
ASF-75G, 120V WITH FILTRATION
OIL
HI LIMIT
RESET
NOZZLE
KETTLE
SELECTOR
NOZZLE
CONNECTION PUMP
MASTER
POWER
SWITCH
IGNITION
ALARM
CONTROL
RESET
OPEN
CLOSED
KETTLE DRAIN
SELECTOR
NOZZLE
ON
NOZZLE
OFF
C O N T R O L S B E H I N D A C C E S S P A N E L
ASF-75G, 230V
CONTROL
RESET
MASTER
POWER
SWITCH
IGNITION
RESET
IGNITION
ALARM
OPEN
CLOSED
KETTLE DRAIN
SELECTOR
OIL
HI LIMIT
RESET
IGNITION
ALARM
MASTER
POWER
SWITCH
IGNITION
RESET
OIL
HI LIMIT
RESET
OPEN
CLOSED
KETTLE DRAIN
SELECTOR
ASF-60G, 230V
CONTROL
RESET

NOTE: Perform an initial Boil-Out to clean an
sanitize the fryer station before
operating.
Carbonized deposits along with an accumulation of oil
will eventually build-up on the interior of the frypot as
well as fryer accessories. It is important to periodically
remove these deposits, not only to maintain fryer
efficiency, but also to provide the highest product quality.
NOTE: Because each fryer station is controlle
separately, the following proce ure must
be followe for every component fryer in
multiple-station units.
NOTE: Manual Boil-Out can only be performe
when the actual temperature of the
frypot is less than 230°F (110°C).
1. After emptying the fryer of oil or shortening, remove
filter cartridge from unit if equipped with a filtration
system. (See filtration instructions on page 19.) Close
the DRAIN. The handle should be rotated clockwise
until it stops.
NOTE: Always wear eye protection or a face
shiel an protective rubber gloves
when cleaning the frypot as boil-out
chemical is an alkaline solution an can
cause severe burns.
2. Fill the fryer to the maximum oil fill line with a
mixture of cold water and fryer boil-out solution.
Carefully follow the manufacturer’s directions for
mixing the boil-out solution.
3. Turn the Master Power Switch (located within the
front access door) to the “ON” position.
4. Wait until the LED reads “HEAt”, then press the
BOIL OUT button on the control panel.
5. When 192°F (89°C) is reached, the LED will display
“bOIL” and that temperature will be maintained.
Using a separate timer, allow the frypot to boil-out for
10 minutes.
6. Turn the Master Power Switch located behind the
front access door to the “OFF” position.
Gas Fryer Operat on & Care Manual • 14
OPERATION
BOIL-OUT
MAXIMUM OIL FILL LINE
MINIMUM
OIL FILL LINE
KETTLE
FRONT
OIL/SHORTENING
LEVELS
C A U T I O N
TO AVOID DAMAGING THE PUMP AND CONTAMINATING
CLEAN OIL WITH BOIL-OUT CHEMICAL ON UNITS
EQUIPPED WITH A FILTRATION SYSTEM, NEVER ALLOW
BOIL-OUT SOLUTION OR RINSE WATER TO CIRCULATE
THROUGH THE FRYER PUMP SYSTEM OR FAT DRAWER.
C A U T I O N
BEFORE ENTERING THIS PROGRAM, MAKE CERTAIN
THE FRYPOT IS EMPTY OF ALL OIL OR SHORTENING.
CAUTION
BOIL-OUT SOLUTION AND SURROUNDING METAL
SURFACES BECOME EXTREMELY HOT. TO AVOID
BURNS, ALWAYS USE HAND PROTECTION WHEN
PERFORMING THE BOIL-OUT FUNCTION AND FOLLOW
THE MANUFACTURER'S SAFETY INSTRUCTIONS FOR
THE BOIL-OUT PRODUCT BEING USED.
CAUTION
DO NOT LEAVE THE FRYER UNATTENDED DURING THE
BOIL-OUT PROCESS. THE FRYER MUST BE
CONTINUOUSLY MONITORED FOR BOIL-OVER
CONDITIONS, PARTICULARLY IN HIGH-ALTITUDE
LOCATIONS. IF BOIL-OVER IS IMMINENT, IMMEDIATELY
TURN THE MASTER POWER SWITCH OFF AND ALLOW
THE SOLUTION TO COOL. WHEN THE SOLUTION HAS
COOLED, RE-ENTER THE BOIL-OUT MODE.
C A U T I O N
KEEP A CONTAINER OF COLD WATER ON HAND
DURING BOIL-OUT IN CASE OF BOIL-OVER. IF BOIL-
OVER IS IMMINENT, IMMEDIATELY TURN OFF MASTER
POWER SWITCH AND POUR COLD WATER INTO FRYPOT
TO QUICKLY REDUCE SOLUTION TEMPERATURE.

Gas Fryer Operat on & Care Manual • 15
OPERATION
7.Wearing protective gloves to avoid burns, scrub the
inside of the fypot with a long-handled scrub brush.
8. Attach the drain pipe and direct boil-out solution into
a heat-resistant container.
9. Open the DRAIN. The handle should be rotated
counterclockwise until it stops.
10. Allow the boil-out solution to completely drain.
Discard boil-out solution.
11. Rotate the drain valve clockwise to the
“CLOSED” position. Follow the boil-out solution
manufacturer’s additional boil-out instructions to
rinse the frypot and neutralize boil-out cleaner
residue. Discard rinse solution.
12. There may be residual boil-out solution in the oil fill
hole and tube. This must be flushed out and discarded
separately before filling the tank with new oil to avoid
contamination of new oil.
13. Following the boil-out and rinse procedure, wipe dry
all accessible interior metal surfaces and interior
accessories with a clean, dry cloth to remove
remaining moisture. Clean and dry the fry baskets
separately.
NOTE: Make sure the insi e of the frypot, the
rain opening an all parts that come
into contact with new oil/shortening are
as ry as possible.
14. Wipe the exterior of the fryer cabinet with a
degreaser/sanitizer suitable for use on food contact
surfaces. Always follow the manufacturer's
instructions and/or mixing directions for proper
solution strengths.
Wipe exterior stainless steel surfaces with the grain of
the metal and avoid the use of abrasive pads, steel
wool, or metal implements.
15. Replace the oil filter if equipped with filtration system.
(See instructions on pages 19.)
16. Fill tank with new oil or shortening.
B O I L - O U T
C A U T I O N
ENSURE THERE IS NO WATER IN THE FRYPOT BEFORE
FILLING WITH OIL/SHORTENING. WHEN COOKING
COMPOUNDS ARE HEATED TO COOKING
TEMPERATURE, WATER IN THE FRYPOT WILL CAUSE
OIL TO SPLATTER AND MAY BE A BURN HAZARD.

Gas Fryer Operat on & Care Manual • 16
OPERATION
NOTE: Perform an initial Boil-Out to clean an
sanitize the fryer station before
operating. (See page 14.)
1. Service is to be performed by an authorized
Alto-Shaam service agent.
2. Ensure all local electrical codes, fire codes, and all
other requirements such as hood installation have
been met in the process of installation.
NOTE: Because each fryer station is controlle
separately, the following proce ures
must be followe for every component
fryer in multiple-station units.
3. Open front access door and ensure drain valve is
closed. The handle should be rotated clockwise until
it stops.
4. Fill frypot with frying compound as indicated. (SEE
ILLUSTRATIO O THE OIL/SHORTE I G REQUIREME TS PAGE)
5. The Master Power Switch is located behind the front
access door. Turn Master Power Switch “ON.”
6. Press ELEMENT HI RESET button.
7. The LED display on the basic control panel will
indicate “-AS-”, the software version, and then “CY”.
8. When the fryer has reached 135°F, the melt cycle is
complete and the LED display on the control panel
will indicate “HEAt”.
9. When the fryer displays the set-point temperature,
product can be fried.
10. More detailed operating guidelines along with
information on programming are located within this
manual.
11. To shutdown the fryer, turn the Master Power Switch
located behind the front access door to the “OFF”
position.
NOTE: FOR YOUR PROTECTION The fryer station is
furnished with a hi-limit safety shutoff that will
disengage the control if the frying compound
temperature in the frypot would ever exceed
415°F (213°C). The LED will display “Hi”, the
heat will shut off, the timer will be cancelled, and
a constant alarm will sound. In this event, allow
the frying compound temperature to drop below
415°F (213°C). Open the front access door and
press the OIL HI-LIMIT RESET button for a
period of 3-seconds to restart the control.
START UP & GENERAL OPERATION
D A N G E R
BEFORE STARTING THE
APPLIANCE, MAKE CERTAIN
YOU DO NOT DETECT THE
ODOR OF GAS.
IF THE ODOR OF GAS IS DETECTED:
• DO NOT attempt to lig t any appliance.
• DO NOT touc any electrical switc es.
• Extinguis any open flame.
• Use a telep one OUTSIDE THE
PROPERTY & IMMEDIATELY
contact your gas supplier.
• If unable to contact your gas supplier,
contact t e fire department.

Gas Fryer Operat on & Care Manual • 17
OPERATION
THOROUGHLY CLEAN DAILY
The cleanliness and appearance of this unit
will contribute considerably to operating efficiency
and savory, appetizing food.
Good equipment kept clean works better
and lasts longer.
1. Disconnect unit from power source, and let cool.
2. Remove all detachable items. Clean these items
separately with a good grease solvent or commercial
detergent. Rinse well and dry.
3. Clean control panel, door vents, door handles,
and door gaskets thoroughly since these areas harbor
food debris. Rinse by wiping with
sponge and clean warm water. Wipe dry with
a clean cloth.
4. To help maintain the protective film coating on
polished stainless steel, clean the exterior of the unit
with a cleaner recommended for stainless
steel surfaces. Spray the cleaning agent on a
clean cloth and wipe with the grain of the
stainless steel.
NOTE: Avoid the use of abrasive cleaning, compounds,
chloride based cleaners,
or cleaners containing quaternary salts.
Never use hydrochloric acid (muriatic acid)
on stainless steel.
Always follow appropriate state or local health (hygiene)
regulations regarding all applicable cleaning and
sanitation requirements for foodservice equipment.
CLEANING & MAINTENANCE
D A N G E R
DISCONNECT UNIT FROM
POWER SOURCE BEFORE
CLEANING OR SERVICING.
D A N G E R
AT NO TIME SHOULD THE INTERIOR
OR EXTERIOR BE STEAM CLEANED,
HOSED DOWN, OR FLOODED WITH
WATER OR LIQUID SOLUTION OF
ANY KIND. DO NOT USE WATER JET
TO CLEAN.
SEVERE DAMAGE OR
ELECTRICAL HAZARD
COULD RESULT.
WARRANTY BECOMES VOID IF
APPLIANCE IS FLOODED
C A U T I O N
TO PROTECT STAINLESS STEEL
SURFACES, COMPLETELY AVOID
THE USE OF ABRASIVE CLEANING
COMPOUNDS, CHLORIDE BASED
CLEANERS, OR CLEANERS
CONTAINING QUATERNARY SALTS.
NEVER USE HYDROCHLORIC ACID
(MURIATIC ACID) ON STAINLESS
STEEL. NEVER USE WIRE
BRUSHES, METAL SCOURING
PADS OR SCRAPERS.
N
O
S
C
R
A
P
E
R
S
N
O
W
I
R
E
B
R
U
S
H
E
S
N
O
S
T
E
E
L
P
A
D
S

Gas Fryer Operat on & Care Manual • 18
OPERATION
Careful observation of the finished food product will help
determine optimal filtering frequency. Filtering the
cooking oil at regular intervals will help ensure food
quality.
FOR BEST RESULTS:Do not allow the temperature of
the oil to decrease below the “I le Mo e” temperature of
250°F (121°C) when filtering. If filtering at the end of the
day, pump oil back into the kettle while still hot. Do not
allow oil to cool before returning to kettle.
1. Open the front access door. With the ettle/Nozzle
selector in the “NOZZLE OFF” position, rotate the
drain valve counterclock-wise until rotation stops
and the drain valve is in the “OPEN” position.
Power to the main control panel will automatically
switch “OFF.”
2. Allow contents of the fryer to completely drain.
3. Press the PUMP “ON” to allow the oil to circulate
through the drain system to flush crumbs. Using the
brushes provided, brush the sides and bottom of the
fryer while the oil is circulating through the system.
Use the angle brush under the heat exchangers.
4. Press the PUMP “OFF” and allow contents of the
fryer to completely drain.
5. Rotate the drain valve clockwise to the
“CLOSED” position.
6. Press the PUMP “ON” and allow the fryer to refill
to the recommended level adding additional
oil/shortening as required to maintain proper fill
level.
7. Press the PUMP “OFF” button.
8. After the frypot has completely refilled, pull out the
mobile oil trolley and discard the filter into a proper
receptacle. Clean the filter assembly and oil trolley,
if needed.
9. Replace the oil filter and return the trolley to the
proper position beneath the fryer.
10. Push the ELEMENT HI LIMIT reset button.
11. Press and hold the “ON/OFF” key on
the main control panel for 1-1/2 to 2 seconds to
energize the fryer. Continue normal fryer operation
after the preheat function has been completed.
OIL FILTRATION INSTRUCTIONS (FOR UNITS WITH INSTALLED OPTION)
CAUTION
METAL PARTS OF THIS EQUIPMENT
BECOME EXTREMELY HOT WHEN IN
OPERATION. TO AVOID BURNS,
ALWAYS USE HAND PROTECTION
WHEN OPERATING THIS APPLIANCE.
C A U T I O N
OOPPEERRAATTOORRSS MMUUSSTT BBEE MMAADDEE AAWWAARREE OOFF TTHHEE HHAAZZAARRDDSS
IINNVVOOLLVVEEDD IINN TTHHEE OOPPEERRAATTIIOONN OOFF AA HHOOTT OOIILL FFIILLTTEERRIINNGG
SSYYSSTTEEMM.. OONN--SSIITTEE SSUUPPEERRVVIISSIIOONN DDUURRIINNGG TTHHEE
FFIILLTTRRAATTIIOONN PPRROOCCEESSSS AANNDD TTHHEE CCLLEEAANNIINNGG PPRROOCCEESSSS IISS
SSTTRROONNGGLLYY RREECCOOMMMMEENNDDEEDD..
W A R N I N G
TO AVOID PERSONAL INJURY, USE
CAUTION WHEN SURFACES BECOME
SLIPPERY DUE TO SPILLED OR
DRIPPING OIL.

Gas Fryer Operat on & Care Manual • 19
OPERATION
FILTER REPLACEMENT
1.With the DRAIN in the “CLOSED” position, pull the trolley from the fryer and disconnect the hose from the fryer.
Use optional trolley handle if available, or take care when pulling trolley from fryer as it has sharp edges. (Contact
factory for optional trolley handle information.)
2. Pushing down on filter frame  clip, pull side of filter
cartridge  closest to clip upwards. Slide opposite edge of
filter cartridge out from beneath the filter frame lip.
3. Remove used filter and filter ring . Discard filter .
Retain filter ring .
4. Place new filter and filter ring next to screen on
underside of filter cartridge . Reverse step 2 above.
5. Reconnect hose to fryer and return trolley to
the full position under the fryer.
2FILTER
4FILTER
FRAME
AFILTER
CARTRIDGE
CLIP
FRAMELIP
3FILTER RING
(Use with paper filter only)
STANDARD AND OPTIONAL FILTERS
PART NO.DESCRIPTION
FI-27791 PAPER (STANDARD WITH FRYER) 7-count package
FI-27794 PAPER (STANDARD WITH FRYER) 100-count package
FI-27648 CHARCOAL/CARBON FILTER 30-count pkg.
FI-27014 REUSABLE MESH FILTER, single
OIL FILTRATION INSTRUCTIONS (FOR UNITS WITH INSTALLED OPTION)
