Service Manual
Vector™ Multi-Cook Oven
VMC-H2
VMC-H3
VMC-H4
VMC-H2H
VMC-H3H
VMC-H4H
Structured Air Technology™
MN-39158
REV.01
6/17
EN

Manufacturer’s Information
Copyright © Copyright 6/17 by Alto-Shaam, Inc.
All rights reserved.
This manual or any portion thereof may not be reproduced or used in any
manner whatsoever without the express written permission of Alto-Shaam, Inc.
Trademarks All trademarks referenced in this documentation are the property of their
respective owners.
Manufacturer Alto-Shaam, Inc.
P.O. Box 450
W164 N9221 Water Street
Menomonee Falls, WI 53052
Original instructions The content in this manual is written in American English.

FOREWORD
Vector™ H-Series ?Service Manual ?MN-39158 ?Rev 01 ?6/17
3
OREWORD
Alto-Shaam 24/7 Emergency Repair Service
Call Call 800-558-8744 to reach our 24-hour emergency service call center for
immediate access to local authorized service agencies outside standard business
hours. The emergency service access is provided exclusively for Alto-Shaam
equipment and is available throughout the United States through Alto-Shaam’s
toll free number.
Availability Emergency service access is available seven days a week, including holidays.

FOREWORD
Vector™ H-Series ?Service Manual ?MN-39158 ?Rev 01 ?6/17
4

TABLE OF CONTENTS
Vector™ H-Series ?Service Manual ?MN-39158 ?Rev 01 ?6/17
5
T
ABLE
OF
C
ONTENTS
Manufacturer’s Information . . . . . . . . . . . . . . . . . . . . . . . . 2
Foreword 3
Alto-Shaam 24/7 Emergency Repair Service . . . . . . . . . . . . . . . 3
Table of Contents 5
Safety 7
The Meaning of Signal Words . . . . . . . . . . . . . . . . . . . . . . . 7
Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Operation 11
How to Turn On and Turn Off the Oven . . . . . . . . . . . . . . . . . 11
How to Update the Interface Board (IB) . . . . . . . . . . . . . . . . . 12
How to Update the Control Board (CB) . . . . . . . . . . . . . . . . . . 14
How to Load Config Files . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Components 19
Component Identification . . . . . . . . . . . . . . . . . . . . . . . . . 19
Cavity Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Front Panel Identification . . . . . . . . . . . . . . . . . . . . . . . . . 21
Back Panel Identification . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Component Access Panels Identification . . . . . . . . . . . . . . . . . 23
H4—Electrical Component Identification . . . . . . . . . . . . . . . . . 24
H3—Electrical Component Identification . . . . . . . . . . . . . . . . . 25
H2—Electrical Component Identification . . . . . . . . . . . . . . . . . 26
Electrical Components . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Left Service Panel Identification . . . . . . . . . . . . . . . . . . . . . . 36
Left Service Panel Components . . . . . . . . . . . . . . . . . . . . . . 37
Right Service Panel Identification . . . . . . . . . . . . . . . . . . . . . 40
Right Service Panel Components . . . . . . . . . . . . . . . . . . . . . 41
Internal Components Identification. . . . . . . . . . . . . . . . . . . . 43
Internal Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Theory 45
Standby State . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
On State . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Warm-Up State . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Idle State . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Cooking State . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Cooking State Complete . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Rapid ON/OFF State . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Cool Down State . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Cool Down State Complete. . . . . . . . . . . . . . . . . . . . . . . . . 53

TABLE OF CONTENTS
Vector™ H-Series ?Service Manual ?MN-39158 ?Rev 01 ?6/17
6
Maintenance 55
Maintenance Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
How to Clean the Oven. . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Troubleshooting 61
The Oven will not Power Up . . . . . . . . . . . . . . . . . . . . . . . . 61
The Oven will not Power Up Cont. . . . . . . . . . . . . . . . . . . . . 62
The Cavities will not Heat . . . . . . . . . . . . . . . . . . . . . . . . . 63
Cavity Blower Fans Inoperable . . . . . . . . . . . . . . . . . . . . . . 66
Cavity Lights will not Illuminate . . . . . . . . . . . . . . . . . . . . . . 68
The Check Fan Indicator Light is Illuminated . . . . . . . . . . . . . . 69
The Cooling Fan(s) are Inoperable . . . . . . . . . . . . . . . . . . . . 71
Assembly/Disassembly 73
Removing and Installing the Blower Motor . . . . . . . . . . . . . . . 73
Removing and Installing a Heater Element . . . . . . . . . . . . . . . 75
Schematics 77
VMC-H2 / VMC-H2H. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
VMC-H3 / VMC-H3H. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
VMC-H4 / VMC-H4H. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

SAFETY
Vector™ H-Series ?Service Manual ?MN-39158 ?Rev 01 ?6/17
7
AFETY
The Meaning of Signal Words
Technical content produced by Alto-Shaam contains signal words where needed.
These signal words must be obeyed to reduce the risk of death, personal injury,
or equipment damage. The meaning of these signal words is explained below.
DANGER
Danger indicates a hazardous situation which, if not avoided,
will result in serious injury or death.
WARNING
Warning indicates a hazardous situation which, if not avoided,
could result in serious injury or death.
CAUTION
Caution indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
NOTICE
Notice indicates a situation which, if not avoided, could result
in property damage.
Note indicates additional information that is important to a concept
or procedure.

SAFETY
Vector™ H-Series ?Service Manual ?MN-39158 ?Rev 01 ?6/17
8
Safety Precautions
Before you begin Read and understand all instructions in this manual.
Electrical precautions Follow these precautions while using the appliance:
▪Connect the appliance to a properly grounded outlet. Do not use the appliance if
it is not properly grounded. Consult an electrician if there is any doubt that the
outlet used is properly grounded.
▪Do not attempt to service the appliance or its plug and cord.
▪Keep the cord away from hot surfaces.
▪Do not operate the appliance if it has a damaged cord or plug.
▪Do not immerse the cord or plug in water.
▪Do not let the cord hang over the edge of a table or counter.
▪Do not use an extension cord.
Usage precautions Follow these precautions when using the appliance:
▪Only use this appliance for its intended use of heating or cooking.
▪Use utensils and protective clothing such as dry oven mitts when loading and
unloading the appliance.
▪Do not cover or block any of the openings of this appliance.
▪Do not cover racks or any other part of this appliance with metal foil.
▪Do not use this appliance near water such as a sink, in a wet location, near a
swimming pool, or similar locations.
▪Do not unplug or disconnect the appliance immediately after cooking. The
cooling fans must stay on to protect electrical components.
Maintenance
precautions
Follow these precautions when cleaning and maintaining the appliance:
▪Observe precautions in the manual, on tags, and on labels attached to or shipped
with the appliance.
▪Only clean the appliance when the main disconnect is in the OFF position.
▪Do not store the appliance outdoors.
▪Do not clean the appliance with metal scouring pads.
▪Do not use corrosive chemicals when cleaning the appliance.
▪Do not use the appliance cavity for storage.
▪Do not leave flammable materials, cooking utensils, or food inside the appliance
when it is not in use.
▪Do not remove the top cover or side panels. There are no user-serviceable
components inside.

SAFETY
Vector™ H-Series ?Service Manual ?MN-39158 ?Rev 01 ?6/17
9
Operator training Before using the appliance:
▪Read and understand the operating instructions contained in all the
documentation delivered with the appliance.
▪Familiarize yourself with the location and proper use of all controls.
▪Keep this manual and all supplied instructions, diagrams, schematics, parts lists,
notices, and labels with the appliance if the appliance is sold or moved to another
location.
▪Contact Alto-Shaam for additional training if needed.
Operator
qualifications
Only trained personnel are permitted to use the appliance. They must meet the
following qualifications:
▪Have received proper instruction on how to use the appliance
▪Are familiar with commercial kitchens and the appliances used within
The appliance must not be used by:
▪Children
▪People impaired by drugs or alcohol
Condition of
appliance
Only use the appliance when:
▪All controls operate correctly
▪The appliance is installed correctly
▪The appliance is clean
▪The appliance’s labels are legible
Servicing the
appliance
▪Only trained personnel are permitted to service or repair the appliance. Repairs
that are not performed by an authorized service partner or trained technician, or
the use of non-factory parts, will void the warranty and relieve Alto-Shaam of all
liability.
▪To prevent serious injury, death or property damage, the appliance should be
inspected and serviced at least every twelve (12) months by an authorized service
partner or trained technician.
▪Contact Alto-Shaam for the authorized service partner in your area.
Personal Protective
Equipment (PPE)
Wear the following Personal Protective Equipment (PPE) while cleaning the
appliance.
▪Protective gloves
▪Protective clothing
▪Eye protection
▪Face protection

SAFETY
Vector™ H-Series ?Service Manual ?MN-39158 ?Rev 01 ?6/17
10
