Alto MPV-60 Installation and operation manual

Part No. 2-86-00398 2004 Printed in theAmerican-Lincoln® USA
UL
®
ISO 9001
FILE A2287
#
OPERATOR'S
MANUAL &
PARTS LIST
MPV-60
POWER
SWEEPER
Beginning with Serial No. 482001
READ THIS BOOK
All directions given in this book are as seen from the operator's position at the rear of the machine.
For new books, write to: American-Lincoln, Inc., 1100 Haskins Road, Bowling Green, Ohio 43402
This book has important information for the use and safe operation of this machine. Failure
to read this book prior to operating or attempting any service or maintenance procedure to
your machine could result in injury to you or to other personnel; damage to the machine or to
other property could occur as well. you must have training in the operation of this machine
before using it. If you or your operator (s) cannot read English, have this manual explained
fully before attempting to operate this machine.
Si Ud. o sis operadores no pueden leer el Inglés, se hagen explicar este manual completamente
antes de tratar el manejo o servicio de esta máquina.
AMERICAN-LINCOLN
TECHNOLOGY

American-Lincoln 1-1
MPV 60
MACHINE SPECIFICATIONS ................................................................................................................................................... 1-4
MACHINE DIMENSIONS .......................................................................................................................................................... 1-6
MACHINE PREPARATION ....................................................................................................................................................... 1-7
SAFETY PRECAUTIONS ......................................................................................................................................................... 1-8
SWEEPER CONTROLS/INSTRUMENTS .................................................................................................................................. 1-10
HORN BUTTON ................................................................................................................................................................. 1-10
LIGHT SWITCH .................................................................................................................................................................. 1-10
GLOW PLUG SWITCH ...................................................................................................................................................... 1-10
CHECK ENGINE LIGHT ...................................................................................................................................................... 1-10
KEY SWITCH .................................................................................................................................................................... 1-11
ENGINE SPEED SWITCH ................................................................................................................................................... 1-11
HOUR METER .................................................................................................................................................................... 1-11
FUEL GAUGE .................................................................................................................................................................... 1-11
FOOT BRAKE ................................................................................................................................................................... 1-12
PARKING BRAKE .............................................................................................................................................................. 1-12
FOOT PEDAL .................................................................................................................................................................... 1-12
FORWARD MOVEMENT ................................................................................................................................................... 1-12
BACKWARD MOVEMENT ................................................................................................................................................. 1-12
STOPPING ......................................................................................................................................................................... 1-12
WARNING BANK .............................................................................................................................................................. 1-13
ENGINE TEMP LIGHT ................................................................................................................................................. 1-13
ENGINE OIL PRESSURE LIGHT ................................................................................................................................. 1-13
CHARGING SYSTEM LIGHT ..................................................................................................................................... 1-13
DUST CONTROL LIGHT ............................................................................................................................................ 1-13
HOPPER TEMPERATURE LIGHT ................................................................................................................................ 1-13
DUMP DOOR LIGHT .................................................................................................................................................. 1-13
TILT STEERING LEVER ..................................................................................................................................................... 1-14
SEAT POSITION ADJUSTMENT ......................................................................................................................................... 1-14
TURN SIGNALS (OPTION) ................................................................................................................................................ 1-14
BACKUPALARM (OPTION) .............................................................................................................................................. 1-14
DUST CONTROL SWITCH ................................................................................................................................................. 1-15
FILTER SHAKER SWITCH ................................................................................................................................................. 1-15
BROOM CONTROL LEVER ............................................................................................................................................... 1-15
SIDE BROOM LEVER ........................................................................................................................................................ 1-16
SIDE BROOMADJUSTMENT ............................................................................................................................................. 1-16
MAIN BROOM LEVER ....................................................................................................................................................... 1-16
MAIN BROOMADJUSTMENT ............................................................................................................................................ 1-16
HOPPER DOOR LEVER ..................................................................................................................................................... 1-16
HOPPER LIFT LEVER ........................................................................................................................................................ 1-17
HOPPER LID ...................................................................................................................................................................... 1-17
CIRCUIT BREAKERS ......................................................................................................................................................... 1-18
ENGINE COMPARTMENT LATCH ...................................................................................................................................... 1-18
HYDRAULIC RESERVOIR LEVER SIGHT GAUGE ............................................................................................................ 1-19
MAIN BROOM COMPARTMENT DOORS ........................................................................................................................... 1-19
HOPPER COVER LATCH ................................................................................................................................................... 1-20
HOPPER SAFETYARM ..................................................................................................................................................... 1-20
FILTER PANEL LATCH ....................................................................................................................................................... 1-20
HOPPER TEMP SENSOR ................................................................................................................................................... 1-21
DUST BAFFLE .................................................................................................................................................................. 1-21
LOW OIL SHUTDOWN ...................................................................................................................................................... 1-21
HELPFUL HINTS FOR SWEEPING ........................................................................................................................................... 1-22
INSTRUCTIONS BEFORE STARTING ................................................................................................................................ 1-22
PRE-START CHECK LIST .................................................................................................................................................. 1-22
OPERATING INSTRUCTIONS .................................................................................................................................................. 1-23
TO START GAS ENGINE ................................................................................................................................................... 1-23
TO START DIESEL ENGINE ............................................................................................................................................... 1-23
TO START PROPANE ENGINE .......................................................................................................................................... 1-23
TO DRIVE SWEEPER FOR TRANSPORT .......................................................................................................................... 1-24
TO SWEEP WITH THE MACHINE ....................................................................................................................................... 1-24
TO STOP SWEEPING ........................................................................................................................................................ 1-24
TO EMPTY DEBRIS HOPPER ............................................................................................................................................. 1-25
PULSEAIR SYSTEM OPERATION (option) ....................................................................................................................... 1-25
MAINTENANCE/TROUBLESHOOTING PULSE AIR SYSTEM ................................................................................................ 1-26
PULSEAIR SYSTEM EXPLODED VIEW ............................................................................................................................ 1-27
SERVICE PRECAUTIONS ........................................................................................................................................................ 1-28
SERVICE CHART ..................................................................................................................................................................... 1-29
SERVICE INSTRUCTIONS ....................................................................................................................................................... 1-31
MAIN BROOM ................................................................................................................................................................... 1-31
TO CHECK THE MAIN BROOM SWEEP PATTERN ............................................................................................................ 1-31
TOADJUSTTHE MAIN BROOM SWEEP HEIGHT ............................................................................................................. 1-31
TO REPLACE THE MAIN BROOM ..................................................................................................................................... 1-31
MAIN BROOM LEVELADJUSTMENT ................................................................................................................................ 1-31
SIDE BROOM .................................................................................................................................................................... 1-32
TO CHECKTHE SIDE BROOM SWEEP PATTERN ............................................................................................................. 1-32
TO CHANGE THE SIDE BROOM HEIGHTADJUSTMENT ................................................................................................... 1-32
TABLE OF CONTENTS

1-2 American-Lincoln
MPV 60
TO CHANGE THE SIDE BROOM ....................................................................................................................................... 1-32
HOPPER ............................................................................................................................................................................ 1-33
TO CLEAN HOPPER .......................................................................................................................................................... 1-33
TO CHECK HOPPER SEALS ............................................................................................................................................. 1-33
TO CHECK HOPPER FLAPS .............................................................................................................................................. 1-33
DUST FLAPS .................................................................................................................................................................... 1-33
TO CHECK THE DUST FLAPS .......................................................................................................................................... 1-33
TOADJUST THE DUST FLAPS ......................................................................................................................................... 1-33
DUSTCONTROL FILTER ................................................................................................................................................... 1-34
TO CHECK THE DUST CONTROL FILTER ......................................................................................................................... 1-34
TO CLEAN THE DUST CONTROL FILTER ......................................................................................................................... 1-34
TO CHANGE THE DUST CONTROL FILTER ...................................................................................................................... 1-34
TO CHECK THE VIBRATION ARM ..................................................................................................................................... 1-34
BRAKE SERVICE .............................................................................................................................................................. 1-35
BRAKE PEDALADJUSTMENT .......................................................................................................................................... 1-35
BRAKE DRUMADJUSTMENT ........................................................................................................................................... 1-35
HYDRAULIC SYSTEM SERVICE ....................................................................................................................................... 1-36
HYDRAULIC OIL COOLER ................................................................................................................................................ 1-36
TO FILL THE HYDRAULIC RESERVOIR ............................................................................................................................ 1-36
TO CLEAN THE HYDRAULIC SYSTEM ............................................................................................................................ 1-36
TO DRAIN THE HYDRAULIC RESERVOIR ........................................................................................................................ 1-36
TO CLEAN THE HYDRAULIC SUCTION STRAINER .......................................................................................................... 1-37
TO REPLACETHE RETURN FILTER ELEMENT .................................................................................................................. 1-37
ENGINEAIR INTAKE SERVICE .......................................................................................................................................... 1-38
AIR FILTER ........................................................................................................................................................................ 1-38
TO REPLACEAIR FILTER ELEMENT .................................................................................................................................. 1-38
ENGINE COOLING SYSTEM SERVICE .............................................................................................................................. 1-39
HOSES .............................................................................................................................................................................. 1-39
RADIATOR ........................................................................................................................................................................ 1-39
COOLANT LEVEL ............................................................................................................................................................. 1-39
DRIVE BELTS .................................................................................................................................................................... 1-39
BATTERY .......................................................................................................................................................................... 1-39
LP SAFETY PRECAUTIONS .................................................................................................................................................... 1-40
LP COMPONENTS ................................................................................................................................................................... 1-41
LP FUEL SYSTEM ............................................................................................................................................................. 1-41
LP VAPOR WITHDRAWAL SYSTEM ................................................................................................................................ 1-41
LP CHECKLIST .................................................................................................................................................................. 1-41
LP VAPORIZER-REGULATOR QUICK CHECK .................................................................................................................. 1-41
LP FUEL TANKS ................................................................................................................................................................ 1-42
USEAND CARE OF LP TANKS ................................................................................................................................. 1-42
CHANGING LP FUEL TANKS .................................................................................................................................... 1-43
STORAGE OF LP FUEL TANKS ................................................................................................................................ 1-43
STANDARD METRIC ENGINE TORQUE REQUIREMENTS ...................................................................................................... 1-44
HYDRAULIC TORQUE REQUIREMENTS ................................................................................................................................. 1-45
BOLT IDENTIFICATION CHART .............................................................................................................................................. 1-46
DECIMAL-METRIC CONVERSION TABLE ............................................................................................................................. 1-47
HARDWARE ABBREVIATIONS ................................................................................................................................................ 1-48
HARDWARE LEGEND ............................................................................................................................................................... 1-49
CHECK ENGINE LIGHT CODES ............................................................................................................................................... 1-55
ORDERING PARTS ................................................................................................................................................................... 1-58
TABLE OF CONTENTS - CHAPTER 2 ..................................................................................................................................... 2-1
MAIN BROOM LEVERAND LIFT CABLE ................................................................................................................................... 2-2
MAIN BROOM LIFT FRAME ....................................................................................................................................................... 2-4
MAIN BROOM DRIVER .............................................................................................................................................................. 2-5
MAIN BROOM IDLER ................................................................................................................................................................. 2-6
SIDE BROOMASSEMBLY ......................................................................................................................................................... 2-7
SIDE BROOM LEVER ................................................................................................................................................................ 2-8
SIDE BROOM LIFT SYSTEM ..................................................................................................................................................... 2-10
BRAKE PEDAL .......................................................................................................................................................................... 2-12
HOPPERASSEMBLY ................................................................................................................................................................. 2-14
HOPPERASSEMBLY (con’t) ..................................................................................................................................................... 2-16
HOPPER COVER ....................................................................................................................................................................... 2-18
DUMP DOOR ............................................................................................................................................................................. 2-20
FILTER SHAKER ........................................................................................................................................................................ 2-22
FRONT WHEEL ......................................................................................................................................................................... 2-24
REAR WHEEL ............................................................................................................................................................................ 2-26
STEERING COLUMN .................................................................................................................................................................. 2-28
BROOM DOOR .......................................................................................................................................................................... 2-30
FORWARD/REVERSE CONTROL ............................................................................................................................................. 2-32
ADJUSTABLE FOOT PEDAL ..................................................................................................................................................... 2-34
SAFETYARM ............................................................................................................................................................................ 2-36
OIL COOLER ............................................................................................................................................................................. 2-37
LIGHTSAND HORN ELECTRICAL ............................................................................................................................................. 2-38
TABLE OF CONTENTS

American-Lincoln 1-3
MPV 60
BATTERY2-39
HYDRAULIC RESERVOIR ......................................................................................................................................................... 2-40
VACUUM FAN ........................................................................................................................................................................... 2-42
FLAPS (WHEEL WELL) ............................................................................................................................................................. 2-44
BROOM CHAMBER FLAPS AND SEALS .................................................................................................................................. 2-46
CONTROLAND RELIEF VALVE ................................................................................................................................................ 2-48
PUMP .................................................................................................................................................................................. 2-50
HYDRAULIC FILTER .................................................................................................................................................................. 2-52
INSTRUMENTPANEL ................................................................................................................................................................. 2-53
INSTRUMENT HOUSING ............................................................................................................................................................ 2-54
FRONT BUMPER ....................................................................................................................................................................... 2-56
REAR BUMPER ......................................................................................................................................................................... 2-57
SEAT AND FLOOR ASSEMBLY ................................................................................................................................................ 2-58
ENGINE COVER ........................................................................................................................................................................ 2-60
MITSUBISHI S4L2 DIESEL ENGINE (FANS, BRACKETS) .......................................................................................................... 2-62
MITSUBISHI S4L2 DIESEL ENGINE (COOLING SYSTEM) ......................................................................................................... 2-64
MITSUBISHI S4L2 DIESEL ENGINE (AIR INTAKE) ..................................................................................................................... 2-66
MITSUBISHI S4L2 DIESELENGINE (THROTTLE PUMP PLATE) ................................................................................................. 2-68
MITSUBISHI S4L2 DIESEL ENGINE (THROTTLE CONTROL) ..................................................................................................... 2-69
MITSUBISHI S4L2 DIESEL ENGINE (EXHAUST SYSTEM) ........................................................................................................ 2-70
MITSUBISHI S4L2 DIESEL ENGINE (FUEL SYSTEM) ................................................................................................................ 2-71
FUEL TANK (GAS & DIESEL) .................................................................................................................................................... 2-72
FORD 416EFI ENGINE COMPUTER RELAY BOX ...................................................................................................................... 2-73
FORD 416EFI GAS & LP ENGINES (ALTERNATOR, STARTER, BRACKETS) .......................................................................... 2-74
FORD 416EFI GAS ENGINE (COOLING SYSTEM) .................................................................................................................... 2-76
FORD 416EFI GAS ENGINE (AIR INTAKE & EXHAUST SYSTEMS) ......................................................................................... 2-78
FORD 416EFI GAS ENGINE (FUEL SYSTEM) ........................................................................................................................... 2-80
FORD 416EFI LP ENGINE (FUEL SYSTEM) ............................................................................................................................... 2-82
LP TANK SYSTEM .................................................................................................................................................................... 2-86
FORD 416EFI LP ENGINE (AIR INTAKE & EXHAUST SYSTEMS) ............................................................................................. 2-88
FORD 416EFI LP ENGINE (COOLING SYSTEM) ....................................................................................................................... 2-90
CE KIT .................................................................................................................................................................................. 2-92
DECALS .................................................................................................................................................................................. 2-94
TOTAL STEEL PACKAGE ......................................................................................................................................................... 2-96
HYDRAULIC HOSE DIAGRAM .................................................................................................................................................. 2-98
NOTES .................................................................................................................................................................................. 2-100
HYDRAULIC SCHEMATIC ......................................................................................................................................................... 2-101
HARNESS ROUTING (GAS/LP/DIESEL) .................................................................................................................................... 2-102
HARNESS CONNECTION DIAGRAM (GAS/LP/DIESEL) ........................................................................................................... 2-103
FORD 416EFI ENGINE HARNESS CONNECTIONS .................................................................................................................... 2-104
MITSUBISHI S4L2 ENGINE HARNESS CONNECTIONS ............................................................................................................. 2-105
INSTRUMENT PANEL CONNECTION DIAGRAM ........................................................................................................................ 2-106
ELECTRICAL SCHEMATIC (GAS/LP/DIESEL) ........................................................................................................................... 2-107
TABLE OF CONTENTS - CHAPTER 3 ..................................................................................................................................... 3-1
BROOM OPTIONS ............................................................................................................................................................. 3-2
SIDE BROOM SPOTLIGHT ................................................................................................................................................ 3-3
SKIRTED VACUUMIZED SIDE BROOM .............................................................................................................................. 3-4
BACK-UPALARM OPTION ............................................................................................................................................... 3-6
BRAKE LIGHT OPTION ..................................................................................................................................................... 3-8
REAR WORK LIGHT OPTION ............................................................................................................................................ 3-10
OVERHEAD GUARD OPTION ........................................................................................................................................... 3-23
STROBE LIGHT WITH OVERHEAD GUARD ..................................................................................................................... 3-24
STROBE LIGHT WITHOUT OVERHEAD GUARD .............................................................................................................. 3-26
FIRE EXTINGUISHER OPTION ........................................................................................................................................... 3-28
PULSEAIR OPTION ........................................................................................................................................................... 3-30
LITTER VAC OPTION ........................................................................................................................................................ 3-36
PROTOTECTOSEAL GAS CAP OPTION ........................................................................................................................... 3-46
RETRACTABLE SEATBELT OPTION ................................................................................................................................. 3-48
SUSPENSION SEAT OPTION ............................................................................................................................................. 3-48
SPARKARRESTOR OPTION ............................................................................................................................................. 3-50
TIE DOWN OPTIONS ......................................................................................................................................................... 3-51
FRONT SOLID CUSHION TIRE OPTION ............................................................................................................................. 3-52
REAR SOLID CUSHION OPTION ....................................................................................................................................... 3-53
TURN SIGNAL ................................................................................................................................................................... 3-54
DIESEL SPARE PARTS KIT ................................................................................................................................................ 3-56
GAS SPARE PARTS KIT ................................................................................................................................................... 3-57
TABLE OF CONTENTS

1-4 American-Lincoln
MPV 60
SPECIFICATIONS
TRAVEL SPEED 0 - 8 MPH (0 - 12.875 kph)
TURNING RADIUS
Left 67” (170 cm)
Right 91.5” (232 cm)
DIMENSIONS
Length 98” (249 cm)
Width 62” (157 cm)
Height 50.75” (129 cm)
Height W/Overhead Guard 78” (198 cm)
Wheel Base 43” (109 cm)
Track 55” (138 cm)
WEIGHT
Standard Machine 2800 lb. (1271 kg) (Empty Machine)
TIRES
Type Pneumatic
Front Two (2) 18” (45.7 cm) x 5.80 x 8” on 7 gauge rim assembly
Rear One (1) 18” (45.7 cm) x 5.80 x 8” on 2-piece rim assembly
Note: Inflation 80 PSI for front & back
RAMP CLIMBING
Sweeping 12°
Transporting 12°
ENGINE DATA
Ford TSG416 EFI Engine
Bore and Stroke 3.23” x 2.97” (82.1 mm x 75.5 mm)
Oil Capacity 4.4 quarts (4.2 liters)
Displacement 4 cylinders, 1.6 liters (97.5 CID)
Fuel 87 A.K.I. (Standard unleaded)
ASI grade HD-5 for LP versions
Mitsubishi S4L2 Diesel
Bore and Stroke 3.07” x 3.62” (78 x 92 mm)
Oil Capacity 5.6 quarts (5.4 liters) - w/standard oil pan
Displacement 4 cylinders, 1.8 liters (107.3 cu. in.)
Fuel ASTM No. 2-D
High temperature/low pressure sensors with engine shutdown are standard on both the Ford 416 and
Mitsubishi S4L2.
SWEEPING PATH 60” (152 cm) w/single side broom
MAIN BROOM
One-piece plastic core disposable type. Broom position can be set to “restricted down” or “free floating.”
Length 45” (114 cm)
Diameter 14” (35.6 cm)
Bristle Length 3.25” (8.26 cm) long
Optional Bristle Types Nylon (Herringbone), High Density Nylon,
Proex & Wire, Poly & Wire, Natural Fiber & Wire
SIDE BROOM
Rotary disposable type protected by rotary guard. Floats over uneven surfaces and is adjustable for wear.
Diameter 23” (58 cm)
Optional Bristle Types Wire
Nylon (standard)
Polypropylene
STEERING
Full power steering with single rear wheel steering.
Operator’s Wheel Diameter 15” (38 cm)

American-Lincoln 1-5
MPV 60
HOPPER
Sweep Opening 43” (109 cm)
Volumetric Capacity 14 cubic feet
Weight Capacity 1200 lb. (447.6 kg)
Floor Length 34.25” (87 cm)
Ground Clearance 5.5” (14 cm)
FILTRATION SYSTEM
Air passes through water resistant panel filter that controls dust to one (1) micron in size
Filtering Area 88 square feet (8.18 m2)
HYDRAULIC SYSTEM
Main Broom, Side Broom, and Vacuum Fan are hydraulically driven. Oil Cooler keeps fluid cool.
Propelling-Variable Displacement Pump
CONTROLS AND INSTRUMENTS
Mechanical Foot Brake Hand-Operated Parking Brake
Key Start Switch Oil Pressure Light
Water Temperature Light 3-position Engine Speed Switch
Dust Control Switch Main Broom & Side Broom controls
Hopper Raise/Lower Control Clogged Filter Indicator
Electric Fuel Gauge Hour Meter
Electronically-Timed Filter Shaker Head & Tail Lights
No-Tool Dust Filter Inspection Side Broom Guard
Fluid Level Sight Gauge Push-Button Horn
Side Broom Lift Control Handle Main Broom Lift Control Handle
Low Oil Shutdown Charging System Light
2-speed Sweeping Single-Pedal Control for travel speed, forward/reverse motion
OPTIONAL EQUIPMENT
Back-Up Alarm Overhead Guard
Side Broom Spotlight Brake Lights
Rear Work Light Vac Wand
Turn Signals Tie-Down Kit
Blower Wand 4” Vac Wand
Vac Side Broom In-Hopper Temperature Sensor
Spark Arrestor Dome Light
Protectoseal Gas Cap Suspension Seat
Red or Amber Strobe Light without Overhead Guard Solid Cushion Tires
Red or Amber Strobe Light with Overhead Guard
WARRANTY
Our general conditions of business are applicable with regard to the guarantee. Subject to change as a result of
technical advances. The guarantee is invalidated if the machine is not operated in accordance with these instructions
or otherwise abused. The guarantee is invalidated if the machine is not serviced as described.
MACHINE DATA
SPECIFICATIONS
IP X3
MODEL
MACHINE NAME
DATE / SERIAL NUMBER
WEIGHT
RATED POWER
MAX OPERATING SLOPE
LWA
B
R

1-6 American-Lincoln
MPV 60
MACHINE DIMENSIONS
American-Lincoln
98 "
249 cm
157 cm
129 cm
147 cm
235 cm
198 cm
62.00 "
50.75 "
60.00 "
96.00 "
78.00 "
C0495ecp/1203

American-Lincoln 1-7
MPV 60
MACHINE PREPARATION
YOUR MPV-60 SWEEPER HAS BEEN SHIPPED COMPLETE, BUT DO NOT ATTEMPT TO OPERATE WITH-
OUT READINGAND FOLLOWING THESE INSTRUCTIONS.
PREPARATION
1. Uncrate the sweeper and carefully remove packing material.
2. Inspect the battery connections.
3. Fill fuel tank with appropriate fuel.
WARNING
Risk of personal injury. Never fill fuel tank while engine is running. Always be sure gasoline container and
sweeper are electrically connected prior to pouring fuel. This can easily be done by providing an insulated wire
(permanently attached to the container) with a battery clip attached to the other end.
4. Check engine crankcase oil level before starting engine.
5. Check radiator coolant level. Permanent type antifreeze is added at the factory to provide protection
to approximately -35° F (-37° C). To retain this level of protection always add ½ part water to ½
part antifreeze.
6. Check oil level in hydraulic reservoir which is located in the engine compartment. The hydraulic
reservoir is full when oil can be seen in the sight glass on the side of the reservoir. To get an
accurate reading the hopper must be in the “DOWN” position. If oil is required add
HYDRAULIC FLUID ONLY. Use Ford Automatic Transmission Fluid Type “F”.
LIGHTS
CHOKE
CHOKE
HORN
HORN
WORK
LIGHT
WORK
LIGHT
GLOW
PLUG
GLOW
PLUG
American-Lincoln
American-Lincoln
FILTER
SHAKER
FILTER
SHAKER
DUST
CONTROL
DUST
CONTROL
SIDE BROOM
SIDE BROOM
MAIN BROOM
MAIN BROOM
ENGINE
SPEED
ENGINE
SPEED
IDLE
OFF
OFF
ACC IGN/ON
START
1
2
HOURS
HOURS
00000
1/10
1/10
0
1/2
4/4
FUEL
C1432/9810
C-1432 FIGURE 1

1-8 American-Lincoln
MPV 60
SAFETY PRECAUTIONS
THE FOLLOWING STATEMENTS ARE USED THROUGHOUT THIS MANUALAS INDICATED
IN THEIR DESCRIPTIONS:
DANGER
To warn of immediate hazards which will result in severe personal injury or death.
WARNING
To warn of hazards or unsafe practices which could result in severe personal injury or death.
CAUTION
To warn of hazards or unsafe practices which could result in minor personal injury.
ATTENTION
To warn of unsafe practices which could result in extensive equipment damage.
NOTE
To give important information or to warn of unsafe practices which could result in equipment damage.
THE FOLLOWING INFORMATION PROVIDES A SIGNAL INDICATING POTENTIALLY DANGEROUS
CONDITIONS FOR THE OPERATOR AND/OR EQUIPMENT. READ THIS MANUAL CAREFULLY TO UNDER-
STAND WHEN THESE CONDITIONS CAN EXIST, THEN TAKE THE NECESSARY STEPS TO TRAIN
PERSONNEL WHO WILL BE OPERATING THIS MACHINE.
FOR THE SAFE OPERATION OF THIS MACHINE, READ AND UNDERSTAND ALL WARNINGS,
CAUTIONS AND NOTES.
WARNING
Machines can ignite flammable materials and vapors.
Do not use with or near flammable items such as: gasoline, grain dust, solvents and thinners.
WARNING
Heavy machinery. Improper use can cause personal injury.
WARNING
Operate only when lids, doors, and access panels are securely closed.
WARNING
Use care when reversing machine in confined area.
WARNING
When servicing the machine disconnect the battery first to prevent possible injury.
WARNING
When working on the machine, empty hopper, disconnect battery, clear area of people and obstructions.
Use additional people and proper procedures when lifting the machine.
WARNING
Always empty the Hopper and Disconnect Battery before doing maintenance.
WARNING
You must have training in the operation of this machine before using it. READ THE INSTRUCTION BOOK.
WARNING
Do not operate this machine unless it is completely assembled.
WARNING
Do not use this machine as a step or furniture.

American-Lincoln 1-9
MPV 60
WARNING
Be careful when operating the machine on a ramp or incline. Always move slowly on a ramp.
Do not turn this machine on a ramp. Do not stop and leave this machine on a ramp.
WARNING
Stop and leave this machine on a level surface.
When stopping the machine, put the power switch in the “OFF” position and Engage the parking brake.
WARNING
To prevent personal injury and/or damage to the machine,
do not lift the machine or move it to the edge of a stair or loading dock.
WARNING
Lead acid batteries generate gases which can cause an explosion. Keep sparks and flames away from batteries.
NO SMOKING. Charge batteries only in area with good ventilation.
WARNING
Always wear eye protection and protective clothing when working near batteries. Remove all jewelry. Do not put
tools or other metal objects across the top of the battery its terminals.
WARNING
Maintenance and repairs must be done by authorized personnel only. Tighten all fasteners. Keep adjustments
according to the specifications given in the machine’s service manual. Keep machine’s electrical parts dry.
Store the machine in a building.
WARNING
Make sure that all labels, decals, warnings, cautions and instructions are fastened to the machine.
Get new labels and decals from American-Lincoln.
WARNING
To maintain stability of this sweeper in normal operation, the counterweights, overhead guard, rear bumper guard
or any similar components installed by the manufacturer as original equipment should never be removed.
If it becomes necessary to remove component(s) for repair or maintenance,
REINSTALL before the sweeper is put back in operation.
WARNING
The hopper could lower unexpectedly and cause personal injury.
Engage the hopper safety arm before working on or under the hopper.
SAFETY PRECAUTIONS
ENGLISH
WEEE Symbol Information
Correct Disposal of This Product (Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with separate
collection systems)
This marking, shown on the product or its literature, indicates that it should not be
disposed with other household wastes at the end of its working life. To prevent possible
harm to the environment or human health from uncontrolled waste disposal, please
separate this from other types of wastes and recycle it responsibly to promote the
sustainable reuse of material resources. Household users should contact either the
retailer where they purchased this product, or their local government office, for details
of where and how they can take this item for environmentally safe recycling. Business
users should contact their supplier and check the terms and conditions of the purchase
contract. This product should not be mixed with other commercial wastes for disposal.

1-10 American-Lincoln
MPV 60
HORN BUTTON
The horn button is located on the left side console. Push the button to sound the horn. The horn button is
always active.
LIGHT SWITCH
The light switch is located on the instrument panel and controls the headlights, taillights and instrument panel
lights. To turn on the lights press the upper portion of the switch. The upper potion of the switch will illuminate to
indicate the lights are “ON”. The light switch is always active.
GLOW PLUG SWITCH (Diesel Only)
The glow plug switch is a momentary type rocker switch that is located on the instrument panel and is used to
start the diesel engine. It should be noted that under no circumstances should Ether or other starting aids be
used in conjunction with the glow plugs. To prevent damage to the glow plug switch, do not use for more than
60 seconds. They key switch must be placed in the “ON” position before using the glow plug switch.
CHECK ENGINE LIGHT (Gas/LP Only)
The check engine light is located on the left side console. If the light comes on, it indicates a problem with the
engine. Flip the switch located on/near the air cleaner bracket in the engine compartment and count the number
of times the panel light flashes, then go to “Check Engine Light Codes” at the end of this chapter to determine
the problem.
GLOW
PLUG
SWITCH
MAIN
BROOM
LEVER
LIGHT
SWITCH
HOPPER
LEVER
HOPPER
DOOR
LEVER
BROOM
LEVER
CHECK
ENGINE
LIGHT
(GAS/LP)
HORN
THROTTLE
LEVER
(Diesel)
HOUR METER
WARNING BANK
FUEL GAUGE
FILTER SHAKER
SWITCH
DUST CONTROL SWITCH
SIDE
BROOM
LEVER
MAIN
BROOM
ADJUSTMENT
PARKING
BRAKE
LEVER
SEAT
ADJUSTMENT
FOOT
BRAKE
FWD./REV.
FOOT
PEDAL
CURCUIT
BREAKERS
TILT
STEERING
LEVER
SIDE
BROOM
ADJUSTMENT
KEY
SWITCH
ENGINE SPEED
SWITCH (Gas/LP)
C1416ecp FIGURE 2
SWEEPER CONTROLS/INSTRUMENTS

American-Lincoln 1-11
MPV 60
KEY SWITCH (figure 3)
The keyed ignition switch is located on the instrument
panel to the right of the steering column. The key switch is
a four position switch that controls power to the sweeper
systems and accessories. The “OFF ” position (0 position)
will shut off the engine. The IGN./ON position (I position)
provides power to all sweeper systems and accessories.
The “START” position (one position clockwise of I position)
is momentary and provides power to the starter motor. The
“ACC” (one position counterclockwise of 0 position) position
is the same as the IGN./ON position and provides power to
all electrical systems and accessories.
ENGINE SPEED SWITCH (Gas/LP) (figure 4)
The engine is controlled by a three-position switch which is
located on the instrument panel above the key switch. The
switch position determines the operating speed of the
engine. Place the speed switch in the “IDLE” position to
start the sweeper. Place the switch in the “1” position for
transport and when normal sweeping action is desired.
Place the switch in the “2” position for transport and
sweeping lightweight debris.
THROTTLE LEVER (Diesel) (figure 2)
The throttle lever is located on the left side console. There
are 3 throttle speed positions - IDLE, 1, and 2. To operate,
grasp the lever and push up and left to desired locking
notch. To reduce to idle, grasp the lever and push it up and
to theright (away from both locking notches). Let the lever
lower until it rests at the bottom of the slot.
“Load” (brooms and/or brushes and/or dust control operat-
ing) and “No Load” (brooms, brushes & dust control off)
RPMs are the same for gas and LP equipment; The will be
a slight drop between “Load” and “No Load” RPMs with
diesels. Always return the throttle switch/lever to the idle
position before turning off the key to stop the engine.
HOUR METER (figure 5)
The hour meter is located on the instrument panel. The
meter is activated when the engine begins running. The
meter indicates actual “run” time of the sweeper. The meter
can be used to determine when maintenance should be
done on the sweeper
FUEL GAUGE (figure 5)
The fuel gauge is located on the instrument panel and
indicates the level of fuel in the tank. The fuel gauge is
powered by the key switch. The key switch must be in the
“ON” position for the fuel gauge to work. The fuel gauge is
not included on machines that use Liquid Propane fuel.
C1417/9702
KEY
SWITCH
HOUR
METER
FUEL
GAUGE
C1419
C-1419 FIGURE 5
C-1418 FIGURE 4
C-1417 FIGURE 3
C1418/9702
ENGINE
SPEED
SWEEPER CONTROLS/INSTRUMENTS
MACHINE RPMs
IDLE “NO LOAD”
SWEEPER/ Gas/LP 950 2050
SCRUBBER Diesel 950 2150
(1 speed level)
SWEEPER Gas/LP 1st 950 2050
(2 speed levels) 2nd 950 2450
Diesel 1st 950 2150
2nd 950 2550

1-12 American-Lincoln
MPV 60
FOOT BRAKE (figure 6)
The foot brake pedal is located on the floor of the
operator’s compartment to the left of the foot pedal.
To stop, use the sweepers front wheel brakes, by putting
pressure on the brake pedal.
PARKING BRAKE (figure 7)
The parking brake lever is located on the operator’s
compartment left side panel near the floor. When engaged
the parking brake “locks” the foot pedal in the down
position.
-To engage the parking brake, place the lever in the upright
position.
-To disengage the parking brake, move the lever forward.
-To Adjust The Parking brake “Grab” Turn the knob on the
top of the lever.
-To increase “Grab” Turn the knob in a clockwise direction.
-To decrease “Grab” Turn the knob in a counterclockwise
direction.
FOOT PEDAL (figure 8)
The Foot Pedal is located on the floor of operator’s
compartment to the right of the brake pedal. The foot
pedal provides control of direction/speed and has an
automatic safety feature that limits foot pedal travel while
the hopper is raised. The pedal height is adjustable to
provide for operator comfort.
TO GO FORWARD: Place pressure on the upper portion
of the pedal. Speed increases when additional pressure is
placed on the pedal.
TO GO BACKWARD: Put pressure on the lower portion of
the pedal. Speed increases when additional pressure is
placed on the pedal.
TO STOP: allow the pedal to return to the centered
position.
To Increase braking action while sweeper is moving
forward, gently put pressure on the lower portion of the
pedal.
To Increase braking action while traveling in reverse, gently
put pressure on the upper portion of the pedal.
To adjust the foot pedal height for operator comfort
1. Remove the hairpin cotter from the adjustment pin.
2. Remove the adjustment pin from the foot pedal assem-
bly.
3. Align the holes in the lower bracket with one of the
four adjustment holes on the foot pedal to set the foot
pedal height.
4. With the holes aligned at the desired height, insert the
adjustment pin
5. Reinstall the hairpin cotter.
FOOT
PEDAL
PARKING
BRAKE
REVERSE
NEUTRAL
NEUTRAL
FORWARD
C-1421A FIGURE 6
C-1421B FIGURE 7
P-4066 FIGURE 8
SWEEPER CONTROLS/INSTRUMENTS

American-Lincoln 1-13
MPV 60
WARNING BANK
The Warning Bank is located on the instrument panel and provides the operator with six fault/status indicators
for engine and sweeper systems. The Operator should monitor the indicators while sweeping. It is very important
that the operator be familiar with the meaning of each indicator.
ENGINE TEMP LIGHT
The engine temperature light illuminates to indicate an engine cooling system fault.
When this occurs the operator must turn off the sweeper immediately and have the
cooling system serviced by a qualified service technician.
ENGINE OIL PRESSURE LIGHT
When the oil pressure drops below approximately 5 psi an automatic protection circuit
shuts down the engine and illuminates the light to indicate low engine oil pressure.
When this occurs have the sweeper serviced by a qualified service technician.
CHARGING SYSTEM LIGHT
The charging system light illuminates to indicate a charging system fault. When this
occurs the sweeper charging system is not working properly and must be serviced by a
qualifiedservice technician.
DUST CONTROL LIGHT
The Dust Control Light Illuminates to indicate that the dust control filter is clogged.
When this occurs, stop sweeping and use the filter shaker to clear dirt and debris from
the filter. After using the filter shaker continue sweeping.
HOPPER TEMPERATURE LIGHT (OPTION)
When the temperature of the air moving through the dust control system in the hopper
exceeds 140° F, an automatic protection feature shuts down the dust control fan and
illuminates the hopper temperature light. When this occurs shut down the sweeper and
carefully investigate for a possible fire in the hopper. The temperature switch must be
manually reset.
DUMP DOOR LIGHT
The dump door light will illuminate when the dump door is not fully open. The light
warns the operator to open the hopper dump door completely before sweeping. Do not
sweep when the light is illuminated.
WARNING
BANK
ENGINE
TEMP
LIGHT
HOPPER
DUMP DOOR
LIGHT
DUST
CONTROL
LIGHT
HOPPER
TEMP
LIGHT
ENGINE OIL
PRESSURE
LIGHT
CHARGING
SYSTEM
LIGHT
C1422
C-1422 FIGURE 9
SWEEPER CONTROLS/INSTRUMENTS

1-14 American-Lincoln
MPV 60
TILT STEERING
LEVER
TILT
RELEASE
TILT
LOCK
C-0507
SEAT
POSITION
ADJUSTMENT
LEVER
TO ADJUST
TO
LOCK
C-0508a
LIGHTS
LIGHTS
WORK
LIGHT
WORK
LIGHT
GLOW
PLUG
GLOW
PLUG
FILTER
SHAKER
FILTER
SHAKER
DUST
CONTROL
DUST
CONTROL
ENGINE
SPEED
ENGINE
SPEED
IDLE
OFF
ACC
ACC
IGN/ON
START
1
2
HOURS
0 0 0 0 0
1/10
1/10
0
1/2
4/4
4/4
FUEL
FUEL
American-Lincoln
American-Lincoln
TURN SIGNAL
SWITCH
4-WAY FLASHER
SWITCH
TO SIGNAL
LEFT TURN
TO SIGNAL
LEFT TURN
TO TURN
ON 4-WAY
FLASHER
TO TURN
ON 4-WAY
FLASHER
TO SIGNAL
RIGHT TURN
TO SIGNAL
RIGHT TURN
C-0513/9406
C-0507 FIGURE 10
C-0508a FIGURE 11
C-0513 FIGURE 12
SWEEPER CONTROLS/INSTRUMENTS
TILT STEERING LEVER (figure 10)
The tilt steering lever is located near the base of the steering
column and is spring loaded to the locked position.
To adjust the steering column tilt angle, Grasp the lever and
pull back. While holding the lever, position the steering
wheel to the desired angle, and release the lever to lock the
column in place.
SEAT POSITION ADJUSTMENT (figure 11)
The seat adjustment lever is located on the right side of the
seat base. The lever is spring loaded to the “LOCK” position.
To adjust the seat, push “FORWARD” on the lever and move
seat to desired position then release the lever to “LOCK” the
seat in place.
4-WAY TURN SIGNALS (OPTION) (figure 12)
The turn signal switch is located on the steering column and
functions the same as a typical automotive turn signal. The
operator must return the lever to the centered position after
the turn has been completed.
To signal a right hand turn move the lever to the “FOR-
WARD” position.
To signal a left hand turn position the lever to the “BACK-
WARD” position.
To use the 4-way Flashers pull out on the turn signal lever.
BACK UP ALARM (OPTION)
The backup alarm is activated by a switch in the foot pedal
and automatically emits a loud audible noise when the
machine is driven in reverse.

American-Lincoln 1-15
MPV 60
DUST CONTROL SWITCH (figure 13)
The dust control is a two position switch that is located on
the instrument panel next to the engine speed switch. The
switch controls the vacuum fan in the dust control system.
To turn on the dust control system for “NORMAL” Sweep-
ing, press on the top portion of the switch.
To Turn off the dust control system for sweeping in wet
conditions, press on the lower portion of the switch. This
will prevent the filter from being damaged by water pickup
while sweeping.
FILTER SHAKER SWITCH (figure 14)
The filter shaker switch is located on the instrument panel
below the fuel gauge. This is a momentary switch that will
activate the filter shaker motors for 20 to 30 seconds to
clear the dust control filter. The impeller fan will stop when
the filter shaker has been activated. The filter shaker will
only operate with the hopper in the “DOWN” position.
Use the filter shaker to clear the filter when the dust control
light on the warning bank illuminates and just before
dumping the hopper.
To activate the filter shaker press the upper portion of the
filter shaker switch momentarily and release. The filter
shaker will operate for 20 to 30 seconds.
BROOMS CONTROL LEVER (figure 15)
The brooms control lever is located on the operator’s
compartment center console. The lever is a three position
hydraulic valve that controls hydraulic power to the main
broom and side broom.
WARNING
To prevent injury, Do not turn on the brooms with the hopper
raised.
To turn on the main broom only, move the LEFT HAND lever
to the forward position.
To turn on the main broom and the side broom, move the
LEFT HAND lever fully backwards.
To turn off the brooms and provide hydraulic power to the
hopper lift system place the lever in the center position.
SWEEPER CONTROLS/INSTRUMENTS
C1425/9702
DUST
CONTROL
C1426/9702
FILTER
SHAKER
C1424/9702
BROOM
CONTROL
LEVER
C-1425 FIGURE 13
C-1426 FIGURE 14
C-1424A FIGURE 15

1-16 American-Lincoln
MPV 60
SIDE BROOM LEVER (figure 16)
The side broom lever is located on the right side of the
instrument panel. The side broom lever raises and lowers the
side broom. Use the brooms lever on the operator’s center
console to turn on the side broom.
To raise the side broom, pull the lever back into the “UP”
position.
To lower the side broom, move the lever out of the “UP”
position and move it forward to the “DOWN” position.
SIDE BROOM ADJUSTMENT (figure 16)
The side broom lever has an adjustment for changing the
sweep height to compensate for broom wear. The side broom
adjustment is located under the right side of the instrument
panel.
To Adjust the side broom height turn the threaded knob. (See
page 30 for adjustment instructions)
MAIN BROOM LEVER (figure 17)
The main broom lever is located on the left side of the
instrument panel. The main broom lever has three positions
and controls the main broom sweep height. Use the brooms
lever on the operator’s center console to turn on the main
broom.
To lower the main broom, grasp the lever and move it to the
left out of the “UP” position and place in the “SWEEP” or
“FLOAT” position.
The “SWEEP” position is used for normal sweeping and
should be used under most sweeping conditions.
The “FLOAT” position is used for sweeping very uneven
surfaces only. Using the Float position will cause premature
wear on the main broom if used under normal operating
conditions for extended periods of time.
MAIN BROOM ADJUSTMENT (figure 17)
The main broom lever has an adjustment for changing the
sweep height to compensate for broom wear. The main
broom adjustment is located under the left side of the
instrument panel.
To Adjust the main broom height turn the threaded knob.
(See page 29 for adjustment instructions)
SWEEPER CONTROLS/INSTRUMENTS
LIGHTS
WORK
LIGHT
MAIN BROOM
FLOAT
SWEEP
UP
HOURS
0000
1/10
MAIN BROOM
LEVER
MAIN BROOM
ADJUSTMENT
c0512a
FILTER
SHAKER
DUST
CONTROL
SIDE BROOM
UP
DOWN
ENGINE
SPEED
IDLE
OFF
ACC IGN/ON
START
1
2
0
1/2
4/4
FUEL
SIDE BROOM
ADJUSTMENT
SIDE BROOM LEVER
c0511a
C-0511A FIGURE 15
C-0512 FIGURE 16

American-Lincoln 1-17
MPV 60
C519a
HOPPER
LIFT
LEVER
C-0518A
HOPPER
DOOR
LEVER
C-0517A
C-0517B FIGURE 18
C-0518A FIGURE 19
C-0519A FIGURE 20
HOPPER DOOR LEVER (figure 18)
The hopper door lever is located on the operator’s compart-
ment center console and is used to close and open the
hopper dump door. The lever is a three position hydraulic valve
that is spring loaded to the center position which “HOLDS”
the hopper door in position.
NOTE
To provide hydraulic power to the hopper controls, the broom
control lever must be in the center “Neutral” Position
To ensure the door is fully open while sweeping, monitor the
Hopper Dump Door light on the Warning Bank . The light will
illuminate when the door is not fully open.
To open the hopper dump door for sweeping or dumping, push
the CENTER lever forward in the “OPEN” direction until the
hopper dump door light goes out.
To close the hopper dump door for dumping or transporting,
pull the CENTER lever fully back in the “CLOSE” direction and
hold for 3 seconds or until you hear the door close.
HOPPER LIFT LEVER (figure 19)
The hopper lift lever is located on the operator’s compartment
center console. The lever is a three position hydraulic valve
that controls the operation of the hopper lift system. The lever
is spring loaded to the center position which stops hopper
movement and “HOLDS” the hopper at the present position.
NOTE
To provide hydraulic power to the hopper controls, the broom
control lever must be in the center “Neutral” Position
To raise the hopper for dumping, move the RIGHT HAND lever
back to the “RAISE” position and hold until the hopper
reaches the desired height, then release.
WARNING
To prevent injury, Do not turn on the brooms with the hopper
raised.
To lower the hopper after dumping, move the RIGHT HAND
lever forward to the “LOWER” position until the hopper is fully
lowered and seated in the sweeper, then release.
HOPPER LID (figure 20)
The hopper lid provides the operator with easy access to the
hopper debris compartment for refuse disposal or visual
inspection. The dust control must be turned off before opening
the hopper lid.
To open the hopper lid turn the dust control switch to the
“OFF” position then unlatch and lift the front hinged lid. The
Hopper lid must be closed while sweeping. Failure to close
the door completely will cause poor dust control while
sweeping.
SWEEPER CONTROLS/INSTRUMENTS

1-18 American-Lincoln
MPV 60
CIRCUIT BREAKERS (figure 22)
The circuit breakers are located to the left of the steering
wheel. When a circuit breaker “pops” out, this is an
indication of an electrical problem that must be corrected
before the breaker can be reset.
There can be up to eight circuit breakers in the row. They
control the following circuits, beginning with number 1 on
the left:
CB-1 = Filter shaker motors
CB-2 = Horn
CB-3 = Starter relay
CB-4 = Ignition
CB-5 = Accessory
CB-6 = Lighting
CB-7 = Options
CB-8 = Cab Options
ENGINE COMPARTMENT LATCH (figure 23)
The engine cover encloses the entire engine, radiator and
hydraulic reservoir assembly. The cover can be swung open
to allow easy access to the engine and hydraulics for
service or inspection.
WARNING
Operate Only When Lids, Doors, And Access Panels Are
Securely Closed.
To open the cover, lift the cover latch lever up. Swing the
cover open.
The cover will latch automatically when the cover is closed.
After closing the engine cover, check to be certain the latch
has fully engaged.
SWEEPER CONTROLS/INSTRUMENTS
C-0521
Ame
CIRCUIT
BREAKERS
C-0521 FIGURE 22
C-1436 FIGURE 23
60
American-Lincoln
ENGINE
COMPARTMENT
LATCH
TO
OPEN

American-Lincoln 1-19
MPV 60
HYDRAULIC RESERVOIR LEVEL SIGHT GAUGE
(figure 24)
The sight gauge is located on the side of the hydraulic
reservoir in the engine compartment. The sight gauge is
used to indicate the level of fluid in the reservoir. Fluid level
must be visible in the sight gauge when the hopper is in the
down position.
MAIN BROOM COMPARTMENT DOORS (figure 25)
The main broom compartment doors are located behind the
front tires on both sides of the sweeper. The doors provide
access to the main broom for service or inspection.
WARNING
Operate Only When Lids, Doors, And Access Panels Are
Securely Closed.
Open the right side door to remove or replace the main
broom. The right side door is an integral part of the main
broom drive system and must be closed for operation.
Open the left side broom door for inspection. Check the
drive hub for banding and shrink wrap which have a ten-
dency to get tangled in the broom driver.
To open the main broom door, reach inside the hole in the
door and lift up on the latch handle.
The door latch will automatically engage when the door is
closed.
SWEEPER CONTROLS/INSTRUMENTS
60
American-Lincoln
MAIN BROOM
COMPARTMENT
LATCH
TO
OPEN
HYDRAULIC RESERVOIR
LEVEL SIGHT GAUGE
C-0524
C-0524 FIGURE 24
C-1435 FIGURE 25
