NetWay1 -1-
Overview:
Altronix NetWay1 is a single port midspan PoE compliant power injector which provides power and passes data
(e.g. video) for PoE compliant devices. Devices may be located up to 100m (328 ft.) from NetWay1.
ANetWayXT repeater module can be utilized to extend the distance an additional 100m (328 ft.) for a total range of up to
200m (656 ft.). A maximum range of 600m (1968 ft.) is possible using multiple repeaters, based on device port require-
ment. NetWay1 is capable of supporting non-PoE compliant fixed IP cameras by utilizing NetWay1512 adapter.
Installation Instructions:
Wiring methods shall be in accordance with the National Electrical Code/NFPA70/ANSI, and with all local codes and
authorities having jurisdiction. Wiring should be UL Listed and/or Recognized wire suitable for the application.
Unit is intended to be used with a UL Listed Class 2 or LPS (limited power supply). NetWay1 is not intended to be
connected to outside plant leads and should be installed indoors within the protected premises.
NetWay1 is intended for indoor use only.
1. Mount NetWay1 in desired location utilizing the mounting hole (Fig. 1a, pg. 2).Use a proper fastener and/or wall
anchor when securing NetWay1 with screw through its mounting hole to the wall.
2. Connect 24VAC/24VDC to terminals marked [24VAC/VDC Input], (Fig. 1b, pg. 2). Use 22AWG-16AWG
wire for this connection. Input power should be a UL Listed Access Control power limited power supply (for UL294
applications) or Class 2 rated transformer/power supply (for UL60950-1 applications).
3. Connect structured cable from port marked [IN] on NetWay1 to the corresponding input of an UL Listed ethernet
switch or video server (Fig. 1b, pg. 2).
4. Connect structured cable from port marked [OUT] on the NetWay1 to PoE device (Fig. 1b, pg. 2).
All interconnected devices must be UL Listed.
5. Port status LED will illuminate indicating normal operation (Fig. 1c, pg. 2).
6. To initiate PoE shutdown connect 12VAC to 24VAC or 5VDC to 24VDC to the input terminals marked [PoE Shutdown]
on the NetWay1 (Fig. 1b, pg. 2).The PoE output voltage may be shutdown by manually applying voltage in the rated
range (PoE Shutdown Voltage Range in Specifications).Upon applying voltage the output will drop to zero volts.
Removal of voltage from the shutdown terminals or applying zero volts to the shutdown terminals will allow the PoE
output to operate normally to supply power to PoE compliant devices.
Note: Return to normal operation from shutdown can take about 4 seconds. Although there is no output voltage to
power PoE devices during shutdown, data signals may still be present on the data pair lines of the CAT5 cable.
Agency Listings:
• UL/CUL Listed for Information
Technology Equipment (UL 60950-1).
• UL Listed for Access Control Systems (UL294).
CUL Listed - CSA Standard C22.2 No.205-M1983,
Signal Equipment.
• CE approved.
Input:
• 24VAC @ 1.2 amp or 24VDC @ 1.2 amp.
Data:
• One (1) PoE port provides power and passes data
over ethernet (CAT5) cable up to 100m (328 ft.).
• Data rate: 10/100 BASE-T compliant.
Output Power:
• Port provides up to 15.4W max.
• IEEE 802.3af compliant.
•48VDC.
Output Power (cont’d):
• Short circuit protection.
Functions:
• Port status LED.
• PoE manual shutdown (For UL 60950-1 applications
only) (see Technical Specifications table pg. 4).
•Auto detection and protection of legacy
non-PoE cameras/devices.
• Compact insulated housing.
• Spring terminals (input and PoE shutdown).
Accessories:
NetWay1512:
• 13W adapter for non-PoE compliant IP cameras.
(For UL 60950-1 applications only).
NetWayXT:
•PoE repeater module extends range 100m (328 ft.).
(For UL 60950-1 applications only).
Features:
Installation Guide
NetWay1 - Single Port PoE Injector
for Standard Network Infrastructure
®
Rev. 102609

Installing a NetWay1512 adapter for 12VDC IP cameras up to 13W:
1. Mount NetWay1512 in proximity of IP camera (Fig. 3, pg. 3).Use velcro (supplied).
2. Connect structured cable from port marked [IN] on NetWay1512 to port marked [OUT] of NetWay1
(Fig. 3, pg. 3, Fig. 1b pg. 2).
3. Connect structured cable from portmarked [OUT] on NetWay1512 to the IP camera/device (Fig. 3, pg. 3, Fig. 1b pg. 2).
4. Connect 12VDC output from NetWay1512 terminals marked [---12VDC +] to the power input of the
IP camera (Fig. 3, pg. 3). Polarity must be observed.
5. Power LED indicator will illuminate on NetWay1512 under normal conditions (Fig. 3, pg. 3).
NetWay1 PortStatus and LED Flash Codes
Installing NetWayXT repeater module:
1. Mount NetWayXT in desired location utilizing the mounting hole (Fig. 4, pg. 3).Use a proper fastener and/or wall
anchor when securing NetWayXT to the wall.
2. Connect structured cable from port marked [OUT] on NetWay1 to port marked [IN] on the
NetWayXT (Fig. 4, pg. 3, Fig. 1b pg. 2).
3. Connect structured cable from port marked [OUT] on NetWayXT to the PoE camera/device or next NetWayXT
repeater (Fig. 4, pg. 3).
4. Port status LEDs will illuminate on NetWayXT indicating the port is operational (Fig. 4, pg. 3,
refer to Port LED definitions on pg.2).
5. Power LED will illuminate indicating 12VDC output (Fig. 4, pg. 3).
Port LED definitions for NetWayXT repeater:
-2- NetWay1
Status Green LED Yellow LED
OFF Indicates it is connected as 10Base-T or no link. Indicates no link.
ON Indicates it is connected as 100Base-T. Indicates a link.
Blinking ------- Indicates activity.
Port Status Flash Code Flash Pattern
Non-Powered Device 0Ω < RPORT <200ΩOFF LED OFF
PortOpen RPORT>1MΩOFF LED OFF
Port On 25kΩON LED ON
LowSignature Resistance 300Ω < RPORT<15kΩ1Flash Zlll Zlll Zlll
High Signature Resistance 33KΩ < RPORT <500kΩ2Flashes Z Z l l Z Z l l Z Z l l
Port Overload Fault 5Flashes llll ZZ Z Z Z llll
Structured
Cable from
Network
Switch
24VAC/
24VDC Input
12VAC to 24VAC or
5VDC to 24VDC Input
for PoE shutdown
Structured Cable from
IP Camera, IP Lock or IP device,
NetWay1512 or NetWayXT
24VAC/VDC
Input Power ShutdownIN OUT
Port
Status
General Signaling
Equipment 92R2
I.T.E. 43KC
NetWay1
Single Port Injector (Midspan)
24VAC/VDC, 1.2A Input
48VDC 15.4W max. per IEEE 802.3af
www.altronix.com
Equipment 92R2
Access Control PoE Injector
Attack Class
I
Fig. 1b
Fig. 1a
Structur
Cable fr
Netwo
Switc
24VAC/
24VDC Input
Struc
IP Camera
NetWay
24VAC/VDC
Input Power ShutdownIN OUT
Port
Status
General Signaling
Equipment 92R2
I.T.E. 43KC
NetWay1
Single Port Injector (Midspan)
24VAC/VDC, 1.2A Input
48VDC 15.4W max. per IEEE 802.3af
www.altronix.com
Equipment 92R2
Access Control PoE Injector
Attack Class
I
Fig. 1c
Fig. 1

NetWay1 -3-
NVR/Network Server
Network Switch
24VAC/
24VDC input
PoE Camera
CAT-5 additional
100m (328 ft.)
CAT-5
100m (328 ft.)
Port shutdown
input
Netway1
NetwayXT
Video Monitor
Fig. 7
Typical Applications:
Video Monitor
NVR/Network Server
Network Switch
Netway1 PoE Camera
CAT-5
100m (328 ft.)
Port shutdown
input
24VAC/
24VDC input
Fig. 5a - Typical UL294 application
NVR/Network Server
NetWay1512
Network Switch
12VDC
IP Camera
CAT-5
100m (328 ft.)
24VAC/
24VDC input
Port shutdown
input
Video Monitor
Netway1
Fig. 6
PC/Server
Network Switch
CAT-5
100m (328 ft.)
UL Listed
Access Control
Power Limited
Power Supply
24VDC/24VAC
Card
Reader
Electric
Strike
HID
Solo Edge
Device
Netway1
Fig. 5b
NetwayXT
Repeater
www.altronix.com
IN
OUT
Power
Power
LED
Structured
Cable from
NetWay1
Structured
Cable from
PoE Camera/
Device or
next NetWayXT
Port Staus
LEDs
I.T.E. 43KC
Fig. 3 Fig. 4
www.altronix.com
IN OUT
Netway1512
Adapter
12VDC
--- Output +
-- +
12VDC
Power to
Camera/Device
Structured
Cable from
NetWay1
Structured Cable
from IP Camera/Device
I.T.E.
43KC

Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: [phone]
website: www.altronix.com, e-mail: [email protected], Lifetime Warranty, Made in U.S.A.
IINetWay1 H06I
-4- NetWay1
MEMBER
Maintenance:
Unit should be tested at least once a year for the proper operation as follows:
While the NetWay1 is powered and the output is connected to a suitable UL Listed PoE device.
The NetWay1 should be tested for PoE shutdown operation (For UL 60950-1 applications only).
For UL294 applications, the NetWay1 is to be tested as part of a complete Access Control System and in accordance
with listed Access Control Devices.
Troubleshooting:
Refer to NetWay1 Port Status and LED Flash Codes pg. 2.
Technical Specifications:
Parameter Description
No. of Ports One (1)
Input power requirements 24VAC @ 1.2 amp (min. 30VA transformer, For UL 60950-1 applications only)
or 24VDC @ 1.2 amp.
Indicators Port Status LED
PoE Shutdown Voltage and
Current Range
5VDC to 24VDC or 12VAC to 24VAC
Maximum current: 2mA for 5VDC
Maximum current for higher voltages: 10mA
Environmental Conditions
Operating Ambient Temperature: UL60950-1 - 32ºF to 104ºF (0ºC to 40ºC).
UL294 - 32ºF to 120.2ºF (0ºC to 49ºC).
Relative humidity: 85%, +/ ---5%
Storage Temperature: ---4º to 158ºF (---20º to 70ºC) Storage
Operating Altitude: ---1000 to 10,000 ft. (---304.8 to 3048m).
Regulatory Compliance UL/CUL Listed for Information Technology Equipment (UL 60950-1).
UL Listed for Access Control Systems (UL294).
CUL Listed - CSA Standard C22.2 No.205-M1983, Signal Equipment.
CE approved
