Altronix OLS75 User manual

Overview:
OLS75 power supply/charger converts 115VAC, 60Hz or 230VAC, 50Hz input, into a 12VDC or 24VDC @ 2.5 amps of
continuous supply current (see specifications). This general purpose power supply has a wide range of application for
access control and security system accessories that require additional power.
Specifications:
• 12VDC or 24VDC selectable output.
• 2.5 amp continuous supply current.
• Universal input 115VAC, 60Hz, 0.95 amp or 230VAC, 50Hz, 0.6 amp.
• Filtered and electronically regulated outputs.
• Built-in charger for sealed lead acid or gel type batteries.
• Maximum charge current .5 amp.
• Automatic switch over to stand-by battery when AC fails
(zero voltage drop).
• Low battery supervision (form "C" contacts).
• AC fail supervision (form "C" contacts).
•Short circuit and thermal overload protection.
• AC input and DC output LED indicators.
• Power ON/OFF switch.
• Includes batteryleads.
Board Dimensions (approximate): 4.5”W x 7.25”L x 1.75”H
Specified at 25˚ C ambient.
Voltage Output Selection Table:
Output VDC Switch Position Max. Load DC
12VDC SW 1 - Closed 2.5 amp
24VDC SW1 - Open 2.5 amp
Installation Instructions:
The OLS75 should be installed in accordance with The National Electrical Code and all applicable Local Regulations.
1. Mount the OLS75 in desired location/enclosure.
2. Slide [Power ON/OFF] switch to OFF position.
3. Set the OLS75 to desired DC output voltage via SW1 (Voltage Output Selection Table).
4. Connect AC power to terminals marked [L & N], connect ground to terminal marked [G].
Use 18 AWG or larger for all power connections (Battery, DC output).
Use 22 AWG to 18 AWG for power limited circuits (AC Fail/Low Battery reporting).
5. Measure output voltage before connecting devices. This helps avoid potential damage.
6. Connect devices to be powered to terminals marked [– DC +].
7. When the use of stand-by batteries are desired, they must be lead acid or gel type.
Connect battery to terminals marked [-- BAT +] (battery leads included).
Use two (2) 12VDC batteries connected in series for 24VDC operation.
8. When batteries are not used a loss of AC will result in the loss of output voltage.
9. Connect appropriate signaling notification devices to AC Fail & Low battery supervisory
relayoutputs marked [NC, C, NO].
10. Slide [Power ON/OFF] switch to ON position.
OLS75 - Offline Power Supply/Charger

LED Diagnostics:
Red (DC) Green (AC) Power Supply Status
ON ON Normal operating condition.
ON OFF Loss of AC, Stand-by battery supplying power.
OFF ON No DC output. Short circuit or thermal overload condition.
OFF OFF Loss of AC. Discharged or no stand-by battery. No DC output.
Terminal Identification:
Terminal Function/Description
Legend
L, G, N Connect 115VAC/230VAC to these terminals:
Lto Hot, N to Neutral, G to ground.
– DC + 12VDC / 24VDC @ 2.5 amp continuous supply current.
AC FAIL Used to notify loss of AC power, e.g. connect to audible device or alarm
NC, C, NO panel. Relay normally energized when AC power is present.
Contact rating 1 amp @ 115VAC / 28VDC
Low Battery Used to indicate low battery condition, e.g. connect to alarm panel.
NC, C, NO Relay normally energized when DC power is present.
Contact rating 1 amp @ 115VAC / 28VDC
Lowbatterythreshold:
12VDC output threshold set @ approximately 10.5VDC,
24VDC output threshold set @ approximately 21VDC.
– BAT+ Stand-by battery connections. Maximum charge rate .5 amp.
LG N
OFF ON
OPEN - 24VDC
CLOSED - 12VDC
LOW BAT
NC C NO NC C NO
AC FAIL
--- BAT + --- DC +
AC DC
5A 250V
Altronix is not responsible for anytypographical errors. Product specifications are subject to change without notice.
140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: [phone]
website: www.altronix.com, e-mail: [email protected], Lifetime Warranty, Made in U.S.A.
IIOLS75 - Rev. 010704 E05J MEMBER
