Altronix Trove1V1 User manual

Trove1V1 - Altronix/HID VertX - 1 -
Overview:
Trove1V1 accommodates various combinations of HID VertX®boards with or without Altronix power
supplies and accessories for access systems.
Specifications:
Trove1V1
Trove1 enclosure with TV1 Altronix/HID VertX®backplane.
• 19 Gauge grey enclosure with ample knockouts for convenient access.
• Includes: tamper switch, cam lock, lock nuts and mounting hardware.
Enclosure Dimensions (H x W x D): 18” x 14.5” x 4.625” (457mm x 368mm x 118mm)
TV1
Altronix/HID VertX®backplane.
• 19 Gauge backplane.
• Includes mounting hardware.
Dimensions (H x W x D): 16.625” x 12.5” x 0.3125” (422.275mm x 317.5mm x 7.9mm)
TV1 Backplane accommodates a combination of the following:
• One (1) Altronix AL400ULXB2, AL600ULXB, AL1012ULXB, AL1024ULXB2,
eFlow4NB, eFlow6NB, eFlow102NB or eFlow104NB.
• One (1) Altronix ACM4(CB), MOM5, PD4UL(CB), PD8UL(CB), PDS8(CB), VR6.
• Two (2) of either HID VertX®V100, V200, V300, V1000 or V2000.
Installation Instructions:
Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/ANSI, and with all
local codes and authorities having jurisdiction. Product is intended for indoor use only.
1. Remove backplane from enclosure. Do not discard hardware.
2. Mark and predrill holes on the wall to line up with the top two keyholes in the enclosure.
Install two upper fasteners and screws in the wall with the screw heads protruding.
Place the enclosure’s upper keyholes over the two upper screws, level and secure.
Mark the position of the lower two holes. Remove the enclosure.
Drill the lower holes and install the two fasteners. Place the
enclosure’s upper keyholes over the two upper screws.
Install the two lower screws and make sure to
tighten all screws.
3. Mount included UL Listed tamper switch
(Ademco model 112 or equivalent) in desired location,
opposite hinge. Slide the tamper switch bracket onto
the edge of the enclosure approximately 2” from the
right side (Fig. 1, pg. 1). Connect tamper switch
wiring to the Access Control Panel input or the
appropriate UL Listed reporting device.
To activate alarm signal open the door of the enclosure.
4. Mount Altronix/HID VertX®modules to TV1 backplane,
refer to Page 2.
Rev. 080916
Installation Guide
Versatile Access Power and Integration Enclosures
Trove1V1
- Trove1 enclosure with Altronix/HID VertX®backplane (TV1)
TV1
- Altronix/HID VertX®backplane only
Edge of
Enclosure
to Access Control Panel
or U.L. Listed
Reporting Device
Enclosure
Honeywell
model # 112
Tamper Switch
or equivalent
(provided)
Fig. 1

- 2 - Trove1V1 - Altronix/HID VertX
Mounting Hardware:
Altronix
Power Supply
Altronix
Sub-
Assembly
HID VertX®
V100, V200
V300, V1000
and V2000
HID VertX®
V100, V200
V300, V1000
and V2000
HID VertX®
V100, V200
V300, V1000
and V2000
HID VertX®
V100, V200
V300, V1000
and V2000
HID VertX®
V100, V200
V300, V1000
and V2000
HID VertX®
V100, V200
V300, V1000
and V2000
Metal
Standoff
Placement
Configuration of Altronix Power Supply
and/or Sub-Assembly Boards
1. Fasten standoffs (provided) to pems that match the hole pattern for Altronix Power Supply/
Chargers or Altronix Sub-Assembly boards (Fig. 2, pg. 2). Use male/female nylon standoffs
for the upper two mounting holes in the board. Use metal standoffs for the bottom mounting
holes to provide sufficient grounding for the board.
2. Affix boards to standoffs (Fig. 2, pg. 2) by pressing down the upper mounting holes onto nylon
standoffs. Use provided mounting screws to affix the lower mounting holes.
Make sure that boards are locked onto standoffs.
3. Fasten backplane to Trove1 enclosure utilizing lock nuts (provided).
Configuration of HID VertX®Boards
1. Fasten standoffs (provided) to pems that match the hole pattern for HID VertX®V100, V200,
V300, V1000 or V2000 boards (Fig. 2, pg. 2).
2. Mount boards to standoffs (Fig. 2, pg. 2) utilizing 7/8” pan head screws (provided).
3. Fasten backplane to Trove1 enclosure utilizing lock nuts (provided).
Fig. 2
Male/Female Standoff
Standoff (Metal or Nylon)
5/16” Pan Head Screw
7/8” Pan Head Screw
Lock Nut

Trove1V1 - Altronix/HID VertX - 3 -
TV1 Dimensions
6.25”
(
158.75mm
)
16.65”
(422.9mm)
15.65”
(397.5mm)
12.5”
(321.31mm)
8.15”
(207.01mm)
0.5” (12.7mm)
0.5” (12.7mm)

- 4 - Trove1V1 - Altronix/HID VertX
Trove1V1 Enclosure Dimensions (H x W x D):
18” x 14.5” x 4.625” (457mm x 368mm x 118mm)
14.5”
(321.31mm)
13.0”
(330.2mm)
1.45”
(36.83mm)
7.25”
(184.15mm)
4.5”
(114.3mm)
4.5”
(114.3mm) 4.5” (114.3mm) 2.75” (69.85mm)
1.25”
(31.75mm)
1.5”
(38.09mm)
8.5”
(215.9mm)
18.0”
(457.2mm)
0.5897”
(14.98mm)
1.0958”
(27.83mm)
0.6012”
(15.27mm)
6.5”
(165.1mm)
1.25”
(31.75mm)
1.25”
(31.75mm)
1.5”
(38.09mm)
8.5”
(215.9mm)
6.5”
(165.1mm)
0.569”
(14.52mm)
1.948”
(49.483mm)
1.115”
(28.32mm)
1.362”
(34.59mm)
Altronix is not responsible for any typographical errors. Product specifications are subject to change without notice.
