Altronix Pace1PTM User manual

Agency Listings:
• UL/cUL Listed for Information
Technology Equipment (UL 60950-1).
• CE European Conformity.
• C-Tick compliant.
Input:
• PoE (15W) IEEE 802.3af compliant or
PoE+ (30W) IEEE 802.3at compliant
from Pace1PRM, Pace4PRM,
Pace8PRM, or Pace16PRM.
Ethernet:
• Connectivity: RJ45, auto-crossover.
• Wire type: 4-pair CAT5e or
a single twisted pair UTP.
• Speed: 10/100BaseT, half/full duplex,
auto negotiation.
PoE compliant to IEEE 802.3af (15W) and
PoE+ compliant to IEEE 802.3at (30W)
delivered to camera by Pace1PTM.
• Throughput is rated to pass 100Mbps of data.
CAT5e or Higher from Pace Receiver:
• Distance: up to 500m @ 100Mbps
(see Max. Length of Cable Type vs.
Camera Power/PoE Class, pg. 4)
UTP (Single Twisted Pair) from Pace1PRM:
• Distance: up to 152m @ 100Mbps
(see Max. Length of Cable Type vs.
Camera Power/PoE Class, pg. 4).
LED Indicators:
• Green - PoE ON (by respective RJ45 jack).
•Yellow and Green LED IP Link status,
10/100Base-T/active.
Environmental:
• Operating Temperature:
For 15W: – 40ºC to 75ºC (– 40ºF to 167ºF).
For 25W: – 40ºC to 70ºC (– 40ºF to 158ºF).
For 30W: – 40ºC to 60ºC (– 40ºF to 140ºF).
• Storage Temperature:
– 40ºC to 75ºC (– 40ºF to 167ºF).
• Relative humidity:
20 to 85%, non-condensing.
Functions:
• Auto detection and protection of legacy
non-PoE cameras/devices.
Applications:
• Retrofit digital IP cameras in an analog
CCTV CAT5e or UTP installations.
• Extend Network link distance in an
industrial environment over 610m.
• Works with Megapixel, HD720, HD1080
and VGA (SD) cameras with proper
headend equipment.
Mechanical:
• Dimensions (W x L x H approx.):
3.5” x 3.5” x 1”
(88.9mm x 88.9mm x 25.4mm).
Overview:
Pace1PTM is a long range Ethernet transceiver designed for use with Pace1PRM, Pace4PRM, Pace8PRM, and
Pace16PRM receivers. They transmit data at 100Mbps full duplex and power via CAT5e or higher cable in a
PoE(+) compliant format or a single twisted pair (UTP) (when paired with Pace1PRM). Pace1PTM will not deliver
power to non-compliant devices, thus avoiding damage to improperly connected non-PoE cameras/devices. The
receiver passes the PoE(+) compliant power over the cable to the Pace1PTM transceiver which in turn passes this
power to an enabled IP camera/device. These plug and play units facilitate cost effective solutions for IP devices
that need to be installed at distances greater than 100m. They also provide a simple way to replace legacy analog
products with new IP devices over single twisted pair (UTP) (when paired with Pace1PRM) or structured cable.
Features:
Pace1PTM
IP and PoE+ Transceiver
Over Extended Distance
UTP or CAT5e
Installation Guide
I.T.E. 43KC
Z1409

- 2 - Pace1PTM Installation Guide
Installation Instructions:
Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/ANSI, and with all local codes
and authorities having jurisdiction. Wiring should be UL Listed and/or Recognized wire suitable for the application.
Pace1PTM is not intended to be connected to outside plant leads and should be installed indoors within the
protected premises. Pace1PTM is intended for indoor use only.
1. Secure unit to desired mounting surface with a proper fastening device utilizing the case’s mounting hole
(Fig. 2a, pg. 3). Unit should be mounted in proximity of camera/device.
2. Connect structured cable from IP camera/device to RJ45 jack marked [PoE Out] (Fig. 1, pg. 3).
3. Connect Pace1PTM to the receiver (Pace1PRM, Pace4PRM, Pace8PRM or Pace16PRM):
a. CAT5e or higher: Connect CAT5e or higher to the connector marked [RJ45 Link] (Fig. 1, pg. 3).
b. UTP: Connect UTP to connector marked [UTP Link] (Fig. 1, pg. 3).
Caution: Once PoE connection is established between the receiver and Pace1PTM, disconnection from
Pace1PTM will not disable the PoE output voltage on the receiver. Although the Pace1PTM can be reconnected,
caution should be taken not to connect the CAT5e or single UTP wiring from the receiver to any non-PoE device.
Technical Specifications:
Parameter Description
Connections RJ45 for ethernet link or single pair UTP.
Input power
requirements
PoE (15W) IEEE 802.3af compliant or
PoE+ (30W) IEEE 802.3at compliant
from Pace1PRM, Pace4PRM, Pace8PRM or Pace16PRM.
Indicators
Yellow (RJ45 connector): On - Link,
Off - No Link,
Blinking - Activity.
Green (RJ45 connector): On - 100Base-TX,
Off - 10Base-T.
Green: PoE Active.
Environmental
Conditions
Operating Ambient Temperature (UL60950-1):
For 15W: – 40ºC to 75ºC (– 40ºF to 167ºF).
For 25W: – 40ºC to 70ºC (– 40ºF to 158ºF).
For 30W: – 40ºC to 60ºC (– 40ºF to 140ºF).
Relative Humidity: 20 to 85%, non-condensing.
Storage Temperature: – 40ºC to 75ºC (– 40ºF to 167ºF).
Operating Altitude: – 304.8 to 2,000m.
Regulatory
Compliance
UL/cUL Listed for Information Technology Equipment (UL 60950-1).
CE European Conformity. C-Tick compliant.
Weights (approx.) Product: 0.22 lb. (0.1 kg) | Shipping: 0.4 lb. (0.18 kg).

Pace1PTM Installation Guide - 3 -
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Single PoE Camera Connection:
Fig. 2 Fig. 2a
Structured Cable
to Midspan/Endspan
Green LED
indicates PoE
Present from
Midspan/Endspan
Green LED
indicates PoE
being transmitted
to Pace1PTM
CAT5 or higher
from Pace1PTM
Single UTP from
Pace1PTM
Structured Cable from
Camera/Device
Green LED
indicates PoE
transmitted to
Camera/Device
Green LED
indicates PoE
received
from Pace1PRM
CAT5 or higher
from Pace receiver
Single UTP
from Pace1PRM
Fig. 1
PoE compliant
100m max.
100m max.
Mounting Hole
PoE Camera
Pace1PTMPace1PRM
I.T.E.43KC
RJ45
Link
Z1409
UTP
Link
RJ45 LEDs Yellow - Activity
Green - Speed
Green LED Power and PoE
PoE
Out
Output
PoE
LED
Input
PoE
LED
www.altronix.com
Transceiver
Passes PoE/PoE+
IP-UTP TRANSCEIVER
RJ45
Link
Output
PoE
LED
Input
PoE
LED
UTP
Link
PoE
Input
I.T.E. 43KC
Z1409
RJ45 LEDs Yellow - Activity
Green - Speed
Green LED Power and PoE
www.altronix.com
IP-UTP Receiver
Passes PoE/PoE+
Pace1PRM - Receiver
Structured Cable
Legend:
PoE+ over CAT5e up to 500m max.
Powered Switch
or NetWay MidSpan

- 4 - Pace1PTM Installation Guide
Pace8PRM - Front Panel
Powered Switch or NetWay MidSpan
100m
max.
500m max.
500m max.
500m max.
500m max.
Pace1PTM
OUT
Ports
1 4
IN
OUT
Ports
5 8
IN
PoE Camera
PoE Camera
PoE Camera
PoE Camera
PoE compliant
100m max.
PoE compliant
100m max.
PoE compliant
100m max.
PoE compliant
100m max.
Pace1PTM
Pace1PTM
Pace1PTM
Pace1PTM
500m max.
500m max.
500m max.
500m max.
PoE Camera
PoE Camera
PoE Camera
PoE Camera
PoE compliant
100m max.
PoE compliant
100m max.
PoE compliant
100m max.
PoE compliant
100m max.
Pace1PTM
Pace1PTM
Pace1PTM
Pace1PTM
Multiple PoE Cameras Connection:
Pace8PRM shown. Pace4PRM and Pace16PRM are similar,
with four (4) and sixteen (16) channels respectively.
Fig. 3
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Maximum Length of Cable Type vs. Camera Power/PoE Class:
Cable Type Total Power
Consumption
Max.
Data Distance
Max.
Power Distance
CAT5e 15W 500m 500m
CAT5e 30W 500m 423m
1 Pair UTP 15W 150m 210m
1 Pair UTP 30W 150m 105m
Note: Calculations based on 56VDC starting voltage from power source and accounts for a 10VDC voltage drop.
IEEE standards voltage range requirement for powered devices are:
PoE (15W) - 37VDC to 57VDC
PoE+ (30W) - 44VDC to 57VDC.
Altronix is not responsible for any typographical errors.
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
