Amano PR600 Series User manual

PR600 Series
Watchman’s Clock
Handling Manual

Proprietary Notice
This document contains proprietary information and such information
may not be reproduced in whole or part without the written permission
from Amano Cincinnati, Inc. 140 Harrison Ave., Roseland, New Jersey
07068.
Amano Cincinnati, Inc. reserves the right to make equipment changes
and improvements, which may not be reflected in this document.
Portions of this document may have been updated to include the latest
hardware or firmware version, if applicable. We recommend that this
document be read in its entirety before any attempt is made to operate
the equipment.
Thank You….
For purchasing another fine product from
Amano Cincinnati, Inc.

PR600 Handling Manual i
Table of Contents
Table of Contents.................................................................i
Introduction.........................................................................3
Accessories.........................................................................3
Features...............................................................................3
Names and Functions of Parts ..........................................4
External View.............................................................................4
Internal View ..............................................................................4
Operation.............................................................................5
1. How to Open the Case (Refer to Fig. 1, 2, 3, & 4).........................5
2. How to Operate (Refer to Fig. 1, & 2). .........................................5
3. How to Install the Roll Paper (Refer to Fig. 5, & 6)........................5
4. How to Install the Roll Paper (Refer to Fig. 3, & 7)........................6
5. How to Adjust the Date (Refer to Fig. 3, & 7)................................6
6. How to Remove the Roll Paper (Refer to Fig. 5, & 6). ...................6
7. Battery Replacement.................................................................7
8. Installation of Station Box & Key (Refer to Fig. 8, & 9)...................7

ii PR600 Handling Manual
！IMPORTANT:To open the case or register the time,
rotate the key only in the direction of the arrow shown on the
surface of the case. Any result caused by reverse rotation of the
key will not be responsible by the manufacturer.

PR600 Handling Manual 3
Introduction
This manual explains how to use your PR600 Watchman’s Time
Recorder.
You are strongly encouraged to read this manual completely before
using the PR600, and to retain it for future reference.
Accessories
The following accessories are provided with the PR600. After unpacking,
please ensure that all of the following items are provided:
• 1 PR600 Watchman’s Time Recorder
• 1 Shoulder Belt
• 1 Master Key
• 1 Battery
• 1 Box of Roll Paper (10 rolls)
Please note that specifications, appearance, and/or description are
subject to change without notice due to product enhancements.
This manual has been carefully prepared, but Amano assumes no
liability for errors and/or omissions. If you should find any errors or
unclear information, please contact your Amano dealer.
Features
The PR600 provides the following:
• Quartz Accuracy.
• No inked ribbon required. Clear imprint with carbonless paper.
• A standard dry cell battery for clock and typewheel operation
with normal operation rated for 6 months.
• Each paper roll is 12m long and provides 2,000 imprints.
• Whenever the PR600 is opened with the (K) master key, the
mark special mark of [O] is printed on the rolled paper.
• Flushing warning light [disappear], indicates battery change
required.
• Compact size: 170 mm Wide x 61 mm Depth x 118 mm High.
• Weight: 800 g

4 PR600 Handling Manual
Names and Functions of Parts
The following describes the names of the various parts of the PR600.
External View
Figure 1. Figure 2.
1. Clock Face
2. Case
3. Key Hole
Internal View
4. Seconds Adjuster
5. Feed Lever (Date)
6. Battery Case
7. Paper Winder
8. Key Hole Guide
9. Roll Paper Guide
10. Time Adjustment
Knob
11. Hook
Fi
g
ure 3.

PR600 Handling Manual 5
Operation
1. How to Open the Case (Refer to Fig.
1, 2, 3, & 4).
• Unfasten the hook [11] of the
case [2], and insert the master (K)
key into the key hole [3]. Turn the
(K) key clockwise to open the
case.
• DO NOT push down, and/or hold
the upper case when turning the
(K) key, or the lock will not be
released.
2. How to Operate (Refer to Fig. 1, & 2).
• Place the battery into the battery case [6], and ensure proper
placement by carefully checking the +/- battery sides.
• Once the battery is inserted, the small lamp on the clock face will
light up indicating the clock is ready for operation.
3. How to Install the Roll Paper (Refer to Fig. 5, & 6).
• Release the roll paper guide [9] as shown in Fig. 5, and install
the roll paper.
• Insert the end of the roll paper into the slot of the paper tape
winder [7] as shown in Fig. 5, and turn the knob counter
clockwise (as shown in Fig. 6) so that the roll paper has suitable
tension.
Fi
g
ure 4.
Fi
g
ure 5. Fi
g
ure 6.

6 PR600 Handling Manual
4. How to Install the Roll Paper (Refer to Fig. 3, & 7).
• Set the clock by turning the
time adjustment knob [10] as
shown in Figure 7 either
clockwise, or counter
clockwise.
• Check the time of the
typewheel by printing on the
roll paper.
• Hold the seconds adjuster (4)
as shown in Figure 7 to stop
the clock from advancing.
Note: Whether it is morning or afternoon,
because the hourwheel will only show 0 – 23. The minutes will
print in two minute increments such as, 00, 02, 04, 06, 08, 10,
12……56, 58, & 60.
5. How to Adjust the Date (Refer to Fig. 3, & 7).
• The date typewheel has been preset to imprint “1”. Press the
feed lever (Date) [5] towards the arrow to advance the date
typewheel to the correct date.
• Ensure the imprinted date is correct by using the master (K) key.
• At the beginning of each month you must adjust the date as date
adjustment is not automatic.
• If required, repeat the same action detailed in Step 3 – How To
Set Roll Paper.
6. How to Remove the Roll Paper (Refer to Fig. 5, & 6).
• Turn the paper winder [7] counter clockwise until the last
registration (imprint) is visible past the paper winder.
• Pull out the paper winder, and cut the paper tape after the last
registration.
• Replace the paper winder [7], pushing down hard to the original
position. The paper winder must be placed in the proper position
to obtain a clear imprint.
Fi
g
ure 7.

PR600 Handling Manual 7
Fi
g
ure 8. Fi
g
ure 9.
• Repeat the same action as detailed in Step 3 – How To Set Roll
Paper.
7. Battery Replacement
• As soon as the lamp on the clock face is no longer visible, the
battery must be replaced with a new one.
• See Fig. 3 for battery case location.
Note: If the PR600 is not going to be used for a long time, the battery
should be removed, and stored separately.
8. Installation of Station Box & Key (Refer to Fig. 8, & 9).
• The last link of the station key chain should be attached with one
of the same screws used to attach the station box.

8 PR600 Handling Manual
NOTES

C-182301 © Copyright 2006 11/06/0
