Amantii TRV SLIM Assembly instructions

Repair Guide
TRV SLIM & TRV XT XL

Content
•How to replace the LED light
•How to replace the flicker motor
•How to replace the heating element
•How to replace the PCB board
•How to replace the signal receiver
•How to replace the canopy light

Replacing the LED light
Unscrew one screw on both sides and then to
remove the front glass.
Step 1
Unscrew the
screw
Replace ember bed LED light

After two screws are removed, the
front glass will fall out.
Front glass

Step 2
Unscrew two screws on both sides and then
to take off two bars and the ember bed glass
panel
Zoomed view

After the screws and fending bars are removed,
you can take off the ember bed glass panel and
one black long steel bar with it.

Step 3
After the ember bed glass panel is removed, now you can replace
the LED light for ember bed effect.(Replace flame light see STEP 4)

Step 4
Zoomed view
Zoomed view
Unscrew 2 screws on the left and right
hand side of the fireplace (where the
arrows marked) to take off the fending
bars. After the bars have been taken out, you
can remove two side glass panels.

Screws and fending bars Side glass panels
After screws and fending bars are removed,
now you can take off the side glass panels.

The front glass fending bar
is located here
Step 5 Unscrew the screws on the left and right sides from
the front glass fending bar to take it off the fireplace

The top light is located
here Unscrew 3 screws then
unplug to take off the
canopy light from the
fireplace.
Step 6

The back glass fending bar locates here
Unscrew the screws
and take off the back
glass fending bar.
(Zoomed picture in the
next page)
Step7

Fending bar
Screws that fix
the fending bar

Back glass Fending bar
Step 8 After fending bar is removed, now you can take
off the back glass panel. You come to here.

Step 9
Unscrew 2 screws each on left and right side to take off the flame
stencil. And you can see the LED strips for flame. Replace those
don’t work.

Replacing the flicker motor
Please follow steps 1 to 2 in Replacing the LED light to arrive here
Motor for the ember bed is located here

The flicker motor for ember bed effect is beneath the ember
bed glass panel.
Step 1
Unscrew the screw and then
disconnect the flicker rod from the
motor
Replacing the flicker motor for ember bed effect
Unscrew the screws to take off the
motor from the fireplace

Please follow steps 1 to 9 from Replacing the LED light
Unscrew 2 screws on left and right side to take off the flame stencil. And you
can see the flame motor.

The flicker motor for flame effect is behind the flame stencil.
Step 1
Unscrew the screw and then
disconnect the flicker rod from the
motor
Unscrew the screws to take off the
motor from the fireplace

Replacing the heating element
Please follow Step 1 in replacing LED light, you come to here
The heating element is located here
