AMC MP 11 User manual

User
Manual
MP 11
Media Player

Table of contents
USER MANUAL MP 11 Media Player
Safety instructions
USER MANUAL MP 11 Media Player
Before you start
Introduction......................................................................................................................................................2
Features................................................................................................................................................................2
Operation
Front/rear panel of MP 11.......................................................................................................................3
Front/rear panel of MP 11 operation...............................................................................................4
Media player operation.............................................................................................................................5
Remote control functions.......................................................................................................................6
Specifications
General specifications................................................................................................................................7
When using this electronic device, basic precautions
should always be taken, including the following:
1 Read all instructions before using the product.
2 Do not use this product near water (e.g., near a bathtub, washbowl,
kitchen sink, in a wet basement or near a swimming pool etc).
3 Use this device when you are sure that amplifier has a stable base and
it is fixed securely.
4This product, in combination with loudspeakers and amplifier may be
capable of producing sound levels that could cause permanent hearing
loss. Do not operate for a long period of time at a high volume level or at
a level that is uncomfortable. If you experience any hearing loss or ringing
in the ears, you should consult with otorhinolaryngologists.
5 The product should be located away from heat sources such as radiators,
heat vents, or other devices that produce heat.
6 The product should be connected to a power supply that is described
in the operating instructions or are marked on the product.
7The power supply should be undamaged and never share an outlet
or extension cord with other devices. Never leave device plugged
into the outlet when it is not being used for a long period of time.
8Care should be taken that objects do not fall into liquids and liquids
would not be spilled on the device.
9The product should be serviced by qualified service personnel if:
– The power supply or the plug has been damaged.
– Objects have fallen into or liquid has been spilled on the product.
– The product has been exposed tor rain.
– The product has been dropped or the enclosure damaged.
10 There are some areas with high voltage inside, to reduce the risk of electric
shock do not remove cover of the microphone receiver or power supply.
The cover should be removed by the qualified personnel only.

USER MANUAL MP 11 Media PlayerUSER MANUAL MP 11 Media Player
Before you start
02
MP 11 is a media player with FM and Bluetooth audio receivers. Plays audio files from SD card and
USB drive. Volume and tone control. Mic input available for paging, providing gain and tone control,
phantom power and signal priority. External audio sources can be connected using stereo line input
or 3,5 mm TRS AUX input on the front panel.
FEATURES
• Compressed audio playback
• Supports up to 32 GB USB flash and SD cards
• Media player with SD/USB reader, FM radio and
Bluetooth audio interface
• IR remote control
03
1. XLR input for paging microphone |2. Priority and phantom power dip-switches |3. Microphone tone controls |4. Microphone gain
5. Stereo RCA inputs |6. Stereo RCA outputs |7. Stereo balanced Phoenix outputs |8. FM antenna connector |9. Mains power connector
Front Panel | MP 11
Rear Panel | MP 11
1. Power switch |2. Track skip buttons |3. Play/Pause |4. Media player mode |5. AUX input |6. Output source selector
7. Output volume control |8. Output tone controls
Operation
• RCA stereo line input
• 3.5 mm plug AUX input
• Balanced stereo Phoenix output
• Stereo RCA AUX input
3 2 4 5 7 82 61
1 3 4 5 6 7 9
8
2

USER MANUAL MP 11 Media PlayerUSER MANUAL MP 11 Media Player
Front panel
POWER SWITCH
Switch MP 11 power ON / OFF.
SD / USB SLOTS
Media player supports up to 32 GB flash storage.
LED SCREEN
LED screen displays main information about media player status:
track number and playing time, media player volume level.
PLAY/PAUSE
Start or pause player.
TRACK SKIP BUTTONS
Short press of track skip buttons will change currently playing track to previous
or next track. Long press will adjust media player volume.
MODE
Change media player source between SD / USB / FM radio / Bluetooth.
INPUT SELECTOR
Select audio source for output.
AUX INPUT
3.5 mm jack connector for external audio source.
VOLUME CONTROL
Rotary knob for adjusting output level.
Operation
BASS & TREBLE TONE CONTROLS
Tone controls provide attenuation of bass and treble response. The flat position
is obtained when the knobs are set to the middle. Turn the knob clockwise to
raise tone level +12 dB; turn counter-clockwise to lower tone level by -12 dB
Rear panel functions
PAGING MICROPHONE INPUT
XLR connector for paging microphone.
PRIORITY AND PHANTOM POWER SWITCH
Set paging microphone input priority for output. When using condenser
microphones, switch ON phantom power.
MICROPHONE GAIN AND TONE CONTROLS
Adjust paging microphone sensitivity, bass and treble response.
OUTPUT CONNECTORS
Balanced Phoenix connectors in parallel to stereo RCA for connecting MP 11 to
the amplifier.
LINE INPUTS
Stereo RCA connector for external sound sources.
FM ANTENNA
FM radio antenna connector.
MAINS POWER INPUT
Connect device to mains power supply using provided power cable.
04 05
Media Player Operation
FM RADIO
AUTO-SEARCH RADIO STATIONS
Press PLAY button on front panel to automatically search all available radio
stations. Stations are stored in presets.
NAVIGATING PRESETS
After auto-search, press track skip buttons on the front panel to navigate
between stored station presets. Remote control numeric keypad also can be
used to navigate stored presets.
MANUALLY STORE RADIO STATION PRESET
Short press play button - LCD screen now blinks FM frequency.
Enter FM frequency using numeric keypad or track skip buttons.
Press play to confirm frequency - LCD screen now blinks FM preset number.
Choose new preset number using numeric keypad or track skip buttons.
Press play button to confirm and save.
SD / USB PLAYER
PLAYING MEDIA FROM SD / USB
Press PLAY button to play or pause player.
Press track skip buttons to select next or previous track.
Press REP button on the remote to repeat ONE track, or ALL tracks.
BLUETOOTH
PAIRING
In Bluetooth mode, MP 11 becomes ready to pair with another devices. When
no device is connected, screen blinks word BLUE. Search for "AMC Player" on
your device. When connected, screen stops blinking and confirmation sound
is played. Next time MP 11 will automatically connect to your device when
Bluetooth mode is selected.
UNPAIRING
Press and hold PLAY button on the front panel for a player that needs to be
unpaired from Bluetooth device.
CONTROL
Use track skip and PLAY buttons to select track and start/pause playing on
your connected Bluetooth device. This function may not work on every device
1
2
3
MP 11

USER MANUAL MP 11 Media PlayerUSER MANUAL MP 11 Media Player
Operation
1. Media player power ON / OFF | 2. Player mode select | 3. Equalizer | 4. Player volume up | 5. Play / pause | 6. Track skip backward button | 7. Player
volume down | 8. Repeat button | 9. Numeric keypad | 10. Mute player | 11. Track skip forward button | 12. USB/SD card mode
1. Open the battery cover on the back of the remote control.
2. Insert two AAA batteries as marked inside the remote
control battery compartment.
3. Close the battery cove.
Remote control
Changing batteries
MODE
1
4
7
2
5
8
0
3
6
9
EQ
REP U/SD
VOL+
VOL+
1
2
3 10
11
12
4
5
6
7
8
9
General Specifications
MP 11
Power consumption 10 W
Power supply 115 V or 230 V, 50/60 Hz
Output level Balanced Phoenix: 6 dBu
Unbalanced RCA: 0 dBu
Microphone input Sensitivity: 56 dBu, impedance: 600 Ω
Line input Sensitivity: 0 dBu, impedance: 4,7 kΩ
Aux input Sensitivity: 0 dBu, impedance: 4,7 kΩ
Phantom power +48 V
Media player Radio station memory: 32 stations
Max. USB flash or SD card size: 32 GB
Antennas FM antenna: monopole BNC connector,
Bluetooth antenna: internal, working distance > 10 m
Frequency response 20 Hz – 20 kHz
THD 0.10 %
Tone control Bass: 100 Hz ±12 dB; Treble: 10 kHz ±12 dB
Remote control IR remote
Dimensions 483 mm × 103 mm × 44 mm
Weight 1.7 kg
The specifications are correct at the time of printing
this manual. For improvement purposes, all specifications
for this unit, including design and appearance, are
subject to change without prior notice.
