American Dryer Corp. SL31 User manual

SL31 Parts Manual
Phase 8
ADC Part No. 450282-5
American Dryer Corporation
88CurrantRoad
FallRiver, MA02720-4781
Telephone:[phone] / Fax: [phone]
E-mail:[e-mail]
www.amdry.com

Retain This Manual
In A Safe Place For Future Reference
This product embodies advanced concepts in
engineering, design, and safety. If this product
is properly maintained, it will provide many years
of safe, efficient, and trouble free operation.
ONLYproperlylicensedtechniciansshouldservicethisequipment.
OBSERVEALLSAFETYPRECAUTIONSdisplayedontheequipment
orspecifiedinthe installationmanualincludedwiththedryer.
Thefollowing“FORYOURSAFETY”cautionmustbeposted
nearthedryer ina prominentlocation.
Wehavetriedtomakethismanualascompleteas possible and hope you will find
ituseful. Themanufacturerreservestherighttomakechangesfromtimetotime,
without notice or obligation, in prices, specifications, colors, and material, and to
changeordiscontinuemodels.
Important
For your convenience, log the following information:
DATE OF PURCHASE _____________________________________________________ MODEL NO. _____________
RESELLER’S NAME _________________________________________________________________________________
Serial Number(s)___________________________________________________________________________________
___________________________________________________________________________________________________
___________________________________________________________________________________________________
POURVOTRESÉCURITÉ
Ne pas entreposer ni utiliser d’essence
nid’autresvapeursouliquides
inflammablesàproximité de cet
appareiloudetout autre appareil.
FORYOURSAFETY
Do not store or use gasoline
orotherflammablevapors
andliquidsinthevicinityof
thisoranyotherappliance.
SL31

NOTES _______________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
Replacement parts can be obtained from your reseller
or the ADC factory. When ordering replacement parts from
the factory, you can FAX your order to ADC at [phone]
or telephone your order directly to the ADC Parts Department
at [phone]. Please specify the dryer model number
and serial number in addition to the description and part number,
so that your order is processed accurately and promptly.
The illustrations on the following pages may not depict
your particular dryer exactly. The illustrations are a composite
of the various dryer models. Be sure to check the
descriptions of the parts thoroughly before ordering.
“IMPORTANT NOTE TO PURCHASER”
Information must be obtained from your local gas supplier
on the instructions to be followed if the user smells gas.
These instructions must be posted in a prominent location
near the dryer.

4 American Dryer Corporation 450282-5
Parts Diagram
Illus.No. PartNo. Qty.Description
1 818925 1 BackGuardAssembly(GasandElectric)(For models mfd. as of December 7, 2005)
818683 1 BackGuardAssembly(GasandElectric)(Formodelsmfd.priortoDecember7,2005)
819622 1 BackGuardAssembly(Steam)
2 819619 1 Left Side PanelAssembly (For models mfd. as of December 7, 2005)
818679 1 Left Side PanelAssembly (For models mfd. prior to December 7, 2005)
3 819621 1 RightSidePanelAssembly(For models mfd. as of December 7,2005)
818678 1 RightSidePanelAssembly(For models mfd. prior toDecember7,2005)
4 818690 1 OuterTop PanelAssembly
5 150445 2 1/4-20 x 3/4” Bolt
6 153072 2 SpringWasher
7 318891 1 BackupWasher
8 153048 1 InnerFrictionPad(Gasand Electric)
102373 1 InnerFriction Pad(Steam)

450282-5 www.amdry.com 5
Parts List
Illus.No. PartNo. Qty.Description
9 818110 1 FrontRight/RearLeftWheel
818109 1 FrontLeft/RearRightWheel
10 819288 1 LintScreenAssembly(Painted)
819315 1 LintScreenAssembly(StainlessSteel)
11 819849 1 TumblerAssembly(Galvanized)(Formodelsmfd.asof March 12, 2008)
818815 1 TumblerAssembly(Galvanized)(Formodelsmfd.priortoMarch12,2008)
819850 1 TumblerAssembly(Stainless Steel)(For models mfd. as of July 18, 2008)
819398 1 TumblerAssembly(StainlessSteel) (For models mfd. prior to July 18, 2008)
12 102407 1 Belt
13 819627 1 FrontPanelAssemblyRightHinge(Coin)
819361 1 FrontPanelAssembly RightHinge(Non-Coin)60 Hz
818995 1 FrontPanelAssembly RightHinge(Non-Coin)50 Hz
102004 2 Magnet
102005 2 MagnetBlank
152224 4 MagnetScrew
400563 1 MagnetRemovalBit
14 819301 1 DoorAssemblyRight Hinge(White)
819388 1 DoorAssemblyRight Hinge(StainlessSteel)
819700 1 DoorAssemblyLeft Hinge (White)
819387 1 DoorAssemblyLeftHinge(Stainless Steel)
103067 2 DoorHinge
15 170233 1 Handle
16 819194 1 RotationSensorAssembly
17 819511 1 Phase8ControlDoorAssembly (25¢ Coin)
819633 1 Phase8Control DoorAssembly(Programmable– Euro)
819507 1 Phase8Control DoorAssembly(Non-Coin)
18 185097 1 Toe Panel(White)
185048 1 Toe Panel(StainlessSteel)
19 887215 1 1/4 hp Motor with Sheave – 60 Hz (For models mfd. with a 3 rib tumbler)
884288 1 1/4 hp Motor with Sheave – 60 Hz (For models mfd. with a 4 rib tumbler)
887030 1 1/4hp Motor with Sheave – 50Hz (For models mfd. as ofSeptember1, 2005)
818485 1 MotorAssembly(For models mfd. prior to September 1, 2005)
20 152004 2 5/16-18HexNut
21 153002 2 5/16”Split Lock Washer
22 153018 2 1/4”FlatWasher
23 154266 2 3/8” x 3/8” (5/16-18) Screw
24 319933 1 MotorSheave – 60 Hz (For modelsmfd.with3 rib tumblers)
318909 1 Motor Sheave – 60 Hz (For models with with 4 rib tumbler)
185067 1 MotorSheave–50Hz
25 152011 1 1/2-13HexNut
152028 1 1/2-13NylonInsertLocknut
26 153011 1 9/16”ID,1-3/8”OD Flat Washer
27 150609 1 1/2-13x 4-1/2”Tap Bolt
28 818213 1 CoinAcceptor(25¢ Coin)
819264 1 CoinAcceptor (Programmable–Euro)
29 112587 1 Keypad(Coin)
112586 1 Keypad(Non-Coin)
30 160140 1 Key
31 160071 1 Lock(For models mfd. as of February28, 2007)
160038 1 Lock(For models mfd. prior to February 28, 2007)
32 121530 1 ComputerSupport Cable
33 350250 1 Phase8Control Cover
34 887102 1 Phase8Computer(Formodelsmfd.withoutthe “S.A.F.E.System”)
887103 1 Phase8Computer(Formodelsmfd.withthe“S.A.F.E. System”)
136116 1 3-ampFuse
136054 1 15-ampFuse
35 819196 1 Door SwitchAssembly
36 121350 1 ComputerSupport Cable
37 122200 1 ProgramSwitch (For models mfd. prior to February 28, 2007)
38 154004 1 TwinSpeed Nut (For models mfd.priortoFebruary28,2007)
39 160066 1 1-1/8”LongCam(For models mfd. prior to February 28, 2007)
40 102396 1 DoorGasket
41 125916 1 Coin BoxAssembly with 2 Keys
42 131819 1 ReversingContactor
43 154061 8 U-NutRetainer
44 183129 8 T-20TrussHeadMachineScrew

6 American Dryer Corporation 450282-5
Parts Diagram

450282-5 www.amdry.com 7
Parts List
Illus.No. PartNo. Qty.Description
1 825569 1 LintBox / BlowerAssemblyComplete 120V 60 Hz (For models mfd. asofSeptember1, 2006)
819193 1 LintBox/ BlowerAssemblyComplete120V60Hz (For models mfd. prior to September 1, 2006)
822356 1 LintBox / BlowerAssembly Complete 200-240V 60Hz(For models mfd. as of June 14,2006)
819233 1 LintBox / BlowerAssemblyComplete200-240V 60 Hz (For models mfd. prior to June14,2006)
819233 1 LintBox/ BlowerAssemblyComplete200-240V50 Hz
(Formodels mfd. prior to June 14, 2006 andasofDecember 20, 2006)
819193 1 Lint Box / BlowerAssembly Complete 208-240V 50 Hz with Transformer
(Formodelsmfd.between October 25, 2006 and December 20, 2006)
822356 1 LintBox/ BlowerAssemblyComplete200-240V50 Hz
(Formodels mfd. between June 14, 2006 andOctober24,2006)
2 851242 1 BlowerMotorAssembly120V60 Hz (For models mfd. as ofSeptember1, 2006)
819185 1 BlowerMotorAssembly120V60Hz (For models mfd. prior to September 1,2006)
851243 1 Blower MotorAssembly 200-240V 60 Hz (For models mfd. as of July 14, 2006)
819232 1 BlowerMotorAssembly200-240V60 Hz (For models mfd. prior toJune14, 2006)
819232 1 BlowerMotorAssembly200-240V50Hz
(Formodels mfd. prior to June 14, 2006 andasofDecember 21, 2006)
819185 1 Blower MotorAssembly 200-240V 50 Hz with Transformer
(Formodelsmfd.between October 25, 2006 and December 20, 2006)
851243 1 BlowerMotorAssembly200-240V50Hz
(Formodels mfd. between June 14, 2006 andOctober24,2006)
3 100618 1 20 MFD Capacitor 120V (For models mfd. as of September 1, 2006)
100639 1 32 MFD Capacitor 120V (For models mfd. priortoSeptember1,2006)
100638 1 8 MFDCapacitor200-240V
(Formodels mfd. prior to June 14, 2006 andasofDecember 21, 2006)
100670 1 5 MFDCapacitor200-240V
(Formodels mfd. between June 14, 2006 andOctober24,2006)
100639 1 32 MFD Capacitor 200-240V with Transformer
(Formodelsmfd.between October 25, 2006 and December 20, 2006)
4 130119 1 L190AutomaticThermostat
5 185084 1 BlowerHousingFormedwithBackDraftDamper
818545 1 BlowerHousingMadeIn-House
6 830333 1 ExhaustTemperature SensorAssembly(For models mfd. as of February 19, 2008)
818986 1 ExhaustTemperature SensorAssembly(Formodelsmfd.priortoFebruary19, 2008)
7 122003 1 Lint Drawer Switch
8 318993 1 RearElectricalBox (Gas and Steam)
319327 1 RearElectricalBox(Electric)
318727 1 RearElectricalBoxCover
9 121010 1 TerminalLug
10 153021 1 1/4”Shakeproof Washer
11 152002 1 1/4-20HexNut
12 819188 1 AxialTemperatureSensorAssembly
13 819648 1 SplitPhase RelayAssembly
131818 1 25-amp240VRelay
136054 2 15-ampSlo-BloFuse
136008 2 FuseHolder
14 120728 1 Quick-ConnectTerminalBlock(ForGas andSteamModels)
120699 2 TerminalBlock (ForElectricModels)
120698 2 TerminalBlock Insulator(ForElectricModels)
15 153073 2 #8-32KEPSNut
16 122200 2 SailSwitch
17 150025 2 #4-40 x 1” Phillips Screw
18 154004 1 TwinSpeed Nut
19 153073 14 #8-32KEPSNut
20 819113 1 Heat Duct with Sail SwitchAssembly
21 818109 1 FrontLeft / Rear Right Wheel (Parts Breakdown onpage10)
22 818110 1 Front Right / Rear Left Wheel (Parts Breakdownonpage10)

8 American Dryer Corporation 450282-5
Parts Diagram

450282-5 www.amdry.com 9
Parts List
Illus.No. PartNo. Qty.Description
1 819314 1 BurnerAssembly
819313 1 BurnerChamber
2 183112 1 Thermostat,Gas High-Limit
3 183144 1 InshotBurnerTube,HotSurface Ignition
4 128944 1 Gas Valve 120 VAC 60 Hz
128907 1 Gas Valve 120 VAC 50 Hz
884254 1 LiquidPropaneConversion Kit
5 141318 1 3/8” 90º Union Shutoff
6 140880 1 NaturalGas#22Burner Orifice
140905 1 LiquidPropaneGas#44BurnerOrifice
7 128910 1 Globar®
8 183145 1 #8-32 x 7/8” Hex Screw with Washer
9 130500 1 RadiantControl
10 185096 1 3/8”N.P.T. Male 90ºGasPipe
142953 1 1/2”x3/8”N.P.T. Reducer … Not Illustrated
142954 1 3/8”B.S.P.T. Coupling …NotIllustrated
11 819579 1 SteamValveAssembly120V
819545 1 SteamValveAssembly208-240V
12 165066 1 CopperSteamCoil
13 183112 1 High-LimitThermostat
14 119995 1 ElectricElement
15 819712 1 120V to 24V Transformer
819251 1 208V to 24V Transformer
819267 1 240V to 24V Transformer
132029 1 208-240V to 120V Transformer
16 131352 1 40-amp24VContactor
131357 1 50-amp24VContactor
131321 1 30-amp120VContactor
131325 1 50-amp120VContactor
131324 1 40-amp208-240VContactor
131328 1 60-amp208-240VContactor

10 American Dryer Corporation 450282-5
S.A.F.E. System Assembly Parts Diagram / List
Illus.No. PartNo. Qty.Description
1 143025 1 3/8”x 3/4” NHAdaptor
(ForU.S.and Canada)
143177 1 3/8”x 3/4” B.S.P.T.Adaptor
(ForEuro.Countries)
2 136987 1 Pressure Switch
3 143251 1 3/8”Plug
4 143182 1 BrassTee
5 319231 1 SupportBracket
6 165120 1 WaterValve
7 143099 1 3/8”ODCopper Tubing
8 143208 1 3/8” Brass Connector
9 318422 1 S.A.F.E. Bracket
10 143581 1 Spray Nozzle
Illus.No. PartNo. Qty.Description
1 150510 3 1/4-20x3/4”HexHeadMachineBolt
2 153007 3 1/4”Lock Washer
3 154267 1 M10x25mmShoulderScrew
4 153002 1 5/6”Lock Washer
5 154013 1 M8HexNut
6 154284 1 TumblerWheel Spacer
7 318233 1 RearRightRoller WheelBracket
318232 1 RearLeftRollerWheelBracket… Not Illustrated
318532 1 FrontRightRoller Wheel Bracket…NotIllustrated
318531 1 FrontLeftRollerWheelBracket… Not Illustrated
8 153564 3 1/4-20ClinchNut
9 153018 3 1/4”FlatWasher
10 180050 1 Wheel
Wheel Assembly Parts Diagram / List

450282-5 www.amdry.com 11
Pedestal Assembly Parts Diagram / List
Illus.No. PartNo. Qty.Description
——— 185384* 2 11”StackablePedestalAssembly
Bottom pedestal shown. Duplicate parts for top assembly.
Illus.No. PartNo. Qty.Description
1 150331 4 #8-18x1/2”PanHead TORX Screw
2 150617 4 3/8”-16x1”HexHeadMachineBolt
3 153004 4 3/8”x1”O.D. Flat Washer
4 153005 4 3/8”Split Lock Washer
5 154200 10 5/32”PopRivet
6 319598* 1 11” PedestalBack
7 319599* 1 PedestalInner Support
8 319600* 1 11”Pedestal Front
9 319601* 1 11” PedestalLeftSide
10 310602* 1 11”PedestalRightSide
11 851416* 1 PedestalBase
12 103500 4 LevelingLeg(LowerPedestal Only)
* Specify color when ordering.

ADC Part No. 450282 5 - 08/19/08 - 0
