AD1301
In-Ceiling CameraHousing
Installation Instructions
Contents- CameraHousing,Allen Wrench,and114x 20screwfor cameramount
TheTamperResistant,In-Ceiling CameraHousinghasfour 7/8-inchelectricalknock-outs.Twoknwk-out holesarelocaledoneach
endof thebox.
General Inform&inn
Locating and Mounting of Housing
1. Selectanappropriatelocation. Makesurenoobstructionsor obstaclesexistabovetheceiling,i.e.,joists, wiring, pipes,etc.
2. Measuretheceilingareafor thehousingorplacethehousingontheceilingandtracearoundit for cutout sizeandlocation.
3. Slip thehousinginto thecutoutwith thecoverof thehousingopen.
4. Mark themountingholescmtheceiling.
5. Removethehousinganddrill (orpunchout)theappropriateholesin theceiling.
Thehousingcanbelocatedwithin two typesof ceilings suspendedor permanent.Seerelatedinformationbelow.
Oncethehousingis locatedin theceiling:
6. Besureall mountinghardwareistight.
7. Install thecameraon thehousingcradle.
8. Closethecoyertocheckfor lensclearancetothefmnt window - adjusttoapproximatelyl/4-inch.
9. Makefuxd viewingadjustments.
10. Closeandsecurethecoverwith l/4-20 tamperproof screwssuppliedwith thehousing.
SuspendedCeilings
1. TheT-barceilingrail kit mustbeusedwheninstallingthishousingwithin asuspendedceiling.
2. Slip thehousingboxthroughtheholein theceiling tile.
3. Attachtherailstothehousingusingtheten32x2-inchscrewssuppliedwith therail kit. Therails shouldreston top of theceiling
grid rail.
Note: Therailscanbepositionedacrossthefront or alongthesideof thehousing.
Additional Support
Therearetwo additionalholesin theendof therails which canbeusedtoattachwiresor chainstothejoists or
ceiling abovethehousiig.
4. Electricalandvideocablemaynowbeinstalled.

PermaacntCeiIImgs(ceilingsthatarenotaccessiblefrombehindor above)
1. Electricalandvideocablemustbepulledthroughtheholein theceilingandattachedtotbehousingbeforethehousingcanbe
installedintotheceiling.
2. Attachtbehousingtoashuctual memberoftheceiling,or supplyadditionalsupport.
3. UsethefulluwiaghrudwaredependtngMItbetypeofceibngandbacksupportmembers- #lOOT#12woodscrews,togglebolts.
ormouyboIt.9.
CantIon-Caremustbetakenwheninstallingtbehousingintotbccutwt bolein theceiling. Besarenottopinch
or snagthecable.Besurecableisdearof allinstallationhardware.
No*: TheseimtaIIationinst~ctionsareintendedonlyasarecommendationtoqualifiedpersonnelinstatltngthishousing.Usethese
installationinstructionsasaguideline.Theseiastmctionsarenottobeconstruedastbeonlymeansof installationthatcanhe
used.It isrecommendedthattbeparchasexof this@act contactlocalgovernmentalauthoritiesandbecognilantof local
regulationsregardingsafety,electrical,a st~cturairequirements.
To Ckan theHooniug
Tk housingandwindowshouldbecleanedwithplainsoapandwaterandasoftcloth.
Neverc.leaatbewindowwith abrasivecleanasthatwill scratchthewindow.
Neverwipetbewindowwith adryclothorpapertowels.
Front View Side View Bottom View
OPlMlA
January1994 PrintedinUSA
