American Dynamics ADSDUPIHC User manual

•Reinforced high impact
design
•Vandal resistant option
•Compact, attractive design
•Four tamper-proof screws
with driver bit supplied
•Ceiling, pole, roof, wall and
corner mounts available
FEATURES
SpeedDome®Ultra
INDOOR DOME HOUSING
The SpeedDome Ultra indoor dome housing allows
the SpeedDome Ultra dome to be installed indoors
using the same design as found in the SpeedDome
Ultra outdoor housing. It is available in standard and
vandal resistant options.
The housing is made of a reinforced fiberglass high
impact polycarbonate material along with a UV
stabilized trim ring and top cover. The bubble
assembly is affixed to the top via tamper-proof screws.
For applications where vandalism is a concern, a
vandal resistant model is available which includes an
aluminum sunshield cover and a high impact bubble
which meets ANSI-87.1 impact safety standards. For
additional protection a stainless steel bubble cage is
provided.
Simply add an interface board, plug in the video
cable, connect power and data, and install any
SpeedDome Ultra. Diagnostic power and
communications LEDs confirm proper connection
and aid in troubleshooting. A variety of mounts
accommodate the housing, making it easy to install.
The housing supports both the RUPTB and RUIOB
dome bases (not included) and is supplied with either
a choice of a clear or smoked bubble.
www.americandynamics.net
ADSDUPIVRC
Vandal Resistant Indoor
Dome Housing
ADSDUPIHC
Indoor Dome Housing

AMERICAN DYNAMICS SPEEDDOME®ULTRA INDOOR DOME HOUSING
Product specifications and availability subject to
change witout notice.
Certain product names mentioned herein may be trade
names and/or registered trademarks of other companies.
Tyco Fire & Security Video Systems
6795 Flanders Drive, San Diego, CA 92121 USA
www.tycovideo.com
VS335-01 08/03 L
©2003 Sensormatic Electronics Corporation
Product specifications and availability subject to
change without notice.
Certain product names mentioned herein may be trade
names and/or registered trademarks of other companies.
Model Numbers
ADSDUPIHC . . . . . . . . . . . . . . . . .Indoor Ultra Housing with clear bubble
(f0)
ADSDUPIHS . . . . . . . . . . . . . . . . .Indoor Ultra Housing with smoked bubble
(f1.0)
ADSDUPIVRC . . . . . . . . . . . . . . . .Vandal Resistant Indoor Ultra Housing
with high-impact clear bubble (f0)
ADSDUPIVRS . . . . . . . . . . . . . . . .Vandal Resistant Indoor Ultra Housing
with high-impact smoked bubble (f1.0)
Mechanical
ADSDUPIHC, ADSDUPIHS
Construction
Enclosure . . . . . . . . . . . . . . . . . . .Aluminum
Sun Shade, Trim Ring,
Top Cover . . . . . . . . . . . . . . . . . .UV stabilized polycarbonate
Color . . . . . . . . . . . . . . . . . . . . . . . .Light gray
Height . . . . . . . . . . . . . . . . . . . . . . .321 mm (12.64 in)
Diameter . . . . . . . . . . . . . . . . . . . . .244 mm (9.61 in)
Bubble . . . . . . . . . . . . . . . . . . . . . . .Acrylic
Bubble Diameter . . . . . . . . . . . . . .75.3 mm (6.93 in)
Weight
Without Dome . . . . . . . . . . . . . .1.6 kg (3.50 lbs)
With Dome . . . . . . . . . . . . . . . . . .2.8 kg (6.20 lbs)
Shipping Weight of Housing . . .3.3 kg (7.30 lbs)
Mechanical Connection . . . . . . .1.5 in NPT
ADSDUPIVRL, ADSDUPIVRS
Construction
Enclosure . . . . . . . . . . . . . . . . . . .Aluminum
Sun Shade, Trim Ring,
Top Cover . . . . . . . . . . . . . . . . . .UV stabilized, polycarbonate
Sun Shade Cover . . . . . . . . . . . . .Aluminum with high gloss power coating
Color . . . . . . . . . . . . . . . . . . . . . . . .Light gray
Height . . . . . . . . . . . . . . . . . . . . . . .321 mm (12.64 in)
Diameter . . . . . . . . . . . . . . . . . . . . .244 mm (9.61 in)
Bubble . . . . . . . . . . . . . . . . . . . . . . .High impact acrylic
Bubble Diameter . . . . . . . . . . . . .75.3 mm (6.93 in)
Bubble Cage . . . . . . . . . . . . . . . . . .Stainless steel, painted flat black
Height . . . . . . . . . . . . . . . . . . . . . . .87.7 mm
Width . . . . . . . . . . . . . . . . . . . . . . . .212 mm
Weight
Without Dome . . . . . . . . . . . . . .2.30 kg (5.10 lbs)
With Dome . . . . . . . . . . . . . . . . . .3.50 kg (7.70 lbs)
Shipping Weight of Housing . . .4.00 kg (8.80 lbs)
Mechanical Connection . . . . . . .1.5 inch NPT
Environmental
Operating Temperature . . . . . . . .10° to 50° C (16° to 122° F)
Humidity . . . . . . . . . . . . . . . . . . . . .0 to 95% RH (non-condensing)
Storage Temperature . . . . . . . . . .20° to 65° C (-4° to 149° F)
SPECIFICATIONS
Mounts and Adapters
RHOSW
Indoor/outdoor
short wall mount
with end cap assembly
RHOWPA
Indoor/outdoor pole
strap adapter for
RHOSW and
RHOLW
RHOTR
Outdoor over-the-roof
mount with end cap
assembly
ROENDC
Indoor/outdoor
end cap assembly
adapter
RHIUIB
Indoor I-beam
clamp
RHOLW
Indoor/outdoor
long wall mount
with end cap
assembly
RHOWCA
Indoor/outdoor corner
bracket adapter for
RHOSW and
RHOLW
RHOPN
Indoor/outdoor
pendant mount
ROTRF
Outdoor floor adapter
for RHOTR
ROTRF
