American Dynamics SpeedDome Optima User manual

www.americandynamics.net
FEATURES
The SpeedDome Optima Fixed Drone Housing
provides customers with a value driven in-ceiling
alternative to the conventional dome products.
The tilt table camera mounts are designed to
accommodate most camera and lens
combinations. The top hat is quick and easy to
install and can be used in a variety of indoor
applications.
The SpeedDome Optima Fixed Drone Housing
has a plenum-rated back box which can be
installed in a hard ceiling or standard 61 x 61 cm
(2 x 2 ft) suspended ceiling.
This in-ceiling drone cosmetically matches our
programmable SpeedDome Optima and can be
integrated in an existing Optima installation for
overall aesthetic continuity.
SpeedDome®Optima
Fixed Drone Housing
•Easy installation
•All metal back box
construction
•Suitable for installation
in open plenum ceilings
•Compact, attractive
design
•Identical in appearance
to the SpeedDome
Optima
•Provides fixed camera
capability with
appearance of a
programmable dome
•Powerful visual deterrent
•Comes with long and
short camera mounting
brackets

AMERICAN DYNAMICS SPEEDDOME OPTIMA FIXED DRONE HOUSING
VS258-02 01/03 A4
©2003 Sensormatic Electronics Corporation
Product specifications and availability subject to
change without notice.
Certain product names mentioned herein may be trade
names and/or registered trademarks of other companies.
SPECIFICATIONS
Model Number
RHOPTDOME . . . . . . . . . . . . . . .SpeedDome Optima Top Hat with smoked
optical grade bubble
Mechanical
Housing . . . . . . . . . . . . . . . . . . . . . .Black anodized aluminum
Dimensions (H x D)
Total . . . . . . . . . . . . . . . . . . . . . .252.9 x 245 mm
(9.96 x 9.65 in)
Above Ceiling . . . . . . . . . . . . . .158 x 187.6 mm
(6.23 x 7.39 in)
Below Ceiling . . . . . . . . . . . . . . .94.9 x 245 mm
(3.74 x 9.65 in)
Weight . . . . . . . . . . . . . . . . . . . . . . .1.32 kg (2.90 lbs)
Bubble . . . . . . . . . . . . . . . . . . . . . . .Smoked acrylic optical grade
Maximum Camera/Lens Size
Dimensions (H x W x D) . . . . .165 x 51 x 64 mm
(6.5 x 2 x 2.5 in)
Environmental
Indoor Use Only
Operating Temperature . . . . . . . .0° to 50° C (32° to 122° F)
Regulatory
Safety . . . . . . . . . . . . . . . . . . . . . . . .UL and cUL1950
Mounting Accessories
RH2X2 . . . . . . . . . . . . . . . . . . . . . . .2 x 2 ft ceiling mounting plate
Compatibilty Chart
Fixed Drone Camera Housing
Optical Grade Bubble
Housing
Lens
L2616CS
L0412NI
L0812NI
L0412CS
L0812CS
L35814CS
LD2616CS
LD0412CS
LD0812CS
LD35814CS
Description
1/3 in, 2.6 mm, MI, F1.6
1/3 in, 4 mm, FI, F1.2
1/3 in, 8 mm, FI, F1.2
1/3 in, 4 mm, MI, F1.2
1/3 in, 8 mm, MI, F1.2
1/3 in, 3.5 - 8 mm, MI, F1.4
1/3 in, 2.6 mm, DC, F1.6
1/3 in, 4 mm, DC, F1.2
1/3 in, 8 mm, DC, F1.2
1/3 in, 3.5 - 8 mm, DC, F1.4
ADC710 or
ADC710X
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
ADC732 or
ADC732X
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
ADC762 or
ADC762X
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Cameras
