SPEEDDOME ULTRA INDOOR HOUSING AND INDOOR VANDAL-RESISTANT HOUSING 8200-0184-07, REV. B
INSTALLATION GUIDE 1 of 4
SpeedDome®Ultra Indoor
Housing and Indoor Vandal-
Resistant Housing
Installation Guide
Models: ADSDUPIHC. ADSDUPIHS,
ADSDUPVRC, ADSDUPVRS
For Indoor Use Only!
Figure 1. SpeedDome Ultra housings
About this Guide
This guide explains how to prepare the indoor
housing for installation to a mounting structure and
assumes that the mounting structure is in place
and that data and power cables have been pulled
to the installation site.
This guide does not explain:
- Cable requirements,
- Camera installation, or
- How to install the mounting structure.
For this information, see instructions shipped with
the camera dome or mounting structure.
About the Indoor Housing
The indoor housing (Figure 1) is used to attach the
SpeedDome Ultra camera dome to an indoor
mounting structure. This housing can attach to
mounting structures shown in Table 1.
© 2005 Sensormatic Electronics Corp.
Table 1. Indoor mounting Structures
RHOPN
Pendant Mount
RHIUIBM
I-Beam Mount
RHOSW/RHOLW
Short/Long
Wall Mount
RHOWCA
Corner Mount
RHOWPA
Pole Mount
ROENDC
End Cap
If You Need Assistance…
Contact your sales representative.
Indoor Housing Indoor Vandal-
Resistant Housing

SPEEDDOME ULTRA INDOOR HOUSING AND INDOOR VANDAL-RESISTANT HOUSING 8200-0184-07, REV. B
INSTALLATION GUIDE 2 of 4
Warnings and Cautions
Please review the following warnings and cautions
before you begin installation or service.
WARNINGS
WARNING!
ALWAYS USE:
•Proper safety equipment for the
location and type of installation.
•Proper lift equipment to reach the
installation.
•Safety features of the lift equipment.
BE SURE:
•Electrical power is not connected to
the dome when connecting wires.
Dome will move when power is
applied.
•Electrical power is not connected to
nearby fixtures that you might touch
during installation.
WARNING!
The camera dome used in this
housing runs on 24Vac. DO NOT
connect line voltage to this dome.
Worldwide power requirements: A
certified limited power source is required.
North America power requirements:
This device is intended to be supplied
from a Class 2 power supply.
This installation should be made by a
qualified service person and should
conform to all local codes.
WARNING!
DO NOT install this housing in
hazardous areas where highly
combustible or explosive products are
stored or used.
CAUTION
There are two boxes: one for the indoor housing,
and one for the bubble assembly. Protect the
bubble assembly by leaving it in its box until you
are ready to install it.
Equipment Required for
Installation
Parts Supplied
- Standard housing assembly 0201-0007-01
- Vandal housing assembly 0201-0007-02
- Standard bubble assembly 0400-1402-01/-02
- Vandal bubble assembly 0404-0083-01/-02
- Tamperproof drive 1400-0149-01
(supplied with bubble)
Purchase or Supply Separately
- RUIOB Indoor I/O Board or
RUPTB Pigtail Board
Tools Required
- 6mm (.25in) fixed-handle nut driver for Torx bit
- Small screwdriver for tightening connectors
- Wire cutters and strippers

SPEEDDOME ULTRA INDOOR HOUSING AND INDOOR VANDAL-RESISTANT HOUSING 8200-0184-07, REV. B
INSTALLATION GUIDE 3 of 4
Installation
WARNING: Ensure that ac power and
electrical signals are off before beginning
this procedure.
1. See instructions supplied with the SpeedDome
Ultra housing and eyeball assembly for how to
prepare it for installation in the housing.
2. Connect the housing and eyeball assembly to
the base (Figure 2) by aligning the Cap and
Base tabs and then turning clockwise until you
hear a click.
Figure 2. Attaching dome to the base in an
indoor housing (cables and lanyard
not shown)
Referring to Figure 3:
3. Remove the bubble assembly from the package
and ensure the bubble is clean and free of
debris.
4. Attach the coiled lanyard from the bubble to the
threaded stud on the indoor housing using the
thumbnut supplied.
5. Attach trim bubble assembly.
a. Discard the red “CAUTION: Remove slot
covers” tag. There is no need to remove the
slot covers for indoor applications.
b. Align the key on the inside of the bubble
assembly with the detent on the edge of the
housing.
CAUTION: To maintain the integrity of the
gasket seal between the housing flange and
the trim ring, do not let the lanyard get
caught between these two pieces as you
secure the bubble assembly to the housing.
c. Use the drive (taped inside bubble) to
tighten the four tamper-proof screws on the
bubble assembly. To compress the gasket
evenly, tighten each screw in clockwise
formation until slight resistance is felt, then
retighten each screw again in clockwise
formation until all screws are evenly tight.
6. See instructions for the mounting structure for
how to attach the housing assembly.
Figure 3. Attaching bubble assembly
Sun Shield
Detent
Key
(inside
bubble
assy.)
Lanyard
Stud
!
A
lign tabs on
Cap and Base.
Turn clockwise
to latch

SPEEDDOME ULTRA INDOOR HOUSING AND INDOOR VANDAL-RESISTANT HOUSING 8200-0184-07, REV. B
INSTALLATION GUIDE 4 of 4
Parts List
Only parts below can be ordered, and only by
authorized users. To become authorized, contact
your sales representative.
Note: Not all of the parts are orderable. Parts are
subject to change based on design improvements
and availability.
Table 2. Parts list
1 Bubble/Trim Assy. Clear 0400-1402-01
2 Bubble/Trim Assy. Smoked 0400-1402-02
3 Bubble/Trim Assy. Clear
Vandal
0404-0083-01
4 Bubble/Trim Assy. Smoked
Vandal
0404-0083-02
5 Housing Assembly Indoor 0201-0007-01
6 Housing Assembly Indoor
Vandal
0201-0007-02
7 T20 Tamperproof Torx Bit 1400-0149-01
