American Dynamics SpeedDome Ultra Outdoor Housing ADSDUHOC User manual

-
IMPORTANT! This housing meets IP66/Nema 4 ratings
provided it is used with a properly installed ROENDC End
Cap Assembly and one of the following mounts: RHOTR
Over-the-Roof Mount, RHOSW Short Wall Mount, or
RHOLW Long Wall Mount.
ADSDUHOC, ADSDUHOS, ADSDUHOVRC, ADSDUHOVRS
SpeedDome®Ultra Outdoor Housing Installation Guide
Before performing these steps, read additional
information attached for important details and
warnings!
A
t end of pipe.
Ensure black foam plug is around
cable and press-fit into pipe.
Ensure seal and sleeve are
properly set.
See A, B, C.
Line up. Push to line and
maintain
compression.
Tighten.
Thread cables through end
cap assembly and attach
housing to mounting
structure.
Keep cables from
twisting while turning
housing.
Turn until no threads
are exposed.
A
ttach cable
connectors. Make connections,
insert cables into end
cap assembly, and
attach cover.
Check o-ring is
properly set.
Page 1 of 12 8200-0492-02, Rev. C
Seal Sleeve
1
B A
2
A
3
B C
= Step Prevents
Water Intrusion.
Green 3-Pin Connector (Power)
Pin 1 - Black (24Vac)
Pin 2 - Red (Common)
Pin 3 - White (24Vac)
Green 2-Pin Connector (Twisted Pair Video)
Pin 1 - + (video high)
Pin 2 - – (video ground)
Gray 5-Pin Connector
(Relay)
Pin 1 - Blue (NC)*
Pin 2 - Purple (Common)*
Pin 3 - Gray (NO)*
Pin 4 - White/Red (Alarm Return)
Pin 5 - White/Black (Alarm 1)
* Relay contact not to exceed 1A @
30Vdc or 0.3A @ 125Vac.
Black Connector (Data)
Manchester
Pin 1-4 - Not used
Pin 5 - White/Orange (Manchester W)
Pin 6 - White/Yellow (Manchester B)
RS-422
Pin 1 – Orange (Rx +)
Pin 2 – Green (Rx –)
Pin 3 – Yellow (Tx +)
Pin 4 – Brown (Tx –)
Pins 5-6 - Not used
SensorNet
Pin 1-4 - Not used
Pin 5 - White/Orange (SensorNet Hi)
Pin 6 - White/Yellow (SensorNet Lo)
Blue 4-Pin Connector
(Alarm)
Pin 1 - White/Blue (Alarm 2)
Pin 2 - White/Brown (Alarm 3)
Pin 3 - White/Purple (Alarm 4)
Pin 4 - White/Red (Alarm Return)

Page 2 of 12 8200-0492-02, Rev. C
Set the dome
address.
The address range is from 001
to 255, except for Manchester,
which is 01 to 64.
Set switches. Example: For
address 107, set SW3 to 1,
SW2 to 0, and SW1 to 7.
SW3 SW2 SW1
IMPORTANT! Both the outdoor housing and dome
camera are shipped “terminated” for when they are
installed at the end of a data cable. Should the cable
continue to another dome, “unterminate” the housing.
See information attached.
Place the desiccant bag in the pocket
located inside the housing and adjacent
to the blower/heater assembly.
Connect dome camera by aligning
protrusion on dome with florescent
marks on the mounting base.
Turn clockwise to
lock.
Remove and
discard both
eyeball covers.
To avoid motor damage,
turn eyeball slowly to
expose second cover!
IMPORTANT! Power the dome (heater fans turn on)
and check it performs its homing routine. During this
routine, the camera lens moves up into the dome
housing, down to the floor, pans slowly, and moves
up to its home position. The controller can then be
used to call up and control the dome.
If OK, continue. If not, see “Troubleshooting” in
information attached.
IMPORTANT! If installing a SpeedDome Ultra 8
dome in a legacy outdoor housing, go to the Dome
Information screen and select I/O Configuration.
Then select “Outdoor”. This setting will ensure
proper operation of the heater/blower.
A
ttach lanyard to stud
on flange of housing.
Secure with thumbnut.
A
ttach bubble
assembly.
A
ttach bubble to housing.
Vandal-resistant version has
additional shield installed.
Once the bubble is attached to the housing,
surface A must meet surface B on all sides.
Ensure lanyard is not caught between flange and
trim ring gasket, or trim ring and sunshield.
Ensure all four
tamperproof
screws are tight.
Sunshield
Check for
bent flange.
Discard
housing if
found.
Check for
cracks in
bubble.
Discard
bubble if
found.
4
A
B
5 A
B
C
6
A
B C
7
IMPORTANT! If the
bubble is attached to
the dome for up to 30
minutes or more and
then detached, the bag
must be replaced
before the bubble is
attached again. An
extra bag is supplied. If
more are needed,
order kit 0352-0207-02.
x100 x10 x1

SPEEDDOME ULTRA OUTDOOR HOUSING 8200-0492-02, REV. C
INSTALLATION GUIDE - CONTINUATION 3 of 12
SpeedDome®Ultra
Outdoor Housing
Installation Guide–Continuation
ADSDUHOC
ADSDUHOS
ADSDUHOVRC
ADSDUHOVRS
Contents:
To the Installer....................................................... 3
About the Product.................................................. 3
Parts Supplied ....................................................... 3
Tools Required ...................................................... 3
Warnings and Cautions......................................... 4
Preventing Condensation...................................... 5
Parts List for Authorized Users ............................. 5
Connector Pin Assignments .................................. 6
Cable Requirements.............................................. 6
Housing Termination and Video Configuration ..... 7
Troubleshooting..................................................... 9
Specifications ...................................................... 11
Declarations ........................................................ 12
© 2008 Sensormatic Electronics Corp.
To the Installer
This guide assumes that the outdoor mounting
structure to which the housing is attached is in
place and that data and power cables have been
pulled to the installation site. To install the outdoor
mounting structure, see documents shipped with
the structure.
About the Product
The outdoor housing has a sunshield cover and
bubble that protect the SpeedDome Ultra dome
camera. Tamperproof screws affix the bubble to
the housing.
The housing is temperature controlled and
weatherproof. A built-in thermostat and heater
prevent ice from forming on the outside of the
bubble.
The non-vandal resistant version has four alarm
inputs and one SPDT relay. Surge protection is
provided on all external lines, including video.
Parts Supplied
•Housing assembly 0101-0115-03
•Housing assembly, vandal-resistant
0101-0116-03
•Bubble assembly 0404-1402-01 (Clear) /
-02 (Smoked)
•Tamperproof drive 1400-0149-01
•Install kit 0352-0248-03
Purchase or Supply Separately
Male BNC connector
Tools Required
•6.6mm (1/4in) fixed-handle nut driver for
Torx bit
•Wire cutters and strippers
•2.5mm (0.1in) slotted screwdriver

SPEEDDOME ULTRA OUTDOOR HOUSING 8200-0492-02, REV. C
INSTALLATION GUIDE - CONTINUATION 4 of 12
Warnings and Cautions
Please review the following warnings and cautions
before you begin installation or service.
Warnings
WARNING! Always use proper lift and
safety equipment for the location and
type of installation. Use the safety
features of the lift equipment.
WARNING! When connecting wires,
ensure electrical power is not connected
to the camera dome. The dome will
move when power is applied. Also,
ensure electrical power is not connected
to nearby fixtures you might touch during
installation.
WARNING! The camera dome runs on
24Vac. DO NOT connect line voltage to
the dome.
North America power requirements: In
North America, this device is intended to
be supplied from a Class 2 power
supply. For outdoor installations, use
Class 3 wiring techniques, liquid-tight
conduit, or liquid-tight pipe.
This installation should be made by a
qualified service person and should
conform to all local codes.
WARNING! DO NOT install this housing
where combustible or explosive products
are stored or used.
WARNING! EU power requirements:
This product runs on 24Vac. In the EU, it
is intended to be powered from a Limited
Power Source. A limited power source is
a certified source of SELV, and if
inherently limited, with 8 amps maximum
output current, and a maximum of 100VA
available; or if not inherently limited,
fused with a maximum value of 3.3
Amps, meeting section 2.11 of IEC950,
and a maximum of 250VA available. The
power supply can be obtained through
American Dynamics or through another
source where the provider can furnish
the required certification. This is required
to assure electrical safety in the product.
Cautions
Water leaks, even small ones, can
increase humidity inside the outdoor
housing. To help eliminate humidity,
follow all instructions explicitly and
also the following cautions:
- DO NOT use over seals such as
RTV and silicone caulks.
- Ensure blower/heater assembly
fans spin when power is on.
Also see “Preventing Condensation”
on page 5.
•To protect the bubble assembly, leave it in its
box until you are ready to install it.
•Do not run data/power cables adjacent to or in
the same conduit as line voltage mains power.
•Network cable/device requirements (additional
requirements are listed on page 6):
Network
Cable
Thickness
Required
Maximum
Devices per
Cable Run
SensorNet 0.326mm2
(22AWG)
32
RS-422 0.326mm2
(22AWG)
10
Manchester 0.823mm2
(18AWG)
3
•Remove both slot covers from the eyeball to
prevent overheating
•Keep cables within the housing away from the
heater assembly
•If required, set data cable termination inside the
housing (see “Unterminating the Outdoor
Housing” on page 7).
•If possible, mount the housing so the least
needed view (such as a wall, building corner, or
pole) is opposite the blower/heater assembly.
•Protect this equipment from direct lightning
strikes. See Lightning Protection Reference
Guide 8200-0627-01 available online at
www.americandynamics.net.
!
!
!
!
!

SPEEDDOME ULTRA OUTDOOR HOUSING 8200-0492-02, REV. C
INSTALLATION GUIDE - CONTINUATION 5 of 12
Preventing Condensation
Damage, missing parts, or procedures
that most often allow water to enter
the housing are as follows (refer to
figures opposite):
Missing O-ring on cover, or missing sleeve or
seal on end cap assembly
Missing Teflon tape around any housing pipe
threads
RTV or similar sealant covering an air path
Blower fans not turning
Loose tamperproof screws in bubble assembly
Bent flange on metal housing that
compromises the gasket seal between the
bubble and the housing
Plugged drain holes in the bubble trim ring
Cracked bubble
Tamperproof screws that are missing or
improperly tightened compromise the gasket
seal between the bubble and the housing
Ensure lanyard is not caught between: a)
flange and trim ring gasket, and b) trim ring
and sunshield
In high humidity environments, the desiccant
bag may need to be replaced occasionally.
Parts List for Authorized
Users
The parts listed below and shown in the exploded
view can only be ordered by authorized users. To
become authorized, contact your sales
representative.
1. Housing Assy., 0404-0260-03
2. Blower/Heater Assy., 0304-2906-01
3. I/O Board Assy., 0312-2124-03
4. Bubble Assy. (Clear), 0400-1402-01
5. Bubble Assy. (Smoke), 0400-1402-02
6. Drive, Tamperproof, 1400-0149-01
7. Screws, Tamperproof, 0500-8034-01 (x4)
8. Desiccant Kit, 0352-0207-02
Exploded view
Foam seal
(inside pipe)
Sleeve (outside),
Seal (inside end
cap assembly)
O-ring (inside
cover)
Bent flange
Gasket seal
between
bubble and
metal housing
Blower fans
1
2
3
6
4, 5
Additional shield (not
shown) used for vandal-
resistant version.
7
