American Standard ALLEGIANCE 10 Operation manual

© American Standard Inc. 1999 PUB. NO. 12-1112-03 Tab 1 — December 1999
ALLEGIANCE®10
MODELS 7A0018-060
SPLIT SYSTEM COOLING
1 — 5 TON

2
DATA SUBJECTTO CHANGEWITHOUT NOTICE
PRODUCT DATA
American Standard Inc., Tyler, TX 75711-9010
Features
and Benefits
Split System Cooling Units . . .
Designed WithYour Needs In Mind.
A.R.I. STANDARD CAPACITY RATING CONDITIONS
A.R.I. STANDARD 210 RATING CONDITIONS — (A) Cooling 80°F. D.B., 67°F. W.B. air entering indoor coil, 95°F. D.B. air
entering outdoor coil.
A.R.I. STANDARD 270 RATING CONDITIONS — (Noise rating numbers are determined with the unit in cooling operation.)
Standard Noise Rating number is at 95°F. outdoor air.
Allegiance®10 split systems represent
a new approach to designing products
for American-Standard.The design
team’s mission is “. . . to bring a
system to the marketplace that will
meet your job requirements every
time” . . . And at a competitive price.
American-Standard’s experienced
design team used the newest
computer technology and an entirely
new manufacturing process to develop
a new standard in split systems.
Couple the American-Standard
reputation for quality and reliability in
split system air conditioners with
improvements in efficiency, flexibility
and installation ease . . . and you have
systems that are “Built To A Higher
Standard.”
◆High efficiency Duration™ compressor
◆Attractive warm gray color
◆Brazed refrigerant connections
◆Multi-use service valves
◆Sculpted, contoured top
◆Recessed fan grille
◆Screw covers on fan grille
◆Steel cabinet, full coil protection
◆Powder paint covers uniformly to resist rust & corrosion
◆Fast draining base pan assembly
◆Liquid line filter-drier
◆Single side service access
◆7A0 corner shipping blocks used for base spacers
◆Cavities in base pan designed for standard
heat pump legs
◆Vertical air discharge
◆Direct drive propeller fan
◆Factory supplied charge of HCFC
◆Weatherproof electrical controls
◆Low ambient cooling to 55°F. as shipped
◆Low ambient cooling to 40°F. with EDC accessory
AY28X079
◆Low ambient cooling to 30°F. with EDC accessory
AY28X079 and TXV
◆5-year limited warranty on compressor & coil,
1-year on parts
◆Optional extended warranties

DATA SUBJECTTO CHANGEWITHOUT NOTICE
3
PRODUCT DATA
American Standard Inc., Tyler, TX 75711-9010
Features and Benefits 2
Model Number Description 4
Optional Equipment 4
General Data
7A0018A100A 5
7A0024A100A 7
7A0030A100A 9
7A0036A100A 12
7A0042A100A 14
7A0048B100A 16
7A0060B100A 18
Ratings with
Auxiliary Devices 20
Typical Wiring 24
Dimensional Data 26
Mechanical Specifications 27
DATA SUBJECT
TO CHANGE
WITHOUT NOTICE
Contents
Manufacturing Control
American-Standard’s exclusive control
over the design and manufacturing of all
major components is unique in the
industry.This approach assures us total
control over both the quality and reliability
of these components.It also allows us to
custom match components to deliver the
best in split system performance.
Designing the Details
Careful attention was given to designing
the details — from control wiring to the
access panels.These units feature time-
saving color-coded wiring and removable
panels which allow complete access to all
major components and controls. All
outdoor units feature external high and
low pressure gauge port connections.
Service valves for easy diagnosing and
servicing of the unit are provided.
Standardized Cabinets
In addition all cabinets have been
standardized; so when you are servicing
an outdoor unit or an air handler all
components are in the same location from
unit to unit.
UL Listed
American-Standard meets or exceeds all
nationally recognized agency safety and
design standards. Each condensing unit
is designed, approved, and labeled in
accordance to UL Standards: UL 1995
for central cooling air conditioners and
for refrigeration and air conditioning
condensing and compressor units,
including approval for use in Canada.
Each unit is rated in accordance with
ARI Standard 210 and 270.

4
DATA SUBJECTTO CHANGEWITHOUT NOTICE
PRODUCT DATA
American Standard Inc., Tyler, TX 75711-9010
Product/Service/Parts
Minor Design Modifications
Secondary Functions
Voltage/Power Supply
1 - 200-230 Volts 1 Phase
3 - 208-230 Volts 3 Phase
4 - 460 Volts 3 Phase
Major Design Modification
1234*56789101112
7A0042A100A0
Model Number
Description
Outdoor Product Type
Split Cooling - 7A, 7B, 7C
Split Heat Pump - 6H, 6C
Efficiency
0 - 10 SEER
1 - 11 SEER
2 - 12 SEER
4 - 14 SEER
Primary Capacity
Example: 042 = 42 MBTUH = 4 Tons
OPTIONAL EQUIPMENT
OPTIONAL EQUIPMENT FOR CONDENSING UNITS (Check mark [✓✓
✓✓
✓] indicates accessories included).
Indoor Thermostats — Prog. Electronic Setback 3 Heating/2 Cooling...................................................................................ASYSTAT620 [ ]
Prog. Electronic Setback 1 Heating/1 Cooling...................................................................................ASYSTAT621 [ ]
Cooling Only with Fan Switch ............................................................................................................ASYSTAT603 [ ]
Heating/Cooling — Vertical ................................................................................................................ASYSTAT604 [ ]
Heating/Cooling — Horizontal............................................................................................................ASYSTAT605 [ ]
Manual 2 Heating/1 Cooling...............................................................................................................ASYSTAT606 [ ]
Thermostat Locking Cover................................................................................................................... BAY28X190 [ ]
Outdoor Thermostat ............................................................................................................................................................... TAYSTAT250A [ ]
Evaporator Defrost Control .......................................................................................................................................................... AY28X079 [ ]
Indoor Fan Delay Relay Kit ........................................................................................................................................................ BAY24X045 [ ]
Humidistat.................................................................................................................................................................................ASYSTAT625 [ ]
5 Minute Delay Relay1......................................................................................................................................................... TAYASCT501A [ ]
Quick Start Kit (7A0018,024,036,042A) .............................................................................................................................. BAYKSKT250A [ ]
Quick Start Kit (7A0048-60B) .............................................................................................................................................. BAYKSKT252A [ ]
Rubber Isolators ........................................................................................................................................................................ BAYISLT100 [ ]
Crankcase Heater Kit (7A0048B)2..................................................................................................................................... BAYCCHT200A [ ]
Crankcase Heater Kit (7A0060B)2..................................................................................................................................... BAYCCHT201A [ ]
1 Do not use with programmable thermostats.
2 When field inner connecting lines exceed 60 linear ft.of length consult refrigerant piping software (Pub.No. 12-3312-01).
BRAZEDTUBING REFRIGERANT LINE SETS (All Suction Lines are Insulated.)
5/8" ODM (90° bend, one end), 5/8" & 1/4" tubing ............................................................................................................. TAYREFLN1__* [ ]
3/4" ODM (90° bend, one end), 3/4" & 5/16" tubing ........................................................................................................... TAYREFLN2__* [ ]
7/8" ODM (90° bend, one end), 7/8" & 3/8" tubing ............................................................................................................. TAYREFLN3__* [ ]
1-1/8" ODM (90° bend, one end), 1-1/8" & 3/8" tubing....................................................................................................... TAYREFLN4__* [ ]
*Line lengths: 15, 20, 25, 30, 40 & 50 ft.Insert desired line length in catalog number at right for the complete number.
Example:TAYREFLN220.
LOW OUTDOOR AMBIENT COOLING
Low Ambient As Evaporator
Cooling Manufactured Defrost Control
FCCV Accutron 55°F 40°F
Thermal Expansion Valve (TXV) 45°F 30°F

1 CERTIFIED IN ACCORDANCEWITHTHE UNITARY AIR-CONDITIONER
EQUIPMENT CERTIFICATION PROGRAM,WHICH IS BASED ON A.R.I.
STANDARD 210/240.
2 RATED IN ACCORDANCEWITH A.R.I. STANDARD 270.
SPLIT SYSTEM
3 CALCULATED IN ACCORDANCEWITH NATL.ELECTRIC CODE. ONLY USE
HACR CIRCUIT BREAKERS OR FUSES.
4 STANDARD AIR - DRY COIL - OUTDOOR
5 THISVALUE APPROXIMATE.FOR MORE PRECISEVALUE SEE UNIT
NAMEPLATE AND SERVICE INSTRUCTION.
6 MAX.LINEAR LENGTH:80 FT WITH RECIPROCATING COMPRESSOR -
60 FTWITH SCROLL.MAX.LIFT - SUCTION 60 FT;MAX LIFT - LIQUID 60 FT.
FOR GREATER LENGTH REFER TO REFRIGERANT PIPING SOFTWARE
PUB.NO.12-3312-01.
7 THEVALUE SHOWN FOR COMPRESSOR RLA ONTHE UNIT NAMEPLATE
AND ONTHIS SPECIFICATION SHEET IS USEDTO COMPUTE MINIMUM
BRANCH CIRCUIT AMPACITY AND MAXIMUM FUSE SIZE. THE VALUE
SHOWN IS THE BRANCH CIRCUIT SELECTION CURRENT.
8 NO MEANS NO START COMPONENTS.
YES MEANS QUICK START KIT COMPONENTS.
PTC MEANS POSITIVETEMPERATURE COEFFICIENT STARTER.
DATA SUBJECTTO CHANGEWITHOUT NOTICE
5
PRODUCT DATA
American Standard Inc., Tyler, TX 75711-9010
General Data — 7A0018A100A
✝
See page 20 for combinations with Auxiliary Devices.
OUTDOOR UNIT 12 7A0018A100A
POWER CONNS. —V/PH/HZ 3 200/230/1/60
MIN.BRCH.CIR.AMPACITY 11
BR.CIR. MAX. (AMPS) 15
PROT.RTG.}MIN. (AMPS) 15
NOISE RATING (DECIBELS) 2 80
COMPRESSOR DURATION™
NO.USED - NO.SPEEDS 1 - 1
VOLTS/PH/HZ 200/230/1/60
R.L. AMPS
7 - L.R. AMPS 8.0 - 45
FACTORY INSTALLED
START COMPONENTS 8 NO
INSULATION/SOUND BLANKET NO
COMPRESSOR HEAT NO
OUTDOOR FAN —TYPE PROPELLER
DIA.(IN.) - NO.USED 18 - 1
TYPE DRIVE - NO. SPEEDS DIRECT - 1
CFM @ 0.0 IN.W.G.
4 1960
NO.MOTORS - HP 1 - 1/8
MOTOR SPEED R.P.M. 1075
VOLTS/PH/HZ 200/230/1/60
F.L.AMPS 0.75
OUTDOOR COIL — TYPE SPINE FIN™
ROWS - F.P.I. 1 - 24
FACE AREA (SQ. FT.) 10.61
TUBE SIZE (IN.) 3/8
REFRIGERANT
LBS.— R-22 (O.D.UNIT)
5 3-LBS., 13-OZ.
FACTORY SUPPLIED YES
LINE SIZE - IN.O.D.GAS 6 5/8
LINE SIZE - IN.O.D.LIQ.
6 1/4
FCCV
RESTRICTOR ORIFICE SIZE 0.049
DIMENSIONS H X W X D
OUTDOOR UNIT - CRATED (IN.) 27-3/8X31-1/2 X27-5/8
UNCRATED SEE OUTLINE DWG.
WEIGHT
SHIPPING (LBS.) 166
NET (LBS.) 148
CONDENSING UNIT WITH COOLING COILS
CCBA18A4ACC CCBA24A4ACC CUBA18A4ACC CUBA24A4ACC TXA018C4 TXA024C4 TXA025C4
EXPANSIONTYPE FIXED ORIFICE FIXED ORIFICE FIXED ORIFICE FIXED ORIFICE FACT INS 49 CHGTO 49 CHGTO 49
RATINGS (COOLING) 1
BTUH (TOTAL) 17200 17100 17200 17100 17200 17300 17600
BTUH (SENSIBLE) 11400 11800 11400 11800 11400 11900 12800
INDOOR AIRFLOW (CFM) 600 640 600 640 600 645 660
SYSTEM POWER (KW) 1.74 1.68 1.74 1.68 1.74 1.74 1.75
SEER (BTU/WATT-HR.) 10.00 10.50 10.00 10.50 10.00 10.15 10.20
TXC018C4 TXC024C4 TXC024D4 TXC025C4 TXC025D4 TXH025A4
EXPANSIONTYPE FACT INS 49 CHGTO 49 CHGTO 49 CHGTO 49 CHGTO 49 CHGTO 49
RATINGS (COOLING) 1
BTUH (TOTAL) 17200 17300 17300 17600 17600 17900
BTUH (SENSIBLE) 11400 11900 11900 12800 12800 12400
INDOOR AIRFLOW (CFM) 600 645 645 660 660 670
SYSTEM POWER (KW) 1.73 1.74 1.74 1.75 1.75 1.79
SEER (BTU/WATT-HR.) 10.00 10.15 10.15 10.20 10.20 10.50
CONDENSING UNIT WITH AIR HANDLERS
TVF018A14 TVF024A14 TVF025A14 TWE018C14 TWE024C14 TWG018A14 TWG025A14
EXPANSIONTYPE FACT INS 49 CHGTO 49 CHGTO 49 FACT INS 49 CHG TO 49 FACT INS 49 CHGTO 49
RATINGS (COOLING) 1
BTUH (TOTAL) 17800 17900 18000 17000 16800 17000 16600
BTUH (SENSIBLE) 12800 13400 13500 11400 11700 11600 11900
INDOOR AIRFLOW (CFM) 600 670 675 600 630 600 620
SYSTEM POWER (KW) 1.71 1.79 1.76 1.63 1.72 1.70 1.61
SEER (BTU/WATT-HR.) 10.80 10.35 10.60 10.85 10.10 10.75 10.20

6
DATA SUBJECTTO CHANGEWITHOUT NOTICE
PRODUCT DATA
American Standard Inc., Tyler, TX 75711-9010
General Data — 7A0018A100A
✝
See page 20 for combinations with Auxiliary Devices.
CONDENSING UNIT WITH AIR HANDLERS
TWG030A14
EXPANSIONTYPE CHG TO 49
RATINGS (COOLING) 1
BTUH (TOTAL) 18100
BTUH (SENSIBLE) 13000
INDOOR AIRFLOW (CFM) 675
SYSTEM POWER (KW) 1.80
SEER (BTU/WATT-HR.) 10.75
CONDENSING UNIT WITH FURNACES & COILS
AUY080R9V3
+TXC031E5
EXPANSIONTYPE TXV-B
RATINGS (COOLING) 1
BTUH (TOTAL) 18800
BTUH (SENSIBLE) 13300
INDOOR AIRFLOW (CFM) 575
SYSTEM POWER (KW) 1.59
SEER (BTU/WATT-HR.) 10.90

1 CERTIFIED IN ACCORDANCEWITHTHE UNITARY AIR-CONDITIONER
EQUIPMENT CERTIFICATION PROGRAM,WHICH IS BASED ON A.R.I.
STANDARD 210/240.
2 RATED IN ACCORDANCEWITH A.R.I. STANDARD 270.
SPLIT SYSTEM
3 CALCULATED IN ACCORDANCEWITH NATL.ELECTRIC CODE. ONLY USE
HACR CIRCUIT BREAKERS OR FUSES.
4 STANDARD AIR - DRY COIL - OUTDOOR
5 THISVALUE APPROXIMATE.FOR MORE PRECISEVALUE SEE UNIT
NAMEPLATE AND SERVICE INSTRUCTION.
6 MAX.LINEAR LENGTH:80 FT WITH RECIPROCATING COMPRESSOR -
60 FTWITH SCROLL.MAX.LIFT - SUCTION 60 FT;MAX LIFT - LIQUID 60 FT.
FOR GREATER LENGTH REFER TO REFRIGERANT PIPING SOFTWARE
PUB.NO.12-3312-01.
7 THEVALUE SHOWN FOR COMPRESSOR RLA ONTHE UNIT NAMEPLATE
AND ONTHIS SPECIFICATION SHEET IS USEDTO COMPUTE MINIMUM
BRANCH CIRCUIT AMPACITY AND MAXIMUM FUSE SIZE. THE VALUE
SHOWN IS THE BRANCH CIRCUIT SELECTION CURRENT.
8 NO MEANS NO START COMPONENTS.
YES MEANS QUICK START KIT COMPONENTS.
PTC MEANS POSITIVETEMPERATURE COEFFICIENT STARTER.
DATA SUBJECTTO CHANGEWITHOUT NOTICE
7
PRODUCT DATA
American Standard Inc., Tyler, TX 75711-9010
OUTDOOR UNIT 12 7A0024A100A
POWER CONNS. —V/PH/HZ 3 200/230/1/60
MIN.BRCH.CIR.AMPACITY 15
BR.CIR. MAX. (AMPS) 25
PROT.RTG.}MIN. (AMPS) 20
NOISE RATING (DECIBELS) 2 80
COMPRESSOR DURATION™
NO.USED - NO.SPEEDS 1 - 1
VOLTS/PH/HZ 200/230/1/60
R.L. AMPS
7 - L.R. AMPS 11.6 - 67
FACTORY INSTALLED
START COMPONENTS 8 NO
INSULATION/SOUND BLANKET NO
COMPRESSOR HEAT NO
OUTDOOR FAN —TYPE PROPELLER
DIA.(IN.) - NO.USED 18 - 1
TYPE DRIVE - NO. SPEEDS DIRECT - 1
CFM @ 0.0 IN.W.G.
4 1960
NO.MOTORS - HP 1 - 1/8
MOTOR SPEED R.P.M. 1075
VOLTS/PH/HZ 200/230/1/60
F.L.AMPS 0.75
OUTDOOR COIL — TYPE SPINE FIN™
ROWS - F.P.I. 1 - 24
FACE AREA (SQ. FT.) 10.61
TUBE SIZE (IN.) 3/8
REFRIGERANT
LBS.— R-22 (O.D.UNIT)
5 4-LBS.,3-OZ.
FACTORY SUPPLIED YES
LINE SIZE - IN.O.D.GAS 6 3/4
LINE SIZE - IN.O.D.LIQ.
6 5/16
FCCV
RESTRICTOR ORIFICE SIZE 0.057
DIMENSIONS H X W X D
OUTDOOR UNIT - CRATED (IN.) 27-3/8X31-1/2 X27-5/8
UNCRATED SEE OUTLINE DWG.
WEIGHT
SHIPPING (LBS.) 173
NET (LBS.) 155
CONDENSING UNIT WITH COOLING COILS
CCBA24A4ACC CCBA30A4ACC CCBB30A4ACC CUBA24A4ACC CUBA30A4ACC CUBB30A4ACC TXA018C4
EXPANSIONTYPE FIXED ORIFICE FIXED ORIFICE FIXED ORIFICE FIXED ORIFICE FIXED ORIFICE FIXED ORIFICE CHGTO 57
RATINGS (COOLING) 1
BTUH (TOTAL) 22400 21800 22400 22400 21800 22400 21200
BTUH (SENSIBLE) 14700 14700 16400 14700 14700 16400 13400
INDOOR AIRFLOW (CFM) 800 815 840 800 815 840 675
SYSTEM POWER (KW) 2.40 2.37 2.40 2.40 2.37 2.40 2.28
SEER (BTU/WATT-HR.) 10.00 10.00 10.05 10.00 10.00 10.05 10.00
TXA024C4 TXA025C4 TXA030C4 TXA031C4 TXA035C4 TXA036C4 TXA037C4
EXPANSIONTYPE FACT INS 57 FACT INS 57 CHGTO 57 CHGTO 57 CHGTO 57 CHGTO 57 CHGTO 57
RATINGS (COOLING) 1
BTUH (TOTAL) 23000 22600 23200 23400 23200 23800 23800
BTUH (SENSIBLE) 15100 15500 15900 16900 15900 17300 17300
INDOOR AIRFLOW (CFM) 800 800 870 875 870 890 890
SYSTEM POWER (KW) 2.45 2.39 2.46 2.46 2.46 2.48 2.48
SEER (BTU/WATT-HR.) 10.00 10.05 10.05 10.05 10.05 10.10 10.10
7A0024AWITH TXC018C4 TXC024C4 TXC024D4 TXC025C4 TXC025D4 TXC030C4 TXC030D4
EXPANSIONTYPE CHG TO 57 FACT INS 57 FACT INS 57 FACT INS 57 FACT INS 57 CHGTO 57 CHGTO 57
RATINGS (COOLING) 1
BTUH (TOTAL) 21200 23000 23000 22600 22600 23200 23200
BTUH (SENSIBLE) 13400 15100 15100 15500 15500 15900 15900
INDOOR AIRFLOW (CFM) 675 800 800 800 800 870 870
SYSTEM POWER (KW) 2.28 2.45 2.45 2.39 2.39 2.46 2.46
SEER (BTU/WATT-HR.) 10.00 10.00 10.00 10.05 10.05 10.05 10.05
General Data — 7A0024A100A
✝
See page 20 for combinations with Auxiliary Devices.

8
DATA SUBJECTTO CHANGEWITHOUT NOTICE
PRODUCT DATA
American Standard Inc., Tyler, TX 75711-9010
General Data — 7A0024A100A
✝
See page 20 for combinations with Auxiliary Devices.
CONDENSING UNIT WITH COOLING COILS
TXC031C4 TXC031D4 TXC031E5 TXC035C4 TXC035D4 TXC036C4 TXC036D4
EXPANSIONTYPE CHG TO 57 CHGTO 57 TXV-B CHGTO 57 CHGTO 57 CHGTO 57 CHGTO 57
RATINGS (COOLING) 1
BTUH (TOTAL) 23400 23400 23800 23200 23200 23800 23800
BTUH (SENSIBLE) 16900 16900 17400 15900 15900 17300 17300
INDOOR AIRFLOW (CFM) 875 875 890 870 870 890 890
SYSTEM POWER (KW) 2.46 2.46 2.45 2.46 2.46 2.48 2.48
SEER (BTU/WATT-HR.) 10.05 10.05 10.35 10.05 10.05 10.10 10.10
TXC036E5 TXC037C4 TXC037E5 TXH025A4 TXH033A4
EXPANSIONTYPE TXV-B CHGTO 57 TXV-B FACT INS 57 FACT INS 57
RATINGS (COOLING) 1
BTUH (TOTAL) 24200 23800 24200 23200 24400
BTUH (SENSIBLE) 17800 17300 17800 15300 17500
INDOOR AIRFLOW (CFM) 900 890 900 800 900
SYSTEM POWER (KW) 2.46 2.48 2.46 2.47 2.55
SEER (BTU/WATT-HR.) 10.50 10.10 10.50 10.10 10.15
CONDENSING UNIT WITH AIR HANDLERS
TVF018A14 TVF024A14 TVF025A14 TVF030A14 TVF036A14 TWE018C14 TWE024C14
EXPANSIONTYPE CHG TO 57 CHGTO 57 CHGTO 57 CHGTO 57 CHGTO 57 CHGTO 57 CHGTO 57
RATINGS (COOLING) 1
BTUH (TOTAL) 22400 23200 23200 24000 24200 22400 22600
BTUH (SENSIBLE) 15000 16400 16400 18000 18200 14300 15000
INDOOR AIRFLOW (CFM) 675 800 800 900 900 675 800
SYSTEM POWER (KW) 2.36 2.44 2.40 2.47 2.56 2.38 2.42
SEER (BTU/WATT-HR.) 10.30 10.30 10.50 10.50 10.15 10.15 10.10
TWE030C14 TWE036C14 TWG018A14 TWG025A14 TWG030A14
EXPANSIONTYPE CHG TO 57 CHGTO 57 CHGTO 57 CHGTO 57 CHGTO 57
RATINGS (COOLING) 1
BTUH (TOTAL) 23000 23600 21800 22400 22800
BTUH (SENSIBLE) 16400 16900 14200 15200 15900
INDOOR AIRFLOW (CFM) 860 885 675 800 855
SYSTEM POWER (KW) 2.45 2.50 2.34 2.33 2.44
SEER (BTU/WATT-HR.) 10.20 10.20 10.15 10.00 10.00
CONDENSING UNIT WITH FURNACES & COILS
ADD080R9V3 ADD080R9V3 ADD100R9V5 AUD080R9V3 AUD080R9V3 AUD100R9V5 AUY080R9V3
+TXC031E5 +TXC036E5 +TXC037E5 +TXC031E5 +TXC036E5 +TXC037E5 +TXC031E5
EXPANSIONTYPE TXV-B TXV-B TXV-B TXV-B TXV-B TXV-B TXV-B
RATINGS (COOLING) 1
BTUH (TOTAL) 23800 24400 24400 23800 24400 24400 24600
BTUH (SENSIBLE) 16600 17300 17400 16800 17500 17400 17400
INDOOR AIRFLOW (CFM) 775 775 800 800 825 800 800
SYSTEM POWER (KW) 2.22 2.24 2.22 2.26 2.26 2.22 2.32
SEER (BTU/WATT-HR.) 10.70 10.80 10.80 10.70 10.80 10.80 10.90
AUY080R9V3
+TXC036E5
EXPANSIONTYPE TXV-B
RATINGS (COOLING) 1
BTUH (TOTAL) 25200
BTUH (SENSIBLE) 18000
INDOOR AIRFLOW (CFM) 800
SYSTEM POWER (KW) 2.33
SEER (BTU/WATT-HR.) 10.90

1 CERTIFIED IN ACCORDANCEWITHTHE UNITARY AIR-CONDITIONER
EQUIPMENT CERTIFICATION PROGRAM,WHICH IS BASED ON A.R.I.
STANDARD 210/240.
2 RATED IN ACCORDANCEWITH A.R.I. STANDARD 270.
SPLIT SYSTEM
3 CALCULATED IN ACCORDANCEWITH NATL.ELECTRIC CODE. ONLY USE
HACR CIRCUIT BREAKERS OR FUSES.
4 STANDARD AIR - DRY COIL - OUTDOOR
5 THISVALUE APPROXIMATE.FOR MORE PRECISEVALUE SEE UNIT
NAMEPLATE AND SERVICE INSTRUCTION.
6 MAX.LINEAR LENGTH:80 FT WITH RECIPROCATING COMPRESSOR -
60 FTWITH SCROLL.MAX.LIFT - SUCTION 60 FT;MAX LIFT - LIQUID 60 FT.
FOR GREATER LENGTH REFER TO REFRIGERANT PIPING SOFTWARE
PUB.NO.12-3312-01.
7 THEVALUE SHOWN FOR COMPRESSOR RLA ONTHE UNIT NAMEPLATE
AND ONTHIS SPECIFICATION SHEET IS USEDTO COMPUTE MINIMUM
BRANCH CIRCUIT AMPACITY AND MAXIMUM FUSE SIZE. THE VALUE
SHOWN IS THE BRANCH CIRCUIT SELECTION CURRENT.
8 NO MEANS NO START COMPONENTS.
YES MEANS QUICK START KIT COMPONENTS.
PTC MEANS POSITIVETEMPERATURE COEFFICIENT STARTER.
DATA SUBJECTTO CHANGEWITHOUT NOTICE
9
PRODUCT DATA
American Standard Inc., Tyler, TX 75711-9010
General Data — 7A0030A100A
✝
See pages 20 and 21 for combinations with Auxiliary Devices.
OUTDOOR UNIT 12 7A0030A100A
POWER CONNS. —V/PH/HZ 3 200/230/1/60
MIN.BRCH.CIR.AMPACITY 17
BR.CIR. MAX. (AMPS) 30
PROT.RTG.}MIN. (AMPS) 30
NOISE RATING (DECIBELS) 2 78
COMPRESSOR DURATION™
NO.USED - NO.SPEEDS 1 - 1
VOLTS/PH/HZ 200/230/1/60
R.L. AMPS
7 - L.R. AMPS 13.1 - 75
FACTORY INSTALLED
START COMPONENTS 8 NO
INSULATION/SOUND BLANKET NO
COMPRESSOR HEAT YES
OUTDOOR FAN —TYPE PROPELLER
DIA.(IN.) - NO.USED 18 - 1
TYPE DRIVE - NO. SPEEDS DIRECT - 1
CFM @ 0.0 IN.W.G.
4 2175
NO.MOTORS - HP 1 - 1/8
MOTOR SPEED R.P.M. 1075
VOLTS/PH/HZ 200/230/1/60
F.L.AMPS 0.75
OUTDOOR COIL — TYPE SPINE FIN™
ROWS - F.P.I. 1 - 24
FACE AREA (SQ. FT.) 10.61
TUBE SIZE (IN.) 3/8
REFRIGERANT
LBS.— R-22 (O.D.UNIT)
5 3-LBS., 14 OZ.
FACTORY SUPPLIED YES
LINE SIZE - IN.O.D.GAS 6 3/4
LINE SIZE - IN.O.D.LIQ.
6 5/16
FCCV
RESTRICTOR ORIFICE SIZE 0.065
DIMENSIONS H X W X D
OUTDOOR UNIT - CRATED (IN.) 27-3/8X31-1/2 X27-5/8
UNCRATED SEE OUTLINE DWG.
WEIGHT
SHIPPING (LBS.) 174
NET (LBS.) 156
CONDENSING UNIT WITH COOLING COILS
CCBA30A4ACC CCBA36A4ACC CCBB30A4ACC CCBB36A4ACC CUBA30A4ACC CUBA36A4ACC CUBB30A4ACC
EXPANSIONTYPE FIXED ORIFICE FIXED ORIFICE FIXED ORIFICE FIXED ORIFICE FIXED ORIFICE FIXED ORIFICE FIXED ORIFICE
RATINGS (COOLING) 1
BTUH (TOTAL) 26600 27400 27800 27600 26600 27400 27800
BTUH (SENSIBLE) 17400 18600 19500 19900 17400 18600 19500
INDOOR AIRFLOW (CFM) 950 1020 1000 1030 950 1020 1000
SYSTEM POWER (KW) 2.92 3.01 2.99 3.02 2.92 3.01 2.99
SEER (BTU/WATT-HR.) 10.00 10.00 10.05 10.00 10.00 10.00 10.05
CUBB36A4ACC TXA024C4 TXA025C4 TXA030C4 TXA031C4 TXA035C4 TXA036C4
EXPANSIONTYPE FIXED ORIFICE CHGTO 65 CHGTO 65 CHGTO 65 CHGTO 65 CHGTO 65 CHGTO 65
RATINGS (COOLING) 1
BTUH (TOTAL) 27600 26600 27000 27800 28400 28000 29000
BTUH (SENSIBLE) 19900 17200 18200 18600 19900 19000 21200
INDOOR AIRFLOW (CFM) 1030 900 900 1000 1000 1050 1085
SYSTEM POWER (KW) 3.02 2.91 2.92 3.01 3.09 3.03 3.10
SEER (BTU/WATT-HR.) 10.00 10.00 10.05 10.10 10.00 10.05 10.05
TXA037C4 TXA042C4 TXA043C4 TXC024C4 TXC024D4 TXC025C4 TXC025D4
EXPANSIONTYPE CHG TO 65 CHGTO 65 CHGTO 65 CHGTO 65 CHGTO 65 CHGTO 65 CHGTO 65
RATINGS (COOLING) 1
BTUH (TOTAL) 29000 29400 29400 26600 26600 27000 27000
BTUH (SENSIBLE) 21200 21800 21800 17200 17200 18200 18200
INDOOR AIRFLOW (CFM) 1085 1095 1095 900 900 900 900
SYSTEM POWER (KW) 3.10 3.13 3.13 2.91 2.91 2.92 2.92
SEER (BTU/WATT-HR.) 10.05 10.10 10.10 10.00 10.00 10.05 10.05

10
DATA SUBJECTTO CHANGEWITHOUT NOTICE
PRODUCT DATA
American Standard Inc., Tyler, TX 75711-9010
CONDENSING UNIT WITH COOLING COILS
TXC030C4 TXC030D4 TXC031C4 TXC031D4 TXC031E5 TXC035C4 TXC035D4
EXPANSIONTYPE CHG TO 65 CHGTO 65 CHGTO 65 CHGTO 65 TXV-B CHGTO 65 CHGTO 65
RATINGS (COOLING) 1
BTUH (TOTAL) 27800 27800 28400 28400 28800 28000 28000
BTUH (SENSIBLE) 18600 18600 19900 19900 20300 19000 19000
INDOOR AIRFLOW (CFM) 1000 1000 1000 1000 1000 1050 1050
SYSTEM POWER (KW) 3.01 3.01 3.09 3.09 3.03 3.03 3.03
SEER (BTU/WATT-HR.) 10.10 10.10 10.00 10.00 10.25 10.05 10.05
TXC036C4 TXC036D4 TXC036E5 TXC037C4 TXC037E5 TXC042C4 TXC043C4
EXPANSIONTYPE CHG TO 65 CHGTO 65 TXV-B CHGTO 65 TXV-B CHGTO 65 CHGTO 65
RATINGS (COOLING) 1
BTUH (TOTAL) 29000 29000 29800 29000 29800 29400 29400
BTUH (SENSIBLE) 21200 21200 22300 21200 22300 21800 21800
INDOOR AIRFLOW (CFM) 1085 1085 1110 1085 1110 1095 1095
SYSTEM POWER (KW) 3.10 3.10 3.12 3.10 3.12 3.13 3.13
SEER (BTU/WATT-HR.) 10.05 10.05 10.25 10.05 10.25 10.10 10.10
TXH025A4 TXH033A4
EXPANSIONTYPE CHG TO 65 CHGTO 65
RATINGS (COOLING) 1
BTUH (TOTAL) 26800 28200
BTUH (SENSIBLE) 17300 19600
INDOOR AIRFLOW (CFM) 900 1000
SYSTEM POWER (KW) 2.91 3.02
SEER (BTU/WATT-HR.) 10.00 10.15
CONDENSING UNIT WITH AIR HANDLERS
TVF025A14 TVF030A14 TVF036A14 TWE024C14 TWE030C14 TWE036C14 TWE042C14
EXPANSIONTYPE CHG TO 65 CHGTO 65 CHGTO 65 CHGTO 65 CHGTO 65 CHGTO 65 CHGTO 65
RATINGS (COOLING) 1
BTUH (TOTAL) 27600 28600 29400 26200 27400 28600 28800
BTUH (SENSIBLE) 19100 20700 22400 17100 18700 20200 21000
INDOOR AIRFLOW (CFM) 900 1000 1100 900 950 1070 1080
SYSTEM POWER (KW) 2.98 3.04 3.18 2.90 2.96 3.09 3.11
SEER (BTU/WATT-HR.) 10.20 10.40 10.15 10.00 10.20 10.20 10.20
TWG025A14 TWG030A14 TWG036A14
EXPANSIONTYPE CHG TO 65 CHGTO 65 CHGTO 65
RATINGS (COOLING) 1
BTUH (TOTAL) 26000 27200 28400
BTUH (SENSIBLE) 17300 18500 20000
INDOOR AIRFLOW (CFM) 900 1000 1060
SYSTEM POWER (KW) 2.77 2.94 3.09
SEER (BTU/WATT-HR.) 10.00 10.05 10.00
CONDENSING UNIT WITH FURNACES & COILS
ADD080R9V3 ADD080R9V3 ADD100R9V5 ADD100R9V5 AUD080R9V3 AUD080R9V3 AUD100R9V5
+TXC031E5 +TXC036E5 +TXC037E5 +TXC054E5 +TXC031E5 +TXC036E5 +TXC037E5
EXPANSIONTYPE TXV-B TXV-B TXV-B TXV-B TXV-B TXV-B TXV-B
RATINGS (COOLING) 1
BTUH (TOTAL) 29000 29600 30000 29800 29200 29800 30000
BTUH (SENSIBLE) 20200 20900 21500 21600 20600 21400 21600
INDOOR AIRFLOW (CFM) 950 950 975 975 975 1000 1000
SYSTEM POWER (KW) 2.84 2.86 2.86 2.84 2.88 2.89 2.87
SEER (BTU/WATT-HR.) 10.80 10.90 10.90 10.90 10.80 10.90 10.90
General Data — 7A0030A100A
✝
See pages 20 and 21 for combinations with Auxiliary Devices.

DATA SUBJECTTO CHANGEWITHOUT NOTICE
11
PRODUCT DATA
American Standard Inc., Tyler, TX 75711-9010
General Data — 7A0030A100A
✝
See pages 20 and 21 for combinations with Auxiliary Devices.
CONDENSING UNIT WITH FURNACES & COILS
AUD100R9V5 AUY080R9V3 AUY080R9V3 AUY100R9V4 AUY100R9V4
+TXC054E5 +TXC031E5 +TXC036E5 +TXC037E5 +TXC054E5
EXPANSIONTYPE TXV-B TXV-B TXV-B TXV-B TXV-B
RATINGS (COOLING) 1
BTUH (TOTAL) 29800 29200 29800 30000 29800
BTUH (SENSIBLE) 21700 20700 21400 21600 21700
INDOOR AIRFLOW (CFM) 1000 1000 1000 1000 1000
SYSTEM POWER (KW) 2.88 2.92 2.94 2.87 2.87
SEER (BTU/WATT-HR.) 10.90 10.75 10.75 10.90 10.90

12
DATA SUBJECTTO CHANGEWITHOUT NOTICE
PRODUCT DATA
American Standard Inc., Tyler, TX 75711-9010
1 CERTIFIED IN ACCORDANCEWITHTHE UNITARY AIR-CONDITIONER
EQUIPMENT CERTIFICATION PROGRAM,WHICH IS BASED ON A.R.I.
STANDARD 210/240.
2 RATED IN ACCORDANCEWITH A.R.I. STANDARD 270.
SPLIT SYSTEM
3 CALCULATED IN ACCORDANCEWITH NATL.ELECTRIC CODE. ONLY USE
HACR CIRCUIT BREAKERS OR FUSES.
4 STANDARD AIR - DRY COIL - OUTDOOR
5 THISVALUE APPROXIMATE.FOR MORE PRECISEVALUE SEE UNIT
NAMEPLATE AND SERVICE INSTRUCTION.
6 MAX.LINEAR LENGTH:80 FT WITH RECIPROCATING COMPRESSOR -
60 FTWITH SCROLL.MAX.LIFT - SUCTION 60 FT;MAX LIFT - LIQUID 60 FT.
FOR GREATER LENGTH REFER TO REFRIGERANT PIPING SOFTWARE
PUB.NO.12-3312-01.
7 THEVALUE SHOWN FOR COMPRESSOR RLA ONTHE UNIT NAMEPLATE
AND ONTHIS SPECIFICATION SHEET IS USEDTO COMPUTE MINIMUM
BRANCH CIRCUIT AMPACITY AND MAXIMUM FUSE SIZE. THE VALUE
SHOWN IS THE BRANCH CIRCUIT SELECTION CURRENT.
8 NO MEANS NO START COMPONENTS.
YES MEANS QUICK START KIT COMPONENTS.
PTC MEANS POSITIVETEMPERATURE COEFFICIENT STARTER.
General Data — 7A0036A100A
✝
See pages 21 and 22 for combinations with Auxiliary Devices.
OUTDOOR UNIT 12 7A0036A100A
POWER CONNS. —V/PH/HZ 3 200/230/1/60
MIN.BRCH.CIR.AMPACITY 22
BR.CIR. MAX. (AMPS) 35
PROT.RTG.}MIN. (AMPS) 30
NOISE RATING (DECIBELS) 2 78
COMPRESSOR DURATION™
NO.USED - NO.SPEEDS 1 - 1
VOLTS/PH/HZ 200/230/1/60
R.L. AMPS
7 - L.R. AMPS 16.4 - 88
FACTORY INSTALLED
START COMPONENTS 8 NO
INSULATION/SOUNDBLANKET NO
COMPRESSOR HEAT YES
OUTDOOR FAN — TYPE PROPELLER
DIA.(IN.) - NO.USED 18 - 1
TYPE DRIVE - NO. SPEEDS DIRECT - 1
CFM @ 0.0 IN.W.G.
4 2792
NO.MOTORS - HP 1 - 1/4
MOTOR SPEED R.P.M. 1075
VOLTS/PH/HZ 200/230/1/60
F.L. AMPS 1.50
OUTDOOR COIL — TYPE SPINE FIN™
ROWS - F.P.I. 1 - 24
FACE AREA (SQ.FT.) 14.83
TUBE SIZE (IN.) 3/8
REFRIGERANT
LBS.— R-22 (O.D.UNIT)
5 5-LBS.,8-OZ.
FACTORY SUPPLIED YES
LINE SIZE - IN.O.D.GAS 6 7/8
LINE SIZE - IN.O.D.LIQ.
6 3/8
FCCV
RESTRICTOR ORIFICE SIZE 0.071
DIMENSIONS H X W X D
OUTDOOR UNIT - CRATED (IN.) 31-1/2X31-1/2 X27-5/8
UNCRATED SEE OUTLINE DWG.
WEIGHT
SHIPPING (LBS.) 193
NET (LBS.) 173
CONDENSING UNIT WITH COOLING COILS
CCBA36A4ACC CCBB36A4ACC CCBB42A4ACC CUBA36A4ACC CUBB36A4ACC CUBB42A4ACC TXA030C4
EXPANSIONTYPE FIXED ORIFICE FIXED ORIFICE FIXED ORIFICE FIXED ORIFICE FIXED ORIFICE FIXED ORIFICE CHGTO 71
RATINGS (COOLING) 1
BTUH (TOTAL) 33800 34200 34200 33800 34200 34200 33800
BTUH (SENSIBLE) 21800 22800 23800 21800 22800 23800 21800
INDOOR AIRFLOW (CFM) 1100 1100 1200 1100 1100 1200 1100
SYSTEM POWER (KW) 3.61 3.64 3.68 3.61 3.64 3.68 3.61
SEER (BTU/WATT-HR.) 10.05 10.05 10.05 10.05 10.05 10.05 10.05
TXA031C4 TXA035C4 TXA036C4 TXA037C4 TXA042C4 TXA043C4 TXA048C4
EXPANSIONTYPE CHG TO 71 FACT INS 71 FACT INS 71 FACT INS 71 CHGTO 71 CHGTO 71 CHGTO 71
RATINGS (COOLING) 1
BTUH (TOTAL) 34200 33800 35600 35400 36000 36200 36800
BTUH (SENSIBLE) 22800 21800 24400 24300 25100 25900 26600
INDOOR AIRFLOW (CFM) 1100 1100 1200 1200 1250 1350 1350
SYSTEM POWER (KW) 3.64 3.61 3.83 3.73 3.79 3.83 3.85
SEER (BTU/WATT-HR.) 10.05 10.05 10.00 10.10 10.15 10.05 10.10
TXA049C4 TXA050C4 TXC030C4 TXC030D4 TXC031C4 TXC031D4 TXC031E5
EXPANSIONTYPE CHG TO 71 CHGTO 71 CHGTO 71 CHGTO 71 CHGTO 71 CHGTO 71 TXV-B
RATINGS (COOLING) 1
BTUH (TOTAL) 36800 36800 33800 33800 34200 34200 35200
BTUH (SENSIBLE) 26600 26600 21800 21800 22800 22800 23600
INDOOR AIRFLOW (CFM) 1350 1350 1100 1100 1100 1100 1100
SYSTEM POWER (KW) 3.85 3.85 3.61 3.61 3.64 3.64 3.65
SEER (BTU/WATT-HR.) 10.10 10.10 10.05 10.05 10.05 10.05 10.40

DATA SUBJECTTO CHANGEWITHOUT NOTICE
13
PRODUCT DATA
American Standard Inc., Tyler, TX 75711-9010
General Data — 7A0036A100A
✝
See pages 21 and 22 for combinations with Auxiliary Devices.
CONDENSING UNIT WITH COOLING COILS
TXC035C4 TXC035D4 TXC036C4 TXC036D4 TXC036E5 TXC037C4 TXC037E5
EXPANSIONTYPE FACT INS 71 FACT INS 71 FACT INS 71 FACT INS 71 TXV-B FACT INS 71 TXV-B
RATINGS (COOLING) 1
BTUH (TOTAL) 33800 33800 35600 35600 36200 35400 36200
BTUH (SENSIBLE) 21800 21800 24400 24400 25100 24300 25100
INDOOR AIRFLOW (CFM) 1100 1100 1200 1200 1200 1200 1200
SYSTEM POWER (KW) 3.61 3.61 3.83 3.83 3.73 3.73 3.73
SEER (BTU/WATT-HR.) 10.05 10.05 10.00 10.00 10.40 10.10 10.40
TXC042C4 TXC043C4 TXC048C4 TXC049C4 TXC050C4 TXC054E5 TXH033A4
EXPANSIONTYPE CHG TO 71 CHGTO 71 CHGTO 71 CHGTO 71 CHGTO 71 TXV-B CHGTO 71
RATINGS (COOLING) 1
BTUH (TOTAL) 36000 36200 36800 36800 36800 36600 34000
BTUH (SENSIBLE) 25100 25900 26600 26600 26600 26800 22800
INDOOR AIRFLOW (CFM) 1250 1350 1350 1350 1350 1350 1125
SYSTEM POWER (KW) 3.79 3.83 3.85 3.85 3.85 3.81 3.60
SEER (BTU/WATT-HR.) 10.15 10.05 10.10 10.10 10.10 10.25 10.15
CONDENSING UNIT W/COOLING COILS CONDENSING UNIT W/AIR HANDLERS
TXH041A4 TVF030A14 TVF036A14 TWE030C14
EXPANSIONTYPE CHG TO 71 CHGTO 71 FACT INS 71 CHG TO 71
RATINGS (COOLING) 1
BTUH (TOTAL) 36600 34800 36000 32600
BTUH (SENSIBLE) 26100 24000 25400 21000
INDOOR AIRFLOW (CFM) 1350 1125 1200 950
SYSTEM POWER (KW) 3.79 3.74 3.83 3.49
SEER (BTU/WATT-HR.) 10.25 10.20 10.25 10.20
TWE036C14 TWE042C14 TWE048C14-B TWG030A14 TWG036A14 TWG037A14 TWG042A14
EXPANSIONTYPE FACT INS 71 CHGTO 71 CHGTO 71 CHGTO 71 FACT INS 71 FACT INS 71 CHG TO 71
RATINGS (COOLING) 1
BTUH (TOTAL) 35200 35200 37000 32400 33800 34200 34600
BTUH (SENSIBLE) 23700 24100 26300 21100 22400 22900 24100
INDOOR AIRFLOW (CFM) 1200 1200 1350 1100 1150 1200 1295
SYSTEM POWER (KW) 3.74 3.74 3.94 3.45 3.69 3.62 3.68
SEER (BTU/WATT-HR.) 10.30 10.25 10.25 10.00 10.00 10.00 10.15
CONDENSING UNIT WITH FURNACES & COILS
ADD080R9V3 ADD080R9V3 ADD100R9V5 ADD100R9V5 AUD080R9V3 AUD080R9V3 AUD100R9V5
+TXC031E5 +TXC036E5 +TXC037E5 +TXC054E5 +TXC031E5 +TXC036E5 +TXC037E5
EXPANSIONTYPE TXV-B TXV-B TXV-B TXV-B TXV-B TXV-B TXV-B
RATINGS (COOLING) 1
BTUH (TOTAL) 35600 36400 36800 36600 35800 36400 36800
BTUH (SENSIBLE) 24000 24900 25600 25800 24500 25300 25700
INDOOR AIRFLOW (CFM) 1125 1125 1175 1175 1200 1200 1200
SYSTEM POWER (KW) 3.56 3.57 3.52 3.50 3.65 3.68 3.57
SEER (BTU/WATT-HR.) 10.90 10.90 10.90 10.90 10.85 10.90 10.90
AUD100R9V5 AUY080R9V3 AUY080R9V3 AUY100R9V4 AUY100R9V4
+TXC054E5 +TXC031E5 +TXC036E5 +TXC037E5 +TXC054E5
EXPANSIONTYPE TXV-B TXV-B TXV-B TXV-B TXV-B
RATINGS (COOLING) 1
BTUH (TOTAL) 36600 35200 36000 36400 36200
BTUH (SENSIBLE) 25800 23900 24900 25400 25600
INDOOR AIRFLOW (CFM) 1200 1150 1150 1175 1175
SYSTEM POWER (KW) 3.55 3.56 3.58 3.48 3.48
SEER (BTU/WATT-HR.) 10.90 10.80 10.90 10.90 10.90

14
DATA SUBJECTTO CHANGEWITHOUT NOTICE
PRODUCT DATA
American Standard Inc., Tyler, TX 75711-9010
1 CERTIFIED IN ACCORDANCEWITHTHE UNITARY AIR-CONDITIONER
EQUIPMENT CERTIFICATION PROGRAM,WHICH IS BASED ON A.R.I.
STANDARD 210/240.
2 RATED IN ACCORDANCEWITH A.R.I. STANDARD 270.
SPLIT SYSTEM
3 CALCULATED IN ACCORDANCEWITH NATL.ELECTRIC CODE. ONLY USE
HACR CIRCUIT BREAKERS OR FUSES.
4 STANDARD AIR - DRY COIL - OUTDOOR
5 THISVALUE APPROXIMATE.FOR MORE PRECISEVALUE SEE UNIT
NAMEPLATE AND SERVICE INSTRUCTION.
6 MAX.LINEAR LENGTH:80 FT WITH RECIPROCATING COMPRESSOR -
60 FTWITH SCROLL.MAX.LIFT - SUCTION 60 FT;MAX LIFT - LIQUID 60 FT.
FOR GREATER LENGTH REFER TO REFRIGERANT PIPING SOFTWARE
PUB.NO.12-3312-01.
7 THEVALUE SHOWN FOR COMPRESSOR RLA ONTHE UNIT NAMEPLATE
AND ONTHIS SPECIFICATION SHEET IS USEDTO COMPUTE MINIMUM
BRANCH CIRCUIT AMPACITY AND MAXIMUM FUSE SIZE. THE VALUE
SHOWN IS THE BRANCH CIRCUIT SELECTION CURRENT.
8 NO MEANS NO START COMPONENTS.
YES MEANS QUICK START KIT COMPONENTS.
PTC MEANS POSITIVETEMPERATURE COEFFICIENT STARTER.
OUTDOOR UNIT 12 7A0042A100A
POWER CONNS. —V/PH/HZ 3 200/230/01/60
MIN.BRCH.CIR.AMPACITY 25
BR.CIR. MAX. (AMPS) 40
PROT.RTG.}MIN. (AMPS) 40
NOISE RATING (DECIBELS) 2 80
COMPRESSOR DURATION™
NO.USED - NO.SPEEDS 1 - 1
VOLTS/PH/HZ 200/230/1/60
R.L. AMPS
7 - L.R. AMPS 19.0 - 105
FACTORY INSTALLED
START COMPONENTS 8 NO
INSULATION/SOUNDBLANKET NO
COMPRESSOR HEAT NO
OUTDOOR FAN — TYPE PROPELLER
DIA.(IN.) - NO.USED 18 - 1
TYPE DRIVE - NO. SPEEDS DIRECT - 1
CFM @ 0.0 IN.W.G.
4 2685
NO.MOTORS - HP 1 - 1/4
MOTOR SPEED R.P.M. 1075
VOLTS/PH/HZ 200/230/1/60
F.L. AMPS 1.50
OUTDOOR COIL — TYPE SPINE FIN™
ROWS - F.P.I. 1 - 24
FACE AREA (SQ.FT.) 12.47
TUBE SIZE (IN.) 3/8
REFRIGERANT
LBS.— R-22 (O.D.UNIT)
5 5-LBS.,6-OZ.
FACTORY SUPPLIED YES
LINE SIZE - IN.O.D.GAS 6 7/8
LINE SIZE - IN.O.D.LIQ.
6 3/8
FCCV
RESTRICTOR ORIFICE SIZE 0.077
DIMENSIONS H X W X D
OUTDOOR UNIT - CRATED (IN.) 27-3/8X31-1/2 X27-5/8
UNCRATED SEE OUTLINE DWG.
WEIGHT
SHIPPING (LBS.) 212
NET (LBS.) 194
CONDENSING UNIT WITH COOLING COILS
CCBB42A4ACC CCBB48A4ACC CCBC48A4ACC CUBB42A4ACC CUBB48A4ACC CUBC48A4ACC TXA035C4
EXPANSIONTYPE FIXED ORIFICE FIXED ORIFICE FIXED ORIFICE FIXED ORIFICE FIXED ORIFICE FIXED ORIFICE CHGTO 77
RATINGS (COOLING) 1
BTUH (TOTAL) 39000 39000 40500 39000 39000 40500 37200
BTUH (SENSIBLE) 25800 26300 28900 25800 26300 28900 23400
INDOOR AIRFLOW (CFM) 1200 1250 1505 1200 1250 1505 1100
SYSTEM POWER (KW) 4.22 4.24 4.45 4.22 4.24 4.45 4.09
SEER (BTU/WATT-HR.) 10.05 10.00 10.00 10.05 10.00 10.00 10.00
TXA036C4 TXA037C4 TXA042C4 TXA043C4 TXA048C4 TXA049C4 TXA050C4
EXPANSIONTYPE CHG TO 77 CHGTO 77 CHGTO 77 CHGTO 77 CHGTO 77 CHGTO 77 CHGTO 77
RATINGS (COOLING) 1
BTUH (TOTAL) 39000 40000 40000 40500 41000 41500 41500
BTUH (SENSIBLE) 25700 27100 26800 27900 28200 30000 30000
INDOOR AIRFLOW (CFM) 1200 1350 1250 1400 1350 1555 1555
SYSTEM POWER (KW) 4.22 4.32 4.30 4.38 4.39 4.49 4.49
SEER (BTU/WATT-HR.) 10.05 10.00 10.00 10.05 10.10 10.00 10.00
TXA060C5 TXA061C5 TXC035C4 TXC035D4 TXC036C4 TXC036D4 TXC036E5
EXPANSIONTYPE TXV-B TXV-B CHGTO 77 CHGTO 77 CHGTO 77 CHGTO 77 TXV-B
RATINGS (COOLING) 1
BTUH (TOTAL) 41500 42000 37200 37200 39000 39000 41000
BTUH (SENSIBLE) 30300 30600 23400 23400 25700 25700 28100
INDOOR AIRFLOW (CFM) 1555 1575 1100 1100 1200 1200 1350
SYSTEM POWER (KW) 4.46 4.47 4.09 4.09 4.22 4.22 4.34
SEER (BTU/WATT-HR.) 10.00 10.10 10.00 10.00 10.05 10.05 10.15
General Data — 7A0042A100A
✝
See page 22 for combinations with Auxiliary Devices.

DATA SUBJECTTO CHANGEWITHOUT NOTICE
15
PRODUCT DATA
American Standard Inc., Tyler, TX 75711-9010
General Data — 7A0042A100A
✝
See page 22 for combinations with Auxiliary Devices.
CONDENSING UNIT WITH COOLING COILS
TXC037C4 TXC037E5 TXC042C4 TXC043C4 TXC048C4 TXC049C4 TXC050C4
EXPANSIONTYPE CHG TO 77 TXV-B CHGTO 77 CHGTO 77 CHGTO 77 CHGTO 77 CHGTO 77
RATINGS (COOLING) 1
BTUH (TOTAL) 40000 41000 40000 40500 41000 41500 41500
BTUH (SENSIBLE) 27100 28100 26800 27900 28200 30000 30000
INDOOR AIRFLOW (CFM) 1350 1350 1250 1400 1350 1555 1555
SYSTEM POWER (KW) 4.32 4.34 4.30 4.38 4.39 4.49 4.49
SEER (BTU/WATT-HR.) 10.00 10.15 10.00 10.05 10.10 10.00 10.00
TXC054E5 TXC060C5 TXC061C5 TXH033A4 TXH041A4 TXH054A4
EXPANSIONTYPE TXV-B TXV-B TXV-B CHG TO 77 CHGTO 77 CHGTO 77
RATINGS (COOLING) 1
BTUH (TOTAL) 41500 41500 42000 37600 41000 43500
BTUH (SENSIBLE) 30300 30300 30600 24400 28000 32400
INDOOR AIRFLOW (CFM) 1555 1555 1575 1125 1400 1575
SYSTEM POWER (KW) 4.46 4.46 4.47 4.13 4.39 4.63
SEER (BTU/WATT-HR.) 10.00 10.00 10.10 10.00 10.15 10.20
CONDENSING UNIT WITH AIR HANDLERS
TWE036C14 TWE042C14 TWE048C14-B TWE060A-B TWG037A14 TWG042A14
EXPANSIONTYPE CHG TO 77 CHGTO 77 CHGTO 77 TXV-B CHGTO 77 CHGTO 77
RATINGS (COOLING) 1
BTUH (TOTAL) 39500 40000 42000 41500 38500 39000
BTUH (SENSIBLE) 26200 27100 29900 30100 25200 26400
INDOOR AIRFLOW (CFM) 1350 1350 1570 1550 1275 1400
SYSTEM POWER (KW) 4.39 4.37 4.59 4.32 4.25 4.33
SEER (BTU/WATT-HR.) 10.00 10.05 10.10 10.35 10.00 10.00
CONDENSING UNIT WITH FURNACES & COILS
ADD080R9V3 ADD100R9V5 ADD100R9V5 AUD080R9V3 AUD100R9V5 AUD100R9V5 AUY100R9V4
+TXC036E5 +TXC037E5 +TXC054E5 +TXC036E5 +TXC037E5 +TXC054E5 +TXC037E5
EXPANSIONTYPE TXV-B TXV-B TXV-B TXV-B TXV-B TXV-B TXV-B
RATINGS (COOLING) 1
BTUH (TOTAL) 41000 41500 41500 41000 41500 41000 41500
BTUH (SENSIBLE) 28000 28800 29200 28500 28900 28900 28700
INDOOR AIRFLOW (CFM) 1325 1400 1400 1400 1400 1400 1375
SYSTEM POWER (KW) 4.27 4.26 4.26 4.36 4.32 4.27 4.26
SEER (BTU/WATT-HR.) 10.60 10.85 10.80 10.35 10.60 10.60 10.65
AUY100R9V4
+TXC054E5
EXPANSIONTYPE TXV-B
RATINGS (COOLING) 1
BTUH (TOTAL) 41000
BTUH (SENSIBLE) 28700
INDOOR AIRFLOW (CFM) 1375
SYSTEM POWER (KW) 4.21
SEER (BTU/WATT-HR.) 10.60

16
DATA SUBJECTTO CHANGEWITHOUT NOTICE
PRODUCT DATA
American Standard Inc., Tyler, TX 75711-9010
1 CERTIFIED IN ACCORDANCEWITHTHE UNITARY AIR-CONDITIONER
EQUIPMENT CERTIFICATION PROGRAM,WHICH IS BASED ON A.R.I.
STANDARD 210/240.
2 RATED IN ACCORDANCEWITH A.R.I. STANDARD 270.
SPLIT SYSTEM
3 CALCULATED IN ACCORDANCEWITH NATL.ELECTRIC CODE. ONLY USE
HACR CIRCUIT BREAKERS OR FUSES.
4 STANDARD AIR - DRY COIL - OUTDOOR
5 THISVALUE APPROXIMATE.FOR MORE PRECISEVALUE SEE UNIT
NAMEPLATE AND SERVICE INSTRUCTION.
6 MAX.LINEAR LENGTH:80 FT WITH RECIPROCATING COMPRESSOR -
60 FTWITH SCROLL.MAX.LIFT - SUCTION 60 FT;MAX LIFT - LIQUID 60 FT.
FOR GREATER LENGTH REFER TO REFRIGERANT PIPING SOFTWARE
PUB.NO.12-3312-01.
7 THEVALUE SHOWN FOR COMPRESSOR RLA ONTHE UNIT NAMEPLATE
AND ONTHIS SPECIFICATION SHEET IS USEDTO COMPUTE MINIMUM
BRANCH CIRCUIT AMPACITY AND MAXIMUM FUSE SIZE. THE VALUE
SHOWN IS THE BRANCH CIRCUIT SELECTION CURRENT.
8 NO MEANS NO START COMPONENTS.
YES MEANS QUICK START KIT COMPONENTS.
PTC MEANS POSITIVETEMPERATURE COEFFICIENT STARTER.
OUTDOOR UNIT 12 7A0048B100A
POWER CONNS. —V/PH/HZ 3 208/230/01/60
MIN.BRCH.CIR.AMPACITY 30
BR.CIR. MAX. (AMPS) 50
PROT.RTG.}MIN. (AMPS) 40
NOISE RATING (DECIBELS) 2 76
COMPRESSOR DURATION™ - SCROLL
NO.USED - NO.SPEEDS 1 - 1
VOLTS/PH/HZ 208/230/1/60
R.L. AMPS
7 - L.R. AMPS 23.1 - 131
FACTORY INSTALLED
START COMPONENTS 8 PTC
INSULATION/SOUNDBLANKET NO
COMPRESSOR HEAT NO
OUTDOOR FAN — TYPE PROPELLER
DIA.(IN.) - NO.USED 18 - 1
TYPE DRIVE - NO. SPEEDS DIRECT - 1
CFM @ 0.0 IN.W.G.
4 2875
NO.MOTORS - HP 1 - 1/4
MOTOR SPEED R.P.M. 1075
VOLTS/PH/HZ 200/230/1/60
F.L. AMPS 1.50
OUTDOOR COIL — TYPE SPINE FIN™
ROWS - F.P.I. 1 - 24
FACE AREA (SQ.FT.) 17.19
TUBE SIZE (IN.) 3/8
REFRIGERANT
LBS.— R-22 (O.D.UNIT)
5 6-LBS.,1-OZ.
FACTORY SUPPLIED YES
LINE SIZE - IN.O.D.GAS 6 11/8
LINE SIZE - IN.O.D.LIQ.
6 3/8
FCCV
RESTRICTOR ORIFICE SIZE 0.083
DIMENSIONS H X W X D
OUTDOOR UNIT - CRATED (IN.) 35-3/4X31-1/2 X27-5/8
UNCRATED SEE OUTLINE DWG.
WEIGHT
SHIPPING (LBS.) 198
NET (LBS.) 177
CONDENSING UNIT WITH COOLING COILS
CCBB48A4ACC CCBC48A4ACC CCBC60A4ACC CCBD60A5ACC CUBB48A4ACC CUBC48A4ACC CUBC60A4ACC
EXPANSIONTYPE FIXED ORIFICE FIXED ORIFICE FIXED ORIFICE TXV-B FIXED ORIFICE FIXED ORIFICE FIXED ORIFICE
RATINGS (COOLING) 1
BTUH (TOTAL) 44500 46500 46000 47500 44500 46500 46000
BTUH (SENSIBLE) 28700 31600 32400 34300 28700 31600 32400
INDOOR AIRFLOW (CFM) 1250 1600 1675 1780 1250 1600 1675
SYSTEM POWER (KW) 4.76 5.00 4.97 5.05 4.76 5.00 4.97
SEER (BTU/WATT-HR.) 10.00 10.05 10.00 10.10 10.00 10.05 10.00
CUBD60A5ACC TXA042C4 TXA043C4 TXA048C4 TXA049C4 TXA050C4 TXA060C5
EXPANSIONTYPE TXV-B CHGTO 83 CHGTO 83 FACT INS 83 FACT INS 83 FACT INS 83 TXV-B
RATINGS (COOLING) 1
BTUH (TOTAL) 47500 44500 46000 46000 47500 47500 47500
BTUH (SENSIBLE) 34300 28700 31200 30300 32700 32700 33600
INDOOR AIRFLOW (CFM) 1780 1250 1575 1350 1600 1600 1700
SYSTEM POWER (KW) 5.05 4.76 4.95 4.89 5.16 5.16 5.05
SEER (BTU/WATT-HR.) 10.10 10.15 10.05 10.15 10.00 10.55 10.15
TXA061C5 TXC042C4 TXC043C4 TXC048C4 TXC049C4 TXC050C4 TXC054E5
EXPANSIONTYPE TXV-B CHGTO 83 CHGTO 83 FACT INS 83 FACT INS 83 FACT INS 83 TXV-B
RATINGS (COOLING) 1
BTUH (TOTAL) 48000 44500 46000 46000 47500 47500 47000
BTUH (SENSIBLE) 34400 28700 31200 30300 32700 32700 32600
INDOOR AIRFLOW (CFM) 1800 1250 1575 1350 1600 1600 1600
SYSTEM POWER (KW) 5.08 4.76 4.95 4.89 5.16 5.16 4.97
SEER (BTU/WATT-HR.) 10.20 10.15 10.05 10.15 10.00 10.55 10.15
General Data — 7A0048B100A
✝
See pages 22 and 23 for combinations with Auxiliary Devices.

DATA SUBJECTTO CHANGEWITHOUT NOTICE
17
PRODUCT DATA
American Standard Inc., Tyler, TX 75711-9010
CONDENSING UNIT WITH COOLING COILS
TXC054S3 TXC060C5 TXC061C5 TXC065S3 TXH041A4 TXH054A4 TXH063P3
EXPANSIONTYPE TXV-NB TXV-B TXV-B TXV-NB CHGTO 83 FACT INS 83 TXV-NB
RATINGS (COOLING) 1
BTUH (TOTAL) 47000 47500 48000 48500 47000 49000 49500
BTUH (SENSIBLE) 33300 33600 34400 35300 31600 34400 37000
INDOOR AIRFLOW (CFM) 1700 1700 1800 1800 1575 1600 1800
SYSTEM POWER (KW) 5.00 5.05 5.08 5.11 5.00 5.10 5.13
SEER (BTU/WATT-HR.) 10.50 10.15 10.20 10.65 10.20 10.30 10.80
CONDENSING UNIT WITH AIR HANDLERS
TWE040E13 TWE042C14-B TWE042P13 TWE048C14-B TWE048P13 TWE060C15-C/D TWE060P13
EXPANSIONTYPE TXV-NB CHGTO 83 TXV-NB FACT INS 83 TXV-NB TXV-B TXV-NB
RATINGS (COOLING) 1
BTUH (TOTAL) 48000 46000 46500 47500 49000 47500 49500
BTUH (SENSIBLE) 33000 30500 31500 32200 35000 33800 37200
INDOOR AIRFLOW (CFM) 1425 1575 1575 1600 1600 1780 1800
SYSTEM POWER (KW) 4.80 5.08 5.03 5.11 5.10 5.31 5.18
SEER (BTU/WATT-HR.) 10.90 10.00 10.30 10.25 10.70 10.00 10.60
TWE063P13 TWE065E13 TWG042A14 TWG048A14 TWG060A15
EXPANSIONTYPE TXV-NB TXV-NB CHGTO 83 FACT INS 83 TXV-B
RATINGS (COOLING) 1
BTUH (TOTAL) 49500 49000 44000 47000 47500
BTUH (SENSIBLE) 37300 33600 28900 31600 33900
INDOOR AIRFLOW (CFM) 1800 1375 1475 1600 1780
SYSTEM POWER (KW) 5.35 4.73 4.89 5.08 5.19
SEER (BTU/WATT-HR.) 10.25 10.90 10.00 10.25 10.05
CONDENSING UNIT WITH FURNACES & COILS
ADD100R9V5 ADD100R9V5 ADD100R9V5 ADD120R9V5 AUD100R9V5 AUD100R9V5 AUD100R9V5
+TXC054E5 +TXC054S3 +TXH063P3 +TXH063P3 +TXC054E5 +TXC054S3 +TXC065S3
EXPANSIONTYPE TXV-B TXV-NB TXV-NB TXV-NB TXV-B TXV-NB TXV-NB
RATINGS (COOLING) 1
BTUH (TOTAL) 47000 47000 49500 50000 47000 47000 48000
BTUH (SENSIBLE) 32900 32900 35500 36200 33200 33200 32300
INDOOR AIRFLOW (CFM) 1625 1625 1600 1625 1675 1675 1400
SYSTEM POWER (KW) 4.90 4.90 4.95 4.93 4.97 4.97 4.75
SEER (BTU/WATT-HR.) 10.70 10.70 10.90 10.90 10.50 10.50 10.90
AUD100R9V5H AUD140R9V5 AUD140R9V5H AUY100R9V4 AUY100R9V4 AUY120R9V5
+TXH063P3 +TXC065S3 +TXH063P3 +TXC054E5 +TXC054S3 +TXC065S3
EXPANSIONTYPE TXV-NB TXV-NB TXV-NB TXV-B TXV-NB TXV-NB
RATINGS (COOLING) 1
BTUH (TOTAL) 49000 46500 48500 47000 47000 48000
BTUH (SENSIBLE) 35000 30100 34200 32600 32600 33500
INDOOR AIRFLOW (CFM) 1600 1125 1550 1600 1600 1600
SYSTEM POWER (KW) 5.00 4.56 5.11 4.95 4.95 4.97
SEER (BTU/WATT-HR.) 10.90 10.90 10.60 10.50 10.55 10.75
General Data — 7A0048B100A
✝
See pages 22 and 23 for combinations with Auxiliary Devices.

18
DATA SUBJECTTO CHANGEWITHOUT NOTICE
PRODUCT DATA
American Standard Inc., Tyler, TX 75711-9010
1 CERTIFIED IN ACCORDANCEWITHTHE UNITARY AIR-CONDITIONER
EQUIPMENT CERTIFICATION PROGRAM,WHICH IS BASED ON A.R.I.
STANDARD 210/240.
2 RATED IN ACCORDANCEWITH A.R.I. STANDARD 270.
SPLIT SYSTEM
3 CALCULATED IN ACCORDANCEWITH NATL.ELECTRIC CODE. ONLY USE
HACR CIRCUIT BREAKERS OR FUSES.
4 STANDARD AIR - DRY COIL - OUTDOOR
5 THISVALUE APPROXIMATE.FOR MORE PRECISEVALUE SEE UNIT
NAMEPLATE AND SERVICE INSTRUCTION.
6 MAX.LINEAR LENGTH:80 FT WITH RECIPROCATING COMPRESSOR -
60 FTWITH SCROLL.MAX.LIFT - SUCTION 60 FT;MAX LIFT - LIQUID 60 FT.
FOR GREATER LENGTH REFER TO REFRIGERANT PIPING SOFTWARE
PUB.NO.12-3312-01.
7 THEVALUE SHOWN FOR COMPRESSOR RLA ONTHE UNIT NAMEPLATE
AND ONTHIS SPECIFICATION SHEET IS USEDTO COMPUTE MINIMUM
BRANCH CIRCUIT AMPACITY AND MAXIMUM FUSE SIZE. THE VALUE
SHOWN IS THE BRANCH CIRCUIT SELECTION CURRENT.
8 NO MEANS NO START COMPONENTS.
YES MEANS QUICK START KIT COMPONENTS.
PTC MEANS POSITIVETEMPERATURE COEFFICIENT STARTER.
OUTDOOR UNIT 12 7A0060B100A
POWER CONNS. —V/PH/HZ 3 208/230/01/60
MIN.BRCH.CIR.AMPACITY 40
BR.CIR. MAX. (AMPS) 60
PROT.RTG.}MIN. (AMPS) 50
NOISE RATING (DECIBELS) 2 79
COMPRESSOR DURATION™-SCROLL
NO.USED - NO.SPEEDS 1 - 1
VOLTS/PH/HZ 208/230/1/60
R.L. AMPS
7 - L.R. AMPS 30.6 - 175
FACTORY INSTALLED
START COMPONENTS 8
INSULATION/SOUNDBLANKET NO
COMPRESSOR HEAT YES
OUTDOOR FAN — TYPE PROPELLER
DIA.(IN.) - NO.USED 22 - 1
TYPE DRIVE - NO. SPEEDS DIRECT - 1
CFM @ 0.0 IN.W.G.
4 3884
NO.MOTORS - HP 1 - 1/4
MOTOR SPEED R.P.M. 825
VOLTS/PH/HZ 200/230/1/60
F.L. AMPS 1.90
OUTDOOR COIL — TYPE SPINE FIN™
ROWS - F.P.I. 1 - 24
FACE AREA (SQ.FT.) 20.93
TUBE SIZE (IN.) 3/8
REFRIGERANT
LBS.— R-22 (O.D.UNIT)
5 7-LBS.,12-OZ.
FACTORY SUPPLIED YES
LINE SIZE - IN.O.D.GAS 6 11/8
LINE SIZE - IN.O.D.LIQ.
6 3/8
FCCV
RESTRICTOR ORIFICE SIZE 0.092
DIMENSIONS H X W X D
OUTDOOR UNIT - CRATED (IN.) 35-3/4X36-3/4 X32-1/2
UNCRATED SEE OUTLINE DWG.
WEIGHT
SHIPPING (LBS.) 252
NET (LBS.) 229
CONDENSING UNIT WITH COOLING COILS
TXA060C5 TXA061C5 TXC054S3 TXC060C5 TXC061C5 TXC065S3 TXH054A4
EXPANSIONTYPE TXV-B TXV-B TXV-NB TXV-B TXV-B TXV-NB CHG TO 92
RATINGS (COOLING) 1
BTUH (TOTAL) 57000 59500 56000 57000 59500 59500 60000
BTUH (SENSIBLE) 37500 39400 37000 37500 39400 40800 39800
INDOOR AIRFLOW (CFM) 1700 1800 1700 1700 1800 2000 1700
SYSTEM POWER (KW) 6.23 6.65 6.22 6.23 6.65 6.43 6.42
SEER (BTU/WATT-HR.) 10.00 10.00 10.20 10.00 10.00 10.40 10.15
TXH063P3
EXPANSIONTYPE TXV-NB
RATINGS (COOLING) 1
BTUH (TOTAL) 61000
BTUH (SENSIBLE) 43100
INDOOR AIRFLOW (CFM) 2000
SYSTEM POWER (KW) 6.49
SEER (BTU/WATT-HR.) 10.55
CONDENSING UNIT WITH AIR HANDLERS
TWE048C14-B TWE048P13 TWE060C15-C/D TWE060P13 TWE063P13 TWE065E13 TWE090A-B
EXPANSIONTYPE CHGTO 92 TXV-NB TXV-B TXV-NB TXV-NB TXV-NB TXV-NB
RATINGS (COOLING) 1
BTUH (TOTAL) 57500 60000 58000 60500 60500 61500 61500
BTUH (SENSIBLE) 37500 41000 38900 41300 41500 43000 44500
INDOOR AIRFLOW (CFM) 1800 1800 1950 1800 1825 1875 2250
SYSTEM POWER (KW) 6.46 6.42 6.63 6.47 6.65 6.41 6.28
SEER (BTU/WATT-HR.) 10.00 10.50 9.70 10.50 10.15 10.80 10.90
General Data — 7A0060B100A
✝
See page 23 for combinations with Auxiliary Devices.

DATA SUBJECTTO CHANGEWITHOUT NOTICE
19
PRODUCT DATA
American Standard Inc., Tyler, TX 75711-9010
CONDENSING UNIT WITH AIR HANDLERS
TWG048A14 TWG060A15
EXPANSIONTYPE CHG TO 92 TXV-B
RATINGS (COOLING) 1
BTUH (TOTAL) 56500 58500
BTUH (SENSIBLE) 36100 39400
INDOOR AIRFLOW (CFM) 1625 2000
SYSTEM POWER (KW) 6.28 6.57
SEER (BTU/WATT-HR.) 10.05 10.00
CONDENSING UNIT WITH FURNACES & COILS
ADD100R9V5
+TXC054S3
EXPANSIONTYPE TXV-NB
RATINGS (COOLING) 1
BTUH (TOTAL) 57500
BTUH (SENSIBLE) 39400
INDOOR AIRFLOW (CFM) 2000
SYSTEM POWER (KW) 6.39
SEER (BTU/WATT-HR.) 10.10
General Data — 7A0060B100A
✝
See page 23 for combinations with Auxiliary Devices.

Ratings with
Auxiliary Devices
FAN
OUTDOOR INDOOR DELAY TXV COOLING
MODEL MODEL KIT KIT CFM SEER CAPACITY
FAN
OUTDOOR INDOOR DELAY TXV COOLING
MODEL MODEL KIT KIT CFM SEER CAPACITY
COMBINATIONSWITH FAN DELAY RELAY KIT AND/ORTXV KIT AND/OR INSULATION KIT
✝
When these models are matched with an indoor air handler or coil that has a flow control check valve or expansion valve flow control, the addition of an indoor fan delay relay kit
and/or TXV kit may increase the system SEER. See charts below for ratings.
20
DATA SUBJECTTO CHANGEWITHOUT NOTICE
PRODUCT DATA
American Standard Inc., Tyler, TX 75711-9010
* START KIT REQUIRED
7A0018A100A CCBA18A4ACC Y N 600 10.30 17200
7A0018A100A CCBA24A4ACC Y N 640 10.80 17100
7A0018A100A CUBA18A4ACC Y N 600 10.30 17200
7A0018A100A CUBA24A4ACC Y N 640 10.80 17100
7A0018A100A * TWE030P13 N N 675 10.80 18000
7A0018A100A * TWE031E13 N N 650 10.90 18200
7A0018A100A TXA018C4 Y N 600 10.30 17200
7A0018A100A TXA024C4 Y N 645 10.50 17300
7A0018A100A TXA025C4 Y N 660 10.55 17600
7A0018A100A TXC018C4 Y N 600 10.30 17200
7A0018A100A TXC024C4 Y N 645 10.50 17300
7A0018A100A TXC024D4 Y N 645 10.50 17300
7A0018A100A TXC025C4 Y N 660 10.55 17600
7A0018A100A TXC025D4 Y N 660 10.55 17600
7A0018A100A * TXC031S3 N N 675 10.90 18200
7A0018A100A TXH025A4 Y N 670 10.85 17900
7A0018A100A TXH025A4 Y Y 660 10.90 17700
7A0024A100A CCBA24A4ACC Y N 800 10.20 22400
7A0024A100A CCBA30A4ACC Y N 815 10.20 21800
7A0024A100A CCBB30A4ACC Y N 840 10.35 22400
7A0024A100A CUBA24A4ACC Y N 800 10.20 22400
7A0024A100A CUBA30A4ACC Y N 815 10.20 21800
7A0024A100A CUBB30A4ACC Y N 840 10.35 22400
7A0024A100A * ADD080R9V3 - N 775 10.80 23800
+TXC031S3
7A0024A100A * ADD080R9V3 - N 775 10.90 24400
+TXC036S3
7A0024A100A * ADD100R9V5 - N 800 10.90 24400
+TXC037S3
7A0024A100A * AUD080R9V3 - N 800 10.80 23800
+TXC031S3
7A0024A100A * AUD080R9V3 - N 825 10.90 24400
+TXC036S3
7A0024A100A * AUD100R9V5 - N 800 10.90 24400
+TXC037S3
7A0024A100A TVF018A14 - Y 675 10.50 22200
7A0024A100A TVF024A14 - Y 800 10.50 22600
7A0024A100A * TWE018P13 N N 675 10.60 23200
7A0024A100A * TWE024P13 N N 800 10.70 23800
7A0024A100A * TWE030P13 N N 875 10.70 23400
7A0024A100A * TWE031E13 N N 825 10.80 23600
7A0024A100A TWE036C14 - Y 870 10.35 23200
7A0024A100A * TWE036P13 N N 875 10.55 23400
7A0024A100A * TWE037E13 N N 800 10.85 24600
7A0024A100A * TWE040E13 N N 875 10.90 25400
7A0024A100A TXA018C4 Y N 675 10.20 21200
7A0024A100A TXA024C4 Y N 800 10.20 23000
7A0024A100A TXA025C4 Y N 800 10.35 22600
7A0024A100A TXA025C4 Y Y 800 10.50 22200
7A0024A100A TXA030C4 Y N 870 10.35 23200
7A0024A100A TXA030C4 Y Y 855 10.50 22800
7A0024A100A TXA031C4 Y N 875 10.50 23400
7A0024A100A TXA035C4 Y N 870 10.50 23200
7A0024A100A TXA036C4 Y N 890 10.50 23800
7A0024A100A TXA037C4 Y N 890 10.50 23800
7A0024A100A TXC018C4 Y N 675 10.20 21200
7A0024A100A TXC024C4 Y N 800 10.20 23000
7A0024A100A TXC024D4 Y N 800 10.20 23000
7A0024A100A TXC025C4 Y N 800 10.35 22600
7A0024A100A TXC025C4 Y Y 800 10.50 22200
7A0024A100A TXC025D4 Y N 800 10.35 22600
7A0024A100A TXC025D4 Y Y 800 10.50 22200
7A0024A100A TXC030C4 Y N 870 10.35 23200
7A0024A100A TXC030C4 Y Y 855 10.50 22800
7A0024A100A TXC030D4 Y N 870 10.35 23200
7A0024A100A TXC030D4 Y Y 855 10.50 22800
7A0024A100A TXC031C4 Y N 875 10.50 23400
7A0024A100A TXC031D4 Y N 875 10.50 23400
7A0024A100A TXC031E5 Y N 890 10.75 23800
7A0024A100A * TXC031S3 N N 890 10.80 23800
7A0024A100A TXC035C4 Y N 870 10.50 23200
7A0024A100A TXC035D4 Y N 870 10.50 23200
7A0024A100A TXC036C4 Y N 890 10.50 23800
7A0024A100A TXC036D4 Y N 890 10.50 23800
7A0024A100A TXC036E5 Y N 900 10.85 24200
7A0024A100A * TXC036S3 N N 900 10.90 24200
7A0024A100A TXC037C4 Y N 890 10.50 23800
7A0024A100A TXC037E5 Y N 900 10.85 24200
7A0024A100A * TXC037S3 N N 900 10.90 24200
7A0024A100A TXH025A4 Y N 800 10.35 23200
7A0024A100A TXH025A4 Y Y 800 10.50 22800
7A0024A100A TXH033A4 Y N 900 10.50 24400
7A0030A100A CCBA30A4ACC Y N 950 10.15 26600
7A0030A100A CCBA36A4ACC Y N 1020 10.25 27400
7A0030A100A CCBB30A4ACC Y N 1000 10.35 27800
7A0030A100A CCBB36A4ACC Y N 1030 10.25 27600
7A0030A100A CUBA30A4ACC Y N 950 10.15 26600
7A0030A100A CUBA36A4ACC Y N 1020 10.25 27400
7A0030A100A CUBB30A4ACC Y N 1000 10.35 27800
7A0030A100A CUBB36A4ACC Y N 1030 10.25 27600
7A0030A100A * ADD080R9V3 - N 950 10.80 29000
+TXC031S3
7A0030A100A * ADD080R9V3 - N 950 10.90 29600
+TXC036S3
7A0030A100A * ADD100R9V5 - N 975 10.90 30000
+TXC037S3
7A0030A100A * ADD100R9V5 - N 975 10.90 29800
+TXC054S3
7A0030A100A * AUD080R9V3 - N 975 10.80 29200
+TXC031S3
7A0030A100A * AUD080R9V3 - N 1000 10.90 29800
+TXC036S3
