SCALA OVAL 5-1/2’™
WHIRLPOOL & BATHING POOL
HIGH GLOSS ACRYLIC
SCALA OVAL 5-1/2’WHIRLPOOL & BATHING
POOL
❏2645.018 Whirlpool featuring System I
•Acrylic with fiberglass reinforcement
•Pre-leveled tub bottom
•Molded-in lumbar back rest
•Factory installed and tested whirlpool system
•1.0 HP single speed, self-draining pump/
motor
•Factory-installed power cord with plug
•Six multi-directional color-coordinated
jets
•Deck-mounted air switch On/Off
•Two air volume controls
•Factory installed and tested whirlpool system
❏2645.018C Stay Clean™Whirlpool Massage
Featuring System I:
•Same as 2645.018 except with the
StayClean™whirlpool system featuring
Antimicrobial AlphaSan®
❏2645.002 Bathing Pool only
Nominal Dimensions: 1676 x 914 x 502mm
(66”x 36”x 19-3/4")
© 2003 American Standard Inc. BV-30
NOTE: Roughing-in dimensions and product
specifications shown on reverse side of page.
Revised 4/98
Compliance Certifications -
Meets or Exceeds the Following Specifications:
•Underwriters Laboratories - Hydromassage
Bathtubs UL 1795
•ASME A112.19.7M for Whirlpool Appliances
•ANSI Z124.1 for Plastic Bathtubs
•ASTM E162 for Flammability
•NFPA 258 for Smoke Density
To Be Specified - Required:
❏Color:
❏Bath Filler: (specify finish)
❏Bath Drain: 1583.470 (specify finish)
To Be Specified - Optional:
❏5-1/2 Foot Acrylic Apron: 9366.018 (specify color)
❏5-1/2 Foot Apron: 9266.018 (specify color)
❏Jet Trim Ring Kit: 9860.200-two per kit
(Specify finish)
For color/finish availability and other faucet choices,
please see the Product Selector and Pricing Guide.

SCALA OVAL 5-1/2’™
WHIRLPOOL & BATHING POOL
HIGH GLOSS ACRYLIC
© 2003 American Standard Inc.
NOTES:
BATH CAN BE INSTALLED EITHER ABOVE OR BELOW FLOOR LINE AS PIER, ISLAND, OR PENINSULA TYPE INSTALLATION.
SUMP OF BATH IS SUPPORTED BY INTEGRAL FEET. NO ADDITIONAL SUPPORT REQUIRED. ENCLOSING MATERIAL BY
OTHERS.
REFER TO INSTALLATION INSTRUCTIONS SUPPLIED WITH WHIRLPOOL FOR ADDITIONAL INFORMATION.
OPTIONAL APRON 9266.018 OR 9366.018 AVAILABLE AND MUST BE ORDERED SEPARATELY.
FITTINGS NOT INCLUDED AND MUST BE ORDERED SEPARATELY.
IF INSTALLING A DECK-MOUNTED FITTING, BEFORE DRILLING ANY HOLES: CHECK FOR INTERFERENCE WITH
CIRCULATING SYSTEM PIPING, DRAIN OVERFLOW, AND APRON INSTALLATION. MOUNTING HOLES DRILLED BY
INSTALLER.
PROVIDE SUITABLE REINFORCEMENT FOR ALL SUPPORTS.
IMPORTANT: Dimensions of fixtures are nominal and may vary within the range of tolerances established by ANSI Standard Z124.1.
These measurements are subject to change or cancellation. No responsibility is assumed for use of superseded or voided pages.
●
■
C/L OF
DRAIN
1676mm
(66) 6mm
(1/4)
TYP.
25mm (1)
TYP.
302mm
(11-7/8)
PROVIDE ACCESS
TO PUMP FOR
SERVICING ON ALL
INSTALLATIONS
914mm
(36)
51mm
(2)
HAND SHOWER
LOCATION
●RECOMMENDED FITTING LOCATION
64 X 330mm (2-1/2" x 13")
OUTLINE OF CUTOUT
1626mm X 864mm
(64 X 34)
419mm
(18) 44mm
(1-3/4)
210mm
(8-1/4)
ON/OFF
SWITCH
PUMP
229mm X 305mm
(9 X 12) CUTOUT
FOR DRAIN
1-1/2 O.D. TAILPIECE
1-1/2 N.P.T.M. THREADS
INTEGRAL
FEET SUPPORT
502mm
(19-3/4)
464mm
(18-1/4)
457mm
(3-5/8)
44mm
(1-3/4)
38mm
(1-1/2)
102mm
(4)
LEVELING STRINGER
(NOT FOR SUPPORT)
■C/L OF
DRAIN
1676mm
(66) 6mm
(1/4)
TYP.
25mm (1)
TYP.
302mm
(11-7/8)
914mm
(36)
51mm
(2)
HAND SHOWER
LOCATION
●RECOMMENDED FITTING LOCATION
64 X 330mm (2-1/2" x 13")
OUTLINE OF CUTOUT
1626mm X 864mm
(64 X 34)
419mm
(18) 44mm
(1-3/4)
210mm
(8-1/4)
229mm X 305mm
(9 X 12) CUTOUT
FOR DRAIN
1-1/2 O.D. TAILPIECE
1-1/2 N.P.T.M. THREADS
INTEGRAL
FEET SUPPORT
464mm
(18-1/4)
457mm
(3-5/8)
44mm
(1-3/4)
38mm
(1-1/2)
102mm
(4)
502mm
(19-3/4)
LEVELING STRINGER
(NOT FOR SUPPORT)
66 x 36 x 19-3/4 In. (1676 x 914 x 502mm)
95 Lbs. (43 Kg.)
595 Lbs. (268 Kg.)
60 Gal. (227 L)
55 Gal. (208 L)
46 x 24 In. (1168 x 610mm)
62 X 31-1/2 In. (1575 x 800mm)
13-1/4 In. (337mm)
36 Lbs./Sq.Ft. (175 Kgs/Sq.m)
25.6
45.1
GENERAL SPECIFICATIONS FOR 2645 WHIRLPOOL
1.1 HP, 9.9 AMPS,120V.
WHIRLPOOL ELECTRICAL SPECIFICATIONS
SYSTEM I PUMP
INSTALLED SIZE
WEIGHT
WEIGHT w/WATER
GAL. TO OVERFLOW
WHIRLPOOL MIN. OPERATING VOL.
BATHING WELL AT SUMP
BATHING WELL AT RIM
WATER DEPTH TO OVERFLOW
FLOOR LOADING
(PROJECTED AREA)
PTS.
CUBE (FT3)
66 x 36 x 19-3/4 In.
(1676 x 914 x 502mm)
75 Lbs. (34 Kg.)
575 Lbs. (259 Kg.)
60 Gal. (227 L)
46 x 24 In. (1168 x 610mm)
62 X 31-1/2 In. (1575 x 800mm)
13-1/4 In. (337mm)
35 Lbs./Sq.Ft. (169 Kgs./Sq.m)
25.6
45.1
GENERAL SPECIFICATIONS FOR 2645 BATHING POOL
INSTALLED SIZE
WEIGHT
WEIGHT w/WATER
GAL. TO OVERFLOW
BATHING WELL AT SUMP
BATHING WELL AT RIM
WATER DEPTH TO OVERFLOW
FLOOR LOADING
(PROJECTED AREA)
PTS.
CUBE (FT3)
