730548-100 Rev. B

Product names listed herein are trademarks of American Standard Inc.

ASSEMBLY & INSTALLATION

INSTRUCTIONS

Bordeaux 32" Vanity with Wood Top

9532.200

- 1 -

Recommended Tools & Materials

Roughing-in Dimensions

Thank you for selecting our products...products which have been the benchmarks of fine quality for over 100 years.

To help insure that the installation process will proceed smoothly, please read these instructions carefully before you

begin. Also, review the recommended tools and materials list; carefully unpack and examine your new plumbing fixture.

Adjustable Wrench

Channel Locks

Phillips Screwdriver

Putty Knife

Regular Screwdriver

Drill

Saber Saw Level

Basin Wrench

Plumbers' Putty or

Caulking

Tubing Cutter

10'

Tape

Measure

Hacksaw Pipe Wrench

™

DOORS SWING approx 150°

DEPTH WITH DOORS

1/2 OPEN = 32"

WIDTH WITH BOTH DOORS

FULL OPEN= 47-1/2"

A= 35-5/8"(981mm) forWood top

A= 35-3/4"(908mm) for Marble top

To maintain the beauty of the finish, avoid placing the furniture in direct sunlight, as sunlight causes fading. Also avoid

extreme changes in temperature by arranging furniture away from radiators, heat and air vents, and air conditioning units.

Avoid placing furniture directly under windows.

32-3/8"

822mm

32-3/4"

832mm

22-3/4"

578mm

24-3/4"

629mm

(152mm)

1-1/4" O.D.

WASTE SUPPLIES

AS REQ'D

FINISHED FLOOR

(152mm) 4"

TYP ANCHORING HOLES 21-1/4"

540mm

WOOD TOP (SUPPLIED) SEBRING 0573

COVENTRY 0575

MARBLE TOP (OPTIONAL)

9532.495 OVALYN 0495.221

VANITY TOP RECOMMENDED SINKS

21-1/4"

540mm

730548-100 Rev. B

- 2 -

C/L of 2 x 6

Reinforcement

Finished

Floor

32-3/4"

Wood Top with Recommended Sinks...

Provide suitable reinforcement required for anchoring the vanity to the wall. Centerline of reinforcement should be 32-

3/4" up from the floor (see Figure 1).

The molding needs to be notched to seat the vanity flush against the wall (see Figure 2).

Rough in supply lines and waste per rough in dimensions.

NOTE: If current supply lines are greater than 6" on center, they may interfere with cutout in rear of vanity or vanity shelf.

Remove the wood top from the vanity. The top is held in place from the underside by 4 screws, 1 through each of the 4

angled corner braces.

Move the vanity into place and anchor it to the wall through at least 2 of the anchoring holes in the rear of the vanity (see

Figure 2).

Continue with installation appropriate for top and sink options chosen.

Two people recommended for this installation

Determine which sink is being installed and follow the instructions printed on the

appropriate template supplied with vanity.

NOTE: American Standard is not responsible for cut-out errors when the

incorrect cut-out template is used.

If Installing: Use Template:

Sebring 0573 730541-400

Coventry 0575 730542-400

After top is replaced, connect the trap to the drain assembly hand tight to check

alignment. It may be necessary to cut off part of the tailpiece (area "A") or part

horizontal leg of the trap (area "B").

Connect hot and cold supply lines to the shut off valves. Tighten trap joints for

watertight assembly. AB

VANITY INSTALLATION

32-3/4"

832mm

MOLDING

FIGURE 1 FIGURE 2

ANCHORING

HOLES

PAPER TEMPLATE

WOOD VANITY TOP

IMPORTANT: BE SURE TO CENTER SINK

CUT OUT HORIZONTALLY ON VANITY TOP.

730548-100 Rev. B

- 3 -

Turn the marble top upside down and place it on a clean, scratch

resistant surface. Apply a bead of silicone adhesive to the rim of

the sink. Center the sink over the cutout and (secure it to the top

using the mounting kit provided).

NOTE: Brass inserts are preinstalled on the underside of the marble

top. Use the 4 brackets supplied with the sink mounting kit and the 4

screws supplied with the marble top.

Turn the top right-side up and install the faucet per the manufacturer’s

instructions.

Apply a bead of silicone adhesive to the rim of the vanity. Place the marble top

centered left to right on the vanity and with the back edge of the top even with the

rear of the vanity. Clean up any excess silicone.

Connect the trap to the drain assembly hand tight to check alignment. It may be

necessary to cut off part of the tailpiece (area "A") or part horizontal leg of the trap

(area "B").

Connect hot and cold supply lines to the shut off valves. Tighten trap joints for

watertight assembly.

Optional marble top 9532.495 with Ovalyn 0495 undermount

sink…

Two people recommended for this installation

NOTE: Marble top comes pre-cut for the Ovalyn under counter mount sink and

8" faucet spread. Also it is strongly recommended to seal the marble top after

installation and prior to use.

Remove wood top if not already done.

Mount the drain assembly (not included) on the sink. Be certain to apply a bead

of sealing putty on the underside of the drain (Part "A") in order to ensure a

watertight seal between the sink and drain. Remove excess putty after installing

the drain on the sink.

Care and Cleaning of Vanity

Dust the vanity frequently with a clean, soft, dry, lint-free cloth, as well as polish it on a regular basis. Clean the surface by rubbing in

the direction of the grain. Use polishes that contain detergents, emulsifiers and mineral oil. Avoid using silicone cleaners and waxes.

Clean up excess water and spills immediately. Use a blotting rather than a wiping action. Water left over a long period of time will

cause white spots in the finish.

NOTE: Please note that some chemicals may damage the finish. Take care to avoid the following: iodine, hair dye, after shave lotion,

shaving cream, alcohol, perfume, Lestoil®, Lysol Tub and Tile Cleaner®, Lysol Spray Disinfectant®, Dow Disinfectant®, acetone, paint

remover, Formula 409®, Tile-X®, and Nair®.

Care and Cleaning of the Marble Vanity Top

Marble is porous and easily stained. Wipe off anything spilled on it immediately. It should be washed or cleaned regularly with fresh

warm water and a non-abrasive clean cloth. Also, using a non-abrasive, neutral (pH balanced) cleaner will help remove dirt and grime,

but it is recommended to first try warm water only.

Marble should be sealed regularly with a good quality marble sealer. Marble sealers are available at most retail home supply stores.

Follow the instructions on the sealer container for proper application and frequency of use. The sealer acts as a stain inhibitor and

prevents most stains and soil from being absorbed into the porous surface, but it is NOT a guarantee against staining. All spills should

be cleaned immediately. Avoid contact with all oils and petroleum-based products. Also, avoid contact with all acid or caustic products

such as vinegar, citrus or fruit juices, soda, chlorine, and nail polish remover. If the marble is well sealed, the warm water and non-

abrasive cloth should keep it clean.

730548-100 Rev. B

- 4 -

In the United States:

American Standard Inc.

P.O. Box 6820

Piscataway, New Jersey 08855

Attention: Director of Consumer Affairs

For residents of the United States, warranty information

may also be obtained by calling the following

toll free number: (800) 442-1902

In Canada:

American Standard

2480 Stanfield Rd.

Mississauga, Ontario

Canada L4Y 1S2

Toll Free: (800) 387-0369

In Mexico:

Customer Service Manager

Ideal Standard, S.A. de C.V.

Via Morelos #330

Col. Santa Clara

Ecatepec 55540 Edo. Mexico

AMERICAN-STANDARD GRANITE/MARBLE TABLE TOP WARRANTY

If inspection of this American-Standard plumbing product, within one year after its initial purchase, confirms that it is defective in materials or

workmanship, American-Standard will repair or, at its option, exchange the product for a similar model. Variations in shading, veining, and texture

which may result from natural characteristics of stone and as such are not defects and are not covered by this warranty.

This warranty applies only to the original purchaser and installation of these products.

This limited warranty does not apply to local building code compliance. Since local building codes vary considerably, the purchaser of this product

should check with a local building or plumbing contractor to insure local code compliance before installation.

This warranty shall be void if the product has been moved from its initial place of installation; if it has been subjected to faulty maintenance,

abuse, misuse, accident or other damages; if it was not installed in accordance with American-Standard’s instructions; or if it has been modified in

a manner inconsistent with the product as shipped by American-Standard.

American-Standard’s option to repair or exchange the product under this warranty does not cover any labor or other costs of removal or

installation, nor shall American-Standard be responsible for any other incidental or consequential damages attributable to a product defect or to

the repair or exchange of a defective product, all of which are expressly excluded from this warranty. (Some states or provinces do not allow the

exclusion or limitation of implied warranties, so this exclusion may not apply to you).

This warranty gives you specific legal rights. You may have other statutory rights that vary from state to state or province to province, in which

case this warranty does not affect such statutory rights.

AMERICAN-STANDARD WOOD FURNITURE WARRANTY

If inspection of this American-Standard plumbing product, within one year after its initial purchase, confirms that it is defective in materials or

workmanship, American-Standard will repair or, at its option, exchange the product for a similar model. Variations in actual wood color and

finishes which may result from natural characteristics of the wood, such as grain patterns, mineral streaks and the like, are not defects and are not

covered by this warranty.
