G15
© 2008 AS America Inc. Revised 6/06
CHANDLER™ w/DRAIN BOARD
DOUBLE BOWL KITCHEN SINK
• Dupont Corian® surface
• Double bowl design
• Integral drain board
• Decorative grooves assist drainage
• Top mount
• Silicone sealant supplied
• Available in center hole only, 3, or 4 faucet
hole conguration
Right Hand Drain Board
❏ 7048.401 Center hole only
❏ 7048.403 3 hole
❏ 7048.404 4 hole
Left Hand Drain Board
❏ 7048.501 Center hole only
❏ 7048.503 3 hole
❏ 7048.504 4 hole
Nominal Dimensions:
1264 x 559 x 254mm
(49-3/4" x 22" x 10-1/2")
Bowl sizes:
Right Hand: 359mm (14-1/8") wide
413mm (16-1/4") front to back
203mm (8") deep
Left Hand: 432mm (17") wide
476mm (18-3/4") front to back
254mm (10") deep
Compliance Certications -
Meets or Exceeds the Following Specications:
• ANSI Z124.6 for Non-Metallic Sinks
* See faucet section for available models
To Be Specied:
❏ Color:
❏ Faucet*:
❏ Faucet Finish:
❏ Basket Strainer: 4331.013
❏ Soap Dispenser: 4503.115
❏ Traps:
CHANDLER™ w/DRAIN BOARD
DOUBLE BOWL SINK
DUPONT CORIAN®
7048.403
7048.504
SEE REVERSE SIDE FOR ROUGHING-IN DIMENSIONS

G16
© 2008 AS America Inc.
7048.401 Right Hand
7048.501 Left Hand
CHANDLER™ w/DRAIN BOARD
DOUBLE BOWL SINK
DUPONT CORIAN®
NOTES:
* FOR COUNTERTOP CUTOUT AND INSTALLATION INSTRUCTIONS
USE TEMPLATE SUPPLIED WITH SINK.
FITTINGS NOT INCLUDED AND MUST BE ORDERED SEPARATELY.
PROVIDE SUITABLE REINFORCEMENT FOR ALL WALL AND
COUNTERTOP SUPPORTS.
IMPORTANT: Dimensions of xtures are nominal and may vary within the
range of tolerances established by ANSI Standard Z124.6
These measurements are subject to change or cancellation. No responsibility
is assumed for use of superseded or voided leaet.
7-1/8"
(181mm)
(2) 1-1/2" O.D.
TAILPIECE
10-1/8"
(257mm)
5-3/4"
(146mm)
Y
COUNTERTOP
(BY OTHERS)
5-3/4"
(146mm) 36" (914mm)
SUGGESTED
FINISHED
FLOOR
8-1/8"
(206mm)
1/2"
(13mm)
4" (102mm)
HOT COLD
FINISHED WALL OR
SPLASH BACK
4"
(102mm)
4"
(102mm)
3-1/2" (89mm)
DIA. TYP.
11"
(279mm)
24-7/8"
(632mm)
9-3/8"
(238mm)
1-3/8" (35mm)
DIA. HOLES TYP.
7048.501
1 HOLE
VARIATION
8-3/4"
(222mm)
C/L
SPRAY
7048.504
4 HOLE
VARIATION
7048.503
3 HOLE
VARIATION
3-3/8"
(86mm) REF
1-3/4"
(44mm) DIA
2" (51mm)
OPTIONAL
22"
(559mm)
CUTOUT
NOTE
*
1-1/2"
(38mm REF.)
SEALING
COMPOUND
49-3/4"
(1264mm)
14-1/4"
(362mm)
15-3/8"
(391mm REF.) 2-1/8"
(54mm)
1" (25mm)
RAD. TYP.
7-1/8"
(181mm)
(2) 1-1/2" O.D.
TAILPIECE
10-1/8"
(257mm)
5-3/4"
(146mm)
Y
COUNTERTOP
(BY OTHERS)
5-3/4"
(146mm) 36" (914mm)
SUGGESTED
FINISHED
FLOOR
8-1/8"
(206mm)
1/2"
(13mm)
4"
(102mm)
HOT COLD
FINISHED WALL OR
SPLASH BACK
4"
(102mm)
4"
(102mm)
3-1/2"
(89mm) DIA.
TYP.
3/8"
(10mm)
11"
(279mm)
24-7/8"
(632mm) 1-3/8" (35mm)
DIA. HOLES TYP.
7048.401
1 HOLE
VARIATION
8-3/4"
(222mm) C/L
SPRAY
7048.404
4 HOLE
VARIATION
7048.403
3 HOLE
VARIATION
3-3/8"
(86mm) REF
1-3/4"
(44mm) DIA
2" (51mm)
OPTIONAL
22"
(559mm)
CUTOUT
NOTE
*
1-1/2"
(38mm REF.)
SEALING
COMPOUND
49-3/4"
(1264mm)
14-1/4"
(362mm)
15-3/8"
(391mm REF.)
2-3/8"
(60mm)
1" (25mm)
RAD. TYP.
Revised 6/06
