L65
© 2008 AS America Inc.
HERITAGE/AMARILIS
TWO-HANDLE PANTRY/BAR SINK FAUCET
WITH BRASS GOOSENECK SPOUT
GENERAL DESCRIPTION:
Cast brass valve bodies with reinforced flexible hose
connections for 6" to 12" (152mm to 305mm) installations.
Amarilis 1/4 turn washerless ceramic disc valve cartridges
- reversible for use with either lever or round handles.
One-half inch male inlet shanks with brass coupling nuts
and shank nuts. Brass gooseneck swivel spout.
2.2gpm/8.3L/min. maximum flow rate.
PRODUCT FEATURES:
Ceramic Disc Valve Cartridges: Assures a lifetime of
drip-free performance.
Brass Construction: Durable - Excellent in high use
applications. Ideal for prolonged contact with water.
Low Lead: Meets NSF Standard 61/Section 9 & Prop 65
lead requirements.
Wide Selection of Handle Styles: Full range of
interchangeable handle styles.
MODEL NUMBER:
7890.000 Bar/Pantry Sink Faucet
Gooseneck swivel spout. Less handles.
Handles must be ordered separately.
SUGGESTED SPECIFICATION:
Two handle bar sink/pantry faucet shall feature cast brass valve bodies with reinforced flexible hose connections for 6" to 12"
installations. All brass shank nuts and coupling nuts. Shall also feature 1/4 turn washerless ceramic disc valve cartridges that
are reversible for use with round or lever handles. Faucet shall be American Standard Model # 7890.000.___ and handle kit #
0000.___.___.
To order Less Handles - Specify: 4 digit style number followed by three zeros and 3 digit finish number.
Example 7890.000.002 = Bar Sink faucet in Polished Chrome finish.
7890.000
Product
Number Description
Bar/Pantry Sink faucet. Less handles.
Finish Options
Polished
Chrome
002
Handles must be ordered separately.
127mm
(5)
270mm
(10-5/8)
51mm
(2) DIA.
TYP.
152mm - 305mm
(6 TO 12)
FLEXIBLE
29mm
(1-1/8)
DIA. 89mm
(3-1/2)
165mm
(6-1/2)
38mm
(1-1/2)
MAX.
FOR GROUND JOINT
OR 1/2" O.D. SLIP
CONNECTION
Meets the American Disabilities Act Guidelines
and ANSI A117.1 Requirements for the
physically challenged.
FLOW RATE*
GALLONS PER MINUTE
INLET PRESSURE (PSI)
*Flow rates shown are for mixed hot and cold.
0.0
0.5
1.0
1.5
2.0
2.5
3.0
10080604020
CODES AND STANDARDS
These products meet or exceed the following
codes and standards:
ASME A112.18.1
CSA B 125
NSF 61/Section 9
Lexington
902
912
Wrist
Blade Lever
372H
372V
342H
342V
442 432 552
Metal
Lever
Perfume
Bottle
542
Metal
Lever
Metal
Cross
35mm - 38mm
(1-3/8" to 1-1/2")DIA.
MOUNTING HOLES (3)
The above fittings will accept the following Amarilis-Series handles.

L66
© 2008 AS America Inc.
HERITAGE/AMARILIS
TWO-HANDLE PANTRY/BAR SINK FAUCET
WITH BRASS GOOSENECK SPOUT
GENERAL DESCRIPTION:
Cast brass valve bodies with reinforced flexible hose
connections for 6" to 12" (152mm to 305mm) installations.
Amarilis 1/4 turn washerless ceramic disc valve cartridges
- reversible for use with either lever or round handles.
One-half inch male inlet shanks with brass coupling nuts
and shank nuts. Brass gooseneck swivel spout.
2.2gpm/8.3L/min. maximum flow rate.
PRODUCT FEATURES:
Ceramic Disc Valve Cartridges: Assures a lifetime of
drip-free performance.
Brass Construction: Durable - Excellent in high use
applications. Ideal for prolonged contact with water.
Low Lead: Meets NSF Standard 61/Section 9 & Prop 65
lead requirements.
Wide Selection of Handle Styles: Full range of
interchangeable handle styles.
MODEL NUMBER:
7890.000 Bar/Pantry Sink Faucet
Gooseneck swivel spout. Less handles.
Handles must be ordered separately.
SUGGESTED SPECIFICATION:
Two handle bar sink/pantry faucet shall feature cast brass valve bodies with reinforced flexible hose connections for 6" to 12"
installations. All brass shank nuts and coupling nuts. Shall also feature 1/4 turn washerless ceramic disc valve cartridges that
are reversible for use with round or lever handles. Faucet shall be American Standard Model # 7890.000.___ and handle kit #
0000.___.___.
To order Less Handles - Specify: 4 digit style number followed by three zeros and 3 digit finish number.
Example 7890.000.002 = Bar Sink faucet in Polished Chrome finish.
7890.000
Product
Number Description
Bar/Pantry Sink faucet. Less handles.
Finish Options
Polished
Chrome
002
Handles must be ordered separately.
127mm
(5)
270mm
(10-5/8)
51mm
(2) DIA.
TYP.
152mm - 305mm
(6 TO 12)
FLEXIBLE
29mm
(1-1/8)
DIA. 89mm
(3-1/2)
165mm
(6-1/2)
38mm
(1-1/2)
MAX.
FOR GROUND JOINT
OR 1/2" O.D. SLIP
CONNECTION
Meets the American Disabilities Act Guidelines
and ANSI A117.1 Requirements for the
physically challenged.
FLOW RATE*
GALLONS PER MINUTE
INLET PRESSURE (PSI)
*Flow rates shown are for mixed hot and cold.
0.0
0.5
1.0
1.5
2.0
2.5
3.0
10080604020
CODES AND STANDARDS
These products meet or exceed the following
codes and standards:
ASME A112.18.1
CSA B 125
NSF 61/Section 9
Lexington
902
912
Wrist
Blade Lever
372H
372V
342H
342V
442 432 552
Metal
Lever
Perfume
Bottle
542
Metal
Lever
Metal
Cross
35mm - 38mm
(1-3/8" to 1-1/2")DIA.
MOUNTING HOLES (3)
The above fittings will accept the following Amarilis-Series handles.
