AMGO DX-12A Manual

1
SCISSORS LIFT
Model: DX-12A
Original

2
CONTENTS
Product Features and Specifications ........................................................1
Installation Requirement .......................................................................2
Steps of Installation .............................................................................3
Exploded View ....................................................................................22
Test Run ............................................................................................35
Operation Instruction ..........................................................................38
Maintenance ......................................................................................39
Trouble Shooting ................................................................................40
LIFT DISPOSAL ..................................................................................40

1
I. PRODUCT FEATRUES AND SPECIFICATIONS
Double Scissors Lift
Model DX-12A
· Electric- air control system, mechanical safety locks
· Dual synchronous cylinders are applied to assure the lifting level on both platforms
· Photo cell device protection, avoid vehicle collapse
· Non-skid diamond platforms.
· Double scissors structure, fit for a wide range vehicle of car to van and light truck
· Optional Turnplate.
Model DX-12A SPECIFICATIONS
Model
Lifting
Capacity
Lifting
Height
Min.
Height
Lifting
Time
Overall
Length
(Inc.
Ramps)
Overall
Width
Runway
Width
Distance
Between
Platform
Gross
Weight
Motor
DX-12A
5500kg
12000 lbs
1870mm
73 5/8”
305mm
11”
64S
6527mm
256 ”
2190mm
86 1/4”
625mm
24 5/8”
940mm
37”
2400Kg
4,263 lbs
4.0HP
Fig. 1

2
II.INSTALLATION REQUIREMENT
A. TOOLS REQUIRED
Rotary Hammer Drill (Φ19, Φ10, Φ4,)
Hammer
Level Bar
English Spanner (12")
Ratchet Spanner With Socket (28#)
Wrench Set (8#, 14#, 15#, 17#, 19#)
Carpenter’s Chalk
Screw Sets
Tape Measure (7.5m)
Pliers
Lock Wrench
Grease gun
Fig. 2

3
B．SPECIFICATIONS OF CONCRETE
Specifications of concrete must be adhered to the specification as following.
Failure to do so may result in lift and/or vehicle falling.
1．Concrete must be thickness 5-7/8’’ minimum and without reinforcing steel bars， and
must be dried completely before the installation.
2．Concrete must be in good condition and must be of test strength 3,000psi
(210kg/cm²) minimum.
3．Floors must be level and no cracks.
C．POWER SUPPLY
The electrical source must be 3.0KW minimum. The source cable size must be
2.5mm² and in good condition of contacting with floor.
III. STEPS OF INSTALLATION
A. Location of Installation
Check and insure the installation location (concrete, layout, space size etc.) is
suitable for lift installation.
1. For Standard Installation: On surface installation
1.1 Installation dimension for DX-12A (See Fig. 3).
Fig. 3

4
1.2 Illustration of DX-12A on surface installation (See Fig.4).
2. For Optional Installation: Flush mount installation
2.1 Flush Mount Installation Foundation (Fig.5).
Fig. 4
Fig. 7
1. Concrete must be thickness 150mm
minimum, and test strength 3,000psi
(210kg/cm²) minimum.
2. Useφ100mm PVC Tube
Φ100 PVC Tube
Noted:
Control cabinet can be installed at
the left side or the right side of
drive in direction. Below figure
show the control cabinet installed
at the left side of drive in direction.
Fig. 5
Φ100 PVC Tube

5
2.2 Illustration of DX-12A flush mount installation (Fig.6).
B. Check the parts before assembly.
1. Packaged lift and control cabinet (See Fig. 7).
Fig. 7
Fig. 6

6
2. Move aside the lift with fork lift or hoist, and open the outer packing carefully
2.1 Parts for lift on surface installation (See Fig.8)
2.2 Parts for lift of flush mount installation (See Fig.9)
Fig. 8
PI
PII
64
Fig. 9
132
PI
PII
123
Guide ramp
(510018)
51

7
3. Open the parts box, check the parts according to the part list (See Fig. 10).
4. Check the parts of the parts bag according to the parts bag list.
4.1 Pasts bag for lift on surface installation (See Fig.11)
Fig. 11
Fig.10
124
125

8
4.2 Parts bag for lift of flush mount installation (See Fig.12)
C. Layout and installation of oil system and air line system.
1. Select a location and lay out the lift according to step A(See Fig. 13).
Noted: The control cabinet can be installed on the left or right of the model according to
the site.
PII
PI
Fig. 13
Fig. 12

9
2. Connecting the cylinders’ oil hose and air line of the main scissors. (See Fig. 14)
Fig. 14
PI
PII
○
1Oil Hose: 1/4*6215 mm
○
2 Oil Hose: 1/4*6135 mm
○
3Oil Hose: 1/4*285 mm
○
4 Oil Hose: 1/4*285 mm
○
5Oil Hose: 1/4*1870 mm
Connect to “A”
of Solenoid
valve

10
3.Connect the cylinders’ oil hose and air line of the secondly scissors. (See Fig. 15)
4. Install the oil-water separator (See Fig. 16).
Fig. 16
Connect the air source by the
oil-water separator
Fig. 15
○
6Oil hose 1/4*5500 mm
○
7Oil hose 1/4*5500 mm
○
8Oil hose 1/4*5500 mm
○
9Oil hose 1/4*6800 mm
○
10Oil hose 1/4*5350 mm
103
102
103
129
130
131
104
93
99
100
95
96
97
PII
PI
Connect to “B” connector of
hydraulic valve
101
98
109
106
12-11
12-8
108
106
107

11
5.Connecting the air source (air pressure 5kg/cm2- 8kg/cm2), adjust the air pressure
to 0.8MPa (See Fig. 17).
Clockwise to increase the air pressure
Counter-clockwise to reduce the air pressure
Adjust the air pressure to 0.4~0.6MPa
Adjust the air pressure
to 0.8MPa
Fig. 17
Connecting
air source

12
D. Install electric system
1. Wire connection of hydraulic power unit (380V)
2.1 Connect the power wire and limit switch wire according to the wiring diagram (See
Fig. 18).
Fig. 18
Remove
this
wire in
normal
working
Power wire of motor
Wire of photo cell device
Wire of lower limit switch
Wire of high limit switch for
main scissors
LED Light
Power wire
Wire of high limit switch for
secondly scissors

13
380V Electric Component
Item
Name
Code
Specification
Item
Name
Code
Specification
1
Power switch
QS
25A
15
Time relay
KT
AC24V
2
Breaker
FU1
3P
16
Dual way check
solenoid
valve(main
scissor)
YA
AC24V
3
Breaker
FU2
1P
17
Dual way check
solenoid
valve(secondly
scissor)
YB
AC24V
4
Breaker
FU3
1P
18
Air solenoid
valve
A1
A2
AC24V
5
AC contactor
KM
16A/AC24V
19
Solenoid release
valve
Y
AC24V
6
Buzzer
H
AC24V
20
Push button
UP1
Triple
7
Transformer
TC
24VAC
21
Push button
UP2
Duplex
8
Indicator light
R
24V White
22
Push button
Lock1
Triple
9
Lower Alarm
button
Pass
Duplex
23
Push button
Lock2
Duplex
10
Motor
M
3 Phase
24
Push button
Down1
Triple
11
Rectifier bridge
UR
KBPC10-10
25
Push button
Down2
Duplex
12
Photo cell device
SP
DC24V
26
High limit switch
for main scissor
SQ1
8108（10A）
13
Intermediate
relay
KA3
DC24V
27
Low limit switch
for main scissor
SQ2
8108（10A）
14
Intermediate
relay
KA1
KA2
AC24V
28
Low limit switch
SQ3
8104（10A）

14
1.2 Circuit Diagram (See Fig. 19).
Fig. 19

15
Remove
this wire
in
normal
working
2.Wire connection of hydraulic power unit (220V)
2.1 Connect the power wire and limit switch wire according to the wiring diagram (See
Fig. 20)
Fig. 20
Power wire
Power wire of motor
Wire of photo cell device
Wire of lower limit switch
LED Light
Wire of high limit switch for main scissors
Wire of high limit switch for
secondly scissors

16
220V Electric Component
Item
Name
Code
Specification
Item
Name
Code
Specification
1
Power switch
QS
25A
15
Time relay
KT
AC24V
2
Breaker
FU1
2P
16
Dual way check
solenoid
valve(main
scissor)
YA
AC24V
3
Breaker
FU2
1P
17
Dual way check
solenoid
valve(secondly
scissor)
YB
AC24V
4
Breaker
FU3
1P
18
Air solenoid
valve
A1
A2
AC24V
5
AC contactor
KM
16A/AC24V
19
Solenoid release
valve
Y
AC24V
6
Motor
M
Single Phase
20
Push button
UP1
Triple
7
Transformer
TC
24VAC
21
Push button
UP2
Duplex
8
Indicator light
R
24V White
22
Push button
Lock1
Triple
9
Lower Alarm
Button
Pass
Duplex
23
Push button
Lock2
Duplex
10
Buzzer
H
AC24V
24
Push button
Down1
Triple
11
Rectifier bridge
UR
KBPC10-10
25
Push button
Down2
Duplex
12
Photo cell device
SP
DC24V
26
High limit switch
for main scissor
SQ1
8108（10A）
13
Intermediate
relay
KA3
DC24V
27
Low limit switch
for main scissor
SQ2
8108（10A）
14
Intermediate
relay
KA1
KA2
AC24V
28
Low limit switch
SQ3
8104（10A）

17
2.2 Circuit Diagram (See Fig. 21).
Fig. 21

18
E. Adjust Photo cell device and level two platforms
1. Remove the cover of photo cell device on off-side platform firstly. (See Fig.22)
2. Check by level bar and adjust the lower leveling bolts(See Fig.23), use the shims to
adjust the platforms until the front and rear of two platforms are in the same level.
Adjust the Upper leveling bolts(See Fig.24) after it touch the Lower leveling bolts
when lower to the lowest position. Then Tighten nut by wrench.
Check by
level bar
P1
P2
131
130
M4 bolts
Fig. 23
Fig. 24
Lower leveling bolts
Tighten nut
Tighten nut
Upper
leveling bolts
Fig. 22
