amiad T Installation and operating instructions

Amiad T-Filters 910101-001273 / 10.2021 1
INSTALLATION & MAINTENANCE INSTRUCTIONS
Amiad T-Filters
1"T (010010) / 1"T-Super (010011) 1½"T (010012) / 1½"T-Super (010013)
Thank you for selecting an Amiad filter. This filter has been designed to provide years of trouble-free service. Please
familiarize yourself with these instructions to ensure correct and reliable operation.
INSTALLATION
1. Amiad recommends using plastic connectors when installing the filter onto metal pipes.
2. Use only Teflon or silicon sealing material on the inlet/outlet connections. Do not use any sealing material on the
plastic ball valve connection to the filter drain port. This is a compression type fitting that does not require any
sealing material.
3. Install a shut-off valve upstream of the filter to facilitate cleaning.
4. Install the filter with the housing oriented downward.
5. The filter is available with either a Screen Cylinder or Disc Element. Make sure that the direction of flow is from
the inside/out in Screen Cylinders and from the outside/in in the Disc element.
CLEANING
The filter requires cleaning when the differential pressure between the inlet and outlet reaches 0.5-0.6 bar (7-8 psi).
1. Close the water supply to the filter and release pressure from the system.
2. Unscrew the lid to remove the filter element.
3. Screen cylinder: Rinse the screen with water. Use a soft brush for hard-to-remove particles. Do not use a metal
brush which may damage the screen.
Disc element: Twist the disc element core at each end and unscrew it counter- clockwise. This loosens the disc
core. Direct a stream of water along the disc edges to rinse with a spinning action. Hand-tighten the disc element
core after cleaning.
4. Insert the filter element into the housing. Make sure that the housing and element seals are in place. Tightly
screw on the lid, then backoff ⅛turn for proper sealing.
5. Close the drain valve and open the inlet valve to pressurize the filter. Check for any leaks.
Maximum pressure drops across the filter element, for a short time should not exceed 6 bar (90 psi).
WARNING: Improper flow direction or backflow through a screen may damage the filter element.
WARNING: NEVER OPEN THE FILTER WHILE IT IS UNDER PRESSURE!

Amiad T-Filters 910101-001273 / 10.2021 2
TYPICAL INSTALLATIONS
1"T / 1" T-S
1½"T / 1½" T-S

Amiad T-Filters 910101-001273 / 10.2021 3
PARTS SCHEDULE:
1"T / 1" T-S Screen
1"T / 1" T-S Disc
No
SAP P/N
Description
1
700190-006409
BODY 1"T BLACK BSP W/PCP, W/RINGS
700190-006410
BODY 1"T BLACK NPT W/PCP, W/RINGS
1.1
700190-001305
PRESSURE CHECK POINT ASSEMBLY
2
700101-002531
DISC ELEMENT PP 200SQ.CM 130MIC
AMIAD 1" NBR SEALS
700101-002532
DISC ELEMENT PP 460SQ.CM 130MIC
AMIAD 1½" NBR SEALS
2.1
770102-000117
PARKER O-RING 2-227 NBR 70 SHORE
DW
3
760107-000003
HELICAL SPRING TIGHTEN 1 1/2"
MANUAL S/ST302
4
770102-000455
MM O-RING SEAL ID87MM TH4MM
EPDM 70 SHORE DW
5
710101-000510
1"T COVER RPP BLACK
710101-000539
1.5"T COVER RPP BLACK
6
300005-000006
BALL VALVE AC 3/4" 10 BAR BLACK
FOR 2"T (OPTIONAL)
700190-001192
CAP 3/4" COMPLETE ASSY
6.1
710101-000674
3/4" CAP PP BLACK
6.2
770103-000025
FLAT SEAL 3/4" NBR OD24.7MM
ID17MM TH2MM 65 SHORE
No
SAP P/N
Description
1
700190-006409
BODY 1"T BLACK BSP W/PCP, W/RINGS
700190-006410
BODY 1"T BLACK NPT W/PCP W/RINGS
1.1
700190-001305
PRESSURE CHECK POINT ASSEMBLY
2
700101-000338
MWW SCREEN S/ST316L 200SQ.CM
130MIC 1" NBR SEALS
700101-000365
MWW SCREEN S/ST316L 460SQ.CM
130MIC 1½" NBR SEALS
2.1
770102-000117
PARKER O-RING 2-227 NBR 70 SHORE
DW
3
770102-000455
MM O-RING SEAL ID87MM TH4MM
EPDM 70 SHORE DW
4
710101-000510
1"T COVER RPP BLACK
710101-000539
1.5"T COVER RPP BLACK
5
300005-000006
BALL VALVE AC 3/4" 10 BAR BLACK
FOR 2"T

Amiad T-Filters 910101-001273 / 10.2021 4
1½"T / 1½" T-S Screen
1½"T / 1½" T-S Disc
No
SAP P/N
Description
1
700190-006443
BODY 1½"T BLACK BSP W/PCP
700190-006448
BODY 1½"T BLACK NPT W/PCP
1.1
700190-001305
PRESSURE CHECK POINT ASSEMBLY
2
700101-002531
DISC ELEMENT PP 200SQ.CM 130MIC
AMIAD 1" NBR SEALS
700101-002532
DISC ELEMENT PP 460SQ.CM 130MIC
AMIAD 1½" NBR SEALS
2.1
770102-000117
PARKER O-RING 2-227 NBR 70 SHORE
DW
3
760107-000003
HELICAL SPRING TIGHTEN 1 1/2"
MANUAL S/ST302
4
770102-000455
MM O-RING SEAL ID87MM TH4MM
EPDM 70 SHORE DW
5
710101-000510
1"T COVER RPP BLACK
710101-000539
1.5"T COVER RPP BLACK
6
300005-000006
BALL VALVE AC 3/4" 10 BAR BLACK
FOR 2"T (OPTIONAL)
700190-001192
CAP 3/4" COMPLETE ASSY
6.1
710101-000674
3/4" CAP PP BLACK
6.2
770103-000025
FLAT SEAL 3/4" NBR OD24.7MM
ID17MM TH2MM 65 SHORE
No
SAP P/N
Description
1
700190-006443
BODY 1½"T BLACK BSP W/PCP
700190-006448
BODY 1½"T BLACK NPT W/PCP
1.1
700190-001305
PRESSURE CHECK POINT ASSEMBLY
2
700101-000338
MWW SCREEN S/ST316L 200SQ.CM
130MIC 1" NBR SEALS
700101-000365
MWW SCREEN S/ST316L 460SQ.CM
130MIC 1½" NBR SEALS
2.1
770102-000117
PARKER O-RING 2-227 NBR 70 SHORE
DW
3
770102-000455
MM O-RING SEAL ID87MM TH4MM
EPDM 70 SHORE DW
4
710101-000510
1"T COVER RPP BLACK
710101-000539
1.5"T COVER RPP BLACK
5
300005-000006
BALL VALVE AC 3/4" 10 BAR BLACK
FOR 2"T
