Amit WRTB1 Series User manual

wrtb1xx_g_en_105
WRTB1xx
LTE router
Operation manual
Version 1.05

WRTB1XX
wrtb1xx_g_en_105 2/42
AMiT, spol. s r. o. does not provide any warranty concerning the contents of this
publication and reserves the right to change the documentation without
obligation to inform any body or authority about it.
This document can be copied and redistributed under following conditions:
1. The whole text (all pages) must be copied without any changes.
2. All redistributed copies must retain the AMiT, spol. s r. o. copyright notice
and any other notices contained in the documentation.
3. This document must not be distributed for purpose making of profit.
The names of products and companies used herein can be trademarks or
registered trademarks of their respective owners.
AMiT is a registered trademark.
Copyright (c) 2017, AMiT, spol. s r. o.
Producer: AMiT, spol. s r. o.
Naskové 1100/3, 150 00 Praha
www.amit-transportation.com
Technical support: [email protected]

WRTB1XX
3/42 wrtb1xx_g_en_105
Contents History of revisions.........................................................................................5
Related documentation...................................................................................5
Definition of used terms..................................................................................5
1. Introduction..........................................................................................6
2. Technical parameters..........................................................................7
2.1. Possible variants ..........................................................................................12
2.2. Dimensions...................................................................................................13
2.3. Recommended drawing symbol ...................................................................14
2.4. Block diagram...............................................................................................15
3. Product marking ................................................................................16
3.1. Producer type label.......................................................................................17
4. Conformity assessment ....................................................................18
4.1. Other tests....................................................................................................19
5. Processor modules............................................................................20
5.1. Master processor module.............................................................................20
5.2. Auxiliary processor module ..........................................................................20
6. Power supply......................................................................................21
6.1. Computer start up and shut down.................................................................22
6.1.1 SB input is used............................................................................................22
6.1.2 SB input is not used......................................................................................23
7. Digital inputs / outputs......................................................................24
8. Communication lines and peripherals.............................................25
8.1. Ethernet........................................................................................................26
8.1.1 10/100 Mbps connection ..............................................................................26
8.1.2 1000 Mbps connection .................................................................................27
8.1.3 Ethernet line state indication ........................................................................27
8.2. WiFi..............................................................................................................28
8.2.1 Transmission speed .....................................................................................28
8.2.2 Connection of antennas................................................................................28
8.2.3 WiFi state indication .....................................................................................29
8.3. LTE...............................................................................................................30
8.3.1 SIM...............................................................................................................30
8.3.2 LTE state indication......................................................................................30
8.4. CDMA...........................................................................................................31
8.4.1 CDMA state indication..................................................................................31
8.5. GPS / GLONASS..........................................................................................32
8.6. USB..............................................................................................................32
9. Service peripherals............................................................................33
9.1. USB..............................................................................................................33
9.2. HDMI............................................................................................................33
9.3. DVI ...............................................................................................................34
9.4. RS232 ..........................................................................................................34

WRTB1XX
wrtb1xx_g_en_105 4/42
10. Indication elements ...........................................................................35
10.1. System LEDs................................................................................................35
11. Packing ...............................................................................................36
12. Storing.................................................................................................37
13. Mounting, installation rules ..............................................................38
13.1. Mounting instructions....................................................................................38
13.2. Cabling.........................................................................................................38
13.3. Mounting apertures.......................................................................................39
14. Ordering information and completion .............................................40
14.1. Ordering information.....................................................................................40
14.2. Completion ...................................................................................................40
14.3. Connectors...................................................................................................40
14.4. Spare parts...................................................................................................40
15. Maintenance .......................................................................................41
16. Waste disposal...................................................................................42

WRTB1XX
5/42 wrtb1xx_g_en_105
History of revisions
Document name: wrtb1xx_g_en_105.pdf
Revision
Date
Author of change
Changes
100
15. 01. 2015
Škoch J.
New document
101
09. 07. 2015
Škoch J.
Digital input/output parameters change in chapters 2 and 7
102
04. 01. 2016
Škoch J.
Power supply switching and interruption parameters
update, battery module information update, safety
classification update, stating peak current values added,
packing and storing chapters added.
103
20. 04. 2016
Škoch J.
Conformity assessment classification update for EN 61000-
4-4:2012
Added new product variants.
Added WiFi interface description.
Revised ordering information.
104
05.05.2016
Pužman O.
Modem frequency range updated.
Added new product variant WRTB1AC03420A
105
11. 05. 2017
Pužman O.
Adjusted information about digital outputs
Added new product variant WRTB1EC04420A
Related documentation
1. Application Note AP0037 –Principles of using Ethernet network
file: ap0037_en_xx.pdf
2. SP_MB247720 –Backup battery module –datasheet
file: sp_mb247720_d_en_xxx.pdf
3. http://www.msc-technologies.eu/ –manufacturer of the MSC Q7-BT CPU core
Definition of used terms
3GPP Long Term Evolution –high speed internet for mobile networks
Code Division Multiple Access –transmission of multiple digital signals on one
medila
LTE
CDMA

WRTB1XX
wrtb1xx_g_en_105 6/42
1. Introduction
WRTB1xx is a family of LTE routers, used in railway applications for providing
internet access using 2G/3G/4G technology. Within the railway installation, the
router connects to local LAN network via Ethernet cable. Hereinafter in the text
it will be referred to as router.
Router contains the Master processor module with Intel Atom processor
(Master CPU hereinafter) and an Auxiliary processor module with processor
Cortex (Aux CPU hereinafter), which ensures the supplementary router
functions.
Router is supplied without application. Application is loaded by user during
installation of the device.
▪CPU Intel Atom E3815 1.46 GHz
▪2 GB DDR3L RAM
▪4 GB eMMC FLASH
▪RTC, RAM and BIOS CMOS backup by battery, optional
▪1 × to 6 × Ethernet 1 Gbps M12 (switch), according to variant
▪0 × to 2 × WiFi, IEEE 802.11.a/b/g/n/(ac), SISO, MIMO (2 × 2), according to
variant
▪0 × to 1 × CDMA 450 MHz (Telefónica O2), according to variant
▪1 × to 4 × 2G/3G /4G modem, according to variant
▪1 × to 4 × SIM cards for each LTE modem
▪2 × USB 2.0
▪1 × GPS / Glonass
▪1 × RS232 serial service interface
▪1 × USB service interface
▪1 × HDMI or DVI service interface
▪Power supply with GI and nominal input voltage of 24 V DC or 24/36 V DC
depending on variant
▪LED indicators for all interfaces
▪Mounting on base plate
▪Rolling stock electronic device
▪Design according to EN 50155:2007
Router is designed so that operates immediately after switching on within the
whole operating temperature range, without need of tempering.
Router is designed to be used with Linux operating system.
Basic features

WRTB1XX
7/42 wrtb1xx_g_en_105
2. Technical parameters
Processor core
Intel Atom E3815 1.46 GHz, 2 GB DDR3L,
4 GB eMMC FLASH
Battery type
Panasonic BR2477 Lithium battery
Battery lifetime
5 years
Number of connectors
1 × to 6 × 1)
Number of interfaces
1 × to 2 ×
Interface configuration
1 × LAN
0 × to 5 × switch
Galvanic isolation
Yes, 1000 V AC / 1 minute 2)
Data transmission rate
10 Mbps / 100 Mbps / 1 Gbps
Recommended cabling
STP CAT6
Maximum segment length
100 m
Operation indication
2 × LED (LNK and ACT)
Connection point
8-pin M12 connector, X-coding
Standards
IEC61375-1:2007
Number of interfaces
2 ×
Communication standards
802.11a/b/g/n or
802.11a/b/g/n/ac
Frequency band
2.4 GHz or 5 GHz
Encryption
64/128 bits WEP, WPA, WPA2, 802.1x
Supported signal transmission
SISO, MIMO 2×2
Maximum output power
19 dBm
Internal WiFi module interface
PCIe
Operation indication
LED
Recommended cabling
Coaxial cable 50 Ω
Maximum cable length
10 m
Connection point for one interface
2 × R-SMA
Quantity
1 ×
Type
GPS / GLONASS
Operation indication
No
Recommended antenna type
GPS with LNA
Recommended cabling
Coaxial cable 50 Ω
Maximum cable length
10.5 m 3)
Connection points
SMA
CPU
RAM + RTC
back-up
Ethernet
WiFi
GPS

WRTB1XX
wrtb1xx_g_en_105 8/42
Quantity
1 × to 4 ×
Communication standarts
2G / 3G / 4G
EGSM class 10 / UMTS / HSPA+ / LTE
2G frequency [MHz]
900 / 1800
3G frequency [MHz / Band]
900 / BdVIII
1800 / BdIII
2100 / BdI
LTE frequency [MHz / Band]
800 / Bd20
900 / Bd8
1800 / Bd3
2100 / Bd1
2600 / Bd7
HSPA Downlink / Uplink [Mbps]
42 / 5.7
LTE Downlink / Uplink [Mbps]
100 / 50
Additional functions
SMS / GPRS class 10 / GSM
Diversity reception
Yes
Number of SIM / modem
1 × to 4 × SIM cards
Operation indication
2 × LED (LNK and ACT)
Recommended cabling
Coaxial cable 50 Ω
Maximum cable length
5.5 m
Connection point
2 × SMA for each LTE modem
Quantity
0 × to 1 ×
Communication standards
CDMA2000 1xEV-DO 450 MHz
class 5, block H
SIM
O2 integrated
Operation indication
2 × LED (LNK and ACT)
Recommended cabling
Coaxial cable 50 Ω
Maximum cable length
5.5 m
Connection point
2 × SMA
Quantity
2 ×
USB version
USB 2.0
Operation indication
No
Galvanic isolation
No
Data transmission rate
12 Mbps / 480 Mbps
Recommended cabling
Shielded USB cable
Maximum cable length
3 m
Connection point
USB connector type A, socket
Quantity
1 ×
Operation indication
No
Galvanic isolation
No
Data transmission rate
600 bps to 256 kbps
Recommended cabling
Shielded cable
Maximum cable length
3 m
Connection point
Connector D-sub DE-9 plug
Modem
CDMA modem
USB
Service RS232

WRTB1XX
9/42 wrtb1xx_g_en_105
Quantity
1 ×
USB version
USB 2.0
Operation indication
No
Galvanic isolation
No
Data transmission rate
12 Mbps / 480 Mbps
Recommended cabling
Shielded USB cable
Maximum cable length
3 m
Connection point
USB connector type B, socket
Quantity
0 × or 1 ×4)
Operation indication
No
Galvanic isolation
No
Recommended cabling
Shielded cable
Maximum cable length
3 m
Connection point
Connector Micro HDMI, socket
Quantity
0 × or 1 ×4)
Configuration
One channel
Operation indication
No
Galvanic isolation
No
Recommended cabling
Shielded cable
Maximum cable length
3 m
Connection point
Connector DVI, socket, UNC 4-40
Quantity
0 × to 2 ×
Type 4)
Digital input / output
24 V DC (16.8 V to 30 V DC)
24 / 36 V DC (16.8 V to 45 V DC)
Maximum input level for log. 0
4.5 V
Minimum input level for log. 1
12.5 V
Log. 0 output voltage
0 V
Log. 1 output voltage
Power supply voltage
Maximum output current
0.3 A for 24 V DC variant
1.5 A for 24/36 V DC variant
Galvanic isolation
Yes, 1000 V AC / 1 minute 2)
Connection point
WAGO 769-106/021-000
Wire cross section
0.75 mm2to 1.5 mm2
Nominal power supply voltage 6)
24 V DC
24 / 36 V DC
Power supply voltage range 6)
16.8 V to 30 V DC
16.8 V to 45 V DC
Maximum power consumption
0.6 A
Starting peak current 7)
250 A / < 200 µs
Connection cable Cu: 2 × 2.5 mm2× 30 cm)
90 A / < 200 µs
Connection cable Cu: 2 × 0.75 mm2× 2.5 m)
Galvanic isolation
Yes, 1000 V AC / 1 minute 2)
Connection point
WAGO 769-106/021-000
Wire cross section
0.75 mm2to 1.5 mm2
Service USB
Service HDMI
Service DVI
Inputs /
outputs
Power supply

WRTB1XX
wrtb1xx_g_en_105 10/42
Mechanics
Metal cover
Colour
RAL 9005
Ingress protection rate
IP30
Mounting
On the base plate
Mounting apertures
4 × hole ø 5.5 mm
Weight 8) –netto
–brutto
2.56 kg to 2.58 kg ±10 %
2.96 kg to 3.12 kg ±10 %
Dimensions (w × h × d)
(325 × 75 × 175) mm
Unit overall mass of plastics
Max. 430.6 g
Included mass of self-extinguishing
plastics
Max. 430.6 g
Device does not contain
PUR, PVC, Asbestos
Device conforms
2011/65/EU (ROHS)
1907/2006EU (REACH)
Operating temperature range
-40 °C to 70 °C
Storage temperature range
-40 °C to 70 °C
Maximum ambient humidity
< 95 % non-condensing
Reliability (MTBF) min
300 000 h, with 45 °C of ambient temperature
Lithium battery
Unit is supplied without application.
Control unit is intended to operate up to 1 400 m above the sea level.
Control unit is designed to meet the Temperature Class TX.
According to EN 61373:2010 standard, the control unit is classified in terms of
vibrations into Category 1, Class A (mounting to vehicle body).
Permissible supplying voltage drop-outs duration: no interruptions (Class S1
according to Chapter 3.1.1.2 of EN 50155:2007).
For supply voltage switching –conditions of C1 Class are permissible.
The device is not classified according to EN 50128:2011 Railway applications –
Communications, signalling and processing systems –Software for railway control
and protection systems.
The device is not classified according to EN 50129:2003 Railway applications –
Communication, signalling and processing systems –Safety related electronic
systems for signalling.
1) 2 × separate Ethernet controller. One connector is always on integrated
controller of main CPU, other 0 to 5 connectors are located on dedicated
controller of 5 port switch.
2) Galvanic isolation must not be used for dangerous voltage separation.
3) The length is only valid when using antenna with integrated LNA.
4) Only one connector is fitted –either HDMI or DVI.
Mechanics
Dangerous
materials
Temperatures
Others
Components
with reduced
lifetime
Software
Claims of EN
50155:2007
Safety
classification
Note

WRTB1XX
11/42 wrtb1xx_g_en_105
5) Output current is determined by power voltage of the router and its range is
identical with the range of power voltage of the router.
6) Power supply range for specific router variant is specified in the chapter 2.1.
7) Values are valid for nominal power supply voltage.
8) Weight of specific variant is specified in the chapter 2.1.

WRTB1XX
wrtb1xx_g_en_105 12/42
2.1. Possible variants
WRTB1xx router can be supplied in following variants that differs in power
supply voltage and number of peripherals.
Name
Ethernet
WiFi
a/b/g/n
WiFi
a/b/g/n/ac
WRTB1ACA33201
4 ×
0 ×
0 ×
WRTB1AD043201
3 ×
0 ×
0 ×
WRTB1CC034201
4 ×
2 ×
0 ×
WRTB1CAA44211
6 ×
2 ×
0 ×
WRTB1AC03420A
4 ×
0 ×
0 ×
WRTB1EC04420A
4 ×
0 ×
2 ×
Name
CDMA
LTE
SIM / LTE
WRTB1ACA33201
1 ×
3 ×
3 ×
WRTB1AD043201
0 ×
4 ×
3 ×
WRTB1CC034201
0 ×
3 ×
4 ×
WRTB1CAA44211
1 ×
4 ×
4 ×
WRTB1AC03420A
0 ×
3 ×
4 ×
WRTB1EC04420A
0 ×
4 ×
4 ×
Name
Battery
module
Digital
I/O
Video
Output
WRTB1ACA33201
No
2 ×
HDMI
WRTB1AD043201
No
2 ×
HDMI
WRTB1CC034201
No
2 ×
HDMI
WRTB1CAA44211
No
2 ×
HDMI
WRTB1AC03420A
No
0 ×
HDMI
WRTB1EC04420A
No
2 ×
DVI
Name
Weight
netto
Weight
brutto
Power
supply
Power supply
range
WRTB1ACA33201
2.58 kg
3.12 kg
24 V DC
+16.8 V to 30 V DC
WRTB1AD043201
2.58 kg
2.96 kg
24 V DC
+16.8 V to 30 V DC
WRTB1CC034201
2.56 kg
3.04 kg
24 V DC
+16.8 V to 30 V DC
WRTB1CAA44211
2.56 kg
3.04 kg
24 V DC
+16.8 V to 30 V DC
WRTB1AC03420A
2.56 kg
3.04 kg
24 / 36 V DC
+16.8 V to 45 V DC
WRTB1EC04420A
2.56 kg
3.04 kg
24 / 36 V DC
+16.8 V to 45 V DC

WRTB1XX
13/42 wrtb1xx_g_en_105
2.2. Dimensions
295
75
325
131
134
175
Fig. 1 - Router mechanical dimensions

WRTB1XX
wrtb1xx_g_en_105 14/42
2.3. Recommended drawing symbol
Following drawing symbol is recommended for this router. Variants of drawing
symbol for router different variants are available on AMiT web site. This drawing
symbol is particularly for WRTB1ACA33201.
PE
VCC
GND
X1 - PWR
WRTB1ACA33201
4
5
6
SB3
DIO12
DIO21
X21
X2
ETH1
M12 8-pin, X-coded
X20
GPS
SMA
X3
ETH2
M12 8-pin, X-coded
X4
ETH3
M12 8-pin, X-coded
X5
ETH4
M12 8-pin, X-coded
X10
USB1
USB A
USB2
USB A
X11
RS232
D-sub DE-9
LTE1 TX/RX
SMA
X22
LTE1 RX DIV
SMA
X23
LTE2 TX/RX
SMA
X24
LTE2 RX DIV
SMA
X25
LTE3 TX/RX
SMA
X26
LTE3 RX DIV
SMA
X29
CDMA TX/RX
SMA
X30
CDMA RX DIV
SMA
Fig. 2 - Recommended drawing symbol

WRTB1XX
15/42 wrtb1xx_g_en_105
2.4. Block diagram
Power
input
I210 SWITCH WiFi 1 WiFi 2
X2 X3 X4 X5 X6 X7 X12 X13 X15 X16
Temperature
sensor
EEPROM
SATA
FLASH CFAST
USB
HDMI
RS232
USB
SATA
SATA
PCIe
I2C
USB
X10
X11
LAN SWITCH WiFi WiFi USB
Main CPU
X1
Power
I/O
LTE 1
+ GPS
A B
CD
LTE 2
A B
CD
LTE 3
A B
CD
LTE 4
A B
CD
CDMA
X21 X22 X24X23 X26X25 X28X27 X30X29
SIM SIM SIM SIM
X20
GPS LTE LTE LTE LTE LTE LTE LTE LTE CDMA
Auxiliary
CPU
Power
internal
POWER CTL
PCIe
PCIe
USB
HUB
USB
USB
HUB
USB USB USB USB USB
POWER CTL
USB
Fig. 3 - WRTB1xx block diagram

WRTB1XX
wrtb1xx_g_en_105 16/42
3. Product marking
WRTB1xx is fitted with producer type label.
Location of labels, see Fig. 4 - Location of label on router cover.
WEIGHT:
2.06 kg
DATE:
09.06.2015
MAC:
xx-xx-xx-xx-xx-xx
HiPot:
HiPot - OK
TEST:
OK-JP
POWER:
24 V DC / 0.5 A
S/N:
xxxxxxx
TYPE:
WRTB1XX
1
Fig. 4 - Location of label on router cover
Number
Description
1
Type label
Legend

WRTB1XX
17/42 wrtb1xx_g_en_105
3.1. Producer type label
The unit has a producer type label attached to its rear side. Data located on
type label are listed in the table above, for example of label design see Fig. 5 -
Example of AMiT type label.
Description
Data
Note
–
Logo AMiT
Producer logo
–
QR code
Producer QR code
TYPE
WRTB1xx
Product type designation
S/N
xxxxxxx
Serial number
MAC X2
xx-xx-xx-xx-xx-xx
MAC address
MAC X3
xx-xx-xx-xx-xx-xx
MAC address
POWER
24 V DC / 0.5 A
Power supply voltage /
Consumption
WEIGHT
2.06 kg
Weight
TEST
OK-xx
Routine testing result
HiPot
HiPot-OK
HiPot test result
Date
dd.mm.yyyy
Production date
–
Logo CE
The product is in compliance
with EU legislation and directives
–
Crossed out dustbin logo
Disposal of the product is
a subject to regulations on the
disposal of electronic waste
WEIGHT 2.06 kg
DATE 09.06.2015
MAC X2 xx-xx-xx-xx-xx-xx
HiPot HiPot - OK
TEST OK-JE
POWER 24 V DC / 0.5 A
S/N xxxxxxx
TYPE
WRTB1xx
MAC X3 xx-xx-xx-xx-xx-xx
Fig. 5 - Example of AMiT type label

WRTB1XX
wrtb1xx_g_en_105 18/42
4. Conformity assessment
Providing, that router is correctly used, it complies with the requirements of
Czech governmental decree NV616/2006. The conformity assessment has
been carried out in accordance with harmonized standard EN 50121-3-2:2006.
Tested in accordance
with standard
Type of test
Classification
EN 55011:2009
Industrial, scientific and medical
equipment –Radio-frequency
disturbance characteristics –Limits and
methods of measurement
Complies
EN 61000-4-2:2009
Electromagnetic compatibility (EMC) –
Part 4-2: EMC –Testing and
measurement techniques –Indirect
electrostatic discharge immunity test,
contact discharge
±8 kV
EN 61000-4-2:2009
Electromagnetic compatibility (EMC) –
Part 4-2: EMC –Testing and
measurement techniques –Indirect
electrostatic discharge immunity test,
aerial discharge
±16 kV
EN 61000-4-3:2006
Electromagnetic compatibility (EMC) –
Part 4-3: Radiated, radio-frequency,
electromagnetic field immunity test,
800 MHz to 1000 MHz
20 V/m
EN 61000-4-3:2006
Electromagnetic compatibility (EMC) –
Part 4-3: Radiated, radio-frequency,
electromagnetic field immunity test,
1400 MHz to 2100 MHz
10 V/m
EN 61000-4-3:2006
Electromagnetic compatibility (EMC) –
Part 4-3: Radiated, radio-frequency,
electromagnetic field immunity test,
2100 MHz to 2500 MHz
5 V/m
EN 61000-4-4:2012
Electromagnetic compatibility (EMC) –
Part 4-4: Testing and measurement
techniques –Electrical fast transient/burst
immunity test, power supply
±3 kV
EN 61000-4-4:2012
Electromagnetic compatibility (EMC) –
Part 4-4: Testing and measurement
techniques –Electrical fast transient/burst
immunity test, input
±2 kV
EN 61000-4-5:2006
Electromagnetic compatibility (EMC) –
Part 4-5: Testing and measurement
techniques –Electrostatic discharge
immunity test
±4 kV
EN 61000-4-6:2009
Electromagnetic compatibility (EMC) –
Part 4-6: Testing and measurement
techniques –Immunity to conducted
disturbances, induced by radio-frequency
fields
10 V

WRTB1XX
19/42 wrtb1xx_g_en_105
4.1. Other tests
Router has been assessed and approved for use in railway applications
according to standards:
Tested in accordance
with standard
Type of test
Result
EN 50155:2007
Railway applications –Electronic
equipment used on rolling stock
Complies
EN 50121-3-2:2006
Railway applications –Electromagnetic
compatibility (EMC) –Part 3-2 Rolling
stock –equipment
Complies
EN 61373:2010
Railway applications –Rolling stock
equipment –Shock and vibration tests.
Category 1,
Class B
EN 61000-4-29:2000
Electromagnetic compatibility (EMC) –Part
4-29: Testing and measurement
techniques –Voltage dips, short
interruptions and voltage variations
immunity tests
S1, C1
EN 60068-2-1:2007
Environmental testing –Part 2-1: Tests –
Test A: Cold
Complies
EN 60068-2-2:2007
Environmental testing –Part 2-2: Tests –
Test B: Dry heat
Complies
EN 45545-2:2013
Railway applications –Fire protection on
railway vehicles
HL3

WRTB1XX
wrtb1xx_g_en_105 20/42
5. Processor modules
5.1. Master processor module
For master CPU, router uses a processor module with CPU Intel Atom.
The core contains processor Intel® Atom™ E3815 2 GB DDR3L, 4 GB eMMC.
For more details see the MSC Q7 module datasheet on manufacturer's website
(see Related documentation).
Master CPU module is equipped with eMMC (NAND flash) type memory.
Therefore, when keeping the memory lifetime in mind it is recommended to
minimize the number of writing cycles.
5.2. Auxiliary processor module
Router contains an Auxiliary CPU with CORTEX processor.
Auxiliary CPU controls modems and GPS.
The Auxiliary CPU communicates with Master CPU by Auxiliary processor
commands. By using these commands it’s possible:
▪Find-out FW version
▪Control modem power supply
Core
Flash memory
Supplies
management
Auxiliary
processor
commands
