Amped Wireless TITAN-AP APA1900 User manual

User’s Guide
APA1900
TITAN-AP
HIGHPOWERTM AC1900
WI-FI®ACCESS POINT

APA1900
USER’S GUIDE
1
CONTENTS
INTRODUCTION.....................................................................2
GETTING STARTED.................................................................3
Package Contents...................................................................... 3
LED Indicators............................................................................ 4
Back Panel Description.............................................................. 6
PLUG AND PLAY SETUP GUIDE ...............................................8
Connect the Access Point to your Router.................................. 8
Connect your PC to the Access Point......................................... 9
Open your Web Browser to Access the Setup Wizard............. 11
Welcome to the Setup Wizard ................................................ 12
5.0GHz WIRELESS SETTINGS................................................. 17
Basic Settings........................................................................... 17
Guest Networks....................................................................... 19
Security Settings...................................................................... 20
Wi-Fi Protected Setup –WPS .................................................. 21
User Access ............................................................................. 22
Wireless Coverage Controls..................................................... 23
Access Schedule ...................................................................... 23
Advanced Settings................................................................... 25
2.4GHz WIRELESS SETTINGS................................................. 26
Basic Settings........................................................................... 26
Guest Networks....................................................................... 28
Security Settings ......................................................................29
Wi-Fi Protected Setup –WPS...................................................30
User Access..............................................................................31
Wireless Coverage Controls .....................................................32
Access Schedule.......................................................................32
Advanced Settings....................................................................34
NETWORK SETTINGS............................................................35
USB STORAGE......................................................................37
USB Storage: Local Sharing ......................................................37
MANAGEMENT FEATURES ...................................................41
System Clock............................................................................42
System Logs .............................................................................43
Upgrade Firmware...................................................................44
Save/Reload Settings ...............................................................46
Password Settings....................................................................47
TECHNICAL SPECIFICATIONS.................................................48
DEFAULT SETTINGS..............................................................49
TROUBLESHOOTING AND SUPPORT INFORMATION..............50
WARRANTY AND REGULATORY INFORMATION ....................61
LEGAL NOTICES AND DISCLAIMERS.......................................70

APA1900
USER’S GUIDE
2
INTRODUCTION
Thank you for purchasing this Amped Wireless product. At Amped Wireless we strive to provide you with the
highest quality products through innovation and advanced technology. We pride ourselves on delivering
products that outperform the competition and go beyond your expectations. If you have any questions please
feel free to contact us. We’d love to hear from you and thank you for your support!
Email: [e-mail]
Call: 888-573-8830
Web: www.ampedwireless.com

APA1900
USER’S GUIDE
3
GETTING STARTED
Package Contents
Check to make sure you have all the contents within your package:
TITAN-AP –High Power AC1900 Wi-Fi Access Point
Four Detachable High Gain Antennas
RJ-45 Ethernet Cable
Power Adapter
Setup Guide
CD: User’s Guide, Setup Guide, Wi-Fi Analytics Android/Windows App

APA1900
USER’S GUIDE
4
LED Indicators
Power/WPS: Indicates when the Access Point is powered on. The LED will remain on. Blinks when Wi-Fi
Protected Setup (WPS) is activated and the Access Point awaits a connection.
5.0GHz Wireless Activity: Blinks rapidly when wireless data traffic is transmitted or received over the 5GHz
wireless network.
2.4GHz Wireless Activity: Blinks rapidly when wireless data traffic is transmitted or received over the 2.4GHz
wireless network.
Network Connection: Indicates when the Access Point is connected to a network. The LED will blink rapidly
when network traffic is transmitted or received.
USB Connection: Indicates when a USB storage device is connected to either of the USB ports.

APA1900
USER’S GUIDE
5
Gigabit Wired Ports 1-4: Indicates when a networking device is connected to a wired port on the back
of the Access Point. The LED will blink rapidly when wired data traffic is transmitted or received. The
green LED displays when a there is an active gigabit connection.

APA1900
USER’S GUIDE
6
Back Panel Description
From Left to Right
Antenna Connectors: RJ-SMA antenna connectors. Attach the included high gain antennas to these
connectors.
Power On/Off: Push to turn the Access Point on or off.
Power: Power adapter port. Output: 12V 2.5A, Input: 100-240v.
USB Port: Attach USB storage devices, such as USB flash drives and external hard drives, for file sharing. A USB
3.0 port is located on the right side panel of the Access Point for faster connections.
Wired Devices: Gigabit RJ-45 ports for connecting to wired computers or network devices.
Network: Gigabit RJ-45 port for connecting to an available port on your network router or switch.

APA1900
USER’S GUIDE
7
Power: Power adapter port. Output: 12V 1.5A, Input: 100-240v.
LED On/Off: Push to turn LED indicators on or off.
WPS: Hold down for 3 seconds to enable WPS push button configuration.
Reset: Push down once to reboot the Access Point. Hold down for 5-10 seconds to reset the Access Point back
to factory settings.

APA1900
USER’S GUIDE
8
PLUG AND PLAY SETUP GUIDE
Connect the Access Point to your Router
a) Attach the antennas to the antenna connectors on the Access Point
b) Plug in the Power Adapter
c) Using the included RJ-45 Ethernet cable, attach one end to the Access Point’s NETWORK port and the other to
your router’s network port (or any available port on a network switch)

APA1900
USER’S GUIDE
9
Connect your PC to the Access Point
Connecting Wirelessly:
With your PC or Mac, scan for available wireless networks and locate the wireless networks for the Access
Point:
By default the Access Point will have SSIDs with the names:
Amped_TitanAP_2.4 and Amped_TitanAP_5.0
The default WPA security key is: wireless

APA1900
USER’S GUIDE
10
Wired Connections:
Attach any wired devices to the Access Point using Ethernet
cables.
Your Plug and Play setup is now complete. You may now use
the Access Point to access your network.

APA1900
USER’S GUIDE
11
Open your Web Browser to Access the Setup Wizard
a. Open your web browser
b. Type in: http://setup.ampedwireless.com into the web address bar
c. If the web menu fails to open, type in the following IP address into your web address bar:
http://192.168.80.240

APA1900
USER’S GUIDE
12
Welcome to the Setup Wizard
If this is your first time setting up the Access Point, the Setup
Wizard should automatically load.
If you wish to manually configure your Access Point you can
also choose to skip the Setup Wizard.
Double check that the Access Point is connected to your
network router or switch port.
Check that your antennas are all attached firmly to the antenna
connectors.
Click Next to continue.
If the Dashboard loads (see right image) instead of the Setup
Wizard, scroll to the bottom and click the Setup Wizard button
to access the Wizard.

APA1900
USER’S GUIDE
13
Network Connection Detection
The Wizard will try to detect your network settings. Please
be patient.
If there is a problem with the Automatic Configuration, the
wizard will notify you of the issue. If you continue to have
problems, contact our Elite Support department at 888-
573-8820.
If the network detection was successful, you will see a
green check mark.
Click Next to continue.

APA1900
USER’S GUIDE
14
Personalize your Wi-Fi Settings
The default SSID of the Access Point is
“Amped_TitanAP_2.4” and “Amped_TitanAP_5.0”
To change it, enter a new name in the SSID field.
Users connecting wirelessly to the Access Point will
use this ID to identify your wireless network.
Depending on the capabilities of your wireless
adapter, you may connect to either the 2.4 or
5.0GHz wireless networks.
The default Security Key (WPA/WPA2 Mixed Mode)
of your wireless network(s) is: wireless
To change it, enter a new key in the Security Key field. The key must be a minimum of 8 characters.
Click Next to continue.

APA1900
USER’S GUIDE
15
Create a Password for your Access Point
This password is NOT your Wi-Fi connection password.
This password is to access the web menu of the Access
Point to configure additional settings. Leave this blank
if you do not wish to have a password.
Click Apply to save your settings. The Access Point will
reboot. This process may take up to 1 minute. The page will automatically reload after the countdown. If it
does not, you may need to refresh the page manually or check your connection to the Access Point.

APA1900
USER’S GUIDE
16
Setup Summary
Once the Access Point has rebooted, it will
load the Setup Summary page and provide
you with the details of your setup.
Print the Setup Summary details and save it
for future reference.
If you have any wired devices that you would like to attach to the Access Point you may do so now as well.
Enjoy your Amped Wireless network.

APA1900
USER’S GUIDE
17
5.0GHz WIRELESS SETTINGS
5.0GHz Wi-Fi Settings: Basic Settings
The Basic Settings page allows you to adjust settings for your 5GHz
local wireless network.
Disable 5.0GHz Wireless Connections: Disabling will turn off all
5GHz Wi-Fi activity. Users will no longer be able to connect
wirelessly to your 5GHz network.
Band: Select the compatible Wi-Fi standard and speed for your
wireless network.
Broadcast SSID: Selecting Disable Broadcast SSID will hide the
visibility of the Access Point’s 5GHz network SSID. Users must
manually enter the SSID to connect.
Wi-Fi Network ID (SSID): The name of your 5GHz wireless network.

APA1900
USER’S GUIDE
18
Channel Number: Wi-Fi networks operate on specific wireless channels. Some network channels may have
more interference than others. If your performance is unstable, try a different channel number. If you are
using a repeater with this network, it is recommended you set a static channel, instead of using "Auto".
WMM: Prioritizes multimedia data over the wireless network.
Associated Clients: Shows the active users connected wirelessly to your 5GHz network.
Tx Beamforming: Enable or disable Beamforming capabilities with Beamforming capable devices to increase
Wi-Fi connection reliability and range.

APA1900
USER’S GUIDE
19
5.0GHz Wi-Fi Settings: Basic Settings: Guest Networks
Guest Networks: You may add additional names (SSID) to
your Wireless Network with different characteristics for each
SSID.
Each additional Network or SSID can have its own unique
security key that can be configured from the Security settings
page.
Associated Clients: View all computers and network devices that are connected to your network wirelessly.
