amperis TC706 User manual
AMPERIS PRODUCTS
USER MANUAL
Gas Detection Thermal Imaging Camera
AMPERIS TC706
GAS DETECTION THERMAL IMAGING CAMERA
AMPERIS TC706
www.amperis.com
3support: info@amperis.com | t (+34) 982209920
Warnings and precautions ……....… 04
Introduction ……… 05
Accesories ……………… 06
Functions ……… 07
Functions and key interface……..............................................................................................…08
Operations ……… 11
Battery - Install /Uninstall ……...................................................................................................…11
Battery - Change battery………..................................................................................................................................12
Quick Guide - Get infrared imaging………........................................................................................................13
Quick Guide - Temperature measurement…....................................................................……14
Quick Guide - Freeze and save image - Playback - Export - Led screen sets……......…16
Quick Guide - Menu operating instructions…..................................................................……17
Quick Guide - Graphic interface description - Screen graphic interface……..............…18
Shortcut key interface……..............................................................................................................…19
Measurement Object Adding………........................................................................................20
Recording…….....................................................................................................................................…21
Photo…….............................................................................................................................................…22
Settings….........................................................................................................................................……23
General setting……........................................................................................................................…24
General setting - Temperature measurement setting…….............................................…29
General setting - Adjustment…...........................................................................................……31
General setting - Image settings….....................................................................................……32
General setting - Network settings….................................................................................……35
General setting - SD card management……........................................................................…36
General setting - Capture setting…….....................................................................................…37
General setting - System settings…….....................................................................................…38
General setting - System settings - System Version Info…...........................................……39
General setting - File management - Playback….............................................................……40
General setting - File management - Delete……..................................................................…41
Troubleshooting…............................................................................................................................……42
Appendix A - Common material emissivity FYI……..................................................................…43
Appendix B - Factory default parameter setting table…....................................................……44
CONTENTS TABLE
www.amperis.com
4support: [email protected] t (+34) 982209920
WARNINGS AND PRECAUTIONS
• Infrared gas leak temperature imager uses a very sensitive thermal sensor, so in any case (power on or off) shall
Otherwise it will cause permanent damage to the Infrared Gas Leak Detector Imager.
• Do not strongly shake or hit the equipment during transportation and use.
• It is recommended to use the original packing box when storing the equipment, and place it in a cool, dry,
•
close the lens cap.
• It is recommended to backup. In order to prevent the potential danger of data loss, please copy (backup) the data
to the computer frequently.
• An infrared gas leak detector may require 8-10 minutes of warm-up before the data can be read accurately.
• Each Infrared Gas Leak Detector has been calibrated at the factory. Temperature correction is recommended
every year.
• Do not open the cabinet or modify it. The maintenance can only be carried out by our authorized personnel.
GAS DETECTION THERMAL IMAGING CAMERA
www.amperis.com
5support: info@amperis.com | t (+34) 982209920
INTRODUCTION
Thank you for choosing TC 706 infrared gas leak detection thermal imager.
TC 706 infrared gas leak detection thermal imager is infrared system, long-wave infrared quantum
well focal plane array detector, electronic processing systems and image processing software,
the infrared radiation measurement object is converted to visual thermal images, to long-range
target surface temperature, is a fast, accurate, non-contact detection of live equipment and other
micro-leakage and thermal fault of advanced measuring instruments. The brand of the camara is Dali
or Dali TC706.
www.amperis.com
6support: [email protected] t (+34) 982209920
ACCESSORIES
Standard
• TC 706 infrared gas leakage thermal imager
• Shoulder strap
• Safety box
• Lens cap
• Li-on Battery(2pcs)
• Charger
• Video output cable
• Power adapter
• SD Card
• SD Card reader
• User manual
• Network cable (Mini-USB to RJ45)
Optional
• Wide angle lens
• Telephoto lens
• Tripod
www.amperis.com
7support: [email protected] t (+34) 982209920
FUNCTIONS
TC 706 have below functions:
• 11 color pallet
• 11 language
• 1-8x digital zoom
• 10 movable spot temperature measurement
• 5 movable area temperature measurement
• 2 line temperature measurement
• Shortcut customization
• Auto focus
• Electrical focus
• Power saving mode
• LCD brightness adjustment
• Video output NTSC or PAL
• Network settings
• Time/date settings
• Factory reset
• SD card unloading, formatting
• SD card capture, video storage
• Capture voice or text annotations
• Snapshot continuous shooting
• Alarm catch
• Alarm video
• Isothermal function
• Temperature setting
• Gas leak detection and jitter mode
• Built-in common material ratio emissivity selection table
• CMOS visible image and storage
• Infrared and visible light image fusion
• Integration of high and low temperature
www.amperis.com
8support: [email protected] t (+34) 982209920
FUNCTION KEYS AND INTERFACE
# Name Function
1 Power button Press this switch for more than three seconds to turn on / off the camera.
Note: after shutting down, turn on the boot again at least 20 seconds to ensure that the thermal imager is safe
2 Menu /
button
3 Cancel / Auto
• Long press for more than 3 seconds, IR, auto mode auto focus.
4
to delete the item.
5 Select / Auto
• Color pallet
the current image and is the default color of the next boot.
• Upper and lower limits
manual mode.
www.amperis.com
9support: [email protected] t (+34) 982209920
FUNCTION KEYS AND INTERFACE
# Name Function
6 F1 custom
7 F2 shortcut
lights.
8 F3 shortcut
9 Microphone
www.amperis.com
10 support: [email protected] t (+34) 982209920
FUNCTION KEYS AND INTERFACE
# Name Function
11
interface
12 Power
interface
13
14
www.amperis.com
11 support: [email protected] t (+34) 982209920
OPERATION
Battery - Install /Uninstall
Install: Insert the battery with the end of the
battery into the battery compartment, pushing the
battery until the battery lock is locked;
Uninstall: Remove the battery by pressing the two
snap buttons on the rear end of the battery to the
center and then pulling it out.
When inserting the battery, please pay attention to
the shape of the battery face down, if the opposite
direction can not be inserted, do not force too much
damage to the instrument or battery.
Note: The instrument should use the standard
battery, otherwise the battery size and voltage
may be incorrect, and damage the mechanical or
electrical performance of the instrument.
3. WARNING:
• Never disassemble, incinerate or puncture battery ; • Never short circuit the battery; • Keep battery dry
• Keep out of reach of children ; • Always dispose of battery in accordance with local, state and federal regulations
Open the battery cover: slide down the battery cover button; push the battery cover to close the battery cover.
www.amperis.com
12 support: [email protected] t (+34) 982209920
OPERATION
Battery - Change battery
• Batteries should be stored in an ambient
temperature of -4°F (–20°C) to 67.9°F (+20°C).
Lithium batteries will self-discharge during storage,
so they should be fully charged before storage.
Self-discharge may affect long term battery
performance. Furthermore, it is recommended
that the battery should be charged in a set time, as
below;
Ambient temperature of:
1. -4°F (–20°C) to 67.9°F (+20°C), once every 6
months
2. 67.9°F (+20°C) to 113°F (+45°C), once every 3
months
3. 113°F (+45°C) to 149°F (+60°C), once every
month
• Battery should have greater than 50% charge prior
to recharge.
• The ambient temperature for charging should be
32°F (0°C) to 104°F (+40°C). If under 32°F (0°C),
the battery capacity will be diminished; if over 104°F
(+40°C), the battery may overheat, resulting in
permanent damage.
3. WARNING:
• Never disassemble, incinerate or puncture battery ; • Never short circuit the battery; • Keep battery dry
• Keep out of reach of children ; • Always dispose of battery in accordance with local, state and federal regulations
When the battery is empty and blinks for about 1 minute and 50 seconds, the instrument displays a low battery message and
shuts down automatically after about 10 seconds.
Battery safety and usage
www.amperis.com
13 support: [email protected] t (+34) 982209920
OPERATION
Quick Guide - Get infrared imaging
3. WARNING:
• Focusing is not clear and can cause measurement errors
• After installing the battery, press the thermal imager power switch (more than 3 seconds) until
the boot screen appears. After about 15 minutes, the instrument is initialized and entered into
the working state.
• Open the lens cover, aim at the target, adjust the focal length of the camera, so that the target
image is clear.
• Press the “A” key for automatic calibration to obtain the best thermal image
• Move the target object to the cross temperature point on the screen, and the “XX” displayed
in the upper right corner of the screen is the temperature of the target at the temperature
measurement point. If you want to temperature more accurate, you can press the “A” key for 3
seconds after the measurement.
• If you want to display the thermal image on the current screen for detailed temperature
measurement, you can press the “S” key to freeze the image, and then analyze. You can also press
the “S” key to store the thermal image and analyze it
• When the target temperature is greater or less than the upper or lower temperature
will show> XXX ° C or <XXX ° C to prompt the user
• If you need to modify the properties of the temperature measurement object,
!
the Enter key, the screen is displayed on the temperature object properties
"#
measurement, temperature measurement area of the property dialog box:
# -
tance and reference object, left and right keys to choose, press the A key to switch up and down.
When the “reference object” option is changed to “on”, the temperature value displayed by
other temperature measurement objects is the temperature difference from the temperature
www.amperis.com
14 support: [email protected] t (+34) 982209920
#
-
ta
ta
nc
nc
e
e
an
an
d
d
reference o
b
je
t
ct
,
le
le
ft
ft
a
a
nd
nd
rig
h
t
k
eys to c
ho
os
e,
e
p
p
re
re
ss
ss
t
t
h
eA
k
ey to switc
h
up an
d
d
do
do
wn
wn
.
.
Wh
W
en the “re
fe
re
nc
nc
e
e
ob
ob
je
je
ct” option is
ch
h
an
n
ge
ge
d
d
to
to
“
on”, the tempera
tu
re
v
v
al
al
ue
ue
d
d
isplayed by
ot
h
er te
mp
p
er
er
at
at
ur
ur
e
e
measuremen
t
t
ob
ob
je
je
ct
ct
s
s
is t
h
etempera
tu
t
re
re
d
d
if
if
fe
fe
re
nce from t
h
e tempe
ra
ra
tu
tu
re
re
OPERATION
Quick Guide - Temperature measurement
The temperature line is divided into the upper and lower pages. The properties of the tempera-
ture measurement line can modify the ratio, the distance, the maximum temperature, the lowest
temperature, the average temperature, the maximum temperature difference, the intersection
temperature and the reference object, the left and right keys, Switch up and down. When the “ref-
erence object” option is changed to “on”, the temperature value displayed by other temperature
measurement objects is the temperature difference from the temperature
The properties of the temperature measurement area can modify the ratio, distance, maximum
temperature, minimum temperature, average temperature, maximum temperature difference and
reference temperature, left and right keys to choose, press the A key to switch up and down. When
the “Reference object” option is changed to “On”, the temperature value displayed by other tem-
perature measurement objects is the temperature difference with the temperature measurement
result of this temperature measurement area.
www.amperis.com
15 support: [email protected] t (+34) 982209920
re
r
su
l
t of t
h
is tem
p
era
tu
tu
re
re
m
m
ea
e
surement are
a.
OPERATION
Quick Guide - Temperature measurement
NOTE: Infrared thermal imager can only set one reference temperature measurement target
• Press the Enter key to select the “Photo” option in the menu, the system will automatically save
the image
• Press the “S” key to freeze the image and press it again to store it.
• By setting the shortcut key to “take pictures” option, press the shortcut key to save the image
• Press enter key to activate the main menu, select “File Manager” menu , then select the submenu
(via the arrow keys to select)
• $%&'
keys to switch selection)
• After you open the image, you could use upper and lower sections of the playback control panel
keys to playback the current store images.
• Press Cancel key to exit and return to the current state.
$#(
• 1. Press Menu key to activate the main menu. Choose
adjustment to adjust LED screen brightness.
• 2. Set shortcut key to LCD brightness adjustment to adjust LED screen brightness
www.amperis.com
16 support: [email protected] t (+34) 982209920
OPERATION
Quick Guide - Freeze and save image - Playback - Export - Led screen sets
Note:
It is recommended to use the thermal camera curing formatting capabilities in software for SD card format
•
interface.
•
the submenu.
•
to enter the lower menu
•
•
•
• Cancel and return to the previous menu button. Save and return to the previous
menu button. (For touch screen)
•
www.amperis.com
17 support: [email protected] t (+34) 982209920
OPERATION
Quick Guide - Menu operating instructions
www.amperis.com
18 support: [email protected] t (+34) 982209920
OPERATION
Quick Guide - Graphic interface description - Screen graphic interface
No. Name Description
1 Company ogo
2 Emissivity the current emissivity setting
3 Reference Temperature Fixed reference temperature
4 Resu t Indicates the temperature va ue of the target object. B ack and
ye ow denotes the temperature va ue of the se ected object.
5 Spot temperature measurement white crosshair
6 System time the current system time
7 Battery status Indicates the current battery status.
8 Manua /auto enhancement mode choose manua or auto mode
9 Min temperature indicate minimum va ue of the pa ette
10 Pa ette pa ette bar. User can choose different pa ettes
11 Ca ibration/freeze
indicate the ca ibration status or freeze status
12
13 B uetooth se ect B uetooth function
14 Lens 0.5x or 2x
15 Record current record status. Continuous capture mark
Record mark
16 SD card indicate the TF card oad status
17 Mode switch
current mode: IR mode CCD mode fusion mode
from left to right, up to down is adding spot,
adding line, adding area, delete, taking photo,
record, playback and main menu
Main menu interface
The main menu items: display the main menu
item, namely the document management,
temperature settings, image settings, camera
settings, general settings, network settings, SD
card management and system settings
Sub-menu interface
www.amperis.com
19 support: [email protected] t (+34) 982209920
OPERATION
Shortcut key interface
No. Name Description
1 Figure name Disp ays the name of the dia og box. The name of the dia og box
as shown in the examp e is “temperature measurement setting.
2 Item tit e A dia og box may contain more than one item. As shown in the
" %
3 Item Content each item corresponds to the content of a project, the eft and
right keys to make changes, “> indicates the ower menu.
4 Parameter options press the eft button to se ect a different parameter.
#
measurement objects. Press the Enter key, activate the shortcut key interface, select the
temperature measurement target to add and press the Enter key, the following dialog box pops up
If choosing !
www.amperis.com
20 support: [email protected] t (+34) 982209920
OPERATION
Measurement Object Adding
Note:
When deleting a single temperature measurement object, you can directly press the “A” key to select the
temperature measurement object, and then press the “C” key to delete
Table of contents
